Vivitek D755WT, D751ST User Manual

Copyright

This publication, including all photographs, illustrations and software, is protected under international
copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may
be reproduced without written consent of the author.

© Copyright 2013

Disclaimer

The information in this document is subject to change without notice. The manufacturer makes no
representations or warranties with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of
the manufacturer to notify any person of such revision or changes.

Trademark Recognition

Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations
and pending applications in other countries throughout the world.

HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.

All other pro
acknowledged.

duct names used in this manual are the properties of their respective owners and are

— i—

DLP Projector—User’s Manual

Important Safety Information

Important:

It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years of safe use of the projector.
Keep this manual for future reference.

Symbols Used

Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
The following styles are used in this manual to alert you to important information.

Note:

Provides additional information on the topic at hand.

Important:

Provides additional information that should not be overlooked.

Caution:

Alerts you to situations that may damage the unit.

Warning:

Alerts you to situations that may damage the unit, create a hazardous environment, or cause
personal injury.

Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:

“Push the Menu button on the remote control to open the Main menu.”

General Safety Information

 Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in

the unit. For servicing, contact qualified service personnel.

 Follow all warnings and cautions in this manual and on the unit case.
 The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the

lens when the lamp is on.

 Do not place the unit on an unstable surface, cart, or stand.
 Avoid using the system near water, in direct sunlight, or near a heating device.
 Do not place heavy objects such as books or bags on the unit.

— ii—

Projector Installation Notice

 Place the projector in a horizontal position

The tilt angle of the projector should not exceed 15 degrees, nor should the projector be

installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease

dramatically, and may lead to other unpredictable damages.

 Allow at least 50 cm clearance around the exhaust vent.

 Ensure that the intake vents do not recycle hot air from the exhaust vent.
 When operating the projector in an enclosed space, ensure that the surrounding air temperature

within the enclosure does not exceed operation temperature while the projector is running, and the
air intake and exhaust vents are unobstructed.

 All enclosures should pass a certified thermal evaluation to ensure that the projector does not

recycle exhaust air, as this may cause the device to shutdown even if the enclosure temperature is
with the acceptable operation temperature range.

Verify Installation Location

 To supply power, the 3-blade (with earthing lead) socket should be used to ensure proper

grounding and equalized ground potential for all of the equipment in the Projector System.

 The power code provided with the Projector should be used. In case of any missing item, other

qualified 3-blade (with earthing lead) power cord can be used as substitution; however, do not use
2-blade power cord.

P

r

e

f

a

c

P

P

ee

r

e

f

a

c

r

e

f

a

c

e

 Verify if the voltage is stable, grounded properly and there is no electricity leakage.

 Measure total power consumption which should not higher the safety capacity and avoid safety

issue and short circuit.

 Turn on Altitude Mode when located in high altitude areas

 The projector can only be installed upright or inverted.

 When installation the bracket, make sure the weight limit is not exceed and firmly secured.

 Avoid installing near air conditioner duct or subwoofer.

 Avoid installing at high temperature, insufficient cooling and heavy dust locations.

 Keep your product away from fluorescent lamps to avoid malfunction caused by IR interference.

 The VGA IN connector should be connected to the VGA IN port. Note that it should be inserted

tightly, with the screws on both sides securely fastened to ensure proper connection of the signal
wire for achieving optimal display effect.

 The AUDIO IN connector should be connected to the AUDIO IN port and CANNOT be connected

to AUDIO OUT or other ports like BNC, RCA; otherwise, it will lead to mute output and even
DAMAGE the port.

 Install the projector above 200cm to avoid damage.

 The power cord and signal cable should be connected before power on the projector. During the

projector starting and operating process, DO NOT insert or remove the signal cable or the power
cord to avoid damaging the projector.

— iii—

DLP Projector—User’s Manual

Cooling notes

Air outlet

 Make sure the air outlet is 50cm clear of any obstruction to ensure proper cooling.

 Air outlet location should not be in front of the lens of other projector to avoid causing illusions.

 Keep the outlet at least 100cm away from the inlets of other projectors

 The projector generates a massive amount of heat during use. The internal fan dissipates the heat

of the projector when shutting down, and such process may continue for a certain period. After the
project enters STANDBY MODE status, press the AC power button to turn off the projector and
remove the power cord. DO NOT remove the power cord during the shutdown process, as it may
cause damage to the projector. In the meantime, the delayed heat radiating will also affect the
service life of the projector. The shutdown process may vary depending on the model used.
Whatever the case may be, be sure to disconnect the power cord till after the projector enters the
STANDBY status.

Air inlet

 Make sure there is no object blocking air input within 30 cm.

 Keep the inlet away from other heat sources

 Avoided heavy dust area

— iv—

P

r

P

r

P

Power Safety

 Only use the supplied power cord.
 Do not place anything on the power cord. Place the power cord where it will not be in the way of

foot traffic.

 Remove the batteries from the remote control when storing or not in use for a prolonged period.

Replacing the Lamp

Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 43

for clear and safe instructions for this procedure. Before replacing the lamp:

 Unplug the power cord.

 Allow the lamp to cool for about one hour.

Caution:

In rare cases the lamp bulb may burn out during normal operation and cause glass dust or shards
to be discharged outward from the rear exhaust vent.

Do not inhale or do not touch glass dust or shards. Doing so could result in injury.
Always keep your face away from the exhaust vent so that you do not suffer from the gas and

broken shards of the lamp.

e

f

a

c

ee

e

f

a

c

r

e

f

a

c

e

Cleaning the Projector

 Unplug the power cord before cleaning. See Cleaning the Projector on page 48.

 Allow the lamp to cool for about one hour.

Regulatory Warnings

Before installing and using the projector, read the regulatory notices in the Regulatory Compliance section

on page 63.

Important Recycle Instructions:

Lamp(s) inside this product contain mercury. This product may contain other electronic waste that
can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal
Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG

specific disposal information check WWW.LAMPRECYCLE.ORG.

. For lamp

Symbol Explanations

DISPOSAL: Do not use household or municipal waste collection services for
disposal of electrical and electronic equipment. EU countries require the use
of separate recycling collection services.

About this manual

This manual is intended for end users and describes how to install and operate the DLP projector.
Wherever possible, relevant information—such as an illustration and its description—has been kept on
one page. This printer-friendly format is both for your convenience and to help save paper, thereby
protecting the environment. It is suggested that you only print sections that are relevant to your needs.

— v—

DLP Projector—User’s Manual

Table of Contents

GETTING STARTED........................................................................................................................................................... 1

PACKING CHECKLIST........................................................................................................................................................... 1

VIEWS OF PROJECTOR PARTS............................................................................................................................................... 2

Front-right View............................................................................................................................................................ 2

Top view—On-screen Display (OSD) buttons and LEDs....................................................................................... 3

Rear view....................................................................................................................................................................... 4

Bottom view................................................................................................................................................................... 6

REMOTE CONTROL PARTS ...................................................................................................................................................7

REMOTE CONTROL OPERATING RANGE...............................................................................................................................9

PROJECTOR AND REMOTE CONTROL BUTTONS.................................................................................................................... 9

SETUP AND OPERATION............................................................................................................................................... 10

INSERTING THE REMOTE CONTROL BATTERIES ................................................................................................................. 10

STARTING AND SHUTTING DOWN THE PROJECTOR............................................................................................................. 11

SETTING AN ACCESS PASSWORD (SECURITY LOCK).......................................................................................................... 12

ADJUSTING THE PROJECTOR LEVEL................................................................................................................................... 14

ADJUSTING THE FOCUS AND KEYSTONE ............................................................................................................................ 15

ADJUSTING THE VOLUME ..................................................................................................................................................15

ON-SCREEN DISPLAY (OSD) MENU SETTINGS...................................................................................................... 16

OSD MENU CONTROLS .....................................................................................................................................................16

Navigating the OSD................................................................................................................................................... 16

SETTING THE OSD LANGUAGE.......................................................................................................................................... 17

OSD MENU OVERVIEW ..................................................................................................................................................... 18

IMAGE MENU.....................................................................................................................................................................19

Computer Menu..........................................................................................................................................................20

Advanced Feature......................................................................................................................................................21

Color Manager............................................................................................................................................................ 22

SETTINGS 1 MENU ............................................................................................................................................................. 23

Audio............................................................................................................................................................................ 24

Advanced 1 Feature................................................................................................................................................... 25

Advanced 2 Feature................................................................................................................................................... 27

SETTINGS 2 MENU ............................................................................................................................................................. 28

Status........................................................................................................................................................................... 29

Advanced 1 Feature................................................................................................................................................... 30

Advanced 2 Feature................................................................................................................................................... 41

MAINTENANCE AND SECURITY..................................................................................................................................43

REPLACING THE PROJECTION LAMP................................................................................................................................... 43

Resetting the Lamp....................................................................................................................................................45

CLEANING THE FILTER (FILTER: OPTIONAL PARTS) ............................................................................................................ 46

REPLACING THE FILTER ..................................................................................................................................................... 47

CLEANING THE PROJECTOR................................................................................................................................................48

Cleaning the Projector Mirror:...................................................................................................................................48

Cleaning the Case...................................................................................................................................................... 49

USING THE PHYSICAL LOCK ..............................................................................................................................................50

Using the Kensington® Lock..................................................................................................................................... 50

Using the Security Bar............................................................................................................................................... 50

TROUBLESHOOTING...................................................................................................................................................... 51

COMMON PROBLEMS AND SOLUTIONS ............................................................................................................................... 51

TIPS FOR TROUBLESHOOTING............................................................................................................................................ 51

LED ERROR MESSAGES..................................................................................................................................................... 52

IMAGE PROBLEMS.............................................................................................................................................................. 52

LAMP PROBLEMS............................................................................................................................................................... 53

REMOTE CONTROL PROBLEMS .......................................................................................................................................... 53

AUDIO PROBLEMS ............................................................................................................................................................. 53

HAVING THE PROJECTOR SERVICED .................................................................................................................................. 54

— vi—

HDMI Q & A ....................................................................................................................................................................55

SPECIFICATIONS............................................................................................................................................................. 56

SPECIFICATIONS................................................................................................................................................................. 56

PROJECTION DISTANCE VS. PROJECTION SIZE.................................................................................................................... 58

Projection Distance and Size Table......................................................................................................................... 58

TIMING MODE TABLE........................................................................................................................................................ 59

PROJECTOR DIMENSIONS ................................................................................................................................................... 61

REGULATORY COMPLIANCE....................................................................................................................................... 63

FCC WARNING.................................................................................................................................................................. 63

CANADA ............................................................................................................................................................................ 63

SAFETY CERTIFICATIONS................................................................................................................................................... 63

APPENDIX I........................................................................................................................................................................ 64

RS-232C PROTOCOL.......................................................................................................................................................... 64

P

r

e

f

a

c

P

P

ee

r

e

f

a

c

r

e

f

a

c

e

— vii—

DLP Projector—User’s Manual

GETTING STARTED

Packing Checklist

Carefully unpack the projector and check that the following items are included:

PROJECTOR (D755WT/D751ST Series ) INTERACTIVE PROJECTOR (D755WTi Series )

DLP

EMOTE CONTROL

R

(W

ITH TWO

AAA B

CD-ROM

HIS USER’S MANUAL)

(T

P

ATTERIES

)

OWER CORD VGA CABLE

Q

UICK START CARD WARRANTY CARD

T

HE FOLLOWING ITEMS ONLY FOR D755WTi SERIES

CD-ROM

(I

NTERACTIVE DRIVER AND

SOFTWARE

)

USB CABLE

(A-TAPE TO MINI)

PENS BOX

ITH FOUR AAA BATTERIES

(W

FOUR TIPS)

&

Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work.
It is recommend that you keep the original packing material should you ever need to return the
equipment for warranty service.

Caution:

Avoid using the projector in dusty environments.

— 1—

Views of Projector Parts

613

Front-right View

DLP Projector—User’s Manual

2

4

5

7

8

ITEM LABEL DESCRIPTION SEE PAGE:

1.

2.

3.

4.

5.

6.

7.

8.

Important:

Ventilation openings on the projector allow for good air circulation, which keeps the projector
lamp cool. Do not obstruct any of the ventilation openings.

Lamp cover Removes cover to replace lamp module

IR receiver Receives IR signal from remote control

Lens Projection Lens

Focus ring Focuses the projected image

Manual Lens shift For Image vertical shift adjustment (Reserved)

Function keys

Interactive Camera (*) Interactive function use

Aspheric mirror Reflects images

See Top view—On-screen Display (OSD)
buttons and LEDs.

3

Note:

(*)Not available in D755WT/D751ST Series.

— 2—

DLP Projector—User’s Manual

Top view—On-screen Display (OSD) buttons and LEDs

1

2

3

4

5

12

ITEM LABEL DESCRIPTION

1.

2.

3.

4.

MENU Opens and exits OSD menus

Navigates in the OSD

SOURCE Enter the Source menu

Quick Menu – For Keystone

Navigates and changes settings in the OSD

6

7
8

9

10

11

SEE

PAGE:

16

16

5.

6.

7.

8.

9.

10.

11.

12.

AUTO Optimizes image size, position, and resolution

LAMP LED

POWER LED

TEMP LED Red Over Temperature

Enter or confirm highlighted OSD menu item

Navigates and changes settings in the OSD

Navigates in the OSD
Quick Menu – For Keystone

Turns the projector On or Off

Red Lamp Fail

Flashing Error code

Ready to power on (Standby)

Green

Flashing

Lamp Lit , System stable
Over Temperature

System initial, Power on,
Cooling, Error code

— 3—

16

52

Rear view

DLP Projector—User’s Manual

1234

19

17

18

56789 10

15

14

13

12

16

11

ITEM LABEL DESCRIPTION SEE PAGE:

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

Security bar For security and authorized usage

Kensington lock

3D SYNC

AUDIO L/R
(For VIDEO/ S-VIDEO)

AUDIO IN
(For VGA-1/ VGA-2)

AUDIO OUT Connect an AUDIO cable to an audio amplifier

MIC Connect the Microphone for use

Mini USB (*)

USB Connect the USB cable from a computer

AC IN Connect the POWER cable

VGA – 2 Connect the RGB cable from a computer or components device

VGA – 1 Connect the RGB cable from a computer or components device

Secure to permanent object with a Kensington®
Lock system

Connect the 3D IR glasses transmitter
(Note: For Vivitek brand 3D IR glasses only)

Connect an AUDIO cable from the audio device

Connect an AUDIO cable from the audio device

Connect the USB cable to PC(

for Interactive function)

50

11

13.

14.

15.

RS-232 Connect RS-232 serial port cable for remote control

VGA OUT

S-VIDEO Connect the S-video cable from a video device

Connect the RGB cable to a display
(Loop Thru only for VGA IN-1)

— 4—

DLP Projector—User’s Manual

ITEM LABEL DESCRIPTION SEE PAGE:

16.

17.

18.

19.

DISPLAYPORT Connect a DISPLAYPORT CABLE from a DISPLAYPORT device

VIDEO Connect the composite cable from a video device

HDMI Connect the HDMI cable from a HDMI device

RJ – 45 Connect a LAN cable from Ethernet

Note:

If your video equipment has various input sources, it is recommended to connect in priority of
HDMI/DVI, component (thru VGA), Composite for better picture quality.

Note:

User should install “D-Point” and ”i-Draw” driver before used Interactive function.
For more detail see “D-Point” and ”i-Draw” driver disc.

Note:
(*)Not available in D755WT/D751ST Series.

Warning:

As a safety precaution, disconnect all power to the projector and connecting devices before
making connections.

— 5—

Bottom view

2

0

1

12221

1

DLP Projector—User’s Manual

47.

135.51

ITEM LABEL DESCRIPTION SEE PAGE:

1.

2.

Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum
screw depth of 12 mm (0.47 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling
mount load capacity must exceed the weight of the installed equipment, and as an additional
precaution be capable of withstanding three times the weight of the equipment (not less than

5.15 kg) over a period of 60 seconds.

Tilt adjustor Rotate adjuster lever to adjust angle position

Ceiling support holes

Contact your dealer for information on mounting the projector on a
ceiling

14

— 6—

DLP Projector—User’s Manual

Remote Control Parts

Important:

1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency

fluorescent lights can disrupt remote control operation.

2. Be sure nothing obstructs the path between the remote control and the projector. If the path
between the remote control and the projector is obstructed, you can bounce the signal off
certain reflective surfaces such as projector screens.

3. The buttons and keys on the projector have the same functions as the corresponding buttons
on the remote control. This user’s manual describes the functions based on the remote control.

— 7—

DLP Projector—User’s Manual

ITEM LABEL DESCRIPTION SEE PAGE:

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

13.

14.

15.

IR transmitter Transmits signals to projector
Status LED Lights when the remote co ntrol is used
Laser Press to operate the on-screen pointer
Up Up arrow when connected through USB to a PC
Right Right arrow when connected through USB to a PC
Down Down arrow when connected through USB to a PC
Page Down Page down when connected through USB to a PC
Up cursor Navigates in the OSD
Right cursor Navigates and changes settings in the OSD
Down cursor Navigates in the OSD
Volume +/- Adjusts volume
Mute Mutes the built-in speaker
Zoom+ Zoom in
Zoom- Zoom out
Freeze Freeze/unfreezes the on-screen picture

16

15

16.

17.

18.

19.

20.

21.

22.

23.

24.

25.

26.

27.

28.

Blank Makes the screen blank
Source Detects the input device
Auto Auto adjustment for phase, tracking, size, position
Menu Opens or exit the OSD

Status
Keystone

top/bottom
Left cursor Navigates and changes settings in the OSD

Enter
Page Up Page up when connected through USB to a PC
Left Left arrow when connected through USB to a PC
Enter Enter key when connected through USB to a PC
Power Turns the projector on or off
Laser Use as on-screen pointer. DO NOT POINT IN EYES.

Opens the OSD Status menu (the menu only opens
when an input device is detected)

Corrects image-trapezoid (wider top/bottom) effect

Changes settings in the OSD

16
29

15

16

11

！

Caution:

Use of controls, adjustments or performance of procedures other than those specified herein may
result in hazardous laser light exposure.

— 8—

DLP Projector—User’s Manual

Remote Control Operating Range

The remote control uses infrared transmission to control the projector. It is not necessary to point
the remote directly at the projector. Provided you are not holding the remote perpendicular to the
sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23
feet) and 15 degrees above or below the projector level. If the projector does not respond to the
remote control, move a little closer.

Projector and Remote Control Buttons

The projector can only be operated using the remote control. All operations can be carried out with
the remote control.

— 9—

Inserting the Remote Control Batteries

Remove the battery compartment

1.

cover by sliding the cover in the
direction of the arrow.

Insert the battery with the positive

2.

side facing up.

DLP Projector—User’s Manual

SETUP AND OPERATION

Replace the cover.

3.

Caution:

1. Only use AAA batteries (Alkaline batteries are recommended).

2. Dispose of used batteries according to local ordinance regulations.

3. Remove the batteries when not using the projector for prolonged periods.

— 10—

DLP Projector—User’s Manual

Starting and Shutting down the Projector

Connect the power cord to the

1.

projector. Connect the other end to
a wall outlet.

Turn on the connected devices.

2.

Ensure the POWER LED displays a

3.

solid green. Then press the POWER

button
projector.

The projector splash screen displays
and connected devices are
detected.

See Setting an Access Password
(Security Lock) on page 12 if

security lock is enabled.

of the remote to turn on the

If more than one input device is

4.

connected, press the SOURCE

button
scroll among devices.
(Component is supported through
the RGB to COMPONENT
ADAPTER.)

of the remote and use ▲▼ to

 VGA 1/VGA 2: Analog RGB

Component: DVD input YCbCr / YPbPr, or
HDTV input YPbPr via HD15 connector

 Composite Video: Traditional composite video

 S-Video: Super video (Y/C separated)

 HDMI: HDMI, DVI

 DP: Digital display interface

When the “Power Off? /Press Power

5.

again” message appears, press the

POWER button. The projector turns

off.

Caution:

Do not unplug the power cord until the POWER LED solid green–indicating the projector has

cooled down.

— 11—

DLP Projector—User’s Manual

Setting an Access Password (Security Lock)

You can use the four (arrow) buttons to set a password and prevent unauthorized use of the

projector. When enabled, the password must be entered after you power on the projector. (See

Navigating the OSD on page 16 and Setting the OSD Language on page 17 for help on using

OSD menus.)

Important:

Keep the password in a safe place. Without the password, you will not be able to use the
projector. If you lose the password, contact your reseller for information on clearing the
password.

Press the MENU button to open the

1.

OSD menu.

Press the cursor ◄► button to move

2.

to the Settings 1 menu, press the
cursor ▲▼ button to select Advanced

1.

Press (Enter) / ► to enter the

3.

Advanced 1 sub menu. Press the
cursor ▲▼ button to select Security
Lock.

Press the cursor ◄► button to enter

4.

and enable or disable security lock
function.

A password dialog box automatically
appears.

— 12—

DLP Projector—User’s Manual

You can use the cursor buttons

5.

▲▼◄►
either on keypad or IR remote control
for password entry. You can use any
combination including the same arrow
five times, but not less than five.

Press the cursor buttons in any order

to set the password. Push the MENU
button to exit the dialog box.

The password confirm menu appears

6.

when user presses the power-on key

in case the Security Lock is enabled.

Enter the password in the order you
set it at step 5. In case you forget the
password, please contact the service
center.
The service center will validate the
owner and help reset the password.

— 13—

Adjusting the Projector Level

Take note of the following when setting up the projector:

 The projector table or stand should be level and sturdy.
 Position the projector so that it is perpendicular to the screen.
 Ensure the cables are in a safe location. You could trip over them.

DLP Projector—User’s Manual

To adjust the angle of the picture, turn the tilt-adjuster right or left until the desired angle
has been achieved.

— 14—

DLP Projector—User’s Manual

Adjusting the Focus and Keystone

Use the Image-focus

1.

control (on the projector
only) to sharpen the
projected image

Use the KEYSTONE

2.

buttons on the remote
control to correct
image-trapezoid (wider
top or bottom)
effect.

The keystone control

3.

appears on the display.

Adjusting the Volume

Press the Volume +/-

1.

buttons on the remote
control.
The volume control
appears on the display.

Press the MUTE button

2.

to turn off the volume.
(This feature is available
only on the remote).

— 15—

DLP Projector—User’s Manual

2

ON-SCREEN DISPLAY (OSD) MENU SETTINGS

OSD Menu Controls

The projector has an OSD that lets you make image adjustments and change various settings.

Navigating the OSD

You can use the remote control cursor buttons to navigate and make changes to the OSD.

4

2

3

6
5

1. To enter the OSD, press

the MENU button.

2. There are three menus.

Press the cursor ◄►
button to move through the
menus.

3. Press the cursor ▲▼

button to move up and
down in a menu.

4. Press ◄► to change

values for settings.

1

1

5. Press MENU to close the

OSD or leave a submenu.

Note:

Depending on the video source, not all items in the OSD are available. For example, the
Horizontal/Vertical Position items in the Computer menu can only be modified when
connected to a PC. Items that are not available cannot be accessed and are grayed out.

— 16—

DLP Projector—User’s Manual

Setting the OSD Language

Set the OSD language to your preference before continuing.

1. Press the MENU button. Press the cursor ◄► button to navigate to Settings 1. Press
the cursor ▲▼ button to move to the Advanced 1 menu.

2. Press (Enter) / ► to enter the Advanced 1 sub menu. Press the cursor ▲▼ button
until Language is highlighted.

3. Press the cursor button until the language you want is highlighted.

4. Press the MENU button four times to close the OSD.

— 17—

DLP Projector—User’s Manual

OSD Menu Overview

Use the following illustration to quickly find a setting or determine the range for a setting.


Settings 1

Settings 2

Display Mode

Brightness

Contrast

Computer

Auto Image

Advanced

Color Manager

Source

Projection

Aspect Ratio

Keystone

Digital Zoom

Audio

Advanced 1

Advanced 2

Auto Source

No Signal Power Off

Auto Power On

Lamp Mode

Reset All

Status

Advanced 1

Advanced 2

Presentation, Bright, Game, Movie, TV, sRGB, Blackboard, User

Horizontal Position

Vertical Position

Frequency

Tracking

Brilliant Color

Sharpness

Gamma

Color Temperature

Video AGC

Video Saturation

Video Tint

Red

Green

Blue

Cyan

Magenta

Yellow

White

Source

Normal, Real, Ceiling, Real+Ceiling

Volume

Mute

Language

Security Lock

Blank Screen

Splash Logo

Closed Captioning

Keypad Lock

3D Setting

Logo Capture

Test Pattern

H Image Shift

V Image Shift

Off, On

Off, On

Eco, Normal

Active Source

Video Information

Lamp Hours (Eco, Normal)

Menu Position

Translucent Menu

Low Power Mode

Fan Speed

Lamp Hour Reset

Projector ID

Network

Sleep Timer

Source Filter

1.8, 2.0, 2.2, 2.4, B& W, Linear

Warm, Normal, Cold

Off, On

Hue

Saturation

Gain

Hue

Saturation

Gain

Hue

Saturation

Gain

Hue

Saturation

Gain

Hue

Saturation

Gain

Hue

Saturation

Gain

Red

Green

Blue

Reference Input So urce Select (IR/Keypad)

Fill, 4:3, 16:9, Letter Box, Native, 2.35:1

Off, On

English, Français, Deutsch, Español, Português, 簡体中文, 繁體中文, Italiano,
Norsk, Svenska, Nederlands, Русский, Polski, Suomi, Ελληνικά, 한국어,
Magyar, Čeština, اﻟﻌﺮﺑﻴﺔ , Türkçe, Việt, 日本語, ไทย, ﻓﺎرﺳﯽ , תירבע

Off, On

Blank, Red, Green, Blue, White

Std., Off, User

Off, On

Off, On

3D

3D Sync Invert

3D Format

None, Grid, White, Red, Green, Blue, Black

Center, Down, Up, Left, Right

0%, 25%, 50%, 75%, 100%

Off, On

Normal, High

00-98

RS232, NetworkRS232

Network State

DHCP

IP Address

Subnet Mask

Gateway

DNS

Apply

VGA1

VGA2

Composite Video

S-Video

HDMI

DP Disable, Enable

Off, DLP-Link, IR

Off, On

Frame Packing, Top/Bottom, Side-By-Side, Frame
Sequential (3D FramePacking HDMI source only)

Connect, Disconnect

Off, On

0~255, 0~255, 0~255, 0~255

0~255, 0~255, 0~255, 0~255

0~255, 0~255, 0~255, 0~255

0~255, 0~255, 0~255, 0~255

OK / Cancel

Disable, Enable

Disable, Enable

Disable, Enable

Disable, Enable

Disable, Enable

— 18—

DLP Projector—User’s Manual

Image Menu

Attention !

All of display mode parameters when changed will be saved to user mode.

Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the
Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄►

to enter and change values for settings.

ITEM DESCRIPTION

Display Mode Press the cursor ◄► button to enter and set the Display Mode.
Brightness Press the cursor ◄► button to enter and adjust the display brightness.
Contrast Press the cursor ◄► button to enter and adjust the display contrast.
Computer Press (Enter) / ► to enter the Computer menu. See Computer Menu on page 20.

Auto Image

Advanced

Color Manager

Press
position.

Press

21.

Press

information on Color Manager.

(Enter) / ► to automatically adjustment for phase, tracking, size and

(Enter) / ► to enter the Advanced menu. See Advanced Feature on page

(Enter) / ► to enter the color manager menu. See page 22 for more

— 19—

DLP Projector—User’s Manual

Computer Menu

Press the MENU button to open the OSD menu. Press ◄► to move to the Image menu. Press
▲▼ to move to the Computer menu and then press Enter or ►. Press ▲▼ to move up and

down in the Computer menu.

ITEM DESCRIPTION

Horizontal Position Press the cursor ◄► button to enter and adjust the display position to left or right.
Vertical Position Press the cursor ◄► button to enter and adjust the display position to up or down.
Frequency Press the cursor ◄► button to enter and adjust the A/D sampling clock.
Tracking Press the cursor ◄► button to enter and adjust the A/D sampling dot.

— 20—

DLP Projector—User’s Manual

Advanced Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press
▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and

down in the Advanced menu.

ITEM DESCRIPTION

Brilliant Color Press the cursor ◄► button to enter and adjust the Brilliant Color value.
Sharpness Press the cursor ◄► button to enter and adjust the display sharpness.
Gamma Press the cursor ◄► button to enter and adjust the gamma correction of the display.

Color Temperature

Video AGC

Video Saturation Press the ◄► buttons to enter and adjust the video saturation.
Video Tint Press the ◄► buttons to enter and adjust the video tint/hue.

Press the cursor

Press the ◄► buttons to enter and enable or disable the Automatic Gain Control for
video source.

◄► button to enter and adjust the color temperature.

— 21—

DLP Projector—User’s Manual

Color Manager

Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press
▼▲ to move to the Color Manager menu and then press Enter or ►. Press ▼▲ to move up and

down in the Color Manager menu.

Red

Green

Blue

Cyan

Magenta

Yellow

White

ITEM DESCRIPTION

Select to enter the Red Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Green Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Blue Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Cyan Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Magenta Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Yellow Color Manager.
Press the◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the White Color Manager.
Press the ◄► buttons to adjust the Red, Green, and Blue.

— 22—

DLP Projector—User’s Manual

Settings 1 Menu

Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the
Settings 1 menu. Press the cursor ▲▼ button to move up and down in the Settings 1 menu.

Press ◄► to

enter and change values for settings.

ITEM DESCRIPTION

Source

Projection Press the cursor ◄► button to enter and choose from four projection methods.
Aspect Ratio Press the cursor ◄► button to enter and adjust the video aspect ratio.
Keystone Press the cursor ◄► button to enter and adjust the display keystone.
Digital Zoom Press the cursor ◄► button to enter and adjust the Digital Zoom menu.
Audio Press (Enter) / ► to enter the Audio menu. See Audio on page 24.

Advanced 1

Advanced 2

Press the cursor
Source select (IR / Keypad).

Press
page 25.

Press
page 27.

(Enter) / ► to enter the Advanced 1 menu. See Advanced 1 Feature on

(Enter) / ► to enter the Advanced 2 menu. See Advanced 2 Feature on

(Enter) / ► button to enter the Source menu. Reference input

— 23—

DLP Projector—User’s Manual

Audio

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu.
Press ▼▲ to move to the Audio menu and then press Enter or ►. Press ▼▲ to move up and
down in the Audio menu.

ITEM DESCRIPTION

Volume Press the ◄► buttons to enter and adjust the audio volume.
Mute Press the ◄► buttons to enter and turn on or off the speaker.

— 24—

DLP Projector—User’s Manual

Advanced 1 Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu.
Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up
and down in the Advanced 1 menu. Press ◄► to enter and change values for setting.

ITEM DESCRIPTION

Language Press the cursor ◄► button to enter and select a different localization Menu.
Security Lock Press the cursor ◄► button to enter and enable or disable security lock function.
Blank Screen Press the cursor ◄► button to enter and select different color to blank the screen.
Splash Logo Press the cursor ◄► button to enter and select splash logo.
Closed Captioning Press the cursor ◄► buttons to enter and enable or disable Closed Captioning

Keypad Lock

3D Setting

Logo Capture Press (Enter) / ► to capture screen pattern to Logo.

Note:

To enjoy the 3D function, first enable the Play Movie in 3D setting found in your DVD device under
the 3D Disc Menu.

Press the cursor ◄► button to enter and enable or disable keys can be work on
keypad.

Press
Setting.

(Enter) / ► to enter the 3D menu. See page 26 for more information on 3D

— 25—

DLP Projector—User’s Manual

3D Setting

ITEM DESCRIPTION

3D Press the cursor ◄► button to enter and select different 3D mode.
3D Sync Invert Press the cursor ◄► button to enter and enable or disable 3D Sync Invert.
3D Format Press the cursor ◄► button to enter and enable or disable different 3D Format.

Note:

1. The 3D OSD menu item is gray if there is no appropriate 3D source. This is the default setting.

2. When the projector is connected to an appropriate 3D source, the 3D OSD menu item is enabled
for selection.

3. Use 3D glasses to view a 3D image.

4. You need 3D content from a 3D DVD or 3D media file.

5. You need to enable the 3D source (some 3D DVD content may have a 3D on-off selectio n
feature).

6. You need DLP link 3D or IR 3D shutter glasses. With IR 3D shutter glasses, you need to install a
driver on your PC and connect a USB emitter.

7. The 3D mode of the OSD needs to match the type of glasses (DLP link or IR 3D).

8. Power on the glasses. Glasses normally have a power on -off switch.
Each type of glasses has their own configuration instructions. Please follow the configuration
instructions that come with your gla sses to finish the setup process.

Note:

Since different types of glass (DLP link or IR shutter glass) have their own setting instructions,

Please follow the guide to finish the setup process.

— 26—

DLP Projector—User’s Manual

Advanced 2 Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu.
Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up
and down in the Advanced 2 menu. Press ◄► to enter and change values for setting.

ITEM DESCRIPTION

Test Pattern Press the cursor ◄► button to enter and select internal test pattern.
H Image Shift Press the cursor ◄► button to enter and select H Image Shift.
V Image Shift Press the cursor ◄► button to enter and select V Image Shift.

— 27—

DLP Projector—User’s Manual

Settings 2 Menu

Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the
Settings 2 menu. Press the cursor ▲▼ button to move up and down in the Settings 2 menu.

ITEM DESCRIPTION

Auto Source

No Signal Power
Off (min.)

Auto Power On

Lamp Mode

Reset All Press (Enter) / ► to reset all settings to default values.

Status

Advanced 1

Advanced 2

Press the cursor ◄► button to enter and enable or disable automatic source
detection.

Press the cursor ◄► button to enter and enable or disable automatic shutdown of
lamp when no signal.

Press the cursor ◄► button to enter and enable or disable automatic power On when
AC power is supplied.

Press the cursor ◄► button to enter and select the lamp mode for higher brightness
or lower brightness to save lamp life.

Press
Status.

Press
page 30.

Press
page 41.

(Enter) / ► to enter the Status menu. See page 29 for more information on

(Enter) / ► to enter the Advanced 1 menu. See Advanced 1 Feature on

(Enter) / ► to enter the Advanced 2 menu. See Advanced 2 Feature on

— 28—

DLP Projector—User’s Manual

Status

Press the cursor ▲▼ button to move up and down in the Settings 2 menu. Select the Status
menu and press Enter or ► to enter.

ITEM DESCRIPTION

Active Source Display the activated source.

Video Information

Lamp Hours Lamp hour used information is displayed. ( Eco and Normal )

Displays resolution/video information for RGB source and color standard for Video
source.

— 29—

DLP Projector—User’s Manual

Advanced 1 Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu.
Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up
and down in the Advanced 1 menu. Press ◄► to

enter and change values for setting.

ITEM DESCRIPTION

Menu Position Press ◄► button to enter and select different OSD location.
Translucent Menu Press ◄► button to enter and select OSD background translucent level.
Low Power Mode Press ◄► to enter and turn Low Power Mode on or off.

Press the cursor ◄► button to enter and toggle between Normal and High fan

Fan Speed

Lamp Hour Reset

Projector ID

RS232

Network

speeds.

Note: We recommend selecting high speed in high temperatures, high humidity, or

high altitude (higher than 1500m/4921ft) areas.

After replacing the lamp, this item should be reset. See page 31 for more information

on Lamp Hour Reset.
Press the cursor ◄► button to enter and adjust a two digit projector ID from 00

through 98.
Press ◄► to select RS232 (remote) or Network (LAN) mode depending on projector

connection method.
Press

(Enter) / ► to enter the Network menu. See page 31 for more information on

Network.

— 30—

DLP Projector—User’s Manual

Lamp Hour Reset

Please refer to Resetting the Lamp on page 45 to reset the lamp hour counter.

Network

ITEM DESCRIPTION

Network State Displays the network connection status.

Press ◄► to turn DHCP On or Off.

DHCP

IP Address Enter a valid IP address if DHCP is turned off.

Subnet Mask Enter a valid Subnet Mask if DHCP is turned off.

Gateway Enter a valid Gateway address if DHCP is turned off.

DNS Enter a valid DNS name if DHCP is turned off.
Apply Press (Enter) / ► to confirm settings.

Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and

DNS fields.

— 31—

DLP Projector—User’s Manual

Wired LAN Terminal functionalites

Remote control and monitoring of a projector from a PC (or Laptop) via wired LAN is also possible.
Compatibility with Crestron / AMX (Device Discovery) / Extron control boxes enables not only
collective projector management on a network but also management from a control panel on a PC
(or Laptop) browser screen.

* Crestron is a registered trademark of Crestron Electronics, Inc. of the United States.

* Extron is a registered trademark of Extron Electronics, Inc. of the United States.

* AMX is a registered trademark of AMX LLC of the United States.

Supported External Devices

This projector is supported by the specified commands of the Crestron Electronics controller and
related software (ex, RoomView ®).

http://www.crestron.com/

This projector is supported by AMX ( Device Discovery ).

http://www.amx.com/

This projector is compliant to support Extron device(s) for reference.

http://www.extron.com/

For more detail of information about the diverse types of external devices which can be connected
to the LAN/RJ45 port and remote/control the projector, as well as the related control commands
supporting for each external device, kindly please get contact with the Support-Service team
directly.

— 32—

DLP Projector—User’s Manual

LAN RJ45

1. Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop).

2. On the PC (Laptop), select Start

→ Control Panel → Network Connections.

— 33—

DLP Projector—User’s Manual

3. Right-click on Local Area Connection, and select Properties.

4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP).

5. Click Properties.

— 34—

DLP Projector—User’s Manual

6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK.

7. Press the Menu button on the projector.

8. Select Settings 2 → Advanced 1 → RS232 → Network Option

9. After getting into Network, input the following:

 DHCP: Off

 IP Address: 10. 10. 10. 10

 Subnet Mask: 255.255.255.0

 Gateway: 0.0.0.0

 DNS Server: 0.0.0.0

10. Press

(Enter) / ► to confirm settings.

11. Open a web browser (for example, Microsoft Internet Explorer with Adobe Flash Player 9.0 or higher).

— 35—

DLP Projector—User’s Manual

12. In the Address bar, input the IP address: 10. 10. 10. 10.

13. Press (Enter) / ►.

The projector is setup for remote management. The LAN/RJ45 function displays as follows.

— 36—

DLP Projector—User’s Manual

CATEGORY ITEM INPUT-LENGTH

IP Address 15

Crestron Control

Projector

Network Configuration

User Password

Admin Password

IP ID 3

Port 5

Projector Name 10

Location 10

Assigned To 10

DHCP (Enabled) (N/A)

IP Address 15

Subnet Mask 15

Default Gateway 15

DNS Server 15

Enabled (N/A)

New Password 10

Confirm 10

Enabled (N/A)

New Password 10

Confirm 10

For more information, please visit http://www.crestron.com/.

— 37—

DLP Projector—User’s Manual

RS232 by Telnet Function

Besides projector connected to RS232 interface with “Hyper-Terminal” communication by
dedicated RS232 command control, there is alternative RS232 command control way, so called
“RS232 by TELNET” for LAN/RJ45 interface.

Quick Start-Guide for “RS232 by TELNET”

Check and get the IP-Address on OSD of the projector.

Make sure that laptop/PC can access the web-page of the projector.

Make sure that “Windows Firewall” setting to be disabled in case of “TELNET” function filtering out
by laptop/PC.

Start => All Programs => Accessories => Command Prompt

— 38—

DLP Projector—User’s Manual

Input the command format like the below:

telnet ttt.xxx.yyy.zzz 23 (“Enter” key pressed)
(ttt.xxx.yyy.zzz: IP-Address of the projector)

If Telnet-Connection ready, and user can have RS232 command input, then “Enter” key pressed,
the RS232 command will be workable.

How to have TELNET enabled in Windows VISTA / 7

By default installation for Windows VISTA, “TELNET” function is not included. But end-user can
have it by way of “Turn Windows features On or Off” to be enabled.

Open “Control Panel” in Windows VISTA

Open “Programs”

— 39—

Select “Turn Windows features on or off” to open

DLP Projector—User’s Manual

Have “Telnet Client” option checked, then press “OK” button.

Specsheet for “RS232 by TELNET” :

1. Telnet: TCP

2. Telnet port: 23 (for more detail, kindly please get contact with the service agent or team)

3. Telnet utility: Windows “TELNET.exe” (console mode)

4. Disconnection for RS232-by-Telnet control normally: Close Windows Telnet utility directly
after TELNET connection ready

5. Limitation 1 for Telnet-Control: there is only one connection for Telnet-Control in one projector

Limitation 2 for Telnet-Control: there is less than 50 bytes for successive network payload for
Telnet-Control application.

Limitation 3 for Telnet-Control: there is less than 26 bytes for one complete RS232 command
for Telnet-Control.

Limitation 4 for Telnet-Control: Minimum delay for next RS232 command must be more than
200 (ms).

(*, In Windows XP built-in “TELNET.exe” utility, “Enter” key pressed will have “Carriage­Return” and “New-Line” code.)

— 40—

DLP Projector—User’s Manual

Advanced 2 Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu.
Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up
and down in the Advanced 2 menu. Press ◄► to

enter and change values for setting.

ITEM DESCRIPTION

Sleep Timer (min)

Source Filter

Press the cursor ◄► buttons to enter and set Sleep timer. The projector automatically
turns off after the preset period of time.

Press

information on Source Filter.

(Enter) / ► to enter the Source Filter menu. See page 42 for more

— 41—

DLP Projector—User’s Manual

Source Filter

Press the ENTER button to enter the Source Filter sub menu.

ITEM DESCRIPTION

VGA1 Press the ◄► buttons to enter and enable or disable the VGA1 source.
VGA2 Press the ◄► buttons to enter and enable or disable the VGA2 source.
Composite Video Press the ◄► buttons to enter and enable or disable the Composite Video source.
S-Video Press the ◄► buttons to enter and enable or disable the S-Video source.
HDMI Press the ◄► buttons to enter and enable or disable the HDMI source.
DP Press the ◄► buttons to enter and enable or disable the DisplayPort source.

— 42—

DLP Projector—User’s Manual

MAINTENANCE AND SECURITY

Replacing the Projection Lamp

The projection lamp should be replaced when it burns out. It should only be replaced with a
certified replacement part, which you can order from your local dealer.

Important:

a. The projection lamp used in this product contains a small amount of mercury.
b. Do not dispose this product with general household waste.
c. Disposal of this product must be carried out in accordance with the regulations of your local

authority.

Warning:

Be sure to turn off and unplug the projector at least 30 minutes before replacing the lamp.
Failure to do so could result in a severe burn.

Caution:

In rare cases the lamp bulb may burn out during normal operation and cause glass dust or
shards to be discharged outward from the rear exhaust vent.

Do not inhale or do not touch glass dust or shards. Doing so could result in injury.
Always keep your face away from the exhaust vent so that you do not suffer from the gas and

broken shards of the lamp.
When removing the lamp from a ceiling-mounted projector, make sure that no one is under the

projector. Glass fragments could fall if the lamp has been burned out.

！

IF A LAMP EXPLODES

If a lamp explodes, the gas and broken shards may scatter inside the projector and they may
come out of the exhaust vent. The gas contains toxic mercury.

Open windows and doors for ventilation.
If you inhale the gas or the shards of the broken lamp enter your eyes or mouth, consult the

doctor immediately.

Remove the single screw

1.

on the lamp compartment
cover.

— 43—

Remove the lamp

2.

compartment cover.

Remove the two screws

3.

from the lamp module.

DLP Projector—User’s Manual

Lift the module handle up.

4.

Pull firmly on the module

5.

handle to remove the lamp
module.

Reverse steps 1 to 5 to

6.

install the new lamp
module.
While installing, align the
lamp module with the
connector and ensure it is
level to avoid damage.

Note: The lamp module

must sit securely in place
and the lamp connector
must be connected
properly before tightening
the screws.

— 44—

DLP Projector—User’s Manual

Resetting the Lamp

After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following:

Press the MENU button to open

1.

the OSD menu.

Press the cursor ◄► button to

2.

move to the Settings 2 menu.

Press the cursor button to move

down to Advanced 1 and press

enter.

Press the cursor ▼▲ button to

3.

move down to Lamp Hour Reset.

Press the cursor ► or Enter

4.

button.

A message screen appears.

Press ▼▲◄► buttons to reset

5.

the lamp hour.

Press the MENU button to get

6.

back to Settings 2.

— 45—

DLP Projector—User’s Manual

Cleaning the filter (filter: optional parts)

The air filter prevents dust from accumulating on the surface of the optical elements inside the
projector. If the filter is dirty or clogged, your projector may overheat or degrading the projected
image quality.

Turn off the projector, and

1.

unplug the AC power cord
from the AC outlet.

Cleaning the filter with a

2.

vacuum cleaner.

Caution:

Recommend avoiding dusty or smoky environments when you operate the projector, it may
cause poor image quality.

If the filter is heavily clogged and unable to clean, replace a new filter.

Note:

Using a ladder is recommended to access the filter. Do not remove the projector from the
wall mount.

— 46—

DLP Projector—User’s Manual

Replacing the Filter

Turn off the projector, and

1.

unplug the AC power cord
from the AC outlet.
Clean up the dust on the
projector and around the
air vents.
Pull out the filter cover and
remove from the projector

Use soft brush gently to
clean the filter dust both
side.

Or lift the filter from the

2.

filter cover.

Replace a new filter

3.

module or replace filter into
cover.

Replace the filter cover

4.

back to the projector by
pushing gently in the
direction shown.

Warning:

Do not wash the filter with the water or other liquid matter

Important:

When the lamp is replaced, the filter should also be replaced, not cleaned.

— 47—

DLP Projector—User’s Manual

Cleaning the Projector

Cleaning the projector to remove dust and grime will help ensure trouble-free operation.

Cleaning the Projector Mirror:

1. Remove dust with a “Bellows/Lens Blower”
readily available from Camera shops to prevent scratching the mirror when subsequently
wiped.

2. Gently wipe with a lens cleaning cloth or alternatively, use a lens cleaning tissue in
conjunction with a small amount of lens cleaning fluid.

Cautions:

1. Always turn the projector off and allow to cool for at least 30 minutes prior to cleaning.

2. Never touch the projector mirror or Lens directly by hand.

3. Do not use hard fibre cloths.

4. Do not use abrasive cleaners, solvents or other harsh chemical cleaners.

— 48—

DLP Projector—User’s Manual

Cleaning the Case

Refer to the following to clean the projector case.

1. Wipe off dust with a clean dampened cloth.

2. Moisten the cloth with warm water and mild detergent (such as used to wash dishes), and

then wipe the case.

3. Rinse all detergent from the cloth and wipe the projector again.

Caution:

To prevent discoloration or fading of the case, do not use abrasive alcohol-based cleaners.

Warning:

1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do

so could result in a severe burn.

2. Use only a dampened cloth when cleaning. Do not allow water to enter the ventilation
openings on the projector.

3. If a little water gets into the projector interior while cleaning, leave unplugged in a well­ventilated room for several hours before using.

4. If a lot of water gets into the projector interior when cleaning, have the projector serviced.

— 49—

DLP Projector—User’s Manual

Using the Physical Lock

Using the Kensington® Lock

If you are concerned about security, attach the projector to a permanent object with the
Kensington slot and a security cable.

Note:

Contact your vendor for details on purchasing a suitable Kensington security cable.

The security lock corresponds to Kensington’s MicroSaver Security System. If you have any
comment, contact: Kensington, 2853 Campus Drive, San Mateo, CA 94403, U.S.A. Tel: 800-

535-4242, http://www.Kensington.com.

Using the Security Bar

In addition to the password protection function and the Kensington lock, the Security Bar helps
protect the projector from unauthorized removal.

See the following picture.

— 50—

DLP Projector—User’s Manual

TROUBLESHOOTING

Common problems and solutions

These guidelines provide tips to deal with problems you may encounter while using the projector.
If the problem remains unsolved, contact your dealer for assistance.

Often after time spent troubleshooting, the problem is traced to something as simple as a loose
connection. Check the following before proceeding to the problem-specific solutions.

 Use some other electrical device to confirm that the electrical outlet is working.
 Ensure the projector is turned on.
 Ensure all connections are securely attached.
 Ensure the attached device is turned on.
 Ensure a connected PC is not in suspending mode.
 Ensure a connected notebook computer is configured for an external display.

(This is usually done by pressing a Fn-key combination on the notebook).

Tips for Troubleshooting

In each problem-specific section, try the steps in the order suggested. This may help you to solve
the problem more quickly.

Try to pin point the problem and thus avoid replacing non-defective parts.
For example, if you replace batteries and the problem remains, put the original batteries back and
go to the next step.

Keep a record of the steps you take when troubleshooting: The information may be useful when
calling for technical support or for passing on to service personnel.

— 51—

LED Error Messages

DLP Projector—User’s Manual

ERROR CODE MESSAGES

System Initial Flashing OFF OFF

Ready to Power on (Standby) ON OFF OFF

System Power on Flashing OFF OFF

Lamp Lit , System stable ON OFF OFF

Cooling Flashing OFF OFF

Over Temperature ON OFF ON

Thermal Break Sensor error 4 blinks OFF OFF

Lamp Fail 5 blinks ON OFF

Lamp Temperature shut down 5 blinks 1 blinks OFF

Lamp Short circuit in output detected 5 blinks 2 blinks OFF

Lamp End of lamp life detected 5 blinks 3 blinks OFF

Lamp did not ignite 5 blinks 4 blinks OFF

Lamp extinguished during normal operation 5 blinks 5 blinks OFF

Lamp extinguished during run-up phase 5 blinks 6 blinks OFF

Lamp voltage got error 5 blinks 7 blinks OFF

POWER LED

GREEN

LAMP LED

RED

TEMP LED

RED

Lamp ballast got error 5 blinks 8 blinks OFF

Ballast watt value is out of range
(Lamp Normal & Eco mode)

Lamp ballast Communication error 5 blinks 10 blinks OFF

Fan-1 error 6 blinks 1 blinks OFF

Fan-2 error 6 blinks 2 blinks OFF

Fan-3 error 6 blinks 3 blinks OFF

Fan-4 error 6 blinks 4 blinks OFF

Case Open 7 blinks OFF OFF

DAD1000 error 8 blinks OFF OFF

Color wheel error 9 blinks OFF OFF

In the event of an error, please disconnect the AC power cord and wait for one (1) minute before
restarting the projector. If the Power or Lamp LEDs are still blinking or any other situation that isn't
listed in the chart above

, please contact your service center.

5 blinks 9 blinks OFF

Image Problems

Problem: No image appears on the screen

1. Verify the settings on your notebook or desktop PC.

2. Turn off all equipment and power up again in the correct order.

Problem: The image is blurred

1. Adjust the Focus on the projector.

2. Press the Auto button on the remote control.

3. Ensure the projector-to-screen distance is within the specified range.

4. Check that the projector lens is clean.

— 52—

DLP Projector—User’s Manual

Problem: The image is wider at the top or bottom (trapezoid effect)

1. Position the projector so it is as perpendicular to the screen as possible.

2. Use the Keystone button on the remote control to correct the problem.

Problem: The image is reversed

Check the Projection setting on the Settings 1 menu of the OSD.

Problem: The image is streaked

1. Set the Frequency and Tracking settings on the Image->Computer menu of the OSD

to the default settings.

2. To ensure the problem is not caused by a connected PC’s video card, connect to

another computer.

Problem: The image is flat with no contrast

Adjust the Contrast setting on the Image menu of the OSD.

Problem: The color of the projected image does not match the source image.

Adjust the Color Temperature and Gamma settings on the Image->Advanced menu of

the OSD.

Lamp Problems

Problem: There is no light from the projector

1. Check that the power cable is securely connected.

2. Ensure the power source is good by testing with another electrical device.

3. Restart the projector in the correct order and check that the Power LED is on.

4. If you have replaced the lamp recently, try resetting the lamp connections.

5. Replace the lamp module.

6. Put the old lamp back in the projector and have the projector serviced.

Problem: The lamp goes off

1. Power surges can cause the lamp to turn off. Re-plug power cord. When the Power

LED is on, press the power button.

2. Replace the lamp module.

3. Put the old lamp back in the projector and have the projector serviced.

Remote Control Problems

Problem: The projector does not respond to the remote control

1. Direct the remote control towards remote sensor on the projector.

2. Ensure the path between remote and sensor is not obstructed.

3. Turn off any fluorescent lights in the room.

4. Check the battery polarity.

5. Replace the battery.

6. Turn off other Infrared-enabled devices in the vicinity.

7. Have the remote control serviced.

Audio Problems

Problem: There is no sound

1. Adjust the volume on the remote control.

2. Adjust the volume of the audio source.

— 53—

DLP Projector—User’s Manual

3. Check the audio cable connection.

4. Test the source audio output with other speakers.

5. Have the projector serviced.

Problem: The sound is distorted

1. Check the audio cable connection.

2. Test the source audio output with other speakers.

3. Have the projector serviced.

Having the Projector Serviced

If you are unable to solve the problem, you should have the projector serviced. Pack the projector
in the original carton. Include a description of the problem and a checklist of the steps you took
when trying to fix the problem: The information may be useful to service personnel. For servicing,
return the projector to the place you purchased it.

— 54—

DLP Projector—User’s Manual

HDMI Q & A

Q. What is the difference between a “Standard” HDMI cable and a “High-Speed”
HDMI cable?

1. Recently, HDMI Licensing, LLC announced that cables would be tested as Standard
or High-Speed cables.

2. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of
75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.

3. ˙High Speed (or “category 2”) HDMI cables have been tested to perform at speeds of
340Mhz or up to 10.2Gbps, which is the highest bandwidth currently available over an
HDMI cable and can successfully handle 1080p signals including those at increased
color depths and/or increased refresh rates from the Source. High-Speed cables are
also able to accommodate higher resolution displays, such as WQXGA cinema monitors
(resolution of 2560 x 1600).

Q. How do I run HDMI cables longer than 10 meters?

4. There are many HDMI Adopters working on HDMI solutions that extend a cable’s

effective distance from the typical 10 meter range to much longer lengths. These
companies manufacture a variety of solutions that include active cables (active electronics
built into cables that boost and extend the cable’s signal), repeaters, amplifiers as well as
CAT5/6 and fiber solutions.

Q. How can I tell if a cable is an HDMI certified cable?

5. All HDMI products are required to be certified by the manufacturer as part of the HDMI

Compliance Test Specification. However, there may be instances where cables bearing
the HDMI logo are available but have not been properly tested. HDMI Licensing, LLC
actively investigates these instances to ensure that the HDMI trademark is properly used
in the market. We recommend that consumers buy their cables from a reputable source
and a company that is trusted.

For more detail information check http://www.hdmi.org/learningcenter/faq.aspx#49

— 55—

DLP Projector—User’s Manual

SPECIFICATIONS

Specifications

Model D755WT Series (WXGA) D751ST Series (XGA)
Display type
Resolution
Projection distance
Projection screen size
Projection lens
Throw ratio
Vertical keystone correction
Projection methods
Data compatibility
SDTV/EDTV/ HDTV
Video compatibility
H-Sync
V-Sync
Safety certification
Operation temperature
Dimensions
AC Input
Power consumption
Lamp
Audio speaker
Interactive function

Input Terminals

Output Terminals

Control Terminals

Security

FCC, UL, cUL, CB, CE, CCC, KC, PSB, GOST, CECP, NOM, ICES-003, C-TICK

DMD 0.65" WXGA DMD 0.55" XGA

WXGA 1280 x 800 Native XGA 1024 x 768 Native

336~421mm 371~417mm

16:10 (80”~100”) 4:3 (68"~85”)

Fix

0.35 : 1 0.437 : 1

+/- 40 degrees

Front, Rear, Desktop/Ceiling (Rear, Front)

VGA, SVGA, XGA, SXGA, UXGA, Mac

40i, 576i, 480p, 576p, 720p, 1080i, 1080p

NTSC/NTSC 4.43, PAL (B/G/H/I/M/N/60), SECAM

15, 30 – 91.4 kHz

24-30, 47-120 Hz

5° ~ 40°C

287.5 mm (W) x 160 mm (H) x 374.5 mm (D)

AC Universal 100 ~ 240V

290W , <0.5W (Stand By)

230W

10W x2

No

VGA x 2

Mini jack x 1 (Audio In)

Composite Video x 1

HDMI x 1

Display Port x 1

S-Video x 1

Audio In (L/R) x 1

MIC x 1

VGA x 1 (Loop Thru only for VGA IN-1)

Mini jack x 1 (Audio out)

RS-232C

RJ45

USB (type B)

3D sync

Kensington lock

— 56—

DLP Projector—User’s Manual

Specifications

Model D755WTi Series (WXGA)
Display type
Resolution
Projection distance
Projection screen size
Projection lens
Throw ratio
Vertical keystone correction
Projection methods
Data compatibility
SDTV/EDTV/ HDTV
Video compatibility
H-Sync
V-Sync
Safety certification
Operation temperature
Dimensions
AC Input
Power consumption
Lamp
Audio speaker
Interactive function

Input Terminals

Output Terminals

Control Terminals

Security

Front, Rear, Desktop/Ceiling (Rear, Front)

VGA, SVGA, XGA, SXGA, UXGA, Mac

480i, 576i, 480p, 576p, 720p, 1080i, 1080p

NTSC/NTSC 4.43, PAL (B/G/H/I/M/N/60), SECAM

FCC, UL, cUL, CB, CE, CCC, KC, PSB, GOST, CECP, NOM, ICES-003, C-TICK

287.5 mm (W) x 185.98 mm (H) x 374.5 mm (D)

VGA x 1 (Loop Thru only for VGA IN-1)

DMD 0.65" WXGA

WXGA 1280 x 800 Native

336~421mm

16:10 (80”~100”)

Fix

0.35 : 1

+/- 40 degrees

15, 30 – 91.4 kHz

24-30, 47-120 Hz

5° ~ 40°C

AC Universal 100 ~ 240V

290W , <0.5W (Stand By)

230W

10W x2 (stereo)

Yes

VGA x 2

Mini jack x 1 (Audio In)

Composite Video x 1

HDMI x 1

Display Port x 1

S-Video x 1

Audio In (L/R) x 1

MIC x 1

Mini jack x 1 (Audio out)

RS-232C

RJ45

USB (type B)

Mini USB (Interactive used)

3D sync

Kensington lock

— 57—

Projection Distance vs. Projection Size

DLP Projector—User’s Manual

D755WT/D751ST Series D755WTi Series

Projection Distance and Size Table

Diagonal 80" 87" 97" 100"

Distance 282.3+/-20mm 336.3+/-20mm 421.4+/-20mm 445.8+/-20mm

Image Width 1723mm 1869mm 2088mm 2154mm

Image height 1077mm 1168mm 1305mm 1346mm

H 280+/-50mm 298.5+/-50mm 325.5+/-50mm 336.9+/-50mm

D755WT / D755WTi Series

WXGA

16:10

D751ST Series

XGA

4:3

Diagonal 68" 78" 82" 85"

Distance 282.3+/-20mm 371.4+/-20mm 417.35+/-20mm 445.8+/-20mm

Image Width 1382mm 1566mm 1670mm 1727mm

Image height 1036mm 1175mm 1240mm 1295mm

H 301.3+/-50mm 334.8+/-50mm 350.8+/-50mm 363.7+/-50mm

— 58—

DLP Projector—User’s Manual

Timing Mode Table

The projector can display several resolutions. The following table outlines the resolutions that can
be displayed by the projector.

SIGNAL RESOLUTION

NTSC
PAL/SECAM
VESA

－
－

640 x 400 37.9 85.1
720 x 400 31.5 70.1
720 x 400 37.9 85.0
640 x 480 31.5 60.0
640 x 480 37.9 72.8
640 x 480 37.5 75.0
640 x 480 43.3 85.0
800 x 600 35.2 56.3

* 800 x 600 37.9 60.3

800 x 600 46.9 75.0
800 x 600 48.1 72.2
800 x 600 53.7 85.1

** 800 x 600 76.3 120.0

1024 x 576 35.8 60.0
1024 x 600 37.3 60.0
1024 x 600 41.5 65.0

* 1024 x 768 48.4 60.0

1024 x 768 56.5 70.1
1024 x 768 60.0 75.0
1024 x 768 68.7 85.0

** 1024 x 768 97.6 120.0

1024 x 768 99.0 120.0

1152 x 864 67.5 75.0

* 1280 x 720 45.0 60.0
* 1280 x 720 90.0 120.0

1280 x 768 47.4 60.0

* 1280 x 768 47.8 59.9

* 1280 x 800 49.7 59.8

1280 x 800 62.8 74.9

1280 x 800 71.6 84.9

** 1280 x 800 101.6 119.9

*** 1280 x 1024 64.0 60.0

1280 x 1024 80.0 75.0
1280 x 1024 91.1 85.0

*** 1280 x 960 60.0 60.0

1280 x 960 85.9 85.0

*** 1360 x 768 47.7 60.0

*** 1400 x 1050 65.3 60.0

1440 x 900 55.5 59.9

*** 1440 x 900 55.9 59.9

1440 x 900 70.6 75.0

H-SYNC

( KHZ )

15.7 60.0 ○

15.6 50.0 ○

V-SYNC

( HZ )

COMPOSITE

S_VIDEO

COMPONENT

－ － －

－ － －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －

RGB

(ANALOG)

○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○

DP/HDMI

(DIGITAL)

— 59—

DLP Projector—User’s Manual

SIGNAL RESOLUTION

1600 x1200 75.0 60.0
1680 x 1050 64.7 59.9
1680 x 1050 65.3 60.0
1920 x 1200 74.0 60.0
1920 x 1080 67.5 60.0

640 x 480 35.0 66.7

Apple
Macintosh

SDTV

EDTV

HDTV

832 x 624 49.7 74.5
1024 x 768 60.2 74.9
1152 x 870 68.7 75.1

480i 15.7 60.0

576i 15.6 50.0
576p 31.3 50.0
480p 31.5 60.0
720p 37.5 50.0
720p 45.0 60.0

1080i 33.8 60.0

1080i 28.1 50.0
1080p 27.0 24.0
1080p 28.0 25.0
1080p 33.7 30.0
1080p 56.3 50.0
1080p 67.5 60.0

H-SYNC

( KHZ )

V-SYNC

( HZ )

COMPOSITE

S_VIDEO

－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－ －
－
－
－
－
－
－
－
－
－
－
－
－
－

COMPONENT

○
○
○
○
○
○
○
○
○
○
○
○
○

RGB

(ANALOG)

○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○
○ ○

－
－
－
－
－
－
－
－
－
－
－
－
－

DP/HDMI

(DIGITAL)

○
○
○
○
○
○
○
○
○
○
○
○
○

O: Frequency supported

—: Frequency not supported

3D note：

“” It means the timing can support non-3D and 3D signal with Frame Sequential and
Top-Bottom format.

“”It means the timing can support non-3D and 3D signal with Frame Sequential format.

“”It means the timing can support non-3D and 3D signal with Top-Bottom format.

There 3D timing showing depend the EDID file and display card. It is possible that user cannot
choose the above 3D timings on display card.

The resolution of the panel is 1280 x 800. Resolution other than native resolution may display

with uneven size of text or lines.

The color of mean Displayable only. (4:3 only)

The color of mean may have a little noise is acceptable, Because video mode sync don’t

auto adjustment.

HDTV timing main check tool is DVD player, VG828 is secondary

— 60—

DLP Projector—User’s Manual

122

8

Projector Dimensions ( D755WT / D751ST Series )

374.51

.5

— 61—

160.0

Projector Dimensions ( D755WTi Series )

DLP Projector—User’s Manual

374.51

122.58

185.98

— 62—

DLP Projector—User’s Manual

REGULATORY COMPLIANCE

FCC Warning

This equipment has been tested and found to comply with the limits for a Class B digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own
expense.

Changes or modifications not expressly approved by the parties responsible for compliance could
void the user’s authority to operate the equipment.

Canada

This class B digital apparatus complies with Canadian ICES-003.

Safety Certifications

FCC, UL, cUL, CB, CE, CCC, KC, PSB, GOST, CECP, NOM, ICES-003, C-TICK

— 63—

RS-232C Protocol

RS232 Setting

Control Command Structure

Header code Command code Data code End code

HEX Command Data 0Dh
ASCII ‘V’ Command Data CR

Operation Command

Baud rate: 9600

Parity
check:

None

Data bit: 8
Stop bit: 1

Flow
Control

None

DLP Projector—User’s Manual

APPENDIX I

Note:
XX=00-98, projector's ID, XX=99 is for all projectors
Return Result P=Pass / F=Fail
n: 0:Disable/1: Enable/Value(0~9999)

Command Group 00

ASCII HEX Function Description Return Result

VXXS0001 56H 39H 39H 53H 30H 30H 30H 31H 0DH Power On P/F

VXXS0002 56H 39H 39H 53H 30H 30H 30H 32H 0DH Power Off P/F

VXXS0003 56H 39H 39H 53H 30H 30H 30H 33H 0DH Resync P/F

VXXG0004 56H 39H 39H 47H 30H 30H 30H 34H 0DH Get Lamp Hours Pn/F

VXXS0006 56H 39H 39H 53H 30H 30H 30H 36H 0DH System Reset P/F

0:Reset

VXXG0007 56H 39H 39H 47H 30H 30H 30H 37H 0DH Get System Status

VXXG0008 56H 39H 39H 47H 30H 30H 30H 38H 0DH Get F/W Version Pn/F

1:Standby
2:Operation
3:Cooling

Pn/F

Command Group 01

ASCII HEX Function Description Return Value

VXXG0101 56H 39H 39H 47H 30H 31H 30H 31H 0DH Get Brightness n=0~100 Pn/F

VXXS0101n 56H 39H 39H 53H 30H 31H 30H 31H n 0DH Set Brightness n=0~100 P/F

VXXG0102 56H 39H 39H 47H 30H 31H 30H 32H 0DH Get Contrast n=0~100 Pn/F

VXXS0102n 56H 39H 39H 53H 30H 31H 30H 32H n 0DH Set Contrast n=0~100 P/F

VXXG0103 56H 39H 39H 47H 30H 31H 30H 33H 0DH Get Color n=0~100 Pn/F

VXXS0103n 56H 39H 39H 53H 30H 31H 30H 33H n 0DH Set Color n=0~100 P/F

VXXG0104 56H 39H 39H 47H 30H 31H 30H 34H 0DH Get Tint n=0~100 Pn/F

VXXS0104n 56H 39H 39H 53H 30H 31H 30H 34H n 0DH Set Tint n=0~100 P/F

VXXG0105 56H 39H 39H 47H 30H 31H 30H 35H 0DH Get Sharpness 0~31 Pn/F

— 64—

DLP Projector—User’s Manual

Command Group 01

ASCII HEX Function Description Return Value

VXXS0105n 56H 39H 39H 53H 30H 31H 30H 35H n 0DH Set Sharpness 0~31 P/F

0:Cold

VXXG0106 56H 39H 39H 47H 30H 31H 30H 36H 0DH Get Color Temperature

VXXS0106n 56H 39H 39H 53H 30H 31H 30H 36H n 0DH Set Color Temperature

VXXG0107 56H 39H 39H 47H 30H 31H 30H 37H 0DH Get Gamma

VXXS0107n 56H 39H 39H 53H 30H 31H 30H 37H n 0DH Set Gamma

Command Group 02

ASCII HEX Function Description Return Value

VXXS0201 56H 39H 39H 53H 30H 32H 30H 31H 0DH Select RGB P/F

VXXS0202 56H 39H 39H 53H 30H 32H 30H 32H 0DH Select RGB2 P/F

VXXS0204 56H 39H 39H 53H 30H 32H 30H 34H 0DH Select Video P/F

VXXS0205 56H 39H 39H 53H 30H 32H 30H 35H 0DH Select S-Video P/F

VXXS0206 56H 39H 39H 53H 30H 32H 30H 36H 0DH Select HDMI P/F

VXXS0210 56H 39H 39H 53H 30H 32H 31H 30H 0DH Select DisplayPort P/F

1:Normal
2:Warm

0:Cold
1:Normal
2:Warm

0:1.8
1:2.0
2:2.2
3:2.4
4: B&W
5:Linear
0:1.8
1:2.0
2:2.2
3:2.4
4: B&W
5:Linear

Pn/F

P/F

Pn/F

P/F

Return
1:RGB
2:RGB2

VXXG0220 56H 39H 39H 47H 30H 32H 32H 30H 0DH Get Current Source

4:Video
5:S-Video
6:HDMI
10:DisplayPort

Pn/F

ommand Group 03

ASCII HEX Function Description Return Value

0: Fill
1: 4:3

VXXG0301 56H 39H 39H 47H 30H 33H 30H 31H 0DH Get Scaling

VXXS0301n 56H 39H 39H 53H 30H 33H 30H 31H n 0DH Set Scaling

VXXG0302 56H 39H 39H 47H 30H 33H 30H 32H 0DH Blank Pn/F

VXXS0302n 56H 39H 39H 53H 30H 33H 30H 32H n 0DH Blank P/F

VXXG0303 56H 39H 39H 47H 30H 33H 30H 33H 0DH Auto Keystone On Pn/F

VXXS0303n 56H 39H 39H 53H 30H 33H 30H 33H n 0DH Auto Keystone On P/F

VXXG0304 56H 39H 39H 47H 30H 33H 30H 34H 0DH Freeze On Pn/F

2: 16:9
3 :Letter Box
4 :Native
5: 2.35:1
0: Fill
1: 4:3
2: 16:9
3 :Letter Box
4 :Native
5: 2.35:1

Pn/F

P/F

— 65—

DLP Projector—User’s Manual

ommand Group 03

ASCII HEX Function Description Return Value

VXXS0304n 56H 39H 39H 53H 30H 33H 30H 34H n 0DH Freeze On P/F

VXXG0305 56H 39H 39H 47H 30H 33H 30H 35H 0DH Volume n=0~8 Pn/F

VXXS0305n 56H 39H 39H 53H 30H 33H 30H 35H n 0DH Volume n=0~8 P/F

0:Front

VXXG0308 56H 39H 39H 47H 30H 33H 30H 38H 0DH Projection Mode

VXXS0308n 56H 39H 39H 53H 30H 33H 30H 38H n 0DH Projection Mode

VXXG0309 56H 39H 39H 47H 30H 33H 30H 39H 0DH

VXXS0309n 56H 39H 39H 53H 30H 33H 30H 39H n 0DH

VXXG0311 56H 39H 39H 47H 30H 33H 31H 31H 0DH Adjust the zoom n= -10~10 Pn/F

VXXS0311n 56H 39H 39H 53H 30H 33H 31H 31H n 0DH Adjust the zoom n= -10~10 P/F

Set vertical keystone
value
Set vertical keystone
value

Command Group 04 (Remote Control)

ASCII HEX Function Description Return Value

VXXS0401 56H 39H 39H 53H 30H 34H 30H 31H 0DH UP arrow P/F

VXXS0402 56H 39H 39H 53H 30H 34H 30H 32H 0DH DOWN arrow P/F

VXXS0403 56H 39H 39H 53H 30H 34H 30H 33H 0DH LEFT arrow P/F

VXXS0404 56H 39H 39H 53H 30H 34H 30H 34H 0DH RIGHT arrow P/F

VXXS0405 56H 39H 39H 53H 30H 34H 30H 35H 0DH POWER P/F

VXXS0406 56H 39H 39H 53H 30H 34H 30H 36H 0DH EXIT P/F

VXXS0407 56H 39H 39H 53H 30H 34H 30H 37H 0DH INPUT P/F

VXXS0408 56H 39H 39H 53H 30H 34H 30H 38H 0DH AUTO P/F

VXXS0409 56H 39H 39H 53H 30H 34H 30H 39H 0DH KEYSTONE+ P/F

VXXS0410 56H 39H 39H 53H 30H 34H 31H 30H 0DH KEYSTONE- P/F

VXXS0411 56H 39H 39H 53H 30H 34H 31H 31H 0DH MENU P/F

VXXS0412 56H 39H 39H 53H 30H 34H 31H 32H 0DH STATUS P/F

VXXS0413 56H 39H 39H 53H 30H 34H 31H 33H 0DH MUTE P/F

VXXS0414 56H 39H 39H 53H 30H 34H 31H 34H 0DH ZOOM+ P/F

VXXS0415 56H 39H 39H 53H 30H 34H 31H 35H 0DH ZOOM- P/F

VXXS0416 56H 39H 39H 53H 30H 34H 31H 36H 0DH BLANK P/F

VXXS0417 56H 39H 39H 53H 30H 34H 31H 37H 0DH FREEZE P/F

VXXS0418 56H 39H 39H 53H 30H 34H 31H 38H 0DH VOLUME+ P/F

VXXS0419 56H 39H 39H 53H 30H 34H 31H 39H 0DH VOLUME- P/F

VXXS0420 56H 39H 39H 53H 30H 34H 32H 30H 0DH Enter P/F

1:Rear
2:Ceiling
3:Rear+Ceiling
0:Front
1:Rear
2:Ceiling
3:Rear+Ceiling

n= -40~40 Pn/F

n= -40~40 P/F

Pn/F

P/F

— 66—
