Vitek VTM-143C User Manual
VITEK
VTM-143C
14” Color CRT Monitor
• 450 TV Lines At Center on a 14" Diagonal Screen
• Attractive Black Metal Cabinet
• Digital Front Panel Controls For: Tint, Color, Brightness, Contrast
• Front Panel Video Source Buttons for: Video1 / Video2 / S-Video
• 2 Looping Video Inputs & Dual Audio In / Out
• Rack Kit Available: VI-141CRM
SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRICAL SHOCK
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER, NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference with radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference with radio or
television reception, which can be determined by turning the equipment off and on, the user should correct the interference by
taking one or more of the following actions:
- Re-orient or relocate the receiving antenna.
- Increase the distance between the equipment and receiver.
- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced Radio/TV technician for help.
The user may find the following booklet prepared by the Federal Communications Commission helpful:
HOW TO IDENTIFY AND RESOLVE RADIO-TV INTERFERENCE PROBLEMS.
This booklet is available from the US Government Printing Office, Washington, DC 20402, Stock Number 004-000-00345-4
DO NOT OPEN
1) Read Instructions
All the safety and operating instructions should be read
before the appliance is operated.
2) Retain Instructions
The safety and operating instructions should be retained for
future reference.
3) Heed Warnings
All warnings on the product and in the operating instructions
should be adhered to.
4) Follow Instructions
All operating and use instructions should be followed.
5) Cleaning
Unplug this product from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning the unit.
Exception: A product that is meant for uninterrupted service
and that for some specific reason, such as the possibility of
the loss of an authorization code for a CATV converter, is not
intended to be unplugged by the user for cleaning or any
other purpose, may exclude the reference to unplugging the
product in the cleaning description.
6) Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7) Water and Moisture
Do not use this product near water, for example near a bath
tub, wash bowl, kitchen sink, or laundry tube in a wet
basement or near a swimming pool and the like.
8) Accessories
Do not place this product on an unstable cart, stand, tripod,
bracket or table. The product may fall, causing serious injury
to a child or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket or table recommended
by the manufacturer, or sold with the product. Any mounting
of the product should follow the manufacturer’s instructions,
and should use a mounting accessory recommended by the
manufacturer.
9) Any product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces may
cause the product and cart combination to overturn.
10) Ventilation
Openings in the cabinet are provided for ventilation and to
ensure reliable operation of the product and to protect it from
overheating and these openings must not be blocked or
covered. The openings should never be blocked by placing
the product on a bed, sofa, rug or other similar surface. This
product should not be placed in a built-in installation such as
a bookcase or rack unless proper ventilation is provided or
the manufacturer’s instructions have been adhered to.
2
SAFETY INSTRUCTIONS
11) Power Sources
This product should be operated only from the type of power
resource indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your appliance
dealer or local power company. For products intended to
operate from battery power or other sources, refer to the
operating instructions.
12) Grounding or Polarization
This product is equipped with a three-wire grounding-type plug
a plug having a third (grounding) pin. This plug will only fit into
a grounding-type power outlet. This is a safety feature. If you
are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the grounding-type plug.
13) Power-Cord Protection
Power-supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against
them paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
14) Protective Attachment Plug
The product is equipped with an attachment plug having
overload protection. This is a safety feature. See instruction
Manual for replacement or resetting of protective device. If
replacement of the plug is required, be sure the service
technician has used a replacement plug specified by the
manufacturer that has the same overload protection as the
original plug.
15) Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the
product, be sure the antenna or cable system is grounded so
as to provide some protection against voltage surges and builtup static charges. Article 810 of the National Electrical Code.
ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding
electrodes.
16) Lightning
For added protection for this product during a lightning storm,
or when it is left unattended and unused for long periods of
time, unplug the product from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the
product due to lightning and power line surges.
17) Power Lines
An outside antenna should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or
where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits as
contact with them may be fatal.
18) Overloading
Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or
electric shock.
19) Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short
out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the receiver.
20) Servicing
Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
21) Damage Requiring Service
Unplug the product from the wall outlet and refer service
opening to qualified service personnel under the following
conditions:
a) when the power-supply cord or plug is damaged,
b) if liquid has been spilled, or objects have fallen into the
product,
c) if the product has been exposed to rain or water.
d) if the product does not operate normally by following the
operating instructions. Adjust only the controls that are covered
by the operating instructions as an improper adjustment of
other controls may result in damage and will often require
extensive work by a qualified technician to restore the video
product to its normal operation.
e) If the product has been dropped or damaged in any way,
and
f) When the product exhibits a distinct change in performance this indicates a need for service.
22) Replacement Parts
When replacements parts are required, be sure the service
technician has used replacements parts specified by the
manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may results in fire, electric
shock or other hazards.
23) Safety Check
Upon completion of any service or repairs to this receiver, ask
the service technician to perform safety checks to determine
that the product is in proper operating condition.
24) Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
25) Heat
The product should be situated away from heat sources such
as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
3
