Page 1
VITEK
• 620 TV Lines of Resolution
• 1/3” Sony SuperHAD II CCD
• Hercules DSP Engine
• 3.6mm Fixed and 2.8~12mm IR Corrected DC Auto-Iris Lens Options
• Available with 35 IR LEDs (120’ Range)
• Advanced OSD Functions: WDR, 3D DNR, DSS, DIS, Sens-up, Motion
Detection, Privacy
• Secondary Video Output (Cable Included)
• 3-Axis Mount for Optimum Viewing Angle
Alpha Series Indoor
High Resolution WDR
Dome Cameras
Page 2
BOX CONTENTS
BOX CONTENTS AVAILABLE MODELS / ACCESSORIES
1) Dome Camera
2) Mounting Accessories
3) This instruction Manual & Mounting Template
BOX CONTENTS
Self Tapping Screws
For attaching the housing base to a solid surface.
Type #: Phillips ST4x30
Qty: 4
BOX CONTENTS AVAILABLE MODELS / ACCESSORIES
1) Dome Camera
2) Mounting Accessories
3) This instruction Manual & Mounting Template
BOX CONTENTS
Self Tapping Screws
For attaching the housing base to a solid surface.
Type #: Phillips ST4x30
Qty: 4
Secondary Video Output Cable
To be used with a service monitor for adjusting
the angle, focus and zoom.
Qty: 1
1) Dome Camera
2) Mounting Accessories
3) This instruction Manual & Mounting Template
BOX CONTENTS
Self Tapping Screws
For attaching the housing base to a
solid surface.
Type #: Phillips ST4x30
Qty: 4 (2 screws - VTD-A4F/I)
Secondary Video Output Cable
To be used with a service monitor for
adjusting
the angle, focus and zoom.
Qty: 1
2
Page 3
AVAILABLE MODELS / ACCESSORIES
VTD-A4F/IW
Indoor High Resolution WDR Dome Camera with White Base.
VTD-A4F/IB
Indoor High Resolution WDR Dome Camera with Black Base.
VTD-A2812/IW
Indoor High Resolution WDR Varifocal Dome Camera with White
Base.
VTD-A2812/IB
Indoor High Resolution WDR Varifocal Dome Camera with Black
Base.
VTD-AR2812/IW
Indoor High Resolution Infrared WDR Varifocal Dome Camera
with White Base.
VTD-AR2812/IB
Indoor High Resolution Infrared WDR Varifocal Dome Camera
with Black Base.
3
Page 4
VTD-A4F/I INSTALLATION
VTD-A2812/IB / VTD-A2812/IW INSTALLATION
VTD-A4F/IB / VTD-A4F/IW INSTALLATION
4.
Pan / Tilt (3Axis) Controls
GUIDE PATTERN
5. Closing the cover
4
Page 5
VTD-A2812/I INSTALLATION
VTD-A2812/IB / VTD-A2812/IW INSTALLATION
a
GUIDE PATTERN
5
Page 6
VTD-AR2812/I INSTALLATION
a
6
GUIDE PATTERN
Page 7
OSD OPERATION
OSD OPERATION
7
Page 8
OSD OPERATION
OSD MENU TREE
8
Page 9
OSD OPERATION
9
Page 10
OSD OPERATION
10
Page 11
OSD OPERATION
The Wide Dynamic Range feature improves the overall picture balance beyond the
Backlight Compensation feature. It creates an optimal balance of brightness and color
by combining images from a bright area (high shutter speed) and images from a dark
area (low shutter speed).
11
Page 12
OSD OPERATION
OSD OPERATION OSD OPERATION
s
a cleaner
12
Page 13
13
OSD OPERATION
s
Page 14
OSD OPERATION
OSD OPERATION OSD OPERATION
14
Page 15
15
OSD OPERATION
Page 16
OSD OPERATION
OSD OPERATION OSD OPERATION
16
Page 17
17
OSD OPERATION
Page 18
OSD OPERATION
18
Page 19
19
OSD OPERATION
Page 20
OSD OPERATION
OSD OPERATION OSD OPERATION
on
Y
ays
the
s
ly
t
s
d
is
20
Page 21
shown
21
OSD OPERATION
Page 22
OSD OPERATION
22
Page 23
VTD-A4F/I
4.23” (107.5mm)
DIMENSIONS
3.54” (89.97mm)
3.35” (85mm)
3.07” (78mm)
VTD-A2812/I
VTD-AR2812/I
3.35” (85mm)
3.36” (85.30mm)
3.94” (100mm)
5.44” (138.30mm)
4.60” (117mm)
3.94” (100mm)
3.69” (93.76mm)
5.44” (138.30mm)
3.94” (100mm)
5.44” (138.30mm)
23
Page 24
SPECIFICATIONS
VTD-AF4/ I
Image Device 1/3” Sony SuperHAD II CCD
Resolution 620 TV Lines
Min. Illumination 0.1 Lux at F1.2 (Color) / 0.0001 Lux (Sense up x256)
Effective Pixels 811 (H) x 508 (V) 410K pixels
S/N Ratio More Than 52dB (AGC Off)
Shutter AUTO / MANUAL (1/60sec~1/100,000sec)
White Balance ATW / AWC / PUSH / MANUAL (Adjustable)
Standard Lens 3.6mm Fixed Lens
Video Output CVBS: 1.0Vp-p / 75ohm
Power Source 12VDC Operation
Environmental 14°F~122°F (-10°C~50°C) at 30%~80% RH
Dimensions 4.6” x 3.07” (117mm x 78mm)
Weight 0.5lbs (227g)
24
Page 25
SPECIFICATIONS
VTD-A2812/ I
Image Device 1/3” Sony SuperHAD II CCD
Resolution 620 TV Lines
Min. Illumination 0.1 Lux at F1.2 (color) / 0.0001Lux (Sense up x256)
Effective Pixels 811(H) x 508(V) 410K pixels
S/N Ratio More Than 52dB (AGC Off)
Shutter AUTO / MANUAL (1/60sec ~ 1/100,000sec)
White Balance ATW / AWC / PUSH / MANUAL (Adjustable)
Standard Lens 2.8-12mm DC Auto Iris Lens
Video Output CVBS: 1.0Vp-p / 75ohm
Power Source Dual Voltage 12VDC/24VAC Operation
Environmental 14°F~122°F (-10°C~50°C) at 30%~80% RH
Dimensions 5.45” x 3.7” (138.30mm x 93.76mm)
Weight 0.62lbs (272g)
25
Page 26
SPECIFICATIONS
VTD-AR2812/ I
Image Device 1/3” Sony SuperHAD II CCD
Resolution 620 TV Lines
IR LEDs 35 IR LEDs at 850nm
Min. Illumination 0 Lux (IR ON)
Effective Pixels More Than 52dB (AGC Off)
S/N Ratio 811(H) x 508(V) 410K pixels
Shutter AUTO / MANUAL (1/60sec ~ 1/100,000sec)
White Balance ATW / AWC / PUSH / MANUAL (Adjustable)
Standard Lens 2.8-12mm IR Corrected DC Auto Iris Lens
Video Output CVBS: 1.0Vp-p / 75ohm
Power Source Dual Voltage 12VDC/24VAC Operation
Environmental 14°F~122°F (-10°C~50°C) at 30%~80% RH
Dimensions 5.44” x 4.23” (138.3mm x 107.5mm)
Weight 0.75lb (318g)
26
Page 27
VTM-LCDP Series
15”, 17“, and 19” Professional LCD Monitors with
Looping BNC Inputs
• 15”, 17“, and 19” Professional LCD Display Panels
• Designed for continuous 24/7 operation
• VGA, Looping BNC Composite, and S-Video Video Inputs. DVI &
HDMI Inputs on 17“ & 19” Versions
• Resolution up to 1280 X 1024 (17” & 19”)
• Stereo Audio Input/Output
• VESA Standard Mounting
27
Page 28
VT-H Series
4, 8, and 16 Channel Digital Video
Recorders with H.264 Compression
The Alpha Series VT-H Series Digital Recorders combine the latest H.264 Compression
technology with stability and simple operation. H.264 Compression is the next generation of
MPEG4 allowing up to 50% smaller file sizes for increased storage capability and/or
resolution as well as a more fluid internet transmission speed. VT-H Series DVRs can be controlled
via supplied IR Remote control or remote client.
• 4, 8, or 16 Video Inputs with 1 BNC & 1 VGA Output
• H.264 Compression
• Supports both Dynamic and Static IP Addresses
• Up to 120 IPS Recording / Live Display
• Remote Viewing over the Internet or LAN
• Supports one internal SATA Hard Drive
• 250GB to 1TB Internal Storage Options
• Quadplex operation enabling simultaneous recording, playback,
networking, and backup
28
H.264
Page 29
29
NOTES
Page 30
NOTES
30
Page 31
31
NOTES
Page 32
VITEK LIM ITED PRODUCT WARRANTY
VITEK products carry a three (3) year limited warranty. VITEK warrants to the purchaser
that products manufactured by VITEK are free of any rightful claim of infringement or
the like, and when used in the manner intended, will be free of defects in materials and
workmanship for a period of three (3) years, or as otherwise stated above, from the
date of purchase by the end user. This warranty is non-transferable and extends only to
the original buyer or end user customer of a Vitek Authorized Reseller.
The product must have been used only for its intended purpose, and not been subjected to damage by misuse, willful or accidental damage, caused by excessive voltage
or lightning.
The product must not have been tampered with in any way then the guarantee will be
considered null and void.
This guarantee does not affect your statutory rights.
Contact your local VITEK Reseller should servicing become necessary.
Vitek makes no warranty or guarantee whatsoever with respect to products sold or
purchased through unauthorized sales channels. Warranty support is available only if
product is purchased through a Vitek Authorized Reseller.
28492 Constellation Road ValenCia, Ca 91355
