Page 1
A PROUD HERITAGE OF EXPERIENCE & QUALITY
Beverage/Wine Cooler
OWNER’S MANUAL
VT-38
Page 2
Page 3
Your Beverage/Wine Cooler
This unit can be used for Storage and/or Service. The unit has a glass
door and soft interior light that you can leave on to elegantly display your
wines or beverages.
Serving Wines
Storing wines at the proper temperature is important. To preserve them
as long as possible wine should be stored at approximately 55°F. The
chart below suggests the optimal serving temperature for the different
styles of wine.
°C °F Wine Style
19 66 Armagnac, Brandy, Cognac
18 64.5 Full Bodied Red wines, Shiraz
17 62 Tawny Port
15 59 Medium Bodied Red Wines
14 57 Amontillado Sherry
13 55.5 Light Bodied Red Wines
12 53.5 Full Bodied White Wines
11 52 Medium Bodied White Wines
10 50 Rosé, Light Bodied White Wines
9 48 Vintage Sparkling
8 53.5 Fino Sherry
7 44.5 Non Vintage Sparkling
17621 South Susana Road, Rancho Dominguez, California 90221
3
3
Page 4
General Operating Instructions
Remove all external and internal packaging from your cooler. Be sure that
all parts have been included before discarding any packaging materials.
You may want to keep the box and packing materials for use at a later
date.
Upon receipt and inspection of unit, the supply cord must be replaced if it
is damaged. Contact our customer service at 1-800-777-8466 or
[email protected].
• Let the unit rest, UNPLUGGED for 24 hours once you have it placed
in your home.
• Please fully read the instruction manual.
Please read and follow all safety rules
and operating instructions before using.
WWW.VINOTEMP.COM
Page 5
TABLE OF CONTENTS
Parts And Specifications ............................................. 6
Important Safety Instructions ..................................... 7
Cord Instructions ...................................................... 8
Cooler Installation .....................................................8
Operating Instructions ............................................... 9
Temperature Control.................................................. 9
Rack Removal / Installation ...................................... 10
Cleaning And Care................................................... 11
Moving Your Cooler.................................................. 11
Troubleshooting ...................................................... 12
Terms Of Sale And Warranty..................................... 13
17621 South Susana Road, Rancho Dominguez, California 90221
5
5
Page 6
PARTS AND SPECIFICATIONS
1. Double-pane window
2. Grill
3. Adjustable leveling legs
4. Shelf
5. Cabinet
6. Control Panel
7. LED Indicator
8. Temperature Adjustment
9. Light Switch
Type 2 Temp.
Item Number VT-38
Dimension (HxWxD) 34.3"×23.9"×22.6"
Weight 153.9 Lbs
Power Consumption 2.1 kW.h/24h
Cooling System R134a
Temperature Range (for Right Side) 48～65°F
Temperature Range (for Left Side) 40～65°F
Rated Voltage 115V
Rated Frequency 60Hz
Input Power 150W
WWW.VINOTEMP.COM
Page 7
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should be followed
to reduce the risk of fire, electric shock, and personal injury.
1. Use this appliance only as described in this manual. Other users
are not recommended and may cause fire, electric shock or injury.
2. This product is intended for household use.
3. To protect against electric shock, do not immerse unit, plug or
cord in water or other liquids. Avoid locating the unit in moist
areas.
4. Keep away from children.
5. Unplug from the outlet when not in use, when moving from one
location to another, or before cleaning.
6. To disconnect the appliance, grip the plug and pull it from the wall
outlet. Never pull by the cord.
7. Do not operate the appliance in the presence of explosive and/or
flammable fumes.
8. Do not place the appliance or any of its parts near an open flame,
cooking or other heating appliance.
9. Do not operate the appliance with a damaged cord or plug. If the
product malfunctions, or if it is dropped or damaged in any
manner, do not use.
10. The use of attachments is not recommended and may be
hazardous.
11. Do not operate if the housing is removed or damaged.
12. A loose fit plug may cause overheating and a distortion of the plug.
Contact a qualified electrician to replace loose or worn outlet.
13. This appliance is designed to be built-in (fully recessed) or free
standing.
14. This cooler is intended for use in a controlled ambient location
such that the ambient temperature does not exceed 90°F (32°C)
and is not below 60°F (16°C).
15. Locate the unit away from direct sunlight and sources of heat
(stove, heater, radiator, etc.). Direct sunlight may affect/alter the
outside color of the appliance.
WARNING: To reduce the risk of fire, electric shock or personal injury,
unplug or disconnect the appliance from the power supply before
servicing.
WARNING: Risk of child entrapment. Before you throw away your old
cooler, take off the door and leave the shelves in place so that children
may not easily climb inside.
17621 South Susana Road, Rancho Dominguez, California 90221
7
7
Page 8
CORD INSTRUCTIONS
For your protection, this unit is equipped with
a 3-conductor cord set that has a molded 3prong grounding-type plug, and should be
used in combination with a properly
connected grounding-type outlet as shown in
figure A.
It is not recommended to use this cooler with
an extension cord or power board. Please
ensure that the appliance is plugged directly
into the electrical outlet.
COOLER INSTALLATION
1. This cooler is designed to be built-in (fully recessed) or free standing.
2. Remove all exterior and interior packaging.
3. Place your cooler on a flat surface that is strong enough to support
the unit when fully loaded.
4. Do not place the unit in a moist place or display in direct sunlight.
5. Do not place heavy objects on top of the unit.
6. Do not place the unit next to a major appliance that emits large
amounts of heat, such as a dishwasher, microwave, oven, etc.
7. Unit is not designed for installation in a garage or basement.
8. Before connecting the appliance to the power source, let it stand
upright for approximately 24 hours. This will reduce the possibility of
a malfunction in the cooling system due to handing during
transportation.
9. Clean the interior surface with lukewarm water using a soft cloth
before first use. Be sure to wipe dry.
10. Do not plug unit into the same outlet as a refrigerator or microwave.
WWW.VINOTEMP.COM
Page 9
OPERATING INSTRUCTIONS
o Plug the power cord into a standard electrical outlet.
o Gently place/slide the racks in the cooler.
o Determine the best temperature setting to use.
o Place bottles inside the cooler.
o Limit the frequency of opening the door to conserve energy and
maintain proper storage temperature.
Important: When using the cooler for the first time, allow at least 24
hours for the internal temperature to adjust properly. Make sure there are
at least 3 to 5 bottles in the unit.
TEMPERATURE CONTROL
Important note: In order to operate efficiently, unit should be in
an environment with an ambient temperature of less than 90°F
(32°C).
Temperature Presets:
For your convenience, the cooler is programmed at storing temperat ure.
The temperature zone for the right side pre-set by the manufacturer is
o
54
F (12oC). The temperature zone for the left side pre-set by the
manufacturer is 45
Setting the temperature control (manually):
o
F (7oC).
You can manually adjust the temperature. Simply press the
the control panel to decrease the temperature and the
button on
button to
increase the temperature inside the cooler in 1° increments. The
temperature zone for the right side ranges from 48
The temperature zone on the left side ranges from 40
o
18
C). The variance between compartments can be no more than 18oF
o
(10
C).
o
F to 65oF (9oC -18oC).
o
F to 65oF (4oC -
When the cabinet temperature is too low the LED will display “LL”. When
the temperature is too high it will display “HH”. The “ER” display shows
when there has been a power disruption.
Both sides of this unit can store wine or beverages, but the left side can
be set colder than the right side.
17621 South Susana Road, Rancho Dominguez, California 90221
9
9
Page 10
RACK REMOVAL / INSTALLATION
To prevent damaging the door gasket, make sure to have the door
all the way opened when pulling shelves out of the rail
compartment.
1. Remove any bottles stored on the rack.
2. Grasp the rack, and gently pull it up, then take it out.
3. To reinstall, push the racks into track rails until it completely stops.
(See figure 1)
NOTE: Shelves are interchangeable, to store wine or beverage.
WWW.VINOTEMP.COM
Page 11
CLEANING AND CARE
• Always unplug the cooler before cleaning.
• Do not use benzene, scrubbing brushes or chemical cleaners as these
will damage the unit.
• Use only a mild, nonabrasive cleanser to clean the exterior of the
cabinet.
• Clean the stainless steel door and handle by wiping with a warm water
and baking soda solution. The solution should be about 2 tablespoons
of baking soda to a quart of water.
• Wash the racks with a mild detergent solution.
• Always dry all the parts with a clean dry cloth before plugging the
cooler back into the receptacle.
MOVING YOUR COOLER
• Always unplug the beverage/wine cooler before moving.
• Always remove all beverages before moving the cooler.
• Securely tape down all loose items (shelves) inside your appliance.
• Turn the levelling legs up to the base to avoid damage.
• Tape the doors shut.
• Be sure the cooler stays in the upright position during transportation
• Protect the outside of appliance with a blanket or similar item as
needed.
17621 South Susana Road, Rancho Dominguez, California 90221
11
11
Page 12
TROUBLESHOOTING
You can solve many common cooler problems easily, saving you the cost
of a possible service call. Try the suggestion below to see if you can solve
the problem before contacting Vinotemp at [email protected].
SYMPTOM POSSIBLE CAUSE
Vibrations • Check to make sure the cooler is on a level surface.
• The cooler is not on a level surface.
Door will not
close properly.
Fan is always
running.
Unit does not
operate—does
not have power
Power is ON but
the unit will not
cool.
• The racks are out of position.
• A bottle in the cooler is too long.
• The door gasket is dirty.
• This is simply a function of the cooling system. The lower
the setting, the more the fan will run. If the room is
warmer than 90°F (32°C), it will run more.
• The unit has been designed to run continuously when
operating at the lower temperatures.
• Check that unit is plugged into the wall socket.
• Make sure the wall socket has power. If outlet is controlled
by a wall switch, make sure switch is set to on. Test wall
socket functionality by testing another electrical appliance
in the power socket.
• Make sure there are at least 3 to 5 bottles in the unit.
When using the unit for the first time, it can take up to 24
hours to reach the desired temperature.
• Make sure the cooling vents are not obstructed.
• The room may be too hot. If the ambient room
temperature is above 90°F (32°C), the unit can have
difficulty chilling adequately and will not get below 51°F
(11°C). Humidity does not affect the cooling ability of the
unit.
• To achieve accurate temperature control, the unit should
not be used or operated in any of the following locations:
o In a sunny place
o In a room with poor air circulation such as a garage near
another heat-producing appliance such as a dishwasher,
oven or refrigerator.
o With an outlet shared with a refrigerator, as the
refrigerator will drain power from the unit.
o In a cabinet or closet.
WWW.VINOTEMP.COM
Page 13
TERMS OF SALE AND WARRANTY
Vinotemp International (“Seller”) and the p erson or entity that acquires these goods from Seller (“Purchas er”)
hereby fully agree to the following terms an d conditions of the sa le: Shipping fees a re the responsib ility of the
Purchaser whether freight prepaid or freigh t collect. Seller assumes no respon sibility for the goods sold to the
Purchaser once the goods have left the Se ller’s premises, including, but not limited to, late delivery by the
moving carrier, or for events caused by any difficulty carrier incurs in attempting to fit the goods into the
Purchaser’s place of business or re sidence due to the size of the goods or otherwise. Pu rchaser assumes all
responsibility for delivery, payment of freight, access, measurement, installation, hook-up, wiring, moving and
storage of the goods. The transportation of all goods is subject to the terms and condit ions which the moving
carrier imposes on Purchaser including, but not limited to, additional charges imposed per flight of stairs,
and/or additional charges resulting from the carrier’s inability to safely and/or adequately use the building
elevator to lift the goods to an upper floor. Any claim for damages incurred du ring shipment by the carrier of
the goods are insured and handled directly with the carrier. Any damage s due to manufacture defects will be
handled directly with Vinotemp International, subject to the limite d warranty.
All sales are final, and unless aut horized in writing by the Seller, Pu rchaser may not return the goods, un der
any circumstance. If Purchaser re fuses to a ccept the goo ds, under any c ircumsta nce, the Pu rcha ser is liab le fo r
the return and cost of freight both ways, a nd if Seller does take back the goods, there will be a restocking
charge that is 35% of the purchase price of the goods. Purchaser must notify Se ller of non-conforming goods
within four days of delivery, after which time all goods are deemed accepted.
If Purchaser tenders payment with a check that has insufficient funds (NSF ), or stops payment on a check or
credit card for any reason, Purchaser agrees to pay for all costs associated with the Seller’s connection or
litigation of such a claim, including without limitation ext ra damages, court costs and attorneys’ fees. Finance
charges begin the date of invoice. Colle ction fees plus NSF fe e of 50$ will be added to your invoice, which yo u
agree to promptly pay. Title to the goods does not pass until paym ent is received in full by Seller and Seller
retains a security interest in the goods until they are paid for in full.
LIMITED WARRANTY: Seller warrants that the goods will be free of defects in materials and workmanship as
follows: Metal cabinet wine, beverage, refri gerator and freezer units: parts and labor for cooling system and
cabinetry for a period of 12 (twelve) months from date of sale, removal and re-installation of unit is not
included in warranty. For a scratch and dent or refurb ished unit, warran ty is 3 months from your dated invoice
(parts for function only, not cosmetic). There is no warranty on parts purchased separately. Purchaser’s
exclusive remedy is limited, at Seller’s option; to repair or replace defective part[s] with either new or factory
reconditioned part[s]. Purchaser is responsible fo r shipping the unit pre-paid to designated facility and Seller
will pay return shipping charges in the continen tal United States for items repaired under war ranty within 12
months from date of sale. Improper place ment of the unit will void the warranty. T his limited warranty does
not cover damage due to such things as accident, misuse, abuse, mishandling, neglect, acts of God, fires,
earthquakes, floods, high winds, government, war, riot or labor trouble, strikes, lockouts, delay of carrier,
unauthorized repair, or any othe r cause beyond the control of the Seller, whether similar or dissim ilar to the
foregoing. Seller is not responsible for any dam ages caused to Seller’s property resulting from th e good. This
limited warranty applies only inside the Continental US. (Alaska, Puerto Rico and Hawaii are not warranted).
Purchaser understands and a cknowledges that th e goods sold here are wine cellars and/or othe r similar units
which house beverages. Purchaser a ssumes all risk of using these units, including risk of spoilage, h umidity
variations, temperature variations , leaks, f ire, wate r damage , mold, m ildew, d ryness and s imilar and a ny other
perils that might occur.
Seller is not responsible for incidenta l or consequential damages, and there are no warranties, ex pressed or
implied, which extend beyond the Limited Warranty described above. The implied warranties of
merchantability and of fitness for a particular purpos e are hereby expressly disclaimed. Some states do not
allow the exclusion of incidental or consequential damages, or a waiver of the implied warranties of fitn ess
and/or merchantability, so the a bove limitations may not apply to you . This warranty gives you spec ific legal
rights and you may also have other rights which vary from state to state.
In the event of any dispute between Seller and Purchaser arising out of or relating to these terms and
conditions or to the goods sold generally, P urchase r must first f ile a written claim w ith Selle r within te n days of
the occurrence giving rise to the claim and wait an additional thir ty days for a response before initiating any
legal action. The sale and all terms are subject to California law. Any legal proceeding arising out of or
relating to these terms and condition s or to the goods so ld generally sha ll be brought solely a nd exclusively in
the County of Los Angeles. In no event may Pu rchase r init iate any legal proc eeding mo re than s ix month s after
the occurrence of the event giving rise to the dispute.
The above terms and conditions are the only ones governing this transaction and Seller makes no oral
representations of any kind. These Terms and Conditions can only be modified in writing, signed by both
Purchaser and Seller. 07/08
17621 South Susana Road, Rancho Dominguez, California 90221
13
13
Page 14
SERVICE & IMPORTANT NOTICE
Upon receipt and inspection of unit, the supply cord must be replaced if it
is damaged. Contact our customer service at 1-800-777-8466 or
[email protected].
The manufacturer has a policy of continuous improvement on its products
and reserves the right to change materials and specifications without
notice.
WARNING
Please do not place the unit within reach of children.
For adult use only.
Contact [email protected] with any questions or visit:
www.vinotemp.com
WWW.VINOTEMP.COM
Page 15
17621 South Susana Road, Rancho Dominguez, California 90221
info@vinotemp.com
15
15
Page 16
17621 S. Susana Road
Rancho Dominguez, CA 90221
www.vinotemp.com
Vinotemp is a registered trademark of Vinotemp International. All products, features, and services
are subject to change without notice. We cannot guarantee the accuracy of the contents of this
document. We disclaim liability for errors, omissions, or future changes.
© 2008 Vinotemp International. All rights reserved.
WWW.VINOTEMP.COM
Loading...
