Vishay MBR20..CTPbF Series Data Sheet

TO-220AB

Schottky Rectifier, 2 x 10 A

FEATURES

• 150 °C TJ operation

Base

common

Anode

2

cathode

2

Common

13

cathode

Anode

• Center tap TO-220 and D

• Low forward voltage drop

• High frequency operation

• High purity, high temperature epoxy
encapsulation for enhanced mechanical strength and
moisture resistance

• Guard ring for enhanced ruggedness and long term
reliability

• Lead (Pb)-free (“PbF” suffix)

• Designed and qualified for industrial level

MBR20..CTPbF Series

Vishay High Power Products

2

PAK packages

Pb-free

Available

RoHS*

COMPLIANT

PRODUCT SUMMARY

I

F(AV)

V

R

I

RM

2 x 10 A

35/45 V

15 mA at 125 °C

DESCRIPTION

This center tap Schottky rectifier has been optimized for low
reverse leakage at high temperature. The proprietary barrier
technology allows for reliable operation up to 150 °C junction
temperature. Typical applications are in switching power
supplies, converters, freewheeling diodes, and reverse
battery protection.

MAJOR RATINGS AND CHARACTERISTICS

SYMBOL CHARACTERISTICS VALUES UNITS

I

F(AV)

V

RRM

I

FRM

I

FSM

V

F

T

J

Rectangular waveform (per device) 20 A

35/45 V

TC = 135 °C (per leg) 20

tp = 5 µs sine 1060

10 Apk, TJ = 125 °C 0.57 V

Range - 65 to 150 °C

A

VOLTAGE RATINGS

PARAMETER SYMBOL MBR2035CTPbF MBR2045CTPbF UNITS

Maximum DC reverse voltage V

Maximum working peak reverse voltage V

R

RWM

35 45 V

ABSOLUTE MAXIMUM RATINGS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum average
forward current

Peak repetitive forward current per leg I

Non-repetitive peak surge current I

Repetitive avalanche current per leg I

Non-repetitive avalanche energy per leg E

* Pb containing terminations are not RoHS compliant, exemptions may apply

Document Number: 94288 For technical questions, contact: [e-mail]
Revision: 21-Aug-08 1

per leg

per device 20

I

F(AV)

FRM

FSM

AR

TC = 135 °C, rated V

Rated VR, square wave, 20 kHz, TC = 135 °C 20

5 µs sine or 3 µs rect. pulse

Surge applied at rated load condition half wave,
single phase, 60 Hz

Current decaying linearly to zero in 1 µs
Frequency limited by T

TJ = 25 °C, IAS = 2 A, L = 4 mH 8 mJ

AS

R

Following any rated load condition
and with rated V

maximum VA = 1.5 x VR typical

J

RRM

applied

1060

150

10

A

2

www.vishay.com

MBR20..CTPbF Series

Vishay High Power Products

Schottky Rectifier, 2 x 10 A

ELECTRICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

20 A TJ = 25 °C 0.84

Maximum forward voltage drop V

FM

(1)

20 A 0.72

Maximum instantaneous reverse current I

Threshold voltage V

Forward slope resistance r

Maximum junction capacitance C

Typical series inductance L

RM

F(TO)

(1)

T

= 125 °C 15

J

TJ = TJ maximum

t

VR = 5 VDC (test signal range 100 kHz to 1 MHz) 25 °C 600 pF

T

Measured from top of terminal to mounting plane 8.0 nH

S

TJ = 25 °C

Maximum voltage rate of change dV/dt Rated V

T

= 125 °C

J

Rated DC voltage

R

0.57

0.1

0.354 V

17.6 mΩ

10 000 V/µs

Note

(1)

Pulse width < 300 µs, duty cycle < 2 %

THERMAL - MECHANICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum junction temperature range T

Maximum storage temperature range T

Maximum thermal resistance,
junction to case per leg

Typical thermal resistance,
case to heatsink

J

Stg

DC operation 2.0

R

thJC

R

thCS

Mounting surface, smooth and greased
(Only for TO-220)

Approximate weight

Mounting torque

minimum

maximum 12 (10)

Non-lubricated threads

Marking device Case style TO-220AB MBR2045CT

- 65 to 150

- 65 to 175

0.50

2g

0.07 oz.

6 (5)

kgf · cm

(lbf · in)

V10 A

mA

°C

°C/W

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 94288

2 Revision: 21-Aug-08

MBR20..CTPbF Series

Schottky Rectifier, 2 x 10 A

100

10

1

- Instantaneous Forward Current (A)

F

I

0.40.2 0.6 1.0

0.8 1.4

VFM - Forward Voltage Drop (V)

Fig. 1 - Maximum Forward Voltage Drop Characteristics

(Per Leg)

TJ = 150 °C

= 125 °C

T

J

= 25 °C

T

J

1000

1.61.2 1.8

Vishay High Power Products

100

10

1

0.1

0.01

- Reverse Current (mA)

R

0.001

I

0.0001

0

5152535

Fig. 2 - Typical Values of Reverse Current vs.

TJ = 150 °C

TJ = 125 °C

TJ = 100 °C

TJ = 75 °C

TJ = 50 °C

TJ = 25 °C

4540302010

VR - Reverse Voltage (V)

Reverse Voltage (Per Leg)

- Junction Capacitance (pF)

T

C

100

10

040

VR - Reverse Voltage (V)

Fig. 3 - Typical Junction Capacitance vs. Reverse Voltage (Per Leg)

10

1

0.1

Single pulse

- Thermal Impedance (°C/W)

thJC

Z

0.01

0.00001 0.0001 0.001 0.01 0.1

(thermal resistance)

t1 - Rectangular Pulse Duration (s)

Fig. 4 - Maximum Thermal Impedance Z

20

D = 0.75
D = 0.50
D = 0.33
D = 0.25
D = 0.20

TJ = 25 °C

thJC

5030

Notes:

1. Duty factor D = t

2. Peak TJ = PDM x Z

1

Characteristics (Per Leg)

P

DM

t

1

t

2

1/t2

+ T

thJC

C

10

100

Document Number: 94288 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 21-Aug-08 3
