PROFESSIONAL FEATURES
§ 5.5 cu. ft. capacity stores 20 wine bottles total (7 flat) and up to (162)
12-oz cans
§ Slide-Out Convertible Shelf features removable split glass panes with
wine rack option to store beverages, food or wine
§ Tall item storage: half-width interior shelf allows for high-clearance
vertical storage
§ Access contents easily with full-extension shelf, glideout shelving on
the smooth-glide ball bearing system
§ Cantilevered shelving system adjusts height to meet storage needs
§ Dynamic cooling technology delivers rapid cool down, frost-free
operation and precise temperature stability
§ Thermal-efficient cabinet ensures optimum food preservation and
energy efficiency while maximizing capacity
§ Argon-filled, UV-resistant tinted dual pane glass door protects
contents from damaging ultraviolet light and helps conserve energy
§ Multifunction controls allows selection of precise cabinet temperature
from 33°F to 70° F
§ At the touch of a button, change the interior light color to Alluvial Blue
or Arctic White
§ Theater-style display lighting gently brightens as door is opened and
dims to off when closed
§ Midnight Black interior
UNDERCOUNTER REFRIGERATOR
Viking 5 Series – VRUI
MODEL NUMBERS
§ VRUI5241GSS – 24”W. Undercounter Refrigerator
(indoor unit) – Glass door
DESIGN OPTIONS
§ Reversible soft-close door allows for right
or left swing for adaptable installation
COLOR FINISHES
§ Available in Stainless Steel (SS)
WARRANTY
§ 2-year full covers complete unit
§ 6-year full – sealed refrigeration system
§ 90-day full – cosmetic parts such as glass,
painted items, and decorative items
§ 12-year limited – sealed refrigeration
system
"D"
"E"
"F"
"G"
"H"
"J"
105 lbs
(47.6 kg)
105 lbs
(47.6 kg)
140 lbs
(63.6 kg)
140 lbs
(63.6 kg)
140 lbs
(63.6 kg)
3
1
⁄2" (8.9 cm)
Minimum
21
1
⁄2"
(54.6 cm)
UNDERCOUNTER REFRIGERATOR
24”W. UNDERCOUNTER/FREESTANDING REFRIGERATOR
DESCRIPTION VRUI5241
Overall Width 23-7/8” (60.6 cm)
Overall Height 33-3/4” min – 34-3/4” max (85.7 cm min – 88.3 cm max)
Overall Depth from Rear To front of door – 23-23/32” (60.2 cm)
Electrical Requirements 120V / 60Hz / 15A (5 ft. power cord attached to product)
Maximum Amp Us age 3.0 amps
Maximum Storage Capacity 5.5 cu. ft.
Interior finish Black
Approximate Shipping Weight 160 lb. (72.6 kg)
Please do not prepare installation from brochure data only. See installation instructions for important clearance/installation information.
Cabinet Dimensions
D E F
23-7/8”
(60.7 cm)
33-3/4” to 34-3/4”
To handle– 26-7/32” (66.6 cm)
With door at 90º – 46-13/32” (117.9 cm)
(85.7 to 88.3 cm)
23-23/32”
(60.2 cm)
Viking 5 Series – VRUI
24” Rough-in Dimensions
A B C
24”
(61 cm)
34” to 35”
(86.4 to 88.9 cm)
"C"
"B"
24”
(61 cm)
"A"
G H J
26-7/32”
(66.6 cm)
46-13/32”
(117.9 cm)
26-7/16”
(67.2 cm)
VIKING RANGE, LLC 111 FRONT STREET GREENWOOD, MISSISSIPPI 38930 USA
For detailed product information, model numbers, or to request a quote call 1-888-845-4641 or visit vikingrange.com
© 2020 Viking Range, LLC All rights reserved. Specifications subject to change without notice.
F60346N 0521
