Vizio P602ui-B3, P702ui-B3 User Manual

VIZIO

USER MANUAL

Models: P602ui-B3 & P702ui-B3

Safety & Certification



THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO HDTV.

To get the most out of your new VIZIO product, read these
instructions before using your product and retain them for future
reference. Be sure to inspect the package contents to ensure
there are no missing or damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services
for your VIZIO product, visit our website at www.VIZIO.com or call
toll free at [phone].

We recommend that you either:

• Register your VIZIO product at www.VIZIO.com

• Complete and mail the enclosed registration card

Extended Warranties

For peace of mind, and to protect your investment beyond the
standard warranty, VIZIO offers on-site extended warranty service
plans. These plans provide additional coverage during the
standard warranty period. To purchase an extended warranty
service plan, visit www.VIZIO.com.

WHEN READING THIS MANUAL

When you see this symbol, please read the
accompanying important warning or notice. It is
intended to alert you to the presence of important
operating instructions.

When you see this symbol, please read the
accompanying helpful tip.

IMPORTANT SAFETY INSTRUCTIONS

Your TV is designed and manufactured to operate within defined
design limits. Misuse may result in electric shock or fire. To prevent
your TV from being damaged, the following instructions should
be observed for the installation, use, and maintenance of your
TV. Read the following safety instructions before operating your
TV. Keep these instructions in a safe place for future reference.

• To reduce the risk of electric shock or component
damage, switch off the power before connecting other
components to your TV.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

• Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.

• Only use attachments/accessories specified by the
manufacturer.

• Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when
unused for long periods of time.

• Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in
any way, such as when the power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally or has been
dropped.

• Unplug the power cord before cleaning your TV.

• When moving your TV from an area of low temperature
to an area of high temperature, condensation may form
in the housing. Wait before turning on your TV to avoid
causing fire, electric shock, or component damage.

• A distance of at least three feet should be maintained
between your TV and any heat source, such as a radiator,
heater, oven, amplifier etc. Do not install your TV close to
smoke. Operating your TV close to smoke or moisture may
cause fire or electric shock.

• Slots and openings in the back and bottom of the
cabinet are provided for ventilation. To ensure reliable
operation of your TV and to protect it from overheating,
be sure these openings are not blocked or covered. Do
not place your TV in a bookcase or cabinet unless proper
ventilation is provided.

• Never push any object into the slots and openings on
your TV cabinet. Do not place any objects on the top of
your TV. Doing so could short circuit parts causing a fire
or electric shock. Never spill liquids on your TV.

• Your TV should be operated only from the type of power
source indicated on the label. If you are not sure of the
type of power supplied to your home, consult your dealer
or local power company.

ii

• Do not apply pressure or throw objects at your TV.
This may compromise the integrity of the display. The
manufacturer’s warranty does not cover user abuse or
improper installations.

• The power cord must be replaced when using different
voltage than the voltage specified. For more information,
contact your dealer.

• When connected to a power outlet, power is always
flowing into your TV. To totally disconnect power, unplug
the power cord.

• The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of un-isolated, dangerous voltage within the
inside of your TV that may be of sufficient magnitude to
constitute a risk of electric shock to persons.

• Do not overload power strips and extension cords.
Overloading can result in fire or electric shock.

• The wall socket should be installed near your TV and
easily accessible.

• Only power of the marked voltage can be used for your
TV. Any other voltage than the specified voltage may
cause fire or electric shock.

• Do not touch the power cord during lightning. To avoid
electric shock, avoid handling the power cord during
electrical storms.

• Unplug your TV during a lightning storm or when it will not
be used for long period of time. This will protect your TV
from damage due to power surges.

• Do not attempt to repair or service your TV yourself.
Opening or removing the back cover may expose you to
high voltages, electric shock, and other hazards. If repair
is required, contact your dealer and refer all servicing to
qualified service personnel.

• WARNING: Keep your TV away from moisture. Do not expose
your TV to rain or moisture. If water penetrates into your TV,
unplug the power cord and contact your dealer. Continuous
use in this case may result in fire or electric shock.

• Do not use your TV if any abnormality occurs. If any
smoke or odor becomes apparent, unplug the power
cord and contact your dealer immediately. Do not try to
repair your TV yourself.

• Avoid using dropped or damaged appliances. If your
TV is dropped and the housing is damaged, the internal
components may function abnormally. Unplug the power
cord immediately and contact your dealer for repair.
Continued use of your TV may cause fire or electric
shock.

• Do not install your TV in an area with heavy dust or high
humidity. Operating your TV in environments with heavy
dust or high humidity may cause fire or electric shock.

• Follow instructions for moving your TV. Ensure that the
power cord and any other cables are unplugged before
moving your TV.

• When unplugging your TV, hold the AC/DC power
adapter, not the cord. Pulling on the power cord may
damage the wires inside the cord and cause fire or
electric shock. When your TV will not be used for an
extended period of time, unplug the power cord.

• To reduce risk of electric shock, do not touch the
connector with wet hands.

• Insert batteries in accordance with instructions. Incorrect
polarities may cause the batteries to leak which can
damage the remote control or injure the operator. Do not
expose batteries to excessive heat such as sunshine, fire
or the like.

• If any of the following occurs, contact the dealer:

- The power cord fails or frays.

- Liquid sprays or any object drops into your TV.

- Your TV is exposed to rain or other moisture.

- Your TV is dropped or damaged in any way.

- The performance of your TV changes substantially.

• This apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.

• The mains plug or appliance coupler is used as the
disconnect device, the disconnect device shall remain
readily operable.

• CAUTION - These servicing instructions are for use by
qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than
that contained in the operating instructions unless you
are qualified to do so.

• The lightning flash with arrowhead symbol within an

h

equilateral triangle is intended to alert the user to the
presence of uninsulated DANGEROUS VOLTAGE within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electrical shock to persons.

iii

TELEVISION ANTENNA CONNECTION
PROTECTION

If an outside antenna/satellite dish or cable system is to be
connected to the TV, make sure that the antenna or cable system
is electrically grounded to provide some protection against
voltage surges and static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70,
provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of the grounding conductors,
location of antenna discharge unit, connection to grounding
electrodes, and requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during a lightning storm or when
it is left unattended or unused for long periods of time, unplug
the TV from the wall outlet and disconnect the antenna or cable
system.

Power Lines

Do not locate the antenna near overhead light or power circuits,
or where it could fall into such power lines or circuits. Remember,
the screen of the coaxial cable is intended to be connected to
earth in the building installation.

Ground Clamp

Antenna Lead In Wire

Antenna Discharge Unit
(NEC Section 810-20)

Grounding Conductors
(NEC Section 810-21)

Ground Clamps

Electric Service Equipment

Power Service Grounding Electrode System

(NEC ART 250, part H)

iv

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing
Limited. DTS, the Symbol, & DTS and the Symbol together
are registered trademarks, and DTS Studio Sound is a

trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.

Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of

Dolby Laboratories.

HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of

HDMI Licensing LLC.

v

Table Of Contents

Table Of Contents

Getting to Know Your TV ......................................... 7

Inspecting the Package Contents .............................................. 7

Installing the TV ........................................................................... 8

Installing the TV Stand .............................................................. 8

Installing the TV on a Wall ........................................................ 9

Front Panel ................................................................................... 10

Rear Panel ................................................................................... 11

Remote Control Front .................................................................. 12

Replacing the Batteries ............................................................ 13

Connecting Your Devices ....................................... 14

Connecting A Device .................................................................. 14

Connecting A Device - Audio & Video Cable Types ................... 15

Connecting an Audio Device ..................................................... 16

Connecting An Audio Device - Audio Cable Types .................... 17

Connecting an Audio Device - Arc ............................................. 18

Connecting to Your Network ....................................................... 19

Connecting to a Wired Network (Best) .................................... 19

Connecting to a Wireless Network ........................................... 19

Completing The First-Time Setup ............................ 20

Using the On-Screen Menu .................................... 23

Navigating the On-Screen Menu ................................................ 23

Changing the Input Source ........................................................ 23

Changing the Screen Aspect Ratio ............................................ 24

Viewing Video with the Menu Open ........................................... 24

Adjusting the Picture Settings ..................................................... 25

Adjusting the Advanced Picture Settings* .............................. 26

Adjusting the Picture Mode Management Settings* .............. 26

Adjusting the Color Tuner Settings ........................................... 27

Renaming a Custom Picture Mode ......................................... 29

Locking/Unlocking a Custom Picture Mode ............................ 29

Deleting a Custom Picture Mode ............................................. 30

Resetting Picture Mode ............................................................ 30

Adjusting the Audio Settings ....................................................... 31

Changing the Equalizer Settings ............................................. 31

Deleting the Custom Audio Mode ........................................... 32

Setting Timers .............................................................................. 33

Setting the Sleep Timer ............................................................. 33

Setting the Auto Power Off Feature .......................................... 33

Enabling the Screen Saver ....................................................... 33

Blank Screen Feature ............................................................... 33

Using the Network Connection Menu ......................................... 34

Connecting to a Wireless Network ........................................... 34

Changing the Manual Setup Settings ..................................... 34

Finding MAC Addresses for Network Setup .............................. 34

Connecting to a Hidden Network ............................................ 35

Setting Up the Tuner .................................................................... 36

Selecting a Tuner Input ............................................................ 36

Scanning for Channels ............................................................ 36

Adding New Channels ............................................................. 36

Skipping Channels ................................................................... 37

Listening to Alternate Audio ........................................................ 38

Changing the Analog Audio Language .................................. 38

Changing the Digital Audio Language ................................... 38

Setting Up Closed Captioning .................................................... 39

Changing the Appearance of Digital Closed Captions ......... 39

Renaming Devices on the Input Menu ....................................... 41

Changing the TV Settings ........................................................... 42

Viewing System Information ..................................................... 42

Changing the On-Screen Menu Language ............................ 42

Setting the Time and Local Settings ......................................... 43

Using the Parental Controls ...................................................... 43

Accessing the Parental Controls Menu ................................... 43

Enabling or Disabling Program Ratings ................................... 43

Locking and Unlocking Channels ............................................ 43

Blocking and Unblocking Content by Rating .......................... 44

Changing the Parental Control PIN ......................................... 44

Resetting the Content Locks .................................................... 44

Changing the View Mode Settings .......................................... 45

Adjusting the Wide Mode (Aspect Ratio) ................................ 45

Changing your TV Name ......................................................... 45

Adjusting the CEC Settings ...................................................... 46

Turning the Power Indicator On or Off ..................................... 46

Using the Reset & Admin Menu .................................................. 47

Restoring the TV to Factory Default Settings ............................ 47

Using the Guided Setup Menu ................................................ 48

Using Guided Setup ................................................................. 48

Using the Info Window ................................................................. 48

Using the USB Media Player ................................... 49

Using the USB Media Player ........................................................ 49

Preparing Your USB Drive to Play USB Media ............................ 49

Playing USB Media .................................................................... 49

Removing the USB Drive from the TV ........................................ 49

Using VIZIO Internet Apps Plus® (V.I.A. Plus) ........... 53

Using the fullscreen V.I.A. Apps Window ...................................... 54

Fullscreen V.I.A. Plus Apps Window Overview .............................. 55

Customizing the V.I.A. Plus Apps Window .................................... 56

Adding an App to the My Apps Tab ........................................ 56

Deleting an App from the My Apps Tab ................................... 56

Moving an App in My Apps...................................................... 56

Viewing Ultra HD Content ....................................... 58

What is Ultra HD? ......................................................................... 58

What You Need to View Ultra HD Content ................................... 58

What is HDMI 2.0 and HDCP 2.2? ................................................ 58

Troubleshooting & Technical Support .................... 59

Specifications ......................................................... 63

Warranty ................................................................. 65

Legal & Compliance .............................................. 66

vi

Getting to Know Your TV

INSPECTING THE PACKAGE CONTENTS

Before installing your new TV, take a moment to inspect the
package contents. Use the images below to ensure nothing is
missing or damaged.

INPUT

LIST

EXIT

VOL

1 2 3

4 5 6

7 809

ENTER

1

MENU

INFO

GUIDEBACK

CH

3D

Power CordVIZIO LED HDTV with Stand Two-Sided Remote with Keyboard

Quick Start Guide 4 x M5 20mm

Phillips Screws

(Batteries Included)

4 x M5 23mm

Phillips Screws

PACKAGE CONTENTS

7

1

INSTALLING THE TV

After removing the TV from the box and inspecting the package
contents you can begin installing the TV. Your TV can be installed
in two ways:

• On a flat surface, using the included stand

• On a wall, using a VESA-standard wall mount (not
included)

Installing the TV Stand

Your TV includes a stand designed to support the weight of the
TV and keep it from falling over. However, the TV can still fall over if:

• It is placed on an uneven, unstable, or non-level surface

• It is pushed, pulled, or otherwise improperly moved

• If an earthquake occurs and the TV is not properly
secured

It is recommended that two people take part in the
base installation.

To install the base:

Place the TV screen-down on a clean, flat surface. To prevent
scratches or damage to the screen, place the TV on a soft
surface, such as carpet, rug, or blanket.

1. Align the neck piece with the bottom of the TV and slide it
into place.

Insert and tighten four (4) M5 20mm Phillips screws into the
back of the TV as shown.

2. Align the base with the neck.

Insert and tighten four (4) M5 23mm Phillips screws into the
bottom of the base as shown.

3. When you are finished, place the TV on a stable,
level surface.

8

Installing the TV on a Wall

To mount your TV on a wall, you will need a wall mount. Consult
the information below to find the appropriate mount for your TV
model:

Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.

P602ui-B3 P702ui-B3

Screw Size: M6 M6

Hole Pattern:

Weight w/o Stand: 48.72 lbs 60.56 lbs

400mm (V) x

400mm (H)

400mm (V) x

400mm (H)

1

Be sure the mount you choose is capable of supporting the
weight of the TV. After you have determined that you have the
correct mount for your TV, you can begin the installation.

To install your TV on a wall:

1. Disconnect any cables connected to your TV.

2. Place the TV face-down on a clean, flat, stable surface.
Be sure the surface is clear of debris that can scratch or
damage the TV.

3. Remove the base and neck by loosening and removing
the screws.

4. Attach your TV and wall mount to the wall, carefully following
the instructions that came with your mount.

Use only with a UL-listed wall mount bracket rated for the
weight/load of this TV.

For some wall mounts, you may want to use cables
with right-angle connectors. This allows the TV to rest
closer to the wall.

WALL-MOUNT SCREW LOCATIONS

9

1

REMOTE SENSOR & POWER INDICATOR
When using the remote, aim it directly at this sensor.

The power indicator flashes on when the TV turns on, then goes out after several seconds.
To keep the power indicator on as long as the TV is on, see

Turning the Power Indicator On or Off on page 46.

FRONT PANEL

10

USB - Connect USB thumb drive to play photo, music, or video.

HDMI - Connect HDMI device.

1

Component/Composite - Connect component or composite device.

Stereo Audio Out - Connect RCA audio device, such as sound bar.

Optical Audio Out - Connect optical/SPDIF audio device, such as

home audio receiver.

HDMI - Connect HDMI device.

Coaxial - Connect coaxial cable from cable, satellite, or antenna.

Ethernet - Connect Ethernet cable from home network.

Power/Input - Press once to turn on the TV. Press once to access the

input menu. Press and hold to turn off the TV.

REAR PANEL

11

APP LAUNCHER

Quickly launch the pictured App.

1

INPUT

Change the currently

displayed input.

A/V CONTROLS

Control USB media player and

video streaming playback.

CLOSED CAPTIONS

Turn closed captions on and off.

EXIT

Close the on-screen menu.

OK

Select the highlighted option.

BACK

Go to the previous on-screen menu.

VOLUME UP/DOWN

Increase or decrease loudness

of the audio.

MUTE

Turn the audio off or on.

WIDE

Change the display mode.

NUMBER PAD

Manually enter a channel.

ENTER

Confirm channel or passcode

entered using the Number Pad.

POWER
Turn TV on or off.

MENU

Display the on-screen menu.

INFO
Display the info window.

ARROW
Navigate the on-screen menu.

GUIDE

Display the info window.

CHANNEL UP/DOWN

Change the channel.

V BUTTON
Open the VIZIO Internet Apps
Plus® (V.I.A. Plus) dock.

LAST
Return to the channel last
viewed.

PIC

Opens the Picture Mode menu.

DASH

Use with number pad to
manually enter a digital
sub-channel.
(For example, 18-4 or 18-5.)

SHIFT

Press and hold while

pressing another key to

enter a capital letter.

DO NOT COVER THIS AREA

This is the transmitter.

ALT

Press and hold while pressing
another key to enter a blue
character. For example, press ALT
and W to enter a # character.

ARROWS

Navigate the

on-screen menu.

REMOTE CONTROL

12

Replacing the Batteries

1. Press in on the button on the rear of the remote. 3. Insert two AAA batteries into the remote control. Make sure

1

that the (+) and (-) symbols on the batteries match the (+)
and (-) symbols inside the battery compartment.

4. Replace the battery cover.2. Remove the battery cover.

13

CONNECTING A DEVICE

Your TV can be used to display output from most devices.

1. Verify that your device has a video port that matches an
available port on the TV (HDMI, Component, etc.).

2. Turn the TV and your device off.

3. Connect the appropriate cable (not included) to the TV and
the device.

4. Turn the TV and your device on. Set the TV’s input to match
the connection you used (HDMI-1, HDMI-2, etc.).

2Connecting Your Devices

1

Maximum Resolution

2

HDCP 2.2 supported on HDMI ports 1,2, and 5

* Recommended for use with high-performance devices only

†

Latest technology to ensure compatibility with future UHD sources

‡

Available for compatible gaming systems or high-performance PCs for display of 1080p @ 120 fps

AV CABLE

GOOD

COMPONENT CABLE

BETTER

COAXIAL CABLE

BETTER

HDMI CABLE (HDMI 1-4)

BEST

HDMI CABLE (HDMI 5*)

BEST

• ANALOG

• SD VIDEO (480i)1

• STEREO AUDIO

• ANALOG

• HD VIDEO (1080p)1

• STEREO AUDIO

• ANALOG/DIGITAL

• HD VIDEO (1080i)1

• STEREO/HD AUDIO

2

• DIGITAL

• ULTRA HD VIDEO (4K @ 30 Hz)1

• HD AUDIO

• DIGITAL

• ULTRA HD VIDEO (4K @ 60 Hz)1

• HD AUDIO

• HIGH VELOCITY MODE

‡

14

CONNECTING A DEVICE - AUDIO & VIDEO CABLE TYPES

COMPONENT VIDEO

2

AV CABLE

AV cables (or Composite cables) are the
traditional way of connecting your devices
to your TV. Video signals are sent over the
yellow connector while audio is sent over
the red and white connectors.

• Video Resolutions up to 480i

• Analog Connection

• Audio and Video Signals

Y L R

COAXIAL CABLE

Coaxial cables are the traditional way of
connecting antennas and cable television
signals to your TV. Coaxial cables carry both
audio and video signals through a single
connector.

• HD Video Resolutions up to 1080i

• Analog Connection

• Audio and Video Signals

Coaxial

COMPONENT CABLE

Component cables are designed to carry high
definition video signals along with additional
audio connections. Colors are delivered with
color information split up three different ways
over three connectors for video (separated into
Red, Blue and Green signals) and the left and
right audio connectors (Red and White).

• HD Video Resolutions up to 1080i

• Analog Connection

• Audio and Video Signals

R L Pr/Cr Pb/Cb Y

HDMI CABLE

HDMI is the intelligent, all-digital interface
that delivers both dazzling quality and
unmatched ease of use. HDMI technology
transmits crystal-clear digital video along with
multi-channel surround audio. HDMI-connected
devices have the ability to automatically adjust
themselves for optimal viewing.

• HD Video Resolutions up to UHD*

• HD Audio

• Digital Connection

• Audio and Video Signals

HDMI

GOOD

* High-Speed HDMI cable required for UHD resolutions

BETTER

BETTER

BEST

15

CONNECTING AN AUDIO DEVICE

Your TV can output sound to an audio device, such as a receiver
or sound bar.

1. Verify that your device has a audio port that matches an
available port on the TV (Optical, RCA, etc).

2. Turn the TV and your audio device off.

2

3. Connect the appropriate cable (not included) to the TV and
the device.

4. Turn the TV and your device on.

Home Audio Receiver VIZIO Sound Bar

RCA CABLE

GOOD

OPTICAL/SPDIF CABLE

BETTER

• ANALOG STEREO CONNECTION

• 2.0 CHANNEL

• PCM STREAM

• DOLBY DIGITAL 5.1 CHANNEL

• DTS 5.1 CHANNEL

HDMI CABLE

BEST

• ARC 2-WAY COMMUNICATION

• 2.0-5.1 DIGITAL AUDIO

• PCM, DTS, DOLY DIGITAL

16

CONNECTING AN AUDIO DEVICE - AUDIO CABLE TYPES

COMPONENT VIDEO

2

RCA CABLE

RCA cables (or Composite cables) are the
traditional way of connecting your devices to
your audio device. Audio signals are sent over
the red and white connectors.

• Quality Stereo Connection

• 2.0 Channel

• Analog Connection

• Audio Signal Only

L R

OPTICAL/SPDIF CABLE

Optical/SPDIF cables transmit audio signals as
pulses of light through a cable made of plastic
fibers. Audio signals are digitally transmitted
between devices.

• PCM Stream (Lossless)

• Dolby Digital 5.1 Channel

• DTS 5.1 Channel

• Digital Connection

• Audio Signal Only

Optical/SPDIF

HDMI CABLE

HDMI technology transmits crystal-clear digital
multi-channel surround audio through a single
HDMI cable. Audio Return Channel-enabled
(ARC) TVs allow audio to be sent over an already
connected HDMI cable, eliminating the need
for a separate audio cable. See

Audio Device - Arc

• CEC 2-way Communication
(Auto setup)

• PCM, DTS, Dolby Digital

• 2.0 - 5.1 Scaleable Lossless
Digital Audio Connection

• Audio and Video Signals

on page 18.

HDMI

Connecting an

GOOD

BETTER

BEST

17

CONNECTING AN AUDIO DEVICE - ARC

2

WITHOUT HDMI ARC

Without an HDMI ARC setup, your TV will transmit audio signal
from the built-in tuner and VIA apps to your home audio
receiver through a separate audio connection.

Your TV

RCA (Audio)

HDMI Cable

WITH HDMI ARC

With an HDMI ARC setup, the audio connection between
your TV and Home Audio Receiver can be removed. The HDMI
cable will transmit audio signal to and from your TV with an
all-digital audio/video connection.

Your TV

HDMI Cable

Your Home Audio Receiver

HDMI Cable

Your Blu-Ray Player

Your Home Audio Receiver

HDMI Cable

Your Blu-Ray Player

18

CONNECTING TO YOUR NETWORK

2

Your TV is Internet-ready. It can be connected to your home
network with a Wired or Wireless connection.

Connecting to a Wired Network (Best)

1. Connect an Ethernet cable to your router and to the
Ethernet port on the back of the TV. See below.

2. Use the Guided Network Setup to configure the TV. See

Guided Setup on page 48

.

Using

Connecting to a Wireless Network

1. Ensure you have a router or modem broadcasting as
high-speed wireless signal (802.11n recommended).

2. Use the Guided Network Setup to configure the TV. See

the Guided Setup Menu on page 48.

Using

Router / ModemEthernet Cable

19

3Completing The First-Time Setup

The first time you turn on the TV, the Setup App will guide
you through each of the steps necessary to get your TV
ready for use.

Before you begin the first-time setup:

• Your TV should be installed and the power cord
should be connected to an electrical outlet.

• Your devices should be connected.

• If you have a wireless network, have the network
password ready.

• If you are connecting to your network with an
Ethernet cable, connect it to the Ethernet port on
the TV.

To complete the first-time setup:

1

Press the Power button on the remote. The TV

powers on and the Setup App starts.

3

Use the Arrow buttons on the remote to highlight

your language of preference and press OK.

2

Select Store Demo for in-store display.

Seleccione "Home Use" por Modo de Casa o "Store Demo" por Demostración de Tienda.

Choisissez "Home Use" pour Mode Domicile ou "Store Demo" pour Démonstration en Magasin.

Use the Arrow buttons on the remote to

highlight Home Use and press OK.

Choose your mode.

Select Home Use for in-home use.

Store Demo Home Use

4

Use the Arrow buttons on the remote to

highlight your country, and then press OK.

20

3

5

Select your time zone and press OK.

6

Select the name of your wireless network from

the list of available networks and press OK.

7

Use the Arrow and OK buttons on the remote to

review the Terms Of Service and Privacy Policy.

When you are finished, highlight I Accept

and press OK.

8

Enter the network password using the keyboard on

the remote, then highlight Connect and press OK.

Enter your E-mail Address, First Name, Last

Name, and Zip Code using the keyboard

on the remote.

Highlight Next and press OK.

21
