Quiet Cool™ Built-In 42”W. Side-By-Side
Standard Features & Accessories
All models include
• Total capacity—23.6 cu. ft. (667.9 L)
o
Refrigerator - 15.0 cu. ft.
o
Freezer - 8.6 cu. ft.
o 84”H./24”D.
• ProChill™ Temperature Management
System
o
Variable-speed DC Overdrive™
Compressor is one of the quietest,
most technologically advanced compressors available
o
Electronic controls maintain the temperature selection within 1ºF
o
Multi-channel airflow system and
Odor Eliminator™ Evaporator
removes odors and excess humidity
• Exclusive Plasmacluster™* Ion Air
Purifier
o
Eliminates airborne bacteria and
mold spores
o
Removes odors
o
Enhances food preservation
o
Never needs replacing
• Refrigerator Compartment
o
Four adjustable tempered glass
spillproof shelves
• Adjustable Cold Zone™ drawer with
precision ball-bearing glides
o
Separate temperature control can be
set for produce or fresh meat storage
o
Quick chill option chills foods and
beverages in minutes
• Adjustable Humidity Zone™ drawers
with precision ball-bearing glides
o
Humidity can be set high for leafy
greens or low for fruits and vegetables with skins
• Two in-the-door sealed dairy
compartments with covers
• Four patented adjustable aluminum
door bins with tempered glass fronts
• Top-shelf provides quick chill-down
area
• Freezer Compartment
o
Adaptive defrost
o
Three wire shelves and two slide-out
baskets
o
Three patented adjustable aluminum door bins with tempered
glass fronts
REFRIGERATION
Refrigerator/Freezer with Dispenser
• Ice/Water Dispenser
o
Through-the-door dispenser
provides cubed ice, crushed ice and
water in easy on-hand operation
o
Premium water filter provides cleaner water and ice supply by filtering
bad tastes, odors, sediment and
harmful contaminants.
• Super Clog-Resistant™ Condenser is
maintenance-free under normal use
• Tru-Flush™ design
o
Allows Professional Integrated and
Custom Panel models to fit flush into
24” deep installation cutout
• Open door alarm sounds and glows to
warn that door has been ajar for three
minutes
• Adjustable door stops standard—90°,
110°, or 120° swing
• Sabbath Mode
*Plasmacluster is a registered trademark
of Sharp Corporation.
Model Options
VCSB542D/VISB542D
Professional/Professional
Integrated
FINISH DETAILS FOR VCSB/VISB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iridescent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Red (RR), Apple
Red (AR), Burgundy (BU), Plum (PL),
Chocolate (CH), and Cobalt Blue (CB).
• Finish codes designate door fronts.
Stainless steel upper grille, side trim,
and handles (with chrome-plated
brackets); black lower kickplate.
• Brass Trim Option (BR)—nameplate,
handle/brackets, and side trim. Brass
components have a durable protective
coating for maintenance-free normal
use.
ORDERING INSTRUCTIONS
First specify model number, and then color code (VCSB542DSS). If ordering optional brass trim, specify code at end (VCSB542DSSBR).
FINISH DETAILS FOR DFSB MODEL
• Handles not included—opt for custom
handles, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• See Custom Panels section for
more information and additional
specifications.
DFSB542D
Custom Front
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R EL E A SE D 3 /1 / 0 9
© 20 0 9 V RC — INFORMATION SUBJECT TO CHANGE
REFRIGERATION
2
2
-
3
/
1
6
”
(
5
6
.
4
c
m
)
2
4
-
1
1
/
1
6
”
(
6
2
.
7
c
m
)
7
5
-
1
5
/1
6
”
(
1
9
2
.9
cm
)
3
-
1
9
/
3
2
”
(
9
.
1
c
m
)
4
2
”
(
1
0
6
.
7
cm)
2
7-
1/
4”
(
6
9
.
2
c
m
)
41”
(1
0
4.1
c
m
)
82-3/
4”
(2
1
0
.2
cm
)
m
i
n
.
to
84-
1/1
6”
(2
1
3
.5
c
m
)
m
ax
.
2
3
-
3
/
8
”
(5
9
.
4
c
m
)
24”
(6
1
.0
c
m
)
7
5
-1
5
/
1
6
”
(
1
9
2.
9
cm
)
4
2
”
(
1
0
6.
7
cm)
4
1”
(
1
0
4
.
1
c
m
)
82-
3/
4”
(
2
1
0.
2
cm
)
m
i
n
.
t
o
84-
1
/1
6”
(
2
1
3
.
5
c
m
)
ma
x
.
26
-
1
/2
”
(6
7
.3
cm)
3
-1
9/3
2”
(
9
.
1
c
m
)
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
Please see
Installation Notes &
Accessories
for important
information,
including panel and
handle kits, and
water filters.
ALL MODELS
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Specifications
PRODUCT DIMENSIONS
VCSB542D/VISB542D
Professional/Professional
Integrated
PROFESSIONAL PROFESSIONAL
INTEGRATED
VCSB542D VISB542D
Overall width 42” (106.7 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm)
To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm)
To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)
Approx. ship weight 676 lbs. (304.2 kg)
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
2
3
-
13
/
1
6
”
(
6
0
.
5
cm
)
2
4
-
3
/4
”
(
6
2
.
9
cm
)
7
5
-
1
5
/
1
6
”
(1
9
2
.9
cm
)
42
”
(1
0
6
.
7
cm)
41”
(1
0
4.1
c
m
)
82-3/
4”
(2
1
0
.2
cm
)
m
i
n
.
to
84-
1/1
6”
(2
1
3
.5
c
m
)
m
ax
.
Var
i
es
3
-
1
/
2
”
(8
.9
c
m)
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
Please see
Installation Notes &
Accessories
for important
information,
including panel and
handle kits, and
water filters.
ALL MODELS
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Specifications
PRODUCT DIMENSIONS
DFSB542D
Custom Front
See Custom Panels section for
more information and additional
specifications.
CUSTOM FRONT
Overall width 42” (106.7 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 23-13/16” (60.5 cm)
To front of top grille 24-3/4” (62.9 cm)
To front of handle Varies
Approx. ship weight 525 lbs. (236.2 kg)
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
DFSB542D
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
41-5/16”
(105.0 cm)
24”
(61.0 cm)
39-15/32”
(100.3 cm)
40-19/32”
(103.1 cm)
43-1/2”
(110.5 cm)
44-31/32”
(114.3 cm)
45-31/32”
(116.8 cm)
9-1/2”
(24.1 cm)
7-5/32”
(18.2 cm)
1-27/32”
(4.7 cm)
11-27/32”
(30.1 cm)
8-3/4”
(22.2 cm)
1-27/32”
(4.7 cm)
42”
(106.7 cm)
41”
(104.1 cm)
90°
90°
110°
110°
120°
120°
2-1/2” (6.4 cm)
Professional Integrated
42”
(
106.7 cm)
4
1-5/16”
(104.9 cm)
24-23/32”
(62.8 cm)
2-1/2”
(6.4 cm)
4
0-19/32”
(
103.1 cm)
39-15/32”
(100.3 cm)
43-1/2”
(110.5 cm)
4
5”
(114.3 cm)
4
5-31/32”
(
116.8 cm)
1
0-19/32”
(26.3 cm)
12-21/32”
(32.1 cm)
9-1/16”
(
24.6 cm)
8-1/8”
(20.6 cm)
41” (104.1 cm)
4
1”
(104.1 cm)
3”
(
7.6 cm)
3”
(
7.6 cm)
90°
90°
110°
110°
120°
1
20°
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
Dimensions & Specifications
DOOR SWING
• Adjustable door stops standard—90°, 110°, or 120° swing
REFRIGERATION
VCSB542D/VISB542D
Professional/Professional
Integrated
PROFESSIONAL
DFSB542D
Custom Front
See Custom Panels section for
more information and additional
specifications.
PROFESSIONAL INTEGRATED
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
R E L E A S E D 3 / 1 / 0 9
Door
Wall
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
3/4”
(1.9 cm)
full end panel
24”
(
61.0 cm)
s
tandard
c
abinet
d
epth
2-1/2”
(6.4 cm) offset
5/16”
(0.8 cm)
1-13/16”
(4.6 cm)
space if 24”standard
cabinet depth is used
D
oor
24”
(
61.0 cm)
s
tandard cabinet depth
Wall
3/4”
(
1.9 cm)
f
ull end panel
2-1/2”
(6.4 cm) offset
Countertop
overhang
Dimensions & Specifications
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Partial overlay
cabinet door
CLEARANCE DIMENSIONS—PROFESSIONAL
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
TOP VIEW
TOP VIEW
TOP VIEW
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Quiet Cool™ Built-In 42”W. Side-By-Side
Door
Wall
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
D
oor
24”
(
61.0 cm)
s
tandard
c
abinet depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
f
ull end panel
1”
(2.5 cm)
if 25” (63.5 cm)
c
abinet depth is used
Flush
Door
24”
(
6
1
.
0
cm
)
standar
d
ca
binet
dep
th
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
3/4”
(1.9 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Cabinet
door
Refrigerator/Freezer with Dispenser
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED
TOP VIEW
REFRIGERATION
TOP VIEW
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
TOP VIEW
Overlapping cabinet doors
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
REFRIGERATION
A
n
t
i
-
t
i
p
b
o
a
r
d
6
”
(
1
5
.
2
c
m
)
9
”
(
2
2
.
9
c
m
)
7
3
-
3
/
8
”
(1
8
6
.
4
c
m
)
8
2
-
7
/
8
”
(
2
1
0
.
5
c
m
)
m
i
n
.
a
n
t
i
-
t
i
p
b
o
a
r
d
&
o
p
e
n
i
n
g
h
e
i
g
h
t
8
4
-
1
/
6
”
(
2
1
3
.
5
c
m
)
m
a
x
.
a
n
t
i
-
t
i
p
b
o
a
r
d
&
o
p
e
n
i
n
g
h
e
i
g
h
t
2
4
”
*
(
6
1
.
0
c
m
)
m
i
n
.
6
-
3
/
4
”
(
1
7
.
1
c
m
)
7
-
5
/
8
”
(
1
9
.
4
c
m
)
3
”
(
7
.
6
c
m
)
5
/
8
”
(
1
.
5
c
m
)
5
/
8
”
(
1
.
5
c
m
)
1
0
-
1
/
2
”
(
2
6
.
7
c
m
)
5
/
8
”
(
1
.
5
c
m
)
1
0
-
3
/
4
”
(
2
7
.
3
c
m)
1
”
(
2
.
5
c
m
)
3
-
5
/
8
”
(
9
.
2
c
m
)
O
p
t
i
on
a
l
f
l
o
o
r
w
a
t
e
r
l
i
n
e
e
n
t
r
y
9
”
(
2
2
.
9
c
m
)
4
1
-
1
/
2
”
(
1
0
5
.
4
c
m
)
m
i
n
.
t
o
4
1
-
3
/
4
”
(
1
0
6
.
0
c
m
)
m
i
n
.
P
r
o
fe
s
s
i
on
a
l
4
2
”
(
1
0
6
.
7
c
m
)
P
r
o
fe
s
s
i
o
n
a
l
I
n
t
e
g
r
a
t
e
d
/
C
u
s
t
om
F
r
o
n
t
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
UTILITY
REQU IR EME NT S
GAS
Not applicable
ELECTRICAL
• Three-wire cord
with grounded
three-prong plug
attached to
product
• 115 VAC 60 Hz;
15 amp dedicated circuit
• Maximum amp
usage—9.9
• Estimated
energy usage—
694 kWh/year
Installation Requirements
ACCESS REQUIREMENTS
VCSB542D/VISB542D
Professional/Professional
Integrated
DFSB542D
Custom Front
See Custom Panels section for
more information and additional
specifications.
ELECTRIC OUTLET LOCATION
PLUMBING
• Inlet waterline
requirements—
1/4” copper
tubing
• 35 psi min.;
120 psi max.
*Custom front models fit flush in 25”-deep (63.5 cm)
cabinet openings. They can be installed in standard
24”-deep openings. The door faces and top grille
Cutout width 41-1/2” (105.4 cm) min. to 42” (106.7 cm) 42” (106.7 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
will protrude 3/4” (1.9 cm) into the room.
VCSB542D VISB542D DFSB542D
41-3/4” (106.0 cm) max.
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
WATER LINE ENTRY AREA
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
R E L E A S E D 3 / 1 / 0 9
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
Installation Notes & Accessories
Side Panel Kits
• Stainless Steel (SS)
• Panels provide finished, freestanding look; unit must still be secured to the wall
Kit includes one panel and installation hardware
•
Model Description Approx. ship wt. lbs. (kg)
SSPL2 Professional side panel left (VCSB) 45 (20.2)
P
SSPR2 Professional side panel right (VCSB) 45 (20.2)
P
SSPL2 Designer side panel left (VISB/DFSB) 45 (20.2)
D
SSPR2 Designer side panel right (VISB/DFSB) 45 (20.2)
D
Side Panel Hardware Kit
• For use with Designer built-in refrigerator/freezers
• Hardware allows installation of custom side panels
• Kit includes brackets, screws, and installation instructions to mount panels on left and right side
Model Description Approx. ship wt. lbs. (kg)
SPHKDS Side panel hardware 3 (1.4)
Top Panel Kit
• Stainless Steel (SS)
• Panel provides finished, freestanding look; unit must still be secured to the wall
• Kit includes one panel and installation hardware
Model Description Approx. ship wt. lbs. (kg)
TOP-42 42”W. top panel 23 (10.4)
Handle Kits
• For use with custom front refrigerator/freezers
• For use on locally supplied custom front panels
• Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products
• Kit includes two handles and installation hardware
Model Description Approx. ship wt. lbs. (kg)
PHK-DFSB5-SS Professional handles (Stainless Steel) 10 (4.5)
PHK-DFSB5-BR Professional handles (Brass) 10 (4.5)
HKFDS-SS Designer handles (Stainless Steel) 10 (4.5)
HKFDS-BR Designer handles `(Brass) 10 (4.5)
Replacement Water Filter
• Reduces sediment, taste, and odor
• Reduces cysts, particulates, turbidity, lead, chlorine, atrazine, and lindane
• NSF-certified
• Ready to install—no assembly required
• Replacement recommended every nine months
Model Description Approx. ship wt. lbs. (kg)
RWF-DISP Replacement water filter 5 (2.3)
Compliance Information
WARRANTY SUMMARY*
• Two-year full warranty—complete unit
• Six-year full warranty—sealed refrigeration system and automatic ice maker
• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,
dryer/strainer, evaporator, and connecting tubing)
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada. ]b]s.
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
R E L E A S E D 3 / 1 / 0 9
Loading...
