ViVOpay 3000 Installation Guide

for VeriFone Ruby

May 2004 Version 1.0

ViVOtech®, Inc.

451 El Camino Real

Santa Clara, CA 95050
Ph: 408.248.7001, ext.105
Email: [e-mail]

www.vivotech.com

Part number: 600-1030-00

Copyright 2004, ViVOtech, Inc. All rights reserved.

ViVOtech, Inc.
451 El Camino Real
Santa Clara, CA 95050
Phone: [phone]

Written and designed at ViVOtech, Inc.

This paper, as well as the software and hardware described in it, is furnished under
license and may be used or copied online in accordance with the terms of such
license. The content of this paper is furnished for information use only, is subject
to change without notice, and should not be construed as a commitment by
ViVOtech, Inc. ViVOtech, Inc assumes no responsibility or liability for any errors or
inaccuracies that may appear in this document.

Except as permitted by such license, no part of this publication may be reproduced
or transmitted by electronic, mechanical, recording, or otherwise, or translated into
any language form without the express written consent of ViVOtech, Inc.
ViVOtech, ViVOwallet, ViVOcard, ViVOpay, ViVOplatform Dynamic Strip,
ViVOsmartcable and ViVOgiftcard are trademarks or registered trademarks of
ViVOtech, Inc. All other products or name brands are trademarks of their
respective holders.

May 2004

VeriFone Ruby Installation Guide 1

The ViVOpay 3000™ patent-pending Dynamic Strip™ technology enables
contactless payments without hardware or software changes to existing POS
devices at minimum cost.

This document assumes that installers are familiar with their host POS system.

NOTE: It is highly recommended that you review the procedure
at least once prior to exposing the adhesive mounting tapes.

Obtain the necessary components by removing the following ViVOtech products
from the shipping carton:

• ViVOpay power adapter

•Dynamic Strip

• Alcohol Wipe

• Cable support clip

• ViVOpay 3000

Obtain the following products from your work area:

• Your POS terminal, turned on

• Ruby, powered up

• Serial link cable

•Pencil

The Plug-and-Play application is installed as follows:

1. Clean the terminal

Use the alcohol wipe to clean the POS terminal
case. Wipe the top and side areas around the
magnetic strip where the cable clips will be attached.

CAUTION: Do not push the pad into the strip!

3 VeriFone Ruby Installation Guide V 1.0
