VIVIBright PLW4100F,Large Venue Projector
8.WIFI DISPLAY
Basic Features
1* Perfect Image quality With a Pixelworks™ Processor.by SONY "BrightEra" 3LCD Panels
2* Brightness: 7000 ansi Lumens (Market) / 6500 ansi Lumens (std)
3* Resolution: WXGA /native 1280x800 Pixels.
4* Weight: 7.8kg only Projector, 15 kg with Packing,G.W including packing 21kg
5* Excellent Connectivity
6* High emitting effeciency,High performance 330W Ushio Brand Single Lamp
7* HDMI*2; DP*1; USB-A*1(Read JPEG); RJ45*1 (Display); USB-B*1(Display) Standard terminal
8* WIFI Display.
9* Power Lens Shift(U/D 50%; L/R 10%) & Lens options(Short throw lens,Long throw lens,Ultra ST lens,Ultra LT lens,360 Fisheye lens...)
Basic Parameters:
Display Technology
Native Resolution
Max. Computer Input
Max. Video Input
Brightness
Contrast
Fan Noise
Aspect Ratio
Projection Method
Dimensions (W x D x H)
Weight
I/O Connectors
Maximum Resolution
Computer Compatibility
Video Compatibility
Displayable Colours
Projection Lens
Throw Ratio
Projection Distance
Horizontal Scan Rate
Vertical Scan Rate
Lamp Type/Lamp Life
Keystone Correction *
Remote Control
Power Supply
Power Consumption
Operating Conditions
Uniformity
Security
OSD Languages
Standard Accessories
Optional Accessories
Warranty
Outstanding Features
3LCD Panels x 0.75" SONY
WXGA / Native 1280 x 800 Pixels Original resolution_PLW4100F
Full HD,1920X1080 Pixels
2K
7000 ansi Lumens (Market) / 6500 ansi Lumens (std)
4000:1 Contrast Ratio,Dynamic Video contrast ratio up to 10000:1 by HDMI
As low as 31 dBa
4:3 Native, 16:9 Compatible
Front, Rear,Ceiling,Table Top;Projection Image support horizontal and vertical flip
407X417X163mm
7.8 kg
Inputs: PC/Video: VGA*2,DVI*1,BNC*5,Video*1,S-Video*1,YPbPr*1…
HDMI: Double HDMI Terminal output Support HD 1.1~1.4
DP Port: DisplayPort 1.0 (DVI successor,A new generation HD multimedia port)
USB Multimedia
Outputs: VGA Out x 1,Audio output x 1(1*10W),RCA…
Network Control: Wired LAN monitor & control and system management with optional module by RJ45
Control: RS232*1/RJ45/USB-B(Share with input interface )
Full HD 1920 x 1080Pixels via HDMI Terminal
Standard 1080P(1920x1080),WSXGA+,WXGA+,WXGA(1280x800/1280x768),UXGA, SXGA, XGA, SVGA, VGA, Mac…
PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080P, 720p)
1.07 Billion
Standard lens: Power zoom and focus lens, 1.6x optics, F=1.7 -2.2,f=21.3~34.16mm,1/4~16Digital zoom
Power Lens Shift: U/D 50%; L/R 10%
Lens Optional: Short throw lens,Long throw lens,Ultra-short focal-lens,360-degree wide-angle lens,Fisheye lens
60"@1.58M
0.768M~12.989M(30"~300")(Standard Power Lens )
15.3 - 91.1kHz
24 - 85Hz
330W_ Ushio Brand Single Lamp, 6000/5000 hours (ECO/BRIGHT mode)
± 40° Vertical
Full function remote with direct source selecting
100-240V, 50-60Hz
TBD…
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m
90%
Kensington Lock, Password Protection
19 languages:Chinese,English,French,Spanish,Portuguese,German,Italian,Janpanese,Korean,Russian,Finnish,Dutch,Thai,Vietnam…
User Manual(Paper), Lens Cover With String,Power Cord,Remote Control&battery,VGA cable, Warranty card,Qualified card,Drying agent
Ceiling Mount Kit, Additional Ultra long Cable
Projector 3-Years,lamp six months or 500Hrs
Applicable Scope Broad as:
1* large-screen Multimedia projection joining together
2* Multimedia classrooms, multi-functional conference room systems integration
3* Outdoor advertising display
4* Bars, KTV night clubs, concerts and churches
5* Large Home cinema
6* Large auditorium or conference room
7* Multimedia Command System
8* Large conference & showrooms
Outsta nding Fe atures:
1. OneTouch change Lens
2. USB display
3.Horizontal keystone，Four corner keystone
4.Tripple filter(Sponge/ESD/ESD)
5.Support multiple units to be input as internet presentation
6.High speed power off
7.Auto Focus
9.Optional wide-angle and telephoto lenses. Instant lens change system.
USB-A*1(read JPEG); USB-B*1(display)
©Copyright2012 VIVIBright Corporation.BrightEra® &BrightEra logo are registered trademarks of SONY,All specifications are subject to change at any time.
ViviBright Corporation | www.Vivibright.com | Email: [email protected]
Phone: 0086-755-8393 8 394 | M/P:0086-1892 7474740
