VIV-AV-750
Instruction Manual
Limited One Year Warranty
Vivitar warrants this quality product to be free of defects in material and workmanship for a
period of one year from the date of purchase. During the period, Vivitar will repair or replace the
product at no charge for parts or labor.
TIME PERIOD OF THIS WARRANTY
The time period of this warranty starts from the date of the original purchase and expires on the
first anniversary date of purchase.
WHAT IS NOT COVERED BY THIS WARRANTY
No express or implied warranty is made for any defects in this product which result from
accident, abuse, misuse, failure to operate the product in accordance with relevant instructions,
neglect, immersion in or exposure to chemicals or liquids, extremes of climate, fungus, excessive
wear and tear/cosmetic damage and defects resulting from other extraneous causes such as
unauthorised disassembly, repair or modification.
This warranty shall not extend to any incidental or consequential damages arising from the
purchase, use or inability to use this product even if Vivitar has been advised of such damages.
The laws of some countries and some States thereof do not allow the limitation of incidental or
consequential damages, so the above limita
-1-
tion or exclusion may apply to you.
WHAT TO DO WHEN SERVICE IS NEEDED
STEP 1. Package the product and relevant accessories carefully, using ample padding materials and a sturdy
mailing container to prevent damage in transit.
STEP 2. Include in package:
a) Evidence of date and place of original purchase (for example, a copy of your sales receipt).
b) Detailed description of your problem.
c) When possible, a sample evidencing the problem.
STEP 3. Return item (insured) to: (in the U.S.):
Vivitar
Attn: Technical Support
195 Carter Drive
Edison NJ 08817
When service is complete, the product will be returned to you shipping prepaid. In the event the product is
deemed to be not faulty or the defect is a result in wear and tear, Vivitar may levy a handling charge for the
from country and State to State thereof. For more information visit our website www.vivitar.com
TECHNICAL SUPPORT
support team members will answer your questions. For phone support in the US please call 1-800-592-9541, in the
UK call 0800 917 4831. If you would like to call from anywhere else, please visit www.vivitar.com for your local toll
free number.
(in the U.K.)
Sakar UK
2D Siskin Parkway East
CV3 4PE, UK
-2-
Included with Your Binoculars
-Carrying Case
-Shoulder Strap
-Cleaning Cloth
-User’s Manual with Warranty Information
Your binoculars will be particularly useful while participating in the following activites:
Outdoor Activities Nature Viewing Birdwatching Sporting Events
-3-
Specifications
Optical Design: BAK 4 Porro Prism
Diameter: 50mm (1.96 inches)
Magnification: 7x
Angular Field of View : 7.1°
Linear Field of View @ 1000 YDS: 372ft (113.38m)
Exit Pupil Distance: 24mm (0.93 inches)
Exit Pupil Diameter: 5.0mm (0.19 inches)
Minimum Focus Distance: 10m
Dimensions: 200x185x80mm
Optical Coatings: Multi-Coated
Features
-Waterproof
-7x Magnification
-Reliable Center Wheel Focus Design
-Multicoated Optics for Clear Sharp Views
-Diopter Adjustment for Precise Focusing
-Nitrogen Filled and Sealed
-4-
Using Your Binoculars
1. Hold the binoculars close to your face so that the eyepieces line up to
your eyes. Use both hands to hold each barrel firmly.
2. Pull the barrels together or apart so that the eyepieces are suitably
spaced to account for the distance between your eyes.
3. Set the Diopter Knob to zero.
4. Look through the binoculars and focus on an object of your choosing.
5. Cover the right Objective Lens so that you will be looking through
your left eye only.
6. Rotate the Center Focus Knob until the object you are viewing with
your left eye looks sharp and clear. At this point the object is in focus.
7. Uncover the right Objective Lens and now cover the left Objective
Lens so that you will be looking through your right eye only.
8. Again look at the object of your choice and now rotate the Diopter
Knob until the object you see through your right eye is sharp and
clear. At this point the object is in focus.
9. Now with a turn of the Center Focus Knob, only, both near and far objects can be brought into focus.
-5-
Diopter
Knob
Eyepiece
Objective
lens
Center
Focus
Knob
Cleaning and Maintenance
A. Only wipe with cleaning
B Accumulated dust should be blown off with a syringe or blower brush specifically designed
for this purpose. To remove fingerprints or smears, shred the end of a lens tissue and roll it to
make a swab: dampen it with a lens cleaner especially made for optics and gently wipe the
surface without applying too much pressure. If necessary, repeat using a new swab. To clean,
start at the center of each lens using a circular motion and working to the edge of each lens
for best results.
C. When your binoculars are not in use, they should be stored in a cool dry place.
papers or the included cleaning cloth.
Warning
Never attempt to observe the sun through your binoculars. Attempts to do so
can cause irreversible eye damage and even blindness.
