Vizio L30 WGUe User Manual

VIZIO L30 WGUe User Guide

Table of Contents

Chapter 1 - Introduction................................................................................................................................2

1.1 - Before Use ......................................................................................................................................... 2

1.2 - Specifications ..................................................................................................................................... 2

1.3 - Opening the Package......................................................................................................................... 3

1.4 - Installation.......................................................................................................................................... 3

1.5 - Important Safety Guidelines............................................................................................................... 4

1.6 - Television Antenna Connection Protection ........................................................................................ 5

1.7 - Package Contents.............................................................................................................................. 6

1.8 - Front Panel Controls .......................................................................................................................... 7

1.9 - Rear Panel Connections .................................................................................................................... 8

1.10 - VIZIO Universal Remote Control...................................................................................................... 9

1.10.1 - Key Remote Control Functions................................................................................................10

1.10.2 - Insertion of Batteries in the Remote Control............................................................................12

1.10.3 - Remote Control Range............................................................................................................12

1.10.4 - Precautions for the VIZIO Universal Remote Control ..............................................................12

Chapter 2 - Connecting Components.........................................................................................................13

2.1 - Which Video Connection Should I Use? ...........................................................................................13

2.2 - Connecting Your DVD Player............................................................................................................14

2.2.1 - Using Digital Video ....................................................................................................................14

2.2.2 - Using Component Video ...........................................................................................................15

2.2.3 - Using S-Video ...........................................................................................................................16

2.2.4 - Using Composite Video.............................................................................................................16

2.3 - Connecting Your HDTV Set-Top Box................................................................................................17

2.3.1 - Using Digital Video ....................................................................................................................17

2.3.2 - Using RGB Video ......................................................................................................................17

2.3.2 - Using RGB Video ........................................................................................................

..............18

2.4 - Connecting Your VCR or Video Camera...........................................................................................18

2.5 - Connecting Coaxial (RF)...................................................................................................................19

2.5.1 - Using Your Antenna or Cable TV ..............................................................................................19

2.5.2 - Using the Antenna through Your VCR.......................................................................................19

2.6 - Connecting External Amplified Speakers ..........................................................................................20

2.7 - Connecting an External Receiver or Amplifier...................................................................................20

2.8 - Connecting a Computer ....................................................................................................................21

Chapter 3 - Getting Started .........................................................................................................................22

3.1 - Turning your LCD TV On and Off......................................................................................................22

3.2 - Watching a TV program ....................................................................................................................22

3.3 - Preparing the LCD for Wall Mounting................................................................................................23

3.4 - Adjusting Basic LCD TV Settings......................................................................................................23

3.5 - Using the On-Screen Display (OSD).................................................................................................24

3.5.1 - Menu Operations.......................................................................................................................24

3.5.2 - OSD Menus and Options ..........................................................................................................25

3.5.3 - Understanding Viewing Features ..............................................................................................28

3.5.4 - Using the Parental Controls ......................................................................................................30

3.5.5 - Setting a Password ...................................................................................................................31

3.5.6 - Setting the Sleep Timer.............................................................................................................31

3.6 - Remote Control Operation ................................................................................................................32

3.6.1 - Programming the VIZIO Universal Remote Control...................................................................32

3.6.2 - Searching for Component Codes ..............................................................................................34

3.6.3 - Reassigning Component Buttons ..............................................................................................34

3.6.4 - Changing Volume Lock .............................................................................................................34

Chapter 4 - Maintenance and Troubleshooting.........................................................................................35

4.1 - Maintenance .....................................................................................................................................35

4.2 - Troubleshooting Guide......................................................................................................................35

4.3 - Telephone & Technical Support........................................................................................................38

4.4 - Compliance .......................................................................................................................................38

4.5 - FCC Class B Radio Frequency Interference Statement....................................................................38

Appendix A: Limited Warranty Information...............................................................................................39

Appendix B: Component Program Codes.................................................................................................40

Version - 4/7/2005

VIZIO L30 WGUe User Guide

Chapter 1 - Introduction

1.1 - Before Use

Congratulations on your VIZIO L30 WGUe 30” LCD Television purchase. Thank you for your support of VIZIO and its LCD Television product line. The L30 WGUe is a precise electronic product and you should read the following instructions carefully to maximize the performance of the product. It has passed regulatory safety certifications and you can be assured of the highest quality display with the utmost reliability. After you have finished reading the instructions, put them away in a safe place for future reference.

Note: In some countries or regions, the shape of the power plug and power outlet may sometimes differ from that shown in the explanatory drawings. However, the method of connecting and operating the unit is the same.

1.2 - Specifications

Panel 30” Color TFT Active Matrix LCD Resolution 1280 x 768 pixels (15:9 Aspect Ratio) Display Compatibility HDTV (720p) Native Signal Compatibility 480i (SDTV), 480p (EDTV), 720p (HDTV), 1080i (HDTV) Response Time 16 ms Brightness 500 nits typical Contrast 600:1 Viewing Angle 170° (horizontal), 170° (vertical) for CR>10

1 x Service Port, 1 x DVI-D with audio in, 1 x RGB D-Sub 15-pin with audio

in, 2 x Component Video (Y/Pb/Pr & Y/Cb/Cr) with Audio (Left and Right), 1

x S-Video, 2 x Composite Video with Audio (Left and Right), 1 x RF (for

Inputs

internal NTSC tuner), 1 x mini-jack

Output 1 x Audio (Right + Left), 1 x Composite Video

SRS Surround, Two-tuner PIP, 3:2 pull down, noise reduction 3D digital

Features

comb filter HDTV ready (480i, 480p, 720p, 1080i) Speakers Built-in 2 x 5 W Lamp Life 50,000 hours (typical) Power

Input IEC Connector for direct power line connection Voltage Range 90– 264 VAC at 50/60 Hz

Power Consumption 170 W Environment Conditions Operating Temperature: 5~35°C, Relative Humidity: 10~90%, Altitude: 0~10,000 ft. Non-Operating Temperature: -20~50°C, Relative Humidity: 10~90%, Altitude: 0~40,000 ft.

23.7” (H) x 29.1” (W) x 7.8” (D) w/stand, 20.6” (H) x 29.1” (W) x 4” (D) w/o

Dimensions

stand Net Weight 42.1 lbs w/stand, 31.1” w/o stand Certifications UL, C-UL, FCC Class B

Version - 4/7/2005

VIZIO L30 WGUe User Guide

1.3 - Opening the Package

• The VIZIO L30 WGUe is packaged in a carton together with other standard accessories. Any optional accessories are packed separately in another carton.

• The weight of the LCD display is approximately 42.1 lbs. Due to the size and weight of the product, it is suggested that it be handled by a minimum of 2 persons.

• Since the glass can be easily scratched or broken, please handle the product gently. Never place the unit on a surface with the glass facing downwards unless it is on protective padding.

• When opening the carton, check that the product is in good condition and that all standard accessories and items are included.

• Save the original box and all packing materials for future shipping needs.

1.4 - Installation

• Please read the user manual carefully before performing the installation.

• The power consumption of the display is approximately 170 watts, significantly higher than a

typical television. Please use the power cord designated for the product. When an extension cord is required, use one with the correct power rating. The cord must be grounded and the grounding feature must not be defeated.

• The product should be installed on a flat surface to avoid tipping. Space should be maintained between the back of the product and the wall for proper ventilation. If you would like mount the TV to the wall, please see Section 3.3 - Preparing the LCD for Wall Mounting, page 23, for additional information.

• Avoid installing the product in the kitchen, bathroom or other places with high humidity dust or smoke, so as not to shorten the service life of the electronic components.

• Please ensure the product is installed with the screen in landscape orientation. Any 90° clockwise or counterclockwise installation may induce poor ventilation and successive component damage.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

1.5 - Important Safety Guidelines

This product is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire. To prevent the product from being damaged, the following rules should be observed for the installation, use and maintenance of the product. Read the following safety instructions before operating the display. Keep these instructions in a safe place for future reference.

• To avoid the risk of electric shock or component damage, switch off the power before connecting other components to the L30

• Unplug the power cord before cleaning the L30 WGUe

• Always use the accessories recommended by the manufacturer to insure compatibility.

• When moving the L30 WGUe LCD TV from an area of low temperature to an area of high temperature, condensation may

• Do not place the L30 WGUe

• A distance of at least 3 feet should be maintained between the L30 WGUe

• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of the L30

• Never push any object into the slot on the L30 WGUe

• The L30 WGUe

• The power cable must be replaced when using different voltage from that specified in the User Manual. For more information,

• The L30 WGUe

• Do not overload power strips and extension cords. Overloading can result in fire or electric shock.

• The wall socket shall be installed near the equipment and shall be easily accessible.

• Only the marked power source can be used for the product. Any power source other than the specified one may cause fire or

• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.

• Unplug the unit during a lightening storm or when it will not be used for long period of time. This will protect the L30 WGUe

• Do not attempt to repair or service the product yourself. Opening or removing the back cover may expose you to high

• Keep the product away from moisture. Do not expose this appliance to rain or moisture. If water penetrates into the product,

• Do not use the product if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact

• Avoid using dropped or damaged appliances. If the product is dropped and the housing is damaged, the internal components

• Do not install the product in an area with heavy dust or high humidity. Operating the product in environments with heavy dust

• Hold the power connector when removing the power cable. Pulling the power cable itself may damage the wires inside the

• To avoid risk of electric shock, do not touch the connector with wet hands.

• Insert batteries in accordance with instructions while using the remote control. Incorrect polarities may cause damage and

• If any of the following occurs please contact the dealer:

• Operating environment: Temperature: 5°C ~ 35°C, Humidity: 10% to 90% non-condensing, Altitude: 0~10,000 ft.

LCD TV.

WGUe

LCD TV. A damp cloth is sufficient for cleaning the L30 WGUe LCD

TV. Do not use a liquid or a spray cleaner for cleaning the product. Do not use abrasive cleaners.

form on the housing. Do not turn on the L30 WGUe component damage.

LCD TV immediately after this to avoid causing fire, electric shock or

LCD TV on an unstable cart, stand, or table. If the L30 WGUe LCD TV falls, it can injure a person

and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the L30

LCD TV.

WGUe

LCD TV and any heat source, i.e. radiator, heater,

oven, amplifier etc. Do not install the product close to smoke. Operating the product close to smoke or moisture may cause fire or electric shock.

LCD TV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the L30

WGUe

LCD TV in a bookcase or cabinet unless proper ventilation is provided.

WGUe

LCD TV cabinet. Do not place any objects on the top of the product. It

could short circuit parts causing a fire or electric shock. Never spill liquids on the L30 WGUe

LCD TV.

LCD TV should be operated only from the type of power source indicated on the label. If you are not sure of

the type of power supplied to your home, consult your dealer or local power company.

contact your dealer.

LCD TV is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit

only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded plug.

electric shock.

LCD TV from damage due to power surges.

voltages, the risk of electric shock, and other hazards. If repair is required, please contact your dealer and refer all servicing to qualified service personnel.

unplug the power cord and contact your dealer. Continuous use in this case may result in fire or electric shock.

your dealer immediately. Do not try to repair the product yourself.

may function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of the product may cause fire or electric shock.

or high humidity may cause fire or electric shock.

cable and cause fire or electric shock. When the product will not be used for an extended period of time, unplug the power connector.

leakage of the batteries, operator injury and contamination the remote control.

o The power connector fails or frays. o Liquid sprays or any object drops into the L30 WGUe o The Display is exposed to rain or other moisture. o The Display is dropped or damaged in any way. o The performance of the Display changes substantially.

LCD TV.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

1.6 - Television Antenna Connection Protection

External Television Antenna Grounding

If an outside antenna or cable system is to be connected to the LCD TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements of the grounding electrode.

Lightning Protection

For added protection of the LCD TV during a lightning storm or when it is left unattended or unused for long periods of time, unplug the LCD TV from the wall outlet and disconnect the antenna or cable system.

Power Lines

Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

1.7 - Package Contents

VIZIO L30 WGUe LCD TV

VIZIO Universal Remote Control

Component Y/Pb/Pr Cable (green, blue, and red connectors)

Audio Cable (red and white connectors)

DVI cable

Power Cord

This User Guide

IMPORTANT: Save the original box and all the packing material for future shipping needs.

Note: Your product may also include various other accessories depending on region of purchase.

Version - 4/7/2005

1.8 - Front Panel Controls

VIZIO L30 WGUe User Guide

3 4 5 6 7

1. Remote Control Sensor – This is the window that passes all of the remote signals to the

sensor. Point the remote control directly at this window for the best response to the remote signal.

2. Power Button - Switch the TV on by pressing the button once. Press the button again to

turn the TV off.

Note: When turning the LCD TV on or off, wait three seconds before pressing this button again. If the button is not lit, then there is not any AC power detected and the power cord is not connected properly. If the button is solid orange, then your LCD TV is turned off. If the button is solid green, then your LCD TV is turned on.

3. Auto – This button automatically adjusts the display to the best settings in VGA and DVI

modes.

4. Volume ◄/► - These buttons increase or decrease volume. When the OSD is active,

these buttons adjust the OSD options.

5. Channel ▲/▼ – These buttons increase or decrease the channels. When the OSD is

active, these buttons are used to select OSD options.

6. Menu – This button opens and cycles through the OSD menu. Pressing this button

repeatedly will allow you to exit the main menu.

7. Input – This button switches between the available input sources in the following

sequence: VGA, DVI, HDTV YPbPr, DVD, AVI, AV2/S, and TV. When the on-screen display (OSD) is active, this button accepts an OSD menu item.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

1.9 - Rear Panel Connections

1 2 3 4 5 6 7 8

1. Service – To be used for factory service.

2. DVI/Audio In - Connect a DVD multimedia player, computer or set-top box and the audio

through these connections. This is a digital only connector.

3. VGA/Audio In - Connect the video from a computer or set-top box and the audio from a

computer, DVD multimedia player or set-top box to these connections.

4. Component HDTV In (Y-Pb-Pr) (green, blue, and red connectors) - Connect the external

video devices, such as a DVD player or set-top box. Use the white and red connectors to connect the external audio from the same source. Note: YPbPr is used for the following signals: 480i, 480p, 720p, and 1080i.

5. Component DVD In (Y-Pb/Cb-Pr/Cr) (green, blue, and red connectors) - Connect the

external video devices, such as a DVD player or set-top box. Use the white and red connectors to connect the external audio from the same source. Note: YCbCr is used for 480i and 480p only.

6. AV In – Connect composite and/or S-Video devices, such as a VCR of video games.

Use the white and red connectors to connect the external audio from the same source.

7. Antenna (TV Input) - Connect to the antenna, satellite or cable service.

8. AV Out - Connect the video and audio from the LCD TV to an external device, i.e., an

external amplifier or secondary TV. This output only supports S-video, AV1 and AV2 equipped with A/V inputs. It does not support YPbPr, YCbCr, TV or RGB.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

528

35 36

30 33 3

1.10 - VIZIO Universal Remote Control

The VIZIO Universal Remote Control is a comprehensive remote that can be used to control up to four different components. The remote control button functions are explained on the following pages.

VIZIO Universal Remote Control Button Description

Version - 4/7/2005

VIZIO L30 WGUe User Guide

1.10.1 - Key Remote Control Functions

1. SETUP – This button starts all programming sequences.

2. Remote LED – Blinks when the remote is being programmed or is

sending a signal to your LCD display.

3. POWER – Press this key to turn the LCD display on from standby

mode. Press it again to return to the standby mode.

4. AUX – This button selects a programmed component.

5. CBL – This button selects a programmed cable TV set-top box or selects a programmed

satellite TV set-top box.

6. VCR – This button selects a programmed VCR.

7. TV – This button selects a programmed TV. Pre-programmed for the VIZIO L30 WGUe

LCD TV.

8. Number Button Pad – These buttons select a channel or

password.

9. MUTE – This button turns the sound on and off.

10. 100/Enter – This button enters a channel number greater than 100

in TV mode. Additionally, it works as an ENTER button in other video modes.

11. VOL (+ or -) – These buttons turn volume up or down.

12. LAST – This button recalls the previously viewed channel.

13. INPUT – This button changes the input source.

14. CH (+ or -) – These buttons change the channels up or down.

15. WIDE/GUIDE – This button cycles through standard and

widescreen viewing modes or accesses programming guides, such as the one that comes with a satellite dish. GUIDE does not work in TV mode.

16. FAV/EXIT – This button exits the component, guide or OSD

menus. Note: The FAV feature is not available on the L30 WGUe.

dcfe - These buttons navigate the on-screen display (OSD)

menus.

17. SELECT – This button works to select your chosen options in on-screen display (OSD)

menus.

18. INFO – This button turns the image and system information display on or off.

19. MENU – This button is used to turn the OSD on or off.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

20. Reverse/AV1 – This button rewinds the CD, DVD or VCR

when the component is activated with the remote control. Additionally, this button will select the AV1 component in TV mode.

21. Play/SVid1 – This button plays the CD, DVD or VCR when the

component is activated with the remote control. Additionally, this button will select the SVid1 component in TV mode.

22. Forward/YPbPr – This button forwards the CD, DVD or VCR when the component is

activated with the remote control. Additionally, this button will select the YPbPr component in TV mode.

23. Record/AV2 – This button functions as a VCR Record when the component is activated

with the remote control. Additionally, this button will select the AV2 component in TV mode.

24. Stop/DVI – This button stops the CD, DVD or VCR when the component is activated with

the remote control. Additionally, this button will select the DVI component in TV mode.

25. Pause/YCbCr – This button pauses the CD, DVD or VCR when the component is

activated with the remote control. Additionally, this button will select the YCbCr component in TV mode.

26. ZOOM – Use this key to zoom the image in or out. Note: This

feature will open the PIP size on the L30 WGUe.

27. Swap – Used to swap the inputs from the main screen, PiP or

POP picture mode.

28. – SubCh + – These buttons are used to select the channels

within the PIP.

29. PIP – Use this key to activate the picture-in-picture mode.

30. FREEZE – Press this key to "Freeze-Frame", the current

screen. You may press this key again to continue playing or play will resume automatically after one minute. Note: This feature will open the PIP source on the L30

WGUe.

31. POP – Use this key will activate the picture on picture. Note: This button will activate the

PIP position on the L30 WGUe.

32. MTS – Press this key to select Stereo, SAP (separate audio program) or Mono audio.

This function is available in the TV mode.

33. CC – Press this key to select closed caption options.

34. Sleep – Press this key to select the sleep options. User can adjust the sleep timer in 5

minute increments.

35. VGA – This button selects a connected VGA display.

36. TV – This button selects a programmed TV. Pre-programmed for the VIZIO L30 WGUe

LCD TV.

Note: The remote control layout is for reference only.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

1.10.2 - Insertion of Batteries in the Remote Control

Insert two AA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the batteries with the (+) and (-) symbols inside the battery compartment. Re-attach the battery cover.

Precautionary Tips for Inserting the Batteries:

• Only use the specified AA batteries.

• Do not mix new and old batteries. This may

result in cracking or leakage that may pose a fire risk or lead to personal injury.

• Inserting the batteries incorrectly may also

result in cracking or leakage that may pose a fire risk or lead to personal injury.

• Dispose of the batteries in accordance with

local laws and regulations.

• Keep the batteries away from children and pets.

1.10.3 - Remote Control Range

• Point the remote control at the remote control sensor to transmit the commands.

• Do not place any obstacles between the remote control and the receiver window.

• The effective range of the remote control is approximately 32 feet (10 meters) from the

front of the receiver window, 30º to the left and right, 20º up and down.

1.10.4 - Precautions for the VIZIO Universal Remote Control

• The remote control should be kept dry and away from heat sources. Avoid humidity.

• If the display responds erratically to the remote control or does not respond at all, check

the batteries. If the batteries are low or exhausted, replace them with fresh batteries.

• When not using the remote control for a long period of time, remove the batteries.

• Do not take apart the batteries, heat them, or throw them into a fire.

• Do not subject the remote control to undue physical stress, such as striking or dropping it.

• Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean,

damp cloth.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

Chapter 2 - Connecting Components

2.1 - Which Video Connection Should I Use?

The VIZIO L30 WGUe LCD TV has five different ways to connect your video equipment from a basic one to the most advanced for digital displays.

Connection

Cable and Connector Description

Quality

Basic

Good

Better

Best

Coaxial RF. This is the only connection that has the audio and the video in one cable. If you have an antenna, this is the only way you can connect it to the LCD TV. If you have a VCR, you can connect your antenna/cable to the VCR RF Input and connect the VCR RF Output to this connector.

Composite. The complete video signal is carried through this single pin connector. This is the most commonly used video connection.

S-Video. The video signal is separated into two signals, one containing the black-and-white information and the other containing the color information. Separating the color in this way avoids ‘cross color’ effects where closely spaced black and white lines are erroneously displayed in color. It also enables text to be displayed more sharply.

Component. The video signal is separated into three signals, one containing the black-and-white information and the other two containing the color information. This enhancement over S-Video takes advantage of the superior picture provided by progressive scan DVD players and HDTV formats.

Digital Video (DVI). All of the picture information is received digitally coded and it does not convert the signal from digital to analog. The other inputs are converted from analog to digital by the LCD TV. Movies are digitally encoded on DVD’s and so by using a component such as the BRAVO D2 DVI Enabled DVD Player from VIZIO with a DVI output it will produce the ultimate picture performance.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

2.2 - Connecting Your DVD Player

You have several options for connecting your DVD player to your new L30 WGUe LCD TV - DVI, Component, S-Video, and Composite inputs. Based on your home theater configuration, you can decide which option is the right one for you.

2.2.1 - Using Digital Video

DVD players that have a digital interface compliant with the DVI (Digital Visual Interface) standard, such as the BRAVO D2 DVI Enabled DVD Player from VIZIO, should be connected to the DVI input of the VIZIO L30 WGUe LCD TV.

Note:

a) Use TMDS signals conforming to DVI standards. The TMDS input is a single link input. b) To maintain the display quality, use a DVI cable from VIZIO that is 10 meters or less.

Installation:

1. Turn off the power to the LCD TV and DVD player.

2. Connect a DVI-D cable to the DVI output of your DVD player and the other end to the DVI

input in the rear of your LCD TV.

3. Connect the R (red color) and L (white color) audio connectors on the rear of your DVD

player to the R (red color) and L (white color) audio input connectors in the DVI Audio group in the rear of your LCD TV.

4. Turn on the power to the LCD TV and your DVD player.

5. Select DVI using the INPUT button on the front of the LCD TV.

Note:

a) The DVI input on your LCD TV supports High-bandwidth Digital Content Protection

(HDCP). HDCP encrypts the transmission between the video source and the digital display for added security and protection.

b) Refer to your DVD player user manual for more information about the video output

requirements of the product.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

2.2.2 - Using Component Video

Installation:

1. Turn off the power to the LCD TV and DVD player.

2. Connect the Y (green color) connector on the rear of your DVD player to the

corresponding Y (green color) connector in the DVD group in the rear of your LCD TV.

3. Connect the Pb (blue color) connector on the rear of your DVD player to the

corresponding Pb (blue color) connector in the DVD group in the rear of your LCD TV.

4. Connect the Pr (red color) connector on the rear of your DVD player to the corresponding

Pr (red color) connector in the DVD group in the rear of your LCD TV.

5. Connect the R (red color) and L (white color) audio connectors on the rear of your DVD

player to the R (red color) and L (white color) audio input connectors in the DVD group in the rear of your LCD TV.

6. Turn on the power to the LCD TV and DVD player.

7. Select DVD using the INPUT button on the front of the LCD TV.

Note: Refer to your DVD player user manual for more information about the video output requirements of the product.

Version - 4/7/2005

2.2.3 - Using S-Video

Installation:

1. Turn off the power to the LCD TV and DVD player.

2. Connect the S-Video jack on the rear of your DVD player

to the S-Video jack in the AV In group in the rear of your LCD TV.

3. Connect the R (red color) and L (white color) audio

connectors on the rear of your DVD player to the R2 (red color) and L2 (white color) audio input connectors in the AV2/S group in the rear of your LCD TV.

4. Turn on the power to the LCD TV and DVD player.

5. Select AV2/S using the INPUT button on the front of

the LCD TV.

VIZIO L30 WGUe User Guide

Note: Refer to your DVD player user manual for more information about the video output requirements of the product.

2.2.4 - Using Composite Video

Installation:

1. Turn off the power to the LCD TV and DVD player.

2. Connect the Video

(yellow color) connector on the rear of your DVD player to the V1 connector in the A/V 1 group in the rear of your LCD TV.

3. Connect the R (red color) and L (white color) audio connectors on the rear of your DVD player to the R1 (red color) and L1 (white color) audio input connectors in the A/V 1 group in the rear of your LCD TV.

4. Turn on the power to the LCD TV and DVD player.

5. Select AV1 using the INPUT button on the front of the LCD TV.

Note:

a) If you are already using the AV1 input for another component, or you do not want to

use the AV1 input for the DVD player, you can connect the DVD player to the AV2 in the A/V In group. If you are using AV2, then please make sure you connect the audio in the AV2/S group.

b) Refer to your DVD player user manual for more information about the video output

uirements of the product.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

2.3 - Connecting Your HDTV Set-Top Box

You have several options for connecting your HDTV Set-Top Box to your new L30 WGUe LCD TV: DVI and RGB inputs. Based on your home theater configuration, you can decide which option is the right one for you.

2.3.1 - Using Digital Video

HDTV Set-Top Boxes that have a digital interface compliant with the DVI (Digital Visual Interface) standard can be connected to the DVI input of the LCD TV.

Note:

a) Use TMDS signals conforming to DVI standards. The TMDS input is a single link

input.

b) To maintain the display quality, use a DVI cable from VIZIO that is 10 meters or less.

Installation:

1. Turn off the power to the LCD TV and HDTV Set-Top Box.

2. Connect a DVI-D cable to the DVI output of your HDTV Set-Top Box and the other end to the DVI input in the rear of your LCD TV.

3. Connect the R (red color) and L (white color) audio connectors on the rear of your HDTV Set-Top Box to the R (red color) and L (white color) audio input connectors in the DVI group in the rear of your LCD TV.

4. Turn on the power to the LCD TV and your HDTV Set-Top Box.

5. Select DVI using the INPUT button on the front of the LCD TV.

Note:

a) The DVI input on your LCD TV supports High-bandwidth Digital Content Protection

(HDCP). HDCP encrypts the transmission between the video source and the digital display for added security and protection.

b) Refer to your HDTV Set-Top Box user manual for more information about the video

output requirements of the product or consult your satellite or cable operator.

Version - 4/7/2005

2.3.2 - Using RGB Video

Installation:

VIZIO L30 WGUe User Guide

1. Turn off the power to the LCD TV and HDTV Set-Top Box.

2. Connect a 15-pin D-Sub RGB cable to the RGB output of your HDTV Set-Top Box and the other end to the VGA input in the rear of your LCD TV.

3. Connect the Audio Out on your HDTV Set-Top Box to the Audio (L/R) within the VGA group on your LCD TV.

4. Turn on the power to the LCD TV and your HDTV Set-Top Box.

5. Select VGA using the INPUT button on the front of the LCD TV.

Note: Refer to your HDTV Set-Top Box user manual for more information about the video output requirements of the product or consult your satellite or cable operator.

2.4 - Connecting Your VCR or Video Camera

Installation:

1. Turn off the power to the LCD TV and VCR or video camera.

2. Connect the S-Video jack on your VCR or video camera to the S-Video jack in the AV In group in the rear of your LCD TV.

3. Connect the R (red color) and L (white color) audio connectors on your VCR or video camera to the R2 (red color) and L2 (white color) audio input connectors in the AV2/S group in the rear of your LCD TV.

4. Turn on the power to the LCD TV and VCR or video camera.

5. Select AV2/S using the INPUT button on the front of the LCD TV.

Note: Refer to your VCR or video camera user manual for more information about the video output requirements of the product.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

2.5 - Connecting Coaxial (RF)

There are several options for connecting your antenna or cable to your new L30 WGUe LCD TV directly to the TV or through your VCR. Based on your home theater configuration, you can decide which option is the right one for you.

2.5.1 - Using Your Antenna or Cable TV

Installation:

1. Turn off the power to the LCD TV.

2. Connect the coaxial (RF) connector from your antenna, cable or cable box to the ANT connector on the rear of your LCD TV.

3. Turn on the power to the LCD TV

4. Select TV using the INPUT button on the front of the LCD TV.

Note: See page 26 for selecting the TV source within the OSD menus (antenna, cable, HRC and IRC). Make sure the antenna or cable TV is correctly grounded.

2.5.2 - Using the Antenna through Your VCR

Installation:

1. Turn off the power to the LCD TV and VCR.

2. Connect the “Output to TV” (RF Out or Antenna Out) connector on the rear of your VCR to the ANT connector on the rear of your LCD TV.

3. Turn on the power to the LCD TV and VCR.

4. Select TV using the INPUT button on the front of the LCD TV.

5. Select Channel 3 or 4 to match the channel selected on the rear of your VCR.

Note:

a) If you have an off-air antenna or cable TV, connect the off-air antenna or TV cable to

the RF connector on the rear of your VCR.

b) Make sure the antenna or cable TV is correctly grounded.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

2.6 - Connecting External Amplified Speakers

Installation:

1. Turn off the power to the LCD TV and external speakers.

2. Connect the R (red color) and L (white color) audio connectors on the rear of your speakers to the R (red color) and L (white color) audio output connectors in the A/V Out group in the rear of your LCD TV.

3. Turn on the power to the LCD TV and speakers.

2.7 - Connecting an External Receiver or Amplifier

You can connect an external receiver or amplifier to your LCD TV. Your LCD TV is equipped with an external speaker switch that can automatically send a remote turn-on/off signal to the connected external receiver or amplifier.

Installation:

1. Turn off the power to the LCD TV and receiver or amplifier.

2. Connect the R (red color) and L (white color) audio connectors on the rear of your receiver or amplifier to the R (red color) and L (white color) audio output connectors in the A/V Out group in the rear of your LCD TV.

3. Turn on the power to the LCD TV and receiver or amplifier.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

2.8 - Connecting a Computer

Installation:

1. Turn off the power to the LCD TV and Computer.

2. Connect a 15-pin D-sub RGB cable to the RGB output of your computer and the other end to the VGA input in the rear of your LCD TV.

3. Connect the RGB Audio Out on your computer to the VGA Audio (L/R) at the rear of your LCD TV.

4. Turn on the power to the LCD TV and your computer.

5. Select VGA using the INPUT button on the front of the LCD TV.

Note:

a) For the best picture quality when connecting a PC through RGB or DVI, set your

product timing mode to VESA 1280 x 768 at 60 Hz. Please refer to the graphic card’s user guide for additional information on how to set the timing mode.

b) Refer to your computer user manual for more information about the video output

requirements of the product.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

Chapter 3 - Getting Started

3.1 - Turning your LCD TV On and Off

1. Connect the power cord to the power cord connector on the back of your LCD TV, and then plug the power cord into an AC wall socket.

2. Press the POWER button on the front panel or the POWER button on the remote control to power on the LCD TV. The POWER indicator on the front panel will light green.

3. Select input source for the LCD TV, via either OSD menu or remote control.

4. If connecting to antenna, cable or other RF source on TV inputs, see page 26 to configure the product to receive all available channels.

Note: For the best picture quality when connecting a PC through RGB or DVI, set your product timing mode to VESA 1280 x 768 at 60 Hz. Please refer to the graphic card’s user guide for additional information on how to set the timing mode.

3.2 - Watching a TV program

Before you start watching TV, please make sure that any cable, satellite, or off-air antenna connections are secure. Also, verify that the power cord is plugged into a correctly grounded electrical outlet or surge protector.

1. Press the power button on the front of your LCD TV. The status LED on the front turns green.

2. There are 2 options for selecting your programming: a) Select TV using the INPUT button on the front of your LCD TV if you are watching a

cable TV box, satellite or off-air antenna. <OR> b) Select HDTV using the Input button on the front of your LCD TV if you are watching

HD cable or satellite dish.

Note: You should be able to see a picture. If you do not, make sure that all connections are secure and you have selected the correct video input source.

3. Press the Channel ▼/▲ buttons on the front of your LCD TV to change the channel.

Note: The Channel ▼/▲ buttons on the front of the TV do not work if you are watching a program using HDTV input.

To make additional adjustments to your LCD TV, please see “Section 3.4 Adjusting Basic LCD TV Settings” on page 23.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.3 - Preparing the LCD for Wall Mounting

The VIZIO L30 WGUe can either be kept on the base stand or mounted to the wall for viewing. If you choose to mount the L30 WGUe to the wall, please follow the instructions below for removing the base stand.

To remove the stand base:

1. Unplug all the cables and cords from the LCD TV.

2. Place the LCD TV face down on a soft and flat surface (blanket, foam, cloth, etc) to prevent any damage to the display.

3. Remove the 6 screws on the stand base of the LCD TV.

Note: Please make sure you secure the base of the stand so that the glass does not fall when the screws are loosened.

4. Remove the glass and stand safely from the back panel.

Now, the LCD TV will fit flush against a LCD TV wall mount. Please make sure to read the directions of your specific wall mount to properly hang the L30 WGUe.

3.4 - Adjusting Basic LCD TV Settings

Volume

To increase the volume, press and hold the VOL + button on the front panel or remote control until the desired level is reached.

To decrease the volume, press and hold the - VOL button on the front panel or remote control until the desired level is reached.

TV Channels

To step up through the available TV channels, press the CH + button on the front panel or remote control once for the next channel or hold it depressed until the desired channel is reached.

To step down through the available TV channels, press the - CH button on the front panel or remote control once for the previous channel or hold it depressed until the desired channel is reached.

Wide

Using this feature you can watch video content in Panoramic, Widescreen, Zoom or Standard mode. Press the WIDE button on the remote control to switch among the modes.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.5 - Using the On-Screen Display (OSD)

The remote control or the bottom control keys on the front panel of the LCD TV can control all the function settings. The on-screen display (OSD) allows you to adjust and save contrast, brightness and other settings. The LCD TV will save changes made to the settings even if the LCD TV is turned off.

3.5.1 - Menu Operations

The OSD consists of several menu options: Video, Audio, TV and Setup. The main menu options may vary depending on your selected input source. Some of the main menu options may have additional sub menus, i.e. Blocking Menu within the Setup Menu.

1. Press the MENU button on the front of the TV or on the remote control. The Main Menu

will be displayed on the screen.

2. Use the Channel (▲/▼) buttons on the front of the

LCD TV or ▲/▼ buttons on the remote control to select a menu option.

3. Use the Volume (e/f) buttons on the front of the

LCD TV or e/f on the remote control to adjust the option setting.

4. Press the SELECT button on the remote control to

confirm the feature.

5. Repeat steps 2 through 4 to adjust additional options within this menu.

6. Once the adjustments are completed, press the Menu button on the LCD TV or on the

remote control again to modify the next menu (Picture, Audio, TV, or Setup). Press the Menu button on the LCD TV or on the remote control to cycle through the main menu options.

7. Press the Exit button on the remote control to exit the OSD completely.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.5.2 - OSD Menus and Options

The OSD menus and options are used to adjust various settings on your LCD TV. Some of the menu options can vary depending on the video input source that you are using.

3.5.2.1 - Video

Available for the following input sources - AV1, AV2/S, DVD, HDTV and TV input.

Brightness – Adjusts the black levels of the picture. Users may

need to readjust the brightness after the LCD TV warms up.

Contrast – Adjusts the level of white between the lightest and

darkest portions of an image. If the contrast is too low, the picture appears dark and lacks detail. If the contrast is too high, the picture appears faded and lacks shadow and depth.

Color – Adjusts the levels of white and color in the picture.

Highly saturated colors tend to be deep and strong while unsaturated colors are weaker and lighter.

Tint – Adjusts to make the flesh tones more natural. Sharpness – Adjusts the clarity of the picture. If the sharpness is

set incorrectly, the picture appears fuzzy or out of focus.

Color Temp. – Adjusts the intensity of the colors in the picture. A “cool” or low color temperature

is good for watching movies or for watching programs in a darkened environment. A “warm” or high color temperature is good for daylight viewing like sporting events.

Noise Reduction – Eliminates video noise. Note: this option is only available in TV mode.

3.5.2.2 - Picture

Available for the following input sources – VGA and DVI input.

Brightness – Adjusts the black levels of the picture. Users may

need to readjust the brightness after the LCD TV warms up.

Contrast – Adjusts the level of white between the lightest and

darkest portions of an image. If the contrast is too low, the picture appears dark and lacks detail. If the contrast is too high, the picture appears faded and lacks shadow and depth.

Auto Picture – Automatically sets the position and size of the

picture.

Manual Picture – Manually sets the position and size of the

picture.

Sharpness – Adjusts the clarity of the picture. If the sharpness is set incorrectly, the picture

appears fuzzy or out of focus.

Color Temp. – Adjusts the intensity of the colors in the picture. A “cool” or low color temperature

is good for watching movies or for watching programs in a darkened environment. A “warm” or high color temperature is good for daylight viewing like sporting events.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.5.2.3 - Audio

Volume – Adjusts the volume. Treble – Adjusts the treble. Bass – Adjusts the bass. Balance – Adjusts the balance level between the channels. Spatial – Enhances the stereo sound of the built-in speakers. MTS (TV mode only) – Changes the sound output for TV

programs. Switch between STEREO, MONO, or SAP (Second Audio Program) for audio simulcasts. The TV program must support the output option.

3.5.2.4.1 - TV

Source – Sets the source for the tuner. Options include

Antenna or Cable. Antenna sets the tuner for an antenna and CABLE sets the tuner for cable or a satellite dish.

Cable Mode – Specifies the type of cable system you subscribe

to. Options include Standard, HRC, IRC, and Auto. For most cable systems, you can set this value to Auto. However, if you are not receiving all the channels you subscribe to, you may need to set this value.

Channel Scan – Adds all channels that have a signal to the channel list. CC Mode – Turns captioning on and off and selects the closed caption style. Options include

Text 1, Text 2, CC1 or CC2.

Parental Controls – Activates parental controls. For more information about Parental Controls,

see the BLOCKING menu below. Access to the Blocking Submenu is only available by entering a password. For your convenience the default has been set to “0000”. For more information, see Section 3.5.5 - Setting a Password, page 31.

3.5.2.4.2 – Blocking

Access to this menu is only available through the Parental Controls.

Change Password - Changes the password used for modifying

the parental control settings or watching a program blocked by the parental controls. For more information, see Section

3.5.5 - Setting a Password, page 31.

Setup TV Blocking - Sets the level of television programs that

will be blocked without typing in the password. For more information, see Section 3.5.4 - Using the Parental Controls, page 30.

Setup Movie Blocking - Sets the level of movies that will be blocked without typing in the

password. For more information, see Section 3.5.4 - Using the Parental Controls, page 30.

Blocking Enable - Turns TV and movie blocking on or off. Key Lockout - Locks the LCD TV so it cannot be controlled using the buttons on the front of the

TV. Options include Lock All, Lock None, and Lock All But Power.

IR Lockout - Locks the LCD TV so it cannot be controlled using the remote control. The user

must use the buttons on the LCD TV to control the television.

Factory Reset - Resets all settings to the factory default.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.5.2.5.1 – Setup

Language - Changes the language of the OSD menu. Options

include French, Spanish, or English.

Gamma - Changes the color space. Options include Linear,

Vivid1, Vivid2 and Vivid3.

Wide - Changes the viewing mode. Options include Zoom,

Standard, Panoramic, or Widescreen. For more information, see Section 3.5.3 – Understanding Viewing Features, page 28.

PIP - Modifies the Picture-in-Picture settings. To access these

settings, press Select on the remote control. For more information, see below.

OSD Style - Switches the OSD background from opaque to translucent.

3.5.2.5.2 – PiP

This submenu is only available through the PIP submenu in the

Setup Menu. After you are finished making the necessary adjustments, then press “Exit” to return to the Setup Menu.

Switch - Turns Picture-in-Picture on or off. Style - Changes the size of the PIP sub-picture. Sizes include

Small, Medium, and Large.

POS - Moves the sub-picture within the display image. Wide - Sets the viewing mode of the PIP sub-picture. Modes

include standard and widescreen.

Source - Changes the video input source of the sub-picture when PIP is turned on. Sources

include AV1, AV2/S, 480i DVD and TV.

PIP TV Channel - Changes the PIP channel if the source is set to TV. Use the Sub CH (-/+)

buttons on the remote control to change the channel up or down.

For additional information regarding the PIP options, see 3.5.3.2 - Picture-in-Picture (PiP) Mode, page 29.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.5.3 - Understanding Viewing Features

Your LCD TV features four viewing modes and Picture-in-Picture (PIP) mode. You can switch viewing modes using the on-screen display (OSD) or the remote control. For more information on using the OSD, see 3.5.2 - OSD Menus and Options, page 25.

3.5.3.1 - Viewing modes

3.5.3.1.1 - Standard Mode - The original 4:3 aspect ratio (1.33:1

source) is preserved, so black bars are added to the left and right of the display image. Standard TV broadcasts are displayed with a 4:3 Aspect Ratio. Movies in 4:3 Aspect Ratio may be referred to as panand-scan or full frame. These movies were originally filmed in 16:9 (widescreen), and then modified to fit a traditional TV screen (4:3).

3.5.3.1.2 - Widescreen Mode - When watching a standard

broadcast or full-frame movie in this mode, the display image is stretched proportionately to fill the TV screen. When watching a widescreen (1.76:1 source) program or movie, the display image fills the TV screen. If you are watching a widescreen (1.85:1 or 2.35:1 source) program or movie, there will still be black bars at the top and bottom.

3.5.3.1.3 - Panoramic Mode - When watching a standard

broadcast or full frame movie in this mode, the 4:3 Aspect Ratio (1.33:1 source) display image is stretched horizontally on the left and right sides to fill the TV screen. The center of the image is not stretched.

3.5.3.1.4 - Zoom Mode - When watching a widescreen (1.76:1,

1.85:1, or 2.35:1 source) program or movie, the display image

is zoomed proportionally to fill the width of the screen. The top and bottom are cut off to remove most of the source material’s black bars. This mode is good for programs or movies with subtitles.

Note: Viewing modes and volume settings are saved based on input. For example, you last watched a DVD in widescreen mode and at high volume, and then watched TV in standard mode and low volume. When you switch back to DVD input, the viewing mode will return to widescreen and your volume will be high.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.5.3.2 - Picture-in-Picture (PiP) Mode

Your LCD TV features PIP mode so you can watch two pictures at the same time. You can use PIP mode if your PIP video input source is set to TV, AV1, AV2/S, or 480i DVD. See below for detailed information regarding the PIP sources.

PiP Source

Main Source TV AV1 AV2/S DVD HDTV VGA DVI

TV x x x 480i NA NA NA

AVI x x x 480i NA NA NA

AV2/S x x x 480i NA NA NA

DVD x x x 480i NA NA NA

HDTV x x x 480i NA NA NA

VGA x x x 480i NA NA NA

DVI x x x 480i NA NA NA

Note: You cannot use HDTV, VGA, DVI, or 480p DVD video as Picture-in-Picture (PIP) sources.

When PIP is turned on, you can display two pictures at one time. One picture is displayed on the full screen and the other picture is displayed in a small window. The picture on the full screen is the main picture. The picture in the window is the sub-picture. The sub-picture can be set to small, medium, or large.

Adjusting Basic PIP Settings

3.5.3.2.1 - PIP Channel

The PIP channel is independent of the main TV channel. To change the PIP channel, press the PIP CH + or - button on the remote control.

3.5.3.2.2 - Swapping PIP Video

You can swap the program that is in the main picture with the program in the PIP sub-picture. To swap the main picture program with the PIP sub-picture program, press SWAP on the remote control. If you press SWAP again, it will return the program to the main picture.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.5.4 - Using the Parental Controls

The Parental Controls feature prevents viewers from watching programs that are not ageappropriate, such as programs containing violence or adult language.

1. Press the MENU button 3 times on the remote control until the TV menu opens.

2. Press ▼ button to highlight PARENTAL CONTROLS, and then press SELECT. The “Enter Password” window opens.

3. Use the number pad to type the password, then press OK. The password was set to “0 0 0 0” at the factory. The BLOCKING submenu opens.

4. Press ▼ button to highlight SETUP TV BLOCKING, and then press the SELECT button on the remote control. The “TV-Rating” window opens. On this window, you can customize the following TV ratings:

Y (all children) Y7 (older children) G (general audience) PG (guidance suggested) 14 (strongly cautioned) MA (mature audience)

You can also customize the TV ratings for the following content:

FV (fantasy violence) D (sexual dialog) L (adult language) S (sexual situations) V (violence)

5. Press the ▼ or ▲ button to select each area, and then press ◄ or ► button to toggle between the options (FV, D, L, S, or V). Press the SELECT button on the remote control to block or unblock each area.

6. Press the MENU button on the remote control to return to the submenu.

7. Press ▼ button to highlight SETUP MOVIE BLOCKING, and then press the SELECT button on the remote control. The MPAA window opens. On this menu, you can customize the following MPAA movie ratings:

G (general audience) PG (parental guidance suggested) PG-13 (recommended for children 13 years of age or older) R (mature audience) NC-17 (no one under 17 years of age) X (no one under 17 years of age)

8. Press the ▼ or ▲ button to select each rating, and then press SELECT button on the remote control to toggle the rating to blocked or unblocked.

9. Press the MENU button on the remote control to return to the submenu.

10. Press ▼ button to highlight BLOCKING ENABLE, then press ◄ or ► button to toggle the blocking enable to yes.

11. Press the EXIT button the remote control to exit the OSD menu when you are finished.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.5.5 - Setting a Password

You control access to the Parental Control features with a password. The default password is “0000”. You can change the password to any four-digit number.

To change the password:

1. Press the MENU button three times on the remote control until the TV menu opens.

2. Press ▼ until the PARENTAL CONTROLS is highlighted. Press SELECT and the Enter Password window opens.

3. Use the number pad to type the password, then press SELECT. For your convenience, the password was set to “0000” at the factory. Once the password has been successfully entered, the BLOCKING sub-menu opens.

4. Highlight CHANGE PASSWORD, and press SELECT. The Change Password window opens.

5. Use the number pad to type the new password.

6. Use the number pad to retype the new password.

7. Press the EXIT button on the remote control immediately to exit the OSD menu.

Note: Please make sure to write down and store the new password in a secured place. The factory reset option in the Blocking menu (see 3.5.2.4.2 – Blocking, p. 26) does not reset the

assword.

3.5.6 - Setting the Sleep Timer

The sleep timer lets you set a time delay to turn off your LCD TV automatically.

To set the sleep time using the remote control:

1. Press the TV component button.

2. Press the SLEEP button on the remote control. The sleep timer appears in the center of your screen.

3. Press the SLEEP button one or more times to select the time you want. Options include 30, 60 or 90 minutes.

4. Press the EXIT button on the remote control to hide the sleep timer display. Your sleep timer is now running in the background.

To turn off the sleep time using the remote control, press the SLEEP button repeatedly until Off appears.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.6 - Remote Control Operation

3.6.1 - Programming the VIZIO Universal Remote Control

You can program the remote control to work with up to four different components. Listed below are the steps for programming your TV, VCR, Cable Box and DVD Player.

3.6.1.1 - Programming for TV

For your convenience, the TV button on the remote has already been preprogrammed for the L30 WGUe. If you would like to program a second TV as the primary TV, please follow the instructions below.

1. Manually turn on the TV.

2. Press the TV button on the remote control.

3. Press and hold the SETUP button until the LED LIGHT flashes twice.

4. Find the programming code for your TV in the code list in the back of this book and enter it using the Number Buttons. If the code is accepted, the LED flashes twice after the last digit is entered.

If the LED does not flash twice, repeat Steps 2 through 4 with the next code listed for the component and manufacturer.

5. Point the remote control at the TV and press the POWER button. The TV will turn off.

Note:

a) If your TV does not respond, try all the codes for your brand. If the codes do not work,

or your brand is not listed, see “Searching for Component Codes”, page 34.

b) Sometimes a code listed will only include limited functions. Try other codes that may

include more functionality.

3.6.1.2 - Programming for VCR

1. Manually turn on the VCR.

2. Press the VCR button on the remote control.

3. Press and hold the SETUP button until the LED LIGHT flashes twice.

4. Find the programming code for your VCR in the code list in the back of this book and enter it using the Number Buttons. If the code is accepted, the LED flashes twice after the last digit is entered.

If the LED does not flash twice, repeat Steps 2 through 4 with the next code listed for the component and manufacturer.

5. Point the remote control at the VCR and press the POWER button. The VCR will turn off.

Note:

a) If your VCR does not respond, try all the codes for your brand. If the codes do not

work, or your brand is not listed, see “Searching for Component Codes”, page 34.

b) Sometimes a code listed will only include limited functions. Try other codes that may

include more functionality.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.6.1.3 - Programming for Cable Box

1. Manually turn on the Cable Box.

2. Press the CBL button on the remote control.

3. Press and hold the SETUP button until the LED LIGHT flashes twice.

4. Find the programming code for your Cable Box in the code list in the back of this book and enter it using the Number Buttons. If the code is accepted, the LED flashes twice after the last digit is entered.

If the LED does not flash twice, repeat Steps 2 through 4 with the next code listed for the component and manufacturer.

5. Point the remote control at the Cable Box and press the POWER button. The Cable Box will turn off.

Note:

a) If your Cable Box does not respond, try all the codes for your brand. If the codes do

not work, or your brand is not listed, see “Searching for Component Codes”, page 34.

b) Sometimes a code listed will only include limited functions. Try other codes that may

include more functionality.

3.6.1.4 - Programming for AUX (DVD Player)

1. Manually turn on the DVD Player.

2. Press the AUX button on the remote control.

3. Press and hold the SETUP button until the LED LIGHT flashes twice.

4. Find the programming code for your DVD player in the code list in the back of this book and enter it using the Number Buttons. If the code is accepted, the LED flashes twice after the last digit is entered.

If the LED does not flash twice, repeat Steps 2 through 4 with the next code listed for the component and manufacturer.

5. Point the remote control at the DVD Player and press the POWER button. The DVD Player will turn off.

Note:

a) If your DVD Player does not respond, try all the codes for your brand. If the codes do

not work, or your brand is not listed, see “Searching for Component Codes”, page 34.

b) Sometimes a code listed will only include limited functions. Try other codes that may

include more functionality.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

3.6.2 - Searching for Component Codes

If the user cannot find the manufacturer in the component list or the program code does not work, the user can use the remote control to search for the correct component code.

To search for a component code:

1. Turn on the component.

2. Press the matching component button on the remote control.

3. Press and hold the SETUP button until the LED flashes twice.

4. Press 9 9 1. The LED flashes twice.

5. Point the remote control at the component and then alternate between pressing the POWER button and the component button on the remote control until the component turns off.

If the component still does not respond, clear the component button, then repeat the search procedure.

To clear the component button:

1. Make sure that the component is turned on.

2. Press and hold the SETUP button on the remote control until the LED flashes twice.

3. Press 9 9 2, then press the component button on the remote control twice.

3.6.3 - Reassigning Component Buttons

You can reassign the component buttons on the remote control if you have more than one of the same types of component. For example, if you are using the remote to control the cable (CBL), CD, DVD, TV and two VCRs, you can reassign the AV2 button as a second VCR button.

To reassign component buttons:

1. Press and hold the SETUP button until the LED flashes twice.

2. Press 9 9 2. The LED flashes twice.

3. Press the component button that you want (VCR) once, and then press the component button that you are reassigning (AV2) once. The AV2 button is now reassigned and can be programmed as a VCR component button. See “Programming the VIZIO Universal Remote Control”, page 32.

3.6.4 - Changing Volume Lock

The remote control is set to control volume through your TV while in cable (CBL), DVD, satellite (SAT) and VCR component modes. Use the volume lock if you want to control the volume for all components through a specific component. For example, you want to control volume for all components through the tuner (TNR).

To change the volume lock:

1. Press and hold the SETUP button until the LED flashes twice.

2. Press 9 9 3. The LED flashes twice.

3. Press the component button that you want (TNR) once. The LED flashes twice. Volume will now be controlled through the tuner for all components.

Version - 4/7/2005

Chapter 4 - Maintenance and Troubleshooting

4.1 - Maintenance

Important

1. Make sure that the power cable is removed from the socket before cleaning the display.

2. Do not use volatile solvent (such as toluene, rosin and alcohol) to clean the display. Such chemicals may damage the housing, screen glass and remote control, and cause the paint to peel.

Cleaning the Housing and the Remote Control

1. Use a soft cotton cloth for cleaning.

2. If the housing or remote control is seriously contaminated, use a soft cloth moistened with diluted neutral cleaner to clean the display. Wring water out of the cloth before cleaning to prevent water from penetrating into the housing. Wipe the display with a dry cloth after cleaning.

Cleaning the Screen

1. Use a soft cotton cloth to gently clean the screen.

2. The screen glass is very fragile. Do not scrape it with any sharp object. Do not press or tap the screen to avoid cracking. When the screen is seriously contaminated, use a soft cloth moistened with diluted neutral cleaner to clean the display. Wring water out of the cloth before cleaning to prevent water from penetrating into the housing. Wipe the display with a dry cloth after cleaning.

VIZIO L30 WGUe User Guide

4.2 - Troubleshooting Guide

If the display fails or the performance changes dramatically, check the display in accordance with the following instructions. Remember to check the peripherals to pinpoint the source of the failure. If the display still fails to perform as expected, contact the dealer for assistance.

Problem Solution There is not any power. Make sure the AC power button is ON, DC power button is ON

(Green LED). Make sure AC power cord is securely connected to the AC socket. Plug another electrical device (like a radio) to the power outlet to verify that the outlet is supplying the proper voltage.

There is not any sound.

Check your audio connection Press MUTE on the remote control again, so that MUTE disappears from the screen Check your audio settings, your TV audio may be set to SAP or minimum Press the Volume + (Up) key on your remote control Make sure that headphones are not connected

Version - 4/7/2005

VIZIO L30 WGUe User Guide

Snow appears on screen

Power is ON but no screen image. Make sure the video cable supplied with the LCD display is tightly

Wrong or abnormal colors appear. If any colors (red, green, or blue) are missing, check the video cable

Control buttons do not work. Press only one button at a time. Remote Control does not work.

There appears to be image quality issues.

You cannot see a picture. Make sure that the power cord is plugged into a grounded electrical

You see a distorted picture or hear unusual sound.

The picture has abnormal patterns. Make sure that the input source cable is attached securely and

The display image does not cover the entire screen.

You can see a picture but you cannot hear sound.

The LCD TV has pixels that are always bright, dark, or colored.

You see “noise” or “trash” on the screen.

You switch to a different input and the volume changes. You switch to a different input and the screen size changes.

Check your antenna connection. Check TV / CATV selection.

secured to the video output port on the back of the computer. If the other end of the video cable is not attached permanently to the LCD display, tightly secure it to the LCD display. Adjust brightness and contrast. If you are using a Macintosh older than G3, you will need a Macintosh adapter. Check Source settings.

to make sure it is securely connected. Loose or broken pins in the cable connector could cause an improper connection. Connect the LCD display to another computer.

Make sure batteries are inserted correctly Batteries could be weak. TV: For best image quality, “Standard Definition” TV should be viewed as 4:3. COMPONENT 480i: For best image quality the “YCbCr” Input should be used.

outlet. Make sure that the power button is turned on. Make sure that the selected input source is connected to a working input source. If your LCD TV is connected to your computer in VGA or DVI mode, press any key on your keyboard to “wake” your computer.

You may be getting interference from electrical appliances, cars, motorcycles, or fluorescent lights. Try moving your LCD TV to another location.

correctly to the back of your LCD TV. Make sure that the video input source is within the range of your LCD TV. Compare the video input source’s specifications with your LCD TV specifications. If you are using VGA mode, make sure that H Size and V Position in the OSD are set correctly. If you are using TV, AV1, AV2/S, or component (DVD or HDTV) with 480i input, use the WIDE button on the remote control to scroll through various screen modes. Make sure that the volume is not turned down. Make sure that the sound is not muted. Make sure that your audio input source cables are connected securely and correctly. Your LCD TV is manufactured using an extremely high level of precision technology. However, sometimes some pixels of your LCD TV may not display. Pixel defects within industry specifications are inherent to this type of product and do not constitute a defective product. When your LCD TV’s digital capabilities exceed a digital broadcast signal, the signal is up-converted (increased) to match your LCD TV’s display capabilities. Up-converting can cause noise or trash. The LCD TV remembers the volume level from the last time you used a particular input (AV1, AV2/S, DVD, HDTV, and TV). The LCD TV remembers the viewing mode from the last time you used a particular input (AV1, AV2/S, DVD, HDTV, and TV).

Version - 4/7/2005

VIZIO L30 WGUe User Guide

The PIP input is set to DVD but the picture does not look correct.

The LCD TV will not accept the parental control password.

Tips for High-Definition Users The LCD TV is an ideal platform for viewing High Definition Content.

Tips for Letterbox Content Users Letterboxed (or “Widescreen”) versions of DVD movies are most

The PIP DVD source must be 480i (interlaced) and not 480p (progressive scan). Set your DVD player to interlaced or choose a different PIP source. To reset the parental control password:

1. Use the remote control to access the Parental Controls OSD menu. When prompted for the password, use 0317.

2. Set the password using the steps in Section 3.5.5 - Setting a Password, page 31.

Best Image Quality will be achieved by the DVI Input, then YPBPR, then RGB. However, due to variances in broadcast practices, it is possible some image distortions can occur.

commonly formatted for standard 4:3 Televisions. The LCD TV has the capability of expanding this content so the entire screen is filled at the expense of image accuracy. To use this function, press the “ZOOM” key on the RCU and cycle among the available options.

Version - 4/7/2005

VIZIO L30 WGUe User Guide

4.3 - Telephone & Technical Support

Products are often returned due to a technical problem rather than a defective product that may result in unnecessary shipping charges billed to you. Our trained support personnel can often resolve the problem over the phone. For more information on warranty service or repair, after the warranty period, please contact our Support Department at the number below.

Quality service and consistent technical support are integral parts of V's commitment to service excellence. V's service representatives are dedicated to assist you with the utmost in customer satisfaction. To better assist you, please call toll free or contact us via email.

Tel: (714) 668-0588, 7:30 am – 5:30 pm PST Mon - Fri

E-mail: techsupp@vinc.com

VIZIO

320A Kalmus Drive

Costa Mesa, CA 92626

Tel: (714) 668.0588 Fax: (714) 668-9099

Web: www.vizioce.com

4.4 - Compliance

Caution: Always use a power cable that is properly grounded. Please use the AC cords listed below for each area.

USA UL Canada CSA Germany VDE Britain BASE/BS Japan Electric Appliance Control Act

4.5 - FCC Class B Radio Frequency Interference Statement

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

Notice:

1. The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.

3. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modification to this equipment. It is the responsibilities of the user to correct such interference.

Version - 4/7/2005

V INC. LIMITED WARRANTY

For VIZIO LCD Displays

Welcome to the V, Inc. Digital Family! Please read this warranty carefully, it is a “ONE-YEAR LIMITED WARRANTY” on parts and labor.

V, Inc.’s Responsibility

V, Inc. LCD Displays purchased in the United States are warranted to be free from defects in materials or workmanship for a period of one (1) year from the date of their original retail purchase. If the unit fails to conform to this warranty, we will service the monitor using new or refurbished parts.

Service Labor

During a period of one year from the effective warranty date, V, Inc. will provide, when needed, service labor to repair a manufacturing defect at its designated Service Center. To obtain warranty service in the Untied States, you must first call our Customer Support at (714) 668-0588, 9:00am-5pm PST. The determination of service will be made by V, Inc. Customer Support. . PLEASE DO NOT RETURN YOUR UNIT TO V, INC. WITHOUT PRIOR AUTHORIZATION.

Parts

New or remanufactured replacements for defective parts will be used for repairs by V, Inc. at its designated Service Center for one (1) year from the effective warranty date. Such replacement parts are warranted for the remaining portion of the original warranty period.

Service

During the one (1) year warranty period, V, Inc. will, at its option and sole discretion, repair or replace defective parts, including replacement of the entire LCD Panel. The Customer will be required to ship the unit to the Service Center indicated at the time Customer Support is contacted to make the necessary repairs. You are responsible for all transportation charges to and from the service facility. V, Inc. is not responsible for the de-installation or re-installation of the unit.

Packaging and Shipping Instructions

When you send the product to an authorized V, Inc. service facility you must use the original carton box and packing material or an equivalent as approved by V, Inc.

Not Covered

This warranty does not cover defects, malfunctions or failures resulting from shipping or transit accidents, abuse, misuse, operation contrary to furnished instructions, operation on incorrect power supplies, operation with faulty associated equipment, modification, alteration, improper servicing, tampering or normal wear and tear or TVs on which the serial number has been removed or defaced. Image Sticking caused by operating at excessive brightness levels for extended periods or mishandling are not covered by this warranty.

ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE SHALL BE LIMITED IN DURATION TO THE PERIOD OF TIME SET FORTH ABOVE. OUR LIABILITY FOR ANY AND ALL LOSSES AND DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER, INCLUDING OUR NEGLIGENCE, ALLEGED DAMAGE OR DEFECTIVE GOODS, WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE DISPLAY. WE SHALL NOT BE RESPONSIBLE FOR LOSS OF USE, COMMERCIAL LOSS OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. This is the only warranty applicable; no one is authorized to extend or modify it or to grant any other warranty.

V, Inc. retains the right to assess all warranty claims and to determine if damages are covered by the warranty. In case of a claim that is not covered by the warranty, you will be contacted to determine whether V, Inc. should repair the damage for a fee or whether

Owner’s Responsibility

the product should be returned to you as received by the repair center.

Effective Warranty Date

Warranty begins on the date of sale to the end user. To ensure warranty service, keep the dated bill or sale receipt as evidence of the purchase date.

User Manual

Read your User Manual carefully so that you will understand the operation of your LCD Display and how to adjust the user controls.

Warranty Service

For warranty service information, contact V, Inc. Customer Support at (714) 668-0588, 9:00am-5pm PST. Parts and service labor that are V, Inc.’s responsibility (see above) will be provided without charge. Other service is at the owner’s expense. You must provide the model, serial number and date of purchase. Before you ask for warranty service, read your User Manual. You might avoid a service call.

For Technical Support, visit WWW.VIZIOCE.COM, Call (714) 668-0588

or E-mail Techsupp@vinc.com

Appendix B: Component Program Codes SETUP CODES FOR AMPLIFIERS

Aiwa 0406 Carver 0269 CurtisMathes 0300 Denon 0160 Harman/Kardon 0892 JVC 0331 Linn 0269 Magnavox 0269 Marantz 0269

SETUP CODES FOR CABLE

ABC 0003,0008,

0014,0017,

0007,0011, 0013 Allegro 0153,0315 Archer 0153,0797 Bell&Howell 0014 Century 0153 Citizen 0153,0315 Comtronics 0040 Contec 0019 Eastern 0002 Emerson 0797 Everquest 0015,0040 Focus 0400 Garrard 0153 Gemini 0015,0797 General Instrument 0476,0276, 0011,0810 GoldStar 0144,0040 Goodmind 0797 Hamlin 0020,0259, 0009,0034 Hitachi 0011 Hytex 0007 Jasco 0015,0153, 0315 Jerrold 0003,0012,0476,0276,

0014,0015, 0011,0810 Memorex 0000 MovieTime 0063 NSC 0063 Oak 0019,0007 Optimus 0021 Panasonic 0000,0107, 0021 Paragon 0000

SETUP CODES FOR CD PLAYERS

Aiwa 0157,0124 Burmester 0420 California Audio Labs 0029,0303 Carver 0157,0179, 0437 DKK 0000 Denon 0003,0873 Emerson 0305 Fisher 0179,0174 Garrard 0420,0393 Genexxa 0032,0305 Harman/Kardon 0157,0173 Hitachi 0032 JVC 0072 Kenwood 0028,0037,

0190,0626, 0826,0681 Krell 0157 LXI 0305 Linn 0157 MCS 0029 MTC 0420 Magnavox 0157,0305 Marantz 0029,0157, 0180 Mission 0157 NSM 0157 Nikko 0174 Onkyo 0101,0868

Optimus 0300 Panasonic 0308 Philips 0269,0892 Pioneer 0013,0300 Sony 0220,0689 Technics 0308 Victor 0331 Wards 0013 Yamaha 0354

Philips 0153 Pioneer 0144,0533, 0877 Popular Mechanics 0400 Pulsar 0000 Quasar 0000 RCA 0021 RadioShack 0015,0315, 0797,0883 Recoton 0400 Regal 0020,0259 Regency 0002 Rembrandt 0011 Runco 0000 SLMarx 0040 Samsung 0144,0040 Scientific Atlanta 0008,0477, 0017,0877 Signal 0015,0040 Signature 0011 Sprucer 0021 Starcom 0003,0015 Stargate 0015,0040, 0797 Starquest 0015 TV86 0063 Teleview 0040 Tocom 0012,0013 Toshiba 0000 Tusa 0015 Unika 0153 UnitedArtists 0007 Universal 0153,0191 Viewstar 0063 Zenith 0000,0525 Zentek 400

Optimus 0000,0032,

Panasonic 0029,0303 Parasound 0420 Philips 0157,0626 Pioneer 0032,0305, 0468,0244 Proton 0157 QED 0157 Quasar 0029 RCA 0179,0305, 0053,0764 Realistic 0179,0420, 0180 Rotel 0157,0420 SAE 0157 Sansui 0157,0305 Sanyo 0179 Scott 0305 Sears 0305 Sharp 0037,0180, 0861 Sherwood 0180 Sony 0000,0185, 0490 Soundesign 0145 Tascam 0420 Teac 0420,0393, 0174,0180 Technics 0029,0303 Victor 0072 Wards 0157,0053 Yamaha 0036,0187 Yorx 0461

VIZIO L30 WGUe User Guide

0179,0305, 0037,0420, 0145,0468, 0437

Version - 1/21/2005

SETUP CODES FOR LASER DISK

Denon 0059 Mitsubishi 0059 NAD 0059 Optimus 0059 Pioneer 0059 Sony 0193,0201

SETUP CODES FOR MISC. AUDIO

Jerrold 0459,0520 Scientific Atlanta 0460 Starcom 0459

SETUP CODES FOR RECEIVERS

ADC 0531 Aiwa 0158,0189,0121, 0405 Capetronic 0531 Carver 0189,0042,0360 Casio 0195 Clarinette 0195 Curtis Mathes 0080 Denon 0004 Emerson 0424 Fisher 0042,0219,0360 Garrard 0463,0424 Harman/Kardon 0110,0189,0891 JBL 0110 JVC 0074 Kenwood 0027,0186,0042 Koss 0424 LXI 0181 Linn 0189 Lloyd's 0195 MCS 0039 Magnavox 0531,0189,0195, 0391 Marantz 0039,0189 Modulaire 0195 NAD 0320 Nakamichi 0097 Onkyo 0135

SETUP CODES FOR SATELLITE

AlphaStar 0772 Echostar 0775 Expressvu 0775 General Instrument 0627,0361,0869 HTS 0775 Hitachi 0819 Hughes Network Systems 0749 JVC 0775 Jerrold 0627,0361 Magnavox 0724,0722 Memorex 0724

Optimus 0531,0670,0186,

Panasonic 0039,0309 Penney 0195 Philips 0189,0391 Pioneer 0531,0014,0150,

Quasar 0039 RCA 0531,0054,0360 Realistic 0195,0181 Sansui 0189 Sanyo 0219,0801 Sharp 0186 Sherwood 0491,0502 Sony 0158,0474 Soundesign 0670 Teac 0463 Technics 0039,0309 Victor 0074 Wards 0158,0014,0189,

Yamaha 0176,0186 Yorx 0195 Zenith 0857

Next Level 0869 Panasonic 0701 Philips 0724,0722 Primestar 0627,0361 RCA 0566,0143,0392,0855 Radio Shack 0869 Sony 0639 Star Choice 0869 Toshiba 0749,0790 Uniden 0724,0722 Zenith 0856

VIZIO L30 WGUe User Guide

0080,0042,0181, 0219,0738,0801, 1023

0630,0080,1023

0080,0054

Version - 1/21/2005

SETUP CODES FOR TELEVISION

AOC 0030,0019 Admiral 0093,0463 Aiko 0092 Akai 0030 Alaron 0179 America Action 0180 Ampro 0751 Anam 0180 Audiovox 0451,0180,0092,0623 Baysonic 0180 Belcor 0019 Bell & Howell 0154,0016 Bradford 0180 Brockwood 0019 Broksonic 0236,0463 CXC 0180 Candle 0030,0056 Carnivale 0030 Carver 0054 Celebrity 0000 Cineral 0451,0092 Citizen 0060,0030,0056,

0039,0092 Concerto 0056 Contec 0180 Craig 0180 Crosley 0054 Crown 0180,0039 Curtis Mathes 0047,0054,0154,0051, 0451,0093,0060,0030, 0145,0056,0016,0039, 0166,0466,1147,1347 Daewoo 0451,0019,0039,

0092,0623,0624 Daytron 0019 Denon 0145 Dumont 0017,0019 Dwin 0720,0774 Electroband 0000 Emerson 0154,0236,0463,0180,

0282,0178,0019,0179,

0039,0623,0624 Envision 0030 Fisher 0154 Fujitsu 0179 Funai 0180,0179,0171 Futuretech 0180 GE0 047,0051,0451,0093,

0282,0178,0021,1147,

1347 Gibralter 0017,0030,0019 Gold Star 0030,0178,0019,0056 Gradiente 0053,0056 Grunpy 0180,0179 Hallmark 0178 Harley Davidson 0179 Harman/Kardon 0054 Harvard 0180 Hitachi 0145,0056,0016 Infinity 0054 Inteq 0017 JBL 0054 JCB 0000 JVC 0053 KEC 0180 KTV 0180,0030,0039 Kenwood 0030,0019 LG0 056 LXI 0047,0054,0154,0156,

0178 Logik 0016 Luxman 0056 MGA 0150,0030,0178,0019 MTC 0060,0030,0019,0056 Magnavox 0054,0030,0179 Majestic 0016 Marantz 0054,0030 Matsushita 0250

Megatron 0178,0145 Memorex 0154,0250,0463,0150,

Midland 0047,0017,0051,0039 Minutz 0021 Mitsubishi 0093,0150,0178,0019 Motorola 0093 Multitech 0180 NAD 0156,0178,0166 NEC 0030,0019,0056 NTC 0092 Nikko 0030,0178,0092 Onwa 0180 Optimus 0154,0250,0166 Optonica 0093,0165 Orion 0236,0463,0179 Panasonic 0051,0250 Penney 0047,0156,0051,0060,

Philco 0054,0463,0030,0145, Philips 0054

Pilot 0030,0019,0039 Pioneer 0166 Portland 0019,0039,0092 Prism 0051 Proscan 0047 Proton 0178,0466 Pulsar 0017,0019 Quasar 0051,0250,0165 RCA 0047,0051,0093,0019,

RadioShack 0047,0154,0165,0180,

Realistic 0154,0165,0180,0030, Runco 0017,0030,0603

SSS 0180,0019 Sampo 0030,0039 Samsung 0060,0030,0178,0019,

Samsux 0039 Sansei 0451 Sansui 0463 Sanyo 0154 Scimitsu 0019 Scotch 0178 Scott 0236,0180,0178,0019,

Sears 0047,0054,0154,0156, Semivox 0180

Semp 0156 Sharp 0093,0165,0039 Shogun 0019 Signature 0016 Sony 0000 Soundesign 0180,0178,0179 Squareview 0171 Starlite 0180 Supreme 0000 Sylvania 0054,0030 Symphonic 0171 TMK 0178,0056 Tandy 0093 Technics 0051,0250 Technol Ace 0179 Techwood 0051,0056 Teknika 0054,0180,0150,0060,

Telefunken 0056 Toshiba 0154,0156,0060 Totevision 0039 Vector Research 0030

VIZIO L30 WGUe User Guide

0178,0056,0016

0030,0178,0021,0019, 0056,0039,1347

0019

0090,1047,1147,1247, 1347

0030,0178,0019,0056, 0039

0178,0019,0056,0039

0056

0179 0178,0179,0056,0171

0019,0179,0056,0016, 0039,0092

Version - 1/21/2005

VIZIO L30 WGUe User Guide

Victor 0053 Vidikron 0054 Vidtech 0178,0019 Wards 0054,0165,0030,0178,

0021,0019,0179,0056,

0016

SETUP CODES FOR VCR

Admiral 0048,0209 Adventura 0000 Aiko 0278 Aiwa 0037,0000 Akai 0041 America Action 0278 American High 0035 Asha 0240 Audiovox 0037 Beaumark 0240 Bell & Howell 0104 Broksonic 0184,0121,0209,0002 CCE 0072,0278 Calix 0037 Canon 0035 Carver 0081 Cineral 0278 Citizen 0037,0278 Colt 0072 Craig 0037,0047,0240,0072,

0271 Curtis Mathes 0060,0035,0041,0162 Cybernex 0240 Daewoo 0045,0278 Denon 0042 Dynatech 0000 Electrohome 0037 Electrophonic 0037 Emerex 0032 Emerson 0037,0184,0000,0121,

0043,0209,0002,0278 Fisher 0047,0104 Fuji 0035,0033 Funai 0000 GE 0060,0035,0048,0240 Garrard 0000 GoVideo 0526 GoldStar 0037,0038 Gradiente 0000 HI-Q 0047 Harley Davidson 0000 Harman/Kardon 0081,0038 Harwood 0072 Headquarter 0046 Hitachi 0000,0042,0041 Hughes Network Systems 0042 JVC 0067,0041 Jensen 0041 KEC 0037,0278 KLH 0072 Kenwood 0067,0041,0038 Kodak 0035,0037 LXI 0037 Lloyd's 0000 Logik 0072 MEI 0035 MGA 0240,0043 MGN Technology 0240 MTC 0240,0000 Magnasonic 0278 Magnavox 0035,0039,0081,0000,

0149 Magnin 0240 Marantz 0035,0081 Marta 0037 Matsushita 0035,0162,0454 Memorex 0035,0037,0048,0039,

0047,0240,0000,0104,

0209,0046,0454,1162,

1262 Minolta 0042

White Westinghouse 0463,0623,0624 Yamaha 0030,0019 Zenith 0017,0463,0016,0092,

Mitsubishi 0048,0067,0043 Motorola 0035,0048 Multitech 0000,0072 NEC 0104,0067,0041,0038 Nikko 0037 Noblex 0240 Olympus 0035 Optimus 0037,0048,0104,0162,

Orion 0184,0209,0002 Panasonic 0035,0162,0225,0454,

Penney 0035,0037,0240,0042, Pentax 0042

Philco 0035,0209 Philips 0035,0081 Pilot 0037 Pioneer 0067 Profitronic 0240 Proscan 0060 Protec 0072 Pulsar 0039 Quarte 0046 Quartz 0046 Quasar 0035,0162,0454,1162 RCA 0060,0035,0048,0240,

RadioShack 0000 Radix 0037 Randex 0037 Realistic 0035,0037,0048,0047,

Runco 0039 STS 0042 Samsung 0240,0045 Sanky 0048,0039 Sansui 0000,0067,0209,0041,

Sanyo 0047,0240,0104,0046 Scott 0184,0045,0121,0043 Sears 0035,0037,0047,0000,

Semp 0045 Sharp 0048 Shintom 0072 Shogun 0240 Singer 0072 Sony 0035,0032,0000,0033 Sylvania 0035,0081,0000,0043 Symphonic 0000 TMK 0240 Tatung 0041 Teac 0000,0041 Technics 0035,0162 Teknika 0035,0037,0000 Thomas 0000 Toshiba 0045,0043 Totevision 0037,0240 Unitech 0240 Vector 0045 Vector Research 0038 Video Concepts 0045 Videosonic 0240 Wards 0060,0035,0048,0047,

White Westinghouse 0209,0278 XR-1000 0035,0000,0072 Yamaha 0038 Zenith 0039,0000,0209,0033

0624

0454,1062,1162,1262

1062,1162,1262 0038

0042,0149

0000,0104,0046

0271

0042,0104,0046

0081,0240,0000,0042, 0072,0149

Version - 1/21/2005

SETUP CODES FOR DIGITAL VIDEO DISC

Denon 0490 GE 0522 Harman/Kardon 0582 JVC 0558 Kenwood 0534 Magnavox 0503 Marantz 0521 Onkyo 0503 Optimus 0571 Panasonic 0490 Philips 0503,0539 Pioneer 0525,0571 Proscan 0522 RCA 0522 Samsung 0573 Sony 0533 Technics 0490 ThetaDigital 0571 Toshiba 0503 Yamaha 0490,0545 Zenith 0503,0591

VIZIO L30 WGUe User Guide

Version - 1/21/2005

WHERE

VISION

MEETS

VALUE

BRAVO, VIZIO and the V Logo are trademarks of V, Inc. Product specifications are

Vizio L30 WGUe User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
