VOKERA Compact HE, Compact 25 HE, Compact 29 HE, Compact 35 HE Installation & Servicing Instructions Manual

Supplied By www.heating spares.co Tel. 0161 620 6677

Compact HE

High efficiency combi boiler

Installation & Servicing Instructions

THESE INSTRUCTIONS TO BE RETAINED BY USER

Vokèra is a licensed member of the Benchmark scheme which aims to improve the standards of installation and commissioning of domestic hot water systems in the UK.

Supplied By www.heating spares.co Tel. 0161 620 6677

Contents

Design principles and operating sequence Page

1.1 Principle components 2

1.2 Mode of operation (at rest) 2

1.3 Mode of operation (heating) 2

1.4 Mode of operation (DHW) 2

1.5 Safety devices 2

Technical data Page

2.1 Central heating 3

2.2 Domestic hot water 3

2.3 Gas pressure 3

2.4 Expansion vessel 3

2.5 Dimensions 3

2.6 Clearances 3

2.7 Connections 3

2.8 Electrical 3

2.9 Flue details 3

2.10 Efficiency 3

2.11 Pump duty 4

2.12 Appliance 4

General requirements (UK) Page

3.1 Related documents 5

3.2 Location of appliance 5

3.3 Gas supply 5

3.4 Flue system 5

3.5 Air supply 5

3.6 Water circulation 5

3.6.1 Pipework 6

3.6.2 Automatic by-pass 6

3.6.3 Drain cocks 6

3.6.4 Air release points 6

3.6.5 Expansion vessel 6

3.6.6 Filling point 6

3.6.7 Low pressure sealed system 6

3.6.8 Frequent filling 6

3.7 Electrical supply 6

3.8 Showers 6

3.9 Mounting on a combustible surface 7

3.10 Timber framed building 7

3.11 Inhibitors 7

General requirements (EIRE) Page

3.A1 Related documents 8

3.A2 Location of appliance 8

3.A3 Gas supply 8

3.A4 Flue system 8

3.A5 Air supply 8

3.A6 Water circulation 8

3.A6.1 Pipework 8

3.A6.2 Automatic by-pass 8

3.A6.3 Drain cocks 8

3.A6.4 Air release points 8

3.A6.5 Expansion vessel 8

3.A6.6 Filling point 9

3.A6.7 Low pressure sealed system 9

3.A6.8 Frequent filling 9

3.A7 Electrical supply 9

3.A8 Showers 9

3.A9 Mounting on a combustible surface 9

3.A10 Timber framed building 9

3.A11 Inhibitors 9

3.A12 Declaration of conformity 9

Installation Page

4.1 Delivery 10

4.2 Contents 10

4.3 Unpacking 10

4.4 Preparation for mounting the appliance 10

4.5 Fitting the flue 10

4.5.1 Concentric horizontal flue 10

4.5.2 Concentric vertical flue 11

4.5.3 Twin flue system 12

4.6 Connecting the gas and water 14

4.6.1 Gas 14

4.6.2 Flow and return 14

4.6.3 Cold water inlet 14

4.6.4 Hot water outlet 1 4

4.6.5 Safety valve 14

4.6.6 Condense pipe 14

4.7 Electrical connections 14

4.7.1 Casing removal 1 5

4.7.2 Appliance terminal block 15

4.7.3 Connecting the mains (230V) input 15

Commissioning Page

5.1 Gas supply installation 16

5.2 The heating system 16

5.3 Initial filling of the system 16

5.4 Initial flushing 16

5.5 Filling the hot water system 16

5.6 Pre-operation checks 16

5.7 Initial lighting 16

5.7.1 Checking burner pressures 16

5.8 Final flushing of the heating system 16

5.8.1 Inhibtors 16

5.9 Setting the boiler operating temperature 16

5.9.1 Setting the DHW temperature 17

5.10 Setting the system design pressure 17

5.11 Regulating the hot water 17

5.11.1 Changing the flow restrictor 17

5.11.2 Regulating the central heating system 17

5.12 Final checks 17

5.13 Instructing the user 17

Servicing instructions Page

6.1 General 18

6.2 Routine annual servicing 18

6.3 Replacement of components 18

6.4 Component removal procedure 18

6.5 Pump assembly 18

6.6 Safety valve 18

6.7 Automatic air release valve 19

6.8 Water pressure switch 19

6.9 Pressure gauge 19

6.10 Primary thermistor 19

6.11 High limit thermostat 1 9

6.12 PCB 19

6.13 Gas valve 19

6.14 Integral time switch 20

6.15 Electrode, burner thermostat, burner & injectors 20

6.16 Flue fan 21

6.17 Main heat exchanger 21

6.18 Air pressure switch 21

6.19 Flow restrictor 21

6.20 DHW flow switch 22

6.21 DHW heat exchanger 22

6.22 Valve actuator 2 2

6.23 Divertor valve cartridge 22

6.24 DHW thermistor 22

6.25 Automatic by-pass 2 2

6.26 DHW non-return valve 22

6.27 Expansion vessel 22

6.27.1 Expansion vessel removal (with sufficient clearance above) 22

6.27.2 Expansion vessel removal (with insufficient clearance above) 23

6.28.1 Latent heat collector 23

6.28.2 Dismantling the latent heat collector 23

6.28.3 Retarder 23

6.29 Condense trap removal 24

Checks, adjustments and fault finding page

7.1 Checking appliance operation 2 4

7.2 Appliance mode of operation 24

7.2.1 Selector switch in the OFF position 24

7.2.2 Selector switch in the hot water only position 24

7.2.3 Selector switch in the heating & hot water position 24

7.2.4 Appliance functions 24

7.2.5 DHW mode 24

7.2.6 Heating mode 25

7.3 Checking & adjusting burner pressure 2 6

7.3.1 Setting the maximum burner pressure 26

7.3.2 Setting the minimum burner pressure 26

7.3.3 Setting the minimum CH output 26

7.4 Combustion analysis test 26

7.5 Checking the expansion vessel 27

7.6 External faults 27

7.6.1 Installation faults 27

7.7 Electrical checks 27

7.7.1 Earth continuity test 27

7.7.2 Short circuit check 27

7.7.3 Polarity check 27

7.7.4 Reversed polarity or supply fault 28

7.7.5 Resistance to earth check 28

7.8 Fault finding 28

7.8.1 Replacing the main PCB 28

7.9 Fault codes 28

7.10 Fault finding 29-34

Wiring diagrams Page

8.1 External wiring 35

8.2 Typical control applications 35

8.3 Vokera remote control 35

8.4 Room thermostat 35

8.5 Other controls 35 Functional diagram 36

Exploded diagrams Page

Table 1-5 37-41

L.P.G. instructions Page

10.1 Related documents 42

10.2 Technical data 4 2

10.3 Converting the appliance gas supply 42

10.4 Gas supply 4 2

10.5 Gas supply installation 42

10.6 Checking & adjusting burner pressure 4 2

10.6.1 Setting the maximum burner pressure 42

10.6.2 Setting the minimum burner pressure 42

Supplied By www.heating spares.co Tel. 0161 620 6677

INTRODUCTION

The Compact HE range of appliances is comprised of 2 models of high-efficiency combination boiler with inputs to heating & DHW of 25, 29 & 35kW respectively. Each appliance - by design - incorporates electronic ignition, circulating pump, expansion vessel, safety valve, pressure gauge, and automatic by-pass.

The Compact HE range is produced as room sealed, category II2H3P appliances, suitable for internal wall mounting applications only. They are provided with a fan

powered flue outlet with an annular coaxial combustion air intake that can be rotated - horizontally - through 360 degrees for various horizontal or vertical applications. The Compact HE range can also be used with the Vokera twin flue system. The Compact HE range is approved for use with C12 & C32 type flue applications. These appliances are designed for use with a sealed system only; consequently they are not intended for use on open vented systems

Fig.1 General Layout

1 Diverter valve motor 2 Discharge valve 3 Domestic hot water heat exchanger 4 Safety valve 5 Pump 6 Pressure switch 7 Auto air vent (AAV) 8 Electrode 9 Main burner 10 Main heat exchanger 11 Latent heat collector 12 Flue gas analysis test point 13 Flue outlet 14 Air intake 15 Differential pressure switch 16 Silicone pressure tube (-) 17 Silicone pressure tube (+) 18 Fan assembly 19 CH NTC sensor 20 Combustion chamber 21 High limit thermostat 22 Expansion vessel 23 Condensate pressure switch 24 Ignition transformer 25 Condense trap 26 Modulator coil 27 Gas valve 28 DHW flow switch

Fig. 1

29 30 31 32 33 34

29 Pressure gauge 30 DHW temperature selector 31 Mode selector switch 32 Status fault/indicator led 33 CH temperature selector 34 Timeclock

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 1 DESIGN PRINCIPLES AND OPERATING SEQUENCE

1.1 PRINCIPLE COMPONENTS

● A fully integrated electronic control board fea-

turing electronic temperature control, anti-cycle control, pump over-run, LED fault indicator, full gas modulation.

● Low-water-content, copper heat exchanger.

● Electronic ignition with flame supervision.

● Integral high-head pump.

● Fan.

● Air pressure switch.

● Expansion vessel.

● Water pressure switch.

● Two-stage gas valve.

● Pressure gauge.

● Safety valve.

● Condense switch.

1.2 MODE OF OPERATION (at rest)

When the appliance is at rest and there are no requests for heating or DHW, the following functions are active:

● Frost-protection system - the frost-protection

system protects the appliance against the risk of frost damage. Should the temperature of the appliance fall to 5 °C, the boiler will function in the heating mode at minimum power until it reaches 35 °C.

● Anti-block function - the anti-block function

enables the pump and divertor valve actuator, to be energised for short periods, when the appliance has been inactive for more than 19hours.

expansion

vessel

AAV

valve motor

safety valve

Fig. 2

pump

diverter

automatic

by-pass

latent heat

collector

return

flow

flue

outlet

DHW heat exchanger

intake

gas valve

DHW outlet

air

pressure

switch

main heat

exchanger

CH NTC

sensor main

burner

DHW tempera-

ture sensor

DHW non

return valve

flow switch

Domestic cold water inlet

water

pressure

switch

DHW

1.3 MODE OF OPERATION (Heating)

When there is a request for heat via the time clock and/or any external control, the pump and fan are started, the fan will then prove the air pressure switch. At this point an ignition sequence is enabled.

Ignition is sensed by the electronic circuitry to ensure flame stability at the burner. Once successful ignition has been achieved, the electronic circuitry increases the gas rate to 75% for a period of 15 minutes. Thereafter, the boiler’s output will either be increase to maximum or modulate to suit the set requirement.

When the appliance reaches the desired temperature the burner will shut down and the boiler will perform a three-minute anti-cycle (timer delay).

When the request for heat has been satisfied the appliance pump and fan may continue to operate to dissipate any residual heat within the appliance.

1.4 MODE OF OPERATION (DHW)

When there is a request for DHW via a hot water outlet or tap, the pump and fan are started, the fan will then prove the air pressure switch. At this point an ignition sequence is enabled.

Ignition is sensed by the electronic circuitry to ensure flame stability at the burner. Once successful ignition has been achieved, the electronic circuitry increases the gas rate to maximum or will modulate output to stabilise the temperature.

In the event of the appliance exceeding the desired temperature the burner will shut down until the temperature drops.

When the request for DHW has been satisfied the appliance pump and fan may continue to operate to dissipate any residual heat within the appliance.

1.5 SAFETY DEVICES

When the appliance is in use, safe operation is ensured by:

● A water pressure switch that monitors system

water pressure and will de-activate the pump, fan and burner should the system water pressure drop below the rated tolerance.

● A high limit thermostat that over-rides the tem-

perature control circuit to prevent or interrupt the operation of the burner.

● An air pressure switch that requires the fan to

prove operation before the gas valve is energised.

● A pressure switch that interrupts the operation

of the appliance if the condense pipe becomes blocked.

● A safety valve which releases excess pressure

from the primary circuit.

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 2 TECHNICAL DATA

25 29

2.1 Central heating

Heat input (kW) 25.0 29.0 34.8 Maximum heat output@ 80/60 °C (kW) 24.3 28.1 33.8 Minimum heat output@ 80/60 °C (kW) 14.2 14.2 13.9 Maximum heat output@ 50/30 °C (kW) 25.9 30.2 36.1 Minimum heat output@ 50/30 °C (kW) 14.9 14.8 14.4 Minimum working pressure 0.5 bar 0.5 bar 0.5 bar Maximum working pressure 3.0 bar 3.0 bar 3.0 bar Minimum flow rate 350 l/h 350 l/h 350 l/h

2.2 Domestic hot water

Maximum output (kW) 25.0 29.0 34.8 Minimum output (kW) 9.5 9.9 9.9 Flow rate (35 °C rise) 10.2 l/min 11.9 l/min 14.3 l/min Maximum inlet pressure 6.0 bar 6.0 bar 6.0 bar Minimum inlet working pressure 0.15 bar 0.15 bar 0.15 bar Minimum flow rate 2 l/min. 2 l/min. 2 l/min.

2.3 Gas pressures

Inlet pressure G20 20.0 mbar 20.0 mbar 20.0 mbar Maximum burner pressure 9.40 mbar 9.20 mbar 10.1 mbar Minimum burner pressure (central heating) 3.50 mbar 2.70 mbar 2.10 mbar Minimum burner pressure (domestic hot water) 1.50 mbar 1.20 mbar 1.00 mbar Gross rate (central haeting, max - min) 2.64 - 1.59 m3/h 3.07 - 1.59 m3/h 3.68 - 1.59 m3/h Injectors size 12 x 1.35 mm 14 x 1.35 mm 16 x 1.35 mm

2.4 Expansion vessel

Capacity 8 litres 10 litres 10 litres Maximum system volume 76 litres 76 litres 76 litres Pre-charge pressure 1.0 bar 1.0 bar 1.0 bar

2.5 Dimensions

Height 780 mm 780 mm 780 mm Width 400 mm 450 mm 500 mm Depth 332 mm 332 mm 332 mm Dry weight 40 kg 44 kg 48 kg

2.6 Clearances

Sides 12 mm 12 mm 12 mm Top 150 mm from casing or 25 mm above flue elbow, whichever is applicable Bottom 150 mm 150 mm 150 mm Front 600 mm 600 mm 600 mm

2.7 Connections

Flow & return 22 mm 22 mm 22 mm Hot & cold water connections 15 mm 15 mm 15 mm Gas 15 mm 15 mm 15 mm Safety valve 15 mm 15 mm 15 mm Condense 21 mm 21 mm 21 mm

2.8 Electrical

Voltage 230V/~ 50Hz 230V/~ 50Hz 230V/~ 50Hz Power consumption 153 W 153 W 153 W Internal fuse 2 A 2 A 2 A External fuse 3 A 3 A 3 A

2.9 Flue details (concentric)

Maximum horizontal flue length (60/100mm) 4.5 m 4.0 m 1.85 m Maximum vertical flue length (60/100mm) 5.5 m 5.0 m 2.85 m Maximum horizontal flue length (80/125mm) 11.0 m 9.0 m 6.8 m Maximum vertical flue length (80/125mm) 12.0 m 10.0 m 7.8 m

2.9 Flue details (twin pipe)

Maximum horizontal flue length (80mm + 80mm) 20 m + 20 m 12 m + 12 m 10 m + 10 m Maximum vertical flue length (80mm + 80mm) 20 m + 20 m 12 m + 12 m 10 m + 10 m

2.10 Efficiency

SEDBUK 86.9 Band “B” 87.1 Band “B” 86.65 Band “B”

Ref. Condition 15 °C , 1013,25 mbar, dry gas NOTE: L.P.G. data refer to section 10

Supplied By www.heating spares.co Tel. 0161 620 6677

2.11 PUMP DUTY

Fig. 3 shows the flow rate available - after allowing for pressure loss through the appliance - for system requirements. When using this graph, apply only the pressure loss of the system. The graph is based on a 20 ºC temperature differential.

25 - 29

5,0

4,5

4,0

3,5

3,0

2,5

2,0

1,5

1,0

0,5

0,0

0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300

Residual head (x 100 mbar)

first speed

second speed

Litres Per Hour (x100)

third speed

6,0

5,5

5,0

4,5

4,0

3,5

3,0

2,5

2,0

1,5

1,0

0,5

0,0

0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500

Residual head (x 100 mbar)

first speed

Litres Per Hour (x100)

third speed

second speed

Fig. 3

25 29 35

2.12 Appliance

NOx 98 ppm - 172 mg/kWh 81 ppm - 142 mg/kWh 85 ppm - 149 mg/kWh CO (max-min) 80 ppm - 80 ppm 100 ppm - 60 ppm 100 ppm - 120 ppm CO2 (max-min) 6.75 - 3.90 % 7.05 - 3.40 % 6.8 - 2.7 % CO/CO2 ratio (max) 0.001 to 1 0.001 to 1 0.001 to 1 CO/CO

ratio (min) 0.002 to 1 0.001 to 1 0.004 to 1

SECTION 3 GENERAL REQUIREMENTS (UK)

Fig. 4

Key Location Minimum distance

A Below an opening (window, air-brick, etc.) 300 mm B Above an opening (window, air-brick, etc.) 300 mm C To the side of an opening (window, air-brick, etc.) 300 mm D Below gutter, drain-pipe, etc. 75 mm E Below eaves 200 mm F Below balcony, car-port roof, etc. 1200 mm G To the side of a soil/drain-pipe, etc. 150 mm H From internal/external corner or boundary 300 mm

I Above ground, roof, or balcony level 300 mm J From a surface or boundary facing the terminal 1200 mm K From a terminal facing a terminal 1200 mm L From an opening in the car-port into the building 1200 mm

M Vertically from a terminal on the same wall 1500 mm

N Horizontally from a terminal on the same wall 300 mm P From a structure to the side of the vertical terminal 500 mm Q From the top of the vertical terminal to the roof flashing As determined by the fixed collar

of the vertical terminal

Supplied By www.heating spares.co Tel. 0161 620 6677

This appliance must be installed by a competent person in accordance with the Gas Safety (Installation & Use) Regulations.

3.1 RELATED DOCUMENTS

The installation of this boiler must be in accordance with the relevant requirements of the Gas Safety (Installation & Use) Regulations, the local building regulations, the current I.E.E. wiring regulations, the bylaws of the local water undertaking, the Building Standards (Scotland) Regulation and Building Standards (Northern Ireland) Regulations.

It should be in accordance also with any relevant requirements of the local authority and the relevant recommendations of the following British Standard Codes of Practice.

3.2 LOCATION OF APPLIANCE

The appliance may be installed in any room or internal space, although particular attention is drawn to the requirements of the current I.E.E. wiring regulations, and in Scotland, the electrical provisions of the Building Regulations, with respect to the installation of the appliance in a room or internal space containing a bath or shower.

3.3 GAS SUPPLY

The gas meter – as supplied by the gas supplier – must be checked to ensure that it is of adequate size to deal with the maximum rated input of all the appliances that it serves. Installation pipes must be fitted in accordance with BS 6891.

Pipe work from the meter to the appliance must be of adequate size. Pipes of a smaller size than the appliance gas inlet connection must not be used. The installation must be tested for soundness in accordance with BS6891.

If the gas supply serves more than one appliance, it must be ensured that an adequate supply is maintained to each appliance when they are in use at the same time.

3.4 FLUE SYSTEM

The terminal should be located where the dispersal of combustion products is not impeded and with due regard for the damage and discoloration that may occur to building products located nearby. The terminal must not be located in a place where it is likely to cause a nuisance (see fig. 4).

Water vapour will condense on leaving the terminal and the effect of such pluming must be considered.

BS 5440 PART 1 FLUES BS 5440 PART 2 FLUES & VENTILATION BS 5449 PART 1 FORCED CIRCULATION HOT WATER SYSTEMS BS 5546 INSTALLATION OF GAS HOT WATER SUPPLIES FOR DOMESTIC PURPOSES

(2ND FAMILY GASES) BS 6798 INSTALLATION OF BOILERS OF RATED INPUT NOT EXCEEDING 60kW BS 6891 LOW PRESSURE INSTALLATION PIPES BS 7074 PART 1 APPLICATION, SELECTION AND INSTALLATION OF EXPANSION VESSELS AND

ANCILLARY EQUIPMENT FOR SEALED WATER SYSTEMS

When an appliance is installed in a room or internal space containing a bath or shower, the appliance or any control pertaining to it must not be within reach of a person using the bath or shower.

The location chosen for the appliance must permit the provision of a safe and satisfactory flue and termination. The location must also permit an adequate air supply for combustion purposes and an adequate space for servicing and air circulation around the appliance. Where the installation of the appliance will be in an unusual location special procedures may be necessary, BS 6798 gives detailed guidance on this aspect.

A compartment used to enclose the appliance must be designed and constructed specifically for this purpose. An existing compartment/cupboard may be utilised provided that it is modified to suit.

Details of essential features of compartment/ cupboard design including airing cupboard installations are given in BS 6798. This appliance is not suitable for external installation.

3.5 AIR SUPPLY

3.6 WATER CIRCULATION

If installed less than 2m above a pavement or platform to which people have access (including balconies or flat roofs) the terminal must be protected by a guard of durable material. The guard must be fitted centrally over the terminal. Refer to BS 5440 Part 1, when a terminal is sited less than 1m below a plastic gutter, or less than 500mm below a painted surface, a suitable one metre long heat shield should be fitted.

The following notes are intended for general guidance only.

This appliance is a room-sealed, fan-flued boiler, consequently it does not require a permanent air vent for combustion air supply.

When installed in a cupboard or compartment, ventilation for cooling purposes is also not required.

Detailed recommendations are given in BS 5449 Part 1 and BS 6798. The following notes are for general guidance only.

Supplied By www.heating spares.co Tel. 0161 620 6677

3.6.1 PIPEWORK

It is recommended that copper tubing to BS 2871 Part 1 is used in conjunction with soldered capillary joints.

Where possible pipes should have a gradient to ensure air is carried naturally to air release points and that water flows naturally to drain cocks.

Except where providing useful heat, pipes should be insulated to avoid heat loss and in particular to avoid the possibility of freezing. Particular attention should be paid to pipes passing through ventilated areas such as under floors, loft space, and void areas.

3.6.2 AUTOMATIC BY-PASS

The appliance has a built-in automatic by-pass. However it may be necessary to fit an external bypass should the design of the heating system require such. In any case, the design of the system should be such that it prevents boiler ‘cycling’.

3.6.3 DRAIN COCKS

These must be located in accessible positions to facilitate draining of the appliance and all water pipes connected to the appliance. The drain cocks must be manufactured in accordance with BS 2879.

3.6.7 LOW PRESSURE SEALED SYSTEM

An alternative method of filling the system would be from an independent make-up vessel or tank mounted in a position at least 1 metre above the highest point in the system and at least 5 metres above the boiler (see fig. 5a).

The cold feed from the make-up vessel or tank must be fitted with an approved non-return valve and stopcock for isolation purposes. The feed pipe should be connected to the return pipe as close to the boiler as possible.

Make-up vessel or tank

Automatic air-vent

Non-return

valve

Stopcock

5.0 metres minimum

3.6.4 AIR RELEASE POINTS

These must be positioned at the highest points in the system where air is likely to be trapped. They should be used to expel trapped air and allow complete filling of the system.

3.6.5 EXPANSION VESSEL

The appliance has an integral expansion vessel to accommodate the increased volume of water when the system is heated. It can accept up to 8 litres (25kW) or 10 litres (29 & 35kW) of expansion from within the system, generally this is sufficient, however if the system has an unusually high water content, it may be necessary to provide additional expansion capacity (see 6.19).

3.6.6 FILLING POINT

An approved method for initial filling of the system and replacing water lost during servicing etc. is required (see fig. 5). This method of filling must comply with the current Water Supply (Water Fittings) Regulations 1999 and Water Bylaws 2000 (Scotland).

control valve

temporary

connection

control valve

Fig. 5a

Heating return

3.6.8 FREQUENT FILLING

Frequent filling or venting of the system may be indicative of a leak. Care should be taken during the installation of the appliance to ensure all aspects of the system are capable of withstanding pressures up to at least 3 bar.

3.7 ELECTRICAL SUPPLY

The appliance is supplied for operation on 230V @ 50Hz electrical supply; it must be protected with a 3-amp fuse. The method of connection to the mains electricity supply must allow for complete isolation from the supply. The preferred method is by using a double-pole switch with a contact separation of at least 3mm. The switch must only supply the appliance and its corresponding controls, i.e. time clock, room thermostat, etc. Alternatively an un-switched shuttered socket with a fused 3-pin plug both complying with BS 1363 is acceptable.

flow/return

pipe

Fig. 5

double check

valve

supply pipe

3.8 SHOWERS

If the appliance is intended for use with a shower, the shower must be thermostatically controlled and be suitable for use with a combination boiler.

Supplied By www.heating spares.co Tel. 0161 620 6677

3.9 MOUNTING ON A COMBUSTIBLE SURFACE

If the appliance is to be fitted on a wall of combustible material, a sheet of fireproof material must protect the wall.

3.10 TIMBER FRAMED BUILDING

If the appliance is to be fitted in a timber framed building, it should be fitted in accordance with the Institute of Gas Engineers publication (IGE/UP/

7) ‘Guide for Gas Installations in Timber Frame Buildings’.

3.11 INHIBITORS

Vokera recommend that an inhibitor - suitable for use with copper and aluminium heat exchangers

- is used to protect the boiler and system from the effects of corrosion and/or electrolytic action. The inhibitor must be administered in strict accordance with the manufacturers instructions*.

*Water treatment of the complete heating system

- including the boiler - should be carried out in accordance with BS 7593 and the Domestic Water Treatment Association’s (DWTA) code of practice.

Fig. 6a

30kW

25kW

35kW

Fig. 6

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 3A GENERAL REQUIREMENTS (EIRE)

This appliance must be installed by a competent person in accordance with and defined by, the Standard Specification (Domestic Gas Installations) Declaration (I.S. 813).

3A.1 RELATED DOCUMENTS

The installation of this boiler must be in accordance with the relevant requirements of the local building regulations, the current ETCI National Rules for Electrical Installations, and the bylaws of the local water undertaking.

It should be in accordance also with any relevant requirements of the local and/or district authority.

3A.2 LOCATION OF APPLIANCE

The appliance may be installed in any room or internal space, although particular attention is drawn to the requirements of the current ETCI National Rules for Electrical Installations, and I.S. 813, Annex K.

When an appliance is installed in a room or internal space containing a bath or shower, the appliance or any control pertaining to it must not be within reach of a person using the bath or shower. The location chosen for the appliance must permit the provision of a safe and satisfactory flue and termination. The location must also permit an adequate air supply for combustion purposes and an adequate space for servicing and air circulation around the appliance. Where the installation of the appliance will be in an unusual location special procedures may be necessary, refer to I.S. 813 for detailed guidance on this aspect. A compartment used to enclose the appliance must be designed and constructed specifically for this purpose. An existing compartment/cupboard may be utilised provided that it is modified to suit. This appliance is not suitable for external installation.

3A.3 GAS SUPPLY

The gas meter - as supplied by the gas supplier

- must be checked to ensure that it is of adequate size to deal with the maximum rated input of all the appliances that it serves. Installation pipes must be fitted in accordance with I.S. 813.

If the gas supply serves more than one appliance, it must be ensured that an adequate supply is maintained to each appliance when they are in use at the same time.

3A.4 FLUE SYSTEM

The terminal should be located where the dispersal of combustion products is not impeded and with due regard for the damage and discoloration that may occur to building products located nearby.

The terminal must not be located in a place where it is likely to cause a nuisance (refer to I.S. 813 for guidance on permitted locations and minimum distances of flue terminals).

Water vapour will condense on leaving the terminal; the effect of such pluming must be considered.

If installed less than 2m above a pavement or platform to which people have access (including balconies or flat roofs) the terminal must be protected by a guard of durable material. The guard must be fitted centrally over the terminal. Refer to I.S. 813, when the terminal is 0.5 metres (or less) below plastic guttering or 1 metre (or less) below painted eaves.

3A.5 AIR SUPPLY

The following notes are intended for general guidance only. This appliance is a room-sealed, fan-flued boiler, consequently it does not require a permanent air vent for combustion air supply.

When installed in a cupboard or compartment, ventilation for cooling purposes is also not required.

3A.6 WATER CIRCULATION

Specific recommendations are given in I.S. 813. The following notes are for general guidance only.

3A.6.1 PIPEWORK

It is recommended that copper tubing be used in conjunction with soldered capillary joints.

Where possible pipes should have a gradient to ensure air is carried naturally to air release points and that water flows naturally to drain cocks.

3A.6.2 AUTOMATIC BY-PASS

3A.6.3 DRAIN COCKS

These must be located in accessible positions to facilitate draining of the appliance and all water pipes connected to the appliance.

3A.6.4 AIR RELEASE POINTS

These must be positioned at the highest points in the system where air is likely to be trapped. They should be used to expel trapped air and allow complete filling of the system.

3A.6.5 EXPANSION VESSEL

The appliance has an integral expansion vessel to accommodate the increased volume of water

Supplied By www.heating spares.co Tel. 0161 620 6677

when the system is heated. It can accept up to 8 litres (25kW) or 10 litres (29 & 35kW) of expansion from within the system, generally this is sufficient, however if the system has an unusually high water content, it may be necessary to provide additional expansion capacity (see 6.19).

3A.6.6 FILLING POINT

A suitable method for initial filling of the system and replacing water lost during servicing etc. is required (see fig. 5). You should ensure this method of filling complies with the local water authority regulations.

3A.6.7 LOW PRESSURE SEALED SYSTEM

effects of corrosion and/or electrolytic action. The inhibitor must be administered in strict accordance with the manufacturers’ instructions*.

*Water treatment of the complete heating system

- including the boiler - should be carried out in accordance with I.S. 813 and the Domestic Water Treatment Association’s (DWTA) code of practice.

3A.12 DECLARATION OF CONFORMITY

A Declaration of Conformity (as defined in I.S.

813) must be provided on completion of the installation.

A copy of the declaration must be given to the responsible person and also to the gas supplier if required.

3A.6.8 FREQUENT FILLING

3A.7 ELECTRICAL SUPPLY

3A.8 SHOWERS

If the appliance is intended for use with a shower, the shower must be thermostatically controlled and be suitable for use with a combination boiler.

3A.9 MOUNTING ON A COMBUSTIBLE SURFACE

If the appliance is to be fitted on a wall of combustible material, a sheet of fireproof material must protect the wall.

3A.10 TIMBER FRAMED BUILDINGS

If the appliance is to be fitted in a timber framed building, it should be fitted in accordance with I.S. 813 and local Building Regulations.

The Institute of Gas Engineers publication (IGE/ UP/7) ‘Guide for Gas Installations in Timber Frame Buildings’ gives specific advice on this type of installation.

3A.11 INHIBITORS

Vokera recommend that an inhibitor - suitable for use with copper and aluminium heat exchangers

- is used to protect the boiler and system from the

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 4 INSTALLATION

4.1 DELIVERY

Due to the weight of the appliance it may be necessary for two people to lift and attach the appliance to its mounting. The appliance is contained within a heavy-duty cardboard carton. Lay the carton on the floor with the writing the correct way up.

4.2 CONTENTS

Contained within the carton is:

● the boiler

● the wall bracket

● appliance template

● an accessories pack containing appliance serv-

ice connections and washers

● the instruction pack containing the installation

& servicing instructions, user instructions, Benchmark logbook, guarantee registration card and a 3-amp fuse.

4.3 UNPACKING

At the top of the carton pull both sides open - do not use a knife - unfold the rest of the carton from around the appliance, carefully remove all protective packaging from the appliance, and lay the accessories etc. to one side. Protective gloves should be used to lift the appliance, the appliance back-frame should be used for lifting points.

Reduction for additional bends

Bend Reduction in maximum flue length for each bend

45º bend 0.5 metre 90º bend 1.0 metre

Horizontal flue terminals and accessories

Part No. Description Min-Max Length

0225720 Horizontal flue kit for use with 1000 mm

add. bends & extensions 0225755 Telescopic extension 350 mm – 500 mm 0225740 0.5m extension 500 mm 0225745 1.0m extension 1000 mm 0225750 2.0m extension 2000 mm 0225730 45º bend (pair) N/A 0225735 90º bend N/A 0225760 Wall bracket (5) N/A

Using the template provided, mark and drill a 115mm hole for the passage of the flue pipe. The hole should be drilled level to ensure any condense fluid that forms will drain back to the boiler. The fixing holes for the wall-mounting bracket should now be drilled and plugged, an appropriate type and quantity of fixing should be used to ensure that the bracket is mounted securely. Once the bracket has been secured to the wall, mount the appliance onto the bracket.

4.4 PREPARATION FOR MOUNTING THE APPLIANCE

The appliance should be mounted on a smooth, vertical, non-combustible surface, which must be capable of supporting the full weight of the appliance. Care should be exercised when determining the position of the appliance with respect to hidden obstructions such as pipes, cables, etc.

When the position of the appliance has been decided - using the template supplied - carefully mark the position of the wall- mounting bracket (see fig. 6) and flue-hole (if applicable).

4.5 FITTING THE FLUE

The top flue outlet permits both horizontal and vertical flue applications to be considered, alternatively, the Vokera twin flue system can be utilised if longer flue runs are required.

4.5.1 CONCENTRIC HORIZONTAL FLUE

(For concentric vertical flue, see section 4.5.2). (For twin flue applications, see section 4.5.3).

The appliance can be used with either the Vokera condensing 60/100mm concentric flue system or the optional 80/125mm concentric flue system.

NOTE

These instructions relate only to the Vokera condensing 60/100mm concentric flue system. For specific details on the installation of the 80/125mm concentric flue system please refer to the instructions supplied with the 80/125mm terminal. The appliance flue outlet elbow can be rotated through 360º on its vertical axis. In addition the flue may be extended from the outlet elbow in the horizontal plane (see 2.9). A reduction must also be made to the maximum length (see table below) when additional bends are used.

Push-fit connection

Terminal or

extension

outer

clamp

Fig. 7

Boiler

FITTING THE HORIZONTAL FLUE KIT

Carefully measure the distance from the centre of the appliance flue outlet to the edge of the finished outside wall (dimension X). Add 45mm to dimension X to give you Dimension Y (see fig 7A). Measure dimension Y from the terminal end of the concentric flue pipe and cut off the excess ensuring any burrs are removed. Pass the concentric flue pipe through the previously drilled hole. Fit the flue bend to the boiler flue outlet and insert the concentric flue pipe into the flue bend ensuring the correct seal is made. Using the clamp, gasket, and screws supplied, secure the flue bend to the appliance flue spigot. The 60mm M & F adaptor (supplied with the flue kit) should be discarded.

NOTE

Fit the internal (White) trim to the flue assembly prior to connecting the flue pipe to the bend. You must ensure that the entire flue system is properly supported and connected. Seal the flue assembly to the wall using cement or a suitable alternative that will provide satisfactory weatherproofing. The exterior trim (Black) can now be fitted.

Supplied By www.heating spares.co Tel. 0161 620 6677

Fig. 7a

“X” + 45 mm = “Y”

FLUE RESTRICTOR RING (horizontal flue)

To ensure maximum efficiency of the appliance, it may be necessary to fit one of the supplied flue restrictor rings to the appliance flue outlet (see tables below).

Total flue length Restrictor required

Less than 1.2 metre 82.5mm diameter Less than 3.0 metres 88mm diameter Less than 4.5 metres not required

Total flue length Restrictor required

Less than 2.0 metres 84mm diameter Less than 4.0 metres not required

Total flue length Restrictor required

Less than 1.85 metres not required

4.5.1.1 EXTENDING THE FLUE

Connect the bend - supplied with the terminal kit

- to the top of the boiler using clamp (supplied) see fig. 7. The additional bends & extensions have push-fit connections, care should be taken to ensure that the correct seal is made when assembling the flue system. Connect the required number of flue extensions or bends (up to the maximum equivalent flue length) to the flue terminal (see fig. 7 & 8).

The flue pipe should have a minimum 1-degree rise from the boiler (17mm every 1.0 metre) to ensure that any condense fluid drains back to the appliance.

NOTE

When cutting an extension to the required length, you must ensure that the excess is cut from the plain end of the extension (see fig. 7 & 8). Remove any burrs, and check that all seals are located properly.

125 mm

You must ensure that the entire flue system is properly supported and connected. Seal the flue assembly to the wall using cement or a suitable alternative that will provide satisf actory weatherproofing.

4.5.2 CONCENTRIC VERTICAL FLUE

The appliance can be used with either the Vokera condensing 60/100mm concentric flue system or the optional 80/125mm concentric flue system.

NOTE

The vertical flue terminal can be connected directly to the appliance flue outlet. Alternatively, an extension or bend can be connected to the appliance flue outlet if desired (see 4.4.2), however if additional bends are fitted, a reduction must be made to the maximum flue length (see table below).

Reduction for bends

Bend Reduction in maximum flue length for each bend

45º bend 0.5 metre 90º bend 1.0 metre

Ver tical flue terminal and accessor ies

Part No. Description Min-Max Length

0225725 Vertical flue terminal 1.0 metre 0225770 Pitched roof flashing plate N/A 0225765 Flat roof flashing plate N/A

0225755 350-500 telescopic extension 350 mm – 500 mm 0225740 0.5m extension 500 mm 0225745 1.0m extension 1000 mm 0225750 2.0m extension 2000 mm 0225730 45º bend (pair) N/A 0225735 90º bend N/A 0225760 Wall bracket (4) N/A

Using the dimensions given in fig. 9 as a reference, mark and cut a 107mm hole in the ceiling and/or roof.

Fig. 9

Fig. 8

145

Supplied By www.heating spares.co Tel. 0161 620 6677

Fit the appropriate flashing plate to the roof and insert the vertical flue terminal through the flashing plate from the outside, ensuring that the collar on the flue terminal fits over the flashing. The fixing holes for the wall-mounting bracket should now be drilled and plugged, an appropriate type and quantity of fixing should be used to ensure that the bracket is mounted securely. Once the bracket has been secured to the wall, mount the appliance onto the bracket.

IMPORTANT

The vertical flue terminal is 1.0 metre in length and cannot be cut; therefore it may be necessary to adjust the height of the appliance to suit or use a suitable extension.

Connect the vertical flue assembly to the boiler flue spigot using the 60mm & 100mm clips, gaskets & screws (supplied), ensuring the correct seal is made. The flue support bracket (supplied with the vertical flue kit) can now be fitted.

If the vertical flue requires extension/s or additional bend/s, connect the required number of flue extensions or bends (up to the maximum equivalent flue length) between the boiler and vertical flue assembly (see fig. 8).

Ensure that any horizontal sections of the flue system have a minimum 1º fall back to the boiler (17mm per 1000mm).

NOTE

When cutting an extension to the required length, you must ensure that the excess is cut from the plain end of the extension (see fig. 8). Remove any burrs, and check that any seals are located properly.

You must ensure that the entire flue system is properly supported and connected.

FLUE RESTRICTOR RING (vertical flue)

To ensure maximum efficiency of the appliance, it may be necessary to fit one of the supplied flue restrictor rings to the appliance flue outlet (see tables below).

Total flue length Restrictor required

Less than 2.0 metre 82.5mm diameter Less than 4.0 metres 88mm diameter Less than 5.5 metres not required

Total flue length Restrictor required

Less than 2.8 metres 84mm diameter Less than 5.0 metres not required

Total flue length Restrictor required

Less than 2.7 metres not required

4.5.3 TWIN FLUE SYSTEM

The Vokera twin flue system enables greater flue distances to be achieved (see 4.4.2) than that of a concentric flue system. It can be used for horizontal or vertical applications, however the twin flue system must be converted to the dedicated concentric flue kit for termination. It is essential that the installation of the twin flue system be carried out in strict accordance with these instructions.

GUIDANCE NOTES ON TWIN FLUE INSTALLATION

● The flue must have a fall back of 1º back to the

appliance to allow any condensate that may form in the flue system to drain via the condensate drain. Consideration must also be given to the fact that there is the possibility of a small amount of condensate dripping from the terminal.

● Ensure that the entire flue system is adequately

supported, use at least one bracket for each extension.

● The entire flue system must be adequately

insulated to maintain heat within the flue system thereby reducing the possibility of condensate production.

● As the exhaust outlet pipe can reach very high

temperatures it must be protected to prevent persons touching the hot surface.

● The condensate drainpipe must be connected

in accordance with local building regulations that are in force.

Reduction for bends

Bend Reduction in maximum flue length for each bend

45º bend 1.0 metre 90º bend 1.0 metre

Twin flue accessories

Part No. Description Min-Max Length

0225805 Horizontal flue terminal 1.0 metre 0225810 Vertical flue terminal 1.0 metre 430 T win adapter kit N/A 0225770 Pitched roof flashing plate N/A 0225765 Flat roof flashing plate N/A 0225815 Condensate drain kit N/A 0225820 0.25 m extension (pair) 250 mm 0225825 0.5 m extension (pair) 500 mm 0225830 1.0 m extension (pair) 1000 mm 0225835 2.0 m extension (pair) 2000 mm 0225840 45º bend (pair) N/A 0225845 90º bend (pair) N/A 0225850 Twin br acket (5) N/A 0225855 Single bracket (5) N/A

MOUNTING THE BOILER

The fixing holes for the wall-mounting bracket should now be drilled and plugged, an appropriate type and quantity of fixing should be used to ensure that the bracket is mounted securely. Once the bracket has been secured to the wall, mount the appliance onto the bracket.

FLUE RESTRICTOR RING (vertical flue)

To ensure maximum efficiency of the appliance, it may be necessary to fit one of the flue restrictor rings (supplied with the twin adaptor kit) to the appliance flue outlet (see tables below).

Total flue length Restrictor required

Less than 7.0 metre 40mm diameter Less than 13.5 metres 45mm diameter Less than 19.5 metres not required

Total flue length Restrictor required

Less than 5.0 metres 45mm diameter Less than 12.0 metres not required

Supplied By www.heating spares.co Tel. 0161 620 6677

Total flue length Restrictor required

Less than 5.0 metres 50mm diameter Less than 10.0 metres not required

4.5.3.1 INSTALLATION OF TWIN ADAPTOR KIT (fig. 10 & 11)

● Insert the exhaust connection manifold (A)

onto the appliance flue outlet.

● Remove the blanking plate (located to the right

of the appliance flue outlet) and – using the same screws – install the air inlet plate (B).

● Using the hole in the exhaust connection mani-

fold as a guide, drill a 3mm hole in the appliance flue spigot and secure the exhaust manifold connection to the flue spigot using the screw provided (C).

● Using the two holes in the air inlet plate as a

guide, drill a 3mm hole in each and secure the air inlet pipe/bend using the screws provided.

● The twin flue pipes extensions and accessories

can now be installed by pushing together (the plain end of each extension or bend should be pushed approximately 50mm into the female socket of the previous piece).

Fig. 12

Fig. 10

Fig. 11

4.5.3.2 HORIZONTAL TERMINATION (see fig. 12)

The twin flue system must be converted to the dedicated concentric flue kit for termination.

● The horizontal terminal is supplied with a built-

in converter box and cannot be shortened.

● A 130mm hole is required for the passage of

the concentric terminal through the wall. Depending on site conditions it may be preferable to install the terminal assembly prior to fitting the twin flue pipes.

Mark and drill a 130mm hole for the passage of the horizontal flue terminal, ensuring that there is a minimum 1º fall back to the boiler (17mm per 1000mm). Insert the terminal assembly into the flue hole.

Push-fit the twin flue pipes onto the concentric to twin converter box ensuring that the exhaust pipe connects to the exhaust connection on the concentric to twin converter.

If necessary cut the plain ends (male) of the twin flue pipes to allow connection to the concentric to twin converter.

Fig. 13

NOTE

Before cutting twin flue pipes ensure allowances have been made for connection onto the previous piece and onto the concentric to twin converter. The last twin flue pipes must be pushed 50mm onto the male spigots of the concentric to twin converter.

NOTE

You must ensure that the entire flue system is properly supported and connected. Seal the flue terminal assembly to the wall using cement or a suitable alternative that will provide satisfactory weatherproofing. The interior and exterior trim can now be fitted.

4.5.3.3 VERTICAL TERMINATION (see fig. 13)

The twin flue system must be converted to the dedicated concentric flue kit for termination.

● The vertical terminal is supplied with a built-in

converter box and cannot be shortened.

● A 130mm hole is required for the passage of

the concentric terminal through the ceiling and/ or roof.

Supplied By www.heating spares.co Tel. 0161 620 6677

Depending on site conditions it may be preferable to install the terminal assembly prior to fitting the twin flue pipes. Fit the appropriate flashing plate to the roof and insert the vertical flue terminal through the flashing plate from the outside, ensuring that the collar on the flue terminal fits over the flashing.

Push-fit the twin flue pipes onto the concentric to twin converter ensuring that the exhaust pipe connects to the exhaust connection on the concentric to twin converter. If necessary cut the plain ends (male) of the twin flue pipes to allow connection to the concentric to twin converter.

NOTE

● Before cutting twin flue pipes ensure allow-

ances have been made f or connection onto the previous piece and onto the concentric to twin converter. The last twin flue pipes must be pushed 50mm onto the male spigots of the concentric to twin converter.

● You must ensure that the entire flue system is

properly supported and connected.

● Ensure that any horizontal sections of pipe have

a minimum 1º fall tow ards the appliance (17mm per 1000mm).

4.6 CONNECTING THE GAS AND WATER

The appliance is supplied with an accessory pack that includes service valves. The service valves are of the compression type. The accessory pack contains sealing washers’ etc, for use with the service valves. When connecting pipe work to the valves, tighten the compression end first then insert the sealing washers before tightening the valve to the appliance.

NOTE

It will be necessary to hold the valve with one spanner whilst tightening with another

condense

NOTE

Depending on system requirements, it may necessary to increase the size of the flow & return pipe work after the service valve connections.

4.6.3 COLD WATER INLET (fig. 6 & 14)

The appliance is supplied with a 15mm stopcock, connect a 15mm pipe to the inlet of the stopcock and tighten both nuts.

4.6.4 HOT WATER OUTLET (fig. 6 & 14)

The appliance is supplied with a 15mm outlet connection, connect a 15mm pipe to the outlet connection and tighten both nuts.

4.6.5 SAFETY VALVE (fig. 6 & 14)

Connect the safety valve connection pipe to the safety valve outlet and tighten. The discharge pipe must have a continuous fall away from the appliance to outside and allow any water to drain away thereby eliminating the possibility of freezing. The discharge pipe must terminate in a position where any water - possibly boiling discharges safely without causing damage or injury, but is still visible.

4.6.6 CONDENSE PIPE (fig. 6 & 14)

During normal operation the boiler produces condense which is collected in a trap located in the lower part of the boiler. A flexible pipe (condense outlet pipe) is connected to the outlet of the trap. The flexible pipe must be connected to a plastic waste pipe only. The plastic waste pipe must have a minimum of a 3º fall towards the drain. Any external run of pipe should be insulated to prevent the risk of freezing.

CONNECTING THE CONDENSATE OUTLET

Gently pull the condense outlet pipe down from its location inside the boiler until approximately it protrudes from the underside of the boiler. Connect a suitable plastic (not copper) pipe (no less than 21mm diameter) to the outlet pipe and ensure it discharges in accordance with local building regulations or other rules in force.

4.7 ELECTRICAL CONNECTIONS

return gas DHW

flow

Fig. 14

safety

valve drain

outlet

DHW

inlet

4.6.1 GAS (fig. 6 & 14)

The appliance is supplied with a 15mm service valve, connect a 15mm pipe to the inlet of the valve and tighten both nuts.

NOTE

It will be necessary to calculate the diameter of the gas supply pipe to ensure the appliance has an adequate supply of gas.

4.6.2 FLOW & RETURN (fig. 6 & 14)

The appliance is supplied with 22mm service valves for the flow and return connections, connect a 22mm pipe to the inlet of each valve and tighten both nuts.

The boiler is supplied with a 2-metre fly-lead. This lead can be used for connection to the electrical supply. Connect the fly-lead to a fused plug or fused isolator in the following way:

● brown wire to LIVE supply

● blue wire to NEUTRAL supply

● green/yellow to EARTH connection.

Insert the supplied 3-AMP fuse into the fused isolator or fused plug.

Should the fly-lead be unsuitable, refer to 4.7.3 for details on how to connect the electrical supply directly to the boiler.

The electrical supply must be as specified in section 3/3A. A qualified electrician should connect the appliance to the electrical supply. If controls - external to the appliance - are required, a competent person must undertake the design of any external electrical circuits, please refer to section 8 for detailed instructions. ANY EXTERNAL CONTROL OR WIRING MUST BE SERVED

Supplied By www.heating spares.co Tel. 0161 620 6677

FROM THE SAME ISOLATOR AS THAT OF THE APPLIANCE. The supply cable from the isolator to the appliance must be 3-core flexible sized 0.75mm to BS 6500 or equivalent. Wiring to the appliance must be rated for operation in contact with surfaces up to 90 ºC.

4.7.1 CASING REMOVAL

T o gain internal access to the appliance you must first remove the casing, proceed as outlined below:

● locate and unscrew the 3-screws (A) that se-

cure the outer casing to the appliance (see fig.

15)

● lift the casing upward to disengage it from the

top locating hooks and then remove

● store the casing and screws safely until re-

quired. Re-fit in the reverse order

● gently lower the control fascia until it rests.

Control panel screws and casing screws

The securing screw on the cable anchorage should now be tightened. This must be done before the control fascia is re-fitted in the upright position. The appliance casing and screws can now be re-fitted.

Fig. 15

4.7.2 APPLIANCE TERMINAL BLOCK

The appliance terminal block is located on the left side of the control fascia (see fig. 15). Locate and remove the screw that secures the terminal block cover.

NOTE

The appliance comes with a factory fitted clock to allow basic operation of the boiler. If it is anticipated that additional controls - such as a room thermostat - will be required please refer to the wiring diagrams in section 8 for more detailed information.

4.7.3 CONNECTING THE MAINS (230V) INPUT (see fig. 16)

Lift the terminal block cover as described in 4.7.2. Pass the cable through the cab le anchorage point. At the terminal block on the extreme left, there are 3 terminals from left to right they are:

LIVE NEUTRAL EARTH

Fig. 16

Fig. 17

Connect the supply cable wires (LIVE, NEUTRAL & EARTH) to their corresponding terminals on the appliance terminal block (see fig. 17). Ensure that the EARTH wire is left slightly longer than the others, this will prevent strain on the EARTH wire should the cable become taut.

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 5 COMMISSIONING

5.1 GAS SUPPLY INSTALLATION

Inspect the entire installation including the gas meter, test for soundness and purge. Refer to BS 6891 for specific instruction.

5.2 THE HEATING SYSTEM

The appliance contains components that may become damaged or rendered inoperable by oils and/or debris that are residual from the installation of the system, consequently it is essential that the system be flushed in accordance with the following instructions.

5.3 INITIAL FILLING OF THE SYSTEM

Ensure both flow and return service valves are open, remove appliance casing as described in

4.7.1, identify the automatic air release valve and loosen the dust cap by turning the cap anticlockwise one full turn. IMPORTANT, THERE ARE NO MANUAL AIR RELEASE VALVES LOCATED ON THE APPLIANCE. Ensure all manual air release valves located on the heating system are closed. Connect the filling loop (not supplied) and slowly proceed to fill the system. As water enters the system the pressure gauge will begin to rise. Once the gauge has reached 1 BAR close the filling loop and begin venting all manual air release valves, starting at the lowest first. It may be necessary to go back and top-up the pressure until the entire system has been filled. Inspect the system for water soundness, rectifying any leaks.

5.4 INITIAL FLUSHING

The whole of the heating system must be flushed both cold and hot as detailed in 5.8. Open all radiator or heating valves and the appliance flow & return service valves. Drain the boiler and system from the lowest points. Open the drain valve full bore to remove any installation debris from the boiler prior to lighting. Refill the boiler and heating system as described in 5.3.

5.5 FILLING THE HOT WATER SYSTEM

Close all hot water outlets, turn appliance stopcock to the normal operating position (fully counter clockwise), slowly open each outlet until air has been expelled and clear water is discharged. Check pipe-work etc. for water soundness.

5.6 PRE-OPERATION CHECKS

Before attempting the initial lighting of the appliance, the following checks must be carried out:

● ensure all gas service valves from the meter to

the appliance are open and the supply pipe has been properly purged

● ensure the proper electrical checks have been

carried out, (see 7.7) particularly continuity, polarity, and resistance to earth

● ensure the 3 AMP fuse – supplied with the

appliance – has been fitted.

● ensure the system has been filled, vented, and

the pressure set to 1 BAR.

● ensure the flue system has been fitted properly

and in accordance with the instructions

● ensure all appliance service valves are open.

5.7 INITIAL LIGHTING

Ensure the electrical supply to the appliance is switched on. Move the selector switch to the Heating & Hot Water position, ensure the time clock is switched to an ‘ON’ position and ensure any other external controls (room thermostat for example) are also calling for heat. The appliance will now operate in the mode as described in 1.2. Should the appliance fail to ignite, refer to 5.6 and/or section 7 (faultfinding).

5.7.1 CHECKING THE BURNER PRESSURE

Although the burner pressure is factory set, it is necessary to check it during commissioning. Isolate the appliance from the electrical supply and attach a suitable manometer to the gas valve outlet test-point (see fig. 18). Light the boiler as described in 5.7, turn the Hot Water temperature selector to maximum, and open fully a DHW outlet (preferably the bath), allowing the appliance to stabilise. Compare the reading on the manometer with the value described in 2.3. If adjustment is required, follow the detailed instructions in section 7 (7.3).

Outlet

test-point

Protective

cap

Inlet

Fig. 18

test-point

Once the burner pressure has been checked, close the DHW outlet, isolate the appliance from the electrical supply , remove the manometer , and tighten the gas valve outlet test nipple.

5.8 FINAL FLUSHING OF THE HEATING SYSTEM

The system shall be flushed in accordance with BS 7593. Should a cleanser be used, it must be suitable for Copper and Aluminium heat exchangers. It shall be from a reputable manufacturer and shall be administered in strict accordance with the manufacturers’ instructions and the DWTA code of practice.

5.8.1 INHIBITORS

See section 3 “General requirements”.

5.9 SETTING THE BOILER OPERATING TEMPERATURE

The flow outlet temperature can be adjusted between 40ºC - 80ºC via the Heating thermostat knob (see fig.1).

Supplied By www.heating spares.co Tel. 0161 620 6677

5.9.1 SETTING THE DOMESTIC HOT WATER TEMPERATURE

The DHW outlet temperature can be adjusted between 40ºC - 65ºC via the Hot Water thermostat knob (see fig.1).

5.10 SETTING THE SYSTEM DESIGN PRESSURE

The design pressure should be a minimum of 1 BAR and a maximum of 1.5 BAR.

The actual reading should ideally be 1BAR plus the equivalent height in metres (0.1 BAR = 1 metre) to the highest point in the system above the base of the appliance (up to the maximum of

1.5 BAR total). N.B. The safety valve is set to lift at 3 BAR/30

metres/45 psig.ee fig.1). To lower the system pressure to the required

value, water can be drained from the heating system drain cock or from the boiler drain cock.

5.11 REGULATING THE HOT WATER

The appliance is fitted with a flow rate restrictor that limits the maximum flow rate that can be drawn through the appliance.

8-litre (White) 9-litre (Orange) 10-litre (Blue)

Fitted Spare Spare

9-litre (Orange) 10-litre (Blue) 11-litre (Beige)

Spare Fitted Spare

11-litre (Beige) 12-litre (Red) 13-litre (Olive)

Spare Fitted Spare

The restrictor eliminates the need to manually adjust the DHW flow rate. However if it is felt necessary to further increase or decrease the available flow rate, spare restrictors are included in the accessory pack.

The spare flow rate restrictors can be fitted to either increase or decrease the maximum flow rate. The tables above denote the size of restrictor fitted and the spare restrictors supplied in the accessory pack. Each restrictor is colour-coded to enable identification.

5.12 FINAL CHECKS

● ENSURE ALL TEST NIPPLES ON THE AP-

PLIANCE GAS VALVE HAVE BEN TIGHTENED AND CHECKED FOR SOUNDNESS.

● ENSURE THE APPLIANCE FLUE SYSTEM

IS FITTED CORRECTLY AND IS PROPERLY SECURED.

● ENSURE ALL PIPE WORK IS RE-CHECKED

FOR SOUNDNESS.

● RE-FIT APPLIANCE CASING.

● COMPLETE BENCHMARK CHECKLIST.

FOR UK ONLY

Complete details of the boiler, controls, installation and commissioning in the Benchmark checklist at the back of this book. It is impor tant that the Benchmark checklist is correctly completed and handed to the user. Failure to install and commission the appliance to the manufacturers instructions may invalidate the warranty.

5.13 INSTRUCTING THE USER

Hand over all documentation supplied with this appliance - including these instructions - and explain the importance of keeping them in a safe place.

Explain to the user how to isolate the appliance from the gas, water and electricity supplies, and the locations of all drain points.

Show the user how to operate the appliance and any associated controls correctly.

Show the user the location of the filling valve and how to top-up the system pressure correctly, and show the location of all manual air release points.

Explain to the user how to turn off the appliance for both long and short periods and advise on the necessary precautions to prevent frost damage.

Explain to the user that for continued safe and efficient operation, the appliance must be serviced annually by a competent person.

5.11.1 CHANGING THE FLOW RESTRICTOR

Refer to 6.19 for detailed instruction on changing the flow restrictor.

5.11.2 REGULATING THE CENTRAL HEATING SYSTEM

Fully open all radiator and circuit valves and run the appliance for both heating and hot water until heated water is circulating. If conditions are warm remove any thermostatic heads. Adjust radiator return valves and any branch circuit return valves until the individual return temperatures are correct and are approximately equal.

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 6 SERVICING INSTRUCTIONS

6.1 GENERAL

To ensure the continued safe and efficient operation of the appliance, it is recommended that it is checked and serviced at regular intervals.

To ensure correct and safe operation of the appliance, it is essential that any worn or failed component be replaced only with a genuine Vokera spare part.

The frequency of servicing will depend upon the particular installation conditions, but in general, once per year should be adequate.

It is the law that any servicing work is carried out by competent person such as a V okera engineer , an approved service agent, British Gas, CORGI registered personnel or other suitably qualified personnel.

The following instructions apply to the appliance and its controls, but it should be remembered that the central heating and the domestic hot water systems would also require attention from time to time.

6.2 ROUTINE ANNUAL SERVICING

Check the operation of the appliance and ensure it functions as described in section 7. Compare the performance of the appliance with its design specification. The cause of any noticeable deterioration should be identified and rectified without delay.

Thoroughly inspect the appliance for signs of damage or deterioration especially the flue system and the electrical apparatus.

Check and adjust - if necessary - all burner pressure settings (see section 7.3).

Check and adjust - if necessary - the system design pressure (see section 5.10).

Carry out an analysis of the flue gases (see 7.4) and visually check the condition of the entire flue assembly. Compare the results with the appliance design specification. Any deterioration in performance must be identified and rectified without delay.

Ensure both flue venturis are clean and free from any debris or obstruction.

Ensure the burner, main heat exchanger and latent heat collector are clean and free from any debris or obstruction.

And when necessary, close all service valves on the appliance, remove the appliance casing as described in section 4.7.1 and drain the water content from the appliance via the drain valve located at the front of the hydraulic section using the tube provided. Ensure some water absorbent cloths are available to catch any residual water that may drip from the appliance or removed component. Undertake a complete commissioning check as detailed in section 5, after replacing any component. ALWAYS TEST FOR GAS

SOUNDNESS IF ANY GAS CARRYING COMPONENTS HAVE BEEN REMOVED OR DISTURBED.

6.5 PUMP ASSEMBLY fig. 19

Carry out component removal procedure as described in 6.4. The pump head can be replaced by disconnecting the electrical connection at the pump and removing the 4-Allen screws that secure the head to the pump base. Alternatively, the complete pump assembly can be removed as follows:

● disconnect the electrical connection from the

pump control box

● locate and remove the pressure gauge secur-

ing pin and disconnect the pressure gauge from the pump assembly

● locate and remove the expansion pipe securing

pin and disconnect the expansion pipe from the pump assembly

● locate and remove the condense pipe located

between the air-chamber and condense trap

● refer to fig. 19, disconnect and remove items A,

B & C

● locate and remove securing pin ‘F’ and lift the

pump assembly away from the hydraulic section.

Replace in the reverse order.

6.3 REPLACEMENT OF COMPONENTS

Although it is anticipated that this appliance will give years of reliable, trouble free service, the life span of components will be determined by factors such as operating conditions and usage. Should the appliance develop a fault, the fault finding section will assist in determining which compo-

Fig. 19

6.6 SAFETY VALVE fig. 20

nent is malfunctioning.

6.4 COMPONENT REMOVAL PROCEDURE

To remove a component, access to the interior of the appliance is essential. Isolate the appliance from the electrical supply and remove the fuse.

Carry out component removal procedure as described in 6.4. Disconnect and remove the safety valve outlet pipe. Locate and remove the safety valve securing pin (B). The safety valve can now be removed. Replace in the reverse order.

Supplied By www.heating spares.co Tel. 0161 620 6677

6.11 HIGH LIMIT THERMOSTAT fig. 22

Carry out component removal procedure as described in 6.4. Unclip and remove the air chamber cover.

Pull off electrical connections from the high limit thermostat (2), slacken and remove retaining screws (3).

Replace in reverse order.

Fig. 20

6.7 AUTOMATIC AIR RELEASE VALVE fig. 19 (AAV)

Carry out component removal procedure as described in 6.4. Locate and remove the expansion pipe securing pin and disconnect the expansion pipe from the pump assembly. Locate and remove the AAV securing pin (G) and lift the AAV free from the pump assembly. Replace in the reverse order.

6.8 WATER PRESSURE SWITCH fig. 1

Carry out component removal procedure as described in 6.4. Disconnect the 2-wires from the water pressure switch, taking note of their locations. Locate and remove the pin that secures the water pressure switch to the flow pipe. Remove the water pressure switch from the flow pipe. Replace in the reverse order.

6.9 PRESSURE GAUGE fig. 1

Carry out component removal procedure as described in 6.4. Locate and remove the pressure gauge securing pin and disconnect the pressure gauge from the pump assembly. Locate the spring tabs on the pressure gauge body, push and hold tabs in, to enable extraction of the gauge from its location on the control panel. Replace in the reverse order.

6.10 PRIMARY THERMISTOR fig. 21

Carry out component removal procedure as described in 6.4. Unclip and remove the air chamber cover and remove the right side air baffle.

Disconnect thermistor electrical plug. Using a 13mm spanner slacken and remove the

thermistor and sealing washer (1,2) from the main heat exchanger.

Replace in the reverse order.

Fig. 22

6.12 PRINTED CIRCUIT BOARD fig. 23

Carry out component removal procedure as described in 6.4. Locate and remove the screws that secure the PCB cover, then remove cover. After carefully taking note of all wiring connections, disconnect all wiring from the PCB, locate and remove the PCB securing screws (2,3,), remove the required PCB (Main or ignition control). Replace in the reverse order.

NOTE

Ensure that any replacement PCB has the correct jumper tag configuration, and that the relevant gas pressures are correctly set/adjusted (see 7.8.1).

6.13 GAS VALVE fig. 24

Carry out component removal procedure as described in 6.4. The gas valve must be changed as complete unit. Disconnect the electrical plug and leads from the gas valve. Slacken and unscrew gas valve inlet and outlet connections (3). Please note, the sealing washers (2) must be discarded and replaced with new sealing washers (2). Locate and remove gas valve retaining screws on the underside of the boiler if required. The gas valve can now be removed. Replace in the reverse order. Check and adjust burner pressure settings. WARNING,

A GAS SOUNDNESS CHECK MUST BE CARRIED OUT.

Fig. 21

Supplied By www.heating spares.co Tel. 0161 620 6677

CLK-1

CLK-4

Fig. 23

Fig. 24

6.14 INTEGRAL TIME SWITCH (if fitted)

Carry out component removal procedure as described in 6.4. Locate and remove the PCB cover and securing screws (fig 23/23A), locate and remove the time clock retaining screws, remove time clock. Disconnect wiring after carefully taking note of all electrical connections. Replace in the reverse order.

Fig. 23a

6.15 ELECTRODE, BURNER THERMOSTAT, BURNER & INJECTORS fig. 25

Carry out component removal procedure as described in 6.4. Unclip and remove the air chamber cover (2). Locate and remove the 6 screws securing the front combustion cover (3), pull the cover towards you before lifting and disengaging. Disconnect the electrode lead and burner thermostat from their respective connectors. Ease the electrode sealing grommet from its seating (4). Remove the retaining screw for the burner thermostat and remove the thermostat.

FIG. 26: locate and remove the four screws which secure the burner in position (1), gently ease the burner out of its location. Once the burner has been removed, the electrode retaining screw can be removed. Locate the burner injectors (2) and remove (if necessary). Replace in the reverse order. Please note, the injector sealing washers (3) must be replaced if the injectors have been removed, ensure all seals are in good condition, taking care to ensure they are replaced correctly. Replace in the reverse order.

Fig. 25 Fig. 26

Supplied By www.heating spares.co Tel. 0161 620 6677

Fig. 27

6.16 FLUE FAN fig. 27

Carry out component removal procedure as described in 6.4. Unclip and remove the air chamber cover, gently pull the cover towards you before lifting and disengaging. Locate and remove the six screws that secure the front combustion cover, then remove the cover. Disconnect the electrical connections and silicone tubes attached to the fan, noting their positions. Locate and remove the screws (6) that secure the air pressure switch assembly (4&5). Locate and remove the screws that secure the flue hood and air baffle, disconnect the flue clip (1) from the fan-flue elbow, and gently ease the fan (3) & flue hood assembly (2) from its location. Locate and remove the four screws that secure the fan to the flue hood. Remove the fan to flue elbow. Replace in the reverse order. Ensure all seals are in good condition, taking care to ensure they are replaced correctly.

panels if necessary by unscrewing the securing screws. Disconnect the flow and return connections (4,5, fig. 28) on the heat exchanger. The heat exchanger can now be withdrawn from the appliance. Replace in the reverse order. Ensure all seals are in good condition, taking care to ensure they are replaced correctly.

6.18 AIR PRESSURE SWITCH fig. 27

Fig. 28

6.17 MAIN HEAT EXCHANGER fig. 27/28

Fig. 29

6.19 FLOW RESTRICTOR fig. 29

Carry out the component removal procedure as described in 6.4. Slacken the cold water inlet pipe (A) at the DHW flow switch and disconnect. Ease the flow restrictor (B) from its seating. Replace in the reverse order. Ensure all seals are in good condition, taking care to ensure they are replaced correctly.

Supplied By www.heating spares.co Tel. 0161 620 6677

6.20 DHW FLOW SWITCH fig. 29

Carry out component removal procedure as described in 6.4. Disconnect the cold water inlet pipe (A) from the DHW flow switch. Disconnect the wiring to the DHW flow switch. Remove the locking pin from the DHW flow switch and lift the DHW flow switch from its location. Replace in the reverse order. Ensure all seals are in good condition, taking care to ensure they are replaced correctly.

assembly. The cartridge assembly is a nonserviceable item and therefore needs to be replaced if it’s suspected as being damaged or worn. Replace in the reverse order ensuring that the seating cam inserts into the locating groove correctly (see fig. 30a). Ensure all seals are in good condition, taking care to ensure they are replaced correctly.

6.21 DHW HEAT EXCHANGER fig. 20

Carry out component removal procedure as described in 6.4. Before removing the DHW heat exchanger, it may be necessary to first remove the pump assembly and condense trap. Locate and remove the screws (E) that secure the heat exchanger to the DHW manifolds. Carefully remove the heat exchanger from its location taking care not to spill any residual water. Replace in the reverse order ensuring that the heat exchanger ‘O’ ring seals are correctly inserted into the DHW manifolds. Ensure all seals are in good condition, taking care to ensure they are replaced correctly.

Fig. 30

Fig. 31

6.24 DHW THERMISTOR fig. 31

Carry out component removal procedure as described in 6.4. Disconnect the electrical plug. Using a suitable pair of pliers, remove the thermistor locking pin (E) and ease the thermistor (F) from its seating. Replace in the reverse order ensuring the sealing ring is in good condition.

6.25 AUTOMATIC BY-PASS fig. 31

Carry out component removal procedure as described in 6.4. Locate and remove the hydraulic cover locking pin (A) and remove the cover. Using a suitable hooked wire or screwdriver, gently ease the nonreturn valve (C) from its seating. Ensure all seals are in good condition, taking care to ensure they are replaced correctly. Replace in the reverse order ensuring the cartridge is facing the correct way.

6.26 DHW NON-RETURN VALVE fig. 31

Fig. 30a

6.22 VALVE ACTUATOR fig. 30

Carry out component removal procedure as described in 6.4. Remove the locking pin (A) that secures the

6.27 EXPANSION VESSEL fig. 1

actuator (B) to the hydraulic manifold. Disconnect the electrical plug from the actuator. Replace in the reverse order.

6.23 DIVERTOR VALVE CARTRIDGE fig. 30

Carry out component removal procedure as de-

6.27.1 EXPANSION VESSEL REMOVAL (with suffi-

scribed in 6.4. Remove the valve actuator as described in 6.22. Remove the cartridge locking pin (C) and - using a suitable pair of pliers - withdraw the cartridge

Carry out component removal procedure as described in 6.4. Locate and remove the hydraulic cover locking pin (A) and remove the cover. Using a suitable hooked wire or screwdriver, gently ease the nonreturn valve (D) from its seating. Ensure all seals are in good condition, taking care to ensure they are replaced correctly. Replace in the reverse order ensuring the cartridge is facing the correct way.

Should the removal and replacement of the expansion vessel be deemed impractical, an external expansion vessel may be fitted to the return pipe as close to the appliance as possible.

cient clearance above)

Carry out component removal procedure as described in 6.4. Disconnect the flue from the appliance.

Supplied By www.heating spares.co Tel. 0161 620 6677

Disconnect the flexible expansion pipe from the vessel. Locate and remove the four screws (A) that secure the vessel top holding plate (B), remove the plate (fig. 32). The expansion vessel can now be removed. Replace in the reverse order. Ensure all seals are in good condition, taking care to ensure they are replaced correctly.

Fig. 32

6.27.2 EXPANSION VESSEL REMOVAL (with insufficient clearance above)

Carry out component removal procedure as described in 6.4. Disconnect the flexible expansion pipe from the vessel. Disconnect the flue elbow or pipe from the appliance flue outlet. Unclip and remove the air chamber cover, gently pull the cover towards you before lifting and disengaging. Remove the RH side panel of the air chamber. Disconnect the wiring to the fan, pressure switch, primary thermistor, overheat thermostat, condense switch & spark electrode, taking note of their locations. Carefully unclip the wires from the air chamber and withdraw the wiring & grommet from the air chamber.

Disconnect the outlet gas pipe, the flow & return pipes and the condense pipe from the air chamber.

Locate and remove the 2-screws that secure the lower section of the air chamber. Locate and remove the 2-screws that secure the upper section of the air chamber. The complete air chamber assembly can now be lifted clear from the appliance.

Locate and remove the 4-screws that secure the vessel (see fig. 32). The expansion vessel can now be removed. Replace in the reverse order. Take extreme care when refitting the wiring to the air chamber. Ensure all seals are in good condition, taking care to ensure they are replaced correctly.

the collector from the flue connection. Replace in the reverse order ensuring all seals are intact and located correctly.

6.28.2 DISMANTLING THE LATENT HEAT COLLECTOR

Apart from routine servicing or maintenance of the retarder and coil, the latent heat collector is a non-serviceable component, therefore, there is no requirement to disassemble the collector.

6.28.3 RETARDER fig. 35

Carry out component removal procedure as described in 6.4. Unclip and remove the air chamber cover, gently pull the cover towards you before lifting and disengaging. Remove the 3-screws that secure the sealing plate and prise the plate and sealing ring from the latent heat collector. The retarder can now be removed allowing access to the heat collector coil. Replace in the reverse order ensuring all seals are intact and correctly located.

Fig. 33

Fig. 34

6.28.1 LATENT HEAT COLLECTOR fig. 33/34/35

Carry out component removal procedure as described in 6.4. Remove the flue hood and fan assembly as detailed in 6.16. Disconnect and remove the inlet, outlet and condense pipes from the collector. Unscrew and remove the 3 screws that secure the collector to the air chamber and disconnect

Fig. 35

Supplied By www.heating spares.co Tel. 0161 620 6677

6.29 CONDENSE TRAP REMOVAL fig. 36

Carry out component removal procedure as described in 6.4. Disconnect the flexible condense pipe (1) from the condense trap. Locate and remove the condense pipe locking pin and disconnect the condense pipe (2) from the condense trap. Locate and disconnect the condense pressure switch pipe from the condense trap (3). Carefully remove the condense trap. Replace in the reverse order.

Fig. 36

SECTION 7 CHECKS, ADJUSTMENTS AND FAULT FINDING

7.1 CHECKING APPLIANCE OPERATION

When carrying out any repairs or servicing to the appliance, the relevant commissioning procedure must be undertaken to ensure the continued safe operation of the appliance. Particular attention should be made to ensure gas soundness, water soundness and the electrical integrity of the appliance.

7.2 APPLIANCE MODE OF OPERATION NOTE

There must be sufficient system water pressure (min. 0.5 bar) to ensure the water pressure switch is activated. If there is insufficient system pressure the pump and fan will be prevented from operating.

7.2.1 SELECTOR SWITCH IN THE OFF POSITION

When the selector switch is in the OFF position, the Green LED status indicator will flash every 6seconds to confirm the appliance is in standby mode. The divertor valve is in the DHW position. The appliance will not respond to any DHW or heating requests.

Active functions:

●●

● frost-protection system

●●

● pump anti-block

●●

● valve actuator anti-block

●●

● fan over-run.

7.2.2 SELECTOR SWITCH IN THE HOT WATER ONLY POSITION

When the selector switch is in the HW only position, the Green LED is illuminated:

●●

● flashing every 6-seconds if no DHW request is

●●

active

●●

● constant during a DHW request.

●●

The divertor valve is in the DHW position. The appliance will respond to any DHW requests.

Active functions:

●●

● frost-protection system

●●

● pump anti-block

●●

● valve actuator anti-block

●●

● fan over-run.

●●

7.2.3 SELECTOR SWITCH IN THE HEATING & HOT WATER POSITION

When the selector switch is in the heating & HW position, the Green LED is illuminated:

●●

● flashing every 6-seconds if no Heat or DHW

●●

request is active

●●

● constant during a heat or DHW request.

●●

The divertor valve remains in the DHW position if no heat request is active. The appliance will respond to any heating or DHW requests.

Active functions:

●●

● frost-protection system

●●

● pump anti-block

●●

● valve actuator anti-block

●●

● fan/pump over-run.

●●

7.2.4 APPLIANCE FUNCTIONS

●●

● Frost-protection: this function is only active

●●

when there are no requests for heating or HW. When the temperature of the primary thermistor drops below 5 °C, the valve actuator will motor to the heating position, whereupon the boiler will operate on minimum power until the temperature of the primary thermistor reaches 35 °C. Thereafter the pump will over-run for 30seconds.

●●

● Anti-block cycle: when there has been no

●●

heating or HW request for 19-hours, the antiblock cycle is activated. The valve actuator will motor from the DHW position to the heating position and then motor back to the DHW position. Thereafter the pump will be activated for a period of 30-seconds.

●●

● Fan over-run: should the temperature of the

●●

primary thermistor exceed 78 °C after a heating or DHW request, the pump and/or fan will run for a period of 30-seconds.

●●

● SARA function: the SARA function permits

●●

the boiler (when the set-point is within the SARA range) to automatically adjust (raise) the heating flow outlet temperature should the room thermostat contacts remain closed for more that 20-minutes.

7.2.5 DHW MODE fig. 37

With the selector switch in the Heating & HW position, or HW only position and a DHW outlet is opened, the appliance will operate in the HW mode. The valve actuator will motor to the HW position (if a heating request was active) and the pump and fan will be active. The operation of the fan causes the air pressure switch to deliver a

Supplied By www.heating spares.co Tel. 0161 620 6677

signal voltage to the control PCB. A slow ignition sequence is enabled, whereby the current supplied to the gas valve modulating coil is progressively increased from minimum to maximum over a period of 8-seconds. During this period the ignition electrode sparks continuously even if the burner has ignited.

tion of the fan causes the air pressure switch to deliver a signal voltage to the control PCB. A slow ignition sequence is enabled, whereby the current supplied to the gas valve modulating coil is progressively increased from minimum to maximum over a period of 8-seconds. During this period the ignition electrode sparks continuously even if the burner has ignited.

Fig. 37

NOTE

If the spark/sensing electrode does not sense ignition the appliance will then go to lockout.

Ignition is sensed by the electronic circuitry to ensure flame stability at the burner. Once successful ignition has been achieved, the electronic circuitry modulates the appliance output in order to achieve the DHW set-point (the position of the DHW temperature selector) as measured at the secondary thermistor.

When the set-point has been reached, the appliance will begin the modulation phase whereby the fan and gas valve will continuously modulate to maintain the set-point.

If the temperature continues to rise and exceeds the set-point by 5 °C, the burner will shut down until the temperature drops to set-point + 4 °C, whereby a new ignition sequence will be enabled.

When the request for DHW has been satisfied, the appliance fan may continue to operate to dissipate any residual heat from within the appliance.

7.2.5.1 DHW PARAMETERS

RANGE MINIMUM MAXIMUM

Temperature (°C) 37.5 60 DHW NTC fault ON at 50 °C OFF at 55 °C

7.2.6 HEATING MODE fig. 38

With the selector switch in the Heating & HW position and the relevant controls (time clock, room thermostat, etc,) are calling for heat, the appliance will operate in the heating mode. The valve actuator will motor to the heating position and the pump and fan will be active. The opera-

Fig. 38

NOTE

If the spark/sensing electrode does not sense ignition the appliance will then go to lockout. Ignition is sensed by the electronic circuitry to ensure flame stability at the burner. Once successful ignition has been achieved, the electronic circuitry allows 75% of the full gas rate through the appliance. After 15 minutes the gas rate is increased to maximum (100%).

When the set-point has been reached (the position of the heating temperature selector) as measured at the primary thermistor, the appliance will begin the modulation phase whereby the fan and gas valve will continuously modulate to maintain the set-point.

If the temperature continues to rise and exceeds the set-point by 6 °C, the burner will shut down and the boiler will perform a three-minute anticycle (timer delay).

A new ignition sequence will be enabled when the 3-minute anti-cycle has been performed and the temperature at the primary thermistor has dropped 6 °C below the set-point.

NOTES

The timer delay can be de-activated by the insertion of a ‘jumper’ on the PCB at JP1 or by isolating the appliance from the electrical supply for 30 seconds. Any DHW requests will always have priority over a heating request.

When the request for heating has been satisfied, the appliance pump and fan may continue to circulate to dissipate any residual heat within the appliance.

Supplied By www.heating spares.co Tel. 0161 620 6677

7.2.6.1 HEATING PARAMETERS

RANGE MINIMUM MAXIMUM

Temperature (°C) 4 0 80

sector 40 55

SARA sector 55 65

sector 65 80

When the boiler is operating in the SARA range, the Green LED flashes rapidly to signify the SARA function is active.

SARA FUNCTION

When the heating temperature selector is set within the SARA range (SARA sector) the boiler will automatically raise the heating flow outlet temperature by 5 °C every 20-minutes that the room thermostat contacts remain in the closed position or until the boiler reaches the maximum operating temperature.

7.3 CHECKING AND ADJUSTING BURNER PRESSURE (see fig. 19)

Although the burner pressure is factory set, it is necessary to check it during servicing or if the gas valve has been removed. Isolate the appliance from the electrical supply and attach a suitable manometer to the gas valve outlet test nipple.

Fig. 39

Fig. 40

7.3.1 SETTING THE MAXIMUM BURNER PRESSURE fig. 40

Light the boiler as described in 5.7 and compare the reading on the manometer with the value described in 2.3. If adjustment is required, remove the protective cap from the gas valve modulating coil assembly and turn the outer (10mm) nut clockwise to increase, or counterclockwise to decrease the burner pressure.

NOTE

Always check and/or adjust the minimum and maximum gas pressures whilst the appliance is in the HW only mode. Ensure a DHW outlet (preferably the bath) is fully open, and that the HW temperature selector is at maximum.

7.3.2 SETTING THE MIMIMUM BURNER PRESSURE fig. 39

Once the maximum burner pressure has been checked and/or adjusted, remove one of the grey wires from the modulating coil. Compare the reading on the manometer with the value described in 2.3. If adjustment is required, turn the inner (red) crosshead screw clockwise to increase, or counter-clockwise to decrease the burner pressure, whilst ensuring that the outer (10mm) nut does not move. When checking and/ or adjustment has been completed, isolate the appliance from the electrical supply, replace the protective cap, refit the grey wire to the modulating coil, remove the manometer and tighten the outlet test nipple.

IMPORTANT, A GAS SOUNDNESS CHECK MUST BE CARRIED OUT.

7.3.3 SETTING THE MINIMUM CENTRAL HEA TING OUTPUT THIS CAN ONLY BE CARRIED OUT AFTER THE MAXIMUM AND MINIMUM GAS PRESSURES HAVE BEEN SET.

● Isolate the appliance from the electrical supply.

● Attach a manometer to the gas valve outlet test

nipple.

● Insert a jumper tag at JP2.

● Switch the appliance ON in the heating mode.

● Turn potentiometer P5 to the minimum position

● Adjust potentiometer P4 to the required value

shown in section2.3 (section 10.2 for LPG), i.e. minimum burner pressure (central heating).

● Turn potentiometer P5 back to the maximum

position.

● Isolate the appliance from the electrical supply.

● Remove the manometer, tighten the outlet test

nipple, and check for soundness.

7.4 COMBUSTION ANALYSIS TEST

A combustion analysis check can easily be carried out on the appliance via the test points located on the top of the appliance, however you must check that the burner pressures are set correctly (see 7.3).

● Isolate the appliance from the electrical supply

and turn the mode selector switch to the OFF/ RESET position.

● Locate and remove the CO test point sealing

screw (see fig. 41).

● Insert the flue gas analyser probe into the test

point.

● Restore the electrical supply to the appliance

● Remove the mode selector knob and turn the

shaft fully clockwise (see fig. 42).

Supplied By www.heating spares.co Tel. 0161 620 6677

● The boiler will now enter the combustion analy-

sis mode (CO mode) for a period of 15 minutes, signified by the LED flashing Yellow. During this time, the boiler will remain on full gas.

● Once the flue gas analysis has been made, turn

the shaft back to the required position and replace the mode selector knob.

● Remove the probe and replace the sealing

screw.

Air

analysis

outlet

Fig. 41

Fumes

analysis

outlet

GREEN LED

Frequency Faults/Status

ON every 6-secs At stand-by with no faults

Flashing 8-times a second SARA function active

ON every 0.5-secs Temporary fault, e.g.:

Solid Active for heat/DHW request

●●

● APS fault

●●

● low water pressure

●●

YELLOW LED

Frequency Faults/Status

ON every 0.5-secs CO function active

Solid DHW thermistor fault (see 7.2.5.2)

RED LED

Frequency Faults/Status

ON every 0.5-secs Final fault, e.g.:

Solid

●●

● water pressure switch

●●

● condense pressure switch

●●

● fan/flue problem

●●

● limit thermostat

●●

● primary NTC open/short circuit

●●

7.7 ELECTRICAL CHECKS

Any electrical checks must be carried out by a suitably qualified person.

Fig. 42

7.5 CHECKING THE EXPANSION VESSEL

Carry out the component removal procedure as described in 6.4. You must ensure that the boiler is completely drained of water. Using a suitable pressure gauge, remove dust cap on expansion vessel and check the charge pressure. The correct charge pressure should be

1.0 bar ± 0.1 bar. If the charge pressure is less, use a suitable pump to increase the charge.

NOTE

You must ensure the drain valve is in the open position whilst re-charging takes place. Replace the dust cap and carry out the relevant commissioning procedure (section 5).

7.6 EXTERNAL FAULTS

Before carrying out any faultfinding or component replacement, ensure the fault is not attributable to any aspect of the installation.

7.6.1 INSTALLATION FAULTS

Symptom Possible causes

No ignition Check wiring

Check electrical supply

No hot water Check hot/cold pipe

work is not reversed

No central heating Check wiring of room thermostat

and/or other external controls

7.7.1 EARTH CONTINUITY TEST

Isolate the appliance from the electrical supply, and using a suitable multi-meter carry out a resistance test. Connect test leads between an appliance earth point and the earth wire of the appliance supply cable. The resistance should be less than 1 OHM. If the resistance is greater than 1 OHM check all earth wires and connectors for continuity and integrity.

7.7.2 SHORT CIRCUIT CHECK

Isolate the appliance from the electrical supply, and using a suitable multi-meter, carry out a short circuit test between the Live & Neutral connections at the appliance terminal strip (fig.16).

Repeat above test on the Live & Earth connections at the appliance terminal strip (fig.16).

NOTE

Should it be found that the fuse has failed but no fault is indicated, a detailed continuity. Check will be required to trace the fault. A visual inspection of components may also assist in locating the fault.

7.7.3 POLARITY CHECK

With the appliance connected to the electrical supply and using a suitable multimeter, carry out the following voltage tests:

●●

● Connect test leads between the Live & Neutral

●●

connections at the appliance terminal strip (fig.16). The meter should read approximately 230V ac. If so proceed to next stage. If not, see

7.7.4.

●●

● Connect test leads between the Live & Earth

●●

connections at the appliance terminal strip (fig.16). The meter should read approximately 230V ac. If so proceed to next stage. If not, see

7.7.4.

●●

● Connect test leads between the Neutral &

●●

Earth connections at the appliance terminal strip (fig.16). The meter should read approximately 0 - 15Vac. If so polarity is correct. If not, see 7.7.4.

Supplied By www.heating spares.co Tel. 0161 620 6677

7.7.4 REVERSED POLARITY OR SUPPLY FAULT

Repeat the above tests at the appliance isolator, if testing reveals correct polarity and/or supply at the isolator, re-check wiring and connections between the isolator and the appliance. If tests on the isolator also reveal reversed polarity or a supply fault, consult the local electricity supplier for advice.

7.7.5 RESISTANCE TO EARTH CHECK

Isolate the appliance from the electrical supply and using a suitable multi-meter carry out a resistance test. Connect test leads between the Live & Earth connections at the appliance terminal strip (fig.16). If the meter reads other than infinity there is a fault that must be isolated, carry out a detailed continuity check to identify the location of the fault.

IMPORTANT

These series of checks must be carried out before attempting any faultfinding procedures on the appliance. On completion of any task that required the disconnection and re-connection of any electrical wiring or component, these checks must be repeated.

7.8 FAULT FINDING

Before attempting any faultfinding, the electrical checks as detailed in 7.7 must be carried out. Isolate the appliance from the electrical supply. Disconnect any external controls such as room thermostats etc. from the boiler.

7.9 FAULT CODES

When the boiler is in a fault condition, the LED is displayed in a colour and/or frequency that is relevant to the fault. To reset the boiler, turn the mode selector switch to the reset position (0) for 2-minutes’ then back to the relevant mode of operation.

If the boiler does not reset, refer to the following section and the detailed faultfinding flowcharts overleaf.

YELLOW LED

Frequency Faults/Status

ON every 0.5-secs CO function active

Solid DHW* thermistor fault (see 7.2.5.2)

* When there is a fault condition with the DHW thermistor, the

appliance will still operate and produce limited hot water. The Primary thermistor will control the temperature of the DHW during this period and the outlet temperature is fixed at 50-

RED LED

Frequency Faults/Status

ON every 0.5-secs Final fault, e.g.:

Solid

●●

● water pressure switch

●●

● condense pressure switch

●●

● fan/flue problem

●●

● limit thermostat

●●

● primary NTC open/short circuit

●●

7.8.1 REPLACING THE MAIN PCB

When replacing the main PCB it’s essential that the potentiometers are set as follows:

● It’s essential that the minimum - central heating

- gas pressure is checked/adjusted as described in 7.3.3

● P4 - to be used to set/adjust the minimum

heating output

● P5 - set at maximum.

EFFECT OF JUMPER TAGS FITTED TO THE MAIN PCB AT:

● JP1 - disables DHW function

● JP2 - cancels anti-cycle function and initial

heating output (75% of maximum at start up)

● JP3 - for LPG boilers only

● JP4 - enables DHW temperature stabiliser

function (boiler modulates at set point and remains on minimum power, even if the set point is exceeded).

NOTE

If the Vokera remote-control (RC05) is connected to the appliance, it should be disconnected during any faultfinding checks.

Restore the electrical supply to the boiler and turn the selector switch to the on position. The boiler should now function as described in section 7.2. Should the boiler fail to respond, the internal fuses and connectors should be checked to ensure integrity and continuity. If the boiler still fails to respond, refer to the detailed faultfinding flowcharts overleaf.

Supplied By www.heating spares.co Tel. 0161 620 6677

7.10.1 FAULT FINDING TEST ‘A’: CHECKING OPERATION OF ELECTRONIC CONTROL BOARD AT START UP

START

SWITCH ON BOILER AND

SELECT MODE TO

WINTER C/H

THERMOSTAT AT MAX.

YES

RESTART THE

TEST

THERE 24dc

BETWEEN TERMINALS

CN9.1 & CN9.2

ON PCB

YES

WATER

PRESSURE SWITCH/

CONDENSE PRESSURE

SWITCH

ARE OK

CHECK WIRING AND CONNECTIONS

OR WATER PRESSURE SWITCH/

CONDENSE PRESSURE SWITCH

REPLACE

CONTROL BOARD

MAINS ON

PUMP CONNECTOR

CN2.1 & CN2.2

ON PCB

LOOSE THE PUMP

ACTING WITH A

SCREWDRIVER ON

THE IMPELLER

PUMP RUNNING

MAINS

BETWEEN PIN

CN1.4 & CN1.5

ON PCB

YES

CHECK IDRAULIC

CIRCUIT

YES

REPLACE

PUMP

THERMOSTAT

INPUT LINKED

CHECK WIRING OR

CONNECTIONS BETWEEN TERMINAL STRIP AND CONTROL

MADE A LINK BETWEEN BLACK &

BLACK WIRES AT BOILER

TERMINAL STRIP AND CLOSE THE

YES

REPLACE WIRING

OR CONNECTIONS

CHECK &/OR

REPLACE WIRING

CONNECTIONS

YES

IS ROOM

YES

BOARD

TIMER CONTACT

PUMP

RUNNING

MAINS

ON PUMP

YES

AND

THERE 24dc

BETWEEN TERMINALS

CN8.3 & CN8.5

ON PCB

REPLACE

CONTROL BOARD

MADE A LINK

BETWEEN THE ROOM

THERMOSTAT INPUT

RESTART THE

MAINS

ON FAN

CONNECTOR

CN4.1 & CN4.2

ON PCB

TEST

YES

FAN RUNNING

REPLACE WIRING

OR CONNECTIONS

GREEN LED

MAINS

ON FAN

BETWEEN TERMINALS

YES

AIR FLOW

SWITCH

OFF?

YES

BLINKS

YES

REPLACE FAN

THERE 0 VCC

CN8.3 & CN8.5

ON PCB

YES

REPLACE

CONTROL BOARD

REPLACE AIR FLOW SWITCH OR CHECK FLUE GAS

TUBE

Supplied By www.heating spares.co Tel. 0161 620 6677

7.10.2 FAULT FINDING TEST ‘A’

END

REPLACE

SENSING/SPARK

ELECTRODE AND

LEAD

THERE 0 Vdc

BETWEEN TERMINALS

CN8.7 & CN8.8

ON PCB

SPARK AT

ELECTRODE

YES

IGNITION

YES

LOCKOUT

AFTER

IGNITION

YES

CHEK

SENSING/SPARK

ELECTRODE AND

LEAD

SENSING

SPARK ELECTRODE

AND LEAD

YES

REPLACE PCB

YES

REPLACE THE

CONTROL BOARD

CHECK AND/OR

REPLACE PCB

CHECK WIRING AND

CONNECTIONS OR

THERE 230 Vac

BETWEEN TERMINALS

CN5.1 & CN5.2

ON PCB

THERE 24 Vdc

BETWEEN TERMINALS

CN8.4 & CN8.5

ON PCB

THERE 24 Vdc

BETWEEN TERMINALS

CN8.4 & CN8.8

ON PCB

HIGH LIMIT

THERMOSTAT

CHECK WIRING AND

CONNECTIONS, AIR FLOW

SWITCH AND CONTROL

YES

MAINS

ON E.V.G.

CHECK AND/OR

REPLACE PCB

YES

THERE 24 Vdc

BETWEEN TERMINALS

CN8.4 & CN8.7

ON PCB

YES

BOARD

CHECK/CLEAN THE

VENTURI TUBE AND

SILICONE AIR

TUBES

YES

CHECK REPLACE

AIR FLOW SWITCH

YES

THERE 230 Vac

BETWEEN TERMINALS

CN6.1 & CN6.2

ON PCB

CHECK

SENSING/SPARK

ELECTRODE AND

LEAD

DO THE

AIR FLOW SWTCH

TURN ON

ARE THE

VENTURI TUBE

AND THE SILICONE

AIR TUBES

CLEAN

YES

THE AIR DP >

11 mmCH2O

YES

CHECK WIRING AND

CONNECTIONS OR

HIGH LIMIT THERMOSTAT

CHECK WIRING

AND

CONNECTIONS

REPLACE EVG

EVG OK

YES

CHECK GAS

CHECK THE FAN

AND/OR FLUE GAS

TUBE

Supplied By www.heating spares.co Tel. 0161 620 6677

7.10.3 FAULT FINDING TEST ‘A1’

YES

REPLACE CONTROL

BOARD

SELECTOR ON OFF

YES

RESTART THE

TEST

RED LED

BLINKS

YES

SWITCH ON/OFF

POSITION

SWITCH ON/OFF

SELECTOR TO

WINTER POSITION

GREEN LED

BLINKS

RED LED

LIGHT

CHECK CH NTC

SENSOR OR WIRING

AND CONNECTIONS

PRESENT BETWEEN

YES

BLUE & BROWN WIRES AT

REPLACE WIRING OR

CONNECTIONS

TERMINAL STRIP AND

CONTROL BOARD

YES

BOILER TERMINAL

YELLOW

LED

LIGHT

YES

CHIMNEY

SWEEPER CYCLE.

RESET AND

RESTART TEST

MAINS

STRIP

YELLOW LED

BLINKS

RECHECK SUPPLY

FUSE &

CONNECTORS TO

BOILER

TERMINALS

MAINS

PRESENT BETWEEN

TERMINALS CN1.2

&CN1.3 M2.2 ON

CONTROL

BOARD

YES

CHECK FUSE F1

ON CONTROL

BOARD

YES

BETWEEN TERMINALS

THERE 24 Vdc

BETWEEN TERMINALS

CN8.4 & CN8.6

ON PCB

YES

THERE 24 Vdc

BETWEEN TERMINALS

CN8.4 & CN8.5

ON PCB

CHECK WIRING AND

CONNECTIONS OR

AIR PRESSURE SWITCH

THERE 24 Vdc

CN8.4 & CN8.7

ON PCB

REPLACE

CONTROL BOARD

YES

THERE 24 Vdc

BETWEEN TERMINALS

CN8.4 & CN8.8

ON PCB

YES

CHECK WIRING AND

CONNECTIONS OR

HIGH LIMIT THERMOSTAT

YES

REPLACE

CONTROL BOARD

THERE 0 VCC

BETWEEN TERMINALS

CN9.1 & CN9.2

ON PCB

REPLACE

CONTROL BOARD

REPLACE

CONTROL BOARD

CHECK WIRING AND

CONNECTIONS, WATER

PRESSURE SWITCH AND

HYDRAULIC CIRCUIT

YES

FUSE OK

REPLACE FUSE

RESTART THE

TEST

Supplied By www.heating spares.co Tel. 0161 620 6677

7.10.4 FAULT FINDING TEST ‘B2’: CHECK CONTROL IN DHW MODE

START

SWITCH ON BOILER AND

SELECT MODE TO

SUMMER. DHW

THERMOSTAT AT MAX.

TURN ON TAP

DOES

BURNER LIGHT

YES

3 WAY

MIXING VALVE

IS IN DHW POSITION

YES

VOLTAGE

ACROSS TERMINALS

OF MODULATOR

COIL > 10 VDC

REPLACE PCB

CHECK OR REPLACE THE

ELECTRICAL 3 WAY

MIXING VALVE,

CABLES AND

CONNECTIONS

YES

VOLTAGE >10 VDC

BETWEEN TERMINALS

THERE IS 230 Vac

BETWEEN CN3.1 AND

CN3.3 ON THE PCB

THERE A

CN9.3 & CN9.4

ON PCB

THERE 24 Vdc

BETWEEN TERMINALS

CN9.7 & CN9.8

ON PCB

CHECK BOILER

YES

DHW FLOW SWITCH

OK?

CHECK WIRING AND

CONNECTIONS OR

DHW SWITCH

STARTUP: TEST A

YES

REPLACE

CONTROL

BOARD

YES

IS THE

RESISTENCE OF

MODULATOR COIL

ABOUT 70/80

OHM

REPLACE

MODULATOR COIL

REPLACE WIRE

AND

CONNECTIONS

WAIT D.H.W.

TEMPERATURE

>40 °C

YES

REPLACE

CONTROL BOARD

D.H.W.

TEMPERATURE

>40 °C

YES

REPLACE

CONTROL BOARD

YES

WAIT TILL THE

VOLTAGE BETWEEN

TERMINAL CN9.3 & CN9.4

ON PCB IS < 1.2 Vdc

IS THE

VOLTAGE BETWEEN

TERMINAL CN9.3 &

CN9.4 ON PCB IS

< 1.2 Vdc

YES

SWITCH DHW

THERMOSTAT AT MIN.

BURNER AND FAN

SWITCH OFF

YES

D.H.W.

TEMPERATURE

>60 °C

YES

D.H.W. NTC

REPLACE D.H.W. NTC

WAIT D.H.W.

TEMPERATURE

>60 °C

YES

REPLACE

CONTROL BOARD

Supplied By www.heating spares.co Tel. 0161 620 6677

7.10.5 FAULT FINDING TEST ‘C’: CHECK CONTROL IN C/H MODE

START

SWITCH ON BOILER

AND SELECT MODE

TO WINTER C/H

THERMOSTAT AT

MAX.

MADE A LINK BETWEEN

BLACK & BLACK WIRES AT

BOILER TERMINAL

STRIP AND CLOSE THE

TIMER CONTACT

ACROSS TERMINALS OF

VOLTAGE

MODULATOR COIL

>10 VDC

CONTROL BOARD

THERE A

VOLTAGE <8 VDC

BETWEEN TERMINALS

CN9.3 & CN9.4

ON PCB

REPLACE

YES

YES NO

VOLTAGE

ACROSS TERMINALS OF

MODULATOR COIL

< 8 VDC

YES

TIMER JUMPER

YES

REMOVE JUMPER

RESTART THE

TEST

DOES

BURNER

LIGHT

YES

ACROSS TERMINALS OF

MODULATOR COIL

YES

WAIT TILL THE

VOLTAGE BETWEEN

TERMINAL CN9.3 & CN9.4

ON PCB IS < 1.2 Vdc

CHECK BOILER

STARTUP TEST A

SET TIMER

JUMPER ON

VOLTAGE

>10 VDC

CONTROL BOARD

REPLACE

REPLACE WIRE

IS THE

RESISTENCE OF

MODULATOR COIL

ABOUT 70/80

OHM

REPLACE

MODULATOR COIL

AND

CONNECTIONS

SWITCH CH

THERMOSTAT AT MIN.

YES

REPLACE

CONTROL BOARD

YES

REPLACE

C.H. NTC

IS THE

VOLTAGE BETWEEN

TERMINAL CN9.3 &

CN9.4 ON PCB IS

< 1.2 Vdc

D.H.W.

TEMPERATURE

>80 C

YES

C.H. NTC

WAIT D.H.W.

TEMPERATURE

>80 C

YES

REPLACE

CONTROL BOARD

Supplied By www.heating spares.co Tel. 0161 620 6677

7.10.6 TEST ‘C’ CONT’D

THERMOSTAT AT MAX.

BURNER AND FAN

WAIT 3 MIN.

YES

BURNER AND FAN

SWITCH ON

SWITCH CH

SWITCH ON

YES

BURNER AND FAN

SWITCH OFF

REPLACE

CONTROL BOARD

YES

REPLACE

CONTROL BOARD

YES

WAIT WATER FLOW

IS WATER FLOW TEMPERATURE

>40 C

TIMER JUMPER

TEMPERATURE

< 80 C

WAIT WATER FLOW

TEMPERATURE

>40 C

YES

REMOVE JUMPER

RESTART THE

TEST

OPEN THE TIMER

CONTACT

BURNER

AND FAN

SWITCH

OFF

YES

WAIT

30 SECS.

PUMP SWITCH

OFF

YES

END

REPLACE

CONTROL BOARD

REPLACE

CONTROL BOARD

IS WATER FLOW TEMPERATURE

>80 C

C.H. NTC

REPLACE C.H. NTC

YES

REPLACE

CONTROL BOARD

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 8 WIRING DIAGRAMS

8.1 EXTERNAL WIRING

The appliance comes with a factory fitted clock to allow basic operation of the boiler (fig. 43). If external controls are to be added to the system, they must be connected to the appliance as shown in the following diagrams. For advice on controls that are not featured in this book, please contact Vokera technical on 0870 333 0520.

factory configuration

8.3 VOKERA REMOTE CONTROL

The RC05 remote control must be connected to the appliance as shown in fig. 44. The RC05 can be used in 3-modes:

● Boiler only control, whereby the RC05 con-

trols only the functions of the appliance (Heating & DHW temperature, reset function, fault code display, etc).

● Boiler control with room thermostat func-

tion, whereby the RC05 controls the functions of the appliance (Heating & DHW temperature, reset function, fault code display, etc) and also functions as a room thermostat.

● Boiler control with programmable room

thermostat, whereby the RC05 controls the functions of the appliance (Heating & DHW temperature, reset function, fault code display, etc) and also functions as a programmable room thermostat.

NOTE

If the RC05 is used in the “boiler only” mode, an additional control (such as the integral clock) will be required to switch the heating terminals.

Full details of the operation of the RC05 and its functions can be found in the installations and users instructions of the RC05.

Fig. 43

8.2 TYPICAL CONTROL APPLICATIONS

The appliance can be used with the following controls:

● Vokera RC05 remote control (part no. 405) and

Compact interface (part no. 409)

● Vokera external sensor (must be used in con-

junction with the RC05), (part no. 2359259)

● external single-channel, voltage-free time clocks

● programmable room thermostats.

In addition, the appliance can be used in conjunction with a typical ‘S’-Plan system, please contact Vokera technical for further detailed instruction.

NOTE

This appliance is not suitable for use with ‘Y’-Plan systems.

Fig. 44

8.4 ROOM THERMOSTAT

Should a room thermostat be required, it must be of the ‘voltage-free’ type, and should be connected to the appliance as shown in fig. 45.

Fig. 45

8.5 OTHER CONTROLS

Contact the controls manufacturer and/or Vokera technical department should you require more specific information on the suitability of a particular control. Further guidance on the recommended practice for the installation of external controls, can be found in CHeSS - HC5/HC6 (www.energyefficiency.gov.uk).

Supplied By www.heating spares.co Tel. 0161 620 6677

FUNCTIONAL DIAGRAM

NOTE: L-N-E CONNECTION IS ADVISABLE

JP4 Jumper disable/enable DHW absolut thermostat

P1 Domestic hot water temperature control

P2 Central heating temperature control

P3 Off/summer/winter/combustion test

P4 Minimum heating regulation

Led alarm (red)

Combustion test (blink orange)

P5 Heating potentiometer (must be set to max)

F1-F2 Fuse 2 AF

S.S.E. Spark\Sense electrode

CP04X Control board

CN1-CN9 Connectors

RL1 Pump relay

RL2 Fan relay

RL3 Diverter valve motor relay

RL4 Ignition relay

TRF1 Trasformer

TRX Ignition trasformer

ACF01X Ignition control board

M3-M6 External connections block

LED Led OK (green)

Fig. 46

F2 = fuse 2AF

Key

D.H.W.F.S. Domestic hot water flow switch

P.S. Pressure switch

P.D.S. Differential pressure switch

H.L.T. High limit thermostat

H.T. Heat thermistor

D.H.W.T. Domestic hot water thermistor

C.P.S. Condense pressure switch

MOD Modulator

F Fan

P Pump

3 W 3 way motor

OPE Gas valve solenoids

JP1 C.H. only selector

JP2 Setting timer

JP3 Natural gas or L.P.G. selector

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 9 EXPLODED DIAGRAMS

270

300

226

301

226

POS. DESCRIPTION 25 HE 29 HE

1 Frame assembly 01005403 01005406 12 Pressure gauge 10024019 10024019 18 Cover assembly 10026475 10026475 20 Printed Circuit Board 10025340 10025340 21 Led light guide 10023816 10023816 26 Instrumental panel 10027547 10027547 27 Control knob 10023937 10023937 28 Selection knob 10023936 10023936 31 Case 10026164 10026179 40 Instrumental panel cover 10027549 10027549 49 Adapter 10023935 10023935 61 Cover assembly 01005404 01005404 76 Timer 10023938 10023938 90 Fuse 3478 3478

226 Edge clip 5128 5128 270 Transformer 10021272 10021272 300 Wiring harness (clock) 10023840 10023840 301 Wiring harness (clock) 10023940 10023940

Supplied By www.heating spares.co Tel. 0161 620 6677

290

201

438

433

432

288

435

266

353

351

439

288 435

266

353

201

436

441

432

265

442

432

444

290

443

288

439

343

521

433

438

433

351

432

434

201

265

112

300

POS. DESCRIPTION 25 HE 29 HE

1 Domestic water heat exchanger 8036 8037 2 Connection 10024640 10024640 3 Pressure switch 2044 2044 4 Non return valve 10025056 10025056 6 By-pass casing 10024641 10024641 7 By-pass valve 2047 2047

9 Heating manifold and cartridge 10026508 10026508 10 3 way valve cartridge 10025305 10025305 11 Motorized valve 10025304 10025304 12 Fixing fork wrench 10025450 10025450 13 Fixing fork wrench 10025449 10025449 22 Safety valve 10025055 10025055 24 Flow governor 10026043 10024987 25 Pipe 10027544 10027544 26 DHW actuator 10022349 10022349 27 Heating cock 1789 1789 28 Connection 1790 1790 30 Heating cock 7099 7099 37 Pipe 10025840 10025840 47 By-pass casing cover 10024643 10024643 48 Discharge cock 10024646 10024646 63 Pipe 10026228 10026228

112 Pressure switch 10027535 10027535 201 Washer 5026 5026 265 Washer 5236 5236 266 Washer 5237 5237 288 Washer 6898 6898 290 Clip 2165 2165 351 Nut 1823 1823 353 Nut 1824 1824 432 Clip 10024958 10024958 433 Clip 10024986 10024986 434 Nipple 10024985 10024985 435 Connection 10025059 10025059 436 Clip 10025062 10025062 438 O-Ring 10024988 10024988 439 Washer 10025067 10025067 441 Clip 10025063 10025063 442 O-Ring 10025065 10025065 443 O-Ring 10025064 10025064 444 Washer 10025066 10025066 521 NTC sensor (red O-Ring) 10027351 10027351 600 Wiring harness (PCB + ground faston frame, ground faston floz switch pump diverter valve H20

pressure switch condense, pressure switch gas valve (modulator + safety coils) DHW NTC) 10027558 10027558

Supplied By www.heating spares.co Tel. 0161 620 6677

532

201

396

200

394 395

288

394

200

370

371

202

520

200

393

200

417

290

POS. DESCRIPTION 25 HE 29 HE

1 Expansion vessel 2204 2573 2 Flexible pipe 10025188 10025188 3 Circulation pump 10027571 10027571 4 Automatic air vent bottle 10025485 10025485 6 Pipe 10027541 10027566 7 Pipe 10024312 10024130 8 Heat exchanger 2381 2378

9 Pipe 10021041 10021041 10 Pipe 10027542 10027567 25 Siphon 10027546 10027546 27 Pipe 10027543 10027568 43 Condensing unit assembly 01005291 01005291 45 Retarder 10024136 10024136 48 Pipe 10024311 10024129 49 Pipe 10024313 10024313 66 Flexible pipe 10027545 10027545

200 Washer 24 x 17 5023 5023 201 Washer 18,5 x 11 5026 5026 202 Washer 5041 5041 288 O-Ring 6898 6898 290 Clip 2165 2165 314 Connection 2186 2186 370 O-Ring 10023533 10023533 371 Clip 10023532 10023532 393 O-Ring 10024141 10024141 394 O-Ring 10024142 10024142 395 O-Ring 10024143 10024143 396 Connections kit 01005292 01005292 417 Limit thermostat 10024710 10024710 520 NTC sensor (red O-Ring) 10027352 10027352 532 Washer 10027540 10027540

Supplied By www.heating spares.co Tel. 0161 620 6677

200

300

301

200

POS. DESCRIPTION 25 HE 29 HE

1 Air box bottom 10027533 10027562 2 Ambidx air box side 10024166 10024166 3 Clip 0442 0442 4 Burner assembly 10027536 10027564 5 Spark electrode 10025985 10025985

9 Burner plate 5172 5172 12 Gas pipe 10027537 10027537 13 Gas valve 10025074 10025074 14 Gas pipe 10026703 10026703 15 Gas cock 10020897 10020897 16 Air box cover 10020216 10020217 17 Washer 5072 5072 18 Glass 3139 3139 19 Flange 4007 4007 20 Gas valve solenoid 10020838 10020838 21 Washer 5905 5905 27 Hole cap 8084 8084

200 Washer 5023 5023 300 N.G. conversion kit 01005225 01005225 301 LPG conversion kit 01005407 01005407

Supplied By www.heating spares.co Tel. 0161 620 6677

100

POS. DESCRIPTION 25 HE 29 HE

1 Combustion chamber assembly 10025935 10026406 2 Combustion chamber back panel 5270 5316 3 Combustion chamber lateral panel 5271 5271 4 Combustion chamber front panel 5269 5315

7 Hood assembly 10024310 10024125 10 Fan 10024035 10024035 13 Venturi and pressure tube kit 01005405 01005405 16 Clamp for tube 10024126 10024126 19 Fan flue connection 10024137 10024137 20 Block with combustion analysis check 10026933 10026933 23 Brass cap 8086 8086 25 Pressure differential switch 10020889 10020889

100 Combustion - fan cable (PCB ground faston f an H

NTC flue pressure switch) 10027559 10027559

O limit thermostat CH

Supplied By www.heating spares.co Tel. 0161 620 6677

SECTION 10 L.P.G. INSTRUCTIONS

10.1 RELATED DOCUMENTS

BS 6798 INSTALLATION OF BOILERS OF RATED NOT EXCEEDING 60kW BS 5449 PART 1 FORCED CIRCULATION HOT WATER SYSTEMS BS 5546 INSTALLATION OF GAS HOT WATER SUPPLIES FOR DOMESTIC PURPOSES BS 5440 PART 1 FLUES BS 5482 PART 1 DOMESTIC BUTANE & PROPANE GAS BURNERS IN PERMAMENT DWELLINGS

10.2 TECHNICAL DATA

GAS PRESSURES 25 29 35

Inlet pressure 37 mbar 37 mbar 37 mbar Burner pressure maximum 35.70 mbar 35.50 mbar 35.60 mbar Burner pressure minimum (heating) 12.80 mbar 10.00 mbar 7.00 mbar Burner pressure minimum (DHW) 4.90 mbar 4.50 mbar 3.20 mbar Maximum gas rate 1.94 Kg/h 2.25 Kg/h 2.70 Kg/h Minimum gas rate 1.16 Kg/h 1.16 Kg/h 1.16 Kg/h Injectot size (quantity) 12 x 0.76 14 x 0.76 16 x 0.76 SEDBUK (%) 87.1 Band “B” 87.7 Band “B” 89.57 Band “B” NOx (max - min) PPM 250 - 170 250 - 180 250 - 180 CO (max - min) PPM 90 - 100 120 - 120 65 - 120 CO2 (%) 7.50 - 4.35 7.60 - 4.50 7.60 - 3.05 CO/CO

ratio (max - min) 0.0012 to 1 - 0.0022 to 1 0.0015 to 1 - 0.0026 to 1 0.0008 to 1 - 0.0039 to 1

10.3 CONVERTING THE APPLIANCE GAS TYPE

To convert the appliance to another gas type it is necessary to change the burner injectors and adjust the gas pressures. It is also necessary to ensure the jumper tag at JP3 is enabled or disabled according to the gas type used.

● To change the injectors see section 6.

● For correct jumper tag configuration see 7.8.

10.4 GAS SUPPLY

The gas supply must be connected to the appliance by a competent LPG installer and must be of sufficient size to supply the appliance at its maximum output.

An existing supply must be checked to ensure that it is of adequate size to deal with the maximum rated input of this and any other appliances that it serves.

10.5 GAS SUPPLY INSTALLATION

The entire installation including the meter must be purged and checked for gas soundness.

10.6 CHECKING AND ADJUSTING BURNER PRESSURE (see fig. 26)

Isolate the appliance from the electrical supply and attach a suitable manometer to the gas valve outlet test point.

10.6.2 SETTING THE MINIMUM BURNER PRESSURE fig. 39

Once the maximum burner pressure has been checked and/or adjusted, remove one of the grey wires from the modulating coil. Compare the reading on the manometer with the value described in 10.2.

If adjustment is required, turn the inner (red) crosshead screw clockwise to increase, or counter-clockwise to decrease the burner pressure, whilst ensuring that the outer (10mm) nut does not move. When checking and/or adjustment and/or adjustment has been completed, isolate the appliance from the electrical supply, close the DHW outlet, replace the protective cap, refit the grey wire to the modulating coil, remove the manometer, and tighten the outlet test point.

IMPORTANT, A GAS SOUNDNESS CHECK MUST BE CARRIED OUT.

10.6.1 SETTING THE MAXIMUM BURNER PRESSURE fig. 40

Light the boiler as described in 5.7, fully open a DHW outlet (preferably the bath) and ensure the HW temperature selector is set at maximum. Allow the appliance to stabilise.

Compare the reading on the manometer with the value described in 10.2. If adjustment is required, remove the protective cap from the gas valve modulating coil assembly and turn the outer (10mm) nut clockwise to increase, or counterclockwise to decrease the burner pressure

Supplied By www.heating spares.co Tel. 0161 620 6677

BENCHMARK No.

COLLECTIVE MARK

GAS BOILER COMMISSIONING CHECKLIST

BOILER SERIAL No. NOTIFICATION No.

CONTROLS To comply with the Building Regulations, each section must have a tick in one or other of the boxes

TIME & TEMPERATURE CONTROL TO HEATING ROOM T/STAT & PROGRAMMER/TIMER PROGRAMMABLE ROOMSTAT

TIME & TEMPERATURE CONTROL TO HOT WATER CYLINDER T/STAT & PROGRAMMER/TIMER

HEATING ZONE VALVES FITTED NOT REQUIRED

HOT WATER ZONE VALVES FITTED NOT REQUIRED

THERMOSTATIC RADIATOR VALVES FITTED

AUTOMATIC BYPASS TO SYSTEM FITTED NOT REQUIRED

COMBI BOILER

FOR ALL BOILERS CONFIRM THE FOLLOWING

THE SYSTEM HAS BEEN FLUSHED IN ACCORDANCE WITH THE BOILER MANUFACTURERS INSTRUCTIONS?

THE SYSTEM CLEANER USED

THE INHIBITOR USED

FOR THE CENTRAL HEATING MODE, MEASURE & RECORD

N/A

/hr

GAS RATE

BURNER OPERATING PRESSURE (IF APPLICABLE)

CENTRAL HEATING FLOW TEMPERATURE °C

CENTRAL HEATING RETURN TEMPERATURE °C

/hr

FOR COMBINATION BOILERS ONLY

HAS A WATER SCALE REDUCER BEEN FITTED? YES NO

WHAT TYPE OF SCALE REDUCER HAS BEEN FITTED?

FOR THE DOMESTIC HOT WATER MODE, MEASURE & RECORD

N/A

/hr

GAS RATE

MAXIMUM BURNER OPERATING PRESSURE (IF APPLICABLE) mbar

COLD WATER INLET TEMPERATURE °C

HOT WATER OUTLET TEMPERATURE °C

WATER FLOW RATE

FOR CONDENSING BOILERS ONLY CONFIRM THE FOLLOWING

THE CONDENSATE DRAIN HAS BEEN INSTALLED IN ACCORDANCE WITH THE MANUFACTURERS INSTRUCTIONS? YES

FOR ALL INSTALLATIONS CONFIRM THE FOLLOWING

THE HEATING AND HOT WATER SYSTEM COMPLIES WITH CURRENT BUILDING REGULATIONS

THE APPLIANCE AND ASSOCIATED EQUIPMENT HAS BEEN INSTALLED AND COMMISSIONED IN ACCORDANCE WITH THE MANUFACTURERS INSTRUCTIONS

IF REQUIRED BY THE MANUFACTURER, HAVE YOU RECORDED A CO/CO2RATIO READING? N/A YES CO/CO2RATIO

THE OPERATION OF THE APPLIANCE AND SYSTEM CONTROLS HAVE BEEN DEMONSTRATED TO THE CUSTOMER

THE MANUFACTURERS LITERATURE HAS BEEN LEFT WITH THE CUSTOMER

/hr

lts/min

COMMISSIONING ENGS NAME

PRINT CORGI ID No.

SIGN DATE

Supplied By www.heating spares.co Tel. 0161 620 6677

SERVICE INTERVAL RECORD

It is recommended that your heating system is serviced regularly

and that you complete the appropriate Service Interval Record Below.

Service Provider. Before completing the appropriate Service Interval Record below, please ensure you have carried out the service

as described in the boiler manufacturers instructions. Always use the manufacturers specified spare part when replacing all controls

SERVICE 1

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

SIGNATURE

SERVICE 3

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

SIGNATURE

SERVICE 5

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

DATE

SERVICE 2

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

SIGNATURE

SERVICE 4

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

SIGNATURE

SERVICE 6

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

DATE

SIGNATURE

SERVICE 7

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

SIGNATURE

SERVICE 9

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

SIGNATURE

DATE

SIGNATURE

SERVICE 8

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

SIGNATURE

SERVICE 10

ENGINEER NAME

COMPANY NAME

TEL No.

CORGI ID CARD SERIAL No.

COMMENTS

SIGNATURE

DATE

Supplied By www.heating spares.co Tel. 0161 620 6677

Cod. 10028045 - 42/05 - Ed. 1

Registered address:

Unit 7 Riverside Industrial Estate

enquiries@vokera.co.uk

www.vokera.co.uk

Sales, General Enquires

Vokèra Limited reserve the right to change

specification without prior notice

Consumers statutory rights are not affected.

A Riello Group Company.

Company Reg No: 1047779

Vokèra Ltd

Borderlake House

London Colney Herts AL2 1HG

www.vokera.ie

T 0844 391 099

F 0844 391 0998

Vokèra Ireland

West Court, Callan

Co Kilkenny

T 056 7755057 F 056 7755060

VOKERA Compact HE, Compact 25 HE, Compact 29 HE, Compact 35 HE Installation & Servicing Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
