CHAPTER 1INTRODUCTION

This guide is designed to provide users with the necessary information to install and manage the
Vixel InSpeed™ SAN Storage Switch Model 375 for use in Fibre Channel applications in typical
entry-level Storage Area Networks (SANs).

OVERVIEW

The Vixel InSpeed™ SAN Storage Switch Model 375 is designed for entry-level Storage Area
Networks (SANs), which provide the following advantages over direct attached storage:

• Greater application availability

• Higher performance between servers and storage devices

• Improved storage asset utilization

• Lower storage management and support costs

• Incremental scalability to keep up with difficult to estimate storage growth

This switch is ideal for storage pooling and consolidation, high-performance shared tape library
backup and recovery, server clustering, and streaming rich media applications.

Enclosed in a 1U, full-rack form factor enclosure, the switch is built around the InSpeed™ SOC
320 and is controlled by firmware loaded into the o n-board F lash.

The switch is designed as a central interconnect following the ANSI FC-AL standard. Devices are
connected to the switch through Small Form-factor Pluggable (SFP) transceivers and cables. Each
attached node has 1 or 2 Gigabits per second (Gb/s) of Fibre Ch annel bandwidth. The swi tch
operates at full switching bandwidth that reaches speeds of 4 GB/s per port and up to 80 Gb/s of
aggregate bandwidth.

Complete switch configuration and management is available through the intuitive, graphical­based Web Manager interface. A v a riety of network c onfigu r ations are easily establis hed us ing the
switch’s Port Smart Settings, One-Step Zoning, Automatic Trunking, and Load Balancing features.
In addition, the switch features granular chan ge notification man agement, retaine d system
configuratio n parame ters , and a Comma nd Line Inte rfac e (CL I) for advance d users .

Overview.................... ....... ...... ....... ............ 1

Features ........................... ...... ................... 2

InSpeed™ Technology .................................. 2

Switch Applications............. ...... ....... ...... ...... 3

Note: Important safety, electromagnetic compatib ility, and regulatory infor mat ion is conta ined in

the Vixel Safety & Regulatory Guide. The i nsta llat ion a nd u se o f th is produ ct m ust be in
accordance with the information provided in that guide.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 1 INTRODUCTION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 2

FEATURES

The Vixel InSpeed™ SAN Storage Switch Model 375 has the following features:

• High Performance Fibre Channel Switching:

• Wi re speed non-block ing Crossb ar switch core

• Single 20-port Vixel InSpeed SOC 320 ASIC with embedded SERDES

• Multiple simultaneous conversations between ports

• Traffic routed directly to destination ports

• 2 Gb/s or 1 Gb/s perf ormance a cross all ports

• Aggregate bandwidth of 80 Gb/s

• Supports cascades up to 3 switches and up to 126 host and storage devices

• No complex fabric services or buffers

• Ef fortless ly conne cts to any vendor ’s fabric

• Patent-pend in g tech nol ogy :

• Fairness and Prioritization–ensures devices all have guaranteed access, or
explicitly have prioritized access, over all other devices in a system.

• Stealth

TM

Intelligent Change Manager–delivers maximum stability through
automatic elimination of state and change notific ation system disruption s and
unprecedented control of disruptive events.

• Automatic Trunking–enables fully-multiplied throughput and bandwidth, failover
pathing, and dynamic load balancing and device prioritization.

• Advanced diagnostics, performance monitoring, and fault isolation including continuous
switch an d por t mon itor ing and au toma tic bypass of problematic or unused ports.

• Port Smart Settings, which are predefined port-level configurations that optimize switch
performance and stability.

• One-Step Zoning, including overlapping/non-overlapping zones with port or AL_PA-based
zoning.

• Switch management us ing the embedded http-based web server, Command Line Interface
(CLI), or Simple Network Management Protocol (SNMP).

• Full-rack, 1U size for easy installation (optional 19" rack-mounting kits available).

• Redundant fans and two hot-swappable, auto-sensing, load sharing, universal power
supplies for high availability.

• Fibre Channel ANSI Standards Compliance

INSPEED™ TECHNOLOGY

Vixel’s InSpeed™ technology is an advanced switching architecture that couples a non-blocking
crossbar switch with a uniqu e swi tch po rt log ic a nd per-por t SE RDES . T his re sults in the indu stry’s
highest density Fibre Channel switch on a chip (SOC). The port logic is based on Fibre
Channel-Arbitrated Loop (FC-AL), an ANSI standard (X3T11) designed to provide shared
bandwidth over low-cost media.

This architecture enables the sw itch’s router to send data directly fro m one port to another,
allowing for multiple, simultan eous conversations betw een ports—eff ectively multiply ing
bandwidth. InSpeed™ provides the same performance as complex fabric switches that support
FC-SW2. InSpeed™ can even exceed fabric switch performance in entry-level SAN environments,
where the overhead associated with longer name addressing and services is not beneficial.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 1 INTRODUCTION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 3

SWITCH APPLICATIONS

The Vixel InSpeed™ SAN Storage Switch Model 375 is ideal for consolidation and shared storage
pooling, high-performance shared tape library backup and recovery, server clustering, and
streaming rich media applications. The following sections provide examples of these applications.

Storage Consolidation and Shared Storage Pooling

In this configuration, the switch enables multiple hosts to share single or multiple storage
systems. This application replaces direct-attached configurations that require multiple storage
systems to be attache d to separate s ervers, which ofte n resu lts in diffi cult t o ma nage mu ltipl e
systems and trapped, unused storage islands (storage cannot be shared with other servers).

Benefits include:

• Improved incremental scalability–connect up to 20 hosts and/or other storage devices,
including tape libraries, to a single switch.

• Lower storage management support costs.

• Improved capacity utilization that enables effective use of both servers and storage.

For larger system environments, multiple switches can be connected and Automatic Tr unking can
be used to keep performance and availability at high levels. As a best practice when using
multiple switches, co nnect s ervers and th eir rel ated s torage devi ces t hrough the sa me s witch to
optimize performance.

Figure 1-1: Before storage consolidation...

and after storage consolidation.

Figure 1-2: Multiple switch storage consolidation diagram

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 1 INTRODUCTION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 4

Figure 1-2 depicts a sample multiple switch storage consolidation configuration in which multiple
servers communicate with storage devices an d zoning is incorpo rated. The zoning i n Figure 1-2
might be set up to configure a multiple operating sy stem environment. For example, Z one 1 mi ght
be Windows-based, Zone 2 might be Linux-based, and Zone 3 might be Unix-based. Zoning can
also be used to improve security by masking storage devices or fil es. For example, a finance
department could secu re f inancia l files from view ing by th e engineering department, wh ich in turn
could secure engineering files from viewing by the finance department.

Tape Library Consolidation

Another switch application is the consolidation of multiple tape libraries attached to individual
servers into a single library for all servers for backup and restore purposes.

Benefits include:

• Improved cost effectiveness.

• Improved availability for performing system backups:

• Of f-LAN System Backups o ften reduce the amount of time it takes backups (and
recovery) to occur because SANs run at higher performance bandwidth than LANs.

• Server-less backups enable applications to remain fully active during backup and
recovery processes, when combined wit h the appropriate backu p software
solution.

Figure 1-3 depicts a sample tape library consolidation configuration.

Figure 1-3: Before consolidation, backup and restore
data must travel on the LAN, congesting traffic and
operating at slow speeds.

After consolidation, backup and
restore data travels on the high speed
SAN separate from LAN traffic.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 1 INTRODUCTION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 5

Rich Media

For rich media applications, the switch provides improved storage and file sharing from a single
storage pool for multiple workstations.

Figure 1-4 depicts a sample rich media configuration.

Server Clustering

In this configuration, the switch helps deliver improved application availability when combined
with a server clustering software solutio n, like Microsoft Clu ster Server or Veritas Cluster Server.
This prevents system downtime in case of failure to one of the application servers.

Figure 1-5 depicts a sample server clustering configuration.

Figure 1-4: Rich media diagram

Figure 1-5: Server clustering diagram

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 6

CHAPTER 2SWITCH INSTALLATION

INSTALLATION PREPARATION

After receiving the switch, perform the fo llowing steps to ensu re the switch and other contents
arrived safely.

To unpack the switch:

1. Inspect the outer shipping container for any damage that may have occurred in shipping.
Report any sign of damage to the appropriate shipping agency.

2. Remove the switch and cables from the shipping container; save the shipping container,
foam, and antistatic bags—returning the switch in any other container is not advised.

Make sure the followin g part s are incl uded:

• Switch unit

• RS-232 null-modem serial cable

•Power cables (2)

• Self-adhesive pads (4)

• Retentio n cli ps (2), sc rews (4) , and was hers (4) for s ecur ing the power c ords t o
the switch.

• Vixel InSpeed™ SAN Storage Switch Model 375 Quick Install Card

•Product Release Notes

• Vixel Safety and Regulatory Guide

• Additional documentation, including warranty information and the End User
License Agreement.

3. Inspect the switch thoroughly. (If any signs of damage are seen, notify a sales
representative and/or the shipping agency.)

Installation Preparation ............. ....... ............ 6

Switch Installation....................................... 7

Switch LEDs ............................................... 9

SFP Compatibility ........ ............. ............. .... 12

Booting the Switch and SAN.............. ...... .... 13

Power Supply/Fan Module Replacement ........ 14

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 7

SWITCH INSTALLATION

The switch may be placed on a desktop or installed in a rack.

Desktop Installation

To place the switch on a desktop:

1. Turn the switch upside down so the case bottom is fac ing up.

2. Install a self-adhesive pad (included) on each corner of the switch bottom approxi mately 1
inch from each side (prevents surface damage ).

3. Turn the switch right-side up so t h e case bottom is facing down and place the switch on a
stable table or platform.

For information on environmental requirements, see “Operating Conditions” on page 62.

Rack Installation

Installing the switch in an equipment rack requires an optional rack mount kit (sold separately).
There are two kit variations currently available:

• 24-inch Full Rack Mount Kit (Part Number 00651382), which supports equipment rack
depths from 22 to 29 inches.

• 30-inch Full Rack Mount Kit (Part Number 00651383), which supports equipment rack
depths from 29 to 36 inches.

The rack mount kit incl udes al l th e ne cessary har dware an d instal lati on inst ructi ons f or prope rly
installing a switch into an equipment rack. Contact a sales representative for more information or
assistance in purchasing a kit.

UL Guidelines for Mounting Equipment in a Rack

When installing equipment in a rack, give careful consideration to the following factors:

• The operating ambient temperature of rack-mounted equipment must not exceed the
maximum rated ambient temperature, which is indicated in this installation guide. (See
“Operating Conditions” on page 62.)

• The air flow clearances specified in this installation guide must be maintained within the
rack. (S ee “ Op era tin g Co nd it ion s” on pa ge 62.)

• The AC supply circuit f or rack-mounte d equ ipment must be capabl e of supplying the tot al
current specified on all the labels of the rack-mounted equipment.

• All AC power supply connections must be properly earthed. To ensure the integrity of the
earth connection, special attention must be given to connections that are not directly
connected to the branch circuit (for example, power strips).

• The rack-mounting hardware has been carefully selected to properly support the
equipment. Any alternate rack-mounting hardware must provide equal or superior
support.

Note: Important safety, electromagnetic compa tibili ty, and regulatory inf orm ation is

contained in the Vixel Safety & Regulatory Guide. The installation and use of
this product mu st be in accor dance with the inf ormat ion given in that guid e.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 8

Installing the Retention Clips (optional)

The switch ships with two, optional retention clip s to secure the pow er cords in each power
supply/fan module’s power receptacle. Screws (4) and washers (4) are provided for the clips.

To install the retention clip:

1. Secure the retention clip to the switch by aligning the retention clip with the two screw
holes located to the left and the right of the module’s power receptacle. The retention clip
mounting loops should be facing do wnward.

2. Place the washer on the screw prior to inserting the screw through the retention clip’s
mounting l oop.

3. Using a screwdriver, tighten the screws to secure the retention clip to the power supply/
fan module.

To insert the power cord with the retention clip in place:

1. Insert the power cord plug into the module’s power receptacle. The plug must initially be
inserted into the receptacle at an angle to avoid the retention clip.

2. Once the power cord plug is firmly inserted in the module’s power receptacle, the
retention clip fastens over the end of the power cord plug to secure it in the power
receptacle.

To remove the power cord with the retention clip in place:

Press down on the retention clip while removing the power cord from the module’s power
receptacle.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 9

SWITCH LEDS

The switch incorporates four sets of Light-Emitting Diodes (LEDs) to indicate ethernet, switch,
port, and power supply/fan module status:

1. Ethernet LEDs – two separate LEDs indicating the network connection status.

2. System LEDs – four separate LEDs indicating the switch ’s status.

3. Port LEDs – two LEDs per port indicating the port’s status.

4. Power Supply/Fan LED – a separate LED for each power supply/fan module indicating the
power supply/fan module’s status.

Ethernet LEDs

The Ethernet LEDs indicate the network connection status:

Ethernet LEDs Indication

Ethernet Activity
(green LED)

• When flashing, the ethernet port is receiving data.

• When flashin g rapidly, the traffic level is high.

Ethernet Link
(green LED)

When lit, the switc h is conn ected to an op erationa l ethern et.

Figure 2-1: Switch View Depicting Ethernet, Port, and System LEDs

Port L ED s

Ethernet LEDs

System L EDs

Figure 2-2: Switch View Depicting Power Supply/Fan LED

Power S upp ly /Fan L ED

Power S upp ly /Fan LE D

Figure 2-3: Ethernet LEDs

Ethernet Activity

Ethernet Link

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 10

System LEDs

The System LEDs indicate the switch’s status, independent of the port LEDs.

Port LEDs

The Port LEDs indicate the port’s status. Each port has two LEDs:

•SFP Status LED

•Port Bypassed LED

System LEDs Indication

Fault
(yellow LED)

• Wh en lit, on e or m ore o f the port s has faile d or t he in ter nal tem peratur e h as
exceeded acceptable levels.

• When flashin g, all ports are operational but another error has occurred. Errors
appear in an event log. The level of error severity that will cause flashing to start
can be controlled using the config sys fault command i n the CLI. T he default is
level 3, Critic al.

Note: Whether lit or flashing, the switch will continue to operate. Switch functionality
may be impaired depending on the e vent that trigge red th e Fault LED. Regardless of
the cause, the switch requires imm edia te a ttention .

Power
(green LED)

When lit, the switch is plugged in and the internal power supplies are functional.

2 Gb/s
(green LED)

When lit, the switch is set to o perate a t a spee d of 2 G b/s. Wh en of f, the switch is
set to 1 Gb/s.

Switch
Operational
(green LED)

• Wh en lit, in dic ates th at th e s witch ha s co mp lete d ini tiali zatio n f or p orts wi th
inserted SFPs a nd that the switch is operational .

• When flashing, the sw itch has been configured for multiple zones, and one or
more zones are up with at least one zone down.

If no zones (excluding hard zone s) are operational, the L ED turns of f.

SFP Status

LED

(green LED)

Port

Bypassed

LED

(yellow LED)

Indication

Off Off Normal port op eration al sta tus w hen a n SFP i s not in sta lled.
Off On or Flashing The port is bypassed due to a faulty or improperly seated SFP. After

fixing this problem, power may need to be cycled before the LED
indication will change.

Figure 2-4: System LEDs

Power
Switch Operational

Fault

2 Gb/s

Figure 2-5: Ethernet LEDs

SFP Status

Port By pas se d

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 11

Power Supply/Fan Module LED

The switch uses two power supply/fan modules to guarantee high availability with failover. Each
power supply has a separate LED to indicate its condition.

When a power supply or fan fault occurs, the switch will continue to operate normally as long as
the faulty power supply/fan module remains installed in the switch and th ere are at least two fans
operational in each module. If the power supply/fan module is removed from the switch, the
switch will continue to operate normally for approximately 20-30 minutes. However, to guarantee
continued operation, the malfunctioning module should be immediately replaced to maintain high
availability.

Flashing Off Activity. Data is being transferred between the po rt and dev ice.
On Off Normal operation but no activity. Port and device are fully

operational.

On Flashing Manually bypas sed. A po rt can be manu ally bypass ed usi ng the W e b

Manager’s Bypass Port feature.

On On Bypassed. SFP is installed but the port is not receiving a valid signal

or is receiving an F8 Failure notificat ion from the attac hed devic e.

Flashing Flashing Beaconing. This is set manually using the Web Manager or CLI.

Power Supply/Fan Module

LED (green LED)

Indication

On No faults exist and AC power is supplied to the module.
Off A power sup ply or fan fau lt h as occu rre d in t he mod ule .

Note: Keeping spare power supply/fan modules (Part Number 601319) in stock is highly recommended.

Contact a sa les re prese ntati ve for f urth er inform at ion.

SFP Status

LED

(green LED)

Port

Bypassed

LED

(yellow LED)

Indication

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 12

SFP COMPATIBILITY

SFPs are “hot-pl uggable” into the swit ch, which a llows host com pute rs, s ervers, and storage
devices to be added dynamically without requiring power removal from the switch or any
connected devices.

The switch supports Small Form-Factor Pluggable (SFP) modules that comply with the SFP
specification as produced by the MSA consortium and have passed Vixel’s qualification testing.

The following manufacturers of 1-2Gb optical, shortwave SFPs are recommended:

• Finisar

•JDS Uniphase

Contact a customer service representative to request the certified part numbers for these
vendors.

Installing an SFP

If the Chan ge N oti fica ti on on In serti on pol icy i s e nab led, pl ug gin g a n SF P int o t he swi tch will
automatically send an F7 Initialization notification to indicate the device is ready to begin
initialization.

To insert an SFP:

1. Remove dust covers or plugs from the SFPs, if provided.

2. Slide the SFP into the port, ensuring correct polarity, until the latch clicks into place.

Removing an SFP

To extract an SFP:

Determine what kind of extraction mechanism the SFP has and remove the SFP as follows:

If the SFP has a removal tag, remove the cable from the SFP and then pull the removal tag
outward and toward the side of the SFP with the tag.

If the SFP has a small plastic slider on the top or bottom, remove the cable from the SFP and
then push in the slider and hold while pulling out the SFP.

If the SFP has a bale (small metal clasp), remove the cable from the SFP and then unlatch,
pivot, and pull the bale.

Attaching a Device to the Switch

To attach a device:

1. Make sure that the device is FC-AL compatible.

2. Attach a cable to the device.

3. Attach the other end of the cable to an SFP.

4. Make sure that the device and switch are o perational and set to the same sp eed.

Caution: Forcing an SFP into a port may damage the SFP and/or port.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 13

BOOTING THE SWITCH AND SAN

The following procedure is recommended when booting the switch and SAN. Before powering on
the switch and SAN, read the Release Notes, included with the switch contents, to determine any
modifications that may be required for a specific installation.

To boot the switch and SAN:

1. Power on the storage devices (such as JBODs, tape libraries, and RAIDs).

2. Insert the plug end of the switch’s power cord to a properly grounded power source.

3. Insert the power cord’s IEC connector end into the switch’s power receptacle.
The switch powers on a nd runs Power-On Self-Test (POST) diagn ostics t o verif y the

fundamental integrity of the switch ports. All switch LEDs turn on (LEDs illuminate). Then,
excluding the Ethernet Link, Power Supply/Fan Module, and Power LEDs, the LEDs turn off
(LEDs extinguish). Once the switch is op erational, the LEDs display curre nt status as
described in “Switch LEDs” on page 9.

4. Power on any other switches connected to the SAN.

5. For certain applications, switch configuration must be completed befo re continuing with
the next step. For information regarding switch configuration, see Chapter 3: Switch
Management.

6. After all switches have initialized, power on the hosts.
The network initializes.

7. Check all port LEDs.
The SAN should be fully operational at this point. However, it is appropriate to ensure

proper discovery has taken place and all required devices are participating in the network.
Some host bus adapters may provide this level of functionality or it might be resident in
the application software on the host operating system.

Note: The power cord’s IEC connector plug serves as the switch’s disconnect device.

To cycle power to the switch, remove and reconnect the switch’s power cord.

Note: FC-AL compatible nodes must perform initialization procedures upo n power-up

in order to func tion pro perly. It is the responsib ility of the Fib re C hanne l dr iver
software on FC-AL nodes to perfor m this initia lizatio n.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 2 SWITCH INSTALLATION
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 14

POWER SUPPLY/FAN MODULE REPLACEMENT

The Vixel InSpeed™ SAN Storage Swit ch Model 375 has hot -sw appable power supply/fan modules
for high availability. A power supply/fan module consists of an individual power supply and a fan
bank consisting of three fans.

The switch can run on one functi oning pow e r su pply/fan module indefinitely, as long as the faulty
power supply/fan module remains installed in the switch and there are at least two fans
operational in each module’s fan bank. If the power supply/fan module is removed from the
switch, the switch will continue to operate normally for approximately 20-30 minutes. Non­functional modules should be immediately replaced to maintain high availability.

To remove an old power supply/fan module:

1. Have the new power supply/fan module clo se to the switch fo r quick inser tion. (This st ep
ensures that the pr ocedu re takes no lon ger t han n ecessa ry—the sw itch can only o perate
with one power supply/fan module installed for approximately 20-30 minutes.)

2. Unplug the power cord from the faulty module’s power receptacle.

3. Slide the safety latch over the power receptacle to expose the thumb screw.

4. Loosen the two thumb screws. No tools are required.

5. Pull the unscrewed power supply/fan module out of the switch’s module bay using the
module’s handl e.

To insert a new power supply/fan module:

1. Align the power supply/fan module with the module bay o pening. Ensu re th e warnin g label
is facing up war ds o n t h e mo du le.

2. Carefully slide the module into the opening. Ensure the module is seated firmly in the
module bay (the module should be flush with the switch’s face).

3. Tighten the two thumb screws. No tools are required.

4. Slide the safety latch over the thumb screw (uncovering the power receptacle).

5. Plug the power cord into the module’s module power receptacle.

Note: Keeping spar e power su pply/ fan mod ules (Part N umbe r 60131 9) in stoc k is highl y

recommended. Con tact a sale s represe ntative for fur ther infor mation.

Note: The alternate power supply/fan module should remain powered on while the

faulty module is removed and replaced to guarantee switch availability.

WARNING

To avoid an electrical hazard, never apply power to the power
supply/fan module while the module is removed from the switch.

Note: When using a screwdriver to tighte n the thum b scre ws, ens ure t he thu mb

screws are secure but not overtightened. Overtightening the thumb screws may
damage the screws or the module.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 15

CHAPTER 3SWITCH MANAGEMENT

This chapter is divided into three sections providing information on how to manage and monitor
the switch:

• Getting Started – Describes how to configure the network interface, use the Web
Manager, and perform a basic initia l set up of the s witc h.

• Managing the Switch - Describes how to configure the switch and port settings, manage
firmware versi ons a nd conf igurat ion f iles, set sw itch t hres hold s, and confi gure O ne-Ste p
Zoning, Automatic Trunking, and Load Balancing.

• Monitoring the Switch – Describes how to view switch information, the event log, port
information, and port diagnostics.

The switch incorporates two distinct interfaces for managing and monitoring purposes:

• The Web Manager interface provides an intuitive graphical user interface that enables
users to quickly check swit ch status or modify switch setti ngs in a visual envi ronment.

• The Command Line Interface (CLI) provides flexi bility and additional fu nctionality f or
advanced users.

Both of these interfaces provide nearly identical functionality; however, for the purposes of this
guide, the Web Manager interface is used for switch and port configuration unless otherwise
noted.

For a list of CLI commands, see Appendix B: CLI Quick Reference on page 63. For additional
information on the CLI, see the InSpeed Storage Switch CLI Reference Guide.

Getting Started .................. ...... ....... ...... .... 16

Managing the Switch................. ....... ...... .... 21

Monitoring the Switch ...................... ...... .... 48

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 16

GETTING STARTED

This section explains how to configure the switch’s ethernet network settings prior to using the
Web Manager. Once the switch’s network settings are configured, use the Web Manager to
perform a quick switch setup.

Configuring the Network Interface

Before using the Web Manager, ensure the switch’s ethernet network parameter settings are
correct for the network co nfiguration. The switch shi ps with the fo llowing de fault IP settings:

• IP Address: 169.254.10.10

• Netmask: 255.255.0.0

• Gateway: 0.0.0.0

To adjust these settings to open the Web Manage r, connect to the switch using the provided serial
interface cable and follow the instructions below.

To connect through a serial interface:

1. Attach one end of the included RS-232 null modem cable to the computer’s DB-9 serial
port and attach the other end to the switch’s DB-9 serial port.

2. Open a terminal session through a serial terminal emulation program (such as
HyperTer minal®) with the appropriate serial port (for example, COM1) and the following
serial port parameters:

• Bits per second: 19200

• Data bits: 8

•Parity: None

•Stop bits: 1

• Flow control: None

3. If using HyperTerminal, press E

NTER to receive a prompt.

If using the tip command on a UNIX workstation, do the following:

a. View the /etc/remote file and create an alias similar to Hardware but with the

serial port parameters above. (Suggested name: Switch)

b. Use the tip command to establish a connection through the created alias, for

example tip switch. (For more information, see the tip command M anual page.)

4. Type the password at the prompt and press E

NTER. (The default password is password.)

5. From the serial terminal emulation program, type config network ip and press E

NTER.

The switch’s current IP parameters are displayed with a prompt for entering the IP
address.

6. Change the IP address and press E

NTER.

7. Use the mask and gateway commands to change the su bnet mask and default gateway
respectively.

8. Type save and press E

NTER.

9. Type root reset and press E

NTER.

10. Type y and press E

NTER to reset the switch.

11. Attach the computer to the switch’s 10/100 ethernet connector by doing one of the
following:

• Attach an ethernet RJ-45 cross-over cable directly between the computer and the
switch.

• Attach two ethernet RJ-45 twisted pair cables from the computer and the switch
into an opera tiona l et her net pa tch p anel o r hub.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 17

Connecting to the Web Manager

The Web Manager displays current port utilization and health, enables easy to use Port Smart
Settings and One-Step Zoning, a nd seve ral additional fea tures discusse d l ater in thi s cha pter.

To connect to the Web Manager:

1. Ensure the workstat ion has acces s to the network on which the sw itch is conn ected.

2. Open Microsoft Internet Explorer, version 5.5 or later.

3. In the address bar, type the switch’s DNS name or IP address and press E

NTER.

Web Manager Overview

The Web Manager enables users to view and configure switch and port settings using an intuitive,
graphical user interface. The main page is the Switch Information page. This page displays
general switch status and continually refresh es to display the most curre nt switch statu s. For
more information on th e Switch I nform ation pa ge, see “Switch Info rmation ” on page 48.

To return to this page at any ti me, cl ick the InSpeed™ Storage Switch menu item.

The Web Manager interface consists of a series of command buttons, an expandable navigation
menu, and the displayed information area. The command buttons and navigation menu are
always present on the page.

Note: The Web Manager supports the Micro soft Inter net Ex plore r ve rsio n 5.5 or la ter w eb

browser on Windows or Apple OS-X operating systems.

Note: The web browser’s appearance and information depends on the switch’s active

firmware versio n an d ma y c hange wit hout no tice in s ubse qu ent f irmwa re vers ion s.

Command Button Description

Submit Saves any changes made to the switch configuration. This button is

disabled unt il a con figu ration set ting is ch an ged or ne w in for ma tion i s
entered. This butto n ap pear s gr een to no tify th e user of a cha nge to the
switch configuration. Click this button to accept the configuration change.

Cancel Cancels a request. This button is disabled until a configuration setting is

changed or new information is entered. This button appears green to
notify the user of a change to the switch configuration. Click this button to
cancel the configuration change.

Figure 3-1: Web Manager interface

Navigation Menu

Command

buttons

Current page

information

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 18

The expandable navigation menu provides several options for configuring and monitoring the
switch. The menu us es a tree-bas ed n avigation struc ture wi th a li st of menu option s and item s.
Clicking a menu option with a "+" next to it expands the menu option and displays additional
menu items. Clicking a menu item displays the selected Web Manager page.

To ensure that the most current information is displayed, use the navigation menu instead of the
browser’s Back and Next buttons, which usually display cached copies and may not reflect current
switch information.

To log out of the Web Manager, click Logout, or simply close the browser window.

Documentation

The Web Manager’s Help menu provides links to online product documentation and firmware
downloads.

To access product documentation:

1. Click Help > Documentation.

2. Click Product Docs.
A documentation request web page appears.

3. Enter the appropriate information and click Submit Request.
An email message is sent to the provided email address with the web page location for the

requested product documentation.

To view Technical Brief documentation, click Technical Briefs.

To download firmware:

1. Click Help > Downloads.
A download request web page appears.

2. Enter the appropriate information and click Submit Request.
An email message is sent to the provided email address with the web page location for the

requested firmware download.

Reboot Resets the swi tch .
Login/Logout Logs in to a nd out of t he swit ch .
Refresh Redraws the currently displ ayed web pag e.

Note: The Web Manager will automatically log u sers ou t after 15 min utes of in activity, unless

the Switch Inf orma tion p age i s cu rr ent ly di spla yed. T he Swit ch In for mat ion p age
automatically update s to dis play the mo st cu rren t sw itch status .

Command Button Description

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 19

Initial Switch Setup

Once a network connection has been established with the switch and an instance of the Web
Manager is open, some basic switch co nfiguration tasks are recommended:

• Log in to the switch.

• Change the switch’s password.

• Verify the switch’s date and time settings.

• Change the switch’s name.

For additional information on Web Manager features and functionality, see “Managing the Switch”
on page 21 and “Monitoring the Switch” on page 48.

Step 1: Log in to the Switch

The switch incorporates a password-level security system to prevent unwanted changes to the
current switch configuration. In order to make any changes to the switch, users must be logged in
to the switch.

To log in to the switch:

1. Click Login on any Web Manager page.
A message box appears confirming the login request.

2. Click OK.
The switch login page appears.

3. Enter the switch’s password.
The default password is "password".

4. Click Log In.
A message page appears while the page is loading. If the page fails to load in the

indicated time, click Continue.

See “Logging in to the Switch” on page 22 for additional information.

Step 2: Change the Password

The default password is set at the factory to "password". Change the default password to secure
the switch and guarantee that any configuration changes are only performed by registered users.

To change the password:

1. Click Switch > Password.
The Switch Password page appears.

2. Enter the new password in the New Password text box.

3. Enter the new password again in the Confirm New Password text box.

4. Click Submit.
A message box appears confirming the change to the switch’s configuration.

5. Click OK.
The Password set success message appears confirming that t he new password was saved

and activated.

See “Changing the Password” on page 27 for additional information.

Note: The password must be between 6 and 25 characters in length and is case

sensitive.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 20

Step 3: Verify the Date and Time

During the initial W eb Manager session, the date and time for the switch are set based on the host
system’s current settings.

To view the current date and time:

1. Click Switch > Date & Time.
The Switch Date & Time page appears.

To set the date and time settings:

1. Enter the new date and time settings in the appropriate fields.

2. Click Submit.
The new date and time appear under Current Date & Time.

To synchronize the current date and time settings with the host system:

1. Click Host Time.
The date and time of the current host system appear in the New Date & Time text box.

2. Click Submit.
The new date and time appear under Current Date & Time.

See “Configuring Date and Time Settings” on page 26 for additional information.

Step 4: Change the Switch Name

While not required, changing the switch’s name is recommended for identification and
troubleshooting purposes.

To change the switch name:

1. Click Switch > Configuration.
The Switch Configuration page appears.

2. Enter the new name in the Name text box.

3. Click Submit.
The new name appears in the Name text box and also appears in the title bar after the

"InSpeed™" label.

See “Switch Identification” on page 23 for additional information.

Note: The web page may h ave to b e r efre sh ed befo re s eei ng th e n ame ch an ge. Press

F5 to refresh the web browser instance or open a new web browser instance.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 21

MANAGING THE SWITCH

The Vixel InSpeed™ SAN Storage Switch Model 375 provides several options for managing and
configuring the switch to meet the needs of the network environment.

This section describes h ow to l og in to t he sw itch, confi gure sw itch and port se ttings, manage
firmware and configuration files, and configure One-Step Zoning, Automatic Trunking, and Load
Balancing .

Frequent Switch Configuration Tasks

A list of frequent switch configuration-related tasks is provided below. The list displays the task,
the corresponding Web Manager command, and a reference to where more information may be
found in this guide.

For information on viewing switch status and information, see “Monitoring the Switch” on
page 48.

To… Click… In this guide, see...

View switch statu s InSpeed™ Storage

Switch

“Viewing Switch Sta tus” on pa ge 48.

Change general s witch
configuration

Switch > Configuration “Configuring th e Swit ch Set ting s” on

page 22.
Change the IP Address Switch > Configuration “Network Location” on page 23
Change the switch speed Switch > Configuration “Switch Speed” on page 24.
View the event log Switch > Event Log “Viewing the Event Log” on page 50.
Configure traps Switch > SNMP Traps “Setting SNM P Traps” on page 25.
Upgrade the firmware Switch > Files “Switch Firm ware Fi les” on p ag e 36.
Change the Port Smart

Settings

Port > Smart Settings “Configuring the Port Smar t Settings ” on

page 29.
Configure One-Step Zoning Advanced Functions >

One-Step Zoning

“One-Step Zoning” on page 38.

Configure Automatic
Trunking

Advanced Functions >
Automatic Trunking

“Automatic Trunking” on page 45.

Configure Lo ad B ala ncing Advanced Functions >

Load Balancing

“Load Balancing” on page 46.

Reset the switch Reboot “Configurin g th e Switch S etting s” on

page 22.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 22

Logging in to the Switch

The Web Manager requires users to log in to the switch when c hanges are made to the switch ’s
configuration. Log in is not required for viewing switch information.

To log in to the switch:

1. Click Login on any Web Manager page.
A message box appears confirming the login request.

2. Click OK.
The Switch Login page appears.

3. Enter the switch’s password.

4. Click Log In.
A message page appears while the page is loading. If the page fails to load in the

indicated time, click Continue.

Configuring the Switch Settings

Several switch configuration settings may be changed to customize the switch to the network
environment. To make a change to the current switch configuration, users must be logged in to
the switch or know the switc h passwo rd (t he sw itch prompts u sers f or th e pa ssword be fore
accepting changes to any configuration settings).

To change a switch setting:

1. Enter new information or make changes to current settings.

2. Click Submit.
The Web Manager page displays the new settings or information.

Changes to certain switch settings requ ire that the switch be rese t for those changes to occu r.
Users must be logged in to the Web Manager to reset the switch.

To reset the switch:

1. Ensure any changes to the current swit ch configuration have been saved.

2. Click Reboot on the Web Manager page.
The switch will reset.

Note: If you do not remember the password, contact a customer service representative.

Figure 3-2: Switch Login page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 23

General Switch Settings

The Switch Configuration page displays general settings and switch identification information.
To view the Switch Configuration page, click Switch > Configuration.

Switch Identification

This section includes general switch identification information.

The name, location , and contact name information may be modified for the network environment.
The Serial Number setting is factory set and cannot be modified.

To change the name, location, or contact name:

1. Click Switch > Configuration.

2. Enter the new value in the appropriate text box.

3. Click Submit.
The Switch Configuration page displays the updated information.

Network Location

The switch’s network location is identified by the IP Address, Netmask, and Gateway fields.

Setting Description

Name The name of the switch.
Location The location of the switc h.
Contact Name The person or gro up to cont act ab out the sw itch.
Serial Number A unique identification number as signed t o each switch at t he factory.

Cannot be configured or modified.

Setting Description

Ethernet IP Address The current IP Address for the switch.
Netmask The current IP Netmask address for the switch.
Default Gateway The current Gateway address for the switch.

Figure 3-3: Switch Configuration page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 24

To change the switch’s network location settings:

1. Click Switch > Configuration.

2. Enter the new value in the appropriate text box.

3. Click Submit.
The Switch Configuration page displays the updated information.

Version Information

The different software and hardware versions include:

Switch Speed

The Switch Speed setting indicates the curren t speed per port at whic h the switch is running . All
ports operate at the same speed. The default switch speed is set to 2.125 Gb/s.

To change the switch speed:

1. Click Switch > Configuration.

2. Select the desired speed.

3. Click Submit.

Blocking ARB

When two ports start a communicatio n session, the Blockin g ARB is sent to all oth er ports tryin g
to communicate with those ports until the connection is terminated. The default setting is "FF". If
other connected devices use the "FF" setting for another purpose, select another Blocking ARB
value (for example, "FB" ). Under normal circumstances, this setting does not need to be modified.

Agent Up Time

The Agent Up Time field displays the duration of time that the switch has been operational. If the
switch is r eb oo ted or p o we r i s cycl ed , th is valu e is re s et.

The Agent Up Time field is for display purposes and cannot be configured.

Setting Description

MAC ID A unique device address (MAC address) assigned to each switch at the

factory. Cannot be config ure d o r mo di fied.

Switch FW Version The current firmware loaded onto the switch.
Switch HW Version The hardware version of the s witch. Cannot be con figured o r mo dified.
InSpeed SOC Version The SOC 320 versio n that i s used i n the switch. Canno t be c onfigured or

modified.

MIB Version The pr oprietary Manageme nt Information Base version that is suppor ted

through SNMP. Cannot be configured or modified.

Setting Description

1 Gb/s Set switch spee d to 1.062 5 Gb/s .
2 Gb/s Set switch speed to 2.125 Gb/s.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 25

Setting SNMP Traps

Simple Network Management Protocol (SNMP) uses traps to transmit information to SNMP-based
network administration programs. The Switch SNMP Trap Configuration page displays information
on the switch’s current SNMP trap configuration.

To view the SNMP trap configuration page, click Switch > SNMP Traps.

To configure an SNMP trap:

1. Enter the Trap IP address for the device to which the trap information will be sent.

2. Enter the Trap Port number.
This value is usually set to "162" for Windows and Apple-based networks.

3. Select the State.

4. Click Submit.

When editing a registered IP address, delete the current IP address and create a new entry for
the revised IP address.

State Description

Active The trap sends messages to the host identified in the IP Address

selection.

Inactive The trap is n ot op eratio nal.
Delete The trap will be de leted fr om the tab le once change s are save d.

Figure 3-4: Switch SNMP Trap Configuration page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 26

Configuring Date and Time Settings

The Switch Date & Ti me page displays the swi tch’s current date and time. During the initial Web
Manager session, the date and time for the switch are set based on the host system’s current
settings. If the swit ch is re booted o r powe r is cycl ed, t he sys tem c lock w ill rese t and t he swi tch’s
date and time settings will be set to the host system’s time settings of the next user to log in to
the switch.

To change the time:

1. Click Switch > Date & Time.
The Switch Date & Time page appears.

2. Enter the desired date and time in the appropriate fields.

3. Click Submit.
The new date and time appear under Current Date & Time.

To synchronize time with the host system:

1. Click Host Time.
The date and time of the current host system appear in the New Date & Time text box.

2. Click Submit.
The new time appears under Current Date & Time.

Figure 3-5: Switch Date & Time page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 27

Changing the Password

The Switch Password page enables users to change the password for mo difying the switch ’s
configuration. The same password is used to access both the Web Manager and the CLI.

To change the password:

1. Click Switch > Password.
The Switch Password page appears.

2. Type the new password in the New Password text box.

3. Type the password again in the Confirm New Password text box.

4. Click Submit. If users are not logged in to the switch, a password prompt appears
requesting that the current password be entered. Enter the current password to proceed.

A message displays confirming that the password was saved and activated.

Opening a Telnet Session

Some switch operations may require advanced features currently not found in the Web Manager.
These features are available in the Command Line Interface (CLI), which can be accessed through
the Web Manager by opening a telnet session to the switch.

To open a telnet session with the switch:

1. Click Advanced Functions > Telnet Session.
A message box appears confirming the opening of a telnet sessi on to the switch.

2. Click OK to proceed.

3. Enter the switch’s password and press E

NTER.

For additional information on CLI features and functionality, see the InSpeed Storage Switch CLI
Reference Guide.

Note: Until the default switch password is changed, any user with knowledge of the default

password can make changes to the switch’s configuration.

Note: The password must be between 6 and 25 characters in length and is case sensitive.

Figure 3-6: Switch Password page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 28

Adjusting the Switch Thresholds

The Switch Thresholds page displays a variety of switch threshold settings.

To view the current threshold settings:

Click Advanced Functions > Thresholds > Switch.

The Switch Thresholds page appears.

To change switch thresholds or time intervals:

1. Enter the new value in the appropriate text box.
The valid range is displayed next to the text box.

2. Click Submit.
The new value is set.

Setting Description

Ordered Set Error Threshold The maximum number of OS errors allowed in a 10-second interval

before a port is bypa ssed . Settin g this value to "0" returns it to the
factory defaul t settin g.
This setting is activated on the Port Smart Settin gs page.

CRC Error Threshold The maximum number of CRC errors allowed in a 10-second interval

before a port is bypa ssed . Settin g this value to "0" returns it to the
factory defaul t settin g.
This setting is activated on the Port Smart Settin gs page.

Bad Zone Recovery Hold Time

(measured in centi-seconds)

The amount of time that the switch k eeps the ports in bypass mode
before attempting to r e-inse rt the ports into the zon e.
This setting is activated on the Ad vanced Functio ns One-Ste p
Zoning page.

Bad Zone Recovery Delay Time

(measured in seconds)

The amount of time that the switch waits after a zone goes down
before attempting to r ecover the zone .
This setting is activated on the Ad vanced Functio ns One-Ste p
Zoning page.

Port Utilization Interval

(measured in seconds)

The length o f tim e be twe en re ading s of th e c urren t p ort ’s
utilization.

Figure 3-7: Switch Thresholds page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 29

Configuring the Port Smart Settings

The Port Smart Settings page displays the current Smart Settings (configuration settings)
assigned to each port and enables users to easily create and modify custom Smart Settings.

To view the Port Smart Settings page:

Click Port > Smart Settings.

The Port Smart Settings page appears.

Expanding the op tion al co nfi gurati on men us on the right-side of the page by clicking the
expand buttons provides additional configuration options.

Figure 3-8: Port Smart Settings page

Expand
button

Figure 3-9: Port Smart Settings page (all options displayed)

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 30

Default Smart Settings

There are several default Smart Settings available on the switch. These default Smart Settings
were defined by Fibre Channel storage experts to ensure the switch is optimally configured for
performance and stability.

The default Smart Settings cannot be modified or deleted, but these settings can be used as
templates for creating custom Smart Settings.

Initiator or Target

This Smart Setting is the default se tting for all switch ports from the factory. This setting offers no
change protection and all settings are set to their default values. Initiators and targets can be
connected to ports that are set to this Smart Setting.

This is the recommended Smart Setting for setups with targets and initiators connected to a
single switch.

Initiator with Stealth

This Smart Setting is used when connecting a host device to the port. When a port is set to this
Smart Setting, change notifications are not sent from the initiator to other devices, but change
notifications are re ceived by the init iator.

This Smart Setting is appropriate for embedded storage controllers and external Host Bus
Adaptors (HBAs) or servers wit h installed HB As.

Target with Stealth

This Smart Setting is used when connecting embedded storage devices, like JBODs, SBODs, tape
drives, or external RAID systems (J BODs, SBODs, or tape libraries). Whe n a port is set to this
Smart Setting, change notificatio ns are sent to other devi ces, but change noti fications are not
received by the target.

Fabric Connection

This Smart Setting is used when connecting a port to a Fabric switch. Only one connection from
the Vixel InSpee d™ SAN Storag e Switch Mo del 375 t o a Fabric switch is valid .

Tree Cascade

This Smart Setting is used when connecting two or more switches together in a tree
configuration. Up to four tree cascades are supported between switches. See “Cascading
Switches” on page 44 for additional information.

String Cascade

This Smart Setting is used when connecting two or more switches together in a string
configuration. Up to four string cascades are supported between two switches. See “Cascading
Switches” on page 44 for additional information.

Before selecting a cascade optio n, consider t he following:

• Cascade ports of like number should be connected together. For example, connect port 1
of Switch A to port 1 of Swi tch B, connec t po rt 2 of Switch B to port 2 of Swi tch C, and s o
on.

• Cascade port numbers must be lower than non-cascade port numbers (for example,
Initiator or Target ports). Therefore, select cascade types before selecting these non ­cascade types.

• A maximum of three switches may be connected using string cascades.

Note: Changing the Smart Setti ng of a port may affe ct th e perf orm ance or b ehavior of t he

system. Depending on the implem entation, some Sm art Setting s are more ap propria te
than others.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 31

• When configuring multiple switches with a single cascade, use alternating ports. For
example, connect the second switch using ports 1 and the third using ports 2 as shown in
Figure 3-10.

To assign a Smart Setting to one or more ports:

1. Select the appropriate Smart Setting from the list box.

2. From the list of port numbers, select the ports that will use the selected Smart Setting
under the Assign heading.

3. Once completed, click Submit to save the settings.

To set all ports to the currently selected Smart Setting:

1. Select the desired Smart Setting from the list box.

2. Click Set All.

3. Click Submit to save the new settings.

Creating Custom Smart Settings

In addition to the default Smart Settings, users can create custom Smart Settings for use in a
specific network environment.

To create a custom Smart Setting:

1. Click Create.
A text box appears prompting for the name of the new Smart Setting.

2. Enter the new Smart Setting name.
A name may consist of up to 28 alphanumeric characters and cannot contain spaces (use

underscores for spaces in names).

3. Click OK.
The new Smart Setting is added to the list box.

4. Click Submit to save the new Smart Setting.

Note: The Create function always u ses the Init iator o r Target Smart Setting as the

base setting fr om which to config ure a cust om Sma rt Settin g.

Figure 3-10: Alternating Ports for Single Cascades

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 32

To create a custom Smart Setting based on an existing Smart Setting:

1. Select a Smart Setting from the list box that most closely matches the port settings that
the new Smart Setting should have.

2. Click Clone.

3. Enter the new Smart Setting name.
A name may consist of up to 28 alphanumeric characters and cannot contain spaces (use

underscores for spaces in names).

4. Click OK.
The new Smart Setting is added to the list box.

5. Click Submit to save the new Smart Setting.

To modify a custom Smart Setting:

1. Ensure the custom Smart Setting is not currently assigned to a port before making any
changes.

2. Select the custom Smart Setting in the list box.

3. Select the ne w sett ings .

4. Click Submit to save the new settings.

To rename a custom Smart Setting:

1. Select the desired Smart Setting from the list box.

2. Click Rename.

3. Enter the new Smart Setting name.
A name may consist of up to 28 alphanumeric characters and cannot contain spaces (use

underscores for spaces in names).

4. Click OK.
The new Smart Setting name appears in the list box.

5. Click Submit to save the change.

To delete a custom Smart Setting:

1. Ensure the custom Smart Se tting is not selected or cu rrently in us e.

2. Select the custom Smart Setting in the list box.

3. Click Delete.

4. Click Submit to save the settings.

Smart Setting Assignments

The Smart Settings are based on several port settings grouped into the following categories:

•Port Information

•Pre-Insertion Testing

•Change Notifications

•Port Recovery

•Diagnostics

These settings can be adjusted on custom Smart Settings; however, these settings are fixed on
the default Smart Settings.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 33

Port Information

The following settings are available.

Pre-Insertion Testing

The following settings are available.

Setting Description

Smart Setting Name Disp lays the nam e of the Smar t Setting. T he Smart Se tting name will

automatically a pp e a r i n the text box when sel ec te d in the scroll m en u .

Smart Setting Type The topology among switches for a port. Options include:

• Initia tor or Target Port – the default setting. Should be used when
there are no links between switches.

• Tree Cascade – designates the port as a tree cascade p ort. Us e this
setting when connecting multiple s witch es togethe r in a tree c a scade
configuration. Under most conditions, this setting will re su lt in
acceptable p erformance.

• String Cascade 1 through String Cascade 4 – designates the string
cascade to which a por t is a ss igne d. Strin g c a sca de s m aint a in fairn e ss
when two or more InSpeed-based storage s witch es are s eria lly
cascaded. Switch performan ce may be lower when compared to a tree
cascade configuration.

Setting Description

Enable Policies/Smart
Insertion

This policy is the de fault ope rating mod e for all po rts and dete rmin es
what the switch lo ok s for prior to allowing a por t to in s e rt into a zone.
When the policy is enabled, a n extern al dev ice is sent a n F7
Initialization n otifi cat ion by t he s witch un til an F 7 In itial izati on
notification is r eceive d fr om t he dev ice. On ce a n F7 In itial izatio n
notification is received, th e port is inserted in the zone .
This policy takes precedence over all other policies. When this policy is
disabled, no additional policies are operational, and as long as a port
transmits a signal of the correct freque ncy and amplitude, the port wil l
be allowed in the zone .

Port Test Before Insertion This policy ensures a device on a port is a valid, standards-compliant

participant befo re allow ing the dev ice to be ins erted in to a zone. Th e
device must meet a ll of the FC-AL require ments along with go ing
through a complete change notification cycle. During the change
notification cycle, the device becomes the Initialization Master (IM)
and goes through the change notification phases. Once the change
notification cycle is compl ete, the device can be inserted. This process
ensures a bad de vice is not allow ed into the zo ne.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 34

Change Notifications

The following settings are available.

Port Recovery

The following settings are available.

Setting Description

Stealth Intelligent Change
Manager

Stealth Intelligent Change Manager provides stability and control over
change notification disruptions on a port basis. Options include:

• O ff: No Cha nge Protec tion – no Steal t h Int elligent Change Man ager
control.

• Initiator: Only Receive Changes – device s attached to the port c an
receive change notifications but will not propagate change notifications
generated by that port to other ports.

• Target: Only Send Changes – propagates change notifications
generated by the port to other ports but will not allow devices attached
to the port to receive change notifications from other ports.

• Switch-Switch: Sen d an d Receive Change s – a llows cha nge
notifications to propagate between switches.

• Custom-1 – Note: This setting should not be used unless directed to do
so by a customer service rep res en tative.

Change Notification on
Insertion

The switch normally operates under the condition that when a device
is inserted o nto th e netwo rk, a ch ange not ificat ion is ge nerated.
However, this condition is not always true whe n con necting hub s or
switches toge ther. In some instances , it is poss ible to c on nect two
zones together wit hou t the zones reali zing that m ul tiple A L_PAs ex ist
with the same values.
When this po licy is e nab led, th e sw itch alway s g enerat es a ch ang e
notification to ensure the proper system updates are performed.
However, when a device is re moved (for exa mp le, an ini tiato r or
target), the removal does not generate a change notification and there
are no syst em u pda tes per fo rme d.

Change Notification on
Removal

This policy i s s imilar to the Ch ange No tific atio n on Inse rtion p olicy,
except for the change notification being sent when a device is
removed rather than inserted.
When this po licy is e nab led, th e sw itch alway s g enerat es a ch ang e
notification to ensure the proper system updates are performed.

Setting Description

Bad Device Recovery When a port is already inserted into a zone, the port transforms F8

Failure notifications into F7 Ini tial ization n oti ficatio ns. Wh en thi s
occurs, the po rt is byp asse d a nd F7 Initia lizatio n no tific ations ar e
allowed in the zon e. On ce the init iali zatio n is c omp lete , th e B ad Zone
Recovery Policy is operational and prevents a port that continues to
transmit F8 Failure notific ations from ins ertin g into the zone .

Note: If this policy is disabled while the Bad Zone Recovery policy is
enabled, a zone that does go down will still allow the Bad Zone Recovery
policy to reset the zone and allow ports to be reinserted .

When enab led, this po licy pre ven ts d evic es that send F 8 Failure
notifications from inserting into a zone. T he abi lity to re move d evices
that generate F8 Failure notifications auto matically and
instantane ousl y g uaran te es cont inu al sy st em opera tio n.
When disabled, this policy allo ws devic es that se nd F8 Failure
notifications to insert into a zone and doe s not consid er F8 Failure
notifications when determining whether to insert a device or not.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 35

Diagnostics

The following settings are available.

Clear on Stall In situations where the switch is operating in switching mode, some

devices may fall into an operating mode where the device has opened
a target but ha s no t rele ased the connec tion to the tar get. When this
policy is en able d , th e s witch ca n d ete ct thi s cond itio n a nd
automatically recover when this situation arises.

Bypass on No Activity The switch detects the amount of time a data stre am has gone

without receiving a comm a. Th e time setti ng is se t to 1 00 (. 001
seconds). When this policy is enabled, the switch bypasses the
disruptive port when the threshold is exceeded.

Bypass on Ordered Set Error Ordered Set (O S) error s ar e det ecte d an d cou nted fo r ea ch in divid ual

port. When this po licy is enab led, a por t is bypass ed when its OS
count exceeds the t hresho l d s etti ng. The thr esho ld se t tin g is based on
the number of o rde red set erro rs i de ntifie d in 10 se con ds.

Note: This threshold setting can be ad juste d on th e Web Manager ’s
Advanced Functions Switch Thresholds page.

Bypass on CRC Error Cyclic Redundancy Check (CRC) errors are detected and counted for

each individual port. When this policy is enabled, a port is bypassed
when its CRC count exceeds the threshold setting. The threshold
setting is based on the number of CRC errors identified in 10 seconds.
User interventio n i s re quire d to ret urn the po rt into t he zo ne.
Recovery methods include replacing the defective component, cycling
power to the device on the por t, removing a nd reinsert ing the
bypassed port, or cycling power to the switch.

Note: This threshold setting can be adj usted on the Web Manager’s
Advanced Functions Switch Thresholds page.

Setting Description

Port Control Th e me thod for c ontr olling a por t. Op tio ns inclu de:

• auto – the default setting. The switch will automatically insert a port
based on policy settings. This prevents the insertion of incompatible
ports, which may cause disruption.

• bypass – removes a port from the network. Use this mode to keep a
device out of an initialization cycle when troubleshooting.

• extLoopb ack – re moves a port f rom the network and ro utes the
port's receive signal back through the port's transmitter. Us e this
mode to isolate a specific zone for trou bleshooting or to test a
transceiver’s circuitry and attached media from the n ode end.

• insert – allows ports whose transceivers cannot derive a valid clock
or "K" character (Ordered Set) to join a zone. Use this mode
cautiously – devices without valid characters may put bad data into
a zone, causing the zone to go down.

Bypass on Clock Delta The switch determines the relative freq uency of the signal bein g

received by a port to the internal switch clock. The result of this
test allows the dete rmina tion of h ow f ar a part in fre quency the
switch’s clock is in relation to the clock of the received signal – the
clock delta. If the clock delta exceeds a set threshold, the switch is
notified and the port may be bypassed if necessary. Typically, clock
drift is slow enough to a llow the re moval and repla cem ent of a
defective par t b efor e the defec tive part beg ins to a ffe ct sy stem
performance.

Setting Description

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 36

Managing Firmware and Configuration Files

The Switch Files page displays information on the switch’s firmware and configuration files.
To view the firmware and configuration files, click Switch > Files.

The Switch Files page appears.

Switch Firmware Files

This section displays the current and alternate firmware versions, enables users to select which
firmware version to run the next time the switch is reset, and provides a means to load new
firmware on the switch.

To view or download the latest switch firmware, click Help > Downloads. The Web Manager will
display the firmware request page. Enter the requested customer information and an email with
the location of the appropriate firmwar e download page for the switch will be sent to the specified
email address. If necessary, download the latest switch firmware to the host system.

To load new firmware on the switch:

1. Under Download New Alternate Firmware Version to Switch, enter the directory path and
the specific file name in the text box, or click Browse to navigate to and select the
appropriate file on the host system. The file must have a .bin extension.

2. Click Start to load the new firmware image.
Once the firmware has been installed, the new firmware should appear as the Alternate

Version firmware.

3. Under Next Boot Firmware Version, ensure the Use Alternate Version on Next Reboot
option is selected. The alternate firmware version currently displa yed will be loaded on the
next boot cycle.

4. Click Reboot to reset the switch using the selected firmware.

Note: When loading new firmware on the switch, clear the web browser’s cache and files to

ensure the removal of the older firmware information. In Internet Explorer, use the key
combination C

TRL+F5, or select Tools > Internet Options and click Delete Files.

Figure 3-11: Switch Files page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 37

To select the alternate firmware version for the next boot:

1. Under Next Boot Firmware Version, select Use Alternate Version on Next Reboot. The
alternate firmware version currently displayed will be loaded on the next boot cycle.

2. Click Submit.

3. Click Reboot to reset the switch.

Switch Configuration Files

Switch configuration settings (for example, zoning or Port Smart Settings) can be saved for
backup purposes or for loading the same configuration on multiple switches.

To save the current configuration:

1. Click Save to save the current switch conf iguration.

2. Click OK on the File Download dialog box.

3. Enter the directory path and file name, being sure to use a .cfg extension.

4. Click Save.

To load a saved configuration:

1. Under Download New Configuration File to Switch and Reboot, enter the directory path to
the .cfg file in the text box, or use the Browse button to navigate to the appropriate file.

2. In the Choose File dialog box, navigate to and select the appropriate file and click OK.

3. Click Start.
A message box appears confirming the download and required switch reset.

4. Click OK to proceed.

Restoring the Factory Default Settings

If necessary, the switch settings can be reset to their factory default values; however, the
network co nfig uratio n and port type se tti ngs ar e re tain ed.

To restore the factory default configuration:

1. From the Restore Configuration to Factory Default section, click Restore.
A message box appears confirming the request.

2. Click OK to restore the factory default configuration and reset the switch.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 38

One-Step Zoning

Zoning allows ports to be divided into multiple virtual zones (or work groups), similar to Virtual
Local Area Networking (VLAN). By separating activity on the network, zoning also eliminates
change notification propagation (change notifications that occur within one zone cannot
propagate to other zone s.)

Use zoning to:

• Separate different operating system environments.

• Temporarily block or grant access during backup or other tasks.

• Consolidate equipment logically.

• Designate closed user groups for increa sed security.

• Separate test or maintenance areas from prod uct ion a reas .

Zone configuration settings are available on the Web Manager’s One-Step Zoning page. The page
is arranged as a grid of check boxes for placing ports in appropriate zones. Ports are listed across
the top of th e gr id. Zone s are listed down the left side. Similar to other Web Manager pages, the
port color represents the current port status.

To view the One-Step Zoning page:

Click Advanced Functions > One-Step Zoning.

The switch is capable of up to twelve zones. Initially, all ports reside in Zone 0. However, a port
will clear from Zone 0 whenever it is selected and placed in another zone.

The color of each zone indicates its stat us. See the descri ptions in the fo llowing tabl e:

Color Description

Down (red) One or more port s h a ve been s el ected , zo nin g has be en ac ti vated, but

hardware has caused a failure.

Up (green) Ports have been selected, zoning has been ac tivated, and the FC-AL

circuit is operational.

Not Active (yellow) Ports have been selected but zoning h as not been activated.
Undefined (gray) No ports have been selected.

Figure 3-12: One-Step Zoning page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 39

The Zone Initialization Master Port field displays the port number of the port that is c urrently
assigned as the master for that particular zone. The Initialization Master is responsible for
starting the change notificati on process in each zone.

To add ports to a zone:

1. Select the appropriate check boxes to place ports int o zones.

2. Click Submit.

To activate zoning:

1. Select the Zoning Active check box near the bottom of the page.

2. Click Submit.

To remove a port from a zone:

1. Clear the appropriate check box.

2. Click Submit.

To remove all ports from a zone:

1. Click Clear at the end of the row of check boxes for the appropriate zone.

2. Click Submit.

To remove all zones:

1. Click All under the Clear Zone heading.

2. Click Submit.

Single-Switch Zoning

The simplest zoning configuration is to place each port into a single zone, so that zones are
separate from each other as shown in Figure 3-13.

In Figure 3-13, zone 1 includes ports 1, 3, and 4, while zone 2 includes ports 2 and 5. Devices on
ports 1, 3, and 4 have direct access to each other and devices on ports 2 and 5 have direct access
to each other; however, devices 1, 3, and 4 ar e separated from devices 2 and 5.

Caution: Clearing the Zoning A ctive check box will de activate all zones , which may

degrade system performance or compromise security.

Figure 3-13: Devices in a Single Zone

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 40

Adding Devices to Multiple Zones

In the previous example, each host only communicates with the devices in the same zone as the
host. However, there may be situations in which hosts in separate zones need to share devices.
When this situation occurs, use overlapping zones to share the devices between the hosts. Figure
3-15 depicts this type of zoning configuration.

In Figure 3-15, zone 1 includes ports 1, 3, and 4, while zone 2 includes ports 2, 4 and 5. Port 4 is
in both zones. Devices on ports 1, 3, an d 4 have direct acce s s t o ea ch oth er an d devi ce s on po rt s
2, 4, and 5 have direct access to each other, but devices 1 and 3 are separated from devices 2
and 5. The device on port 4 has direct access to all the devices on ports 1, 2, 3, and 5.

To add storage devices to multiple zones:

1. Select the appropriate zones for each port.

2. Ensure the Zoning Active check box is selected.

Figure 3-14: Single switch zoning configuration

Figure 3-15: Devices in Multiple Zones

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 41

3. Click Submit.

Multiple Switch Zoning

Zones can be configured across multiple switches using a similar procedure to a single switch.
However, multiple-switch zoning requires some coordination between the switches. Building on
the example for ports in multiple zones, move the devices onto two switches and have the zones
stretch between the two, as in Figure 3-17.

In Figure 3-17, zone 1 includes ports 2, 4, 5, and cascade port 1, while zone 2 includes ports 3, 5,
6, and cascade port 1. Ports 1 (cascade port) and 5 are in both zones.

Figure 3-16: Ports in Multiple Zones on the One-Step Zoning page

Figure 3-17: Devices in Multiple Zones Across Multiple Switches

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 42

To configure multiple-switch zoning, do the following for each switch:

1. Plan which ports should belong in each zone.

2. From the One-Step Zoning page, select the appropriate ports for each zone.

3. Ensure the Zoning Active check box is selected for both switches.

4. After making changes, click Submit.

AL_PA Zoning

Another zoning configuration is AL_PA zoning, which enables users to specify that certain devices
only communicate with one another. AL_PA zoning is only accessible through the Command Line
Interface (CLI). Refer to the InSpeed Storage Switch CLI Reference Guide for additional
information.

Recovering a Bad Zone Automatically

Bad zone recovery policy automa tically reco vers tr affic if a device has brought down the zone. The
zone state is monitored continuously. If ports are inserted into a zone, but the zone state never
transitions to the Zone Up or Zone Active state after a set period of time (Hold Time), all devices
in the pertinent zone are bypassed and then allowed to reinsert. There is a secondary timeout,
the Bad Zone Recovery Delay Time, that can also be configured. The Bad Zone Recovery Delay
Time causes a delay before ports are allowed to reinsert, which prevents a high "thrashing" level
of port insertions and de-insertions and ensures that some devic es can reset. The Bad Zone
Recovery Hold Time and Delay Time threshold settings are available on the Advanced Functions
Switch Thresholds page.

When this policy is enabled with the associated PTBI policy, the device causing a zone to go down
is not allowed back into the zone due to the PTBI policy, which allows the system to return to
normal operation. The combination of the Bad Zone Recovery and PTBI policies has resulted in
significant improvements to SAN availability.

To activate bad zone recovery:

1. Click Advanced Functions > One-Step Zoning.

2. Under Bad Zone Recovery, select the check boxes for the appropriate zones.

3. Click Submit.

Caution: Clearing the Zoning Active check box will deactivate all zones, wh ich m ay

degrade system performance or compromise security.

Note: The Bad Zone Recovery poli cy i s en able d by d efa ult. I f t he Bad Zone Recove ry p ol icy i s

disabled, use the followin g instruc tions to en able this po licy for the approp riate zone s.

Figure 3-18: Zones Coordinated on Multiple Switches

Switch A

Switch B

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 43

Connecting Ports Through Hard Zoning

A Hard Zone can be used to add a separate 126 AL_PAs that operate in isolation from any other
zone. A Hard Zone disables switching functionality and creates a shared con nection between the
ports in a zone topology, splitting the switch into multiple unique FC-AL zones. When Har d Zoning
is enabled, all switch zones must be Hard Zones. A combination of Hard Zones and regular zones
on a single switch is not allowed.

The advantages of Hard Zoning include:

• Each Hard Zone contains 126 available AL_PAs.

• The switch can be configured to contain up to eleven isolated Hard Zones.

The limitations of Hard Zoning include:

• 2 Gb of shared bandwidth over the entire Hard Zone.

• Ports in a Hard Zone cannot use the Stealth Intelligent Change Manager.

• Automatic Trunking and route blocking are not allowed in a Hard Zone.

• Ports in a Hard Zone cannot be set to a string or tree cascade configuration.

• Device AL_PAs on a port in a Hard Zone cannot be displayed.

The Hard Zone setting is available on the One-Step Zoning page. To view the page, click

Advanced Functions > One-Step Zoning.

To set up Hard Zoning:

1. Determine which ports will reside in each Hard Zone and ensure the ports are in only one
Hard Zone.

2. Under Hard Zone, select the check boxes for the appropriate zon es.

3. Click Submit.

Caution: Do not set a Hard Zone for ports in mu ltiple zones or share ports that have the Hard Zone

option set. Thi s wil l cause err ors that d o not log an e vent o r di splay a m essa ge.

Figure 3-19: Hard Zoning configuration

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 44

Cascading Switches

When multiple switches are connected, the connecting links between the switches are referred to
as "cascades". There are two distinct cas cade configuratio ns to consider wh en configuring
networks for optimal performance and connectivity: string cascades and tree cascades.

String Cascades

A string cascade connects multiple switches (up to three switches maximum) together in a "daisy­chained" configuration. When one device requests access to another device, the request is sent to
each switch in the casca de befo re device acc ess is granted. This arbitration meth od pro mote s
fairness between the switches. However, when compared to tree cascades, string cascades offer
less performance due to the increased latency between the switches.

When configuring a switch port for a stri ng cascade, use the St ring Cascade S mart Setting. To
reduce contention and improve performance between in itiato r tr affic and tar get traffic when using
a string cascade configuration, connect the ports of each switch togeth er using the same Strin g
Cascade Smart Settings. For example, in Figure 3-20 the three switches are connected through
two string cascades using the String Cascade - Trunk 1 and String Cascade - Trunk 2 Smart
Settings. This creates two dedicated paths through which initiators and targets can communicate.

Tree Cascades

Tree cascades provide the best performance (lowest latency) configuration. A tree cascade
consists of a root swit ch con nected to addi tional swit ches ( up to 8 s witches maximu m). W hen a
device on a switch requests access to another device, the request is sent the particular switch for
that device. The limitation to the tree cascade configuration is the random nature of devices
gaining access to one anot her, as fairness is not used for tree cascades.

When configuring a port for a tree cascade, use the Tree Cascade Smart Setting.

Figure 3-20: String Cascade configuration example

Figure 3-21: Tree Cascade configuration example

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 45

Automatic Trunking

Multiple links between switches are called “trunks”. Trunks provide higher bandwidth across
cascaded switches for systems inco rporating multiple initi ators. Each tru nk can improve system
throughput and provide “failover” capability. A maximum of 4 trunks between each switch is
supported. Trunking is performed automatically when ports are configured properly. Figure 3-22 is
an example of Automatic Trunking.

Each trunk is part of a trunk group. A trunk group consists of two or more cascades between two
switches. There can only be one trunk group between two switches. Each trunk group c ontains a
primary trunk. All traffic flows through the primary trunk on a switch unless specified otherwise
using the Load Balancing feature. The primary trunk is always the lowest numbered port of any
trunk group.

If the primary trunk fails, the secondary trunk automatically becomes the primary trunk unless
otherwise configured. Multiple cascades also enable switch configuration for better performance
through load balancing (see “Load Balancing” on page 46).

The Automatic Trunking page enables users to configure trunking by defining trunk groups and
assigning ports to those groups. The Automatic Trunking feature is available when one or more
ports are assigned a String or Tree Cascade Smart Setting.

To configure Automatic Trunking:

1. Click Advanced Functions > Automatic Trunking.
The Automatic Trunking page appears.

2. Select a trunk group for each port by clicking the appropriate Trunk Group option.

3. When finished making changes, click Submit.

Figure 3-22: Automatic Trunking example

Figure 3-23: Advanced Functions: Automatic Trunking page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 46

Load Balancing

Load balancing builds on the Automatic Trunking functionality by specify ing the path t hat the data
uses to flow between multiple switches. Users can manage the switch’s aggregate bandwidth by
manually distributing traffic across multiple casca de ports as shown below. A cascade port is a
port that is attached to another switch of the same type and configured as a String or Tree
Cascade Smart Setting on the Port Smart Settings page. All data flows through the primary
cascade, unless the switch is confi gured differe ntly.

In Figure 3-24, host 1 uses cascade port 1, while host 2 uses cascade port 2. All traffic will use
the lowest numbered (primary) cascade port by default but ports may be configured to use other
cascades.

Load balancing configuration settings are available on the Web Manager’s Load Balancing page.
Before implementing load balancing on the switch, the au tomatic trunki ng settings must be
configur ed. Se e “Aut om ati c Trunking” on pa ge 45 for a ddi ti on al i nfo rm ati on .

To view the Load Balancing page:

Click Advanced Functions > Load Balancing.

Note: Cascade ports must be properly configured before load balancing will work.

Note: When tape drives or ta pe librarie s a re inclu de d in m ul tiple swi tch c on figurat ions

incorporating m ult iple trun ks, place th e tap e d rive o r ta pe library a nd a ny de vic es t hat
access those devices on the secondary (duplicate) trunk, not the primary trunk.

Figure 3-24: Load Balancing Across Multiple Cascade Ports

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 47

The page is arranged as a grid of check boxes for assigning ports to cascades ("Trunk Groups").

Load Indicators

The Load Balancing page incorporates two sets of visual indicators for measuring traffic:

• Port Load Indicators–the horizontal bars on the right side of the page that display the
current load for each port.

• Trunk Load Indicators–the vertical bars at the bottom of the page that display the current
load for each trunk group.

These bars indicate the amount of traffic across a trunk or port. The size of the bars increase in
correlation to the amount of traffic and, as a bar’s size increases, can iden tify a specific tr unk or
port that is overloaded. If overloading occurs, move one or more ports to a different trunk in the
group.

To change the load balancing settings:

1. Click a Trunk Group option to place a port into a specific trunk group.

2. Continue to assign ports to trunk groups as necessary.

3. When finished, click Submit.

Fairness and Prioritization

The concept of "f airness" is based on the principl e of e nsuri ng f air device a ccess and
communication across all dev ices i n a storage sy stem. The swit ch in corporates fai rness and
prioritization through Vixel’s InSpeed technology and Automatic Trunking and Load Balancing
functionality. In cooperation with each other, these features ensure even and equal access
through multiple links fairly–effectively multiplying bandwidth.

Device prioritization can be achieved using Load Balancing and assigning only a specific device
port to a particular cascade. This ensures a specific device will always have a dedicated trunk.

Figure 3-25: Load Balancing page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 48

MONITORING THE SWITCH

The Vixel InSpeed™ SAN Storage Switch Model 375 provides several options for monitoring the
switch status and port information. This section descr ibes how to view swi tch status, the event
log, port information and utilization, and port diagnostics.

Viewing Switch Status

The Web Manager’s home page is the Switch Information page. This page is displayed first when
the Web Manager is opened and shows general switch information, including switch status, f an
and power supply operational indicators, and port health and utilization.

This page continually refreshes to guarantee that the most curre nt switch status is displayed. To
return to this page at any time, click the InSpeed™ Storage Switch menu item.

Switch Information

Current status i s provid ed for t he fol lowing items .

Item Status Indicators

Switch Status OK (green)–the switch unit is operating normally.

Fault (red)–one or more of the ports has failed, the internal temperature
has exceeded acceptable levels, or another error has occurred. Errors
appe ar in the event log . T he switc h will con tin ue to ope rate; however,
functionality may be impaired depending on the even t tha t trigger ed the
error. Regardless of the cause, the switch requires immediate a ttention .

InSpeed SOC Status OK (green)–the switch ch ipset is op erating n ormally.

Fault (red)–the switch chipset’s selftest has failed.

Enclosure Temperature OK (green)–the switch temperature is within the normal operating range.

OverTemp (red)–the enclosure temperature has exceeded the
recommended operating range.

Fan #1 OK (green)–the fan unit is working properly.

Not Present (yello w)–the po wer su pply/fa n modu le has been removed.
Fault (red)–the fan unit has stoppe d operating. Verify that the power
supply/fan module is properly seated in the switch.

Fan #2 OK (green)–the fan unit is working properly.

Not Present (yello w)–the po wer su pply/fa n modu le has been removed.
Fault (red)–the fan unit has stoppe d operating. Verify that the power
supply/fan module is properly seated in the switch.

Figure 3-26: Switch Information page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 49

Port Utilization and Health

Port utilization measures the amount of traffic passing into a port over a period of time. For
example, if an initiator is transm itting data to a tar get, the initiato r port displa ys a port utilization
value (%) while the target port does not. If the same initiator is receiving data from the target,
the target port displays a port utilization value (%) while the initiator port displays does not.

This part of the web page displays each port number, the port’s current health status, and a
vertical bar indicating the port utilization.

A port number is displayed in one of three colors depending on the port’s current health:

Port utilization is measured by a vertical bar that moves upwards as utilization increases. The
vertical bar has the three distinct levels of utilization:

Power Supply #1 OK (green)–the po wer su pply unit is working pr operly.

Not Present (yello w)–the po wer su pply/fa n modu le has been removed.
Fault (red)–the power supp ly unit ha s stoppe d operatin g. Verify that the
power sup ply/f an modu le is p rope rly se ated in the sw itch.

Power Supply #2 OK (green)–the po wer su pply unit is working pr operly.

Not Present (yello w)–the po wer su pply/fa n modu le has been removed.
Fault (red)–the power supp ly unit ha s stoppe d operatin g. Verify that the
power sup ply/f an modu le is p rope rly se ated in the sw itch.

Tip: Rolling the mouse cu rsor over the port num be r dis play s the cur ren t po rt s tate .

Port Color Indication

Green An SFP is inserted into the po rt and a devic e is connecte d to the SFP.
Yellow Bypassed – The port is by pass ed . A n SF P may be i nse rt ed in th e p ort b ut t her e

may not be a device connected to the SFP.
Loopback – Th ere is no de vice co nnect ed to t he port . The transm it and
receiver are conn ecte d to gethe r on the SFP tra nsceive r.
LIPF8Present – If the switch is receiving an F8 Failure notification, the port is
bypassed to allo w remaini ng devi ces to pro ceed with in itializat ion.
Redundant – The port is a failover link in a cascade and is not currently active.

Red TxFault – Detects an SFP transmi tter fault.

DiagTx – Detects Ordered Sets being transmitted, so traffic cannot be passed
through the port.
DataTimeout – Detects a data timeou t fault.
RxLoss – Detects a loss of received signal amplitude from the device.
SyncLoss – Det ects a loss of word sy nch roniz atio n for a spec ified time , wh ic h
may be caused by poor signal strength, intermittent line conditions, etc.

Gray Unknown – The port status canno t be d eterm ined.

NoSFP – There is no SFP c onnect or insert ed in th e po rt.

Bar Color Indication

Green The port is operating a t optimal u tilizatio n.
Yellow The port is experiencing periods of heavy traffic.
Red The port has too much traffic on it and is not operating at de sired lev els . Some

devices sh ould be trans ferr ed t o oth er port s to im prove port ut ilizat ion.

Item Status Indicators

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 50

Viewing the Event Log

The Event Log contains a list of up to 3000 event log messages generated by the switch. The
Switch Event Log page displays the event log messages with each message containing the
following information:

• Event Number – the number assigned to that specific event in the log.

• Event Date and Time – the date and time when the event was recorded in the log.

• Event Seve ri ty – th e seve ri ty l eve l f or th at e ven t.

• Event Type – the identifier assigned to that event.

• Event Description – a brief description of the event.

For a complete list of event messages and severity levels, see Appendix C : Event Messages on
page 66.

To view the event log:

Click Switch > Event Log.

The Event Log Messages page appears.

The last time the event log was polled appears at the top of the page.

To export the event log:

1. Click Export.
If the File Download dialog box appears, select Save this file to disk, and click OK to

save the file on the host system. The Save As dialo g box appears. Select the appro priate
directory, change the file name if necessary, and click Save.

The event log appears in the host system’s default text editor.

2. Select the appropriate directory to save the event log messages, change the name of the
file (if desired), and save the event log.

To delete the current list of event log messages on the switch:

1. Click Clear.
A message box appears confirming the request.

2. Click OK to delete the event log.
The event log is cleared out and a new event message is displayed reporting that the

event log has been cleared.

Figure 3-27: Switch Event Log page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 51

Viewing Port Information

The Port Information page displays the Smart Settings, Serial ID (SID), and AL_PAs currently
assigned to each port. Initiator AL_PAs are highlighted in blue to differentiate them from target
AL_PAs.

To view port information:

Click Port > Information.

The Port Information page appears.

Note: The Initiator AL_PA information can be use d to easily identify at tache d device s when

configuring load balancin g.

Field Description

Port Displays the curren t health of the port . See “Port Utiliz ation and

Health” on page 45 for additional information on port health.

Smart Setting Displays the specif ic Smart Se tting ass igned to a par ticula r port. See

“Configuring the Port Smart Settings” on page 29 for more
information on the Smar t Settings.

Serial ID (SID) When clicked, provid es additi onal infor matio n ab out th e SFP i nse rte d

in the port, if an SFP is inser ted in that particula r port.

Identified ALPAs Displays all the AL_PAs attached to the port . Initiator AL _PAs appear

highlighted in blue.

Figure 3-28: Port Information page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 52

Viewing Port Utilization

Port utilization measures the amount of traffic passing through a port over a period of time. For
example, if an initiator is transm itting data to a tar get, the initiato r port displa ys a port utilization
value (%) while the target port does not. If the same initiator is receiving data from the target,
the target port displays a port utilization value (%) while the initiator port displays does not.

The Port Utilization page displays each port’s utilization percentage based on high, average, and
low utilization.

To change the port utilization interval:

Click Advanced Functions > Thresholds > Switch. See “Adjusting the Switch Thresholds”
on page 28 for additional information.

To view port utilization:

Click Port > Utilization.

The Port Utilization page appears.

Value Description

High The highest percentage of data communication through a port over a period of

time (measured in seconds).

Average The average percentage of data communication through a port over a period

of time (measured in seconds).

Low The lowest per cent age of d ata c omm unic ation thro ugh a po rt over a pe riod of

time (measured in seconds).

Figure 3-29: Port Utilization page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 53

Viewing Port Diagnostics

This page displays diagnostic information pertaining to each port in the switch. Use the
information provided on this page to diagnose abnormally high error counts on a particular port.

To view the current diagnostic settings:

Click Advanced Functions > Diagnostics > Port.

The Port Diagnostics page appears.

Statistic Description

Port & Health Color Indicato rs

•Green

• Yellow

•Red
See “Port Utilization an d Health” on page 49 for descript ions of the health

indicators.

Insertion Count Number of times this p ort ha s been ins erte d into the netw ork sin ce the sw itch

was reset or the c ou nters we re c leare d.

CRC Errors Number of CRC errors that are detected in frames passing through this port

since the switch was reset or the counters were cleared.

Ordered Set Errors Number of Ordered Se ts th at a re rec eived on this por t w ith an enco din g er ror

since the switch was reset or the counters were cleared.

Clock Delta Diffe rence (in parts pe r million ) betwee n the int ernal sw itch clock a nd the

received clock signal on the port.

State Current state of this port – either inserted or bypassed
Beacon Port Forces both port LED s to fla sh o n and off c ontinuo usly. Use this to loca te and

take action on a specific port. The flashing overrides normal port indication
until beaconing is turned off; however, port operation continues to operate
normally.

Figure 3-30: Port Diagnostics page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 54

To save diagnostic information:

1. Click Upload to save the current diagnostics to the host system.

2. Click OK on the File Download dialog box.

3. Enter the directory path and file name.

4. Click Save.

To clear the counters:

Click Clear.

Manual Port Operation

If necessary, a port can be placed into manual bypass mode or reset. If the port is placed in
bypass mode, the port will remain in bypass mode until the switch is reset. If the port is manually
reset, the port is temporarily placed in bypassed mode and then reset to re-insert the port. These
features may be used to diagnose device problems when a device is locked up or experiencing a
high number of failures on a port.

To place a port into bypassed mode:

1. Click Advanced Functions > Diagnostics > Port.

2. Select the Bypass Port option for the appropriate port.

3. Click Submit.

To reset a port:

1. Click Advanced Functions > Diagnostics > Port.

2. Select the Reset Port option for the appropriate port.

3. Click Submit.

Bypass Port A single instance operation that force s a port int o bypass m ode. This featur e

may be used to diagnose device problems when a device is locked up or
experiencing a high number of failures on a port.

Reset Port A single instance operation that places a port in bypass mode and then

immediately s ets t he port to aut o-de tect to r e-inser t the por t. This f eat ure
may be used to diagnose device problems when a device is locked up or
experiencing a high number of failures on a port.

Statistic Description

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 55

Viewing Ordered Sets

This page displays the Ordered Sets that are being transmitted on the switch for each port since
the last time the page was displayed. Ordered Sets are used when commu nicating data acro ss
networks to indicate actions , ev ents, or status regarding the data. A list of detected Ordered Sets
and their indications is provided below.

To view ordered sets:

1. Click Advanced Functions > Diagnostics > Ordered Sets.
The Ordered Sets page appears.

Detection Indication

End of Frame
(EOF)

An End-of-Frame (EOF) delimiter has been detected; frames are present. (An EOF
immediately follows the CRC of a frame and signals the frame’s end.)

Start of Frame
(SOF)

A Start-of-Frame (SOF) delimiter has been detected; frames are present.

Idle Sequences of IDLEs are be ing trans mitte d to maint ain l ink ac tivity; no o ther data

is being transmitted.

ARB(FF) A RB(FF )s a re being trans mitted to main tain link acti vity ; no o the r dat a i s be ing

transmitted.

ARB A port is arbitrat ing for netw ork a cce ss to perf orm a task.

Read Ready
(RRDY)

The receiving no de on th is p ort has sen t an R_RDY sign al, in dic ating tha t it is
ready for a frame to be transmitted over the link.

Close (CLS) The port is attempting to begin the process of closing the current FC-AL circuit.
Open (OPN) The port is attempting t o open comm unications with ano ther po rt.

Note: As is the case with some orde red sets , an OPN may no t go all the way

around the FC-AL, instead stopping at its destination.

F8 Failure A non- swi tchin g p ort h as dete cte d a failu re on it s recei ve in put, is n otify ing oth er

ports, and is dete rmi ning wh ethe r the netw or k is s till o perat ional .
Some events tha t cou ld cause the p ort t o d etect netw ork fail ure fol low:

• A device has failed or has been powe red of f.

• T he physical co nnection be tween th e transmitter an d re ceiver is broken.

• Ac t ivating the port bypa ss circ uit d oes not typically resu lt in a network failure.

Figure 3-31: Advanced Functions: Ordered Sets page

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 3 SWITCH MANAGEMENT
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 56

F7 Initialization A port is in the non-participating mode and is attempting to win arbitration and

begin initialization, possibly because the port was reset or is powering up.
Sometimes the port is sending this sequence to another hot-cascaded switch, like
a new initiator b eing inse rted in the ne twork .

Change
Notification

A change notification has been detected and action has been taken.

Unknown The switch can not deter mine wh at is being t ransmitted .
Invalid An invalid transmit word has been detected.
CRC Error A Frame CRC erro r has bee n dete cted.
Point-to-Point A point-to-point connection has bee n detec ted.

Detection Indication

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 4 TECHNICAL REFERENCE
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 57

CHAPTER 4TECHNICAL REFERENCE

TROUBLESHOOTING DEVICE CONNECTIONS

Troubleshooting Device Connections............. 57

Troubleshooting Management Connection s .... 58

Port Bypass Conditions and Recovery ........... 58

Default Smart Setting Attributes.................. 59

Fibre Channel References ................. ...... .... 60

Problem Recommended Action

SFP installed in one or
more ports but no
LEDs lit

1) Verify that the power cord is firmly seated into switch and is connected to
a properly earth ed recept acle (ou tlet).

2) Check the Power LED to e nsure that the s witc h is turne d on.

3) Verify that the SFP is firm ly s eat ed.

SFP installed but only
yellow LED is lit

Reseat the SFP. If the same conditio n occurs, the SFP is prob a bl y f aulty a nd
should be replace d.

SFP installed with both
green and yellow LEDs
lit

1) Make sure that th e de vice is powe red o n an d ope rating pro pe rly.

2) Unplug the fiber cable from the node and verify that an optical signal is
present on the cable receiver lead.

3) Verify that the fibe r ca ble is ful ly s eat ed at e ither en d.
If optical power meter is available, verify the device is transmitting a signal.
If there is n o s igna l pr ese nt, the devi ce m ay requ ire r ebo oti ng, de vic e
drivers may n eed to be r ein stalle d, or the H BA or d isk co ntr oller h ardwar e
may require servicing.
If a signal is present on both the cable lead and the end node, the HBA or
disk controller may require service.

4) Ensure the device and switch are operational and set to the same speed.

SFP installed with only
green LED lit, but
devices are not
communicating

The switch is rece iving a valid sign al from the device , but no up per level
protocols are active.

1) Verify that the proper HBA device drivers are loaded for the appropriate
operating system and that the host has been configured to recognize
attached d is k de vice s.

2) Improper FC-AL initializat ion coul d result fr om a defec tive or inope rative
adapter card or device. Run adapter diagnostics with a loopback connector
to see if the adap ter is w ork ing p rope rly.

3) Unplug the fiber cable from the end node and verify that an optical signal
is present on the cab le rece iver lead . If no signal is present, the cable’s
receiver lead may be bad and th e device ma y be stre aming F8 Failure
notifications.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 4 TECHNICAL REFERENCE
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 58

TROUBLESHOOTING MANAGEMENT CONNECTIONS

PORT BYPASS CONDITIONS AND RECOVERY

Problem Recommended Action

Serial cable installed
but connection does
not appear on terminal

1) Cycle po wer by r ein sta lling the pow er c ord.

2) Check the terminal emulation program’s serial port parameters.

3) Replace the serial cable. (Make sure it is a null modem cable.)

Ethernet cable
installed but Web
Manager does not
appear

1) Ensure a crossover ethernet cable is used (unless using an ethernet hub).

2) Check the IP addresses on the switch and workstation as follows:
At a command line pro mpt, type ping DNSorIP (where DNSorIP is the
switch’s DNS name or IP address) and press ENTER.
If a “Reply from…” or “...is alive...” message appears, the devices can
communicate.
If a “Request timed out” message appears (or the command times out), the
devices cannot communicate. Trace the cabling. If needed, reconnect the
devices.

Operational

Condition

Recovery

Rx_los is asserted by
an SFP/GBIC

The port stays bypass ed until rx_lo s is de-asserte d. At that time, the port
insertion w ill be a utoma tica lly retr ied. Th e p ort co ntin ues to st ay b yp asse d
until the por t ca n pa ss t he port ins ert ion crit eria .

Tx_fault is asserted by
an SFP/GBIC

The port stays bypassed until tx_fault is de-asserted. At that time, the port
insertion w ill be a utoma tica lly retr ied. Th e p ort co ntin ues to st ay b yp asse d
until the por t ca n pa ss t he port ins ert ion crit eria .

F8 Failure notification
is received by the port
(when the LIP F8
Recover policy is
enabled)

The switch auto mat ically trie s to re-ins ert the d evice , by send ing F7
Initialization notifications to the device connected to the bypassed port. The
port continue s t o sta y by pass ed u ntil the devi ce r etu rns F7 In itializ a tion
notifications to the po rt and passe s the port inse rtion criteri a.

Loss of Sync (>100ms) The port st ays bypas sed until a signal is re- establis hed. At that time, the

port insertio n will be auto matic ally retr ied. The port cont inues to s tay
bypassed until the port can pass the port insertion criteria.

Firmware Initiated The port stays bypassed until the firmware sets the port control back to

automatic. At that time , the po rt inse rtion wi ll be autom at ically retrie d. Th e
port continues to stay bypassed until the port can pass the port insertion
criteria.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 4 TECHNICAL REFERENCE
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 59

DEFAULT SMART SETTING ATTRIBUTES

Initiator

or Target

Initiator

with Stealth

Target

with Stealth

Fabric

Connection

Tree Cascade

String Cascade

--Trunk 1

String Cascade

--Trunk 2

String Cascade

--Trunk 3

String Cascade

--Trunk 4

Smart Setting
Name

Initiator
or Target

Initiator
with
Stealth

Target
with
Stealth

Fabric
Connection

Tree
Cascade

String
Cascade-

-Tru nk 1

String
Cascade-

-Tru n k 2

String
Cascade-

-Trunk 3

String
Cascade-

-Trunk 4

Smart Setting
Type

Initiator
or Target
Port

Initiator
or Target
Port

Initiator
or Target
Port

Tree
Cascade

Tree
Cascade

String
Cascade
1

String
Cascade
2

String
Cascade
3

String
Cascade
4

Smart
Insertion
Policy

Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled

Port Test
Before Insert
Policy

Enabled Enabled Enabled Disabled Disabled Disabled Disabled Disabled Disabled

Stealth
Intelligent
Change
Manager

Off: No
Change
Protection

Initiator:
Only
Receive
Changes

Target:
Only
Send
Changes

Off: No
Change
Protection

Switch­Switch:
Send and
Receive
Changes

Switch­Switch:
Send and
Receive
Changes

Switch­Switch:
Send and
Receive
Changes

Switch­Switch:
Send and
Receive
Changes

Switch­Switch:
Send and
Receive
Changes

Change
Notification
on Insertion
Policy

Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled

Change
Notification
on Removal
Policy

Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled

Bad Device
Recovery
Policy

Disabled Enabled Disabl ed Disabled Disabled Dis abl ed Dis abled Disabled Disabled

Clear on Stall
Policy

Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled

Bypass on No
Activity Policy

Enabled Enabled E nabled Enabled Enabled Enabled Enabled Enabled Enabled

Bypass on OS
Error Policy

Disabled Dis abled Disabled Disabled Disabled Disabled Disabled Disabled Disabled

Bypass on CRC
Error Policy

Disabled Disabled Disabled Disabled Disabled Disabl ed Disabled Disabled Disab led

Port Control

Auto Auto Auto Auto Aut o Auto Au to Auto Auto

Bypass on
Clock Delta
Policy

Disabled Disabled Disabled Disabled Disabled Disabl ed Disabled Disabled Disab led

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 CHAPTER 4 TECHNICAL REFERENCE
USER’S GUIDE

EMBEDDED

IN THE FUTURE OF STORAGE 60

FIBRE CHANNEL REFERENCES

The following books give useful information about Fibre Channel.

•Alan F. Benner, Fibre Channel. McGraw-Hill, 1996. ISBN 0-07-005669-2.

•Tom Clark, Designing Storage Area Networks. Addison Wesley Longman, 1999,
ISBN 0-201-61584-3.

•Jan Dedek, Fibre Channel - The Basics. ANCOT Corporation, 1997. ISBN 0-9637439-3-7.

• Robert Kembel, Arbitrated Loop. Connectivity Solutions, 1996. ISBN 0-931836-82-4.

• Robert Kembel, A Comprehensive Introduction. Connectivity Solutions, 1998. ISBN
0-931836-84-0.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375
U

SER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 61

Appendixes

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 APPENDIX A SPECIFICATIONS
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 62

APPENDIX A Specifications

SWITCH SPECIFICATIONS

O

PERATING CONDITIONS

The switch must be operated in a clean, dry environment with unrestricted airflow. Air flows in
through the cosmetic end and out through the business end (sometimes called the transceiver
end or “back -of-b ox”) .

To avoid ov erheati ng, maint ain a minimu m clear anc e of two in ches ( 50.8 mi llimeters) on each end
of the switch (the cosmetic end and the business end). Allow an ade quate amount of space on the
top and sides of the switch for proper air ventilation. Do not place the switch on heat-generating
surfaces. Operating conditions are listed below.

Number of Ports 20
Operating Rate All ports ope rate at 1.0625 or 2.125 Gb ps (selec table)
Port Media Type SFP
Enclosure 1U full-rack form-f actor
Management Interface RS-232 or 10/100 Ethernet
Operating Mode Switching or Non-switching modes
Configurability Management interface configurable
Power On Selftest (POST) Yes
Dimensions 17 .20" x 1.57" x 17.50" (W x H x D)
AC Power Input 50 or 60 Hz / 100 – 2 50 VAC / 1. 0 – 0.5 A
AC Power Connector IEC connector
Weight Approximately 18 lb s.

Requirement Value

Operating Temperature 0°C to 40°C normal operation (ambient air temperature)
Storage -40°C to 80°C non-condensing
Power 50 or 60 Hz / 100 – 250 VAC / 1. 0 – 0 .5 A

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 APPENDIX B CLI QUICK REFERENCE
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 63

APPENDIX B CLI Quick Reference

CONNECTING TO THE CLI

The Command Line Interface (CLI) can be accessed through a network interface using a terminal
emulation program, such as HyperTerminal®, or through the serial interface from a local
computer. Refer to the InSpeed Storage Switch CLI Reference Guide for detailed descriptions of
CLI commands and usage. A link is available through the Web Manager interface under Help >
Product Documentation.

To connect through a network interface:

Use a network terminal emulation program. For example, if using the telnet command on a
Windows workstation, type telnet IPaddress at a command prompt.

To connect through a serial interface:

1. Attach one end of the included RS-232 null modem cable to the computer’s DB-9 serial
port, and attach the other end to the switch’s DB-9 serial port.

2. Open a terminal session through a serial terminal emulation program (such as
HyperTer minal®) with the appropriate serial port (for example, COM1) and the following
serial port parameters:

• Bits per second: 19200

• Data bits: 8

•Parity: None

•Stop bits: 1

• Flow control: None

3. If using HyperTerminal, press E

NTER to receive a prompt.

4. If using the tip command on a UNIX workstation, do the following:

a. View the /etc/remote file and create an alias similar to Hardware but with the

serial port parameters above. (Suggested name: Switch)

b. Use the tip command to establish a connection through the created alias, for

example tip switch. (For more information, see the tip c ommand Manual page.)

LOGGING IN AND OUT

The CLI does not require login if only viewing basic system information. However, for viewing
detailed system information or configuring any switch settings, users must log in to the switch.

To log in to the CLI:

Type the password at the prompt and press E

NTER. (The default password is password.)

To log out of the CLI:

Type lo and press E

NTER, o r exi t the t erm ina l ses sion .

Connecting to the CLI ............................ ....... ....... 63

Logging In and Out.............................................. 63

Using the CLI.............. ........................................ 64

Frequent Switch Configuration Tasks ...................... 64

CLI Commands .................. ...... ....... ...... .............. 65

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 APPENDIX B CLI QUICK REFERENCE
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 64

USING THE CLI

The CLI enables users to monitor and change system a nd port configurations, configure One-Step
Zoning, Automatic Trunking, Load Balancing, and event reporting parameters, and download and
install firmware.

For additional i nfo rma tio n o n t he C LI, se e t he InSpeed Storage Switch CLI Reference Guide.

To enter a command:

• Type the command text or the number of the command.

To return to the previous menu:

Type .. and press E

NTER.

To return directly to the Root menu:

Type root and press E

NTER.

To cancel a prompt or input request:

Press E

NTER.

To display help for specific command:

Type ? <command> and press E

NTER.

To save changes to the switch configuration at any time:

1. Type save at any command prompt and press E

NTER.

A message appears confirming the request.

2. Type y and press E

NTER.

FREQUENT SWITCH CONFIGURATION TASKS

A list of frequent switch configuration-related tasks is provided below. The list displays the task
and the corresponding CLI command.

To… Type…

View switch statu s show sysinfo
Change general s witch con figuratio n config sys
Change the IP Address config network ip
Change the switch speed config sys speed
View the event log show events
Upgrade the firmware fw
Change the port s etti ngs config port
Configure zoning config zone
Configure trunking config load
Configure lo ad ba lan cing config trunk
Reset the switch reset
Perform d ia g n os ti cs diag
Reset the switch to factory defa ult setting s config default
Change the password config password

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 APPENDIX B CLI QUICK REFERENCE
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 65

CLI COMMANDS

All of the CLI commands for the Vixel InSpeed™ SAN Storage Switch Model 375 are shown below
in a tree diagram.

Using the “help” command at the command line may provide additional information.

root --> 1. config --> 1. save

2. sys --> 1. speed

2. mode

3. oserr

4. crcerr

5. blkarb

6. clkd

7. time

8. name

9. location

10. contact

11. events

12. sev

13. fault

14. evclr

15. clrled

16. ..

17. ?

3. default

4. port --> 1. clkd

2. beacon

3. show

4. types

5. add

6. view

7. edit

8. del

9. type

10. ..

11. ?

5. password

6. load --> 1. show

2. lbclr

3. delprt

4. addprt

5. delalpa

6. addalpa

7. ialpa

8. util

9. pu 1

10. pu 2

11. ..

12. ?

7. t r unk --> 1. addpr t

2. delprt

3. showmem

4. clr

5. ..

6. ?

8. network --> 1. reset

2. show

3. ip

4. mask

5. gateway

6. ..

7. ?

9. zone --> 1. bzht

2. bzdt

3. addprt

4. delprt

5. showmem

6. act

7. deact

8. zstate

9. zclr

10. addblk

11. delblk

12. showblks

13. hz

14. bzr

15. alpas

16. ..

17. ?

10. ..

11. ?

2. diag --> 1. galpa

2. glim

3. os

4. ps

5. delta

6. showpri

7. prtctrs

8. clrctr

9. beacon

10. con

11. who

12. ialpa

13. ..

14. ?

3. show --> 1. events

2. ptype

3. portinfo

4. prtctrs

5. clrctr

6. sysinfo

7. zninfo

8. lbinfo

9. os

10. galpa

11. glim

12. sensors

13. getcon

14. sync

15. dump

16. sid

17. zalpas

18. ..

19. ?

4. fw --> 1. tftp

2. xmodem

3. revert

4. show

5. reset

6. ..

7. ?

5. reset

6. ?

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 APPENDIX C EVENT MESSAGES
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 66

APPENDIX C Event Messages

The event messages for the switch are listed below. For explanations, contact a customer service
representative. The message’s applicable severity level as defined below is also provided.

These severity levels can be used to designate which events trigger trap messages. Use the
Command Line Interface (CLI) to designate the minimum severity level of events to be logged in
the Event Log and at which severity level to illuminate the switch’s Fault LED.

Severity

Level

Severity Description

1 EMERG Immediate ac tion r equ ired; sys tem failin g
2 ALERT Unrecoverable conditi on report ed; majo r event in pr ogress
3 CRIT Event fai led wit h pos sibl e loss of int egrity
4 ERR Condit ion faile d; action req uired
5 WRN Failed event occurred; no action required
6 NOTIFY Configuration error or abnorma l event occu rred; no act ion require d
7 INFO E vent occurred; no action required

Event Event Message Severity

1 Message log cleared INFO
5 Power Supply # Failed ALERT
6 Power S upply # On line NOTIFY
7 Power Supply # Remove d ALERT
8 Power Supply # Inserted NOTIFY

9 Fan has stopped EMERG
10 Fan has returned ALERT
19 Temperatures over limit ALERT
20 Temperature OK INFO
50 SPF Overvol tage EMERG
54 SOC has detect ed a CRC er ror in the EEP ROM NOTIFY
70 PORT # bypassed NOTIFY
71 PORT # inserted NOTI F Y
72 Transceiver detected at port # NOTIFY
73 Transceiver removed at port # NOTIFY
74 SEOC occu rred on PORT # NOTIFY
75 Port exceeded OS threshold NOTIFY
76 Port exceeded CRC threshold NOTIFY
77 Loop UP on Port # NOTIFY
78 Loop DO WN o n Port # NOTIFY
79 PORT received a LIP(F8) WRN

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 APPENDIX C EVENT MESSAGES
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 67

80 PORT CRC Erro r detecte d in frame WRN
81 PORT did not receive LIPF7) with in timeout WRN
82 PORT is ready to be in serted DBG
83 Segment stall on PORT # NOTIFY
84 Bad Ope n on PO RT # WRN
85 Erro r du ring Port D is c. NOTIFY
86 PORT PTBI failed due to tim eout NOTIFY
87 PORT change d to STATE NOTIFY
88 Transceiver in PORT has been cycled NOTIFY
89 PORT has cycled between insert/bypassed (not necessarily in that order) NOTIFY
90 Loop C YCLED o n Port # NOTIFY
91 Port exceeded Clk Delta threshold INFO
95 Interframe has been received INFO
96 Intersw itch link add ed/remove d INFO
97 LIP Cycle Timeout INFO
98 API Initial ized OK INFO
99 Selftes t failure ERR

100 Received Unknown event INFO
101 CRC detected on either an ISL LIP or Generic Frame NOTIFY
107 Trap task failed to update trap des tination in fo. CRIT
135 CLI level 1 passw ord changed NOTIFY
136 CLI level password changed to default setting NOTIFY
150 WEB level 1 pa sswor d change d NOTIFY
151 Web password level changed to default setting NOTI F Y
165 System config reset to factory default ERR
166 New Port Config Type added NOTIFY
167 Port Config Type deleted NOTIFY
168 Current Config saved to flash NOTIFY
169 Error in sa ving c onfi g file to fla sh ERR
170 Error in r etri eving con fig infor ma tion ERR
171 Config File successfully configured system NOTIFY
172 Error in i nitia lizin g sy st em with con fig f ile ERR
198 A device tried to access another device that was not in the same zone NOTIFY
199 Health timer has e xpir ed o n ZONE NOTIFY
208 PORT is over threshold NOTIFY
218 Trunk DOWN on PORT # NOTIFY
219 Trunk UP on PORT # NOTIFY
220 New Primary Trunk NOTIFY

Event Event Message Severity

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 APPENDIX D AL_PA CROSS REFERENCES
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 68

APPENDIX D AL_PA Cross References

Arbitrated Loop Physical Addresses

AL_PA AL_PA ID AL_PA AL_PA ID AL_PA AL_PA ID

(hex) (hex) (decimal) (hex) (hex) (decimal) (hex) (hex) (decimal)

EF 00 0 A3 2B 43 4D 56 86
E8 0 1 1 9F 2C 44 4C 57 87
E4 0 2 2 9E 2D 45 4B 58 88
E2 0 3 3 9D 2E 46 4A 59 89
E1 0 4 4 9B 2F 47 49 5A 90

E0 0 5 5 98 30 48 47 5B 91
DC 06 6 97 31 49 46 5C 92
DA 07 7 90 32 50 45 5D 93
D9 08 8 8F 33 51 43 5E 94
D6 09 9 88 34 52 3C 5F 95
D5 0A 10 84 35 53 3A 60 96
D4 0B 11 82 36 54 39 61 97
D3 0C 12 81 37 55 36 62 98
D2 0D 13 80 38 56 35 63 99
D1 0E 14 7C 39 57 34 64 10 0

CE 0F 15 7A 3A 58 33 65 10 1
CD 10 16 79 3B 59 32 66 10 2

CC 11 17 76 3C 60 31 67 103
CB 12 18 75 3D 61 2E 68 104
CA 13 19 74 3E 62 2D 69 105
C9 14 20 73 3F 63 2C 6A 106
C7 15 21 72 40 64 2B 6B 107
C6 16 22 71 41 65 2A 6 C 108
C5 17 23 6E 42 66 29 6D 109
C3 18 24 6D 43 67 27 6E 110
BC 19 25 6C 44 68 26 6F 11 1
BA 1A 26 6B 45 69 25 70 112
B9 1B 27 6A 46 70 23 71 113
B6 1C 28 69 47 71 1F 72 114
B5 1D 29 67 48 72 1E 73 115
B4 1E 30 66 49 73 1D 74 116
B3 1F 31 65 4A 74 1B 75 117
B2 20 32 63 4B 75 18 7 6 118
B1 21 33 5C 4C 76 17 77 119
AE 22 34 5A 4D 77 10 7 8 120

AD 23 35 59 4E 78 0F 79 121

AC 24 36 56 4F 79 08 7A 12 2
AB 25 37 55 50 80 04 7B 123
AA 26 38 54 51 81 02 7C 124
A9 27 39 53 52 82 01 7D 125
A7 28 40 52 53 83 00 7E 126
A6 29 41 51 54 84 --- 7F 127
A5 2A 42 4E 55 85 --- -- - ---

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 APPENDIX E GLOSSARY
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 69

APPENDIX E Glossary

AL_PA or Arbitrated
Loop Physical Address

A one-byte valu e used t o i denti fy a por t in a n Ar bi trated Lo op to po logy. The
value of the AL_PA correspo nds to bits 7:0 of the 24-bit Native Addr ess
Identifier.

Arbitration The process of selecting one respondent from a group requesting service at

the same time.

Close (CLS) An Arbitrated Loop protocol used to terminate a loop circuit.
Current Fill Word The fill word that the Loop Port State Machine uses when a fill word is to be

transmitted.

Duplex Cable Two fibers in one cable suitable for duplex transmission.
Fiber Optics Light transmission through optical fibers for communication or signaling
Fibre Channel Fi bre Channel is a data transfer interface technology that maps several

common transp ort proto cols in cludi ng IP an d SCSI , al low ing it to me rge
high-speed I/O and netwo rking fun ction ality in a sing le conne ctivity
technology. Fibre channel is an open standard as defined by ANSI and OSI
standards and operates over copper and fiber optic cabling at distances of up
to 10 Kilomete rs. It is un ique in its su ppo rt of mult ipl e inte rop erable
topologies inclu d ing point-to-point, ar bit rated-loop and switchin g and it offers
several qualities of s ervi ce for n etwor k op timiz at ion. W ith its large pa cket
sizes, Fibre Channel is ide al for storage, video, graphic and mass data tr ansf er
applications.

LED Light-Emitting Diode. A s tatus indicat or on a switch.
Gb/s Gigabits per secon d.
Node An entity with one or mo re N _Ports or NL_Ports.
Open (OPN) An Arbitrated Loop protocol used to e stabl ish a loop circ uit.
Protocol A data transmission convention which may include timing, control, formatting,

error detection wit h cor rectio n and d ata repre senta tion .

SCSI Small Computer System Interface. Standard interface for storage modules.
SFP Small Form-Factor Pluggable transceiver. These transceivers are fully

compliant with FC- PI and MSA st andar ds and occ upy less than half the board
space of the existing GBIC products.

Topology The logical and/or physical arrangement of stations on a network. Fibre

Channel topologies include point -to-po int, Arbitrated Loop, a nd switche d
fabric.

Transceiver A device that converts one form of signaling to another for both transmission

and reception. SFPs and GBICs are transceivers.

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 INDEX
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 70

Index

A

AL_PA Cross References 68
AL_PA zoning 42

B

Bad Device Recovery policy 34
Bad Zone Recover y policy 42
Blocking ARB 24
Bypass on Clock Delta policy 35
Bypass on CRC Error policy 35
Bypass on No Act ivi ty po licy 35
Bypass on OS Error policy 35

C

cascades 44

strings 44

trees 44

Change Notification on Insertion policy 34
Change Notification on Removal policy 34
change notifications 34
Clear on St all poli cy 35
CLI

commands 65

connecting 63

frequent tasks 64

logging in and out 63

configuration files 36, 37
configuring

network interface 16

Smart Settings 29

switch settin gs 22

Web Manager 17

custom Sm art Set ting s 31

D

date and time settings 26
desktop installatio n 7
device prioritiza tion 47
diagnostics 35

port 53

displaying

event log 50

ordered sets 55

port diagnostics 53

port informatio n 51

port utilization 52

switch statu s 48

documentation 18
downloading f irmw are 36

E

ethernet LEDs 9
event log 50

messages 66

F

Fabric Connection Sma rt Setting 30
features, s wit ch 2
Fibre Channel references 60
firmware 36

changing versions 37
loading 36

G

glossary 69

H

hard zoning 43

I

Initialization Ma ster 39
Initiator or Target Sm art Sett ing 30
Initiator with Stealth Sm art Setti ng 30
InSpeed Technology 2
installation, sw itch 6, 7

UL guideline s 7
installing th e s witch 6
introduction 1

J

joining mult iple sw itche s 44

L

LEDs

2 Gb/s 10

ethernet 9

port 10

Port Bypassed 10

POST Fault 10

Power 10

power supply/fan module 11

SFP Status 10

switch 9

Switch Operatio nal 10

system 10
load balancing 46
loading firmwar e 36
logging in and o ut 63
logging in to the sw itch 22

M

managing the switch 21
monitoring the switch 48

N

network interface configuratio n 16
network settings 23

O

operating cond itions 62
operating speed 24
ordered sets 55
overview 1

P

password 63

changing 27
policies 33, 34, 35

Bad Device Recovery 34

Bypass on Clock Delta 35

Bypass on CRC E rro r 35

Bypass on No Activity 35

Bypass on OS Error 35

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 INDEX
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 71

Change Notific ation on In sert ion 34
Change Notific ation on R emo val 34
Clear on St all 35
Port Test Before Insert (PTBI) 33

port

diagnostics 53
hard zoning 43
information 51
Smart Settings 30

assignments 32
change notifications 34
creating custom 31
diagnostics 35
Fabric Connection 30
Initiator or Target 30
Initiator with Stealth 30
port informatio n 33
port recovery 3 4
pre-insertion te st ing 33
String Cascade 30
Target with Stealth 30
Tree Cascade 30

utilization 52

port bypass 54

conditions a nd r eco ve ry 58
port informatio n 33
port LEDs 10
port reset 54
Port Test Before Insert (PTBI) policy 33
ports

in multiple zones 40
power supply/fan module 14

LED 11
powering on the switch 13
pre-insertion testing 33
prioritization of devi ces 47

R

rack installation 7

UL guideline s 7
references, Fibre Channel 60

S

serial interface connection 63
SFP

attaching device s 12

compatibility 12

installation 12

removal 12
shipped conte nts 6
Smart Set tings 29, 30 , 59

assignments 32

change notifications 34

creating 31

default 59

diagnostics 35

Fabric Connection 30

Initiator or Targ et 30

Initiator with S tealth 30

policies 33

port informatio n 33

port recovery 34

pre-insertion testing 33

String Cascad e 30

Target with Stealth 30

Tree Cascade 30
SNMP traps 25
speed, operating 24
String Cascade Sm art Sett ing 30
string cascades 44
switch

cascades 44

changing the password 27

configuration 22

configuration files 36, 37

date and time settings 26

default Smart Settin gs 59

event log 50

event log messages 66

features 2

firmware 36

general settings 23

hard zoning 43

identification 23

initial setup 19

installation 6, 7

LEDs 9

load balancing 46

management 15, 21

monitoring 48

network settings 23

operating cond itions 62

ordered sets 55

overview 1

package contents 6

policies 33, 34, 35

port diagnostics 53

port informa tion 51

port utilization 52

powering on 13

settings 22

specifications 62

speed 24

status 48

telnet session 27

thresholds 28

trunking 45

unpacking 6

version 24

Web Manager login 22

zoning 38, 39, 40, 41
system LEDs 10

T

Target with S tealth Smar t Se ttin g 30
telnet session 27
temperature 62
terms

see glossary 69
thresholds 28
time and date settings 26
traps 25
Tree Cascade Smar t Setting 30
tree cascades 44
troubleshooting 57
trunking 45

VIXEL INSPEED™ SAN STORAG E SWIT C H MODEL 375 INDEX
USER’S GUIDE

EMBEDDED IN THE FUTURE OF STORAGE 72

U

UL guideline s 7
unpacking the switch 6

V

version inform ati on 24
viewing

event log 50
ordered sets 55
port diagnostics 53
port informatio n 51
port utilization 52
switch statu s 48

W

Web Manager 15

agent up time 24
automatic trunking 45
Bad Zone Recov ery 42
configuration 17
configuration files 36, 37
event log 50
firmware 36
getting started 16
hard zoning 43
initial switch set up 19
load balancin g 46
loading firmw are 36
network location 23
network settings 23
opening a te lnet s es sion 27
ordered sets 55
overview 17
password 27
port diagnostics 53
port informatio n 51
port utilization 52
Smart Settings 29
SNMP traps 25
switch iden tifica tion 23
switch login 22
switch spee d 24
switch statu s 48
switch thres hold s 28
switch versio n 24
time settings 26
zoning 38, 39, 40, 41

Z

Zone Initialization Master 39
zoning 38

bad zone rec ove ry 42
hard zoning 43
Initialization Ma ster 39
multiple switch es 41
ports in multiple zo nes 40
single switch 39
using AL_PAs 42
