MS-1E
OPERATION MANUAL
0D\
585.0394.90A
MS-1e Product Description
The MS-1e is a networked message server that supports multiple paging functions within a Vocia
system—including message playback, event scheduling, VoIP paging interface, logging and remote
access.
MS-1e Setup and Installation
Setup and Use
The Vocia software provides an intuitive interface for configuration of the MS-1e. The information supplied
by this manual relates to physical connections and assignment. For more details on software setup,
please consult the Vocia Help File.
Installation
The unit requires one 1.75 inch (44.45 mm) high and 19 inch wide rack space with 17 inch (432 mm)
depth. Mounting the unit using four screws with washers will prevent marring of the front panel. PVC or
nylon washers are appropriate. The unit should also be supported at the rear to prevent bending of the
enclosure and/or rack ears.
When installing the rack ears, please note that the hardware is not symmetrical. Please install the rack
ear labeled “left” on the left side of the unit (when looking at the equipment facing the front plate) and the
rack ear labeled “right” to the right of the unit.
• Remove the screw from the chassis (with a Phillips P2 screw driver)
• Attach the appropriate rack ear and re-affix the Phillips screw to the chassis and 4 additional
Phillips screws supplied with the rack ears.
Install the unit away from heat sources, such as vents and radiators, and in rooms with adequate
ventilation. Ensure that air can circulate freely behind, beside, and above the unit. Do not exceed the
maximum ambient operating temperature of 32°-113° F (0° -42°C). Be aware of conditions in an enclosed
rack that may cause the temperature to exceed ambient room conditions.
MS-1e Front
MS-1e Front Panel
The Unit features one power indication LED on the front panel:
• Not illuminated: The device is not powered.
• Flashing green: The unit is receiving power but not data, or the unit has not been configured
correctly.
• Solid green: The unit is operational. Power supply and network traffic are functional.
MS-1e Rear
CAUTION
for all service requirements.
1 - AC Power Entrance (IEC)
The IEC power entrance provides for connection of the appropriate power cord (included with unit). An
internal universal switching power supply accepts 100~240VAC @ 50/60Hz, with a maximum power
consumption of 350 watts.
Do not remove or defeat the ground prong on the power cord, as this will constitute a shock hazard. Equipment should be
connected to a mains socket outlet with a protective earthing connection. This plug is the main disconnecting device and should
remain readily operable. There are no user interchangeable parts. Please contact Biamp Technical Support or your local distributor
2 - RS-232 Port
This port is used to support console access to the MS-1e. This enables third party access to the Vocia
MS-VTP (Vocia Text Protocol) API. Please refer to the seperate VTP programmers document or the
software help file for more details.
3 - Network Connection
The MS-1e has four RJ45 Ethernet connectors located on the rear panel (Control, CobraNet, VoIP, and
Live Interworld Streaming). Each connector has two green LEDs, which display Ethernet Link (left LED)
and Activity (right LED).
LAN-1 Connector (Control)
This port connects the MS-1e to the Ethernet control network. This should be separate to the LAN that is
being used by the CobraNet port either physically or through the use of managed switches and VLANs.
The MS-1e can be configured in the Vocia software interface via this port, and as such it should be
connected to the same network as the configuration PC during set up. This connection supports
Interworld paging and communications. The default IP address of the MS-1e is 192.168.1.101.
LAN-2 Connector (CobraNet)
This port is used to communicate with non-server Vocia devices and as such should be connected to the
same network as the local Vocia system. The data from the CobraNet network should be placed on its
own LAN, either physically or through the use of managed switches and VLANs. Unlike other Vocia
devices, the MS-1e physical network port does not display LED indication of CobraNet status. By default
the MS-1e takes on the role of CobraNet conductor (time sync master).
LAN-3 Connector (VoIP)
This port is used to host VoIP paging functionality for the MS-1e. MS-1e VoIP paging is enabled at the
World level. Connection should be made to the same network as other VoIP infrastructure within the
facility. If Live Interworld Streaming is enabled (LAN 4) MS-1e VoIP paging functionality (LAN 3) will be
disabled at the Universe level.
LAN-4 Connector (Interworld)
This port is used for Live Interworld Streaming. Live Interworld Streaming is enabled at the Universe level.
The fourth network interface (LAN-4) on every MS-1e in the Universe will need to be configured with an
IP address, subnet mask and optional gateway. This configuration requires the MS-1e hardware to be
physically connected on the LAN-4 Network Interface port to a LAN or WAN with a valid connection to the
other Worlds. If MS-1e VoIP paging is enabled Live Interworld streaming (LAN-4) will be disabled at the
Universe level.
4 - Inactive
NOTE
Connection of external devices to inactive ports is not required or recommended.
NOTE
Changes made to the Device ID while connected to the network
require a power cycle in order to take effect.
These ports are inactive at this time.
5 - Inactive
This port is inactive at this time
6 - Device ID
The rotary ID switches give the unit a unique Device ID. The switches are in hexadecimal format. All units
of the same device type must have a unique Device ID to function properly within a Vocia Paging World.
The Factory Default Device ID is 01. A Device ID of 00 is invalid and cannot be used.
To assign a Device ID of hex 07, leave the MSB switch on 0 and turn the LSB switch to 7. Device ID
switches should be set using a 0.1 inch (2.5mm) to 0.12 inch (3.0mm) flat blade screwdriver. More
information on setting IDs and the hexadecimal numbering scheme can be found in the Vocia Help File.
