VIRUSKILLER VK-blue User's Manual & Instructions

!"#$%&'()%*+,&-*#&./(#*$*0)/*"+&)+%&

12#*3*4)/*"+&562*78(+/&

9:;<$2(&

&

&

=.5>&?=@A5&B&@C.D>=ED@FC.&

Sales & Design: Radic8 Ltd

Man & Scythe Building 6 - 8 Churchgate Bolton, BL1 1HL, UK

Tel : [phone], E-mail: [e-mail],

www.radic8.com

Manufacturer: INBair Co., Ltd

3F, 15, Beotkkot-ro 12-gil,Geumcheon-gu, Seoul, Korea

Tel: [phone], E-mail: [e-mail],

www.inbair.com

Made in Korea, Designed in England

Table of Contents

Safety Instructions………………………………………1

Operation Instructions…………………………………..4

Key Parts and Components……………………………5

VirusKiller Functions…………………………………….6

Cleaning and Maintenance………..………………….15

Error Messages………………………………………..18

Troubleshooting………………………………………..19

Customer Service……………………………………...21

Specifications………………………………………….22

Limited Warranty Card

Important Safety Instructions

The following instructions are provided to ensure your
safety and to protect the unit from accidental damage.

• Read these instructions – All the safety and

operating instructions should be read before

this product is operated.

• Keep these instructions – The safety and

operating instructions should be retained for

future reference.

• Heed all warnings – All warnings on the

appliance and in the operating instructions

should be adhered to.

• Follow all instructions – All instructions for

use and operation should be followed.

• Warranty – included inside.

1 of 20

Warning – This symbol indicates important
safety instructions that must be followed to avoid
injury.

Caution – This symbol is to bring important
information to your attention to avoid the risk of injury
or damage to the unit.

Prohibited – This symbol indicates a forbidden

action. Adhere to these to reduce the risk of injury or
damage to the unit.

Electrical Safety

• The unit should only be connected to a properly

grounded mains power supply with voltage that
matches that specified.

• To prevent overload, do not

share the same power supply
socket with too many other
electronic components.

• Do not place the power cord

where it could be stepped on
or tripped over.

• Do not place heavy items on

the power cord, they could
damage the wire.

• Do not allow water or moisture to enter the unit or

power adapter.

• Do not use in wet, moist areas

such as bathrooms, steamy
kitchens or near swimming
pools.

• Pull the plug out immediately and seek professional

help if the plug or power cord is damaged, liquid is
spilled onto the unit, if it is accidentally exposed to
moisture or the unit is not working normally.

2 of 20

Operation Safety

• Keep the product away from flammable gases and

liquids, candles and open
flames.

• Do not install near any heat

sources such as radiators,
stoves, or other apparatus that
produce heat.

• Do not attempt to repair or

replace any part of this
equipment unless it is
specifically recommended in
the user guide. All other
services should be referred to a
qualified technician.

• Make sure the power cord is plugged

firmly and completely into the outlet.

• Hold the main plug, not the wires,

when removing from a socket.

• During a thunderstorm switch off the unit and

unplug from the socket.

• Do not handle the unit with wet hands.

• Only clean with a soft, dry cloth. Do not use solvents

or petroleum based fluids.

• Do not place heavy objects on the unit.

• Do not shake, knock or move the product while in

operation, you may damage the internal circuits.

• If a strange smell, noise, or smoke is

emitted, turn off immediately and contact
customer services.

3 of 20

Operation Instructions

• Switch off while cleaning the room

After cleaning, it is important to
properly ventilate the room
before using VirusKiller again.

• Switch off while cooking

Oils released while cooking may
reduce the lifespan of the
sterilizing module. After cooking,
the room should be ventilated to
remove oils. VirusKiller can then
be used to remove the remaining smell.

• Ensure airflow is not restricted

Do not position VirusKiller so
that airflow to and from the unit
is restricted by large items
such as furniture, electronic
items or curtains.

• Position at least 3 metres from the bed

To avoid excessive cooling
caused from sleeping in direct
airflow, we recommend
positioning VirusKiller at least 3
metres away from the bed.

• Maintain proper ventilation – 30 minutes per day

VirusKIller is designed to purify
and sterilize your indoor air, and
will do this very effectively if used
correctly. Good indoor air quality
also requires proper ventilation.
We recommend opening
windows or doors, or operating A/C units, for at least
30 minutes a day.

• Maintain regular servicing and maintenance

4 of 20

Caution

• The appliance is not to be used by children or

persons with reduced physical, sensory or mental
capabilities. This appliance is not a toy. Children
should be supervised at all times.

• Never look directly at a burning ultra-violet light

– this may permanently damage your eyes.
Switch off and unplug before performing
maintenance.

Key Parts and Components

1. Air Inflow

2. Santized and Purified Air Outflow

3. Fan

4. Dual Reactor Module (Left and Right)

5. 8 x UVC Lamps and Multiple Nano Tube Filters

6. Fragrance Pod

7. Pre Filter

8. HEPA Filter

9. Carbon Filter (Left and Right)

5 of 20

Wall Mounting

The Reactor Module

6 of 20

Control Panel and Display

Remote Control

7 of 20

VirusKiller Functions

Manual Operation Mode

When the power button is pressed, the unit emits a
beep sounds and begins to operate. If the product
does not operate, ensure the socket is plugged
securely into a live, properly grounded outlet of the
correct voltage.

8 of 20

· Increasing the Fan Speed

· Fan speed increases when the UP button is
pressed.

FAN 1 Quiet Mode

FAN 2 Normal Mode

FAN 3 High Speed Mode

9 of 20

· Reducing the Fan Speed

· Pressing the DOWN button decreases the

fan speed.

FAN 1 Quiet Mode

FAN 2 Normal Mode

FAN 3 High Speed Mode

10 of 20

Operating the LED Lamp

11 of 20

Setting the Timer

1. Press TIMER button on the remote
controller.

2. Press MODE button on main body.

Press either TIMER or MODE to toggle between the
timer preset options. The unit will automatically
switch off when the programme time has passed.

·

Pr - 3 3 hours preset

Pr - 6 6 hours preset

Pr - 9 9 hours preset

12 of 20

Mode Indicator

Repeatedly pressing the MODE button on either
the unit or the remote control changes the display
in the following order:

0001 Operation time (in hours) of

Sterilizing Module

_27d Current temperature

FAN3 Fan Speed

13 of 20

To Switch the Unit Off

To switch the unit off, press the POWER button
on the unit or on the remote control.
Turn the product off and unplug power cord when
it is not in use for an extended period of time.

14 of 20

Cleaning and Maintenance

Cleaning the Pre-Filter

The plastic pre-filter is reusable. To clean it follow this
procedure:

1. Open front cover G.

2. Remove pre-filter case from unit H and
separate from HEPA filter I.

3. Clean the pre-filter with plain water.

4. Allow to dry completely out of direct sunlight.

5. Replace

Ensure you have removed the HEPA filter

before washing the pre-filter

We recommend you check the pre-filter regularly and
clean it as often as necessary, depending on the levels
of pollution.

15 of 20

Replacing the HEPA Filter

When the display shows ‘FILT’ at 2 minute intervals, it
is time to replace the HEPA filter (2000 hours). After
replacing the HEPA filter I, press and hold the UP
switch J for at least 14 seconds to reset the HEPA
timer to zero.

Changing the Side Carbon Filters

After switching off the power, open side filter door K
and replace carbon filter L, then close the door.

The HEPA and carbon filters are not reusable and
should be replaced.

Depending on the levels of pollution the lifetime of the
HEPA may be longer or shorter than the recommended
2000 hours use time.

Please contact your local customer service center or
distributor to purchase replacement HEPA and carbon
filters.

16 of 20

Changing the Fragrance Filter

The fragrance pod can be used to distribute a
pleasant aroma throughout the room.

Open the white lid on the fragrance pod and place a
Radic8 fragrance filter pad into the pod.

Fragrance Pod

17 of 20

Error Messages

When to Replace the Sterilizing Module

The lifespan of the Sterilizing Module is 8000 hours.
When the unit has been operated for 8000 hours, the
operation time (displayed by pressing MODE) will be a
minus figure, as shown below.

The Sterilizing Module should be replaced when
recommended, otherwise the sterilizing power and the
lifespan of the unit will be reduced.

Circuit overheat error

The below error message is displayed when the circuit
is overheated.
Switch off the unit and contact the customer service
center.

Door Open

If the door is open the unit will not switch on. It will emit
3 rapid descending beeps. Check the magnet
connections in the door are properly aligned with those
on the body.

18 of 20

Troubleshooting

Before you call for service, review this list. It may save
you time and expense. This list includes common
occurrences that are not the result of defect in
workmanship or materials.

· Problem – Product will not turn on.
Possible causes

Is power cord correctly connected to outlet?

Solutions

Put power plug into AC outlet and DC jack again.

Check remote controller?

Change / reinstall batteries correctly according to the
polarity.

Check the outlet

This product should be plugged into a properly
grounded outlet with the correct voltage (as shown on
the back of the unit)

· Problem – Weak wind volume or unusual noise from
the product.

Possible Causes

Check if dust has accumulated in the filter?

Solutions

Filters should be replaced or cleaned at appropriate
time.

· Problem – The air purifying function is not effective.
Possible Causes

Is the air in the room seriously contaminated?

Solutions

Use only after sufficient ventilation, minimum 30
minutes.

Possible Causes

Check if the pre-filter is heavily contaminated.

Solutions

Clean the pre-filter

Possible Causes
Check if the HEPA filter is heavily contaminated.

Solutions

Replace HEPA filter.

19 of 20

Possible Causes

Check the room size compared to the product
specifications.

Solutions

Select the appropriate model of VirusKiller to suit the
space to be covered.

Possible Causes

Check if airflow is restricted?

Solutions

Make sure there is sufficient clearance around the
product and that the air inlet and outlet are not blocked
by furniture, curtains, etc.

· Problem – The unit is emitting a strange smell
Possible causes

Is this a ‘new product’ smell?

Solutions

It may be an antimicrobial smell emitted by the
sterilizing module or filters and will disappear over a
short period of operation (1-2 weeks). It is completely
harmless to humans and animals.

Possible causes

Is the washable pre-filter completely dry?

Solutions

This may be from the pre-filter if replaced before dry.
Remove, wash again, and allow to dry completely
before further operation.

Possible causes

Has the unit been used during or shortly after cooking?

Solutions

Some food odors can permeate into the filter or
sterilizing module. Only switch on the unit after
sufficient ventilation.

Possible causes

Has the unit been used where there are heavy
emissions of smoke or odors?

Solutions

In areas emitting smoke or odors, the performance of
the air purifying function may be affected. Use after
ventilation.

20 of 20

Customer Services

In this manual, you will find a card containing
details of your limited warranty and contact details
for your local customer services center, to whom
all enquiries and warranty claims should be
directed.

All warranties are rendered void and the cost of
repair will be payable by the user in the case of:

1. Damages caused by putting foreign

objects (such as water, soft drink, coffee,
fragrance oils or toy etc.) in or on the unit.

2. Damages caused by transportation or

handling.

3. Damages caused by use of products such

as benzene or thinner.

4. Damages caused by using incorrect power

supply or output voltage.

5. Breakdown or loss of parts caused by

unauthorized disassembling or
modification.

6. Repair or replacement undertaken by

unauthorized persons.

7. Damages caused by non-adherence to the

instructions provided in this user guide,
and as given by the local customer service
center.

8. Damages caused by careless or improper

use.

9. Damages caused by operating the product

in a corrosive or moist environment.

21 of 20

Specifications

The company reserves the right to make changes to
the exterior, design or specifications of the product
without prior notice.

Description

Air purifier

Brand

VIRUSKILLER

Model No

VK-blue

Elec. Power

Check back of unit

Elec. Consumption

95 watt

Net Weight

7.5 Kg

Gross Weight

10.1 Kg

Net Dimension

640 x 380 x165 mm

Box Dimension

680 x 540 x 210 mm

22 of 20
