Vitek VT-SMKC9-H User Manual

VT-SMKC9/H
700TVL 960H Covert Color
Smoke Detector Camera
VITEK
SONY® 1/3 Super HAD CCD II 960H CCD, ultra-high
700 TV lines resolution
Minimum Illumination of Color: 0.3 lux B/W: 0.01 lux
Camera Mounted On Adjustable Gimbal To Achieve the
Perfect Viewing Angle
3.6mm Standard lens Included (Optional 2.8mm to 25mm
Dimensions: 5.12” (OD) X 2.29” (H)
black
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
1. Unit contains uninsulated dangerous voltage within the enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons
2. Only use DC Power Supply
3. Read & Keep these instructions.
4. Heed all warnings and follow all instructions carefully.
5. Do not use near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. install in accordance with the instructions.
8. Do not install near any heat source such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has to blades with one wider the other. A grounding type plug has to blades and a third grounding plug. The wide blade or the third prong are provided for safety. if the provided plug dose not fit into your into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Pay attention to safety when installing the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
11. Only use attachment/accessories specified by VITEK.
12. Use only with bracket sold with the Unit.
13. Unplug this unit during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel, Servicing is required when the unit has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the unit, the unit has been exposed to rain or moisture, does not operate normally or has been dropped.
15. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personal.
CAUTION - To reduce the risk of electric shock, do not perform any servicing other than contained in these operating instructions unless you are qualified to do so.
2
5.12
0.99
DIMENSIONS
(unit: inches)
2.29
5.12
3
blackblack
NOTES
4
black
Detailed Specifications VT-SMKC9/H
Image Device
Effective Pixels
Resolution
Lens
Minimum Illumination
S/N Ratio
Electronic Shutter
AGC
White Balance
Digital WDR
Back Light Compensation
Day/Night Mode
2DNR
Lens Shading
Sync. Mode
Scanning System
Gamma Correction
1/3” Sony® Super HAD CCD II
<NTSC>: 976(H)*494(V) ; <PAL>: 976(H)*582(V)
700 TV Lines 960H
3.6 mm Board Lens
Color:0.3lux B/W:0.01lux
More than 50dB
<NTSC>: 1/60~1/100,000 sec ; <PAL>: 1/50~1/100,000 sec
On
ATW
ON
BLC
Auto
ON
ON
Internal Sync.
2:1 Interlace
0.45
Horizontal Sync. Frequency
Vertical Sync. Frequency
Video Output
Power Source
Power Consumption
Operation Temperature
Standard Lens
Dimensions (W x H)
Weight
<NTSC>: 15.734 KHz ; <PAL>: 15.625KHz
60Hz
Composite: 1.0 Vp-p / 75 Ohm
12 VDC
350mA
-10° ~ 50°C (14° ~ 122°F) Less Than 80% RH
f3.6mm (Optional 2.8mm to 25mm Available)
5.12” x 2.29” (130 x 58mm)
12.34 Oz. / 350 g. / 0.77 Lbs.
* Depending on Scene Reflection
5
black
LIMITED LIABILITY WARRANTY
Your new Camera is guaranteed to be free from defects in materials and workmanship for a period of three years from the date of purchase.
The product must have been used only for its intended purpose, and not been subjected to damage by misuse, willful or accidental damage, caused by excessive voltage or lightning.
The product must not have been tampered with in any way then the guarantee will be considered null and void.
This guarantee does not affect your statutory rights.
Contact an Authorized VITEK reseller for all servicing needs.
28492 Constellation Road ValenCia, Ca 91355
WWW.ViteKCCtV.CoM
6
Version 1.1
March 2015
