Vinotemp VT-32BCSB User Manual

B e v e r a g e C o o l e r

A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y

V T - 3 2 B C S B

O W N E R ’ S M A N U A L

W W W . V I N O T E M P . C O M

2

Y o u r

Y o u r B e v e r a g e

Y o u r Y o u r

B e v e r a g e C

B e v e r a g eB e v e r a g e

C o o l e r

C C

o o l e r

o o l e ro o l e r

This unit can be used for Storage and/or Service. The unit has a glass
door and soft interior light that you can leave on to elegantly display your
beverage.

General Operating Instructions

Remove all external and internal packaging from your beverage cooler. Be
sure that all parts have been included before discarding any packaging
materials. You may want to keep the box and packing materials for use at
a later date.

Upon receipt and inspection of unit, the power cord must be replaced if it
is damaged. Contact our customer service at 1-800-777-8466 or
[e-mail].

• Let the unit rest UNPLUGGED for 24 hours once you have it placed
in your home.

• Please fully read the instruction manual.

• Save these instructions.

Please read and follow all safety rules

and operating instructions before using.

W W W . V I N O T E M P . C O M

S N 3 2 B C H D 1 7 V T - S 1

Table of Contents

PARTS AND SPECIFICATIONS ...................................................... 4

IMPORTANT SAFETY INSTRUCTIONS............................................. 5

CORD INSTRUCTIONS ................................................................ 6

BEVERAGE COOLER INSTALLATION .............................................. 6

TEMPERATURE CONTROL ............................................................ 7

REVERSAL OF DOOR SWING ....................................................... 8

CLEANING AND CARE................................................................. 9

MOVING YOUR BEVERAGE COOLER .............................................. 9

TROUBLESHOOTING .................................................................10

TERMS OF SALE AND WARRANTY ................................................11

SERVICE & IMPORTANT NOTICE..................................................12

1 7 6 3 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1

S N 3 2 B C H D 1 7 V T - S 1

i n f o @ v i n o t e m p . c o m

3

4

PARTS AND SPECIFICATIONS

1. Glass Door

2. Grill

3. Adjustable Leveling Legs

4. Shelf

5. Cabinet

6. PVC Control Panel

7. LED Temperature Indicator

8. Light Switch

9. Temperature Adjustment Button

Item Number VT-32BCSB

Dimension (HxWxD) without handle 34.4"×15.0"×22.7"

Weight 74 Lbs
Power Consumption 1.8 kW.h/24h
Cooling System R134a

Ambient Temp. Range 60～90°F

Temperature Range 40～65°F

Rated Voltage 115V
Rated Frequency 60Hz
Input Power 120W

W W W . V I N O T E M P . C O M

S N 3 2 B C H D 1 7 V T - S 1
