Vollrath Mirage 59500 Operating And Safety Instructions Manual
Operating and Safety
Instructions
Induction Range
Model Description Voltage HZ Watts Plug
59500 Countertop – Single 120 60 1800 5-15P
59500
Thank you for purchasing this Vollrath Mirage™ Induction range. Before operating this unit, read and familiarize yourself with
the following operating and safety instructions. SAVE THE ORIGINAL BOX AND PACKAGING. They should be used to ship
the unit if repairs are needed. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
WARNING
ELECTRIC SHOCK, FIRE OR BURN INJURIES CAN
OCCUR IF THIS EQUIPMENT IS NOT USED
PROPERLY. TO REDUCE RISK OF INJURY:
FUNCTION AND PURPOSE
This unit is intended to be used with induction ready
cookware (see below) with a flat, magnetic base measuring
4.5 inches (11.5 cm) through 14 inches (26 cm).
ENGLISH
Plug only into grounded electrical outlets
matching the nameplate rated voltage.
Do not leave an empty pan on an operating unit.
Unit should only be used in a flat, level position.
Unplug unit and let it cool before cleaning or
moving.
Do not touch cooking surface. It remains hot
after the unit is turned off.
Do not spray controls or outside of unit with
liquids or cleaning agents.
Unplug when not in use.
Keep induction unit and power cord away from
open flames, electric burners or excessive heat.
Do not heat sealed cans or containers as they
may explode.
Handle hot cookware carefully.
Do not place any objects inside the air intake or
exhaust panels.
Do not operate unattended.
Closely supervise units operating in public areas
and/or around children.
Do not operate if unit has been damaged or is
malfunctioning in any way.
Do not place weight on the front control knob.
INDUCTION READY COOKWARE
Iron
Cast iron
Ferrous stainless steel
UNSUITABLE COOKWARE
Cookware with a diameter of less than 4.5”
Pottery, glass, aluminum, bronze or copper
cookware
Cookware with any type of footed base
INSTALLATION
This unit is to be used on a flat, level surface. The unit is not
designed to be enclosed or built into any area.
IMPORTANT: There must be a minimum of 4” (10 cm) of
space between the induction range and any surrounding
surface to allow sufficient airflow around the unit. Blocking
the airflow could overheat the unit.
Item No. OSI00002 Rev. 11/06
OPERATING AND
SAFETY INSTRUCTIONS
Mi
rage™ Induction Range
BEFORE USING YOUR
INDUCTION RANGE
As a precaution for persons wearing a pacemaker,
please stand back 12 inches (30 cm) from an operating
unit. Studies have shown that the induction element
presents no danger.
The cooking surface is made of a strong, non-porous
material. However, should it crack or break, stop using
and immediately unplug the unit.
Do not place spoons, kitchen utensils, pan lids or other
small objects on the cooking surface while the unit is
operating, as they may become hot. The unit is
equipped with a “small object detector” to prevent
small objects from accidentally heating if placed alone
on the cooking surface. However, if they are placed on
the cooking surface with a suitable piece of cookware
that activates the unit, the smaller object may also
become hot.
ENGLISH
WARNING
BURN HAZARD
The cooking surface gets very hot.
Hot surfaces and hot cookware can burn
skin. Allow the induction range and any
cookware to cool before handling.
Keep all credit cards, driver licenses and other items
with a magnetic information strip away from the unit.
The unit’s magnetic field will damage the information
on these strips.
OPERATION
1. Place the induction range on a flat, stable surface.
2. Plug the power cord into a grounded electrical outlet
with the matching nameplate rated voltage.
IMPORTANT: Do not preheat empty cookware. Because of
the speed and efficiency of the induction range, cookware
can very quickly overheat and be damaged.
IMPORTANT: Using a voltage other than the nameplate
rated voltage will cause damage to the unit.
WARNING
ELECTRICAL SHOCK HAZARD
Keep water from entering the inside
of the unit. If liquid spills or boils over
onto the unit, immediately unplug the unit
and wipe up any liquid. The liquid could
enter the electrical compartment and
cause an electrical shock.
3. Place induction-ready cookware containing food in the
center of the hob.
IMPORTANT: Do not drop cooking utensils or other
objects onto the cooking surface. The strong, non-porous
material will break. The warranty does not cover this type of
abuse.
Front Control Panel
59500 shown
4. Press the power ON/OFF button. The power level LED
within the display window will light. When an
appropriate pan is placed on the range, the display will
remain on, indicating that the unit is heating.
The unit will start in the power mode when it is first
turned on. Turning the unit off and on with the ON/OFF
button will not reset the control power or temperature
setup from the previous operation.
5. Press the POWER/TEMP button to choose between
power control mode and temperature control mode. The
power control mode will display a number from 1 to
100, indicating 1% to 100% of rated power. In the
temperature control mode, the display will show the
selected temperature. Two LED lights to the right of the
display window will indicate the selected temperature
in degrees Fahrenheit or degrees Celsius. Turning the
rotary knob clockwise will increase the power or
temperature. Turning the rotary knob counterclockwise
will decrease power or temperature.
6. Press the TIMER button to activate the timer function.
When first activated, a number "1" will display in the
window and a "timer" indicator will light up near the
lower right hand corner of the display. Turning the
rotary knob clockwise will increase the time up to a
maximum of 180 minutes. Turning the rotary knob
counterclockwise will decrease the time down to a
minimum of one minute. When the timer cycle is
complete, the unit will automatically shut off. To
cancel the timer, push the POWER/TEMP button. The
timer will be cancelled and the unit will go back to the
power or temperature setting.
Item No. OSI00002 Rev. 11/06 Page 2
Mirage™ Induction Range
OPERATING AND
SAFETY INSTRUCTIONS
WARNING
BURN HAZARD
Induction ranges heat extremely
fast, much faster than most other types of
stovetops or ranges. Be very careful when
adding food to preheated oil, liquid or
other food already in the cookware. Hot
food and liquids can burn skin.
IMPORTANT: Do not heat cookware on the unit without
something to be heated in the pan. Because of the speed and
efficiency of the induction range, the cookware can develop
an excessive amount of heat very quickly and damage the
cookware and non-stick coatings.
The unit is equipped with an overheating protection device.
If the temperature of the top plate gets too hot, the unit will
shut down until the top plate cools. The heating indicator
will flash to indicate the over heating protection function is
on.
7. The unit will continuously display the power level
when an appropriate pan is placed on the unit. If the
power display is flashing, the cookin g ut en si l m ay not
be suitable.
8. While in use, it will not harm the unit to remove the
cooking utensil for a short time. If the unit is left on for
more than one minute without a pan, the unit will turn
off automatically.
CLEANING
To maintain the appearance and increase the service life,
clean your induction range daily.
1. Unplug the unit and let it completely cool.
WARNING
BURN HAZARD
The cooking surface gets very hot.
Hot surfaces and hot cookware can burn
skin. Allow the induction range and any
cookware to cool before handling.
WARNING
ELECTRICAL SHOCK HAZARD
Do not spray water or cleaning
products. Liquid could enter the electrical
compartment and cause a short circuit or
electric shock.
2. Wipe the unit exterior with a clean damp cloth.
3. Do not use abrasive materials, scratching cleansers or
souring pad to clean the unit. These can damage the
finish.
4. Thoroughly wipe off any mild soap or chemical
cleaners. Chemical residue could corrode the surface of
the unit.
ENGLISH
TROUBLESHOOTING
If It might be caused by Course of Action
The unit turned off after one minute. If the induction range is left on for more than
one minute without a pan or if unsuitable
cookware is used, the unit will automatically
shut off.
The unit is on but not heating. The cookware may be too small or may not
be induction ready.
The digital display lights are flashing. The overheat protection feature may have
been activated.
The unit suddenly stopped working. The unit may have stopped working from
excessive internal temperature.
Check the cookware you are using and
make sure it falls within the guidelines for
induction ready cookware listed on page
one of this manual.
Check the cookware you are using to make
sure it falls within the guidelines for
induction ready cookware.
Remove cookware. Let cooking surface
cool.
Relocate the unit away from any external
heat source. Clear any obstructions to the
air intake.
Page 3 Item No. OSI00002 Rev. 11/06
OPERATING AND
Mira
SAFETY INSTRUCTIONS
ge™ Induction Range
REPAIR
There are no user serviceable parts within this appliance. To avoid serious injury or damage, never attempt to repair the induction
range or replace a damaged power cord yourself. Do not send units directly to the Vollrath Company. Please contact the qualified
professional repair service listed below.
Vollrath Induction Repair Service • 1-800-825-6036
When contacting the Authorized Professional Service Center, please be ready with the model number, serial number, and proof of
purchase showing the date the unit was purchased.
WARRANTY POLICY FOR THE VOLLRATH CO. L.L.C.
The Vollrath Company L.L.C. warranties all products it manufactures and distributes against defects in materials and
workmanship for a period of one year from date of purchase, except as listed below:
Refrigeration compressors – five year warranty
Replacement parts – 90 (ninety) days on the part only
Fry pans and coated cookware – 90 (ninety) days
ENGLISH
Cayenne
Additional 1 year warranty on heating element (parts
only)
®
Heat Strips – 1 year parts and labor.
Jacob’s Pride® Collection
The Vollrath Co., L.L.C. offers a Limited Lifetime Warranty to all products in our Jacob’s Pride Collection.
NSF Certified One-Piece Dishers
NSF Certified Spoodle
NSF Certified Heavy-Duty Spoons with Ergonomic Handle
NSF Certified Heavy-Duty Basting Spoons
One-Piece Tongs*
*Jacob’s Pride® Warranty does not cover Kool-Touch® Coating and GatorGrip® handles.
All warranties cover normal use and service only and are void if the product has been damaged by accident, neglect, improper use
or other causes not arising out of defects in materials or workmanship. The Vollrath Company shall not be liable for loss of use of
the product or other incidental or consequential costs, expenses, or damage incurred by the purchaser.
Warranty work must have prior approval from The Vollrath Company L.L.C. See the operating and safety instructions for each
specific product for warranty claim procedures.
®
Heavy-Duty One-Piece Ladles*
Nylon Handle Whips
One-Piece Skimmers
Classic Select
®
and Intrigue® Cookware
INDUCTION RANGE WARRANTY INFORMATION
The Vollrath Company will warranty the Mirage™ Induction Range for a period of one (1) year in accordance with the policy
stated above. Any damages from improper use, abuse or damage resulting from improper packaging during return shipment for
warranty repair will not be covered under warranty.
The Vollrath Company, L.L.C.
1236 North 18
Sheboygan, WI 53082-0611
1-800-825-6036
Item No. OSI00002 Rev. 11/06
th
Street
