D2PAK
PRODUCT SUMMARY
I
F(AV)
V
R
Schottky Rectifier, 15 A
FEATURES
N/C
Base
cathode
1
2
3
Anode
15 A
60 V
• 150 °C TJ operation
• Very low forward voltage drop
• High frequency operation
• High purity, high temperature epoxy
encapsulation for enhanced mechanical
strength and moisture resistance
• Guard ring for enhanced ruggedness and long
term reliability
• Meets MSL level 1, per J-STD-020, LF maximum peak of
260 °C
• Halogen-free according to IEC 61249-2-21 definition
• Compliant to RoHS directive 2002/95/EC
• AEC-Q101 qualified
DESCRIPTION
The VS-15TQ060SPbF Schottky rectifier has been
optimized for very low forward voltage drop, with moderate
leakage. The proprietary barrier technology allows for
reliable operation up to 150 °C junction temperature. Typical
applications are in switching power supplies, converters,
freewheeling diodes, and reverse battery protection.
VS-15TQ060SPbF
Vishay High Power Products
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL CHARACTERISTICS VALUES UNITS
I
F(AV)
V
I
FSM
V
T
RRM
F
J
Rectangular waveform 15 A
60 V
tp = 5 μs sine 1000 A
15 Apk, TJ = 125 °C 0.56 V
Range - 55 to 150 °C
VOLTAGE RATINGS
PARAMETER SYMBOL VS-15TQ060SPbF UNITS
Maximum DC reverse voltage V
Maximum working peak reverse voltage V
R
RWM
60 V
ABSOLUTE MAXIMUM RATINGS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum average forward current
See fig. 5
Maximum peak one cycle
non-repetitive surge current
See fig. 7
Non-repetitive avalanche energy E
Repetitive avalanche current I
Document Number: 94143 For technical questions, contact: diodestech@vishay.com
Revision: 12-Mar-10 1
I
F(AV)
I
FSM
50 % duty cycle at TC = 104 °C, rectangular waveform 15 A
5 μs sine or 3 μs rect. pulse
10 ms sine or 6 ms rect. pulse 260
TJ = 25 °C, IAS = 1.5 A, L = 11.5 mH 6 mJ
AS
AR
Current decaying linearly to zero in 1 μs
Frequency limited by T
maximum VA = 1.5 x VR typical
J
Following any rated
load condition and with
rated V
RRM
applied
1000
A
1.50 A
www.vishay.com
VS-15TQ060SPbF
Vishay High Power Products
Schottky Rectifier, 15 A
ELECTRICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
15 A
Maximum forward voltage drop
See fig. 1
V
FM
30 A 0.82
(1)
15 A
30 A 0.71
Maximum reverse leakage current
See fig. 2
I
RM
Maximum junction capacitance C
Typical series inductance L
T
S
TJ = 25 °C
(1)
T
= 125 °C 45
J
VR = 5 VDC (test signal range 100 kHz to 1 MHz), 25 °C 720 pF
Measured lead to lead 5 mm from package body 8.0 nH
Maximum voltage rate of change dV/dt Rated V
T
= 25 °C
J
= 125 °C
T
J
V
= Rated V
R
R
R
0.62
0.56
0.80
10 000 V/μs
Note
(1)
Pulse width < 300 μs, duty cycle < 2 %
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum junction and storage
temperature range
Maximum thermal resistance,
junction to case
Typical thermal resistance,
case to heatsink
Approximate weight
Mounting torque
minimum 6 (5)
maximum 12 (10)
Marking device Case style D
, T
T
J
Stg
R
thJC
R
thCS
DC operation
See fig. 4
Mounting surface, smooth and greased 0.50
- 55 to 150 °C
3.25
2g
0.07 oz.
kgf · cm
(lbf · in)
2
PAK 15TQ060S
V
mA
°C/W
www.vishay.com For technical questions, contact: diodestech@vishay.com
Document Number: 94143
2 Revision: 12-Mar-10
VS-15TQ060SPbF
1000
TJ = 150 °C
= 125 °C
T
J
= 25 °C
100
Current (A)
10
- Instantaneous Forward
F
I
T
J
1
0 0.4 0.8 1.2 1.6 2.0
V
- Forward Voltage Drop (V)
FM
Schottky Rectifier, 15 A
1000
100
10
0.1
- Reverse Current (mA)
R
0.01
I
0.001
Vishay High Power Products
TJ = 150 °C
TJ = 125 °C
TJ = 100 °C
1
01020
TJ = 75 °C
TJ = 50 °C
TJ = 25 °C
30
V
- Reverse Voltage (V)
R
50
40
Fig. 1 - Maximum Forward Voltage Drop Characteristics Fig. 2 - Typical Values of Reverse Current vs.
Reverse Voltage
1000
60
TJ = 25 °C
- Junction Capacitance (pF)
T
C
100
10
020304050
V
- Reverse Voltage (V)
R
60
Fig. 3 - Typical Junction Capacitance vs. Reverse Voltage
10
1
D = 0.75
D = 0.50
0.1
D = 0.33
D = 0.25
D = 0.20
0.01
- Thermal Impedance (°C/W)
thJC
Z
0.001
0.00001 0.0001 0.001 0.01 0.1 1 10 100
Single pulse
(thermal resistance)
Notes:
1. Duty factor D = t
2. Peak TJ = PDM x Z
P
DM
t
1
1/t2
thJC
t1 - Rectangular Pulse Duration (s)
Fig. 4 - Maximum Thermal Impedance Z
Characteristics
thJC
t
2
.
+ T
C
.
Document Number: 94143 For technical questions, contact: diodestech@vishay.com
www.vishay.com
Revision: 12-Mar-10 3
VS-15TQ060SPbF
Vishay High Power Products
150
140
130
120
110
Square wave (D = 0.50)
100
80 % rated V
90
Allowable Case Temperature (°C)
See note (1)
80
02510
I
F(AV)
applied
R
51520
- Average Forward Current (A)
Fig. 5 - Maximum Allowable Case Temperature vs.
Average Forward Current
DC
1000
Schottky Rectifier, 15 A
14
12
10
8
6
4
Average Power Loss (W)
2
0
0
D = 0.20
D = 0.25
D = 0.33
D = 0.50
D = 0.75
RMS limit
DC
822
10
642
I
- Average Forward Current (A)
F(AV)
12
14 16 18
20
Fig. 6 - Forward Power Loss Characteristics
Note
(1)
Formula used: TC = TJ - (Pd + Pd
Pd = Forward power loss = I
Pd
= Inverse power loss = VR1 x IR (1 - D); IR at VR1 = 80 % rated V
REV
At any rated load condition
and with rated V applied
- Non-Repetitive Surge Current (A)
FSM
I
following surge
100
10
tp - Square Wave Pulse Duration (µs)
Fig. 7 - Maximum Non-Repetitive Surge Current
D.U.T.
Current
monitor
Fig. 8 - Unclamped Inductive Test Circuit
) x R
thJC
;
F(AV)
/D) (see fig. 6);
x VFM at (I
F(AV)
REV
100
L
IRFP460
= 25 Ω
R
g
RRM
1000
R
High-speed
switch
Freewheel
diode
40HFL40S02
10 000
V
= 25 V
d
+
www.vishay.com For technical questions, contact: diodestech@vishay.com
Document Number: 94143
4 Revision: 12-Mar-10
VS-15TQ060SPbF
ORDERING INFORMATION TABLE
Device code
VS- 15 T Q 060 S TRL PbF
1 - HPP product suffix
2 - Current rating (15 A)
3
- Circuit configuration: T = TO-220
4 - Schottky “Q” series
5 - Voltage rating (060 = 60 V)
- S = D
6
-
7
8
- PbF = Lead (Pb)-free
Schottky Rectifier, 15 A
324
2
PAK
None = Tube (50 pieces)
TRL = Tape and reel (left oriented)
TRR = Tape and reel (right oriented)
51
678
Vishay High Power Products
LINKS TO RELATED DOCUMENTS
Dimensions www.vishay.com/doc?95014
Part marking information www.vishay.com/doc?95008
Packaging information www.vishay.com/doc?95032
Document Number: 94143 For technical questions, contact: diodestech@vishay.com
Revision: 12-Mar-10 5
