Vivint AP03 Users Manual

Installation and User Guide

SR1530

Outdoor Wireless AP

Version 0.01

4931 NORTH 300 WEST

PROVO, UT 84604

T: 801.377.9111

F: 801.377.4116

SR1530 Installation and User Guide Page 2

Record of Changes

Manual Version /
Date

0.01 May 5, 2015 Preliminary version

Description

SR1530 Installation & User Guide Ver. 0.01

SR1530 Installation and User Guide Page 3

Notices

This product contains software proprietary to Vivint and protected by US and International copyright law.
Unauthorized reproduction or disclosure, in whole or in part, is strictly prohibited.

The software and methods implemented in this product may be protected by US Patents:

Patent Application Name

DYNAMIC ROUTING WITHIN A
WIRELESS MESH NETWORK

DYNAMIC ADJUSTMENT OF
QUALITY OF SERVICE
PARAMETERS IN RESPONSE
TO CHANGING NETWORK
CONDITIONS

SYSTEM FOR MINIMIZING
INTERFERENCE THROUGH
SIMULTANEOUS CHANNEL
SWITCHING WITHIN A MESH
NETWORK, AND METHODS,
DEVICES, SOFTWARE, AND
COMPUTER-READABLE MEDIA
ASSOCIATED THEREWITH

MULTICAST TRAFFIC
MANAGEMENT WITHIN A
WIRELESS MESH NETWORK

BANDWIDTH ESTIMATION
BASED ON LOCATION IN A
WIRELESS NETWORK

Patent
Application
Number

61/794,869 U.S.

61/785,074 U.S.

61/784,795 U.S.

61/794,968 U.S.

61/793,415 U.S.

Jurisdiction of
Grant

SYSTEMS AND METHODS FOR
EXTENDING BROADBAND
ACCESS THROUGH A
WIRELESS MESH NETWORK

61/793,177 U.S.

Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a residential environment. This equipment generates, uses, and can
radiated radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

 Reorient or relocate the receiving antenna.

SR1530 Installation & User Guide Ver. 0.01

SR1530 Installation and User Guide Page 4

 Increase the separation distance between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

This device complies with FCC Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

Caution, changes or modifications not expressly approved by Vivint could void the
user’s authority to operate the equipment.

RF Exposure: In order to comply with radio frequency (RF) exposure limits, the
antennas for this product should be positioned no less than 20 cm from your body or
nearby persons.

SR1530 Installation & User Guide Ver. 0.01

SR1530 Installation and User Guide Page 5

Copyright

SR1530 Outdoor Wireless AP, Installation and User Guide, Version 0.01
© 2015. Vivint Wireless All right reserved.

SR1530 Installation & User Guide Ver. 0.01
