VITRA Eames Radio User Manual
EN
EN
COMPLIANCE
Vitra declares that this radio equipment is in compliance with Directive
2014/53/EU. The full text of which can be found online at the following address:
http://ec.europa.eu/growth/sectors/electrical-engineering/red-directive_en
SAFETY WARNINGS
• This product is only serviceable in the UK
• Do not operate this radio near water
• Do not remove screws or casing parts
• Use only the power supply unit supplied
• Avoid small objects and liquids from entering the product
• Do not attempt to use this radio in temperatures outside the range of 0°C - 40°C.
TECHNICAL SUPPORT
Should you encounter problems using this product, please refer to the
troubleshooting section on page 19 of this owner’s guide.
Alternatively, call Revo technical support on :
UK 01555 666161
From outside the UK + 44 1555 666161
Alternatively, email support@revo.co.uk
For all the other inquiries please contact service@vitra.com or visit
www.vitra.com/contact/contact-product-service
ENVIRONMENTAL INFO
PRODUCT DISPOSAL INSTRUCTIONS (WEEE DIRECTIVE)
The symbol shown here and on the product means that it is classed as Electrical
or Electronic Equipment and should not be disposed with other household or
commercial waste at the end of its working life.
The Waste of Electrical and Electronic Equipment (WEEE) Directive (2002/96/
EC) has been put in place to recycle products using best available recovery
and recycling techniques to minimise the impact on the environment, treat any
hazardous substances and avoid the increasing landfill.
For more information please contact your local authority or the retailer where
the product was purchased.
02
RoHS COMPLIANCE
This product has been designed to comply with international directives on
the Restriction of Hazardous Substances (RoHS).
WARRANTY
Vita GmbH warrants to the end user that this product will be free from
defects in materials and workmanship in the course of normal use for a
period of two years from the date of purchase.
This guarantee covers breakdowns due to manufacturing faults and does
not apply in cases such as accidental damage, general wear and tear, user
negligence, modification or repair not authorised by Vitra GmbH.
COPYRIGHTS AND
ACKNOWLEDGEMENTS
Copyright 2018 Vitra GmbH. All rights reserved.
No part of this publicationmay be copied, distributed,transmitted or
transcribedwithout the permissionof Vitra GmbH.
VITRA and The Eames Radio are trademarks or registered trademarks of
Vitra GmbH.
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks is under license. Qualcomm is
a trademark of Qualcomm Incorporated, registered in the United States and
other countries, used with permission. aptX® is a trademark of Qualcomm
Technologies International Ltd, registered in the United States and other
countries, used with permission.
DISCLAIMER
Vitra GmbH makes no representation or warranties with respect to the
content of this publication, and specifically disclaims any implied warranties
of merchantability or fitness for any particular purpose. Further, Vitra GmbH
reserves the right to makechanges to this publication from time to time,
without notification to any person or organisation.
Vitra GmbH, Charles-Eames-Strasse 2, 79576 Weil am Rhein, Germany.
www.vitra.com
EN
CONTENTS
02 Technical Support
02 Environmental Info
02 Warranty
02 Copyrights and Acknowledgements
02 Disclaimer
03 Welcome / Unpacking
04 Anatomy
05 Power Supply
05 Set-Up
06 - 07 DAB Radio Mode
08 - 09 DAB Mode Menu Options
10 - 11 FM Radio Mode / AUX IN Mode
12 - 13 Bluetooth Mode
14 - 15 Alarm Clock
16 - 18 Miscellanous Settings
19 Troubleshooting
FCC NOTICES
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
The normal function of the product may be disturbed by strong
Electro-Magnetic Interference. If so, simply reset the product to resume
normal operation by following the instruction manual. In case the function
could not resume, please use the product in other location.
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
03
FCC STATEMENTS
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should
be installed and operated with minimum distance 20cm between
the radiator & your boday.
03 FCC Statements
WELCOME
Thank you for purchasing The Eames Radio.
This guide has been designed to quickly get you up-and-running with your
radio, offer guidance on the more complex features of this product and
provide information on safety, warranty details and troubleshooting.
UNPACKING YOUR RADIO
The Eames Radio box should include the following items:
· The Eames Radio
· Power supply with adaptors for UK, Euro and USA
· Owner’s guide
Should any item be missing or damaged, please contact your point of
purchase or email service@vitra.com
NOTE: All packaging should be retained for possible future use, it is the
safest way to transport your radio should it be necessary.
03 FCC Noties
EN
MODE
MENU
INFO PRESET S
LEFT / RIGHT / SE LECT
ON / OFF / VOL UME
R
CONTROL DIAL
POWER / VOLUME DIAL
MODE INFO
MODE
MENU
INFO PRESET S
LEFT / RIGHT / SE LECT
ON / OFF / VOL UME
EAM ES RADIO
Design : Charles & Ray Ea mes, 1946
USB
AUX IN
R
18V DC
1.3A
5V 1A
CONTROL DIAL
POWER / VOLUME DIAL
MODE INFO
PRESETSMENU
KENSINGTON
LOCK
TELESCOPIC
ANTENNA
HEADPHONE
CONNECTOR
USB CHARGING
& UPGRADE PORT
DC POWER
CONNECTOR
AUX IN
ANATOMY OF THE EAMES RADIO
04
EN
The Eames Radio is supplied with a multi-region power supply, meaning
that it can be operated in a number of countries around the world.
Simply choose the correct adaptor for your country from the
selection supplied and attach to the PSU as per the illustration opposite.
POWER SUPPLY (PSU)
EAMES RA DIO
Design : Char les & Ray Eames, 1946
USB
AUX IN
18V DC
1.3A
5V 1A
1 2
!"#$
Please fully extend the antenna before powering the Eames Radio for
the first time.
INITIAL SET-UP
Using the PSU supplied, connect one end to the DC power socket found
on the rear of your radio, then plug the opposite end into the mains
socket on the wall. The Eames Radio will now automatically perform a
scan to see what DAB stations are being broadcast in your area.
05
EN
GETTING READY FOR DAB OPERATION
Please ensure that the radio’s antenna is extended before operation in DAB Mode.
When you switch on the Eames Radio for the first time, it will automatically perform a scan
to see what stations are being braodcast in your area, before storing them alphabetically in
the radio’s memory.
To enter DAB MODE, press the MENU button until the DAB MODE intro screen is displayed.
It may be necessary to perform a FULL SCAN from time to time, in order to update your
radio’s station list. This may be required for any one of the following reasons:
1. Station availability can change from time to time as new stations appear, or existing
stations cease broadcasting.
2. Reception was poor during the initial automatic scan, if for example the radio’s antenna
was not completely extended, it may be that the station list is incomplete or even empty.
3. You have poor reception on some of the stations (resulting in broken or poor quality
audio), you may wish to list only stations that have a strong signal strength.
To initiate a scan, press the MENU button then select FULL SCAN from the menu list.
When the scan is complete, your radio will list all available stations.
To remove stations that are listed but unavailable, press MENU then choose PRUNE.
When asked whether you wish to “PRUNE?”, select YES.
DAB RADIO MODE
Scanning... 52
DAB
Prune?
YES <NO>
06
