7 Portable ATSC/NTSC TV
PLC7V96
STANDBY
Page 2
Getting Started
PICTURE Menu
AUDIO Menu
TIMER Menu
SETUP Menu
V-CHIP Menu
CHANNEL Menu
10-11
12
12
13
13
14-18
19
20
20
Page 3
Safety Precautions
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO
ALERT THE USER TO THE PRESENCE OF UNINSULATED "DANGEROUS
VOLTAGE" WITHIN THE UNIT'S CABINET THAT MAY BE OF SUFFICIENT
MAGNITUDE TO CONSTITUTE A RISK
OF ELECTRIC SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN
EQUILATERAL TRIANGLE IS
INTENDED TO ALERT THE USER TO
THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE
(SERVICING) INSTRUCTIONS IN THE
MANUAL ACCOMPANYING THE UNIT.
WARNING:
TO PREVENT FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THE UNIT TO RAIN OR MOISTURE.
NEVER ATTEMPT TO OPEN THE CABINET,
DANGEROUS HIGH VOLTAGES ARE PRESENTED
IN THE UNIT. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH
WIDE- BLADE PLUG WITH WIDE SLOT AND
FULLY INSERT.
THE APPARATUS SHALL NOT BE EXPOSED
TO WATER AND NO OBJECTS FILLED WITH
LIQUID SUCH AS VASES SHALL BE PLACED ON THE APPARATUS.
WARNING:
FCC REGULATIONS STATE THAT ANY CHANGE
OR MODIFICATION TO THE EQUIPMENT, NOT
EXPRESSLY APPROVED BY MAKER OR ITS
AUTHORIZED PARTIES, COULD VOID USER'S
AUTHORITY TO OPERATE THIS EQUIPMENT.
ATTENTION
RISQUE DE CHOC ELECTRIQUE!
NE PAS OUVRIR!
WARNING:
THE MAINS PLUG/APPLIANCE COUPLER IS USED
AS THE DISCONNECT DEVICE, THE DISCONNECT
DEVICE SHALL REMAIN READILY OPERABLE.
ALWAYS REMEMBER TO REMOVE THE PLUG
FROM THE MAINS SOCKET BEFORE
DISCONNECTING THE POWER LEAS FROM THE
UNIT. THE APPARATUS SHALL NOT BE EXPOSED
TO DRIPPING OR SPLASHING AND THAT NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED THE APPARATUS NO NAKED
FLAME SOURCES SUCH AS LIGHTED CANDLES
SHOULD BE PLACED ON THE APPARATUS THE
USE OF APPARATUS IN MODERATE CLIMATES
WARNING:
ATTENTION SHOULD BE DRAWN TO THE
ENVIRONMENTAL ASPECTS OF BATTERY
DISPOSAL. DANGER OF EXPLOSION IF BATTERY
IS INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE.
Introduction
2
Page 4
Important Safety Instructions
Introduction
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions
The safety and operating instructions should be
retained for future reference.
3. Heed Warnings
All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions
All operating instructions should be followed.
5. Cleaning
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6. Attachments
Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7. Water and Moisture
Do not use this product near water for example, near
a bathtub, wash bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming pool; and the like.
8. Accessories
Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage
to the product. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer, or
sold with the product. Any mounting of the product
should follow the manufacturer's instructions, and
should use a mounting accessory recommended by
the manufacturer.
9. Portable Cart Warning
A product and cart combination should be moved with
care. Quick stop, excessive force, and uneven
surface may cause the product and car t combination
to overturn.
10. Ventilation
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from overheating, and these
openings must not be blocked or covered. The
openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer's
instructions have been adhered to.
11. Power Sources
This product should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult your product dealer or local power company.
For products intended to operate from battery power
or other sources, refer to the operating instructions.
12. Grounding or Polarization
This product may be equipped with a polarized
alternating current line plug (a plug having one blade
wider than the other). This plug will fit into the power
outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
13. Power Cord Protection
Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point
where they exit from the product.
(Symbol provided by RETAC)
3
Page 5
Important Safety Instructions
Introduction
14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to
the product, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810
of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of
the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antennadischarge
unit, connection to grounding electrodes, and
requirements for the grounding electrode. See figure
below.
15. Lightning
For added protection for this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and
power lines surges.
16. Power Lines
An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep
from touching such power lines or circuits as contact
with them might be fatal.
17. Overloading
Do not overload wall outlets, extension cords, or
integral convenience receptacles, as this can result in a
risk of fire or electric shock.
18. Object and Liquid Entry
Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short-out parts th at could result in a
fire or electric shock. Never spill liquid of any kind on
the product.
19. Servicing
Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.
20. Damage Requiring Service
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A)When the power-supply cord or plug is damaged,
B)If liquid has been spilled, or objects have fallen
into the product,
C)If the product has been exposed to rain or water,
D)If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the product to its normal operation,
E)If the product has been dropped or damaged in
any way.
F)When the product exhibits a distinct change in
performance this indicates a need for service.
21. Replacement Parts
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
22. Safety Check
Upon completion of any service or repairs to this
product, ask the service technician to perform safety
checks to determine that the product is in proper
operating condition.
23. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
24. Heat
The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
4
Page 6
Introduction
Thank you for purchasing this product which has been designed and manufactured
to give you many years of trouble-free service.
About This User Guide
This user guide contains all the information you need to know about how to setup
and watch available free view channels using your Portable ATSC/NTSC TV.
Accessories In the Box
Remove your Portable ATSC/NTSC TV carefully from the box , and remove the
packaging from each part.
You will find the following items:
Portable ATSC/NTSC TV
Remote Control (CR2025 battery included)
User Manual
USB adaptor
Magnetic base antenna
Power adaptor
Look out for this symbol. It indicates useful and important tips.
If the AC/DC adapter is connected while the TV is powered on, it will supply the unit
with power. Note: the battery will always be recharged while the AC/DC adapter is
connected.
Warning: Change or modifications to this unit not expressly by the part responsible for compliance could
void the user 's authority to operate the Equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference will
not occur in a particular installation. If this equipment does cause harmful inter ference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected .
-Consult the dealer or an experienced radio TV technician or help.
Shield cables must be used with this unit to ensure compliance with the Class B FCC limits.
Safety Information
5
Page 7
Safety Information
The apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed the apparatus.
The mains plug is used as the disconnect device, the disconnect device shall remain
readily operable.
Always remember to remove the plug from the mains socket before disconnecting
the power lead from the back of the unit.
Safety is Important
To ensure your safety and the safety of others, please ensure you read the
Safety Instructions before you operate this product.
Keep this information in a safe place for future reference.
Please read all the safety information before use.
Safety Considerations
Position the cables so that they cannot be walked on or pinched by items placed
on or against them.
Do not use the Portable ATSC/NTSC TV in humid or damp conditions.
Do not allow the Portable ATSC/NTSC TV to get wet.
Do not expose the Portable ATSC/NTSC TV to dripping or splashing.
Do not place water filled objects such as vases on top of the Portable ATSC/NTSC TV.
Do not place naked flame sources, such as candles ,on top of the Portable
ATSC/NTSC TV.
Cleaning
ALWAYS unplug the Portable ATSC/NTSC TV before you clean it.
Do not use liquid or aerosol cleaners.
Clean the Portable ATSC/NTSC TV with a soft, damp (not wet) cloth.
Ventilation
The slots and openings on the Portable ATSC/NTSC TV are for ventilation.
Do not cover or block them as it may cause overheating.
NEVER let children push anything into the holes or slots on the case.
Servicing
There are no user serviceable parts in this Portable ATSC/NTSC TV.
When servicing, refer to qualified service personnel.
Consult your dealer if you are ever in doubt about the installation, operation or
safety of this unit.
Battery Disposal
Please ensure batteries are disposed of safely.
Never dispose of batteries in the fire or with household waste.
Check with your local authority for disposal regulations.
6
Page 8
Remote Control
Remote Key Function:
1) POWER To set the TV standby or power on.
2) P.M To switch picture mode.
3) NUMBER KEYS
For directly access the program.
4) RECALL
To access the previously viewed program.
5) MENU:
To display TV menu or to return to the previous menu.
6) EXIT Used to exit menu.
7) TV DISPLAY:
Display/removes the program information.
8) VOL+: To increase sound level.
9) VOL-: To decrease sound level.
10) EPG:
Display/removes all the information of DTV programs.
11) FAV:
Used to access your favourite programs.
12) MUTE: To disable or enable the sound.
13) S.M: To switch sound mode.
14) SLEEP: Set time to turn off the TV.
15) ASPECT:
To change picture aspect.
16) AUDIO:
To switch TV audio channel.
17) SOURCE:
To display or exit TV input source menu.
18) CURSOR: To move within the menu.
19) OK: Confirm selection.
20) CH-:
To access the previous program.
21) CH+:
To access the next program.
22) P.G:
Setting the Parental Control level control.
23) CH.LIST:
Used to display the channel list.
24) CC:
Enable or disable the CC function.
25) Reserved key.
26)PAGE DOWN/PAGE UP:
In EPG mode, use this key to page up/down the EPG
information.
12
13
14
15
16
17
18
19
20
21
22
23
24
25
1
2
3
4
5
6
7
8
9
10
11
EPG
26
7
Page 9
Using the Remote Control
Point the remote control at the remote sensor in order for the player to function correctly.
The remote will function to approximately 21' from the remote sensor at an angle of
approximately 30 each direction.
O
Note: Directing the remote sensor toward any light source, such as direct sunlight,
may cause the unit to malfunction. Do not spill water or put wet items on the remote control.
Never disassemble remote control.
CR2025
2
1
HOW TO REPLACE THE BATTERY
STEP 1: PUSH THE BUTTON TOWARD LEFT;
STEP 2: PULL THE BATTERY LOADER OUT.
Caution:
Incorrect use of batteries may cause them to leak, corrode or explode.
Be sure to place the batteries in the correct direction.
It is dangerous to charge/heat/open or short-circuit the batteries.
Do not leave dead or expired batteries or mix old/new batteries.
When not using the remote control for a long duration of time, remove the batteries.
When operating range becomes reduced, replace all batteries with new, fresh ones.
If leakage from the battery occurs, wipe the battery liquid from the battery
compartment, then replace.
Built-in Rechargeable Battery Management
The capacity of built-in rechargeable Lithium Polymer battery is 1800mAh,
which can provide about 1.5 hours of operation depending on the usage conditions.
This portable TV uses a smart battery management system inside which can support
low battery detection.
1. If the battery voltage falls below a specific value, the unit will enter low battery
mode, displaying a flashing low battery icon in the OSD, indicating the user needs to
recharge the TV immediately.
2. If the AC/DC adapter is connected while the TV is powered on, it will supply the unit
with power. Note: the battery will always be recharged while the AC/DC adapter is
connected.
3. If the TV is kept running on low battery without using AC/DC adapter, the TV will
shut down after a short time to protect the battery from depletion..
BATTERY CAUTION
Do not store or use this portable TV in extremely hot or cold environments. This product
works best in a temperature range from 32 F to 95 F. Storage or operation outside this
temperature range, especially above 95 F cansignificantly and irreparably degrade the
performance of the lithium polymer battery.
Do not store this device in the sun or in a hot car, even in the glove box.
8
Page 10
Front and Rear panel illustration
1. Front View
1
16
CARD READERUSB
1) Antenna input: Connect to an external RF signal.
2) Speaker Left: The left speaker.
3) VOL+: Move around the menu screens or changing the volume in non-menu state.
4) CH+: Move around the menu screens or selecting the channels in non-menu state.
5) VOL-: Move around the menu screens or changing the volume in non-menu state.
6) OK: Confirm a selection within a menu.
7) CH-: Move around the menu screens or selecting the channels in non-menu state.
8) ASPECT: To change picture aspect.
9) MENU:Open the main menu window.
10) EXIT: Exit menu.
11) Speaker Right: The right speaker.
12) REMOTE CONTROL SENSOR: Receive the signal from the remote control
13) STANDBY:To set the portable TV to standby.
14) SOURCE: To select input source.
15) TFT screen: Display the TFT widescreen display.
16) External rod Antenna
2. Right View
2
3
CH+
4
OK
V- V+
5
CH-
6
ASPECT MENU
7
8
9
10
11
12
STANDBY
13
SOURCE
14
15
CHARGE
OFF ON
DC IN 12V
3
1
2
4
DIGITAL
AUDIO IN AUDIO OUT
AUDIO OUT
5
VIDEO IN
7
6
8
1) CHARGE INDICATOR: The system is in charging state when red LED is lighting,
it will turn into green when full charged.
2) DC IN JACK: This is used for AC-DC adaptor input, the voltage range is 12V.
3) POWER SWITCH: This switch used to switch on/off the system, the system will enter fast
charging state if the DC adaptor connected in power off state.
4) EARPHONE JACK: This jack outputs analog audio L/R signal to earphone.
5) DIGITAL AUDIO OUT: This jack outputs analog coaxial audio signal.
6) AUDIO IN JACK: This jack is used for input analog audio L/R signal to system.
7) VIDEO IN JACK: This jack is used for input composite video signal to system.
8) AUDIO OUT JACK: This jack out puts analog audio L/R signal.
AUDIO IN JACK and VIDEO IN JACK should be used at the same time.
AUDIO IN cannot be used for audio-only without an associated video connection
9
Page 11
Getting Started
CHARGE
DC IN 12V
OFF ON
DIGITAL
AUDIO IN AUDIO OUT
AUDIO OUT
VIDEO IN
Switch the button to ON position to
power on the system
Switching on for the First Time
1.Connect the rod antenna to antenna jack on the left side of the unit.
2.Connect the power adaptor to “DC IN 12V” jack on the right side of the unit
3.Switch on the portable LCD TV using the power key on the right side of the unit.
4.Press MENU key and select the rightmost icon-channel menu.
Good
Air
6-1
!
TV Source
Auto Scan
Favorite
Show/Hide
Channel/NO.
Channel Label
5.Use the navigation key to select the TV source item and select Air or CATV.
6.Select the Auto Scan item and press the Right key to start auto searching all the channel
programs.
R F CH
18
Found
2
1
ATV
Digital
1
Press MENU to exit auto scan
7. After completing the Auto Scan, use the channel+/- key or numeric keys
(remote control only) to select the TV programs.
10
Page 12
Getting Started
For good reception, place the rod antenna as near as the window of house, and place
it as far as the screen of the TV.
Don't place the rod antenna near other machine/appliance (such as motor, computer,
switching power, TV, audio power amplifier, speakers... etc), since these machines/
appliances can cause interferences to the antenna.
To conserve power while the TV is not in use, the power switch key on the right side
should be turned to the OFF position.
How to use USB interface
CARD READERUSB
SD, MS, MMC
USB DEVICE
1.Connect USB storage with the USB adapter.
2. Connect USB adapter with the portable LCD TV by the mini USB interface.
3. Press the source key and select the External Storage item.
4. Select the USB icon.
5. Then can select JPG icon or MUSIC icon or MOVIE icon to play the JPG file or Mp3 file or MOVIE
file.
How to use 3 In 1 Card Reader
1. Insert SD or MS or MMC card into the Card Reader interface.
2. Press the source key and select the External Storage item.
3. Select the SD/MS/MMC icon.
4. Then select JPG icon or MUSIC icon or MOVIE icon to play the JPG file or Mp3 file or MOVIE file.
Please refer to page 19 for details of USB and card reader use.
11
Page 13
1. PICTURE MENU
The first item of the MENU is PICTURE MENU.
You can adjust picture effect here, such as contrast, brightness, etc.
Press to select, press to adjust, press MENU to exit.
Picture mode
Brightness
Contrast
Color
Sharpness
Tint
Color Temp.
Standard
Normal
50
50
50
50
50
Note:
If you want to adjust contrast, brightness, color and sharpness , the picture mode must return to
personal status.
2.AUDIO MENU
The second item of the MENU is AUDIO MENU. You can adjust sound here.
Press to select, press to adjust, press MENU to exit.
Sound mode
Bass
Treble
Balance
Prefer Language
Standard
Audio Channel 1
50
50
0
12
Page 14
3.TIMER MENU
The third item of the MENU is TIMER MENU. You can adjust time here.
Press to select, press to adjust, press MENU to exit.
Sleep timer
Time zone
DST
Time Format
Auto Sync
Off
Pacific
Off
24-hour
On
1).SLEEP TIMER: adjust this item , you can set the sleep timer .
4. SETUP MENU
1).The forth item of the MENU is SETUP MENU. You can setup system here.
Press to select, press to adjust, press MENU to exit.
Menu Language
Aspect Mode
Transparency
OSD Time Out
Closed Caption
Restore Default
Software Upgrade
Note:
Restore Default: Reset all the settings to default value.
Software Upgrade: Only use for system software upgrade by USB .
English
Wide
0%
60 se c
13
Page 15
2). Closed Caption: switch close caption mode.
Press button to select Closed Caption ,Press button, the screen will display as follow:
CC Mode
Basic Selection
Advanced Selection
CC On
CC4
Service 3
5. V-CHIP MENU
The fifth item of the MENU is V-CHIP MENU. You can setup here.
Press to select, press to adjust, press MENU to exit.
Parent control: input the password, it will go into menu. Factory default
password is 6666.
Enter password
5.1 .Input the correct password ,the screen will display as follow:
Change password
System Lock
US
Canada
Parental Control
Parental Control
----
On
14
Page 16
1). Change Password: Press button, the screen will display as follow:
Enter Old Password
Enter New Password
Confirm Password
----
1).Enter Old Password: Input the old password.
2).Enter New password: Input the new password.
3).Confirm password: Input the new password again.
5.2 V-CHIP switch:
When the System Lock is ON, the below options can be adjusted.
5.3 US: Press button, the screen will display as follow:
TV
MPAA N/A
1):TV: Press button, the screen will display as follow:
ALL FV V S L D
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
15
Page 17
Content
Rating Content
Suggested age
TV-Y (All children)
TV-Y7(Direct to order children)
TV-G(General audience)
TV-PG(Parental Guidance suggested)
TV-14(Parents strongly cautioned)
TV-MA(Mature audience only)
FV(Fantasy
violence)
X
V (Violence)
X
X
X
S(Sexual
situation)
X
X
X
And use OK key to switch lock/ unlock feature.Parental Control
2).MPAA:switch the movie-rating control level; N/A, G,PG, PG-13,R,NC-17,X.
L
(Adult
language)
X
X
X
D
(Sexually suggestive
dialog)
X
X
Rating
G General audiences, All Ages admitted
Parental Guidance suggested. Some material may not be suitable for children.
PG
PG-13
Age
Parents strongly cautioned. Some material .may be inappropriate for children under 13.
R
Restrict. Under 17 requires accompanying parent or adult guardian(age varies in some jurisdictions)
NC-17
No one 17 and under admitted.
X is an order rating that is unified with NC-17 but may be encoded in the data of order movies.
X
Description
5.4 Canada: Press button, the screen will be displayed as follow:
Canada English
Canada French
E
E
16
Page 18
1): Canadian English: switch the english rating control level:E,C,C8+,G,PG,14+,18+.
Rating
E Exempt: Includes news, sports, documents and other information programming: talk shows, music videos, and variety
programming.
C Children: Intended for younger children under the age of 8 years. Pays careful attention to themes that
heir sense of security and well-being.
C8+ Children over 8 years old: Contains no portrayal of violence as the
nor encourage children to imitate dangerous acts which they may see on the screen .
G General: Considered acceptable for all age groups, Appropriate
Age
physical, verbal or emotional.
PG Parental Guidance: Intended for a general audience, but may not be
because it could contain controversial themes or issues.
14+ Over 14 Years: Could contain themes where violence is one of the
to the development of plot or character. Language usage could be profane and nudity , present within the context of theme.
18+ Adults: Intended for viewers 18 years and older and might contain
development of plot, character or themes, are intended for adult viewing. Could contain graphic language and portrayals
of secretary and nudity.
2).Canadian French: switch the French-rating control level: E, G,8ANS+,13 ANS+,16ANS+,
Description
preferred, acceptable, or only way to resolve conflict;
viewing for the entire family, contains very little violence,
suitable for younger children (under the age of 8)
dominant elements of the storyline But it must be integral
depictions of violence, which while related to the
could threaten t
18ANS+.
Rating
E Exempt programming
G General :All ages and children, contains minimal direct violence,
unrealistic manner .
8ans+ General but inadvisable for young children :May be viewed by a
to children under 8 who cannot distinguish between imaginary and real situations. Recommended for viewing with paren.
Age
13ans+ Over 13 years: Could contain scenes of frequent violent scenes
16ans+ Over 16 years: Could contain frequent violent scenes and violence.
18ans+ Over 18 years: Only for adult viewing. Could contain frequent
Description
but may be integrated into the plot in a humorous or
wide public audience, but could contain scenes disturbing
and in tense violence.
violent scenes and extreme violence.
17
Page 19
6. Channel MENU
The right most icon is Channel MENU. You can adjust TV Channel .
Press to move, press to adjust here.
Good
Air
6-1
!
TV Source
Auto Scan
Favorite
Show/Hide
Channel/NO.
Channel Label
1). TV Source: select Air TV signal or cable TV signal.
2). Auto Scan: press the button to confirm, you will see below menu :
R F CH
18
Found
2
1
ATV
Digital
1
Press MENU to exit auto scan
3). Favorite: Press button to choose/delete the favorite channel .
4). Show/Hide: Press button to display or hide currently channel.
5). Channel NO . :Display the currently channel number.
6). Channel lable: Press button to edit currently channel name.
7). DTV signal: Display DTV signal intension. It can't be selected and adjusted.
18
Page 20
External Storage MENU
Please use the CURSOR key and OK key to operation.
1. Top Menu 2. Navigation Menu
3. Select Menu
T
460x689
4. Play Menu
Title size:553KB
1: As loon as love .mp3
2: Angel.mp3
03:12/05:20
24
Play Control Bar:
Fast backward
Previous
Play/Pause
/
Stop
Fast Forward
Next
Normal play
Shuffle play
Volume level
Repeat all
Repeat one
ZOOM(only for JPG file)
Six window navigation
(only for JPG file)
T JPG play interval time
To use the button on front panel to adjust volume,please select the Play Control Bar and
select icon and press OK key, then press V+/V- key for volume control.
19
Page 21
Service & Support
Problem
No signal found
No picture or sound
Encrypted channel message
No response from remote control
Square blocks in picture or picture
freezes
Specifications
Video Signal System
Display Device
Receiving Channel
Screen Size
Screen pixels
Audio output
Power Voltage
Power consumption
Size
Weight
Probable cause
Aerial is disconnected
Aerial is damaged/misaligned
Out of digital signal area
Under standby mode
It is a pay per view channel
Remote control is not aimed correctly
Front panel obstructed
Remote control batteries inserted incorrectly
Remote control batteries exhausted
Aerial may not be compatable
Aerial is damaged/misaligned
ATSC/NTSC
Color TFT-LCD
Air: 2-69 Cable: 2-135
7 inches
1440x234 dot
2CH
DC IN 12V
15W
220X130X31mm
0.65kg
What to do
Check aerial lead
Check aerial
Check with dealer
Press the POWER button
Select an alternative channel
Aim remote control at front panel
Check for obstructions
Check batteries are inserted correctly
Replace remote control batteries
Check with dealer
Check aerial
Specifications are subject to change without notice.
20
Page 22
Loading...
