Programming
BT Scanner
For BT310N
User’s Manual
Ver. 1.0
2
Pairing Process:
1. Press the trigger to activate the scanner.
2. Trigger Scanner about 6 seconds (one long beep and
Blue LED fast flash) to disconnect the scanner from the
paired device to be ready for pairing another device.
3. Reading the setting barcode
Of SPP or HID. (HID is for Manufacture default)
CABLE Online Mode:
The scanner provides another way to transmit data
beside BT mode. Connecting Micro USB cable is to
switch from BT mode to Cable online mode and also in
battery charger.
Memory Mode:
1. Memory Mode setting: Switch BT mode to
Memory Mode
2. Data Upload setting: Transmitting barcode data in
Memory Mode
3. Clear All Saved Data setting: Erase all barcode
data saved in Memory mode
4. To Bluetooth mode setting: Switching from
Memory mode to Bluetooth mode
5. Total Storage quantity: Check the amount of
memory storage
3
BT Mode Selection
Memory Mode
*Bluetooth Mode
*HID
SPP
Unpair
Memory Mode (Data storage)
Data Upload
Clear All Saved Data
To Bluetooth mode
Total Storage quantity
4
Keyboard Language
IOS Screen Keyboard on/off:
USA
Germany
*Czech
Spain
French
Portugal
Italy
UK
Japan
5
Set Sleep Mode
*1 Min
6 Min
12 Min
30 Min
60 Min
Start Configuration((+SETF))
End Configuration((+ENDF))
6
Chap.1 System Information
Set All default((+RETF))
Do not change the settings in
the previous chapters !
S/W Version((+SFUR))
2.1Message Terminator
None((+C9A))
<CR>((+C9C))
TAB((+C9E))
CR+LF((+C9B))
LF((+C9D))
2.2 Character Installation
The preamble and postamble character: You can put 10
ASCII at most in front of the barcode data. When the
installation is “0” that means you don’t need to add the
first and last character. Please find the format as below:
Preamble Character
Barcode
Postamble Character
The process for adding the first and last character to the
barcode:
1. Scan the barcode of “Start Configuration” and “The
Preamble Character Installation”.
2. Check the ASCII table to get the ASCII code of the
first and last character.
Start Configuration((+SETF))
End Configuration((+ENDF))
7
3. Scan the barcode of ASCII in the Appendix.
4. Scan the “End Configuration”.
G1/G2 character Insertion: You can put 10 ASCII at most
in front of the barcode data. When the installation is “0”
that means you don’t need to add the first and last
character.
1. Scan the barcode of the “Start Configuration” and
“G1 Insert Character”.
2. Check the ASCII table to get the ASCII code of the
first and last character.
3. Scan the barcode of ASCII in the Appendix.
4. Scan the “End Configuration”.
5. Repeat the same process to the G2 insertion.
6. Scan the “End Configuration”.
The position of G1/G2 character insertion: To select a
character insert to the barcode. You can’t insert any
character while the installation is “0”
1. Scan the barcode of the “Start Configuration” and
“G1 character insertion position”
2. Check the ASCII table to get the corresponding
ASCII code of the insertion position.
3. Scan the “End Configuration”.
4. Repeat the same process to the G2 character
insertion position.
5. Scan the “End Configuration”.
Code Transmission: If your application needs to transmit
the code (barcode type ID), you have to set “ON” for this
feature and the format is ID + Barcode data.
The Preamble Installation （Default：00）
Appendix A((+E4A))
The Postamble Installation （Default：00）
Appendix A((+E5A))
Start Configuration((+SETF))
End Configuration((+ENDF))
8
G1 Character Insertion （Default：00）
Appendix A((+E6A))
G2 Character Insertion （Default：00）
Appendix A((+E7A))
G1 Character Insertion Position（Default：00）
Appendix A((+E8A))
G2 Character Insertion Position（Default：00）
Appendix A((+E9A))
Code ID Transmission
ON((+EAA))
<OFF>((+EAB))
2.3 Other Installation
Scanning Precision: You can set to scan once or twice
and then transfer the bar code data. The twice will
reduce the error reading.
Bar Reverse Output Installation: This feature can read the
highlight barcode.
Start Configuration((+SETF))
End Configuration((+ENDF))
9
Scanning Verify
<Single>((+EDA))
Multi-verify(Max:2)
((+EDB))
Chap.3 BAR-CODE
INSTALLATION
3.1 UPC-A
Reading
OFF((+F1A))
Code ID (Default：F)
<20H-7EH>((+F2A))
UPC-A convert to EAN-13
<OFF>((+F3A))
Transmit Check Character
OFF((+F4A))
Truncate Leading Zero
<OFF>((+F5A))
<ON>((+F1B))
.
ON((+F3B))
<ON>((+F4B))
ON((+F5B))
Start Configuration((+SETF))
End Configuration((+ENDF))
10
Truncate Leading Digit(Default:00)
<00H-0DH>((+F6A))
Truncate Last Digit(Default:00)
<00H-0DH>((+F7A))
Select Insertion(Default:00)
<00H-02H>((+F9A))
Start Configuration((+SETF))
End Configuration((+ENDF))
11
3.1 UPC-A
Add-On 2/5
<None>((+F8A))
5 digit((+F8C))
AUTO_Enable
((+F8E))
2 digit((+F8B))
2 or 5 digit((+F8D))
Start Configuration((+SETF))
End Configuration((+ENDF))
12
3.2 UPC-E
Reading
OFF((+G1A))
Code ID (Default：G)
<20H-7EH>((+G2A))
UPC-E Convert to UPC-A
<OFF>((+G3A))
Transmit Check Character
OFF((+G4A))
Truncate Leading Zero
<OFF>((+G7A))
<ON>((+G1B))
ON((+G3B))
<ON>((+G4B))
ON((+G7B))
Truncate Leading Digit(Default:00)
<00H-08H>((+G5A))
Truncate Last Digit(Default:00)
<00H-08H>((+G6A))
Select Insertion(Default:00)
<00H-02H>((+G9A))
Start Configuration((+SETF))
End Configuration((+ENDF))
13
3.2 UPC-E
Add-On 2/5
<None>((+G8A))
5digit((+G8C))
AUTO_Enable
((+G8E))
2digit((+G8B))
2 or 5 digit((+G8D))
Start Configuration((+SETF))
End Configuration((+ENDF))
14
3.3 EAN-13
Reading
OFF((+H1A))
Code ID (Default: H)
<20H-7EH>((+H2A))
Transmit Check Character
OFF((+H3A))
<ON>((+H1B))
<ON>((+H3B))
Truncate Leading Digit (Default:00)
<00H-0DH>((+H4A))
Truncate Last Digit (Default:00)
<00H-0DH>((+H5A))
Select Insertion (Default:00)
<00H-02H>((+H8A))
Start Configuration((+SETF))
End Configuration((+ENDF))
15
3.3 EAN-13
Add-On 2/5
<None>((+H6A))
5 Digit((+H6C))
AUTO_Enable
((+H6E))
2 Digit((+H6B))
2or 5 Digit((+H6D))
ISBN/ISSN Convert
<OFF>((+H7A))
ON((+H7B))
Start Configuration((+SETF))
End Configuration((+ENDF))
16
3.4 EAN-8
Reading
OFF((+I1A))
Code ID (Default: I)
<20H-7EH>((+I2A))
Transmit Check Character
OFF((+I3A))
<ON>((+I1B))
<ON>((+I3B))
Truncate Leading Digit (Default:00)
<00H-08H>((+I4A))
Truncate Last Digit (Default:00)
<00H-08H>((+I5A))
Select Insertion (Default:00)
<00H-02H>((+I7A))
Start Configuration((+SETF))
End Configuration((+ENDF))
17
Add-On 2/5
<None>((+I6A))
5 digit((+I6C))
AUTO_Enable
((+I6E))
2 digit((+I6B))
2 or 5 digit((+I6D))
Start Configuration((+SETF))
End Configuration((+ENDF))
18
3.5 Code 39
Reading
OFF((+J1A))
Code ID (Default: J)
(20H-7EH)((+J2A))
Verification
<OFF>((+J3A))
Transmit Check Character
OFF((+J4A))
Min. Length (Default:01)
<01H-50H>((+J6A))
<ON>((+J1B))
ON((+J3B))
<ON>((+J4B))
Max. Length
(Default:50H)
<01H-50H>((+J7A))
Start Configuration((+SETF))
End Configuration((+ENDF))
19
3.5 Code 39
Format
<Standard Code39> ((+J9A))
Trioptic CODE39
((+J9C))
Full ASCII Code39
((+J9B))
Transfer Start / End Character
<OFF>((+JDA))
ON((+JDB))
Code 39 Concatenation
<OFF>((+JFA))
ON((+JFB))
Truncate Leading Digit(Default:00)
<00H-32H>((+JAA))
Truncate Last Digit(Default:00)
<00H-32H>((+JBA))
Select Insertion(Default:00)
<00H-02H>((+JCA))
Start Configuration((+SETF))
End Configuration((+ENDF))
20
3.6 Codabar
Reading
OFF((+K2A))
Code ID (Default: K)
<20H-7EH>((+K2A))
Verification
<OFF>((+K3A))
Transmit Check Character
<OFF>((+K4A))
<ON>((+K1B))
ON((+K3B))
ON((+K4B))
Truncate Leading Digit(Default:00)
<00H-7EH)((+K6A))
Truncate Last Digit(Default:00)
<00H-7EH>((+K7A))
Select Insertion (Default:00)
<00H-02H>((+KCA))
Start Configuration((+SETF))
End Configuration((+ENDF))
21
3.6 Codabar
Start / End Character Type
<ABCD/ABCD>((+K8A))
abcd/tn*e((+K8C))
abcd/abcd((+K8B))
Transmit Start / End
Character
OFF((+K9A))
Min. Length (Default:06)
<01H-50H>((+KAA))
<ON>((+K9B))
Max. Length
(Default:50H)
<01H-50H>((+KBA))
Start Configuration((+SETF))
End Configuration((+ENDF))
22
3.7 Code93
Reading
OFF((+L1A))
Code ID (Default: L)
<20H-7EH>((+L2A))
Verification
OFF((+L3A))
Transmit Check Character
<OFF>((+L4A))
<ON>((+L1B))
<ON>((+L3B))
ON((+L4B))
Select Insertion (Default:00)
<00H-02H>((+L9A))
Truncate Leading Digit (Default:00)
<00H-7EH>((+L7A))
Truncate Last Digit (Default:00)
<00H-7EH>((+L8A))
Min. Length(Default:03)
<01H-50H>((+L5A))
Max.
Length(Default:50H)
<01H-50H>((+L6A))
Start Configuration((+SETF))
End Configuration((+ENDF))
23
3.8 Code 128
Reading
OFF((+M1A))
Code ID (Default: M)
<20H-7EH>((+M2A))
Verification
OFF((+M3A))
Transmit Check Character
<OFF>((+M4A))
<ON>((+M1B))
<ON>((+M3B))
ON((+M4B))
Truncate Leading Digit(Default:00)
<00H-7FH>((+M8A))
Truncate Last Digit(Default:00)
<00H-7FH>((+M9A))
Select Insertion(Default:00)
<00H-02H>((+MCA))
Min. Length(Default:03)
<01H-50H>((+MAA))
Max.
Length(Default:50H)
<01H-50H>((+MBA))
Start Configuration((+SETF))
End Configuration((+ENDF))
24
UCC/EAN128
<OFF>((+M6A))
FNC1 Transmit
<OFF>((+M7A))
FNC2 Concatenation
<OFF>((+M5A))
ON((+M6B))
ON((+M7B))
ON((+M5B))
Application ID transmit
01 & Terminator ((+MDA))
01 & Terminator ((+MDA))
OFF & Terminator
((+MDC))
(01) & Terminator
((+MDB))
Application ID Terminator
<00H-7EH>((+MEA))
Start Configuration((+SETF))
End Configuration((+ENDF))
25
IATA Code
<OFF>((+V1A))
ON((+V1B))
3.9 Interleaved 2 of 5
Reading
OFF((+N1A))
Code ID (Default: N)
<20H-7EH>((+N2A))
Verification
<OFF>((+N3A))
Transmit Check Character
OFF((+N4A))
<ON>((+N1B))
ON((+N3B))
<ON>((+N4B))
Truncate Leading Digit(Default:00)
<00H-7EH>((+N5A))
Truncate Last Digit(Default:00)
<00H-7EH>((+N6A))
Start Configuration((+SETF))
End Configuration((+ENDF))
26
Select Insertion(Default:00)
<00H-02H>((+N9A))
Min. Length(Default:06)
<01H-50H>((+N7A))
Max.
Length(Default:50H)
<01H-50H>((+N8A))
3.10 Industrial 2 of 5
Reading
<OFF>((+O1A))
Code ID (Default: O)
<00H-7EH>((+O2A))
Verification
<OFF>((+O7A))
Transmit Check Character
<OFF>((+O8A))
ON((+O1B))
ON((+O7B))
ON((+O8B))
Truncate Leading Digit(Default:00)
<00H-32H>((+O5A))
Truncate Last Digit(Default:00)
<00H-32H>((+O6A))
Start Configuration((+SETF))
End Configuration((+ENDF))
27
Select Insertion (Default:00)
<00H-02H>((+O9A))
Min. Length (Default:06)
<01H-50H>((+O3A))
Max. Length(Default:50H)
<01H-50H>((+O4A))
3.11 Matrix 2 of 5
Reading
<OFF>((+P1A))
Code ID (Default: P)
<20H-7EH>((+P2A))
Verification
<OFF>((+P3A))
Transmit Check Character
<OFF>((+P4A))
ON((+P1B))
ON((+P3B))
ON ((+P4B))
Truncate Leading Digit(Default:00)
<00H-50H>((+P5A))
Truncate Last Digit(Default:00)
<00H-50H>((+P6A))
Start Configuration((+SETF))
End Configuration((+ENDF))
28
Select Insertion(Default:00)
<00H-02H>((+P9A))
Min. Length(Default:06)
<01H-50H>((+P7A))
Max.
Length(Default:50H)
<01H-50H>((+P8A))
3.12 China Post Code
Reading
<OFF>((+Q1A))
Code ID (Default: Q)
<20H-7EH>((+Q2A))
Verification
<OFF>((+Q3A))
Transmit Check Character
<OFF>((+Q4A))
ON((+Q1B))
ON((+Q3B))
ON((+Q4B))
Truncate Leading Digit(Default:00)
<00H-50H>((+Q5A))
Truncate Last Digit(Default:00)
<00H-50H>((+Q6A))
Start Configuration((+SETF))
End Configuration((+ENDF))
29
Select Insertion(Default:00)
<(00H-02H>((+Q9A))
Min. Length(Default:06)
<01H-50H>((+Q7A))
Max.
Length(Default:50H)
<01H-50H>((+Q8A))
3.13 MSI / Plessey
Reading
<OFF>((+R1A))
Code ID (Default: R)
<20H-7EH>((+R2A))
Verification
<OFF>((+R3A))
MOD 10((+R3B))
Transmit Check Character
OFF((+R4A))
ON((+R1B))
MOD 11/10((+R3D))
MOD 10/10((+R3C))
<ON>((+R4B))
Start Configuration((+SETF))
End Configuration((+ENDF))
30
Truncate Leading Digit (Default:00)
<00H-3CH>((+R5A))
Truncate Last Digit (Default:00)
<00H-3CH>((+R6A))
Select Insertion (Default:00)
<00H-02H>((+R9A))
Start Configuration((+SETF))
End Configuration((+ENDF))
31
3.13 MSI / Plessey
Min. Length (Default:06)
<01H-50H>((+R7A))
Max. Length
(Default:50H)
<01H-50H>((+R8A))
Start Configuration((+SETF))
End Configuration((+ENDF))
32
3.14 CODE32
Reading
<OFF>((+S1A))
Code ID (Default: S)
<20H-7FH>((+S2A))
Verification
<OFF>((+S3A))
Transmit Check Character
<OFF>((+S4A))
ON((+S1B))
ON((+S3B))
ON((+S4B))
Truncate Leading Digit( Default:00)
<00H-0AH>((+S5A))
Truncate Last Digit(Default:00)
<00H-0AH>((+S6A))
Select Insertion (Default:00)
<00-02H>((+S7A))
Transmit "A"
<OFF>((+S8A))
ON((+S8B))
Start Configuration((+SETF))
End Configuration((+ENDF))
33
3.15 Code 11
Reading
<OFF>((+T1A))
Code ID (Default: T )
<20H-7EH>((+T2A))
Verification
<OFF>((+T3A))
Transmit Check Character
<OFF>((+T4A))
ON((+T1B))
ON((+T3B))
ON ((+T4B))
Truncate Leading Digit (Default:00)
<00H-50H>((+T5A))
Truncate Last Digit (Default:00)
<00H-50H>((+T6A))
Select Insertion(Default:00)
<00H-02H>((+T9A))
Min. Length (Default:06)
<01H-50H>((+T7A))
Max. Length (Default:50H)
<01H-50H>((+T8A))
Start Configuration((+SETF))
End Configuration((+ENDF))
34
3.16 GS1 Code (Option)
GS1-14
Reading
OFF ((+U1B))
Code ID (Default: U )
<20H-7EH>((+UUA))
Application ID transmit
OFF ((+UAA))
(01) ((+UAC))
<ON> ((+U1A))
01 ((+UAB))
Symbol ID transmit
OFF((+UDA))
ON ((+UDB))
Transmit Check Character
OFF((+UGA))
<ON> ((+UGB))
GS1-14 To UPC/EAN
<OFF> ((+U4B))
ON ((+U4A))
Start Configuration((+SETF))
End Configuration((+ENDF))
35
GS1- Limited
Reading
<OFF> ((+U2B))
Code ID (Default: V )
<20H-7EH>((+UVA))
Application ID transmit
OFF((+UBA))
(01) ((+UBC))
<ON >((+U2A))
01 ((+UBB))
Symbol ID transmit
OFF((+UEA))
ON ((+UEB))
Transmit Check Character
OFF((+UHA))
<ON >((+UHB))
Start Configuration((+SETF))
End Configuration((+ENDF))
36
GS1- Expanded
Reading
OFF ((+U3B))
Code ID (Default: W)
<20H-7EH>((+UWA))
Application ID transmit
01 & Terminator ((+MDD))
(01) ((+MDB))
<ON >((+U3A))
OFF& Terminator ((+MDC))
01 ((+MDA))
FNC1 Transmit
<OFF>((+M7A))
ON((+M7B))
Application ID Terminator(Default:00)
<01H-7EH>((+MEA))
Symbol ID transmit
<OFF>((+UFA))
ON ((+UFB))
A
APPENDIX A - ASCII CODE
B
APPENDIX B - ASCII Table
0 1 2 3 4 5 6 7 0 NUL
DLE
SP 0 @ P ` p 1
SOH
DC1 ! 1 A Q a q 2 STX
DC2 “ 2 B R b r
3
ETX
DC3 # 3 C S c s
4
EOT
DC4 $ 4 D T d t 5 ENQ
NAK % 5 E U e u
6
ACK
SYN & 6 F V f v
7
BEL
ETB ‘ 7 G W g w
8
BS
CAN ( 8 H X h x
9
HT
EM ) 9 I Y i y A LF
SUB * : J Z j z B VT
ESC + ; K [ k { C FF
FS , < L \ l | D CR
GS - = M ] m } E SO
RS . > N ^ n ~ F SI
US / ? O _ o DEL
C
APPENDIX C
ASCII Tabl (Under Function Off)
*Function OFF
0 1
0
NUL
DLE
1
SOH
DC1
2
STX
DC2
3
ETX
DC3
4
EOT
DC4
5
ENQ
NAK
6
ACK
SYN
7
BEL
ETB
8
BS
CAN
9
HT
EM
A
LF
SUB
B
VT
ESC
C
FF
FS
D
CR
GS
E
SO
RS
F
SI
US
D
APPENDIX D
Function key Table (Under Function on)
Function ON
0 1
0
NULL
CTRL
1
UP
F1
2
DOWN
F2
3
LEFT
F3
4
RIGHT
F4
5
PAGE
UP
F5
6
PAGE
DOWN
F6
7 F7 8 BS
F8
9
TAB
F9
A F10
B
HOME
ESC
C
END
F11
D
ENTER
F12
E
INSERT
ALT
F
DELETE
SHIFT
Loading...
