Viridian EV User Manual

User Guide for Viridian EV

Charging Stations

Iss 3 - JULY 2015 Page 2 of 8

Thank you for purchasing a Viridian EV Charging station.

This guide is intended to instruct in the proper use of all models of Viridian Charging stations.

Installation of this equipment should only be carried out by a fully qualified person. Viridian EV accepts
no responsibility for damage caused by improperly installed equipment.

For installation instructions see document "Guidance to installers".

Cautions and Dangers

This guide contains several instructions to which the following symbols have been attached. Failure to
comply with instruction could result in:

DANGER Indicates where failure to comply with instructions will cause death or serious

injury.

WARNING Indicates where failure to comply with instructions could lead to death or

serious injury.

CAUTION Indicates where failure to comply with instructions could lead to minor or

moderate injury.

This document is intended to instruct on the use of and general maintenance of all models of Viridian
manufactured charging stations (current model numbers at the time of writing listed below).
Instructions specific to particular models will be highlighted and clearly marked.

M03-T1C-16A-1P
M03-T2C-16A-1P

M07-T1C-32A-1P
M07-T2C-32A-1P
M07-T2S-32A-1P

M22-T2C-32A-3P
M22-T2S-32A-3P

Understanding the model number of your charging station

M07-T2S-32A-1P

Approximate
maximum available
power in kWh
Example: 7kWh

Enclosure Type
Example: Metal

Enclosure

Connector Type
Example: Type 2

Socket or cable
(Socket type 2
only)
Example: Socket

Maximum Available
Current per phase

Example: 32A

Number of phases
Example: Single
Phase

Iss 3 - JULY 2015 Page 3 of 8

WARNING

The charging station is designed for electric vehicle (EV) charging only. It is designed to only allow the
flow of electricity once an EV is connected and correct communication is established. Any tampering of
the Charging station to allow the flow of electricity at any times other that this will present a risk of
electric shock.

CAUTION

The Charging station is covered by a manufacturers parts and labour warranty. Alterations to the
charging station that are not permitted will invalidate this warranty.

Charging Station Features

1. The charging station connects to an EV via the attached vehicle coupler (shown right) or via the

socket (shown left). Models fitted with sockets allow the use of a range of approved
interconnecting cables.

2. Integrated RCBO

3. Status LED

4. Cover strips

5. Identification label

1 2 3 1 4

5

Model
Number

Charging
Current

Serial
Number
