Vishay 63CPQ100GPBF Data Sheet

TO-247AC

PRODUCT SUMMARY

I

F(AV)

V

R

Schottky Rectifier, 2 x 30 A

FEATURES

1 3

Anode

1

Base

common

cathode

2

2

Common

cathode

2 x 30 A

100 V

Anode

2

• 175 °C TJ operation

• Center tap TO-247 package

• Low forward voltage drop

• High frequency operation

• High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance

• Guard ring for enhanced ruggedness and long term
reliability

• Lead (Pb)-free (“PbF” suffix)

• Designed and qualified for industrial level

DESCRIPTION

The 63CPQ100GPbF center tap Schottky rectifier series has
been optimized for low reverse leakage at high temperature.
The proprietary barrier technology allows for reliable
operation up to 175 °C junction temperature. Typical
applications are in switching power supplies, converters,
freewheeling diodes, and reverse battery protection.

63CPQ100GPbF

Vishay High Power Products

Pb-free

Available

RoHS*

COMPLIANT

MAJOR RATINGS AND CHARACTERISTICS

SYMBOL CHARACTERISTICS VALUES UNITS

I

F(AV)

V

RRM

I

FSM

V

F

T

J

Rectangular waveform 60 A

100 V

tp = 5 µs sine 2200 A

30 Apk, TJ = 125 °C (per leg) 0.64 V

Range - 55 to 175 °C

VOLTAGE RATINGS

PARAMETER SYMBOL 63CPQ100GPbF UNITS

Maximum DC reverse voltage V

Maximum working peak reverse voltage V

R

RWM

100 V

ABSOLUTE MAXIMUM RATINGS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum average
forward current
See fig. 5

Maximum peak one cycle non-repetitive
surge current per leg
See fig. 7

Non-repetitive avalanche energy per leg E

Repetitive avalanche current per leg I

per leg

per device 60

I

F(AV)

I

FSM

AR

50 % duty cycle at TC = 153 °C, rectangular waveform

5 µs sine or 3 µs rect. pulse

10 ms sine or 6 ms rect. pulse 410

TJ = 25 °C, IAS = 1 A, L = 30 mH 15 mJ

AS

Current decaying linearly to zero in 1 µs
Frequency limited by T

maximum VA = 1.5 x VR typical

J

Following any rated load
condition and with rated
V

applied

RRM

30

2200

A

1A

* Pb containing terminations are not RoHS compliant, exemptions may apply

Document Number: 94243 For technical questions, contact: [e-mail]
Revision: 13-Aug-08 1

www.vishay.com

63CPQ100GPbF

Vishay High Power Products

Schottky Rectifier, 2 x 30 A

ELECTRICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

30 A

Maximum forward voltage drop per leg
See fig. 1

V

FM

60 A 0.92

(1)

30 A

60 A 0.76

Maximum reverse leakage current per leg
See fig. 2

I

RM

Threshold voltage V

Forward slope resistance r

Maximum junction capacitance per leg C

Typical series inductance per leg L

F(TO)

TJ = 25 °C

(1)

T

= 125 °C 25

J

TJ = TJ maximum

t

VR = 5 VDC (test signal range 100 kHz to 1 MHz) 25 °C 1300 pF

T

Measured lead to lead 5 mm from package body 7.5 nH

S

Maximum voltage rate of change dV/dt Rated V

T

= 25 °C

J

= 125 °C

T

J

V

= Rated V

R

R

R

0.77

0.64

0.3

0.38 V

5.75 mΩ

10 000 V/µs

Note

(1)

Pulse width < 300 µs, duty cycle < 2 %

THERMAL - MECHANICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum junction and storage
temperature range

Maximum thermal resistance,
junction to case per leg

Maximum thermal resistance,
junction to case per package

Typical thermal resistance,
case to heatsink

Approximate weight

Mounting torque

minimum 6 (5)

maximum 12 (10)

Marking device Case style TO-247AC (JEDEC) 63CPQ100G

T

, T

J

Stg

DC operation
See fig. 4

R

thJC

- 55 to 175 °C

0.8

DC operation 0.4

R

thCS

Mounting surface, smooth and greased 0.25

6g

0.21 oz.

kgf · cm

(lbf · in)

V

mA

°C/W

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 94243

2 Revision: 13-Aug-08

63CPQ100GPbF

1000

100

10

- Instantaneous

F

I

Forward Current (A)

1

0

V

Schottky Rectifier, 2 x 30 A

TJ = 175 °C
T

= 125 °C

J

T

= 25 °C

J

0.3 0.6 0.9 1.2

- Forward Voltage Drop (V)

FM

1.5

- Reverse Current (mA)

R

I

Vishay High Power Products

1000

10

0.1

1

TJ = 175 °C

TJ = 150 °C

TJ = 125 °C

TJ = 100 °C

TJ = 75 °C

TJ = 50 °C

TJ = 25 °C

0

20 40 60

V

- Reverse Voltage (V)

R

80

100

0.01

0.001

Fig. 1 - Maximum Forward Voltage Drop Characteristics Fig. 2 - Typical Values of Reverse Current vs.

Reverse Voltage

10 000

100

1000

- Junction Capacitance (pF)

T

C

100

0

TJ = 25 °C

4020 60 80 100

VR - Reverse Voltage (V)

Fig. 3 - Typical Junction Capacitance vs. Reverse Voltage

1

0.1

D = 0.75

Single pulse

(thermal resistance)

- Thermal Impedance (°C/W)

thJC

Z

0.01

0.00001 0.0001 0.001 0.01 0.1 1

D = 0.50
D = 0.33
D = 0.25
D = 0.20

t1 - Rectangular Pulse Duration (s)

Fig. 4 - Maximum Thermal Impedance Z

120

Notes:

1. Duty factor D = t

2. Peak TJ = PDM x Z

Characteristics

thJC

P

DM

t

1

t

2

1/t2

+ T

thJC

C

100 10

Document Number: 94243 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 13-Aug-08 3

63CPQ100GPbF

Vishay High Power Products

180

170

160

150

Square wave (D = 0.50)

140

80 % rated V

130

120

See note (1)

0

I

F(AV)

Allowable Case Temperature (°C)

applied

R

2010 30 40

- Average Forward Current (A)

Fig. 5 - Maximum Allowable Case Temperature vs.

Average Forward Current

DC

10 000

Schottky Rectifier, 2 x 30 A

30

25

20

15

10

5

Average Power Loss (W)

50

0

0

Fig. 6 - Forward Power Loss Characteristics

D = 0.20
D = 0.25
D = 0.33
D = 0.50
D = 0.75

DC

10

I

- Average Forward Current (A)

F(AV)

RMS limit

5020 30 40

At any rated load condition
and with rated V
following surge

1000

- Non-Repetitive Surge Current (A)

100

FSM

I

10

100 1000

tp - Square Wave Pulse Duration (µs)

Fig. 7 - Maximum Non-Repetitive Surge Current

L

D.U.T.

Current
monitor

IRFP460

= 25 Ω

R

g

RRM

applied

High-speed

switch

Freewheel

diode

40HFL40S02

10 000

V

= 25 V

d

+

Fig. 8 - Unclamped Inductive Test Circuit

Note

(1)

Formula used: TC = TJ - (Pd + Pd
Pd = Forward power loss = I
Pd

= Inverse power loss = VR1 x IR (1 - D); IR at VR1 = 80 % rated V

REV

F(AV)

) x R

REV

x VFM at (I

thJC

;

F(AV)

/D) (see fig. 6);

R

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 94243

4 Revision: 13-Aug-08

63CPQ100GPbF

Schottky Rectifier, 2 x 30 A

ORDERING INFORMATION TABLE

Device code

63 C P Q 100 G PbF

1 - Current rating (60 A)

2 - Circuit configuration:

3 - Package:

4 - Schottky “Q” series

5 - Voltage rating (100 V)

6 - G = Schottky generation

7

-

51324

C = Common cathode

P = TO-247

None = Standard production

PbF = Lead (Pb)-free

Vishay High Power Products

67

Tube standard pack quantity: 25 pieces

LINKS TO RELATED DOCUMENTS

Dimensions http://www.vishay.com/doc?95223

Part marking information http://www.vishay.com/doc?95226

Document Number: 94243 For technical questions, contact: [e-mail]
Revision: 13-Aug-08 5

www.vishay.com

DIMENSIONS in millimeters and inches

0.10 AC

MM

E

E/2

(2)

(3)

(4)

(4)

(2) R/2

B

2 x R

S

D

See view B

2 x e

b4

3 x b

2 x b2

L

C

(5) L1

1

2

3

D

D

A

A2

A

A

A1

C

Ø K BD

MM

A

(6)

Ø P

(Datum B)

FP1

D1 (4)

4

E1

0.01 BD

MM

View A - A

Thermal pad

D2

DDE E

C

C

View B

(b1, b3, b5)

Base metal

c1

(b, b2, b4)

Section C - C, D - D, E - E

(c)

Planting

Lead assignments

Diodes

1. - Anode/open

2. - Cathode

3. - Anode

Outline Dimensions

Vishay Semiconductors

TO-247

SYMBOL

Notes

(1)

Dimensioning and tolerancing per ASME Y14.5M-1994

(2)

Contour of slot optional

(3)

Dimension D and E do not include mold flash. Mold flash shall not exceed 0.127 mm (0.005") per side. These dimensions are measured at
the outermost extremes of the plastic body

(4)

Thermal pad contour optional with dimensions D1 and E1

(5)

Lead finish uncontrolled in L1

(6)

Ø P to have a maximum draft angle of 1.5 to the top of the part with a maximum hole diameter of 3.91 mm (0.154")

(7)

Outline conforms to JEDEC outline TO-247 with exception of dimension c

Document Number: 95223 For technical questions within your region, please contact one of the following: www.vishay.com
Revision: 01-Dec-10 [e-mail]

MILLIMETERS INCHES
MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX.

NOTES SYMBOL

MILLIMETERS INCHES

NOTES

A 4.65 5.31 0.183 0.209 D2 0.51 1.30 0.020 0.051
A1 2.21 2.59 0.087 0.102 E 15.29 15.87 0.602 0.625 3
A2 1.50 2.49 0.059 0.098 E1 13.72 - 0.540 -

b 0.99 1.40 0.039 0.055 e 5.46 BSC 0.215 BSC
b1 0.99 1.35 0.039 0.053 FK 2.54 0.010
b2 1.65 2.39 0.065 0.094 L 14.20 16.10 0.559 0.634
b3 1.65 2.37 0.065 0.094 L1 3.71 4.29 0.146 0.169
b4 2.59 3.43 0.102 0.135 N 7.62 BSC 3
b5 2.59 3.38 0.102 0.133 FP 3.56 3.66 0.14 0.144

c 0.38 0.86 0.015 0.034 FP1 - 6.98 - 0.275
c1 0.38 0.76 0.015 0.030 Q 5.31 5.69 0.209 0.224

D 19.71 20.70 0.776 0.815 3 R 4.52 5.49 1.78 0.216
D1 13.08 - 0.515 - 4 S 5.51 BSC 0.217 BSC

, [e-mail], [e-mail] 1

Legal Disclaimer Notice

Vishay

Disclaimer

ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.

Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,
“Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other
disclosure relating to any product.

Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or
the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all
liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special,
consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular
purpose, non-infringement and merchantability.

Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of typical
requirements that are often placed on Vishay products in generic applications. Such statements are not binding statements
about the suitability of products for a particular application. It is the customer’s responsibility to validate that a particular
product with the properties described in the product specification is suitable for use in a particular application. Parameters
provided in datasheets and/or specifications may vary in different applications and performance may vary over time. All
operating parameters, including typical parameters, must be validated for each customer application by the customer’s
technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase,
including but not limited to the warranty expressed therein.

Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining
applications or for any other application in which the failure of the Vishay product could result in personal injury or death.
Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk and agree
to fully indemnify and hold Vishay and its distributors harmless from and against any and all claims, liabilities, expenses and
damages arising or resulting in connection with such use or sale, including attorneys fees, even if such claim alleges that Vishay
or its distributor was negligent regarding the design or manufacture of the part. Please contact authorized Vishay personnel to
obtain written terms and conditions regarding products designed for such applications.

No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by
any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.

Document Number: 91000 www.vishay.com
Revision: 11-Mar-11 1
