MINI SKID STEER
V20 MINI SKID
STEER RAIL
PALLET FORK
V20 MINI SKID
STEER WIDE RAIL
PALLET FORK
Adjustable ITA Class II forged tines. Wider rail for better stability and adjustable
ITA Class II forged tines.
36.0”
FRAME WIDTH
1. 3/16" BRICKGUARD & 3/4"
BEVELED RAIL
2. BRICKGUARD FLUSH WITH TINES
TO HELP STABILIZE LOADS
Width: Frame / Overall w/Step (Inches) 36.0 42.0 / 47.0
Tine: Length / Width / Thickness (Inches) 36.0 / 3.0 / 1.19 42.0 / 3.0 / 1.19 36.0 / 3.0 / 1.19 42.0 / 3.0 / 1.19
2200 LB
CAPACITY
Overall Height (Inches) 30.1
Tine Space: Min / Max (Inches) 8.4 / 30.9 8.4 / 37.6
Approximate Weight (Pounds) 245 255 265¹ 275¹
Capacity (Pounds) 2200
Recommended Loader Capacity Less than 1650 pounds
LESS THAN
36”& 42”
TINE LENGTHS
CHOOSE MINI SKID MOUNT:
• TORO®/MINI UNIVERSAL
• BOBCAT®
• ASV®
• Universal skid steer quick tach
mount not available.
MODEL CPF3622 CPF4222 CWPF3622 CWPF4222
LOADER OPERATING CAPACITY
1650 LB
1. 3/16" BRICKGUARD & 3/4"
BEVELED RAIL
2. BRICKGUARD FLUSH WITH TINES
TO HELP STABILIZE LOADS
3. ASV® PALLET FORK INCLUDES
BOLT-ON STEP
¹Bobcat® & ASV® models weigh approximately 5 lbs less.
42.0”
FRAME WIDTH
¹PURCHASE IN GROUPS OF 5 OF ONE MODEL NUMBER FOR NET PRICE.
- Cannot mix tine lengths to get to 5.
¹PURCHASE 10 OR MORE TO HAVE DEALER NAME CUT INTO THE BADGE.
- Able to mix groups of 5 to get to the 10 fork minimum.
See Pallet Fork Program on page 61 for full details.
Eective 06.01.22 - All information subject to change without notice.
|
