Video Mount Products Mounting Solutions For Video,Audio, & Security... Nothing Holds Up Better!
LCD-2537CB
Mid-Size Flat Panel Ceiling Mount
Product Features:
Holds 25” – 37” at panel
Mast telescopes from 18” – 30”
Accommodates panel with 75, 100, 200 and
100 x 200 mm VESA hole patterns
Adjustable -5º to +20º tilt
Rotates 360º (ceiling) / Rotates 240º (panel)
Clip based cable management system
Load capacity 75 lbs
Black powder coat nish
Available in silver powder coat nish (LCD-2537C)
Product Speci cations:
(for Architects & Engineers)
The ceiling mount for the at panel shall be the Video
Mount Products (VMP) model LCD-2537C. The mount shall be
constructed primarily of tubular steel and shall incorporate
nylon lled nuts and arc welds. The mount shall be a universal
style mount capable of mounting to all 25” - 37” at panels
that incorporate VESA 75, 100, 100x200, or 200 standard hole
patterns and not necessarily model be speci c. The mount
shall include one plate with VESA 75mm and 100mm and
another plate with VESA 100x200mm and 200mm hole
patterns. The mount shall include a cable management
system. The mount shall include a telescoping mast that
adjusts from 18” to 30” from the ceiling. The mount must
allow for adjustable tilt from -5° to 30°and must swivel 360°.
The load capacity shall be 75 lbs.
Video Mount Products
345 Log Canoe Circle
Stevensville, MD 21666
Toll Free: 877.281.2169
Telephone: 410.643.6390
Facsimile: 410.643.6615
www.videomount.com
