BRUSH CUTTERS BRUSH CUTTERS
V40 OPEN FRONT ROTARY BRUSH CUTTER
Available widths 60” & 72”
Cuts up to 3” diameter trees, and exposed blades allow faster cutting for a maintained nish.
2 41 3
Do not operate rotary brush cutter withouta shatterproof cab door on loader.
3.0”
CUT CAPACITY
60” & 72”
CUT WIDTHS
DETAIL UNDER DECK
16-25 GPM
ONE MOTOR OPTION
STANDARD FLOW ONLY
UP TO 220 LB
FLYWHEEL
WEIGHT
UP TO 1310 LB
OVERALL WEIGHT
1. DIRECT DRIVE EATON® MOTOR WITH
RELIEF VALVES
2. HYDRAULIC BRAKING STOPS FLYWHEEL INLESS
THAN 10 SECONDS
MODEL BBV60-O BBV72-O
Cut Width (in.) 60.0 72.0
Overall Width (in.) 66.0 78.0
Overall Height (in.) 21.4
Overall Depth (in.) 71.1 82.1
Deck Height (in.) 7.7
Push Bar Height (in.) 19.7
Minimum Cut Height (in.) 1.9
Cutting Capacity, Diameter (in.) 3.0
Deck Thickness: Top / Side (in.) 0.19/ 0.25*
Recommended Flow Rate (GPM) 16 - 25 StandardFlow
Approximate Weight(lbs) 1090 1310
Recommended LoaderCapacity Greater than 1500 lbs
Eective 11.01.22 - All information subject to change without notice. || virnigmfg.com • [email protected] • 800.648.2408 • 320.818.4040
3. STANDARD MOTOR GUARD & SPINDLEGUARD
4. CIRCULAR FLYWHEEL WITH 3 UPDRAFTBLADES
BOUNCES OFF STUMPS
*Material is Grade 50 Plate (50,000 PSI Minimum Yield Strength).
