VITEK

VTC-HOCRBD4F

2.1MP HD-SDI Compact Indoor/Outdoor
WDR True Day/Night Ball Camera

FEATURES:

• 1/2.9” Sony Progressive Scan CMOS

• 2.1MegaPixel with Full 1080p/720p HD-SDI Output (SMPTE292M)

• 25 IR LEDs with 70’ Range

• Built in fixed 3.7mm Megapixel lens

• Heavy Duty Vandal & IP67 Weather Resistance rating

• 16:9 Video Format

• 100% Pure Digital Transmission of video data

• Up to 700’ HD Transmission Range (depending on

cable characteristics and integrity)

• 12VDC Operation

Detailed Specifications

Sensor

Resolution

S/N

Video Output

IR Illuminators

IR Color Temp.

IR Range

Dynamic Intensity IR LEDs

Lens

Minimum Illumination

Day/Night

Electronic shutter speed

White Balance

Brightness

DNR

WDR

HD Transmission Range

Weather Resistance Rating

Operating Conditions

Input Voltage

Power Consumption (12VDC)

Dimensions

1/2.9” Sony CMOS

2.1 MegaPixel (1080p / 720p)

More than 52 dB (AGC Off)

1x HD-SDI (BNC)

25 IR LEDs

850nm

70’

YES

3.7mm Fixed

1 Lux at F1.2 / 0.1 Lux (B/W) / 0 Lux at IR On

Auto

Auto

Auto

Auto

3D-DNR

YES

Up to 700’ (Depending on cable characteristics and integrity)

IP-67

14°-122°F (-10°-50°C) < 80% RH

12VDC

190mA / 360mA (IR OFF/ON)

3.06” x 3.67” (H x Dia.)

Sony® and PELCO® are the registered trademarks of their independently owned and operated companies. These products have not been licensed
or endorsed by the manufacturers of Sony® and PELCO® products.
