USER MANUAL
Read carefully before using the device and save these instructions.
Redefining Tradition
USER MANUAL
1
Table of Contents.....................................................Page
1. An Introduction to Your New VLeaF Device................................2
2. Packaging List of Components...................................................4
3. Getting Started.......................................................................5
4.
Charging................................................................................7
5. Power Indicator.......................................................................8
6. Power On Indicator..................................................................9
7. Setting Your Temperature.......................................................10
8.
Reset..................................................................................11
9. Warranty..............................................................................12
10. Company Contact Information...............................................13
An Introduction to Your New VLeaF Device
VLeaF is a powerful yet versatile pen-style leaf vaporizer that hits
harder than devices five times the price! Five temperature settings
provide you with five options to enjoy your favorite strains just the
way you like it. At the core of this powerful vaporizer is a patent
pending ceramic heating chamber that utilizes a helical air-path
channel to providing both convection and conduction heating
simultaneously. It optimizes heating power, surface area, and
airflow for the most satisfying user experience. A fully isolated air
path provides a pristine, clean taste. Use the included water-pipe
adapter for an amazing session with your glass bong. The vapor is
so pure that you won’t need to clean your glassware! Simply grind
your material and pack it into the ceramic bowl, and VLeaf is ready
to go!
• Simple Yet Powerful
• LED Light Indicator
• Built in Li-ion Battery
• Ceramic Heating Chamber
• Water Pipe Adaptor
2
3
An Introduction to Your New VLeaF Device
O Ring
Top Cap
Power Button
LED Light
Display
Battery
Ceramic Heating
Chamber
4
Packaging List of Components
Things included in the box are following:
1* VLeaF 1 * Cleaning Brush
1* Extra O Ring
1* USB Cable
1 *Water
Pipe Adaptor
1 * Quick Guide
1 * Packing Tool
2* Stainless Steel Mesh
(Mesh Number:200)
Silicone Sleeve
Twist and pull off the top cap.
1.
Load grinded materials into the
ceramic bowl.
2.
5
Getting Started
(We only recommend loading
0.1g-0.3g of material each time to
get the best vaping experience.)
Twist and press on the top cap.
3.
Quickly press the power button 5
times to turn on VLeaF. Press and
hold the power button for 2
seconds to start your session. After
flashing for about 30 seconds, the
LED will remain lit to indicate that
VLeaF is ready for use.
4.
6
Getting Started
Power Button
LED Indicator
You can enjoy this session in 90 seconds.
7
Charging
To charge, connect VLeaF to a wall adaptor via the USB cable. We
recommend to use 1 Amp wall adaptor.
Note:
Please disconnect VLeaF from
the charger once the red light
turn off when fully charged.
8
Power Indicator
Battery life remaining is displayed by the LED in the format below：
While the device is on, simply press the power button once to
show the battery life.
Power Button
80-100% battery life
60-79% battery life
40-59% battery life
20-39% battery life
0-19% battery life
9
Power On Indicator
When the device is on, the red led indtcator near the USB port
will remain lit.
The device will automatically turn off when there is no action
for 10 minutes.
Power On Indtcator
10
Quickly press the power button 2X while the device is ON to
adjust the temperature. The LED will flash below the tempera-
ture markings to indicate the current temperature level. Press
the power button 2X to increase to the next temperature level.
You may cycle through the five temperature levels this way to
reach your desired temperature setting.
Setting Your Temperature
Press and hold the power button until the LED turns off to
confirm and exit the temperature adjustment setting. Alterna-
tively, you may simply wait until the LED turns off automatically
to confirm and exit the temperature adjustment setting.
11
Reset to factory defaultsettings: When the device is off, press
and hold the power button for 10 seconds to restore the factory
default settings. The LED will remain lit for 5 seconds to confirm
that reset has been completed.
10 Seconds
Reset
12
Vivant Product Replacement
Warranty
This warranty provides free replacement of an authentic Vivant product
if it malfunctions due to manufacturing defects. This warranty does not
cover any damages outside of expected normal use.
Void of Warranty
Any one of the following conditions will void the warranty:
Voiding the warranty is not limited to the conditions stated above. This
warranty only covers authentic Vivant brand products and is valid for
two years from the user’s date of purchase.
Failure to provide original receipt of purchase.
1.
2.
Product failure or damage due to the use of excessive force or user
negligence (i.e. dropping the device, submerging the device in
liquids, etc.).
3.
Product failure or damage caused by using incompatible parts or
wires (i.e. using the wrong power cable, etc.).
4.
Product failure or damage due to improper use or unauthorized
repair or alteration.
13
Contact Information
Vivant Inc
Address:
3059 Edinger Ave, Tustin, CA 92780, USA
Email: info@vivant.com
Tel: 1-844-8-vivant (1-844-8-848268)
Web: www.vivant.com
