Page 1
Standard Features & Accessories
All models include
• Hidden touchpad electronic controls
with digital temperature readout
o
Inside temperature can be adjusted
from 32 – 45ºF
o
TruProtect™ system signals if door is
left open or if temperature is out of
set range
o
Sabbath mode disables audible
tones, LED display and lights
o
Temperature can be displayed in
either Fahrenheit or Celsius
• Capacity—5.8 cu. ft. (164.1 L)
• Full-extension drawer glides
• Vertical storage of wine bottles or twoliter drink bottles in bottom drawer
• Automatic cycle defrost
• Interior LED lighting
• Install as undercounter or freestanding
unit
Model Options
REFRIGERATION
Undercounter/Freestandin g
24" W. Refrigerated Drawer
VURD144D
Professional
FINISH DETAILS FOR VURD MODEL
• Solid door—Stainless Steel (SS)
• Finish code designates drawer fronts.
Stainless steel handle with chromeplated brackets, black exterior
cabinet, and stainless steel interior.
DURD144D
Designer
FINISH DETAILS FOR DURD MODEL
• Solid door—Stainless Steel (SS)
• Finish code designates drawer fronts.
Stainless steel handle with chromeplated brackets, black exterior cabinet,
and stainless steel interior.
DFRD144D
Custom Front
FINISH DETAILS FOR DFRI MODEL
• Handle not included—opt for custom
handle, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• Accepts 3/4” -thick custom wood panel
• See Custom Panels section for more
information and additional
specifications.
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C OM • 1 - 8 8 8 - V I K I N G 1
R E L E A S E D 6 / 1 0 / 0 8
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
Page 2
REFRIGERATION
3
0
-
3
/
4
”
(
7
8
.
1 c
m
)
22
”
(
5
5
.
9
c
m
)
24
-
3
/
8
”
(
6
1
.
9
cm
)
26
-
7
/
8
”
(
6
8
.
3
cm
)
2
3
-
7/
8
”
(
6
0
.
6
c
m
)
3
4
-
1
/
4
”
(
8
7
.
0
cm
)
m
in
.
t
o
35
”
(
8
8
.
9
c
m
)
m
a
x
.
3
0
-
3/
4
”
(
7
8
.
1 c
m
)
22”
(
5
5
.
9
cm
)
2
3
-
7
/
8”
(
6
0
.
6
cm
)
3
4
-
1
/
4
”
(
8
7
.
0
c
m
)
m
i
n
.
t
o
3
5
”
(
8
8
.
9
c
m
)
m
a
x
.
2
4
-
3
/
8
”
(
6
1
.9
c
m
)
2
4
-
3
/
1
6”
(
6
1
.
4
c
m
)
2
5-
3
/
8
”
(
6
4
.
5
c
m
)
V
a
r
i
e
s
Unde rcounter/Freestanding
24" W. Refrigerated Drawer
Please see
!
Installation Notes &
Accessories
for important
information,
including pan sets
and dividers.
Dimensions & Specifications
PRODUCT DIMENSIONS
VURD144D
Professional
DURD144D
Designer
DFRD144D
Custom Front
See Custom Panels for more
information and additional
specifications.
Overall width 23-7/8" (60.6 cm)
Overall height 34-1/4” (87.0 cm) min. to 35” (88.9 cm) max.
Overall depth (from rear)
To front edge of lower vent 22” (55.9 cm)
To front edge of door 24-3/8” (61.9 cm) 24-3/8” (61.9 cm) Varies
To front edge of handle 26-7/8” (68.3 cm) 25-3/8” (64.5 cm)
With drawer fully extended 47-1/4” (120.0 cm)
Approx. ship wt. 180 lbs. (81.8 kg)
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
PROFESSIONAL DESIGNER/
CUSTOM FRONT
VURD144D DURD144D DFRD144D
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
R E L E A S E D 6 / 1 0 / 0 8
Page 3
47-1/4” (120.0 cm)
22” (55.9 cm)
24-3/8” (61.9 cm)
25-3/8” ( 64.5 cm)
22” (55.9 cm)
24-3/8” (61.9 cm)
26-7/8” (68.3 cm)
47-1/4” (120.0 cm)
Dimensions & Specifications
DRAWER EXTENSION
REFRIGERATION
Unde rcounter/Freestanding
24" W. Refrigerated Drawer
VURD144D
Professional
PROFESSIONAL
DURD144D
Designer
DFRD144D
Custom Front
See Custom Panels section for
more information and additional
specifications.
DESIGNER
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E L E A S E D 6 / 1 0 / 0 8
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
Page 4
REFRIGERATION
24” (61.0 cm)*
34-1/2” (87.6 cm) min.
35-1/8” (89.2 cm) max.
2
4
”
(
6
1
.
0
c
m
)
Unde rcounter/Freestanding
24" W. Refrigerated Drawer
UTILITY
REQU IR EMENT S
GAS
Not applicable
ELECTRICAL
• Three-wire cord
with grounded
three-prong plug
attached to
product
• 115 VAC/60 Hz;
15 amp dedicated
circuit
• Maximum amp
usage—3.3
Installation Requirements
ACCESS REQUIREMENTS
VURD144D
Professional
DURD144D
Designer
DFRD144D
Custom Front
See Custom Panels section for
more information and additional
specifications.
PLUMBING
Not applicable
*Optional: Cutout for electrical outlet can be placed in adjacent cabinetry.
Cutout width 24” (61.0 cm)*
Cutout height 34-1/2” (87.6 cm) min. to 35-1/8” (89.2 cm) max.
Cutout depth 24” (61.0 cm)
All models
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E L E A S E D 6 / 1 0 / 0 8
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
Page 5
REFRIGERATION
Unde rcounter/Freestanding
24" W. Refrigerated Drawer
Installation Notes & Accessories
!
Pan Set
•
Stainless Steel (SS)
•
Four commercial restaurant-style pans with clear lids
o
wo 6”D. x 6-15/16”L. x 6-3/8”W.—2.3 qt. (2.2 lit.) capacity
T
o
One 6”D. x 12-13/16”L. x 6-15/16”W.—5.8 qt. (5.5 lit.) capacity
o
One 8”D. x 12-13/16”L. x 10-7/16”W.—11.6 qt. (11.0 lit.) capacity
• Stainless Steel (SS) pan support rail
Model Description Approx. ship wt. lbs. (kg)
RDPS Pan set 12 (5.4)
Dividers
•
Adjustable dividers allow customized placement of items within drawer
Model Description Approx. ship wt. lbs. (kg)
DUD Upper dividers 4 (1.8)
R
DLD Lower dividers 4 (1.8)
R
Handle Kits
•
For use with Professional and Designer 24”W. refrigerated drawer
Model Description Approx. ship wt. lb. (kg)
PURHK23-BR Professional brass handle kit and logo for VURD 5 (2.3)
PHK23-SS Professional stainless steel handle kit for DFRD 5 (2.3)
PHK23-BR Professional brass handle kit for DFRD 5 (2.3)
DHK18-SS Designer stainless steel handle kit for DFRD 5 (2.3)
DHK18-BR Designer brass handle kit for DFRD 5 (2.3)
Compliance Information
WARRANTY SUMMARY*
• Two-year full warranty—complete unit
• Six-year full warranty—sealed refrigeration system
• Twelve-year limited warranty—sealed refrigeration system
• Ninety-day limited—cosmetic parts such as glass, painted, and decorative items
*For complete warranty, see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
R E L E A S E D 6 / 1 0 / 0 8
