VAS35P / VAS36P
SHAKER LOUDSPEAKER SYSTEMS
Thank you for your interest in VM Audio products. Our goal
is to enhance your listening experience. The Shaker Series
was designed as the economical solution for a performance
craving, casual consumer. The experts and engineers at VM
Audio have meticulously tested and designed this product with
a reasonable price tag to t any budget. Let the Shaker Series
maximize the value of your investment.
Table of Contents
SYSTEM FEATURES
PACKAGE CONTENTS
FEATURES OVERVIEW
GETTING STARTED
INSTALLATION
TIPS
LOUDSPEAKER CONFIGURATIONS
TROUBLESHOOTING
SPECIFICATIONS
LIMITED WARRANTY AGREEMENT
3
5
5
7
8
10
11
12
13
14
VAS35P VAS36P
System Features
• 2-Way Passive Loudspeaker System
• High Output Compact DJ System Design
• Wide Angle High Frequency 1” Horn Tweeter
• High Output Ribbed Cone Woofer
• 0.75” High Temp Multi-Layer Copper Voice Coil
• Low Noise CAD Tuned Bass Reex Enclosure
• Computer Engineered HDF Acoustic Enclosure
• Heavy Duty Aviation Grade Enclousure Carpet Cover
• Sturdy ABS Heavy Duty Cabinet Handle
• Impact Resisting Black ABS Corner Guards
• Strong Rubber Edge Black Steel Woofer Grilles
• Tough Spring Loaded Speaker Wire Terminals
2 3
CAUTION
1. Please read these intructions carefully before attempting
to install and operate this unit.
2. Please read all instructions as indicated in the User Guide.
3. Keep this User Guide for future reference.
4. Save all packaging in the event the unit needs to be
returned for service or replacement.
5. Heed all warnings, unit can be hazardous if not used
properly or as directed.
6. Ensure to setup your system in a safe and secure manner.
7. Do not expose the unit to rain, moisture, dripping,
splashing or use near water.
8. Do not place objects lled with liquids on the unit.
9. Do not place or install unit near heat sources such as
radiators, heat registers, stoves, ampliers or other
apparatus that produce heat.
10. Protect the speaker wires from being walked on or getting
pinched.
11. Use only hardware such as tripods, brackets,
attachments, and other accessories components specied
by VM Audio.
12. Before placing, installing or suspending this loudspeaker
product, inspect all hardware, brackets, surfaces,
cabinets and associated equipment for damage. If a fault
is discovered, it should be corrected immediately.
13. Do not attempt to service this unit, refer all servicing to
qualied service personnel.
Safety Precautions
Package Contents
Your Shaker DJ Loudspeaker was carefully packaged to
ensure a safe and secure transport to its destination. Please
review the contents of the package and make sure you have
received all the items included with your loudspeaker.
VASP35P, VAS36P
(2) Loudspeakers
(1) User Guide
Features Overview
The Shaker DJ Series are easy to operate loudspeaker
systems, designed for both professional and consumer DJ
use. Please take a few moments to read this user guide and
familiarize yourself with the loudspeaker features.
VAS35P, VAS36P
Tweeter
Woofer
Speaker
Terminal
Ports
Front
Rear
4 5
Features Overview
Getting Started
Input Terminal
Negative
Terminal
Positive
Terminal
Input Terminal - Spring-Loaded connector accepts bare
wires only.Push each tab to open and insert wire.
Loudspeaker Placement
The Shaker DJ Series Loudspeakers were designed to sit
on a solid at surface.
• Follow the user guide installation procedures to install your
Shaker DJ Loudspeakers into your own sound system.
• Place the loudspeaker cabinet on a solid level surface
where it cannot be toppled or tilted.
• Elevate the loudspeaker at or above head level. This
is to prevent the high frequencies from being blocked
and getting mufed by obstacles directly in front of the
tweeters.
• Avoid placing full-range loudspeakers in a corner or right
next to a wall to avoid degrading the overall sound quality.
• If loudspeakers are to be placed in locations where large
amounts of reverberations or echoes are produced, such
as gymnasiums and auditoriums, laying carpet or rugs will
help dampen the reections and improve the overall sound
quality of the system.
CAUTION!
• Before installing this loudspeaker product, inspect all
hardware, brackets, surfaces, cabinets and associated
equipment for damage. If a fault is discovered, it should be
corrected immediately.
• Never connect multiple amplier outputs to the input
terminals at the same time. This may cause a short and may
damage your equipment or cause a re.
• This loudspeaker can easily reproduce sound pressure levels
(SPL) loud enough to cause permanent ear damage that
could result in hearing loss. Take great precaution to protect
yourself from prolonged exposure to high output sound
pressure levels.
6 7
Installation
Installation
Step 1
Carefully run both CH 1 and CH 2 speaker wires from the
amplier up to the location of the loudspeakers.
WARNING!
To prevent electrical shock hazard, always switch off the
amplier when making connections to the speaker.
Step 2
Strip off 1/2 inch of insulation from the ends of each
speaker wire to expose the two conductors, and tightly
twist the wire strands.
Step 3
Push terminal tabs to expose wire holes and insert the
positive (+) and negative (-) wires through their respective
terminals and release button to secure wires.
Stereo Loudspeaker
Installation
8 9
Loudspeaker Congurations Tips
Speaker Power Requirements
The following guidelines will assist you in selecting the
appropriate amplier for your loudspeaker(s) to maintain a
safe level of operation.
• For clear, high quality performances where distortion
should be at its minimum, the loudspeaker(s) should be
powered with an amplier capable of delivering twice its
power rating. (ex. Classical, Jazz, Instrumental, etc)
• For non-distorted high output performances where the
music is at a constant beat, the loudspeaker(s) should be
powered with an amplier with the same power rating.
• For musical performances where distorted material will
be allowed to be played back, an amplier with half the
power rating is recommended for safe operation.
Speaker Wires
When running long lengths of speaker wires, it is
recommended that higher gauge wire (12 Ga or higher) is
always used. Using speaker wires lower than 12 Ga limits
the amplier from delivering full power to the loudspeaker(s),
which may result in poor sound performance.
Equipment Protection
• Always optimize the signal levels throughout the system
to avoid overdriving your system and the loudspeaker(s).
Stereo Operation
CH 2CH 1
Left Right
Stereo with Subwoofer Operation
CH 1 CH 2
Brigde Mono
Operation
• When possible, use a low pass electronic crossover to
protect the loudspeakers from low frequency notes and
protect the system.
• Keep in mind the electrical limitations of your system.
• Always avoid feedback.
Left Right
10 11
Table of Contents
Troubleshooting
Table of Contents
Specications
No audio when loudspeaker is connected
• Make sure the mute is off.
• Ensure volume and all gain controls in your system are
turned up.
• Check if speaker wire connections have been interrupted
and make sure they have a solid connection to the speaker
terminals on the amplier and enclosure.
• Check if all line level cables are carrying a signal.
• Make sure all relevant channels are turned on.
Audio output only on one channel
• Make sure sure all relevant channels are turned on.
• Check that the mixer console and amplier are working
properly and do not have a muted channel.
• Check speaker wire connections to the silent channel and to
the corresponding speaker and make sure thay are solid.
Distorted output
• Make sure that all signal gains have been adjusted correctly
on the mixing console.
• Check if all signal levels on the signal processor(s) have been
set to the correct levels.
• Ensure input signal to the amplier is not higher than the
maximum allowed input level.
• Make sure that the amplier outputs are not “clipping”.
• Check cable and speaker wire connections and make sure
that they are not electrically shorting out.
Treble output too low
• Check that the treble level on the mixer is turned up.
• Position the cabinet with the tweeter at ear level.
• Tweeter protection feature may be on, check the tweeter
for output.
Bass output too low
• Speakers wires may not be connected properly. Ensure that
the positive (+) and negative (-) speaker wires are connected
to the positive (+) and negative (-) terminals on the amplier
and on the speaker terminal on the enclosure.
VAS35P
Loudspeaker Type
High Frequency Drivers
Low Frequency Driver
Frequency Response
Total Power (RMS)
Total Power (Peak)
Impedance
Sensitivity
Enclosure Construction
Enclosure Finish
Input Connectors
Net Weight
Dimensions (W x H x D)
VAS36P
Loudspeaker Type
High Frequency Drivers
Low Frequency Driver
Frequency Response
Total Power (RMS)
Total Power (Peak)
Impedance
Sensitivity
Enclosure Construction
Enclosure Finish
Input Connectors
Net Weight
Dimensions (W x H x D)
2-way Full-Range Loudspeaker
2.75” x 5.75” Horn Piezo Tweeter
5.25” High Output Woofer
70 Hz - 20 kHz
200 Watts
400 Watts
8 Ohms
89 dB
Heavy Duty HDF Wood
Aviation Grade Carpet Cover
Spring-Loaded Push Tab
5.6 Lbs / 2.54 kg (each)
7.28” x 13.58” x 5.51” (each)
2-way Full-Range Loudspeaker
2.75” x 5.75” Horn Piezo Tweeter
6.5” High Output Woofer
60 Hz - 20 kHz
300 Watts
600 Watts
8 Ohms
90 dB
Heavy Duty HDF Wood
Aviation Grade Carpet Cover
Spring-Loaded Push Tab
6.9 Lbs / 3.13 kg (each)
8.66” x 15.75” x 5.51” (each)
12 13
Table of Contents
Limited Warranty Agreement
Limited Warranty Agreement
Your product is covered by a limited warranty by VM Audio as
established below:
Electronics Limited Warranty
Products purchased from an Authorized VM Audio Dealer are
warranted to be free of defects in material and workmanship
for one (1) year from the date of original purchase under
normal usage. Products that are identied as “refurbished”
have a limited warranty of ninety (90) days from the date of
original purchase. Dated proof of purchase (original receipt
or invoice) will be required for all warranty claims. In the
unlikely event that you experienced a manufacturing defect or
malfunction during the warranty period, VM Audio will repair
the defective product or replace with the same or equivalent
product if the same item is not available or discontinued.
Replacement product may have supercial blemishes or
scratches that do not affect the performance of the product.
This warranty is only intended and valid for the original
purchaser and cannot be extended to subsequent owners. Any
applicable implied warranties are limited to the period of the
expressed warranty starting from the original purchase date.
No warranties, expressed or implied, will be accepted after the
previously listed periods. Exclusions may apply; please check
your local state laws.
Instructions for Claiming Warranty Service
If you should require warranty service, please return the
product to the Authorized VM Audio Dealer you originally
purchased the item for an experienced and speedy claim of
your warranty service. Contact VM Audio directly to nd the
Authorized Dealers nearest you.
In the case the defective merchandise needs to be returned
to VM Audio, please contact us and a Return Merchandise
Authorization (RMA) number will be assigned. It is important
to pack all defective items in the original packaging to prevent
damages from shipping, and be sure to write the RMA number
clearly on the outside of the box for faster processing. Do
not include non-defective items as it is not necessary and will
increase your shipping costs.
Include a copy of the original receipt or invoice with the
purchase date, dealer’s name, customer’s name and invoice
number clearly visible. Manufacturing date may be used if no
proof of purchase is provided. The customer will pay to ship the
defective product; COD will not be accepted.
Please follow the above instructions carefully to prevent voiding
your warranty.
Your Warranty Service Does Not Cover the Following:
- Products not purchased from an Authorized VM Audio
Dealer
- Damages from poor installation by not following the included
instruction manual.
- Damages due to excessive moisture, heat and other
elements from improper care.
- Evidence of tampering or repair by non-authorized personnel.
- Products not issued an RMA number.
- Damage during freight from poor packaging or handling.
- Return shipping on non-defective items.
Warranty Turnaround Time
It is VM Audio’s goal to turnaround the merchandise in a timely
fashion of 1 week. Unexpected delays may occur due to repair
parts or replacement shortage.
International Warranty
Please check with your Authorized International VM Audio
Dealer or distributor for specic warranty policies and process
for your country.
14 15
Loading...
