Distress / Fall-det ector PowerCode™ Transmitter
1. INTRODUCTION
1. INTRODUCTION
1. INTRODUCTION1. INTRODUCTION
The MCT-241MD RL is a miniature,
microprocessor-controlled personal UHF
transmitter. It is designed to transmit coded alert
signals manually (when the user presses the
button) or automatically (when the user falls
down). The transmitter is waterproof and suitable
for wearing in a shower. Operating power is
obtained from an internal 3V CR-2 Lithium battery.
Transmission is initiated in the following cases:
!
Depressing the recessed oval pushbutton (see
Fig. 1). A built-in timer determines the
transmission time to 3 seconds, even if the user
maintains the button pressed shorter or longer
than that.
!
Tilting the transmitter by more than 60° in any
direction. In this case, the 3-second transmission
will take place after a 2- second delay.
When triggered, the MCT-241MD RL transmits a
unique 24-bit digital ID, randomly selected in the
factory. This code is one of 16 million possible code
combinations and is therefore virtually impossible to
reproduce. The ID code is followed by the
appropriate digital marker that indicates an “alarm”
or a ‘fall-detector” event, as the case may be.
A red LED (see Fig. 1) lights steadily during
transmission, to reassure the user that a
transmission is taking place and to indicate that
the battery condition is good. If the LED flashes
each time the transmitter is triggered, this
indicates that the voltage is low and the battery
must be replaced as soon as possible.
If the transmitter is triggered while the battery
voltage is low, a ‘low battery’ digital marker is
included in the transmitted message. In addition,
the battery is self-tested every 12 hours. A
supervisory ‘low battery’ message is transmitted
after detection of 3 consecutive “low battery” states.
2222. OPERATION AND EN ROLLMENT
. OPERATION AND ENROLLMENT
. OPERATION AND ENROLLMENT. OPERATION AND ENROLLMENT
The transmitter case is hermetically sealed (no
screws) to ensure complete waterproofing of the
case. Battery replacement can therefore be carried
out in the factory only.
The transmitter is supplied with two wearing
accessories, a neck cord (to be worn around the
neck - see Fig. 2) and a clip (to be attached to the
user belt or shirt pocket - see Fig. 3).
The neck cord includes a built-in safety release
mechanism. This neck cord must never be replaced
with a cord that does not include a safety release.
User’s Guide
MCT -241MD RL Transmitter
Transmission
pushbutton
Clip
Figure 1 - Using the MCT-241MD RL
Figure 2 - MCT-241MD RL with Neck Cord
Figure 3 - Clip Attachment
LED
Front side
(don’t cover
with hand
during
transmission)
2.1 Transport Mode
New MCT-241MD RL units are shipped with the tilt
(fall-detector) function in ‘deep sleep”, to prevent
inadvertent transmissions until the unit is placed
into service. To ‘awaken” the tilt function, the
alarm pushbutton must be pressed at least 5 times
in succession.
DE2294RLU 1
2.2 Tilt Alarm/Tilt Restore
A built-in tilt sensor is activated once the unit is
tilted over by more than 60° in any direction. The
Base Unit will notify the user after 30 seconds, and
the actual tilt alarm transmission to the central
station will take place af ter an additional 30-second
delay, throughout which t he unit may be restored to
the upright position. This allows the user to pr event
an accidental “tilt alarm” message from being
transmitted. If a tilt alarm had bee n transmit ted and
the unit was subsequently returned to the upright
position, a “tilt restore” message will be transmitted.
Note: Please refer to the POM3000 user manual
for further details on this feature.
2.3 Low Battery Voltage Indication
The battery is automatically tested under load
once in 12 hours. If a low battery state is
registered in 3 consecutive tests, a “low battery”
message will be transmitted, and a “low battery”
digital marker will be included in every
transmission, “alarm” or “tilt”. In addition, when the
battery voltage is low, the LED flashes while the
pushbutton is pressed.
2.4 Transmitter Stand
When putting the transmitter away, it is
recommended to use the special stand included in
the package (Fig. 5). The stand will maintain the
unit in a vertical (upright) position, thus preventing
accidental activation of the tilt sensor. Place the
stand on a flat surface, then insert the bottom end
of the unit into the stand.
2.5 Initial Test
Upon press of the transmission butt on, the control
panel will sound and display simultaneously
CALLING SERVICE BUREAU… until contact is
established. This means that the transmitter is
working properly.
Note: If for any re ason the MCT-241 MD RL does
not result in the above response from the control
panel, please contact the central station at 1-800894-1428 and verify th e PowerCo de ID located both
on the unit's p ackage an d on the r e verse s ide of th e
transmitter.
2.6 Teaching the Target Receiver
To provide the desired response, the target
receiver must “learn” to identify the Transmitter ID
code. Advise the Central Station (either by
telephone or by fax) of the Transmitter ID located
both on the unit's package and on the reverse side
of the unit.
Figure 4. Transmitter Stand
3333. SPECIFICATIONS
. SPECIFICATIONS
. SPECIFICATIONS. SPECIFICATIONS
Frequency (MHz): 315, stabilized by SAW resonator
Frequency Tolerance:
Modulation: A.S.K (on-off keying)
Encoding: Factory programmed, 24-bit digital word
Transmission Duratio n: 3 seconds (even if the user keeps the
transmission button depressed shorter or longer than that)
Power Supply: 3 V Lithium Battery, 0.7 Ah Panasonic CR-2 only.
(Battery replacement is performed at the factory.)
Current Consumption: 7
transmission)
Batt ery Life Expecta nc y: 3 years (for typical use)
Battery Condition Indication and Reporting:
A. Good battery - the LED lights steadily upon transmission.
B. Low battery - when transmission button is pressed, “low
battery” alarm code is transmitted and the LED flashes.
±
120 kHz
µ
A (during standby), 10 mA (during
C. Battery supervision - every 12 hours. If 3 consecutive “low
battery” states are detected, a “low battery” message is
transmitted.
Operating Temperature: -10°C to 40°C (14°F to 104°F)
Dimensions (H x W x D):
With Clip: 73 x 41 x 30 mm (2-7/8 x 1-5/8 x 1-3/16 in.)
Witho ut Clip: 67 x 41 x 21 mm (2-5/8 x 1-5/8 x 13/16 in.)
Weight: 35 g (with clip), 30 g (without clip)
Color: White
Compliance with Standards: Meets FCC Part 15, MPT1349
and Directive 1999/5/EC
This device complies with the essential requirements and
provisions of Directive 1999/5/EC of the European Parliament
and of the Council of 9 March 1999 on radio and
telecommunications terminal equipment.
