VMware vFabric Suite - 5.3 Getting Started

Getting Started with vFabric Suite

VMware vFabric Suite 5.3

This document supports the version of each product listed and

supports all subsequent versions until the document is replaced by

a new edition. To check for more recent editions of this document,

see http://www.vmware.com/support/pubs.

EN-001013-00

You can find the most up-to-date technical documentation on the VMware Web site at: https://www.vmware.com/

support.

The VMware Web site also provides the latest product updates.

If you have comments about this documentation, submit your feedback to: [e-mail]

Copyright © 2013 VMware, Inc. All rights reserved. This product is protected by copyright and intellectual property
laws in the United States and other countries as well as by international treaties. VMware products are covered by
one or more patents listed at http://www.vmware.com/go/patents.

VMware is a registered trademark or trademark of VMware, Inc. in the United States and other jurisdictions. All
other marks and names mentioned herein may be trademarks of their respective companies.

VMware, Inc., 3401 Hillview Avenue, Palo Alto, CA 94304

www.vmware.com

Table of Contents

1. About Getting Started with vFabric Suite .................................................................................................. 1

Intended Audience ......................................................................................................................... 1

2. Quick Start Guide .............................................................................................................................. 3

3. Overview of vFabric Suite 5.3 ............................................................................................................... 7

vFabric Suite Editions and Components ............................................................................................... 7

Component Integration and Cross-Platform Consistency ............................................................................ 8

Optimized for vSphere and Spring-Built Applications ............................................................................... 9

Product Overviews ........................................................................................................................ 9

4. vFabric Suite Licensing ...................................................................................................................... 19

vFabric Suite Licensing Terminology ................................................................................................. 19

How vFabric Suite Licensing Works ................................................................................................. 19

Check the Validity of an Existing License Key ..................................................................................... 20

5. Installing vFabric License Server and Activating Your License ....................................................................... 23

Installing vFabric License Server on Your vCenter Server ........................................................................ 23

RHEL Only: Installing vFabric License Server Standalone ....................................................................... 27

Activate vFabric Suite Licenses ....................................................................................................... 31

Optionally Configure Computer to Track License Usage of OSS Components on RHEL .................................... 33

Upgrade vFabric License Server on vCenter Server ................................................................................ 35

Uninstall vFabric License Server from vCenter Server ............................................................................ 35

Uninstall Standalone vFabric License Server ........................................................................................ 36

6. Monitoring vFabric License Usage ......................................................................................................... 37

Monitor License Usage with Command-Line Tools ................................................................................ 37

License Monitoring: Command Reference ........................................................................................... 38

Monitor License Usage with the vFabric License Server Reporting UI ......................................................... 44

Display the Component Events File in Readable Format .......................................................................... 45

vCenter License Reporting Manager .................................................................................................. 47

7. FAQ: vFabric Suite Integration and Off-Cycle Releases ............................................................................... 49

iii

iv vFabric Suite

About Getting Started with vFabric
Suite

1. About Getting Started with vFabric Suite

Revised April 23, 2013.

Getting Started with vFabric Suite describes product concepts and initial setup tasks for VMware® vFabric Suite™ products.
Read this documentation for an overview of vFabric Suite components; to familiarize yourself with the licensing infrastructure;
and to see walkthrough procedures for installing vFabric Suite components.

Intended Audience

Getting Started with vFabric Suite is intended for experienced Windows and Linux developers and system administrators who
want to learn about vFabric Suite and its included components; install the vFabric License Server on an existing VMware®
vCenter™ Server; and understand how vFabric licensing works.

1

1

2 vFabric Suite

About Getting Started with vFabric

2

Suite

Quick Start Guide 3

2. Quick Start Guide

This section guides you through the end-to-end process of installing vFabric Suite in a vSphere environment, or more
specifically, installing one vFabric component on a Red Hat Enterprise Linux (RHEL) virtual machine in the context of
vFabric Suite. In particular, the procedure describes how to perform the following tasks:

• Create an ODBC data source on the Windows computer running vCenter Server that connects to either the database system

used by vCenter Server or to a separate database system.

In this Quick Start Guide, it is assumed you are using a SQL Server database system, although you can also use other database
system such as Oracle.

• Install vFabric License Server on the same computer as your vCenter Server.

• Activate a vFabric license.

• Install the VMware repository RPM on the RHEL virtual machine (VM), which makes it easy for you to browse the available

vFabric RPMs.

• Install one vFabric component (vFabric tc Server) on the RHEL VM from the VMware RPM repository.

The procedure assumes a vSphere environment, although you can also install the vFabric License Server standalone in a physical
or Amazon EC2 environment. The procedure shows you how to complete the entire installation process as quickly as possible,
with minimal explanation of what each step means. For more details, and information about the standalone vFabric License
Server, see Installing vFabric Suite.

Prerequisites

• Install and configure vCenter Server and vSphere Client on a Windows computer.

See vSphere Installation and Setup.

• Create the database instance that will contain vFabric license data. See Guidelines for Creating the vFabric License Server

Database Instance.

• Create a virtual machine (VM) and install Red Hat Enterprise Linux (RHEL) as the guest operating system.

See vSphere Virtual Machine Administration.

• Install VMware Tools on the VM.

See Installing and Configuring VMware Tools.

• Ensure that the Windows computer on which vCenter Server is running has the SQL Server Native Client ODBC

driver installed on it; if not, download and install the driver from the Microsoft SQL Server Web site.

Procedure

1. Create an ODBC data source that connects to the vFabric database instance on either the vCenter database system,

or an external database.

a. On the Windows computer on which you are running vCenter Server, invoke the ODBC Data Source Administrator

window using Start > Programs > Administrative Tools > Data Source (ODBC).

b. Click the System DSN tab.

c. Click the Add... button.

d. Select the SQL Server Native Client driver, then click Finish.

3

4 vFabric Suite

e. Enter a name and description of the data source, then select the SQL Server and database instance you want this data

source to connect to from the drop-down list. The SQL Server database system can be either the one used by the
vCenter Server or a separate one, whichever works best for your environment. Click Next.

f. Specify that you want SQL server to verify the authenticity using a login ID and password entered by the user, then

enter the Login ID and password of the SQL Server user. This database user must have privileges to load the schema.

VMware recommends that you not specify integrated Windows authentication.

g. Continue clicking Next, and then Finish, taking all default values, until you see a summary of the data source

configuration. Test the data source to ensure you have configured it correctly, then click OK.

2. From the Windows computer on which you are running vCenter Server, download the vFabric License Server installer from
the VMware Download Center page and save it to your computer.

The installer program is called vFabric_License_Server-version.exe.

3. Install the vFabric License Server on the same computer as your vCenter Server.

a. Double-click on the installer from Windows Explorer to start the installation. After preparing the installation, the

vFabric Welcome Screen appears.

b. Continue clicking Next to accept the license agreement and view where the installer will install the vFabric License

Server.

c. Enter the credentials of the vCenter user who has the appropriate privileges to register the vFabric License Server as an

extension. At a minimum, the user must have the following vCenter privileges:

• Extension.Register

• Extension.Update

Click Next to continue.

d. Enter the login ID and password of the database user, and select the ODBC data source (DSN) that you created in a

preceding step.

e. Click Install to proceed with the installation.

The installer program completes successfully when you see the message InstallShield Wizard Completed. Click Finish
to complete the installation.

f. Restart your vCenter Server to enable the vFabric License Server changes.

4. Make a note of the license key that you purchased for vFabric Suite. VMware license keys consist of groups of characters
separated by dashes, such as 123AA-123BB-123CC-123DD-123EE.

5. Activate the vFabric license keys in vCenter Server.

a. Start vSphere Client and log in to the vCenter Server in which you installed vFabric License Server.

Note: This procedure shows how to use version 5.0 of vSphere Client.

b. Select Home>Administration>Licensing to invoke the vCenter Licensing page, then click the Manage vSphere

Licenses link in the top-right corner.

c. Enter one or more license keys in the text window to the right, one license key per line. Enter an optional label.

d. Click the Add License Keys button. The license keys shows up in the review window.

4 Quick Start Guide

Quick Start Guide 5

e. Follow the prompts until you get to the Confirm Changes window, verify changes, and click Finish.

The license keys are displayed in the main vCenter Licensing window under the name VMware vFabric Suite
Standard|Advanced, depending on the vFabric Suite package you purchased.

6. Install the VMware repository RPM on the RHEL VM.

a. Log in to the RHEL VM as the root user (or user with sudo privileges) and start a terminal.

b. Run the following wget command, passing it the appropriate URL. The URL differs depending on the version of

RHEL you are using.

Important: You must run the entire wget command on a single line. Be sure you include the | sh at the end, or the
RPM installation will not work.

For RHEL 5:

prompt# wget -q -O - http://repo.vmware.com/pub/rhel5/vfabric/5.3/vfabric-5.3-suite-installer | sh

For RHEL 6:

prompt# wget -q -O - http://repo.vmware.com/pub/rhel6/vfabric/5.3/vfabric-5.3-suite-installer | sh

If necessary, use sudo to run the preceding commands if you are not logged in as the root user.

7. Install vFabric tc Server on the RHEL VM.

a. Log in to the VM as the root user (or user with sudo privileges) and start a terminal.

b. Execute the following yum install command to install vFabric tc Server:

prompt# yum install vfabric-tc-server-standard

If necessary, use sudo to run the preceding commands if you are not logged in as the root user.

The yum command displays information about the contents of the installation.

c. Enter y at the prompt to begin the installation.

If the installation is successful, you will see a Complete! message at the end.

The yum command installed tc Server in the /opt/vmware/vfabric-tc-server-standard directory.

What to do next

• Install additional vFabric components on the RHEL VM, such as vFabric Hyperic or vFabric RabbitMQ. See Installing vFabric

Suite.

• If your vFabric license includes open-source software (OSS) support and you have OSS components (such as Tomcat Apache)
running on the VM, configure the VM to track their usage.

• Monitor the vFabric Suite license usage by querying the vFabric License Server. See Monitoring vFabric License Usage.

5

6 vFabric Suite

6 Quick Start Guide

Overview of vFabric Suite 5.3 7

3. Overview of vFabric Suite 5.3

Cloud computing and IT as a service continue to transform application infrastructure and development. VMware® vFabric
Suite™ drives this change by integrating the familiar Spring Developer Frameworks with a proven set of services that span the
lifecycle of modern application development, deployment, and management. Engineered for VMware vSphere® virtualization
and cloud environments, vFabric Suite offers advantages for users throughout the enterprise.

• Application developers and architects get tools that let them build data-intensive, Web-oriented applications quickly and
reliably.

• IT gets an agile platform that makes applications easy to deploy, instantly scalable, and portable across clouds.

• End users get applications that are data rich, quick to access, and always available.

Subtopics

vFabric Suite Editions and Components
Component Integration and Cross-Platform Consistency
Optimized for vSphere and Spring-Built Applications
Product Overviews

vFabric Suite Editions and Components

vFabric Suite is available in two commercial editions, vFabric Suite Standard and vFabric Suite Advanced.

Table 3.1. vFabric Suite 5.3 Editions and Components

Component and Version Description

vFabric tc Server 2.9 (Spring
Edition)

Elastic Memory for Java (EM4J

1.3)

Spring Insight Operations 1.9 Performance monitoring with real-

Lightweight application server,
fully compatible with Apache
Tomcat 7, that can be instantly
provisioned and elastically scaled.
Elastic Memory for Java (EM4J

1.3 ) is packaged with vFabric

tc Server (Spring Edition), and

Spring Insight Operations 1.9 is

available as a separate download.
Memory management technology

that enables you to run more Java
applications on your ESXi servers
than previously possible. EM4J
helps maintain Java application
performance and reliability while
freeing memory that allows you to
run more VMs per host. An EM4J
plug-in is now available for the
vSphere Web Client.

time, multi-layered visibility into
applications running on tc Server.

vFabric Suite Standard
Component

Yes. Yes.

Yes. Yes.

Yes. Yes.

vFabric Suite Advanced
Component

vFabric Hyperic 5.0 Proactive performance

vFabric GemFire 7.0 (Application
Cache Node)

management with complete and
constant visibility into applications
and infrastructure.

Data management platform that
provides real-time, consistent
access to data across widely

Yes. Yes.

Yes. Yes.

7

8 vFabric Suite

Component and Version Description

distributed cloud architectures.
GemFire Application Cache Node
is the vFabric Suite offering for
vFabric GemFire.

vFabric Web Server 5.3 Precompiled and pretuned Web

vFabric RabbitMQ 3.0 De facto standard for cloud

vFabric SQLFire 1.1
(Professional)

vFabric Application Director 5.0
(Provisioning)

server and load-balancing service
that dynamically routes requests
to an application server for
processing. vFabric Web Server
is fully compatible with Apache
Web Server.

messaging and leading
implementer of AMQP. Delivers
highly available, scalable,
and portable messaging with
predictable, consistent throughput
and latency.

Memory-optimized, distributed
database management system
that provides extremely high
throughput; predictable latency;
dynamic and linear scalability;
and continuous availability of
data.

Cloud-enabled application
provisioning solution that
simplifies how to create
and standardize application
deployment topologies across
cloud services.

vFabric Suite Standard
Component

Yes. Yes.

No. Yes.

No. Yes.

No. Yes.

vFabric Suite Advanced
Component

vFabric Postgres 9.2 (Standard
Edition)

ACID-compliant, ANSI-SQL­compliant transactional and
relational database designed
for the virtual environment and
optimized for vSphere.

No. Yes.

Component Integration and Cross-Platform Consistency

VMware performs full integration testing on each component in a vFabric Suite release.

Key integration points:

• vFabric Hyperic plug-ins are provided for each vFabric Suite 5.3 component. From a single management console, you can
remotely monitor and manage all vFabric Suite components and applications, installed on multiple computers.

• User interfaces implement consistent LDAP integration for authentication in vFabric EM4J (vSphere console), Spring Insight,
vFabric RabbitMQ (Admin UI), and vFabric Hyperic.

• A common API provides a consistent product interaction model. All products implement consistent REST and JSON API
behavior.

• Application Director services are available for all versions of vFabric components included in vFabric Suite 5.3. Optimized for
vFabric runtime components, vFabric Application Director is a cloud-enabled application provisioning solution that accelerates
and automates the configuration and deployment of multi-tier applications.

• Spring Insight Operations provides automatic instrumentation of Spring applications running on tc Server, exposing
application performance from both general and fine-grained perspectives.

8 Overview of vFabric Suite 5.3

Overview of vFabric Suite 5.3 9

• Hyperic- Spring Insight integration enables you to move from Hyperic to Insight, in the same application context, to diagnose
the underlying problem. See tc Server Plug-In for Easier Management and Monitoring.

• vFabric GemFire includes an HTTP session management module for tc Server that provide fast, scalable, and reliable session
replication without requiring application changes.

• A sample application, Spring Trader, demonstrates how products in vFabric Suite work together.

• For details on vFabric Suite integration with vSphere and Spring, see Optimized for vSphere and Spring-Built Applications.

Optimized for vSphere and Spring-Built Applications

Tight integration between vFabric Suite and vSphere enables you to achieve higher levels of software density, higher utilization
rates on hardware, and the cost benefits of dynamic scalability. Through integration with vSphere solutions, vFabric also offers
application portability and vendor choice across private and public clouds

More than half of Java developers use Spring's open-source platform to build rich Web applications for virtual and cloud
environments. Spring minimizes vendor lock-in, enables code to run in diverse environments, and helps applications retain value
as environments and business priorities change. Spring Mobile, Spring Android, and Spring Social extend the framework with the
ability to run on the newest generation of devices.

vFabric Suite components are engineered to leverage vSphere and the efficiencies of Spring-built applications.

• vFabric Elastic Memory for Java (EM4J) enables memory to be shared dynamically among Java virtual machine (JVM)
instances without sacrificing performance. With EM4J, you can deploy more application server VMs on each vSphere host
to increase server consolidation, and automatically allocate Java heap memory to JVMs that need it most. EM4J's monitoring
GUI supports vSphere 5.1.

• Spring Insight Operations, available with vFabric tc Server Spring Edition, provides a dashboard view of Spring application
performance metrics in real-time. Developers can test, tune, and debug applications from their desktops, without changing
code. Automatic instrumentation of Spring applications running on tc Server expose application performance from both
general and fine-grained perspectives.

• To encourage agile development and testing, vFabric tc Server and Spring Insight are tightly integrated with SpringSource
Tool Suite™ (STS). STS is an Eclipse-powered development environment that includes the latest Spring (Core, Rich Web,
Integration, Batch), Groovy, Grails, and Roo technologies as well as OSGi tools. See SpringSource STS.

• vFabric tc Server Spring Edition includes commercial support for Spring-built applications, as well as for vFabric tc Server.

• Developers can incorporate vFabric GemFire data caching into their Spring applications with minimal code, providing globally
distributed, highly available data.

• vFabric RabbitMQ-based messaging solutions incorporate core Spring concepts, enabling developers to easily add AMQP
messaging to their applications.

Product Overviews

The following sections describe key features and functionality of vFabric Suite components. For more detailed information, see
the product documentation and release notes for each component.

vFabric tc Server 2.9 (Spring Edition)

VMware® vFabric™ tc Server is 100-percent compatible with Apache Tomcat 7. It has all the runtime advantages of Tomcat,
plus operational management, advanced diagnostics, mission-critical support, and unmatched visibility into Spring-powered
applications — none of which are available in the open source product. vFabric tc Server Spring Edition includes all of the
components and features of tc Standard Edition, plus Spring Insight Operations, Elastic Memory for Java (EM4J), and Spring
commercial support.

9

10 vFabric Suite

tc Server harnesses the power of traditional JEE architectures while eliminating their complexity and performance drawbacks,
making it easier, faster, and more cost-effective to build and run cloud-ready applications. With its lean architecture and small,
10MB memory footprint, tc Server requires significantly fewer resources than conventional servers, which allows for greater
server density in virtual and cloud environments. tc Server supports integration with VMware tools and vFabric Hyperic, and
provides templates for vFabric GemFire session replication.

Main features of vFabric tc Server (Spring Edition):

• Compatible with existing Apache Tomcat applications, thus eliminating migration costs and cycles.

• Parallel deployment. Deploy multiple revisions of the same application at the same time so you can roll out a new revision of
an application without affecting users.

• Automatic instance upgrades. A script lets you easily upgrade earlier instances to function with the latest version.

• Automated deployment of applications to multiple instances of tc Server and standardized templates for rapid provisioning of
new instances.

• Commercial support for vFabric tc Server and Spring Framework.

• Elastic Memory for Java (EM4J). Included with tc Server Spring Edition, EM4J allows Java workloads to cooperate more fully
with ESXi advanced memory-sharing technologies. EM4J helps maintain Java application performance and reliability while
freeing memory so you can run more VMs per host, improving your consolidation ratio.

• Spring Insight Operations. Available with tc Server Spring Edition, Spring Insight Operations is a Web application that gives
you real-time, detailed visibility into application behavior and performance. Insight Operations is optimized for monitoring and
tuning Spring-built applications in production.

For new feature information, see vFabric tc Server Release Notes.

vFabric EM4J 1.3

Elastic Memory for Java (EM4J) revolutionizes the virtualization of Java applications.

Previously, if you ran Java on VMware ESXi, you had to reserve 100% of the configured memory for a VM running Java
applications or risk serious performance problems. To determine the optimum size of the Java heap, you determined the
application's peak requirement. Allocating less could mean unacceptable performance, errors, or crashes; allocating more than
was necessary wasted memory.

EM4J changes all that. You can run more Java applications on your ESXi servers than previously possible, and Java applications
can now effectively leverage ESXi's industry-leading memory sharing technology.

Main features of vFabric EM4J:

• Balloon that sits directly in the Java heap and works with a new memory-sharing interface introduced in ESXi 5.0. ESXi can
share available memory in the Java heap among VMs as needed, while preserving application performance and reliability.

• Ability to size the Java heap to accommodate the peak workload, without wasting or running out of memory. Any excess
memory is ballooned away and redistributed where it is needed.

• Ability to create more VMs and pack more tc Server instances onto a single vSphere host.

• Reduced possibility of out-of-memory errors that can cripple applications.

• EM4J plug-in for vSphere Web Client that lets you monitor EM4J configuration and memory performance for EM4J-enabled
Java workloads in the vSphere Web Client. View Java workload statistics for selected VMs; detailed information about JVM
process and memory usage; alerts; and suggested best practices.

10 Overview of vFabric Suite 5.3

Overview of vFabric Suite 5.3 11

For new feature information, see vFabric EM4J Release Notes.

Spring Insight Operations 1.9

Spring Insight Operations gives you real-time, granular visibility into application behavior and performance in production
environments. It is a Web application that runs with tc Server Spring Edition and is a separate download.

Insight Operations graphs the health of an application over time for the entire cluster and for each server in the cluster.
Administrators see application and server problems as they occur, with detailed information about contributing events, presented
in one unified dashboard. You can quickly identify under performing servers, server errors, and trace details for specific events
and exceptions.

VMware partners with Google to integrate Spring Insight data into SpeedTracer, a Google Chrome extension that analyzes
how your application is performing inside the browser and that ties browser performance to backend performance. If your Web
application uses Ajax and other rich open Web technologies, try SpeedTracer with Spring Insight.

Main features of Spring Insight Operations:

• Automatic instrumentation of Spring applications running on tc Server expose application performance from both general and
fine-grained perspectives.

• Isolation of performance problems by application, endpoint, application server, and method.

• Tracking of performance over time, to understand whether problems are chronic or spurious.

• Response-time histograms that reveal whether performance problems affect many users, or a small subset.

• High-performing instrumentation with sub-microsecond impact to application response time, designed for applications in
production.

• Integration with vFabric Hyperic that enables operations and development teams to view a single set of both server-oriented
and application-oriented performance, and collaborate more effectively to fix performance problems faster. Spring Insight
metrics give Hyperic a broader range of data for triggering alerts and for control actions that implement automatic problem
remediation.

For new feature information, see vFabric tc Server Release Notes.

vFabric Hyperic 5.0

VMware® vFabric™ Hyperic® provides more than 50,000 performance metrics on more than 75 technologies at every layer of
the application infrastructure. It consolidates complete discovery, monitoring, analysis and control of all application, system, and
network assets -- including other vFabric Suite components -- both inside and outside of virtual machines powered by VMware.
Hyperic provides proactive performance management through transparent visibility into dynamic applications deployed across
physical, virtual, and cloud environments.

At startup, Hyperic automatically discovers and adds new servers and VMs to inventory; configures monitoring parameters; and
collects performance metrics and events. This level of automation lets you deploy fully monitored VMs with minimal effort and
scale out monitoring across your virtual infrastructure.

Main features of vFabric Hyperic:

• Simplifies management of virtualized applications by maintaining a continually updated inventory of vSphere ESXi and ESX
hosts, their virtual machines, and guest operating systems.

11

12 vFabric Suite

• Single unified dashboard for managing and monitoring performance across all application tiers.

• tc Server plug-in for easier, remote management and monitoring of multiple tc Server instances and applications. See tc Server

Plug-In for Easier Management and Monitoring.

• Spring Insight plug-In for in-depth application monitoring. The plug-in makes it easier to discover whether a problem is
infrastructure or application-related. See Spring Insight Plug-In for In-Depth Application Metrics.

• Centralized plug-in manager that synchronizes Hyperic plug-ins between Hyperic Server and all Hyperic Agents in the
environment, enabling system administrators to easily configure and upgrade agents distributed across hundreds of servers.

• iPad and iPhone support.

• Deeper integration with LDAP that enables the automatic import of existing LDAP user groups to preassign roles to users.

• Auto-discovery across all operating systems that run on vSphere and in disparate run-time environments, from Java to .NET.

• Bridges the gap between virtual and physical: compares guest and host metrics (CPU, memory, disk utilization); relates
physical and virtual performance to individual applications.

• Advanced alerting: role-based, time-based (for geographically dispersed teams), server group-based, and so on. Automated
alert responses and alert escalation processes.

• Ability to resolve a broad range of issues without human intervention, often before end users notice, with automated
remediation that reduces mean time-to-resolution and ensures service level agreement (SLA) compliance.

• Plug-in framework that extends management and monitoring to any environment. Through the framework, Hyperic can
discover, monitor, and control any application or device using a straightforward Java/XML API.

• Scales dependably from the ground up — to more than 1,000 servers and one million metrics per minute with a single Hyperic
Server.

For new feature information, see vFabric Hyperic Release Notes.

tc Server Plug-In for Easier Management and Monitoring

The Hyperic tc Server plug-in enables you to remotely manage vFabric tc Server instances and applications on multiple
computers. Hyperic provides a single console with powerful dashboards through which you can:

• Manage the lifecycle of tc Runtime instances by starting, stopping, and restarting a local or remote instance.

• Manage the lifecycle of a group of tc Runtime instances that are distributed over a network of computers.

• Configure a single instance of tc Runtime. Configuration options include the various port numbers to which the tc Runtime
instance listens, JVM options such as heap size and enabling debugging, default server values for JSPs and static content,
JDBC datasources, various tc Runtime connectors, and so on.

• Deploy a Web application from an accessible file system, either local or remote. You can deploy to a single tc Runtime
instance or to a predefined group of servers.

• Manage the lifecycle of applications deployed to a single tc Runtime instance or group of servers. Application lifecycle
operations include start, stop, redeploy, undeploy, and reload.

Spring Insight Plug-In for Detailed Application Metrics

vFabric Hyperic includes the Spring Insight plug-in. The plug-in enables a Hyperic Agent running on a tc Server instance to auto­discover web applications running on that instance and to obtain detailed, real-time application health and request metrics. You
can apply alerting on those metrics, as you can with other Hyperic resources and metrics. A new interface view of application

12 Overview of vFabric Suite 5.3

Overview of vFabric Suite 5.3 13

metrics associates the application to currently monitored Hyperic resources such as application servers, database servers, the
operating system, and specific resource types. By providing all of this information on one screen, Hyperic makes it easier to
pinpoint whether the problem is infrastructure- or application-related. If the application is the culprit, Hyperic-Insight integration
enables you to move from Hyperic to Insight, in the same application context, to diagnose the underlying problem.

vFabric GemFire 7.0 (Application Cache Node)

VMware® vFabric™ GemFire® is a high performance, in-memory distributed data management solution that scales elastically at
runtime, ensuring fast, reliable data access in the cloud and across the enterprise. GemFire is language- and infrastructure-neutral,
which enables data-sharing across existing process, software, and hardware boundaries.

Business events often require many people to see the same information at the same time in globally distributed environments.
These demands strain IT resources, degrade performance, and increase costs for bandwidth, hardware, and personnel. GemFire
addresses the problem by provisioning consistent data dynamically at the right place, at the right time, and in the right format in
memory. Using dynamic replication and data partitioning techniques, GemFire offers continuous availability, high performance
and linear scalability for data-intensive applications without compromising data consistency, even under failure conditions. Data
virtualization provides data location transparency and decouples data access logic from applications.

The vFabric Suite offering for vFabric GemFire is the Application Cache Node, which provides peer-to-peer
functionality. You can buy an additional, separate license, Data Management Node, which includes client/server
and global WAN functionality. For details, see the vFabric GemFire documentation.

Main features of vFabric GemFire:

• Applications run 4 to 40 times faster with no additional hardware.

• Data awareness and real-time business intelligence. If data changes as you retrieve it, you see the changes immediately.

• Re-engineered APIs and integration with Spring Framework speed and simplify the development of scalable, transactional
enterprise applications.

• HTTP session replication provides linear scalability, and integrates cleanly with tc Server.

• Fixed partitioned regions, for greater control of deployment options.

• Portable Data eXchange (PDX) serialization, which provides reduced object size to store more data with less memory, and
Language independence for better integration with .NET.

• Faster startup and recovery for persistent regions.

• Client-initiated transactions.

• Client querying using parameters.

• Combines redundancy, WAN replication, and a “shared nothing” persistence architecture to deliver fail-safe reliability and
performance.

• Continuous querying to provide active data change notifications.

• Horizontally scalable to thousands of cache nodes, with multiple cache topologies to meet different enterprise needs. The
cache can be distributed across multiple computers.

• Support for asynchronous and synchronous cache update propagation.

• Optimized low latency distribution layer for reliable asynchronous event notifications and guaranteed message delivery.

For new feature information, see vFabric GemFire Release Notes.

13

14 vFabric Suite

HTTP Session Replication

The GemFire HTTP Session Management Module provides fast, scalable, and reliable HTTP session replication for vFabric tc
Server, Oracle WebLogic Server, and Apache Tomcat with minimal or no application changes. Depending on your usage model,
you can replicate session data across multiple peers, partition data across multiple servers, distribute session data across a WAN,
or manage your session data in many other customizable ways.

vFabric RabbitMQ 3.0

VMware® vFabric RabbitMQ™ delivers highly available, scalable, and portable messaging with predictable, consistent
throughput and latency. It is specifically designed to operate and scale in cloud environments, where applications leverage pools
of shared infrastructure and data is routed between widely distributed applications. RabbitMQ is the leading implementation of
AMQP, an open-standard messaging protocol created as an alternative to costly, proprietary commercial messaging technologies.

Main features of vFabric RabbitMQ:

• Offers customers and developers a consistent approach to messaging across multiple stacks and more than 70 developer
platforms.

• Supports all modern messaging patterns: point-to-point (RPC style), point-and-shoot, publish-subscribe, multicast, and more.
All are available as durable or non-durable message types.

• Protocol-based for better interoperability. Other messaging systems are API based, which limits their interoperability.

• Through protocol adapters, supports a full range of Internet protocols for lightweight in-browser messaging— including
XMPP, SMTP, STOMP, and HTTP.

• Transparent integration with Spring Batch and Spring Integration.

• Supported on all major operating systems and developer platforms, and open-sourced under the Mozilla public license.

• JMS client support. The JMS Client for RabbitMQ feature is an implementation of the Java Message Service (JMS) 1.1
specification that uses the RabbitMQ Java client API. This feature allows new and existing JMS applications to connect with
RabbitMQ brokers through AMQP. JMS applications can interoperate with AMQP clients on diverse platforms, including non­Java platforms.

For new feature information, see vFabric RabbitMQ Release Notes.

vFabric Web Server 5.3

VMware® vFabric™ Web Server, which is compatible with Apache Web Server, distributes and dynamically balances
application load to ensure optimal performance. Unlike Apache Web Server, vFabric Web Server is precompiled, prepatched, and
pretuned, resulting in dramatically reduced time-to-deployment and substantially improved performance. vFabric Web Server
provides scalability, enhanced security, and performance without the complexity and cost of sophisticated Web infrastructures.
Support customers receive a standard, certified, easy-to-install software build, continual product updates, security alerts and
patches, guaranteed bug fixes, indemnification on all software in the bundle, and expert technical support.

vFabric Web Server is similar to vFabric ERS. However, vFabric Web Server runs only in a virtual environment,
on vSphere and vSphere guest operating systems. It is available exclusively as part of a vFabric Suite package.
ERS runs on both vSphere and physical infrastructure.

Main features of vFabric Web Server:

• Sample template that automatically configures vFabric Web Server for a tc Server 2.6 instance.

• Precompiled builds that deliver up to 100% performance improvements, increasing uptime and reducing costs for hardware
capacity.

14 Overview of vFabric Suite 5.3

Overview of vFabric Suite 5.3 15

• Guaranteed binary drop-in bug and security-fix help for every supported platform, to reduce the time you spend on security
issues.

• Fast installation process that gets you up and running in minutes: consistent installation and directory structure across all
operating systems, seamless integration with existing infrastructures, and no preset installation requirements.

• Easy installation of multiple instances of on a single server.

• Scalable management of multiple Web sites and servers.

• In addition to Apache httpd and its core modules, support for mod_ftp, mod_fcgid, openssi, openldap, mod_ik, mod_bmx,
libexpat, libapr, zlib.

For new feature information, see vFabric Web Server Release Notes.

vFabric SQLFire 1.1 (Professional)

VMware® vFabric™ SQLFire is a memory-optimized, distributed database management system designed for applications with
highly demanding scalability and availability requirements. Applications can manage database tables entirely in memory, or they
can overflow table data from memory to disk.

A flexible architecture enables SQLFire to pool memory and disk resources from hundreds of clustered members. This clustered
approach provides extremely high throughput, predictable latency, dynamic and linear scalability, and continuous availability
of data. SQLFire memory-speed write performance is well-suited for large-scale databases with high transaction volumes and
demanding Service Level Agreements. For systems that require deployment of a relational database across a cluster of machines,
such as a grid or cloud, SQLFabric's distributed, shared-nothing architecture can simplify the deployment while providing linear
scalability.

Because it leverages the SQL interface and tools, Java, and other widely implemented technologies, SQLFire is easily adaptable
to existing database applications. Moreover, a SQLFire distributed system can be scaled out using commodity hardware.

Main features of vFabric SQLFire:

• Enables applications to manage data entirely in memory through partitioning and synchronous replication that distributes data
across numerous SQLFire members.

• Optimized disk persistence mechanism with a non-flushing algorithm to maintain high performance in applications that require
stable, long-term storage.

• Memory-based data management that maintains consistently high application performance by eliminating lookup, read/write,
and network round-trip latencies.

• Elastically scaled so that SQLFire servers can dynamically go online and offline to serve a growing or shrinking demand
pattern.

• Collocation of application logic with data and execution of application logic in parallel substantially increases application
throughput. SQLFire also transparently re-executes application logic if a server fails.

• Supports global WAN connectivity with the option of replicating data to remote clusters for disaster recovery.

• Based on SQL, JDBC and ADO.net standards. Supports Hibernate, SQuirreL SQL Client, CDC, Spring JDBC, and more.

For new feature information, see vFabric SQLFire Release Notes.

15

16 vFabric Suite

vFabric Application Director 5.0 (Provisioning)

VMware® vFabric™ Application Director is a cloud-enabled application provisioning solution that accelerates and automates
the configuration and deployment of multi-tier applications. vFabric Application Director is optimized for vFabric components,
but is extensible to other components that may be part of your Spring application. Starting with an intuitive drag-and-drop
workspace, application architects can easily create and save complete deployment blueprints that can be deployed onto any cloud.
These visual deployment topologies give you fine-grained control over installation dependencies and configuration changes, as
well as editable scripts.

Main features of vFabric Application Director:

• True separation between applications and infrastructure, enabling the same blueprint to be reused on multiple virtual and cloud
infrastructures.

• Familiar point-and-click user interface that lets you customize scripts, override configurations directly on the application
blueprint, and execute deployments with the click of a button.

• Direct integration to cloud provider catalog for selecting virtual machine templates as the foundational components to build
and deploy applications.

• A customizable catalog, populated with standard application components and scripts, that organizes application building
blocks for easy reuse. A language-agnostic approach makes it easy to add any type of application infrastructure component to
the catalog, and to deploy and update it.

• Version control for application blueprints that help standardize applications and allow organizations to reuse deployment plans
on multiple clouds.

• Organized workflow and dependencies for creating highly orchestrated deployment execution plans that adapt to any cloud,
application requirement, and IT compliance policy.

• Stored scripts to install, configure, start, and stop applications and application infrastructure components.

For new feature information, see vFabric Application Director Release Notes.

vFabric Postgres 9.2 (Standard Edition)

VMware® vFabric™ Postgres Standard Edition (vFabric Postgres) integrates VMware virtualization technology and is
compatible with Postgres SQL (psql) and the PostgreSQL tools and client drivers. It is ACID- and ANSI-SQL-compliant. You
can create, run, and manage vFabric Postgres databases using the Data Director administration UI, or use vFabric Postgres client
tools to connect to vFabric Postgres databases, load data, run scripts, perform backups, and run applications. (vFabric Suite does
not include Data Director.)

vFabric Postgres databases offer elastic database memory, database-aware high availability, and automated optimal database
configuration. The following list calls out vFabric Postgres enhancements over the standard Postgres database.

Main features of vFabric Postgres (Standard Edition):

• Achieves elastic database memory by participating in memory resource management with the vSphere guest operating system
and vSphere Hypervisor. Responding to memory needs and availability, the vFabric Postgres buffer manager shrinks the
database buffer pool to make memory available, and, when memory is available, accordingly increases the amount of memory
dedicated to the buffer pool.

• Higher default values for many critical settings compared with standard Postgres databases, including the settings for
shared_buffers, checkpoint_segments, and wal_buffers. These defaults give you higher out-of-the-box performance than
standard Postgres and a database that you can tune more easily according to workload. (A slight tradeoff occurs in disk space
and memory usage.)

16 Overview of vFabric Suite 5.3

Overview of vFabric Suite 5.3 17

• Checksums performed by default on each write operation to tables and indexes, ensuring that when vPostgres retrieves data,
the data is clean.

• Allows you to configure the required crash-recovery Service Level Agreement (SLA), and tunes the checkpoint parameters
dynamically as it monitors performance. This feature addresses the trade-off between configuring more frequent checkpoints
(for less crash recovery time and lower performance) and configuring less frequent checkpoints (for higher performance and
more crash recovery time). Solving the trade-off problem in the virtualized world is especially complex because resources
alloted to the database virtual machine vary dynamically.

For new feature information, see vFabric Postgres Release Notes.

17

18 vFabric Suite

18 Overview of vFabric Suite 5.3

vFabric Suite Licensing 19

4. vFabric Suite Licensing

vFabric Suite Standard and vFabric Suite Advanced packages are licensed on a per-machine and average-usage basis. This
chapter explains how vFabric Suite licensing works.

Subtopics

vFabric Licensing Terminology

How Licensing Works

Check the Validity of an Existing License Key

vFabric Suite Licensing Terminology

To understand vFabric licensing, review the related terminology:

• license key. vFabric Suite production licensing requires a license key. The license key represents the licenses (also known
as license units) that you have purchased, whether one or multiple licenses. A license key is an alphanumeric sequence
of 25 characters that encodes details of the associated product, the license expiration date, the license capacity, and other
information.

• license unit. A license unit is a single vFabric Suite license.

• machine. The definition of a machine depends on the infrastructure environment in which you are installing vFabric Suite:

• In an Amazon EC2 environment, a machine is an Amazon Machine Image (AMI).

• In a VMware vSphere environment, a machine is a virtual machine (VM).

• In a physical computer environment, a machine is the central processing unit (CPU).

• processing unit.The definition of a processing unit depends on the infrastructure environment in which you are installing
vFabric Suite:

• In an Amazon EC2 environment, a processing unit is an EC2 compute unit (ECU).

• In a VMware vSphere environment, a processing unit is a virtual central processing unit (vCPU).

• In a physical computer, a processing unit is an internal processor core.

• Cross-Cloud pricing. Cross-cloud pricing refers to the ability to license vFabric Suite Standard or Advanced across virtual,
cloud, and physical infrastructure.

How vFabric Suite Licensing Works

What type of licensing you get and how you activate it depends on whether you purchased your vFabric product(s) standalone or
as part of a vFabric Suite package (Standard or Advanced).

Licensing for vFabric Suite

vFabric Suite Standard and vFabric Suite Advanced packages are licensed on a per-machine and average-usage basis.

Each licensed machine can run any or all vFabric software components. Thus licensing is tied to machines, rather than to
component installations. One license unit covers one machine with a maximum of two processing units. For example, in the
Amazon EC2 environment, if you plan to install one or more vFabric components on a single Amazon Machine Image (AMI)
configured with up to two EC2 compute units (ECU), you need only one vFabric license unit for that AMI. However, if the AMI
is configured with four ECUs, then you need two vFabric license units for that AMI.

19

20 vFabric Suite

You obtain a pool of licenses that you activate by adding only one license key to the vFabric License Server. Rather than
installing a license key on each machine, you register one license key that represents the number of license units that you have
purchased. See Activate vFabric Suite Licenses.

To check the validity of a license key, see Check the Validity of an Existing License Key.

The production license is a V8 license that is perpetual for a particular version and package (Standard or Advanced) of vFabric
Suite. If you do not install a license, your component installation defaults to an evaluation license, which is valid for 60 days after
you first start the component. The license includes support for all vFabric products in your vFabric Suite Standard or vFabric
Suite Advanced package.

Licensing for Standalone vFabric Components

If you purchase a vFabric component individually, rather than as part of a vFabric Suite Standard or Advanced package, you
install license keys locally, on one or more machines. Local licensing does not involve integration with the vFabric License
Server.

To install a local license for a standalone vFabric product, refer to the documentation for that product. Each
product implements licensing in a slightly different way. To check the validity of a license key, see Check the

Validity of an Existing License Key.

Check the Validity of an Existing License Key

If you have previously installed one or more vFabric components, such as vFabric GemFire or vFabric tc Server, you might
already have a license key (also referred to as a serial number in the following procedure). However, you need to confirm
whether it is valid for the latest release of the component or in the context of vFabric Suite. The vfabric-licensetool
checkserial utility checks the validity of your existing license key.

For each license key that you input, the utility displays detailed information such as the vFabric component to which it is
associated, the type of license key, the capacity, and its expiration date.

Procedure

1. From the Drivers and Tools tab of the download page for vFabric Suite Advanced or Standard, download the vFabric

License Check Tool utility ZIP file onto the computer on which you want to run it.

The file is called vfabric-vfchksn-version.bin.zip.

2. Unzip the file into a directory.

The utility and supporting files are unzipped into the vfabric-vfchksn-version child directory.

3. If necessary, install a JDK or JRE on the computer.

Be sure the JAVA_HOME and PATH environment variables point to the JDK or JRE.

For example, if you installed the JDK in /usr/java/jdk1.6.0_24, you can set the environment variables in the user's
Linux profile as follows:

export JAVA_HOME=/usr/java/jdk1.6.0_24
export PATH=$JAVA_HOME/bin:$PATH

4. Open a command (Windows) or terminal (Linux) window, change to the directory in which you unzipped the utility, and run
the following (Linux):

prompt$ vfabric-licensetool checkserial [options] serial-number

On Windows:

20 vFabric Suite Licensing

vFabric Suite Licensing 21

prompt> vfabric-licensetool.bat checkserial [options] serial-number

You can specify the following options:

• -f input-filename : Read the license key from a text file called input-filename rather than from the
command line.

• -o output-filename : Print results to a file called output-filename rather than to the standard output.

• -? : Print usage information.

For example, to view information about the validity of a license key (123AA-123BB-123CC-123DD-123EE in the example)
and write the output to a file called validity-output.txt, run the following (Linux):

prompt$ cd /opt/vfabric/utils/vfabric-vfchksn-1.0.1
prompt$ vfabric-licensetool checkserial -o validity-output.txt 123AA-123BB-123CC-123DD-123EE

In the preceding example, it is implied that you unzipped the ZIP file into the /opt/vfabric/utils directory.

The validity-output.txt file contains information similar to the following:

123AA-123BB-123CC-123DD-123EE:
vFabric 5.1 License.
Product: vFabric
Edition: vf.pfm.adv
Description: VMware vFabric Advanced
Quantity: 50
ExpirationDate: never
Addons: none

21

22 vFabric Suite

22 vFabric Suite Licensing

Installing vFabric License Server and
Activating Your License

5. Installing vFabric License Server and Activating Your License

Before you install vFabric Suite components, you need to install vFabric License Server and activate your vFabric Suite license.

1. Install vFabric License Server. How and where you install the License Server depends on your environment:

• Install vFabric License Server on the same Windows machine on which you installed VMware vCenter Server.

• Install vFabric License Server on an EC2 instance that is running RHEL or on a physical machine that is running RHEL.
Because you do not install the License Server as an extension of the vCenter environment, this scenario is referred to
henceforth as installing vFabric License Server Standalone . This version of vFabric License Server is known as the
standalone License Server.

2. Activate your vFabric licenses.

3. Install individual vFabric Suite components (such as vFabric tc Server).

• If you are installing vFabric Suite components on Red Hat Enterprise Linux (RHEL), you have two options: Use the yum
command to install from an RPM file in the vFabric RPM repository, or install from a ZIP or TAR file from the standard
VMware download Web site.

23

• If you are installing on another supported operating system (such as Windows), you install the vFabric components from
a package that you download from the VMware download Web site. If you install from a download page, the package
might be in a *.zip, *.tar, or *.exe format, depending on the component.

This chapter provides installation-related procedures for vFabric License Server and describes how to activate your vFabric Suite
license. For product installation instructions, see the documentation for a particular vFabric component.

Subtopics

Installing vFabric License Server on vCenter Server

RHEL Only: Install vFabric License Server Standalone

Activate vFabric Suite Licenses

Optionally Configure Computer to Track License Usage of OSS Components on RHEL

Upgrade vFabric License Server on vCenter Server

Uninstall vFabric License Server from vCenter Server

Uninstall Standalone vFabric License Server

Installing vFabric License Server on Your vCenter Server

If you are installing vFabric License Server into your existing vCenter environment, install it on the same Windows computer
that is running vCenter.

vFabric License Server requires a database to store and organize its data. The License Server fully supports using the database
system associated with vCenter Server to store its license data. However, VMware recommends that you create a separate
database instance for vFabric use so as to keep the data of the two products separate. (The term database instance refers to an
Oracle database schema or a Microsoft database.) You can also use a completely separate database system. In either case, you
must create an ODBC data source specifically for use by vFabric License Server, as described in the procedures that follow.

vFabric License Server supports Microsoft SQL Server and Oracle database systems. In general, the supported versions of each
database system are the same as those supported by vCenter Server.

23

24 vFabric Suite

Prerequisites

• Install and configure vCenter Server and vSphere client on your Windows computer and be sure they are running correctly.
See vSphere Installation and Setup.

• Create a vFabric License Server database instance and create an ODBC data source that connects to the vCenter database
system or to a separate database system. Make sure that only vFabric License Server uses this ODBC data source. vFabric
License Server supports Microsoft SQL Server and Oracle databases. See Create the Microsoft SQL Server ODBC Data

Source or Create the Oracle ODBC Data Source for details.

• From the Windows computer on which you are running vCenter Server, download the vFabric License Server installer
program from the VMware Download Center and save it to your computer.

The installer program is called vFabric_License_Server-version.exe.

Guidelines for Creating the vFabric License Server Database Instance

vFabric License Server fully supports using the database system associated with vCenter Server to store its license data.
However, VMware recommends that you create a separate database instance for vFabric use so as to keep the data of the two
products separate. (The term database instance refers to either an Oracle database schema or a Microsoft database.)

Follow these general guidelines when creating the database instance:

• Access permissions: In general, use the same database access permissions defined for the vCenter Server database.

• Database size: Estimating the size of the vFabric License Server database is an inexact science that depends on a number of
variables. Most important is the number of vFabric component installations across all the VMs on your vCenter Server. The
more installations you have, the more data collected by vFabric License Server, and the bigger the database. However, the
amount of data collected by the license server for a particular component installation is relatively small. In sum, 5 GB should
be more than adequate for the vFabric License Server database instance.

For reference information about creating databases (Microsoft SQL Server) and schemas (Oracle) as well as users and their
required permissions, see:

• Configure Microsoft SQL Server Databases

• Configure Oracle Databases

Create the Microsoft SQL Server ODBC Data Source

Before you install vFabric License Server in a vCenter Server environment, you must create an ODBC data source that connects
to the database system associated with vCenter Server or to a separate database system. If you use the vCenter database system,
VMware recommends that you create a separate SQL Server database instance for vFabric use so as to keep the data of the two
products separate. This ODBC data source should be used only by vFabric License Server. This section provides instructions for
the Microsoft SQL Server database system.

Prerequisites

• Ensure that the Windows computer on which vCenter Server is running has the SQL Server Native Client ODBC
driver installed on it; if not, download and install the driver from the Microsoft SQL Server Web site.

• Create the database instance that will contain vFabric license data. See Guidelines for Creating the vFabric License Server

Database Instance.

Procedure

1. On the same Windows computer on which you are running vCenter Server, invoke the ODBC Data Source Administrator

window: Start > Programs > Administrative Tools > Data Source (ODBC).

2. Select the System DSN tab.

Installing vFabric License Server and

24

Activating Your License

Installing vFabric License Server and
Activating Your License

3. Click the Add... button.

4. Select the SQL Server Native Client driver. Click Finish.

5. Enter a name and description of the data source, then select the SQL Server you want this data source to connect to from the

drop-down list. Click Next.

The SQL Server can be the one used by the vCenter Server or a different one, depending on which works best for your
environment.

6. Specify that you want SQL Server to verify the authenticity with a login ID and password entered by the user, then enter the
login ID and password of the SQL Server user. This database user must have privileges to load the schema.

VMware recommends that you do not specify integrated Windows authentication.

7. Continue clicking Next, accepting all default values, and then click Finish.

You see a summary of the data source configuration.

8. Test the data source to make sure you configured it correctly, then click OK.

Create the Oracle ODBC Data Source

Before you install vFabric License Server in a vCenter Server environment, you must create an ODBC data source that connects
to either the database system associated with vCenter Server or to a separate database system. If you use the vCenter database
system, VMware recommends that you create a separate database instance (also referred to as an Oracle database schema) for
vFabric use so as to keep the data of the two products separate. This ODBC data source should be used only by vFabric License
Server. This section provides instructions for the Oracle database system.

25

Prerequisites

• Install the appropriate Oracle ODBC driver on the vCenter Server Windows computer. You will use this driver to connect to

your Oracle database.
Warning: The following procedure provides only general guidelines for installing the Oracle ODBC driver. Contact your

Oracle database administrator for the instructions for your particular environment.

1. Download the following ZIP files from the Instant Client for Microsoft Windows (x64) Web site and unzip them into a
directory:

• Instant Client Package - Basic: All files required to run OCI, OCCI, and JDBC-OCI applications.

• Instant Client Package - ODBC: Additional libraries for enabling ODBC applications.

For the remainder of this procedure it is assumed you unzipped the files into the C:\instantclient_11_2 directory.

2. Set the TNS_ADMIN environment variable to the C:\instantclient_11_2 directory and add the C:
\instantclient_11_2 directory to the PATH environment variable.

3. Open a command prompt and execute the following commands to install the ODBC driver:

prompt> cd C:\instantclient_11_2
prompt> odbc_install.exe

You should see the message Oracle ODBC Driver is installed successfully.

4. If necessary, create or update the C:\instantclient_11_2\tnsnames.ora file and define your Oracle database
address so the ODBC driver can connect to it.

• Create the database instance that will contain vFabric Suite license data. See Guidelines for Creating the vFabric License

Server Database Instance.

25

26 vFabric Suite

Procedure

1. On the same Windows computer on which you are running vCenter Server, invoke the ODBC Data Source Administrator

window: Start > Programs > Administrative Tools > Data Source (ODBC).

2. Select the System DSN tab.

3. Click the Add... button.

4. Select the Oracle driver from the list. Click Finish.

5. In the Oracle ODBC Driver Configuration window, enter a Data Source Name and Description of the data source.

From the TNS Service Name drop-down list, select the Oracle database system and database to which this data source will
connect. The entries in the list come from the c:\instantclient_11_2\tnsnames.ora file.

The Oracle database system can be the one used by the vCenter Server or another one, depending on which works best for
your environment.

6. Enter the Oracle database user name in the User ID field.

7. Click Test Connection, enter the user's password, and ensure that you can connect to the Oracle database.

8. Click OK.

Install vFabric License Server on the vCenter Server

1. On the same Windows computer on which you are running vCenter Server, log in as the Administrator user (or user with
administrator privileges) if you have User Account Control (UAC) enabled. If UAC is disabled, log in as any user.

2. Double-click the vFabric License Server installer program from Windows Explorer to start the installation.

The vFabric License Server welcome screen appears.

26

Installing vFabric License Server and

Activating Your License

Installing vFabric License Server and
Activating Your License

3. Continue clicking Next to accept the license agreement and view where the installer will install vFabric License Server.

You cannot change the location of vFabric License Server, which is a Web application and thus must be located in the
webapps directory of the vCenter Tomcat instance.

4. Enter the credentials of the vCenter user who has the appropriate privileges to register the vFabric License Server as an
extension. At a minimum, the user must have the following vCenter privileges:

• Extension.Register

• Extension.Update

By default, vCenter users with the Administrator role have all these privileges. However, users and roles may have been
customized for your particular environment, so check with your vCenter Server administrator. See Authentication and User

Management for information on assigning vCenter privileges.

1. Click Next to continue. The installer program performs the required validations and other tasks.

2. Enter the login ID and password of the database user, and select the ODBC data source (DSN) that you created as a

prerequisite to this procedure.

3. Click Install to proceed with the installation.

27

The installer program installs the vFabric License Server, showing you a status of the installation as it performs its tasks.

The program completes successfully when you see the message InstallShield Wizard Completed.

4. To view details of the installation, click Show the Windows Installer Log. Click Finish to complete the installation.

5. Restart your vCenter Server to enable the vFabric License Server changes.

6. Optionally verify that the vFabric License Server is running by invoking the monitoring graphical UI. See Monitor License

Usage with the vFabric License Server Reporting UI.

What to do next

• Activate vFabric Suite licenses in your vCenter Server.

• Install one or more vFabric components, such as vFabric tc Server or vFabric GemFire, on a new or existing virtual machine

(VM.) Refer to the documentation for a particular vFabric component.

• If your vFabric Suite license includes open-source software (OSS) support, optionally configure the RHEL VM on which you

have installed one or more OSS components to track their usage. OSS components you can track include Apache Tomcat,
Apache HTTP Server, and RabbitMQ. You can track OSS usage only on RHEL computers. See Optionally Configure

Computer to Track License Usage of OSS Components on RHEL.

• Monitor vFabric Suite license usage by using the vFabric Suite command-line interface or graphical UI. See Monitoring

vFabric License Usage.

RHEL Only: Installing vFabric License Server Standalone

The standalone version of vFabric License Server (supported on RHEL operating systems only) can track license usage of all
vFabric components that are configured to communicate with the License Server computer. The vFabric components might be
installed on physical computers or on Amazon EC2 instances. Similarly, you install the License Server on a physical RHEL
computer or an Amazon EC2 instance running RHEL.

The standalone vFabric License Server uses an internal database to store its licensing information. However, unlike the vCenter
version of the vFabric License Server, you cannot configure it to use any other database server.

27

28 vFabric Suite

The vFabric License Server uses vFabric tc Server internally. If necessary, the installation of the vFabric License Server on
RHEL will automatically install vFabric tc Server.

Prerequisites

• Be sure the RHEL computer on which you are going to install vFabric License Server has a JDK or JRE (Version 6 only)
installed.

Set the following environment variables for the user who is going to install vFabric License Server (either root or a user with
sudo privileges):

• JAVA_HOME: Points to the JDK or JRE installation.

• PATH: Points to JAVA_HOME/bin.

• Install the vFabric repository RPM from which you will install the standalone vFabric License Server. In addition to the
License Server, the vFabric repository contains all product RPMs that are certified with this release of vFabric Suite.

1. On the RHEL computer (either physical or an Amazon EC2 instance), start a terminal either as the root user or as an

unprivileged user using sudo.

2. Install the vFabric repository RPM using the following wget command, passing it the RHEL 6 URL.

Important: You must run the entire wget command on a single line. Be sure you include the | sh at the end, or the
RPM installation will not work.

prompt# wget -q -O - http://repo.vmware.com/pub/rhel6/vfabric/5.3/vfabric-5.3-suite-installer | sh

If necessary, use sudo to run the preceding commands if you are not logged in as the root user.

The command performs the following tasks:

• Imports the vFabric GNU Privacy Guard (GPG) key.

• Installs the vFabric 5.3 repository RPM.

• Launches the VMware End User License Agreement (EULA) acceptance and repository configuration script.

• Outputs the EULA for you to read; you must answer yes to accept the terms and continue.

Procedure

1. Log on as the root user (or unprivileged user with sudo privileges) to the RHEL computer (either physical or Amazon

EC2 instance) on which you are going to install vFabric License Server, and start a terminal.

2. Execute the following yum command:

prompt# yum install vfabric-license-server

The yum command begins the install process, resolves dependencies, and displays the packages it will install.

If necessary, use sudo to run the preceding command if you are not logged in as the root user. For example:

prompt$ sudo yum install vfabric-license-server

Enter y at the prompt to begin the actual installation.

If the installation is successful, you see a Complete! message at the end.

3. Run the following script to initialize the vFabric License Server:

Installing vFabric License Server and

28

Activating Your License

Installing vFabric License Server and
Activating Your License

prompt# /opt/vmware/vfabric-license-server/server/create_vls_instance.sh

The script outputs what it is doing; the initialization is successful if you see output similar to the following at the end:

...
Instance created
Connector summary
Port: 8443 Type: Blocking IO Secure: true

Important Make note of the secure (HTTPS) port number because you will need it later when you configure vFabric
component computers to communicate with the License Server. In the example above, the HTTPS port is 8443.

4. Ensure that the vFabric License Server has been correctly installed and initiated by starting it:

prompt# service vfabric-license-server start

You should see the following output:

Starting vfabric license server: [ OK ]

5. Optionally configure the License Server at boot :

prompt# chkconfig --level 35 vfabric-license-server on

29

Note Although this step is optional, VMware recommends it so you do not have to start the License Server manually each
time you reboot your RHEL computer. If you do not perform this step, use the commands in the previous step to start and
stop the License Server.

What the yum install command does

The yum install vfabric-license-server command:

• If the user does not already exist, adds a vls non-interactive user (in the group vfabric).

You cannot log in directly as the vls user because interactive login is disabled. Instead, log in as the root user (or as an
unprivileged user using sudo,) and then su - vls .

• Installs vFabric License Server into the /opt/vmware/vfabric-license-server directory and sets the owner of the
directory, along with all child directories and files, to vls:vfabric.

What to do next

• Activate vFabric Suite licenses for standalone License Server.

• Install one or more vFabric components, such as vFabric tc Server or vFabric GemFire, on a computer that can access the
RHEL computer on which you just installed the vFabric License Server. Refer to the installation instructions for the particular
vFabric component for details.

Important: When using the standalone vFabric License Server on RHEL, you must also configure each tracked vFabric
component to communicate with the vFabric License Server. See Configure vFabric Components to Communicate with

Standalone vFabric License Server.

• If your vFabric license includes open-source software (OSS) support, optionally configure the Red Hat Enterprise Linux
(RHEL) computer on which you have installed one or more OSS components to track their usage. OSS components you can
track include Apache Tomcat, Apache HTTP Server, and RabbitMQ. See RHEL: Optionally Configure Computer to Track

Open-Source Software Component Usage.

• Monitor vFabric license usage by using the vFabric Suite command-line interface or graphical UI. See Monitoring vFabric

License Usage.

29

30 vFabric Suite

Starting and Stopping the Standalone vFabric License Server

If you choose not to use chkconfig to configure standalone vFabric License Server to start at the same time you boot the
RHEL computer, you must start and stop it manually.

Prerequisites

• Install standalone vFabric License Server.

Procedure

1. Log on to the RHEL computer on which you installed the standalone vFabric License Server as the root user (or as an
unprivileged user who has sudo privileges) and start a terminal.

2. Start vFabric License Server:

prompt# service vfabric-license-server start

You should see the following output:

Starting vfabric license server: [ OK ]

3. Use similar commands to get status about the License Server and to stop it:

prompt# service vfabric-license-server status
prompt# service vfabric-license-server stop

Note: If you try to stop the License Server when it is not running, the service vfabric-license-server stop
command returns Fail; this is correct behavior.

Configure vFabric Components to Communicate with Standalone vFabric License Server

For the standalone vFabric License server to track license usage of vFabric components, you must configure each computer on
which you have installed vFabric components to communicate (via HTTPS) with the License Server RHEL computer. You do
this by creating a simple file on the same computer on which the vFabric component is running, as described in the following
procedure.

vFabric components might be installed on physical computers as well as Amazon EC2 instances. The procedure in this section
applies to both.

Important: This section does not apply to vFabric Hyperic components. To configure vFabric Hyperic to communicate with the
standalone License Server, you set the vfabric.licenseServer.url property in the Hyperic Server's SERVER_HOME/
conf/hq-server.conf file to point to the License Server host and port. See Configure vFabric License for details.

Prerequisite

• Make note of the host on which vFabric License Server is installed and the secure (HTTPS) port of the License Server. The

HTTPS port number was outputted when you installed the License Server. The default secure port is 8443.

Procedure

1. Log on to the computer on which the vFabric component is installed; log on as the user who owns the vFabric component
installation.

2. Create a file called vflicense.properties, located in the same directory as the component events file. This directory
differs for each component; see Location of vflicense.properties File for details.

3. Edit the vflicense.properties file by adding a single property called
vfabric.licensing.server.address, as shown in the following sample:

Installing vFabric License Server and

30

Activating Your License

Installing vFabric License Server and

31

Activating Your License

vfabric.licensing.server.address=https://host:port

where:

• host is the hostname of the vFabric License Server RHEL computer.

• port is the secure port number that the License Serve listens to for HTTPS requests.

For example, if your License Server is on host myhost, listening at the default HTTPS port 8443, the file would look like
the following:

vfabric.licensing.server.address=https://myhost:8443

Location of vflicense.properties File

The vflicense.properties file points an installed vFabric component to the location of the standalone vFabric License
Server. You create the vflicense.properties file in the same directory in which the vFabric component keeps its events
file; this events file records particular events, such as the component start and stop times, as well as when it used its license.

The events file directory differs for each vFabric component. Depending on the component, the events file might be relative to an
instance (such as tc Server) or relative to the component installation directory, as shown in the following table.

Table 5.1. Location of the vflicense.Properties File

vFabric Component Location of vflicense.properties File

vFabric Web Server INSTALL_DIR/instance-name/conf, where INSTALL_DIR refers to the main installation directory of vFabric

vFabric tc Server INSTANCE_DIR/instance-name/logs, where INSTANCE_DIR refers to the directory that contains vFabric tc

Spring Insight Operations INSTANCE_DIR/instance-name/logs, where INSTANCE_DIR refers to the directory that contains the vFabric

vFabric EM4J INSTANCE_DIR/instance-name/logs, where INSTANCE_DIR refers to the directory that contains the vFabric

vFabric GemFire GemFire Cache Server working directory.
vFabric SQLFire SQLFire Server working directory.
vFabric RabbitMQ /opt/vmware/vFabric (RHEL) or c:\ProgramData\VMware\vFabric (Windows)
vFabric Postgres /opt/vmware/vFabric (RHEL) or c:\ProgramData\VMware\vFabric (Windows)

Web Server (such as /opt/vmware/vfabric-web-server on RHEL), and instance-name refers to the
name of the Web Server instance.

Server instances (such as /var/opt/vmware/vfabric-tc-server-standard on RHEL), and instance-
name refers to the name of the tc Server instance.

tc Server instance that is hosting Spring Insight (such as /var/opt/vmware/vfabric-tc-server-standard
on RHEL), and instance-name refers to the name of the tc Server instance.

Note that the name Spring Insight Operations will not show up on the vFabric License Server usage report; rather,
the tc Server instance in which Spring Insight is running will show up instead.

tc Server instance that is hosting EM4J (such as /var/opt/vmware/vfabric-tc-server-standard on
RHEL), and instance-name refers to the name of the tc Server instance.

Activate vFabric Suite Licenses

VMware offers VMware V8 production licenses for the vFabric Suite Standard and vFabric Suite Advanced platform packages.
The license is perpetual for a particular version and package of vFabric Suite.

The following procedures describe how to active your vFabric licenses, depending on the environment in which you installed the
License Server:

• Activate a vFabric Suite License in vCenter

• Activate a vFabric Suite License with a Standalone License Server

31

32 vFabric Suite

Activate a vFabric Suite License in vCenter

You activate vFabric licenses on vCenter Server using the vSphere Client.

Prerequisites

• Install vFabric License Server on your vCenter Server.

• Decide how many vFabric Suite license units you need, purchase them, and then get your license key from the VMware license

portal. See How Licensing Works with vFabric Suite Standard and Advanced.

Procedure

1. Start vSphere Client and log in to the vCenter Server in which you installed vFabric License Server.
Note: This procedure shows how to use version 5.0 of vSphere Client.

2. Select Home > Administration > Licensing to invoke the vCenter Licensing page, then click the Manage vSphere
Licenses link in the top-right corner, as shown in the screenshot.

3. Enter one or more license keys in the text window to the right, one license key per line. Enter an optional label.

4. Click the Add License Keys button. The license key shows up in the review window.

5. Repeat the preceding steps to add any additional license keys.

6. Click Next and follow the prompts until you get to the Confirm Changes window, verify changes, then click Finish.
The license keys are displayed in the main vCenter Licensing window under the name VMware vFabric Suite

Standard|Advanced, depending on the vFabric Suite package you purchased.

Installing vFabric License Server and

32

Activating Your License

Installing vFabric License Server and
Activating Your License

The vCenter Licensing page displays only the capacity of your vFabric Suite license; it does not actually keep
track of the number of licenses currently assigned. See Monitoring vFabric License Usage for information on
using the monitoring commands.

33

Activate a vFabric Suite License with the Standalone License Server

You activate vFabric licenses when using the standalone vFabric License Server on RHEL by updating a file with your serial
numbers. The vFabric License Server reads this file every minute.

Prerequisites

• Install the standalone vFabric License Server on your RHEL computer.

• Decide how many vFabric Suite license units you need, purchase them, and then get your license key from the VMware license
portal. See How Licensing Works with vFabric Suite Standard and Advanced.

Procedure

1. On the RHEL computer on which you installed the standalone vFabric License Server, log on as the root user, or as a user

who has sudo privileges.

2. If you have not already done so, create a file called serials.txt in the /opt/vmware/vfabric-license-

server/server/vls/webapps/vfabric-license-server/WEB-INF/classes directory. This directory is
created as part of the installation of the standalone vFabric License Server.

3. Add your license keys to the serials.txt file, one key per line, as shown in the following example:

----- VMware vFabric Standard ----­AB123-BC234-CD345-DE456-EF567

----- VMware vFabric Advanced ----­FG123-GH234-HI345-IJ456-JK567
KL123-LM234-MN345-NO456-OP567

Optionally Configure Computer to Track License Usage of OSS Components on RHEL

If your vFabric license includes support for open-source software (OSS) components, you can also monitor the usage of the
OSS components installed on Red Hat Enterprise Linux (RHEL) computers. To do this you must first install a vFabric OSS
license agent on the computer, as described in this section. Subsequently, when you monitor the vFabric license usage with the
monitoring commands or the user interface, the open-source components will also be included in the usage numbers along with
the vFabric components.

You can monitor usage of the following open-source components. Click on the links to view the supported versions and
additional information about the support provided by VMware.

• Apache Tomcat

• Apache HTTP Server

• RabbitMQ

Prerequisites

• Install the vFabric repository RPM. The vFabric RPM repository contains the OSS license agent RPM, which is called
vfabric-agent.

• Ensure that crontab is installed and running on your RHEL computer. The vFabric OSS license agent runs as a cron job.

33

34 vFabric Suite

Procedure

1. Log in as the root user on the RHEL computer on which you are going to install the OSS license agent and start a terminal.

2. Execute the following yum command to install the OSS license agent:

prompt# yum install vfabric-agent

The yum command begins the install process, resolves dependencies, and displays the packages it plans to install.

The yum command automatically choses the appropriate RPM package based on your architecture (32- or 64-bit).

3. Enter y at the prompt to begin the actual installation.

If the installation is successful, you will see a Complete! message at the end.

4. If you are using the standalone (non-vSphere) version of vFabric License Server, configure the OSS license agent to
communicate with the License Server by creating a file called vflicense.properties that contains a single property
(vfabric.licensing.server.address), as shown in the following sample:

vfabric.licensing.server.address=https://host:port

where:

• host is the hostname of the vFabric License Server RHEL computer.

• port is the secure (HTTPS) port number that the License Server listens to for HTTPS requests.

These secure port number was outputted when you installed the License Server.

For example, if your License Server is on host myhost, listening at the default HTTPS port 8443, the file would look like
the following:

vfabric.licensing.server.address=https://myhost:8443

Save the vflicense.properties file in the /opt/vmware/vfabric-agent directory.

You do not perform this step if you install vFabric License Server in a vSphere environment.

Your RHEL computer is now configured to automatically detect whether any of the supported OSS components are installed and
to periodically send usage information to the vFabric License Server.

What the vfabric-agent RPM install does

The yum install of the vfabric-agent RPM performs the following tasks on the RHEL computer:

• If it doesn't already exist, creates the vfabric group.

• Copies the following files and directories (owned by root:vfabric) to disk:

/etc/cron.d/vfabric-agent
/opt/vmware/vfabric-agent
/opt/vmware/vfabric-agent/vfdetect-license.cfg
/opt/vmware/vfabric-agent/vfdetect-scripts
/opt/vmware/vfabric-agent/vfdetect-scripts/oss.rmq
/opt/vmware/vfabric-agent/vfdetect-scripts/oss.tc
/opt/vmware/vfabric-agent/vfdetect-scripts/oss.ws
/opt/vmware/vfabric-agent/vfdetect.log
/usr/sbin/vfdetect

The /etc/cron.d/vfabric-agent file contains the following line:

34

Installing vFabric License Server and

Activating Your License

Installing vFabric License Server and
Activating Your License

*/10 * * * * root /usr/sbin/vfdetect /opt/vmware/vfabric-agent/vfdetect-scripts

The /opt/vmware/vfabric-agent directory will contain the state and log files of the OSS license agent.

Upgrade vFabric License Server on vCenter Server

Upgrade vFabric License Server to the latest version to get the latest features and bug fixes.

Prerequisites

• From the Windows VM on which you are running vCenter Server, download the new version of the vFabric License Server
installer program from the VMware Download Center and save it to your computer.

The installer program is called vFabric_License_Server-version.exe.

Procedure

1. On the same Windows VM on which you are running vCenter Server, double-click the vFabric License Server installer

program from Windows Explorer to start the upgrade.

2. Click Yes to begin the upgrade, and continue clicking Next to accept the license agreement and finish the upgrade. The

upgrade procedure keeps the same metadata that was there when you first installed the License Server.

35

3. When the upgrade completes, restart vCenter Server for the upgrade changes to take effect.

Uninstall vFabric License Server from vCenter Server

Uninstalling vFabric License Server removes the Web application from the vCenter Tomcat instance, but it does not remove the
vFabric licensing data from the database; you must perform that step yourself.

Procedure

1. Log on to the Windows computer on which you are running vCenter Server and on which you installed vFabric License

Server.

2. From the Windows Control Panel, start the window from which you add or remove programs. On Windows XP, the window

is called Add or Remove Programs. On Windows Server, the window is called Programs and Features.

3. Select VMware vFabric License Server in the list of programs and uninstall it.

4. If you want to unregister vFabric License Server from vCenter, enter the credentials of the vCenter user who has, at a

minimum, the following vCenter privilege:

• Extension.Unregister

By default, vCenter users with the Administrator role have this privilege, although you might have customized the users
and roles for your particular environment, so check with your vCenter Server administrator. See Authentication and User

Management for information on assigning vCenter privileges.

If you do not want to unregister vFabric License Server, do not enter any credentials.

5. Click Next to finish uninstalling.

What to do next

• If you want to delete the vFabric licensing data from the database, you must do this manually. Consult the vCenter
administrator if you use the internal vCenter database to store license data, or the database administrator of the separate
database.

35

36 vFabric Suite

Uninstall Standalone vFabric License Server

Uninstalling the standalone version of vFabric License Server completely removes it from your RHEL computer, including the
internal database that contains all usage data of vFabric components.

Procedure

1. Log on to the RHEL computer on which you installed the standalone vFabric License Server as the root user (or as an
unprivileged user who has sudo privileges) and start a terminal.

2. Stop the vFabric License Server:

prompt# service vfabric-license-server stop

Note: If the License Server was not running, the previous command returns Fail; this is correct behavior.

3. Uninstall the vFabric License Server by running the following yum command:

prompt# yum remove vfabric-license-server

4. If you previously used chkconfig to configure the License Server to start at computer boot-time, run the following
command to unconfigure it:

prompt# chkconfig --level 35 vfabric-license-server off

36

Installing vFabric License Server and

Activating Your License

Monitoring vFabric License Usage 37

6. Monitoring vFabric License Usage

vFabric Suite provides command-line tools and a simple Web user interface to monitor vFabric license usage by the virtual and
physical computers on which vFabric Suite components are installed.

Note: If you installed the vFabric License Server in a vSphere environment (which means you installed the license server on the
same computer on which vCenter Server is installed), you also activated vFabric licenses using the vSphere client. However, you
cannot use the vSphere client user interface to monitor the vFabric license usage; rather, you must use the commands described in
this chapter.

Subtopics

Monitor License Usage with Command-Line Tools

License Monitoring Command Reference

Monitor License Usage with the vFabric License Server Reporting UI

Display the Component Events File in Readable Format

vCenter License Reporting Manager

Monitor License Usage with Command-Line Tools

vFabric Suite provides four command-line tools to monitor current and periodic vFabric license usage by the virtual and physical
computers on which you are running vFabric components. You run these tools on the same computer on which you installed the
vFabric License Server.

For the complete list of commands, see License Monitoring Command Reference.

Prerequisites

• The vFabric license-usage reports require a 64-bit JDK or JRE (version 6).

• If you are using vFabric Suite in a vSphere environment, by default the reports use the JRE installed with vCenter Server,
located in the c:\Program Files\VMware\Infrastructure\jre directory. The reports use the following line to
add these Java binaries to the PATH variable:

SET PATH=%PATH%;C:\Program Files\VMware\Infrastructure\jre\bin

If you have installed your own JDK or JRE on the vCenter Server computer, and updated the system PATH variable with its
location, the vFabric license-usage reports will use that JDK/JRE instead. This should not cause any problems, as long as the
JDK/JRE is 64-bit and version 6. If it is not, then you must change the SET PATH line in the license reports to the following:

SET PATH=C:\Program Files\VMware\Infrastructure\jre\bin;%PATH%

The preceding sample assumes the default location of the VMware infrastructure directory; if you installed vCenter into a
different directory, then make the appropriate change.

Procedure

1. On the computer on which you installed vFabric License Server, open a command prompt (Windows) or terminal (Linux)

and change to one of the following directories, depending on the environment in which you installed the license server:

• vSphere: vCenter-Install-Dir\vFabric Platform\Reporting , where vCenter-Install-

Dir refers to the directory in which you installed vCenter Server (default is C:\Program Files\VMware
\Infrastructure.)

37

38 vFabric Suite

• RHEL standalone (that is, a non-vSphere environment): /opt/vmware/vfabric-license-server/bin

For example, on the Windows VM on which vCenter Server is installed:

prompt> cd c:\Program Files\VMware\Infrastructure\vFabric Platform\Reporting

If you installed standalone vFabric License Server on a RHEL computer:

prompt$ cd /opt/vmware/vfabric-license-server/bin

2. Run the desired monitoring command.

For example, run the usage-over-periods command to display vFabric license usage over a period of time. Specify
the start and end dates of the time period, as well as the period, such as monthly or yearly. Output is shown after the
command. Usage refers to the number of licenses in use.

prompt> usage-over-periods.bat -startDate 09/01/2012 -endDate 09/4/2012 -period WEEKLY

Period: WEEKLY
License Key,Dates,Minimum Usage,Maximum Usage,Average Usage
123AA-123BB-123CC-123DD-123EE,"Sep 1, 2012 - Sep 7, 2012",2,4,3.1
123AA-123BB-123CC-123DD-123EE,"Sep 8, 2012 - Sep 14, 2012",2,3,2,5
123AA-123BB-123CC-123DD-123EE,"Sep 15, 2012 - Sep 21, 2012",1,1,1
123AA-123BB-123CC-123DD-123EE,"Sep 22, 2012 - Sep 28, 2012",1,1,1
123AA-123BB-123CC-123DD-123EE,"Sep 29, 2012 - Sept 30, 2012",0,1,0.64

For descriptions and examples of each command, see License Monitoring: Command Reference.The commands for
Windows and Linux are the same, except that Windows commands have a .bat suffix and the Linux commands have a
.sh suffix.

License Monitoring: Command Reference

The following sections provide complete reference documentation for the following vFabric license monitoring commands:

• current-usage

• current-versions

• usage-over-periods

• versions-over-periods

Depending on the environment in which you installed the vFabric License Server, you run a Windows version of the monitoring
command (vSphere environment) or a Linux version (standalone RHEL environment.)

The following example shows how to run a monitoring command on Linux:

prompt$ ./current-usage.sh

The equivalent on Windows is as follows:

prompt> current-usage.bat

The remainder of this topic provides Windows examples.

In the sections, usage refers to the number of vFabric licenses that are assigned to a computer (virtual or physical) running one or
more vFabric components, such as vFabric tc Server, and capacity refers to the number of vFabric licenses you have purchased.

Command options available only in a vSphere environment are flagged as such.

38 Monitoring vFabric License Usage

Monitoring vFabric License Usage 39

current-usage

Displays the current vFabric license usage and capacity, organized by license key.

When running in a vSphere environment and no relevant options are specified, the command displays information for the entire
vCenter Server.

Syntax

current-usage [-group group | -cluster name | -datacenter name | -resourcePool name ]

You can specify only one of these options: -group, -cluster, -datacenter, or -resourcePool.

Table 6.1. Options of current-usage

Option Description

-group group (vSphere Environment Only) Groups the output of the current-usage command by cluster, resource pool, or

-cluster cluster-

name

-datacenter

datacenter-name

-resourcePool

resourcePool-name

data center. The output lists the specific cluster, resource pool, or data center for each license usage entry.
Possible values (specify only one):

• cluster

• resourcePool

• datacenter
For example, to group by resource pool, specify -group resourcePool.

(vSphere Environment Only) Displays current usage and capacity information for the specified cluster.

(vSphere Environment Only) Displays current usage and capacity information for the specified virtual data

center.

(vSphere Environment Only) Displays current usage and capacity information for the specified resource pool.

Example

The following example shows how to run the current-usage command to get a report of the total current vFabric license
usage.

prompt> current-usage.bat

The output will look something like the following:

License Key,Quantity Licensed,Quantity Available,Current Usage
123AA-123BB-123CC-123DD-123EE,500,498,2

The entry shows the 500-license vFabric license key, with 498 licenses available and 2 currently in use.

To limit the report to the current usage on the myVDC datacenter, run the following:

prompt> current-usage.bat -datacenter myVDC

current-versions

Displays the current number of computers (virtual or physical) that are running one or more vFabric Suite components along with
the component name and versions.

39

40 vFabric Suite

When running in a vSphere environment and no relevant options are specified, the command displays information for the entire
vCenter Server.

Syntax

current-versions [-group group | -cluster name | -datacenter name | -resourcePool name ]

You can specify only one of these options: -group, -cluster, -datacenter, or -resourcePool.

Table 6.2. Options of current-versions

Option Description

-group group (vSphere Environment Only) Groups the output of the current-versions command by cluster, resource pool,

-cluster cluster-

name

-datacenter

datacenter-name

-resourcePool

resourcePool-name

or data center. The output lists the specific cluster, resource pool, or data center for each license usage entry.
Possible values (specify only one):

• cluster

• resourcePool

• datacenter
For example, to group by resource pool, specify -group resourcePool.
(vSphere Environment Only) Displays the current number of virtual machines in the specified cluster that are

running one or more vFabric components along with the component name and versions.
(vSphere Environment Only) Displays the current number of virtual machines in the specified data center that are

running one or more vFabric components along with the component name and versions.
(vSphere Environment Only) Displays the current number of virtual machines in the specified resource pool that

are running one or more vFabric components along with the component name and versions.

Example

The following example shows how to view all the currently-installed vFabric and open-source components that the vFabric
License Server is tracking and the number of virtual machines on which each component is installed, grouped by datacenter:

prompt> current-versions.bat -group datacenter

The output will look something like the following; note that one of the components the License Server is tracking is open-source
Apache Tomcat:

Datacenter Name,Component Name,Component Version,Number of Machines
Camb_vFabric,Apache Tomcat,7.0.30,1
Camb_vFabric,VMware vFabric tc Server,2.8.0.RELEASE,1
Camb_vFabric,VMware vFabric Web Server,5.2.0,1

usage-over-periods

Displays a report of vFabric license usage over a period of time, organized by license key. The report includes the minimum,
maximum, and average number of vFabric licenses that have been assigned to computers (virtual or physical) over the specified
period.

When running in a vSphere environment and no relevant options are specified, the command displays information for the entire
vCenter Server.

Syntax

usage-over-periods {-days number | range} [-group group | -cluster name | -datacenter name | -resourcePool name ] [-period period]

40 Monitoring vFabric License Usage

Monitoring vFabric License Usage 41

The following table lists the options for this command.

Table 6.3. Options of usage-over-periods

Option Description

-days number Specifies a date range in which the end date is today and the start date is the current date minus number of days.

-startDate MM/DD/

YYYY

-endDate MM/DD/YYYY

-group group (vSphere Environment Only) Groups the output of the usage-over-periods command by cluster, resource

-cluster cluster-

name

For example, use -days 90 to specify an approximate date range of the last three months.
You must specify either the -days option or the two options to specify a custom data range (-startDate and -

endDate), but not both.
Used together, these two options specify a custom date range. Use -startDate to specify the start date of

the report; use the form MM/DD/YYYY, such as 06/01/2012 for a start date of June 1, 2012. Use -endDate to
specify the end date of the report.

For example, to specify a date range between April 1, 2012 and June 30, 2012, use the following: -startDate
04/01/2012 -endDate 06/30/2012.

You must specify either -startDate and -endDate or the -days option, but not both.

pool, or data center. The output will list the specific cluster, resource pool, or data center for each license usage
entry.

Possible values (specify only one):

• cluster

• resourcePool

• datacenter
For example, to group by resource pool, specify -group resourcePool.
You can specify only one of the following options: -group, -cluster, -datacenter, or -resourcePool.
(vSphere Environment Only) Displays periodic usage information for the specified cluster.
You can specify only one of the following options: -group, -cluster, -datacenter, or -resourcePool.

-datacenter

datacenter-name

-resourcePool

resourcePool-name

-period period Specifies the period that the report covers, such as daily or monthly, during the specified date range (see previous

(vSphere Environment Only) Displays periodic usage information for the specified virtual data center.
You can specify only one of the following options: -group, -cluster, -datacenter, or -resourcePool.
(vSphere Environment Only) Displays periodic usage information for the specified resource pool.
You can specify only one of the following options: -group, -cluster, -datacenter, or -resourcePool.

two entries). Valid values are:

• DAILY

• WEEKLY

• MONTHLY

• QUARTERLY (90 days)

• YEARLY

• ALL
Default value is DAILY.

Example

The following example shows how to run the usage-over-periods command to display vFabric license usage over a period
of time. You must specify the start and end dates of the time period, as well as the period, such as monthly or yearly.

prompt> usage-over-periods.bat -startDate 09/01/2012 -endDate 09/30/2012 -period WEEKLY

41

42 vFabric Suite

The output will look something like the following:

Period: WEEKLY
License Key,Dates,Minimum Usage,Maximum Usage,Average Usage
123AA-123BB-123CC-123DD-123EE,"Sep 1, 2012 - Sep 7, 2012",2,4,3.1
123AA-123BB-123CC-123DD-123EE,"Sep 8, 2012 - Sep 14, 2012",2,3,2,5
123AA-123BB-123CC-123DD-123EE,"Sep 15, 2012 - Sep 21, 2012",1,1,1
123AA-123BB-123CC-123DD-123EE,"Sep 22, 2012 - Sep 28, 2012",1,1,1
123AA-123BB-123CC-123DD-123EE,"Sep 29, 2012 - Sept 30, 2012",0,1,0.64

The output shows the minimum, maximum, and average use (number of active computers, physical or virtual, which are assigned
a license) of a single vFabric license key for each week in the month of September 2012. If you had installed additional vFabric
license keys, then these would also show up in the report.

Another example is to view the year-to-date usage of your vFabric Suite licenses. For example, if today is July 31, 2012:

prompt> usage-over-periods.bat -startDate 08/01/2011 -endDate 07/31/2012 -period YEARLY

The output will look something like the following:

License Key,Period,Minimum Usage,Maximum Usage,Average Usage
123AA-123BB-123CC-123DD-123EE,"Aug 1, 2011 - July 31, 2012",50,75,30.5

To view the daily usage over the last 90 days and group the output by the associated resource pool, run the following command:

prompt> usage-over-periods.bat -days 90 -group resourcePool

versions-over-periods

Displays a report of the computers that have run each vFabric component included in vFabric Suite over a period of time. The
report includes the minimum, maximum, and average number of computers over the specified time period.

When running in a vSphere environment and no relevant options are specified, the command displays information for the entire
vCenter Server.

Syntax

versions-over-periods {-days number | range} [-group group | -cluster name | -datacenter name | -resourcePool name ] [-period period]

The following table lists the options for this command.

Table 6.4. Options of usage-over-periods

Option Description

-days number Specifies a date range in which the end date is today and the start date is the current date minus number of days.
For example, use -days 90 to specify an approximate date range of the last three months.
You must specify either the -days option or the two options to specify a custom data range (-startDate and -

endDate), but not both.

-startDate MM/DD/

YYYY

-endDate MM/DD/YYYY

Used together, these two options specify a custom date range. Use -startDate to specify the start date of
the report; use the form MM/DD/YYYY, such as 06/01/2012 for a start date of June 1, 2012. Use -endDate to
specify the end date of the report.

For example, to specify a date range between April 1, 2012 and June 30, 2012, use the following: -startDate
04/01/2012 -endDate 06/30/2012.

You must specify either the -startDate and -endDate or the -days option, but not both.

-group group (vSphere Environment Only) Groups the output of the versions-over-periods command by cluster,
resource pool, or data center. The output will list the specific cluster, resource pool, or data center for each license
usage entry.

Possible values (specify only one):

42 Monitoring vFabric License Usage

Monitoring vFabric License Usage 43

Option Description

• cluster

• resourcePool

• datacenter
For example, to group by resource pool, specify -group resourcePool.
You can specify only one of the following options: -group, -cluster, -datacenter, or -resourcePool.

-cluster cluster­name

-datacenter

datacenter-name

-resourcePool

resourcePool-name

-period period Specifies the period that the report covers, such as daily or monthly. Valid values are:

(vSphere Environment Only) Displays periodic component version information for the specified cluster.
You can specify only one of the following options: -group, -cluster, -datacenter, or -resourcePool.
(vSphere Environment Only) Displays periodic component version information for the specified virtual data

center.
You can specify only one of the following options: -group, -cluster, -datacenter, or -resourcePool.
(vSphere Environment Only) Displays periodic component version information for the specified resource pool.
You can specify only one of the following options: -group, -cluster, -datacenter, or -resourcePool.

• DAILY

• WEEKLY

• MONTHLY

• QUARTERLY (90 days)

• YEARLY

• ALL
Default value is DAILY.

Example

The following example shows how to view a monthly report of the number of computers that have run the vFabric components
from September 1, 2012 to October 04, 2012:

prompt> versions-over-periods.bat -startDate 09/01/2012 -endDate 10/04/2012 -period MONTHLY

The output will look something like the following:

Period: MONTHLY
Component Name,Component Version,Dates,Minimum Number of Machines,Maximum Number of Machines,Average Number of Machines
VMware vFabric tc Server,2.8.0.RELEASE,"Sep 1, 2012 - Sep 30, 2012",0,0,0
VMware vFabric tc Server,2.8.0.RELEASE,"Oct 1, 2012 - Oct 4, 2012",0,1,0.53
Apache Tomcat,7.0.30,"Sep 1, 2012 - Sep 30, 2012",0,0,0
Apache Tomcat,7.0.30,"Oct 1, 2012 - Oct 4, 2012",0,1,0.31
VMware vFabric Web Server,5.2.0,"Sep 1, 2012 - Sep 30, 2012",0,0,0
VMware vFabric Web Server,5.2.0,"Oct 1, 2012 - Oct 4, 2012",0,1,0.37
VMware vFabric tc Server,2.6.2.RELEASE,"Sep 1, 2012 - Sep 30, 2012",1,1,1
VMware vFabric tc Server,2.6.2.RELEASE,"Oct 1, 2012 - Oct 4, 2012",0,1,0.68
VMware vFabric Spring Insight,1.5.1.SR3,"Sep 1, 2012 - Sep 30, 2012",1,1,1
VMware vFabric Spring Insight,1.5.1.SR3,"Oct 1, 2012 - Oct 4, 2012",0,1,0.68

The output includes the name of the component and versions, the period of reporting, and the minimum, maximum, and average
number of computers (physical or virtual) on which the component was running. Note that the report includes information about
open-source components, such as Apache Tomat.

The following example is similar, but limits the output to the mycluster cluster rather than the entire vCenter server.

prompt> versions-over-periods.bat -startDate 09/01/2012 -endDate 10/04/2012 -period MONTHLY -cluster mycluster

43

44 vFabric Suite

Monitor License Usage with the vFabric License Server Reporting UI

The vFabric License Server Reporting web user interface provides a graphical representation of the vFabric license usage and
capacity for a particular vCenter server or for a set of computers that the standalone vFabric License Server is tracking. The
web user interface provides similar output as the monitoring commands but with one difference: you cannot limit the output to
specific resource pools, clusters or data centers as you can with the command-line tools ; rather, the user interface always shows
the usage and capacity for the entire vCenter server.

Procedure

1. Invoke the vFabric License Server UI in your browser by navigating to the following URL:

https://host:8443/vfabric-license-server/report/create

where host is the IP address or hostname of the computer on which you installed the vFabric License Server. If your
browser is on the same computer, you can use localhost:

https://localhost:8443/vfabric-license-server/report/create

The following Web page appears:

2. Specify a range of dates by either entering the number of days previous to the current date, or entering a specific start- and
end-date.

3. Specify the output of the report: either an HTML Web page that is rendered immediately, or a downloadable *.csv file
that you can open in a spreadsheet program, such as Microsoft Excel, or import into a database application.

4. Click Create Report.

5. If you specified HTML output, a Web page similar to the following appears:

44 Monitoring vFabric License Usage

Monitoring vFabric License Usage 45

The output shows the minimum, maximum, and average usage of the two vFabric license keys that have been activated. The
date range is the last 90 days from the current day (in this case October 3, 2012.) The middle table lists all the vFabric and
open-source software (OSS) components that the vFabric License Server is tracking, the version of the installed component,
and the minimum, maximum, and average license usage for each component over the same period. Note that in the example
above, the vFabric License Server is tracking both open-source Apache Tomcat and vFabric tc Server. The bottom table
shows a summary of the vFabric Standard and vFabric Advanced license keys, with capacity and usage.

Display the Component Events File in Readable Format

Each vFabric component keeps an events file that records particular events, such as the component start and stop times, as well
as when it used its license. This events log file is difficult to read in its raw form, so you can use the vfabric-licensetool
printevents utility to display these events in a more readable format.

45

46 vFabric Suite

Prerequisites

• If necessary, install a JDK or JRE on the computer on which the vFabric component is installed.

Be sure the JAVA_HOME and PATH environment variables point to the JDK or JRE.

For example, if you installed the JDK in /usr/java/jdk1.6.0_24, you can set the environment variables in the user's
Linux profile as follows:

export JAVA_HOME=/usr/java/jdk1.6.0_24
export PATH=$JAVA_HOME/bin:$PATH

Procedure

1. On the computer on which the vFabric component is installed, download the vFabric License Check Tool from
the Drivers and Tools tab of the download page for vFabric Suite Advanced or Standard.

The file is called vfabric-vfchksn-version.bin.zip.

2. Unzip the file into a directory.

The utility and supporting files are unzipped into the vfabric-vfchksn-version child directory.

3. Open a command (Windows) or terminal (Linux) window, change to the directory in which you unzipped the utility, and run
the following (Linux):

prompt$ vfabric-licensetool printevents -f events-file

On Windows:

prompt> vfabric-licensetool printevents -f events-file

In the preceding commands, events-file refers to the full pathname of the component events file that you want to
display. Each component names and stores its events file differently. See Location of vflicense.properties File for the
location of the events file for each component (it is the same location as that of the vflicense.properties file). The
following table shows the name of the events file for each vFabric component:

Table 6.5. Name of the Events File For Each vFabric component

vFabric Component Name of Events File

vFabric Web Server vf.ws-events.txt
vFabric tc Server vf.tc-events.txt
Spring Insight Operations vf.ins-events.txt
vFabric EM4J vf.emj-events.txt
vFabric Hyperic vf.hyp-events.txt
vFabric GemFire Data Management Node vf.gf.dmn-events.txt
vFabric GemFire Application Cache Node vf.gf.acn-events.txt
vFabric SQLFire vf.sf-events.txt
vFabric RabbitMQ vf.rmq-events.txt
vFabric Postgres vf.vpg-events.txt

For example, to display event log information in readable fashion for a vFabric tc Server component in which the events file
is in its default RHEL location, run the following (Linux):

46 Monitoring vFabric License Usage

Monitoring vFabric License Usage 47

prompt$ cd /opt/vfabric/utils/vfabric-vfchksn-1.2.0.6
prompt$ ./vfabric-licensetool printevents -f /var/opt/vmware/vfabric-tc-server-standard/myserver/logs/vf.tc-events.txt

In the preceding example, it is implied that you unzipped the ZIP file into the /opt/vfabric/utils directory.

You should see output similar to the following:

2012-10-02T20:28:01 [INFO] The license client's event manager has started.
2012-10-02T20:28:03 [INFO] A local license has been activated with serial number = AB123-AB123-AB123-AB123-AB123, total available = 60,
expiration type = floating-eval, expiration date = unset, allowed components = oss.rmq-2+vf.ins-2+vf.ws-5+vf.tc-3+vf.sf-1+vf.hyp-4+vf.hyp-5+vf.emj-2+
vf.vpg-9.1+vf.rmq-3+vf.emj-1+oss.ws-2+vf.ws-6+oss.tc-7+vf.gf.acn-6+vf.ins-1+vf.tc-2+vf.gf.acn-7+oss.tc-6+vf.rmq-2.
2012-10-02T20:28:04 [INFO] Calculated new state for license with total available units = 60, license type = default, expiration date = permanent,
enforcement = soft, addons = <empty>. It now has a total used count of 0.
2012-10-02T20:28:05 [INFO] Component Instance "self" changed state to "on" at 2012-10-02T20:28:04.
2012-10-02T21:28:05 [INFO] Calculated new state for license with total available units = 60, license type = default, expiration date = 2012-12-01T20:28:05,
enforcement = soft, addons = <empty>. It now has a total used count of 1.
2012-10-02T22:28:06 [INFO] Calculated new state for license with total available units = 60, license type = default, expiration date = 2012-12-01T20:28:05,
enforcement = soft, addons = <empty>. It now has a total used count of 1.
2012-10-02T23:28:06 [INFO] Calculated new state for license with total available units = 60, license type = default, expiration date = 2012-12-01T20:28:05,
enforcement = soft, addons = <empty>. It now has a total used count of 1.
2012-10-03T00:28:07 [INFO] Calculated new state for license with total available units = 60, license type = default, expiration date = 2012-12-01T20:28:05,
enforcement = soft, addons = <empty>. It now has a total used count of 1.
...

You can also specify the -o output-file option to print the results to a file called output-file rather than to the
standard output. For example, to write the output to a file called events-out.txt:

prompt$ ./vfabric-licensetool printevents -f /var/opt/vmware/vfabric-tc-server-standard/myserver/logs/vf.tc-events.txt -o events-out.txt

vCenter License Reporting Manager

The vCenter License Reporting Manager displays the capacity of your vFabric Suite license, although it does not keep track
of the number of licenses currently assigned. To get the usage summary (both current and periodic) from the vFabric License
Server, you run Windows commands or use a simple Web user interface.

For details about how to monitor vFabric license usage, see the preceding sections in this chapter, Monitoring vFabric License

Usage.

47

48 vFabric Suite

48 Monitoring vFabric License Usage

FAQ: vFabric Suite Integration and
Off-Cycle Releases

7. FAQ: vFabric Suite Integration and Off-Cycle Releases

VMware certifies the products listed in the vFabric Suite 5.3 Component table as an integrated suite of components. This
certification ensures seamless integration when you use components together in development or production deployment
environments.

In addition to the specific component versions listed in the component table, all Maintenance releases within each component
Minor release line are fully integration tested and supported with vFabric Suite.

Because vFabric Suite components are loosely coupled, component products may release independently of a vFabric Suite
release in order to meet their distinct customer needs in a timely manner. Thus a particular component occasionally requires an
off-cycle Major or Minor standalone release. A vFabric Suite license includes full production support for an off-cycle release of a
component only when that component becomes formally included in a Generally Available (GA) vFabric Suite release.

Can I get early access to off-cycle component releases?

Yes, customers can get early access to licensed releases for development and evaluation use only.

How do I get access?

The easiest way for you to access an off-cycle release is to download and install an evaluation version from http://
www.vmware.com/products/. Evaluation downloads provide a 60-day evaluation cycle, which in many cases is sufficient time
for the next official version of vFabric Suite to be released.

49

What if I need a non-evaluation license?

Your existing vFabric Suite license covers your non-evaluation use. However, in some cases a component product may
implement runtime constraints that are recognized by the installed license key and that may require an updated license key in
order to run correctly in non-evaluation mode. VMware will publish a Knowledge Base (KB) article for each off-cycle release
that tells you whether an updated license key is required, and if so, tells you how to obtain and install it. Search the KB archive
using your product name and off-cycle as keywords.

What support am I as a vFabric Suite customer entitled to for off-cycle releases?

Support is provided to you equivalent to development use. VMware makes every attempt to work with you and resolve any issues
with an off-cycle product release. However, VMware does not identify any issues as production-critical because this particular
support is for development use only. Because only development-level support is offered for the off-cycle product, customers are
encouraged to use the latest available vFabric Suite release components when working with the off-cycle version.

As previously mentioned, a vFabric Suite license includes full production support for an off-cycle release of a component only
when that component becomes formally included in a Generally Available (GA) vFabric Suite release.

Why doesn't VMware offer vFabric Suite production support for off-cycle releases?

VMware does significant integration testing for each vFabric Suite release. Certifying a specific combination of component
product versions on a twice-yearly basis gives customers a predictable and consumable release schedule. This schedule allows
customers to deploy applications with the confidence that production support is available and consistent on that combination of
products over an extended period. Because VMware does not perform full integration testing of all vFabric Suite components
with each off-cycle release of a particular vFabric Suite component, we are not prepared to offer production support for the use of
an off-cycle release with vFabric Suite as an integrated suite of component technologies.

As previously mentioned, a vFabric Suite license includes full production support for an off-cycle release of a component only
when that component becomes formally included in a Generally Available (GA) vFabric Suite release.

Can I still get production support for the standalone product?

Yes. All off-cycle releases are certified for production use in the context of their use as a standalone product. Note that full
production support for an off-cycle release generally requires a license for the standalone product that is separate from a vFabric
Suite license.

49

50 vFabric Suite

Can I mix and match component versions between vFabric Suite versions?

If you are using two components in an integrated fashion and depending on them to work together seamlessly, you need to use
component versions from the same vFabric Suite version to ensure component compatibility. However, if your use requires no
integration between the components, you can mix and match to suit the upgrade and deployment needs of your application.

50

FAQ: vFabric Suite Integration and

Off-Cycle Releases
