CAUTION: Read manual carefully for
proper procedures and operation.
USER’S MANUAL
PURIFIES UP TO 1500 SQUARE FEET
FRESHAIR
BOX
Congratulations on your new FreshAir Box
Your FreshAir Box comes with a detachable power cord (9950099)
and remote control (9950100).
________________________________________ ________________________________________
Vollara Independent Business Owner Name Phone Number
2
wElcOmE
rear cover
front grill
control pad rear filter
power in
Meet your FreshAir Box
3
IntROductIOn
Where to put your FreshAir Box
For best results, place your FreshAir Box as
high up as possible, with at least
2 inches of clearance on either side.
You can also place your FreshAir Box in
trouble areas for extra eectiveness.
4
plAcEmEnt
CAUTION: Do not operate the FreshAir Box near heat source, open flames, or
combustible vapors or gases.
Plug power supply into the back
of the FreshAir Box and into a
standard wall outlet.
5
pOwER Supply
Electrical:
• 100 - 240v AC
• 21 watts power consumption
• 3-speed fan
Size:
• Dimensions:
16.5cm wide x 16.5cm high x 17.8cm deep
• Weight: 1.36 kg
SpEcIFIcAtIOnS
Red LED solid = Away Mode (returns to Normal Mode after 2 hours or user
input is detected, whichever comes first)
Green LED solid = scalable ozone setting
The control pad is
conveniently located
on the right side of
your FreshAir Box
on/o power
fan speed +
fan speed -
away mode
green & red LED
6
cOntROl pAd And lEd lIGHtS
Press the POWER button to turn the unit on and off.
Press the FAN buttons to adjust the 3 speed fan.
Push the “AWAY MODE” button once and the unit
will go into Away Mode.
Indicator light will be illuminated red.
Push the “AWAY MODE” button a second time and the
unit goes into the Scalable Ozone Mode.
When the unit is in the Scalable Ozone Mode, the
indicator light will be illuminated green.
In the Scalable Ozone Mode, the FreshAir Box unit will operate in a 20%-on, 80%-off mode,
over a one minute total cycle time. This means the unit will continuously cycle the ozone
plate on, at maximum output, for 12 seconds and then transition to ozone plate off for
48 seconds ... then repeat.
Push the button again, and the unit will revert to the “Normal” operation Mode (ActivePure only).
Operating your FreshAir Box
7
cOntROl pAd InFORmAtIOn
CAUTION: Away Mode is intended for unoccupied spaces only. Please be sure all
people and pets have vacated the area when Away Mode is in use.
control panel
The FreshAir Box remote control gives you the convenience of control from anywhere
in the room. Before use, remove paper tab from the bottom of the remote. When
replacing battery, choose a 3 Volt lithium cell CR2025.
on/o power
Away Mode
+ fan speed
- fan speed
8
REmOtE cOntROl
Replacement parts
If your unit fails to operate properly or you have questions, contact your Vollara
Independent Business Owner for further assistance.
9
purifier plate
9950096
power cord
9950099
ActivePure
®
(RCI) cell
9950097
remote control
9950100
rear filter
9950098
pARtS
shown with rear cover removed
every month every year every 3 years part numbers
clean front grill
clean rear filter
9950098
clean purifier plate
9950096
replace ActivePure (RCI) cell
9950097
replace purifier plate
9950096
Caring for your FreshAir Box
Upkeep
Periodically vacuum or wipe the front grill with
a soft towel. You can vacuum or wash the rear
filter in warm water and let dry completely
before reinstalling (replace if necessary). Wipe
down the outside with a damp (not wet) cloth.
Reassemble when finished.
10
mAIntEnAncE
CAUTION: Always unplug the power cord from the back of your FreshAir Box
before servicing. Removing cover may expose ultraviolet light source. To protect
against eye damage, always unplug before servicing.
NOTE: Improper maintenance or failure to maintain the FreshAir Box according to
these instructions may damage the unit or cause the unit to operate incorrectly.
How to change the cell
Unplug unit. (1) Remove the back panel screws and (2) back panel. (3) Press
latches and (4) unplug the power connector to the ActivePure
®
(RCI) cell.
(5) Pull the ActivePure cell straight out to remove. Reverse order to replace cell.
11
REpAIR And upkEEp
CAUTION: Always unplug the power cord from the back of your FreshAir Box
before servicing. Removing cover may expose ultraviolet light source. To protect
against eye damage, always unplug before servicing.
1
2
3
4
5
How to change purifier plate
12
REpAIR And upkEEp
CAUTION: Always unplug the power cord from the back of your FreshAir Box
before servicing. Removing cover may expose ultraviolet light source. To
protect against eye damage, always unplug before servicing.
Unplug unit. (1) Remove the back panel screws and (2) back panel.
(3) Press latches and (4) unplug the power connector to the purifier plate.
(5) Remove the purifier plate from its slot. Reverse order to replace purifier plate.
1
2
3
4
5
Unplug unit. (1) Remove the back panel screws and (2) back panel. (3 - 5) Remove the
purier plate from its slot. (6) Clean purier plate by wiping with a cotton swab dipped
in denatured alcohol. Allow purifier plate to dry completely before reinstalling.
How to clean the purifier plate
13
REpAIR And upkEEp
CAUTION: Always unplug the power cord from the back of your FreshAir Box
before servicing. Removing cover may expose ultraviolet light source. To protect
against eye damage, always unplug before servicing.
1
2
3
4
5
6
How to disassemble your FreshAir Box for cleaning
(1) Remove back cover. (2) Remove ActivePure cell (see page 11). (3) Remove
purifier plate (see page 12). (4) Remove the four front grill screws and the front grill.
You can now access the inside of the unit and the fan for cleaning.
14
dEEp clEAnInG
CAUTION: Always unplug the power cord from the back of your FreshAir Box
before servicing. Removing cover may expose ultraviolet light source. To protect
against eye damage, always unplug before servicing.
1 2
3
4
Name: Vollara Co. Ltd.
Model: FreshAir Box
This device complies with
Part 18 of the FCC Rules.
RESPONSIBLE PARTY
Vollara, LLC
5420 LBJ Freeway, Suite 1010
Dallas, TX 75240
Ph: (800) 989-2299
Signature:________________________
Printed Name: Andy Eide
Title: Vice President, Product
Development & Research
Date: 05/01/12
This equipment has been tested and found to
comply with the limits for Industrial, Scientific,
and Medical Equipment (ISM), pursuant to
Part 18 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses,
and can radiate radio frequency energy, and if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio
or television, which can be determined
by turning the equipment o and on, the
user is encouraged to try to correct the
interference by one or more of the following
measures: Reorient or relocate the receiving
antenna. Increase the separation between
the equipment and receiver. Connect the
equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
Consult the Distributor or an experienced
radio/TV technician for help.
15
Fcc dEclARAtIOn OF cOnFORmIty
lImItEd OnE (1) yEAR wARRAnty
Customer should not repackage and ship the FreshAir Box unit due
to possibility of irreparable damage. For warranty service, please
contact Vollara Customer Service at 800.989.2299, or your Vollara
Independent Distributor, for the address of the nearest service center.
wHAt IS cOVEREd By tHIS wARRAnty
We warrant the FreshAir Box to the Customer, subject to the
conditions below, against defects in workmanship or material,
provided that the products are returned to a service location within
one (1) year from the date of purchase.
InStAllAtIOn And mAIntEnAncE REQuIREmEntS
This warranty is expressly conditioned upon proper installation,
operation, cleaning and maintence, all in accordance with the
Owner’s Manual. Failure to meet any of these requirements will void
this warranty. Servicing of your FreshAir Box by parties other than
our authorized service center and/or using parts other than genuine
parts will also void this warranty.
HOw tO OBtAIn wARRAnty SERVIcE
Customer must contact Vollara Customer Service and provide proof
of purchase within the above time period. We will repair or replace
and return the product, without charge and within a reasonable
period of time, subject to the conditions herein, if its examination shall
disclose any part to be defective in workmanship or material. If we,
in our discretion, are unable to repair the product after a reasonable
number of attempts, we will provide either a refund of the purchase
price or a replacement unit, at the company’s option.
wHAt IS nOt cOVEREd By tHIS wARRAnty
This product is intended for household use only. Ordinary wear and
tear shall not be considered a defect in workmanship or material.
These warranties do not apply to filters nor for loss or damage
caused by accident, fire, abuse, misuse, improper installation, leaking,
modification, misapplication, commercial use or by any repairs other
than those provided by our authorized Service Center. This warranty
is non-transferable.
mISSInG SERIAl numBERS & unAutHORIZEd cHAnnElS
If a valid serial number is missing from the product, the warranty will
be voided. Vollara products are authorized for sale through Vollara
Independent Distributors only. Warranties are voided if a product is
purchased through unauthorized channels. This includes websites
that are not authorized to use Vollara’s trademarked names, images
and logos as well as Internet auction sites (e.g. ebay and Craigslist).
The only approved Internet presence for Vollara products is www.
vollara.com. To confirm warranty coverage prior to purchasing a
product, contact Vollara at 800.989.299 with the serial number
located on the back of the unit.
EXcluSIOn OF OtHER wARRAntIES & cOndItIOnS
EXCEPT AS PROVIDED HEREIN, WE MAKE NO REPRESENTATION
OR WARRANTY OF ANY KIND. ALL OTHER WARRANTIES OF
ANY KIND, EXPRESS OR IMPLIED, ARE HEREBY EXPRESSLY
DISCLAIMED, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
lImItAtIOn OF lIABIlIty FOR SpEcIAl, IncIdEntAl, OR
cOnSEQuEntIAl dAmAGES
WE SHALL NOT IN ANY CASE BE LIABLE FOR SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM
BREACH OF EXPRESSED OR IMPLIED WARRANTIES, CONDITIONS,
GUARANTEES OR REPRESENTATIONS, BREACH OF CONTRACT,
NEGLIGENCE OR ANY OTHER LEGAL THEORY. Such excluded
damages include, but are not limited to, loss of profits or revenue, and
loss of the use of the products, and any loss caused by leaks or other
water damage. This warranty is provided by:
Vollara, LLC
5420 LBJ Freeway, Suite 1010
Dallas, TX 75240.
SERVIcE
Every eort is made to ensure customers receive an up-to-date
instructions manual on the use of our products; however, from time
to time, modifications to our products may without notice make
the information contained herein subject to alteration. For the latest
information, please visit our website.
lImItEd OnE (1) yEAR wARRAnty
Customer should not repackage and ship the FreshAir Box unit due to possibility of irreparable damage. For
warranty service, please contact your Independent Distributor for the address of the nearest service center.
65-00432 VA-00314
© 2012 Vollara, LLC. All Rights Reserved.
FAB_OM_65-00432_VA-00314_0512
Loading...
