Viking Professional VIBB536R, Professional VISB542D, Professional VCBB536, Professional VIBB536, DFBB536 Specifications

Quiet Cool™ Built-In 36”W. Bot tom-Mount

Standard Features & Accessories

REFRIGERATION

Refrigerator/Freezer

All models include

• Total capacity—20.3 cu. ft. (574.5 L) o

Refrigerator - 15.2 cu. ft.

o

Freezer - 5.1 cu. ft.

o

84”H./24”D.

• ProChill™ Temperature Management System

o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Exclusive Plasmacluster™* Ion Air Purifier

o

Eliminates airborne bacteria and mold spores

o

Removes odors

o

Enhances food preservation

o

Never needs replacing

• Refrigerator Compartment

Model Options

o

Five adjustable tempered glass spillproof shelves

• Adjustable Cold Zone™ drawer with precision ball-bearing glides

o

Separate temperature control can be set for produce or fresh meat storage

o

Quick chill option chills foods and beverages in minutes

• Adjustable Humidity Zone™ drawers with precision ball-bearing glides

o

Humidity can be set high for leafy greens or low for fruits and vegetables with skins

• Two conveniently located deli drawers with full-extension precision ball-bearing glides

• Two in-the-door sealed dairy compartments with covers

• Four patented adjustable aluminum door bins with tempered glass fronts

• Top-shelf provides quick chill-down area

• Full extension freezer drawer on precision ball-bearing glides

o

Positive self-closing feature ensures a good seal

o

Adaptive defrost

o

Two slide-out wire baskets

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar for three minutes

• Adjustable door stops standard—90°, 110°, or 120° swing

• Sabbath Mode

• Must be ordered right or left hinge. (As you face unit, RIGHT has hinge on right side and handle on left side; LEFT has hinge on left side and handle on right side.)

*Plasmacluster is a registered trademark

of Sharp Corporation.

VCBB536/VIBB536

Professional/Professional

Integrated

FINISH DETAILS FOR VCBB/VIBB MODELS

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door fronts. Stainless steel upper grille, side trim, and handles (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, and side trim. Brass components have a durable protective coating for maintenance-free normal use.

ORDERING INSTRUCTIONS

First specify model number, followed by hinge preference (“R” for right or “L” for left), and then color code (VCBB536RSS). If ordering optional brass trim, specify code at end (VCBB536RSSBR).

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

DFBB536

Custom Front

FINISH DETAILS FOR DFBB MODEL

• Handles not included—opt for custom handles, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for more information and additional specifications.

R E L E AS ED 3 / 1 / 09

REFRIGERATION

3

6

”

(

9

1

.

4

c

m

)

2

-

3

/

1

6

”

(

5

6

.

4

c

m

)

2

4

-

1

/

1

6

”

(

6

2

.

7

c

m

)

2

7

-

1

/

4

”

(

6

9

.

2

c

m

)

3

5

”

(

8

.

9

c

m

)

8

2

-

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

7

9

-

1

7

/

3

2

”

(

2

0

2

c

m

)

5

2

”

(

1

3

2

.

1

c

m

)

3

-

1

9

/

3

2

”

(

9

.

1

c

m

)

2

3

-

1

/

1

6

”

(

5

8

.

5

c

m

)

3

6

”

(

9

1

.

4

c

m

)

2

3

-

3

/

8

”

(

5

9

.

4

c

m

)

2

4

”

(

6

1

.

0

c

m

)

2

6

-

1

/

2

”

(

6

7

.

3

c

m

)

3

5

”

(

8

.

9

c

m

)

8

2

-

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

7

9

-

1

7

/

3

2

”

(

2

0

2

c

m

)

5

2

”

(

1

3

2

.

1

c

m

)

3

-

1

9

/

3

2

”

(

9

.

1

c

m

)

2

3

-

1

/

1

6

”

(

5

8

.

5

c

m

)

Quiet Cool™ Built-In 36”W. Bottom-Mount

Refrigerator/Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, and handle

kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCBB536/VIBB536

Professional/Professional

Integrated

PROFESSIONAL PROFESSIONAL

Overall width 36” (91.4 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 565 lbs. (254.3 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

INTEGRATED

VCBB536 VIBB536

R E L E AS ED 3 / 1 / 09

3

5

”

(

8

.

9

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

t

o

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

3

-

1

3

/

1

6

”

(

6

0

.

5

c

m

)

2

4

-

3

/

4

”

(

6

2

.

9

c

m

)

7

9

-

1

7

/

3

2

”

(

2

0

2

c

m

)

5

2

”

(

1

3

2

.

1

c

m

)

3

-

1

/

2

”

(

8

.

9

c

m

)

2

3

-

1

/

1

6

”

(

5

8

.

5

c

m

)

3

6

”

(

9

1

.

4

c

m

)

V

a

r

i

e

s

REFRIGERATION

Quiet Cool™ Built-In 36”W. Bottom-Mount

Refrigerator/Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, and handle

kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFBB536

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 36” (91.4 cm) Overall height (from bottom) 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 23-13/16” (60.5 cm) To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 500 lbs. (227.3 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFBB536

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. Bottom-Mount

22--11//22””

((66..44 ccmm))

5588--1111//3322”” ((114488..22 ccmm))

2244--1111//1166”” ((6622..77 ccmm))

5566--55//88””

((114433..88 ccmm))

5544--77//3322””

((113377..77 ccmm

)

1

144””

((3355..66 ccmm))

3366””

((9911..44 ccmm))

3355””

((8888..99 ccmm))

1188--2299//3322”” ((4488..00 ccmm))

33--11//3322”” ((77..77 ccmm))

112200..00

00

111100..00

00

9900..00

00

2244””

((6611..00 ccmm))

3366””

((9911..44 ccmm))

3355””

((8888..99 ccmm))

2-1/2” (6.4 cm)

Professional Integrated

5588--33//88”” ((114488..33 ccmm))

5566--1111//1166”” ((114444..00 ccmm))

5544--99//3322””

((113377..99 ccmm

)

1133--11//88””

((3333..33 ccmm))

1188--33//1166”” ((4466..22 ccmm))

11--2277//3322”” ((44..77 ccmm))

112200..00

00

111100..00

00

9900..00

00

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

Refrigerator/Freezer

VCBB536/VIBB536

Professional/Professional

Integrated

PROFESSIONAL

DFBB536

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. Bottom-Mount

Door

Wall

1-13/16”

(4.6 cm)

space if 24” standard

cabinet depth is used

3/4”

(1.9 cm) full end panel

24”

(61.0 cm) standard c

abinet

depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1

-13/16”

(

4.6 cm) space if 24” standard cabinet depth is used

D

oor

24”

(61.0 cm)

standard cabinet depth

W

all

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Countertop overhang

1-13/16”

(4.6 cm)

space if 24” standard

cabinet depth is used

Door

24”

(61.0 cm) standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay cabinet door

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL

REFRIGERATION

Refrigerator/Freezer

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. Bottom-Mount

Door

Wall

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm)

full end panel

25”

(63.5 cm)

Flush

Door

24”

(

61.0 cm)

s

tandard

c

abinet depth

25”

(63.5 cm)

countertop

depth

Wall

3/4”

(1.9 cm)

f

ull end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Door

2

4

”

(

6

1

.

0 c

m

)

s

t

an

d

ar

d

c

ab

i

n

e

t

d

e

p

th

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

3/4”

(1.9 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Cabinet door

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED

REFRIGERATION

Refrigerator/Freezer

TOP VIEW

Overlapping cabinet doors

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

9

”

(

2

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6

.

4

c

m)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

3

5

-

1

/

2

”

(

9

0

.

2

c

m

)

m

i

n

.

t

o

3

5

-

3

/

4

”

(

9

0

.

8

c

m

)

m

i

n

.

P

r

o

f

e

s

i

o

n

a

l

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

1

”

(

2

.

5

c

m

)

3

-

5

/

8

”

(

9.

2

c

m

)

O

p

t

i

on

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

3

6

”

(

9

1

.4

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

REFRIGERATION

Quiet Cool™ Built-In 36”W. Bottom-Mount

Refrigerator/Freezer

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC/60 Hz; 15 amp dedicated circuit

• Maximum amp usage—9.9

• Estimated energy usage— 567 kWh/year

Installation Requirements

ACCESS REQUIREMENTS

VCBB536/VIBB536

Professional/Professional

Integrated

DFBB536

Custom Front

See Custom Panels section for more information and additional specifications.

ELECTRIC OUTLET LOCATION

PLUMBING

• Inlet waterline

requirements— 1/4” copper tubing

• 20 psi min.;

120 psi max.

*Custom front models fit flush in 25”-deep (63.5 cm)

cabinet openings. They can be installed in standard 24”-deep openings. The door faces and top grille

Cutout width 35-1/2” (90.2 cm) min. to 36” (91.4 cm) 36” (91.4 cm)

Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

will protrude 3/4” (1.9 cm) into the room.

VCBB536 VIBB536 DFBB536

35-3/4” (90.8 cm) max.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

WATER LINE ENTRY AREA

R E L E AS ED 3 / 1 / 09

9

”

(

2

.

9

cm

)

7

3

-3

/8

”

(

1

8

6

.

4

cm

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

7

1

-

1

/

2

”

(

1

8

1

.

6

c

m

)

P

r

o

f

e

s

i

o

n

a

l

7

2

”

(

1

8

2

.

9

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/4

”

(

2

7

.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

er

l

i

n

e

n

t

r

y

1

”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

r

d

i

n

s

t

a

l

a

t

i

o

n

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

Installation Requirements

ACCESS REQUIREMENTS – Dual Installation

REFRIGERATION

Quiet Cool™ Built-In 36”W. Bottom-Mount

Refrigerator/Freezer

ELECTRIC OUTLET LOCATION

*Custom front models fit flush in 25”-deep (63.5 cm) cabinet openings. They can be installed in standard 24”-deep openings. The

door faces and top grille will protrude 3/4” (1.9 cm) into the room.

Cutout width 71-1/2” (181.6 cm) 72” (182.9 cm) 72” (182.9 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.

36”W./36”W. REFRIGERATOR/ FREEZER BOTTOM MOUNT COMBINATION

VCBB536/VCBB536 VIBB536/VIBB536 DFBB536/DFBB536

WATER LINE ENTRY AREA

Cutout depth 24” (61.0 cm) min.*

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 36”W. Bottom-Mount

Refrigerator/Freezer

Installation Notes & Accessories

!

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished, freestanding look; unit must still be secured to the wall Kit includes one panel and installation hardware

•

Model Description Approx. ship wt. lbs. (kg)

PSSPL3 Professional side panel left (VCBB) 45 (20.2) PSSPR3 Professional side panel right (VCBB) 45 (20.2) DSSPL3 Designer side panel left (VIBB/DFBB) 45 (20.2) DSSPR3 Designer side panel right (VIBB/DFBB) 45 (20.2)

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

PHKDS Side panel hardware kit 3 (1.4)

S

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-36 36”W. top panel 22 (10.0)

Top Grille Kits

• Stainless Steel (SS)

• For use with installation of two 36”W. bottom-mount refrigerator/freezers

• Grille creates a single unit look

• Kit includes one full-length grille, center cabinet trim connector, and grill installation hardware

Model Description Approx. ship wt. lbs. (kg)

PBRTGK72-SS Professional 72”W. grille (for two VCBB units) 25 (11.3) DBRTGK72-SS Designer 72”W. grille (for two DFBB units) 25 (11.3)

Handle Kits

• For use with custom front refrigerator/freezers

• For use on locally supplied custom front panels

• Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products

• Kit includes two handles and installation hardware

Model Description Approx. ship wt. lbs. (kg)

PHK-DFBB-SS Professional handles (Stainless Steel) 10 (4.5) PHK-DFBB-BR Professional handles (Brass) 10 (4.5) HKFDS-SS Designer handles (Stainless Steel) 10 (4.5) HKFDS-BR Designer handles (Brass) 10 (4.5)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system and automatic ice maker

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser, dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

* For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 42”W. Side-By-Side

Standard Features & Accessories

REFRIGERATION

Refrigerator/Freezer

All models include

• Total capacity—24.0 cu. ft. (679.7 L) o

Refrigerator - 15.0 cu. ft.

o

Freezer - 9.0 cu. ft.

o

84”H./24”D.

• ProChill™ Temperature Management System

o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Exclusive Plasmacluster™* Ion Air Purifier

o

Eliminates airborne bacteria and mold spores

o

Removes odors

o

Enhances food preservation

o

Never needs replacing

Model Options

• Refrigerator Compartment o

Four adjustable tempered glass spillproof shelves

• Adjustable Cold Zone™ drawer with precision ball-bearing glides

o

Separate temperature control can be set for produce or fresh meat storage

o

Quick chill option chills foods and beverages in minutes

• Adjustable Humidity Zone™ drawers with precision ball-bearing glides

o

Humidity can be set high for leafy greens or low for fruits and vegetables with skins

• Two in-the-door sealed dairy compartments with covers

• Four patented adjustable aluminum door bins with tempered glass fronts

• Top-shelf provides quick chill-down area

• Freezer Compartment o

Adaptive defrost

o

Three wire shelves and two slide-out baskets

o

Three patented adjustable aluminum door bins with tempered glass fronts

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar f or three minutes

• Adjustable door s tops standard—90°, 110°, or 120° swing

• Sabbath Mode

*Plasmacluster is a registered trademark

of Sharp Corporation.

VCSB542/VISB542

Professional/Professional

DFSB542

Custom Front

Integrated

FINISH DETAILS FOR VCSB/VISB MODELS

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door fronts. Stainless steel upper grille, side trim, and handles (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, side trim. Brass components have a durable protective coating for maintenance-free normal use.

ORDERING INSTRUCTIONS

First specify model number, and then color code (VCSB542SS). If ordering optional brass trim, specify code at end (VCSB542SSBR).

FINISH DETAILS FOR DFSB MODEL

• Handles not included—opt for custom handles, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for

more information and additional specifications.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

-

3/

1

6

”

(

56

.

4

c

m

)

2

4

-

11

/1

6

”

(

62

.

7

c

m

)

3

-

1

9/

3

2

”

(

9

.

1

c

m

)

4

2

”

(

10

6

.

7

c

m

)

4

1”

(

10

4

.

1

c

m

)

8

2

-

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

7

-

1

/

4

”

(

69

.

2

c

m

)

2

3

-

3

/

8

”

(

59

.

4

c

m

)

2

4

”

(

61

.

0

c

m

)

7

5

-

1

5

/

1

6

”

(

19

2

.

9

c

m

)

3

-

1

9/

3

2”

(

9. 1

c

m

)

4

2

”

(

10

6

.

7

c

m

)

4

1”

(

10

4

.

1

c

m

)

8

2

-

3

/

4

”

(

21

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1/

1

6

”

(

21

3. 5

c

m

)

m

a

x

.

2

6

-

1

/

2

”

(

67

.

3

c

m

)

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCSB542/VISB542

Professional/Professional

Integrated

PROFESSIONAL

Overall width 42” (106.7 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 652 lbs. (293.4 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

PROFESSIONAL INTEGRATED

VCSB542 VISB542

R E L E AS ED 3 / 1 / 09

2

4

-

3

/

4

”

(

62

.

9

c

m

)

7

5

-

1

5

/

1

6

”

(

19

2

.

9

c

m

)

3

-

1

/

2

”

(

8. 9

c

m

)

4

2

”

(

10

6

.

7

c

m

)

4

1”

(

10

4

.

1

c

m

)

Va

r

i

e

s

2

3

-

13

/

1

6

”

(

60

.

5

c

m

)

8

2

-

3

/

4

”

(

21

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1/

1

6

”

(

21

3. 5

c

m

)

m

a

x

.

REFRIGERATION

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFSB542

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 42” (106.7 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 23-13/16” (60.5 cm) To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 525 lbs. (236.2 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFSB542

R E L E AS ED 3 / 1 / 09

42”

(106.7 cm)

41-5/16” (104.9 cm)

24-23/32” (62.8 cm)

2-1/2”

(6.4 cm)

40-19/32” (103.1 cm)

39-15/32” (100.3 cm)

43-1/2”

(110.5 cm)

45”

(114.3 cm)

45-31/32” (116.8 cm)

10-19/32”

(26.3 cm)

12-21/32”

(32.1 cm)

9

-1/16”

(24.6 cm)

8-1/8”

(20.6 cm)

41” (104.1 cm)

3”

(7.6 cm)

41”

(104.1 cm)

3”

(7.6 cm)

90°

110°

120°

Quiet Cool™ Built-In 42”W. Side-By-Side

41-5/16” (105.0 cm)

24”

(61.0 cm)

39-15/32” (100.3 cm)

40-19/32” (103.1 cm)

43-1/2”

(110.5 cm)

44-31/32” (114.3 cm)

45-31/32” (116.8 cm)

9-1/2” (24.1 cm)

7-5/32” (18.2 cm)

1-27/32” (4.7 cm)

11-27/32”

(30.1 cm)

8-3/4”

(22.2 cm)

1-27/32”

(4.7 cm)

90°

110°

120°

42”

(106.7 cm)

41”

(104.1 cm)

2-1/2” (6.4 cm)

Professional Integrated

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

Refrigerator/Freezer

VCSB542/VISB542

Professional/Professional

Integrated

PROFESSIONAL

DFSB542

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Dimensions & Specifications

Door

Wall

1-13/16”

(4.6 cm)

space if 24” standard

c

abinet depth is used

3/4”

(1.9 cm)

full end panel

24”

(61.0 cm) standard cabinet depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1-13/16”

(

4.6 cm)

s

pace if 24” standard

cabinet depth is used

Door

24”

(61.0 cm) standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Countertop

overhang

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay cabinet door

CLEARANCE DIMENSIONS—PROFESSIONAL

REFRIGERATION

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 42”W. Side-By-Side

Door

Wall

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm)

full end panel

25”

(63.5 cm)

Flush

D

oor

24”

(61.0 cm)

standard

cabinet depth

25”

(63.5 cm) countertop depth

Wall

3/4”

(1.9 cm)

f

ull end panel

1”

(2.5 cm) if 25” (63.5 cm) c

abinet depth is used

Flush

Door

2

4

”

(

6

1

.

0 c

m

)

s

t

an

d

ar

d

c

a

b

i

n

e

t

d

e

p

th

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

3/4”

(1.9 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Cabinet door

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED

TOP VIEW

REFRIGERATION

Refrigerator/Freezer

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

TOP VIEW

Overlapping cabinet doors

R E L E AS ED 3 / 1 / 09

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6

.

4

c

m)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2”

(

2

6

.7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

1

”

(

2

.

5

c

m

)

3

-

5

/

8

”

(

9.

2

c

m

)

O

p

t

ion

a

l

f

l

o

r

w

a

t

er

l

i

n

e

n

t

r

y

9

”

(

2

.

9

c

m

)

4

1

-

1

/

2

”

(

1

0

5

.

4

c

m

)

m

i

n

.

t

o

4

1

-

3

/

4

”

(

1

0

6

.

0

c

m

)

m

i

n

.

P

r

o

f

e

s

i

o

n

a

l

4

2

”

(

1

0

6

.

7

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

te

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

REFRIGERATION

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC/60 Hz; 15 amp dedicated circuit

• Maximum amp usage—9.9

• Estimated energy usage— 653 kWh/year

Installation Requirements

ACCESS REQUIREMENTS

VCSB542/VISB542

Professional/Professional

Integrated

DFSB542

Custom Front

See Custom Panels section for more information and additional specifications.

ELECTRIC OUTLET LOCATION

PLUMBING

• Inlet waterline requirements— 1/4”copper tubing

• 20 psi min.; 120 psi max.

*Custom front models fit flush in 25”-deep (63.5 cm)

cabinet openings. They can be installed in standard 24”-deep openings. The door faces and top grille

Cutout width 41-1/2” (105.4 cm) min. to 42” (106.7 cm) 42” (106.7 cm)

Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

will protrude 3/4” (1.9 cm) into the room.

VCSB542 VISB542 DFSB542

41-3/4” (106.0 cm) max.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

WATER LINE ENTRY AREA

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer

! Installation Notes & Accessories

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished, freestanding look; unit must still be secured to the wall

Kit includes one panel and installation hardware

•

Model Description Approx. ship wt. lbs. (kg)

SSPL2 Professional side panel left (VCSB) 45 (20.2)

P

SSPR2 Professional side panel right (VCSB) 45 (20.2)

P

SSPL2 Designer side panel left (VISB/DFSB) 45 (20.2)

D

SSPR2 Designer side panel right (VISB/DFSB) 45 (20.2)

D

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

SPHKDS Side panel hardware 3 (1.4)

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-42 42”W. top panel 23 (10.4)

Handle Kits

• For use with custom front refrigerator/freezers

• For use on locally supplied custom front panels

• Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products

• Kit includes two handles and installation hardware

Model Description Approx. ship wt. lbs. (kg)

PHK-DFSB5-SS Professional handles (Stainless Steel) 10 (4.5) PHK-DFSB5-BR Professional handles (Brass) 10 (4.5) HKFDS-SS Designer handles (Stainless Steel) 10 (4.5) HKFDS-BR Designer handles (Brass) 10 (4.5)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system and automatic ice maker

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 42”W. Side-By-Side

Standard Features & Accessories

All models include

• Total capacity—23.6 cu. ft. (667.9 L)

o

Refrigerator - 15.0 cu. ft.

o

Freezer - 8.6 cu. ft.

o 84”H./24”D.

• ProChill™ Temperature Management

System o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Exclusive Plasmacluster™* Ion Air

Purifier o

Eliminates airborne bacteria and mold spores

o

Removes odors

o

Enhances food preservation

o

Never needs replacing

• Refrigerator Compartment

o

Four adjustable tempered glass spillproof shelves

• Adjustable Cold Zone™ drawer with precision ball-bearing glides

o

Separate temperature control can be set for produce or fresh meat storage

o

Quick chill option chills foods and beverages in minutes

• Adjustable Humidity Zone™ drawers with precision ball-bearing glides

o

Humidity can be set high for leafy greens or low for fruits and vegetables with skins

• Two in-the-door sealed dairy compartments with covers

• Four patented adjustable aluminum door bins with tempered glass fronts

• Top-shelf provides quick chill-down area

• Freezer Compartment o

Adaptive defrost

o

Three wire shelves and two slide-out baskets

o

Three patented adjustable aluminum door bins with tempered glass fronts

REFRIGERATION

Refrigerator/Freezer with Dispenser

• Ice/Water Dispenser o

Through-the-door dispenser provides cubed ice, crushed ice and water in easy on-hand operation

o

Premium water filter provides cleaner water and ice supply by filtering bad tastes, odors, sediment and harmful contaminants.

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar for three minutes

• Adjustable door stops standard—90°, 110°, or 120° swing

• Sabbath Mode

*Plasmacluster is a registered trademark

of Sharp Corporation.

Model Options

VCSB542D/VISB542D

Professional/Professional

Integrated

FINISH DETAILS FOR VCSB/VISB MODEL

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door fronts. Stainless steel upper grille, side trim, and handles (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, and side trim. Brass components have a durable protective coating for maintenance-free normal use.

ORDERING INSTRUCTIONS

First specify model number, and then color code (VCSB542DSS). If ordering optional brass trim, specify code at end (VCSB542DSSBR).

FINISH DETAILS FOR DFSB MODEL

• Handles not included—opt for custom handles, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for more information and additional specifications.

DFSB542D

Custom Front

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

22

-

3

/

16

”

(

56

.

4

c

m)

2

4

-

1

/

16

”

(

62

.

7

c

m)

7

5

-

1

5/

1

6

”

(

19

2

.

9

c

m

)

3-

1

9

/

32

”

(

9. 1

c

m

)

42

”

(

10

6

.

7

c

m

)

2

7

-

1

/

4

”

(

69

.

2

c

m

)

4

1

”

(

10

4

.

1

c

m

)

8

2-3

/

4

”

(

21

0

.

2

c

m

)

mi

n

.

t

o

84

-

1

/

1

6”

(

21

3

.

5

c

m

)

m

a

x

.

2

3

-

3

/8

”

(

59

.

4

c

m

)

2

4

”

(

61

.

0

c

m

)

7

5

-

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

4

2

”

(

1

0

6

.

7

c

m

)

4

1”

(

10

4

.

1

c

m

)

8

2

-

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1

/

1

6

”

(

21

3. 5

c

m

)

m

a

x

.

2

6

-

1

/

2

”

(

67

.

3

c

m

)

3

-

1

9/

3

2”

(

9. 1

c

m

)

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer with Dispenser

Please see

!

Installation Notes &

Accessories

for important

information,

including panel and

handle kits, and

water filters.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCSB542D/VISB542D

Professional/Professional

Integrated

PROFESSIONAL PROFESSIONAL

Overall width 42” (106.7 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 676 lbs. (304.2 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

INTEGRATED

VCSB542D VISB542D

R E L E AS ED 3 / 1 / 09

2

3

-

1

3/

1

6

”

(

60

.

5

c

m)

2

4

-

3

/

4

”

(

62

.

9

c

m)

7

5

-

1

5

/

1

6

”

(

19

2

.

9

c

m

)

4

2

”

(

10

6

.

7

c

m

)

4

1

”

(

10

4

.

1

c

m

)

8

2-3

/

4

”

(

21

0

.

2

c

m

)

mi

n

.

t

o

8

4-

1

/

1

6”

(

21

3. 5

c

m

)

ma

x

.

V

ar

i

e

s

3

-

1

/2

”

(

8. 9

c

m

)

REFRIGERATION

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer with Dispenser

Please see

!

Installation Notes &

Accessories

for important

information,

including panel and

handle kits, and

water filters.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFSB542D

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 42” (106.7 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 23-13/16” (60.5 cm) To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 525 lbs. (236.2 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFSB542D

R E L E AS ED 3 / 1 / 09

41-5/16” (105.0 cm)

24”

(61.0 cm)

39-15/32” (100.3 cm)

40-19/32” (103.1 cm)

43-1/2”

(110.5 cm)

44-31/32” (114.3 cm)

45-31/32” (116.8 cm)

9-1/2” (24.1 cm)

7-5/32” (18.2 cm)

1-27/32” (4.7 cm)

11-27/32”

(30.1 cm)

8-3/4”

(22.2 cm)

1-27/32”

(4.7 cm)

42”

(106.7 cm)

41”

(104.1 cm)

90°

110°

120°

2-1/2” (6.4 cm)

Professional Integrated

42”

(

106.7 cm)

41-5/16” (104.9 cm)

24-23/32” (62.8 cm)

2-1/2”

(6.4 cm)

40-19/32” (103.1 cm)

39-15/32” (100.3 cm)

43-1/2”

(110.5 cm)

45”

(114.3 cm)

45-31/32” (116.8 cm)

10-19/32”

(26.3 cm)

12-21/32”

(32.1 cm)

9-1/16”

(24.6 cm)

8-1/8”

(20.6 cm)

41” (104.1 cm)

41”

(104.1 cm)

3”

(7.6 cm)

3”

(

7.6 cm)

90°

110°

120°

1

20°

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer with Dispenser

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

VCSB542D/VISB542D

Professional/Professional

Integrated

PROFESSIONAL

DFSB542D

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Door

Wall

1-13/16”

(4.6 cm)

space if 24” standard

cabinet depth is used

3/4”

(1.9 cm)

full end panel

24”

(61.0 cm) standard

c

abinet

depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1-13/16”

(4.6 cm)

space if 24”standard

cabinet depth is used

Door

24”

(61.0 cm) standard cabinet depth

Wall

3/4”

(

1.9 cm)

f

ull end panel

2-1/2”

(6.4 cm) offset

Countertop overhang

Dimensions & Specifications

1-13/16”

(4.6 cm)

space if 24” standard

cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay cabinet door

CLEARANCE DIMENSIONS—PROFESSIONAL

REFRIGERATION

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer with Dispenser

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 42”W. Side-By-Side

Door

Wall

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm) full end panel

25”

(63.5 cm)

Flush

Door

24”

(

61.0 cm)

s

tandard

c

abinet depth

25”

(63.5 cm)

countertop

depth

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

c

abinet depth is used

Flush

Door

2

4

”

(

6

1

.

0 c

m

)

s

t

an

d

ar

d

c

a

b

i

n

e

t

d

e

p

th

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

3/4”

(1.9 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Cabinet door

Refrigerator/Freezer with Dispenser

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED

TOP VIEW

REFRIGERATION

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

TOP VIEW

Overlapping cabinet doors

R E L E AS ED 3 / 1 / 09

REFRIGERATION

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6

.

4

c

m)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

1

”

(

2

.

5

c

m

)

3

-

5

/

8

”

(

9.

2

c

m

)

O

p

t

ion

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

9

”

(

2

.

9

c

m

)

4

1

-

1

/

2

”

(

1

0

5

.

4

c

m

)

m

i

n

.

t

o

4

1

-

3

/

4

”

(

1

0

6

.

0

c

m

)

m

i

n

.

P

r

o

f

e

s

i

o

n

a

l

4

2

”

(

1

0

6

.

7

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer with Dispenser

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC 60 Hz; 15 amp dedicated circuit

• Maximum amp usage—9.9

• Estimated energy usage— 694 kWh/year

Installation Requirements

ACCESS REQUIREMENTS

VCSB542D/VISB542D

Professional/Professional

Integrated

DFSB542D

Custom Front

See Custom Panels section for more information and additional specifications.

ELECTRIC OUTLET LOCATION

PLUMBING

• Inlet waterline requirements— 1/4” copper tubing

• 35 psi min.; 120 psi max.

*Custom front models fit flush in 25”-deep (63.5 cm)

cabinet openings. They can be installed in standard 24”-deep openings. The door faces and top grille

Cutout width 41-1/2” (105.4 cm) min. to 42” (106.7 cm) 42” (106.7 cm)

Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

will protrude 3/4” (1.9 cm) into the room.

VCSB542D VISB542D DFSB542D

41-3/4” (106.0 cm) max.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

WATER LINE ENTRY AREA

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 42”W. Side-By-Side

Refrigerator/Freezer with Dispenser

! Installation Notes & Accessories

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished, freestanding look; unit must still be secured to the wall

Kit includes one panel and installation hardware

•

Model Description Approx. ship wt. lbs. (kg)

PSSPL2 Professional side panel left (VCSB) 45 (20.2) PSSPR2 Professional side panel right (VCSB) 45 (20.2) DSSPL2 Designer side panel left (VISB/DFSB) 45 (20.2) DSSPR2 Designer side panel right (VISB/DFSB) 45 (20.2)

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

SPHKDS Side panel hardware 3 (1.4)

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-42 42”W. top panel 23 (10.4)

Handle Kits

• For use with custom front refrigerator/freezers

• For use on locally supplied custom front panels

• Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products

• Kit includes two handles and installation hardware

Model Description Approx. ship wt. lbs. (kg)

PHK-DFSB5-SS Professional handles (Stainless Steel) 10 (4.5) PHK-DFSB5-BR Professional handles (Brass) 10 (4.5) HKFDS-SS Designer handles (Stainless Steel) 10 (4.5) HKFDS-BR Designer handles `(Brass) 10 (4.5)

Replacement Water Filter

• Reduces sediment, taste, and odor

• Reduces cysts, particulates, turbidity, lead, chlorine, atrazine, and lindane

• NSF-certified

• Ready to install—no assembly required

• Replacement recommended every nine months

Model Description Approx. ship wt. lbs. (kg)

RWF-DISP Replacement water filter 5 (2.3)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system and automatic ice maker

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada. ]b]s.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 48”W. Side-By-Side

Standard Features & Accessories

REFRIGERATION

Refrigerator/Freezer

All models include

• Total capacity—27.4 cu. ft. (775.9 L)

o

Refrigerator - 18.5 cu. ft.

o

Freezer - 8.9 cu. ft.

o 84”H./24”D.

• ProChill™ Temperature Management

System o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Exclusive Plasmacluster™* Ion Air

Purifier o

Eliminates airborne bacteria and mold spores

o

Removes odors

o

Enhances food preservation

o

Never needs replacing

Model Options

• Refrigerator Compartment o

Four adjustable tempered glass spillproof shelves

• Adjustable Cold Zone™ drawer with precision ball-bearing glides

o

Separate temperature control can be set for produce or fresh meat storage

o

Quick chill option chills foods and beverages in minutes

• Adjustable Humidity Zone™ drawers with precision ball-bearing glides

o

Humidity can be set high for leafy greens or low for fruits and vegetables with skins

o

Two in-the-door sealed dairy compartments with covers

o

Four patented adjustable aluminum door bins with tempered glass fronts

o

Top shelf provides quick chill-down area

• Freezer Compartment o

Adaptive defrost

o

Three wire shelves and two slide-out baskets

o

Three patented adjustable aluminum door bins with tempered glass fronts

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar for three minutes

• Adjustable door stops standard—90°, 110°, or 120° swing

• Sabbath Mode

*Plasmacluster is a registered trademark

of Sharp Corporation.

VCSB548/VISB548

Professional/Professional

DFSB548

Custom Front

Integrated

FINISH DETAILS FOR VCSB/VISB MODEL

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door fronts. Stainless steel upper grille, side trim, and handles (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, and side trim. Brass components have a durable protective coating for maintenance-free normal use.

ORDERING INSTRUCTIONS

First specify model number, and then color code (VCSB548SS). If ordering optional brass trim, specify code at end (VCSB548SSBR).

FINISH DETAILS FOR DFSB MODEL

• Handles not included—opt for custom handles, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for more information and additional specifications.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

-

3

/

1

6

”

(5

6

.

4

c

m

)

2

4

-

1

/

1

6

”

(6

2

.

7

c

m

)

7

5

-

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3

-1 9

/

3

2

”

(9

.

1

c

m

)

4

8

”

(

1

2

1

.

9

c

m

)

2

7

-

1

/4

”

(

6

9

.

2

c

m

)

4

7

”

(

1

9

.

4

c

m

)

8

2

-

3

/

4

”

(2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1

/

1

6

”

(2

1

3

.5

c

m

)

m

a

x

.

2

3

-

3

/

8

”

(

59

.

4

c

m

)

2

4

”

(

61

.

0

c

m

)

7

5

-

1

5

/

1

6

”

(

19

2

.

9

c

m

)

4

8

”

(

12

1

.

9

c

m

)

2

6

-

1

/

2

”

(

67

.

3

c

m

)

4

7”

(

119

.

4

c

m

)

8

2

-

3

/

4

”

(

21

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1/

1

6

”

(

21

3. 5

c

m

)

m

a

x

.

3

-

1

9/

3

2”

(

9. 1

c

m

)

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel and

handle kits.

LL MODELS

A

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCSB548/VISB548

Professional/Professional

Integrated

Overall width 48” (121.9 cm)

PROFESSIONAL PROFESSIONAL

Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 715 lbs. (321.8 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

INTEGRATED

VCSB548 VISB548

R E L E AS ED 3 / 1 / 09

2

3

-

1

3

/

1

6

”

(

6

0

.

5

c

m

)

2

4

-

3

/

4

”

(

6

2

.

9

c

m

)

7

5

-

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

4

8

”

(1

2

1

.

9

c

m

)

4

8

”

(1

2

1

.9

c

m

)

4

7

”

(

1

9

.

4

c

m

)

8

2

-

3

/

4

”

(2

1

0

.

2

c

m

)

M

i

n

.

to

8

4

-

1

/

1

6

”

(2

1

3

.5

c

m

)

m

a

x

.

V

a

r

i

e

s

3

-

1

/2

”

(

8

.

9

c

m

)

REFRIGERATION

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel and

handle kits.

LL MODELS

A

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFSB548

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 48” (121.9 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 23-3/16” (60.5 cm) To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 650 lbs. (292.5 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFSB548

R E L E AS ED 3 / 1 / 09

7-3/8”

(18.7 cm)

1-27/32”

(4.7 cm)

9-13/16”

(25.0 cm)

24-3/32” (61.2 cm)

39-15/16” (101.4cm)

41-27/32”

(106.3cm)

47”

(119.4cm)

48-11/32” (122.8cm)

10-21/32” (27.1cm)

1-27/32” (4.7cm)

14-5/8” (37.2cm)

51-7/16” (130.7cm)

50-3/16” (127.5cm)

48”

(121.9cm)

41-3/32” (104.4cm)

90°

110°

120°

90°

110°

120°

2-1/2” (6.4 cm)

Professional Integrated

41-27/32” (106.3 cm)

15-13/32” (39.1 cm)

11-9/16” (29.4 cm)

2-1/2”

(6.4 cm)

41-1/8” (104.4 cm)

39-15/16” (101.4 cm)

48-1/4”

(122.6 cm)

50-1/8”

(127.3 cm)

51-7/16” (130.7 cm)

2-31/32” (7.5 cm)

8-1/8”

(20.6 cm)

10-19/32” (26.3 cm)

24-23/32” (62.8 cm)

48”

(121.9cm)

47”

(119.4cm)

90°

110°

120°

Quiet Cool™ Built-In 48”W. Side-By-Side

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

Refrigerator/Freezer

PROFESSIONAL

VCSB548/VISB548

Professional/Professional

Integrated

DFSB548

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Door

Wall

1-13/16”

(4.6 cm)

space if 24” standard

c

abinet depth is used

3/4”

(1.9 cm) full end panel

24”

(61.0 cm) standard

cabinet

depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1-13/16”

(

4.6 cm)

s

pace if 24” standard

cabinet depth is used

Door

2

4”

(61.0 cm) standard cabinet depth

W

all

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

C

ountertop

o

verhang

Dimensions & Specifications

1-13/16”

(4.6 cm)

space if 24” standard

cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay cabinet door

CLEARANCE DIMENSIONS—PROFESSIONAL

REFRIGERATION

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 48”W. Side-By-Side

Door

Wall

1”

(2.5 cm)

i

f 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm) full end panel

25”

(63.5 cm)

Flush

Door

24”

(61.0 cm) standard cabinet depth

25”

(63.5 cm)

countertop

depth

W

all

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Door

2

4

”

(

6

1

.

0 c

m

)

s

tan

d

ar

d

c

ab

i

n

e

t

d

e

p

th

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

3/4”

(1.9 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Cabinet door

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED

TOP VIEW

REFRIGERATION

Refrigerator/Freezer

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

TOP VIEW

Overlapping cabinet doors

R E L E AS ED 3 / 1 / 09

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

4

7

-

1

/

2

”

m

i

n

.

(

1

2

0

.

7

c

m

)

t

o

4

7

-

3

/

4

”

m

a

x

.

(

1

2

1

.

3

c

m

)

P

r

o

f

e

s

i

o

n

a

l

4

8

”

(

1

2

1

.

9

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

ELECTRIC OUTLET LOCATION

WATER LINE ENTRY AREA

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

1

”

(

2

.

5

c

m

)

3

-

5

/

8

”

(

9.

2

c

m

)

O

p

t

i

on

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

nt

r

y

9

”

(

2

.

9

c

m

)

REFRIGERATION

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC/60 Hz; 15 amp dedicated circuit

• Maximum amp usage—9.9

• Estimated energy usage— 668 kWh/year

Installation Requirements

ACCESS REQUIREMENTS

VCSB548/VISB548

Professional/Professional

Integrated

DFSB548

Custom Front

See Custom Panels section for more information and additional specifications.

PLUMBING

• Inlet waterline requirements— 1/4”copper tubing

• 20 psi min.; 120 psi max.

*Custom front models fit flush in 25”-deep (63.5 cm)

Cutout width 47-1/2” (120.7 cm) min. to 48” (121.9 cm) 48” (121.9 cm)

Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

cabinet openings. They can be installed in standard 24”-deep openings. The door faces and top grille will protrude 3/4” (1.9 cm) into the room.

VCSB548 VISB548 DFSB548

47-3/4” (121.3 cm) max.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer

! Installation Notes & Accessories

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished, freestanding look; unit must still be secured to the wall

Kit includes one panel and installation hardware

•

Model Description Approx. ship wt. lbs. (kg)

SSPL2 Professional side panel left (VCSB) 45 (20.2)

P

SSPR2 Professional side panel right (VCSB) 45 (20.2)

P

SSPL2 Designer side panel left (VISB/DFSB) 45 (20.2)

D

SSPR2 Designer side panel right (VISB/DFSB) 45 (20.2)

D

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

SPHKDS Side panel hardware 3 (1.4)

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-48 48”W. top panel 24 (10.8)

Handle Kits

• For use with custom front refrigerator/freezers

• For use on locally supplied custom front panels

• Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products

• Kit includes two handles and installation hardware

Model Description Approx. ship wt. lbs. (kg)

PHK-DFSB5-SS Professional handles (Stainless Steel) 10 (4.5) PHK-DFSB5-BR Professional handles (Brass) 10 (4.5) HKFDS-SS Designer handles (Stainless Steel) 10 (4.5) HKFDS-BR Designer handles (Brass) 10 (4.5)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system and automatic ice maker

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 48”W. Side-By-Side

Standard Features & Accessories

All models include

• Total capacity—27.1 cu. ft. (767.0 L)

o

Refrigerator - 18.5 cu. ft.

o

Freezer - 8.6 cu. ft.

o 84”H./24”D.

• ProChill™ Temperature Management

System o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Exclusive Plasmacluster™* Ion Air

Purifier o

Eliminates airborne bacteria and mold spores

o

Removes odors

o

Enhances food preservation

o

Never needs replacing

• Refrigerator Compartment

o

Four adjustable tempered glass spillproof shelves

• Adjustable Cold Zone™ drawer with precision ball-bearing glides

o

Separate temperature control can be set for produce or fresh meat storage

o

Quick chill option chills foods and beverages in minutes

• Adjustable Humidity Zone™ drawers with precision ball-bearing glides

o

Humidity can be set high for leafy greens or low for fruits and vegetables with skins

• Two in-the-door sealed dairy compartments with covers

• Four patented adjustable aluminum door bins with tempered glass fronts

• Top-shelf provides quick chill-down area

• Freezer Compartment o

Adaptive defrost

o

Three wire shelves and two slide-out baskets

o

Three patented adjustable aluminum door bins with tempered glass fronts

REFRIGERATION

Refrigerator/Freezer with Dispenser

• Ice/Water Dispenser o

Through-the-door dispenser provides cubed ice, crushed ice and water in easy on-hand operation

o

Premium water filter provides cleaner water and ice supply by filtering bad tastes, odors, sediment and harmful contaminants.

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar for three minutes

• Adjustable door stops standard—90°, 110°, or 120° swing

• Sabbath Mode

*Plasmacluster is a registered trademark

of Sharp Corporation.

Model Options

VCSB548D/VISB548D

Professional/Professional

Integrated

FINISH DETAILS FOR VCSB/VISB MODEL

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door fronts. Stainless steel upper grille, side trim, and handles (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, and side trim. Brass components have a durable protective coating for maintenancefree normal use.

DFSB548D

Custom Front

FINISH DETAILS FOR DFSB MODEL

• Handles not included—opt for custom handles, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for more information and additional specifications.

ORDERING INSTRUCTIONS

First specify model number, and then color code (VCSB548DSS). If ordering optional brass trim, specify code at end (VCSB548DSSBR).

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

-

3

/

1

6

”

(

5

6

.

4

c

m

)

2

4

-

1

/

1

6

”

(

6

2

.

7

c

m

)

7

5

-

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3

-1 9

/

3

2

”

(9

.

1

c

m

)

4

8

”

(

1

2

1

.

9

c

m

)

2

7

-

1

/

4

”

(

6

9

.

2

c

m

)

4

7

”

(

1

9

.4

c

m

)

8

2

-

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

-

1

/

1

6

”

(

2

1

3

.5

c

m

)

m

a

x

.

2

3

-

3

/8

”

(

59

.

4

c

m

)

2

4

”

(

61

.

0

c

m

)

7

5

-

1

5

/

1

6

”

(

19

2

.

9

c

m

)

4

8

”

(

12

1

.

9

c

m

)

2

6

-

1

/

2

”

(

67

.

3

c

m

)

4

7”

(

119

.

4

c

m

)

8

2

-

3

/

4

”

(

2

1

0

.

2

c

m)

m

i

n

.

t

o

8

4

-

1

/

1

6

”

(

2

1

3. 5

c

m

)

m

a

x

.

3

-

1

9/

3

2”

(

9. 1

c

m

)

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer with Dispenser

Please see

!

Installation Notes &

Accessories

for important

information,

including panel, and

handle kits, and

water filters.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCSB548D/VISB548D

Professional/Professional

Integrated

Overall width 48” (121.9 cm)

PROFESSIONAL PROFESSIONAL

Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 735 lbs. (330.8 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

INTEGRATED

VCSB548D VISB548D

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

3

-

1

3

/

1

6

”

(6

0

.

5

c

m

)

2

4

-

3

/

4

”

(6

2

.

9

c

m

)

7

5

-

1

5

/

1

6

”

(1

9

2

.

9

c

m

)

4

8

”

(1

2

1

.

9

c

m

)

4

7

”

(1

1

9

.4

c

m

)

8

2

-

3

/

4

”

(

2

1

0

.

2

c

m

)

M

i

n

.

to

8

4

-

1

/

1

6

”

(

2

1

3

.5

c

m

)

m

a

x

.

V

a

r

i

e

s

3

-

1

/2

”

(

8

.

9

c

m)

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer with Dispenser

Please see

!

Installation Notes &

Accessories

for important

information,

including panel, and

handle kits, and

water filters.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFSB548D

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 48” (121.9 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 23-13/16” (60.5 cm) To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 675 lbs. (303.8 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFSB548D

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 48”W. Side-By-Side

41-27/32” (106.3 cm)

15-13/32” (39.1 cm)

11-9/16” (29.4 cm)

2-1/2”

(6.4 cm)

4

1-1/8”

(104.4 cm)

39-15/16” (101.4 cm)

48-1/4”

(122.6 cm)

50-1/8”

(127.3 cm)

51-7/16” (130.7 cm)

2-31/32” (7.5 cm)

8-1/8”

(20.6 cm)

10-19/32” (26.3 cm)

48”

(121.9cm)

47”

(119.4cm)

90°

110°

120°

24-23/32” (62.8 cm)

7-3/8”

(18.7 cm)

1-27/32”

(4.7 cm)

9-13/16”

(25.0 cm)

24-3/32” (61.2 cm)

39-15/16” (101.4cm)

41-27/32”

(106.3cm)

47”

(119.4cm)

48-11/32” (122.8cm)

10-21/32”

(27.1cm)

1-27/32” (4.7cm)

14-5/8” (37.2cm)

51-7/16” (130.7cm)

50-3/16” (127.5cm)

48”

(121.9cm)

41-3/32” (104.4cm)

90°

110°

120°

90°

110°

120°

2-1/2” (6.4 cm)

Professional Integrated

Refrigerator/Freezer with Dispenser

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

PROFESSIONAL

VCSB548D/VISB548D

Professional/Professional

Integrated

DFSB548D

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Door

Wall

1-13/16”

(4.6 cm)

s

pace if 24” standard

cabinet depth is used

3/4”

(1.9 cm) full end panel

24”

(61.0 cm) standard

cabinet

depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

Door

24”

(61.0 cm) standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Countertop overhang

Dimensions & Specifications

1-13/16”

(4.6 cm)

space if 24” standard

cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay cabinet door

CLEARANCE DIMENSIONS—PROFESSIONAL

TOP VIEW

REFRIGERATION

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer with Dispenser

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

TOP VIEW

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 48”W. Side-By-Side

Door

Wall

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm) full end panel

25”

(63.5 cm)

Flush

Door

24”

(

61.0 cm)

standard

c

abinet

d

epth

25”

(63.5 cm) countertop depth

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Door

2

4

”

(

6

1

.

0 c

m

)

s

tan

d

ar

d

c

a

b

i

n

e

t

d

e

p

t

h

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

3/4”

(1.9 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Cabinet door

Refrigerator/Freezer with Dispenser

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED

TOP VIEW

REFRIGERATION

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

TOP VIEW

Overlapping cabinet doors

R E L E AS ED 3 / 1 / 09

REFRIGERATION

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

cm

)

9

”

(

2

.

9

cm

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

1

”

(

2

.

5

c

m

)

3-

5

/

8”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

9

”

(

22

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6.

4

c

m

)

8

2-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5 c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

4

7

-

1

/

2

”

m

i

n

.

(

1

2

0

.

7

c

m

)

t

o

4

7

-

3

/

4

”

m

a

x

.

(

1

2

1

.

3

c

m

)

P

r

o

f

e

s

io

n

a

l

4

8

”

(

1

2

1

.

9

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer with Dispenser

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC/60 Hz; 15 amp dedicated circuit

• Maximum amp usage—11.5

• Estimated energy usage— 727 kWh/year

Installation Requirements

ACCESS REQUIREMENTS

VCSB548D/VISB548D

Professional/Professional

Integrated

DFSB548D

Custom Front

See Custom Panels section for more information and additional specifications.

PLUMBING

• Inlet waterline requirements— 1/4” copper tubing

• 35 psi min.; 120 psi max.

*Custom front models fit flush in 25”-deep (63.5 cm)

cabinet openings. They can be installed in standard 24”-deep openings. The door faces and top grille

Cutout width 47-1/2” (120.7 cm) min. to 48” (121.9 cm) 48” (121.9 cm)

Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

will protrude 3/4” (1.9 cm) into the room.

VCSB548D VISB548D DFSB548D

47-3/4” (121.3 cm) max.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

ELECTRIC OUTLET LOCATION

WATERLINE ENTRY AREA

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 48”W. Side-By-Side

Refrigerator/Freezer with Dispenser

! Installation Notes & Accessories

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished, freestanding look; unit must still be secured to the wall

Kit includes one panel and installation hardware

•

Model Description Approx. ship wt. lbs. (kg)

PSSPL2 Professional side panel left (VSCB) 45 (20.2) PSSPR2 Professional side panel right (VSCB) 45 (20.2)

SSPL2 Designer side panel left (VISB/DFSB) 45 (20.2)

D

SSPR2 Designer side panel right (VISB/DFSB) 45 (20.2)

D

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

PHKDS Side panel hardware 3 (1.4)

S

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-48 48”W. top panel 24 (10.8)

Handle Kits

• For use with custom front refrigerator/freezers

• For use on locally supplied custom front panels

• Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products

• Kit includes two handles and installation hardware

Model Description Approx. ship wt. lbs. (kg)

PHK-DFSB5-SS Professional handles (Stainless Steel) 10 (4.5) PHK-DFSB5-BR Professional handles (Brass) 10 (4.5) HKFDS-SS Designer handles (Stainless Steel) 10 (4.5) HKFDS-BR Designer handles (Brass) 10 (4.5)

Replacement Water Filter

• Reduces sediment, taste, and odor

• Reduces cysts, particulates, turbidity, lead, chlorine, atrazine, and lindane

• NSF-certified

• Ready to install—no assembly required

• Replacement recommended every nine months

Model Description Approx. ship wt. lbs. (kg)

RWF-DISP Replacement water filter 5 (2.3)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system and automatic ice maker

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 30”W. All Refrigerator

Standard Features & Accessories

All models include

• Capacity—18.2 cu. ft. (515.1 L)

o 84”H./24”D.

• ProChill™ Temperature Management

System o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Adjustable Cold Zone™ drawer with

precision ball-bearing glides o

Separate temperature control can be set for produce or fresh meat storage

o

Quick chill option chills foods and beverages in minutes

• Adjustable Humidity Zone™ drawers with precision ball-bearing glides

o

Humidity can be set high for leafy greens or low for fruits and vegetables with skins

• Four adjustable, full-width, tempered glass spillproof shelves

• Two conveniently located deli drawers with full-extension precision ballbearing glides

• Two in-the-door sealed dairy compartments with covers

• Four patented adjustable aluminum door bins with tempered glass fronts

• Top-shelf provides quick chill-down area

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

REFRIGERATION

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar for three minutes

• Adjustable door stops standard—90°, 110°, or 120° swing

• Sabbath Mode

• For installation of two units side-byside, a separate grille kit accessory must be purchased

• Must be ordered right or left hinge. (As you face unit, RIGHT has hinge on right side and handle on left side; LEFT has hinge on left side and handle on right side.)

Model Options

VCRB530/VIRB530

Professional/Professional Integrated

FINISH DETAILS FOR VCRB/VIRB MODELS

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door front. Stainless steel upper grille, side trim, and handle (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, and side trim. Brass components have a durable protective coating for maintenancefree normal use.

DFRB530

Custom Front

FINISH DETAILS FOR DFRB MODEL

• Handle not included—opt for custom handle, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for more information and additional specifications.

ORDERING INSTRUCTIONS

First specify model number, followed by hinge preference (“R” for right or “L” for left), and then color code (VCRB530RSS). If ordering optional brass trim, specify code at end (VCRB530RSSBR).

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

4

–

1

/

1

6

”

(

6

2

.

7

c

m

)

2

9

”

(

7

3

.

7

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3–

1

9

/

3

2

”

(

9

.

1

c

m

)

3

0

”

(

7

6

.

2

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

0

–

3

/

4

”

(

5

2

.

7

c

m

)

2

–

3

/

1

6

”

(

56

.

4

c

m

)

2

7

–

1

/

4

”

(

6

9

.

2

c

m

)

2

6

-

1

/

2

”

(

6

7

.

3

c

m)

2

9

”

(

7

3

.

7

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3–

1

9

/

3

2

”

(

9

.

1

c

m

)

3

0

”

(

7

6

.

2

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

3

-

3

/

8

”

(

5

9

.

4

c

m

)

2

4

”

(

61

.

0

c

m

)

2

6

–

1

/

2

”

(

6

7

.

3

c

m

)

Quiet Cool™ Built-In 30”W. All Refrigerator

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, trim, and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCRB530/VIRB530

Professional/

Professional Integrated

PROFESSIONAL PROFESSIONAL

Overall width 30” (76.2 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 425 lbs. (193.2 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

INTEGRATED

VCRB530 VIRB5530

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

4

”

(

6

1

.

0

c

m)

2

9

”

(

7

3

.

7

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3

–

1

/

2

”

(

8

.

9

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

0

–

3

/

4

”

(

5

2

.

7

c

m

)

2

3

–

3

/

8

”

(

59

.

4

c

m

)

2

6

”

(

6

.

0

c

m

)

3

0

”

(

7

6

.

2

c

m

)

Quiet Cool™ Built-In 30”W. All Refrigerator

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, trim, and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFRB530

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 30” (76.2 cm)

Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim 23-13/16” (60.5 cm)

To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 425 lbs. (193.2 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFRB530

R E L E AS ED 3 / 1 / 09

22--11//22””

((66..44 ccmm))

1111--77//88””

((3300..22 ccmm))

1155--2277//3322” ((4400..22 ccmm))

33--11//3322”” ((77..77 ccmm))

112200..00

00

111100..00

00

9900..00

00

””

5522--33//88”” ((113333..00 ccmm))

2244--1111//1166”” ((6622..77 ccmm))

5511””

((112299..55 ccmm))

4499--11//1166””

((112244..66 ccmm

)

3300””

((7766..22 ccmm))

2299””

((7733..77 ccmm))

Quiet Cool™ Built-In 30”W. All Refrigerator

22--11//1166”” ((55..22 ccmm))

1100--3311//3322””

((22

77..99 ccmm))

1155--33//3322”” ((3388..33 ccmm))

11--2277//3322”” ((44..77 ccmm))

112200..00

00

111100..00

00

9900..00

00

5522--1111//3322”” ((113322..99 ccmm))

5511””

((112299..55 ccmm))

4499--11//1166””

((112244..66 ccmm

)

2244””

6611..00 ccmm))

3300””

((7766..22 ccmm))

2299””

((7733..77 ccmm))

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

VCRB530/VIRB530

Professional/

Professional Integrated

PROFESSIONAL

DFRB530

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 30”W. All Refrigerator

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay

cabinet door

Door

Wall

1-13/16”

(4.6 cm)

space if 24” standard

c

abinet depth is used

3/4”

(1.9 cm) full end panel

24”

(61.0 cm) standard

cabinet

depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1-13/16”

(4.6 cm) space if 24” standard c

abinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(

1.9 cm)

f

ull end panel

2-1/2”

(6.4 cm) offset

C

ountertop

o

verhang

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL

REFRIGERATION

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 30”W. All Refrigerator

Door

Wall

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm)

full end panel

25”

(63.5 cm)

Flush

Door

2

4”

(61.0 cm) standard cabinet depth

25”

(63.5 cm)

countertop

depth

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Door

2

4

”

(

6

1

.

0 c

m

)

s

ta

n

d

ar

d

c

a

b

i

n

e

t

d

e

p

th

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depthis used

Flush

Cabinet door

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED

REFRIGERATION

TOP VIEW

Overlapping cabinet doors

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

cm)

73-

3/

8

”

(

1

8

6

.

4

cm

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

2

9

-

1

/

2

”

(

7

4

.9

c

m

)

m

i

n

.

t

o

2

9

-

3

/

4

”

(

7

5

.

6

c

m

)

m

a

x

.

P

r

o

f

e

s

i

o

n

a

l

3

0

”

(

7

6

.

2

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

on

t

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

9

”

(

2

.

9

c

m

)

Quiet Cool™ Built-In 30”W. All Refrigerator

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC/60 Hz; 15 amp dedicated circuit

• Maximum amp usage—5.7

• Estimated energy usage— 404 kWh/year

Installation Requirements

ACCESS REQUIREMENTS – Single Installation

VCRB530/VIRB530

Professional/

Professional Integrated

DFRB530

Custom Front

See Custom Panels section for more information and additional specifications.

PLUMBING

Not applicable

*Custom front models fit flush in 25”-deep (63.5 cm) cabinet openings. They can be installed in standard 24”deep openings. The door faces and top grille will protrude 3/4” (1.9 cm) into the room.

VCRB530 VIRB530 DFRB530

Cutout width 29-1/2” (74.9 cm) min. to 30” (76.2 cm) 30” (76.2 cm)

29-3/4” (75.6 cm) max. Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

ELECTRIC OUTLET LOCATION

R E L E AS ED 3 / 1 / 09

9”

(

2

.

9

c

m

)

7

3-

3

/

8

”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

6

5

-

1

/

2

”

P

r

o

f

e

s

i

o

n

a

l

(

1

6

.

4

c

m

)

6

”

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

(

1

6

7

.

6

c

m

)

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l f

l

o

r

w

a

t

e

r

l

i

ne

en

t

r

y

1

”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

r

d

i

n

s

t

a

l

a

t

i

o

n

6

”

(

1

5

.

2

cm

)

9

”

(

2

.

9

c

m

)

9”

(

2

.

9

c

m

)

7

3

-

3

/

8”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

ni

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

5

9

-

1

/

2

”

P

r

o

f

e

s

i

o

n

a

l

(

1

5

1

.

1

c

m

)

6

0

”

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

(

1

5

2

.

4

c

m

)

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

1”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

rd

i

n

s

t

a

l

a

t

i

o

n

6

”

(

1

5

.

2

cm

)

9

”

(

2

.

9

cm

)

Installation Requirements

ACCESS REQUIREMENTS – Dual Installation

REFRIGERATION

Quiet Cool™ Built-In 30”W. All Refrigerator

ELECTRIC OUTLET LOCATION

30”W./30”W. REFRIGERATOR/ FREEZER COMBINATION

WATER LINE ENTRY AREA

Note: cutout opening shown with All Freezer model on left.

Reverse water line entry if All Freezer model is on right

ELECTRIC OUTLET LOCATION

30”W./36”W. REFRIGERATOR/ FREEZER COMBINATION

*Custom front models fit flush in 25”-deep (63.5 cm) cabinet openings. They can be installed in standard 24”-deep openings. The

door faces and top grille will protrude 3/4” (1.9 cm) into the room.

Cutout width 59-1/2” (151.1 cm) 60” (152.4 cm) 60” (152.4 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

Cutout width 65-1/2” (166.4 cm) 66” (167.6 cm) 66” (167.6 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

VCRB530/VCFB530 VIRB530/VIFB530 DFRB530/DFFB530

VCRB530/VCFB536 VIRB530/VIFB536 DFRB530/DFFB536

WATER LINE ENTRY AREA

Note: cutout opening shown with All Freezer model on left.

Reverse water line entry if All Freezer model is on right

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 30”W. All Refrigerator

! Installation Notes & Accessories

Side Panel Kits

• Stainless Steel (SS) Panels provide finished, freestanding look; unit must still be secured to the wall

•

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

SSPL2 Professional side panel left (VCRB) 45 (20.2)

P

SSPR2 Professional side panel right (VCRB) 45 (20.2)

P

SSPL2 Designer side panel left (VIRB/DFRB) 45 (20.2)

D

SSPR2 Designer side panel right (VIRB/DFRB) 45 (20.2)

D

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

SPHKDS Side panel hardware 3 (1.4)

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-30 30”W. top panel 21 (9.5)

Top Grille Kits

• Stainless Steel (SS)

• 60”W. top grille kit—for use with installation of two 30”W. all refrigerators/all freezers side-by-side

• 66”W. top grille kit—for use with installation of one 30”W. and one 36”W. all refrigerators/all freezers side-by-side

• Grille creates a single unit look

• Kit includes one full-length grille, center cabinet trim connector, and installation hardware

Model Description Approx. ship wt. lbs. (kg)

PGK60-SS Professional 60”W. grille (for two VCRB/VCFB units) 21 (9.5) PGK66-SS Professional 66”W. grille (for two VCRB/VCFB units) 23 (10.4) IGK60-SS Professional Integrated 60”W. grille (for two VIRB/VIFB units) 21 (9.5) IGK66-SS Professional Integrated 66”W. grille (for two VIRB/VIFB units) 23 (10.4) DGK60-SS Designer 60”W. grille (for two DFRB/DFFB units) 21 (9.5) DGK66-SS Designer 66”W. grille (for two DFRB/DFFB units) 23 (10.4)

Center Trim Kit

• Stainless Steel (SS)

• Kit includes center cabinet trim connector to install two custom front units with wood top grille

Model Description Approx. ship wt. lbs. (kg)

FCTK-SS Center trim 5 (2.3)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 30”W. All Refrigerator

Handle Kits

• For use with custom front refrigerators

• For use on locally supplied custom front panels

Handles allow refrigerators/freezers with custom front panel to coordinate with other Professional and Designer products

•

• Kit includes handle(s) and installation hardware

Model Description Approx. ship wt. lbs. (kg)

HK28-SS Professional one handle (Stainless Steel) 7 (3.2)

P

HK28-BR Professional one handle (Brass) 7 (3.2)

P

HK25-SS Designer one handle (Stainless Steel) 7 (3.2)

D

HK25-BR Designer one handle (Brass) 7 (3.2)

D

HKDFSB5-SS Professional two handles (Stainless Steel) 10 (4.5)

P PHKDFSB5-BR Professional two handles (Brass) 10 (4.5) HKFDS-SS Designer two handles (Stainless Steel) 10 (4.5) HKFDS-BR Designer two handles (Brass) 10 (4.5)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. All Refrigerator

Standard Features & Accessories

All models include

• Capacity—22.8 cu. ft. (645.2 L)

o 84”H./24”D.

• ProChill™ Temperature Management

System o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Adjustable Cold Zone™ drawer with

precision ball-bearing glides o

Separate temperature control can be set for produce or fresh meat storage

o

Quick chill option chills foods and beverages in minutes

• Adjustable Humidity Zone™ drawers with precision ball-bearing glides

o

Humidity can be set high for leafy greens or low for fruits and vegetables with skins

• Six adjustable tempered glass spillproof shelves (four half-width, two full-width)

• Two conveniently located deli drawers with full-extension precision ballbearing glides

• Two in-the-door sealed dairy compartments with covers

• Five patented adjustable aluminum door bins with tempered glass fronts (two half-width, three full-width)

• Top-shelf provides quick chill-down area

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

REFRIGERATION

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar for three minutes

• Adjustable door stops standard—90°, 110°, or 120° swing

• Sabbath Mode

• For installation of two units side-byside, a separate grille kit accessory must be purchased

• Must be ordered right or left hinge. (As you face unit, RIGHT has hinge on right side and handle on left side; LEFT has hinge on left side and handle on right side.)

Model Options

VCRB536/VIRB536

Professional/Professional Integrated

FINISH DETAILS FOR VCRB/VIRB MODELS

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door front. Stainless steel upper grille, side trim, and handle (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, and side trim. Brass components have a durable protective coating for maintenance-free normal use.

DFRB536

Custom Front

FINISH DETAILS FOR DFRB MODEL

• Handle not included—opt for custom handle, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for more information and additional specifications.

ORDERING INSTRUCTIONS

First specify model number, followed by hinge preference (“R” for right or “L” for left), and then color code (VCRB536RSS). If ordering optional brass trim, specify code at end (VCRB536RSSBR).

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

4

–

1

/

1

6

”

(

6

2

.

7

c

m)

3

5

”

(

8

.

9

c

m

)

7

5

–1

5

/1

6

”

(

1

9

2

.

9

c

m

)

3–

1

9

/

3

2

”

(

9

.

1

c

m

)

3

6

”

(

9

1

.

5

c

m

)

2

7

–

1

/

4

”

(

6

9

.

2

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

0

–

3

/

4

”

(

5

2

.

7

c

m

)

2

–

3

/

1

6

”

(

56

.

4

c

m

)

2

6

-

1

/

2

”

(

6

7

.

3

c

m)

3

5

”

(

8

.

9

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3–

1

9

/

3

2

”

(

9

.

1

c

m

)

3

6

”

(

9

1

.

5

c

m

)

2

6

–

1

/

2

”

(

6

7

.

3

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

3

-

3

/

8

”

(

5

9

.

4

c

m

)

2

4

”

(

61

.

0

c

m

)

Quiet Cool™ Built-In 36”W. All Refrigerator

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, trim, and

handle kits.

LL MODELS

A

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCRB536/VIRB536

Professional/

Professional Integrated

PROFESSIONAL PROFESSIONAL

Overall width 36” (91.5 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 500 lbs. (227.3 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

INTEGRATED

VCRB536 VIRB536

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

4

”

(

6

1

.

0

c

m)

3

5

”

(

8

.

9

c

m

)

7

5

–1

5

/1

6

”

(

1

9

2

.

9

c

m

)

3

–

1

/

2

”

(

8

.

9

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

0

–

3

/

4

”

(

5

2

.

7

c

m

)

2

3

–

3

/

8

”

(

59

.

4

c

m

)

2

6

”

(

6

.

0

c

m

)

3

6

”

(

9

1

.

5

c

m

)

Quiet Cool™ Built-In 36”W. All Refrigerator

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, trim, and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFRB536

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 36” (91.5 cm)

Overall height (from bottom) 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim 23-13/16” (60.5 cm)

To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 500 lbs. (227.3 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFRB536

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. All Refrigerator

2244””

((6611..00 ccmm))

3366””

((9911..44 ccmm))

3355””

((8888..99 ccmm))

112200..00

00

111100..00

00

9900..00

00

22--11//1166”” ((55..22 ccmm))

5588--33//88”” ((114488..33 ccmm))

5566--1111//1166”” ((114444..00 ccmm))

5544--99//3322””

((113377..99 ccmm

)

1133--11//88””

(

3333..33 ccmm))

1188--33//1166”” ((4466..22 ccmm))

11--2277//3322”” ((44..77 ccmm))

22--11//22””

((66..44 ccmm))

5588--1111//3322”” ((114488..22 ccmm))

2244--1111//1166”” (

(6622..77 ccmm))

5566--55//88””

((114433..88 ccmm))

5544--77//3322””

((113377..77 ccmm

)

1144””

((3355..66 ccmm))

3366””

(

(9911..44 ccmm))

3355””

((8888..99 ccmm))

1188--2299//3322”” ((4488..00 ccmm))

33--11//3322”” ((77..77 ccmm))

112200..00

00

111100..00

0

9900..00

00

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

VCRB536/VIRB536

Professional/

Professional Integrated

PROFESSIONAL

DFRB536

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. All Refrigerator

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay

cabinet door

Door

Wall

1-13/16”

(4.6 cm)

space if 24” standard

c

abinet depth is used

3/4”

(1.9 cm) full end panel

24”

(61.0 cm) standard

cabinet

depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1-13/16”

(4.6 cm)

space if 24” standard

cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3

/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Countertop

overhang

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL

TOP VIEW

REFRIGERATION

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

TOP VIEW

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. All Refrigerator

Door

2

4

”

(

6

1

.

0 c

m

)

s

tan

d

ar

d

c

a

b

i

n

e

t

d

e

p

th

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Cabinet door

Door

Wall

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm) full end panel

25”

(63.5 cm)

Flush

Door

24”

(61.0 cm) standard

cabinet depth

25”

(63.5 cm)

countertop

depth

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED

REFRIGERATION

TOP VIEW

Overlapping cabinet doors

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

9

”

(

2

.

9

c

m)

73-

3/

8”

(

18

6

.

4

c

m)

8

2

-

7

/8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

3

5

-

1

/

2

”

(

9

0

.

2

c

m

)

m

i

n

.

t

o

3

5

-

3

/

4

”

(

9

0

.

8

c

m

)

m

a

x

.

P

r

o

f

e

s

i

o

n

a

l

3

6

”

(

9

1

.

5

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

on

t

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

Quiet Cool™ Built-In 36”W. All Refrigerator

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC/60 Hz; 15 amp dedicated circuit

• Maximum amp usage—6.5

• Estimated energy usage— 449 kWh/year

Installation Requirements

ACCESS REQUIREMENTS – Single Installation

VCRB536/VIRB536

Professional/

Professional Integrated

DFRB536

Custom Front

See Custom Panels section for more information and additional specifications.

PLUMBING

Not applicable

*Custom front models fit flush in 25”-deep (63.5 cm) cabinet openings. They can be installed in standard 24”-

deep openings. The door faces and top grille will protrude 3/4” (1.9 cm) into the room.

VCRB536 VIRB536 DFRB536

Cutout width 35-1/2” (90.2 cm) min. to 36” (91.5 cm) 36” (91.5 cm)

35-3/4” (90.8 cm) max. Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

ELECTRIC OUTLET LOCATION

R E L E AS ED 3 / 1 / 09

9”

(

2

.

9

c

m

)

7

3

-

3/

8

”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

7

1

-

1

/

2

”

P

r

o

f

e

s

i

o

n

a

l

(

1

8

1

.

6

c

m

)

7

2

”

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

(

1

8

1

.

6

c

m

)

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

1

”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

r

d

i

n

s

t

a

l

a

t

i

o

n

6

”

(

1

5

.

2

cm

)

9

”

(

2

.

9

c

m

)

Quiet Cool™ Built-In 36”W. All Refrigerator

9”

(

2

.

9

c

m

)

7

3

-

3

/

8”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

ni

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

6

5

-

1

/

2

”

P

r

o

f

e

s

i

o

n

a

l

(

1

6

.

4

c

m

)

6

”

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

(

1

6

7

.

6

c

m

)

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

1

”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

rd

i

n

s

t

a

l

a

t

i

o

n

6

”

(

1

5

.

2

cm

)

9

”

(

2

.

9

cm

)

Installation Requirements

ACCESS REQUIREMENTS – Dual Installation

36”/30” REFRIGERATOR/ FREEZER COMBINATION

REFRIGERATION

ELECTRIC OUTLET LOCATION

WATER LINE ENTRY AREA

Note: cutout opening shown with All Freezer model on left.

Reverse water line entry if All Freezer model is on right

ELECTRIC OUTLET LOCATION

36”/36” REFRIGERATOR/ FREEZER COMBINATION

*Custom front models fit flush in 25”-deep (63.5 cm) cabinet openings. They can be installed in standard 24”-deep openings. The

door faces and top grille will protrude 3/4” (1.9 cm) into the room.

Cutout width 65-1/2” (166.4 cm) 66” (167.6 cm) 66” (167.6 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

Cutout width 71-1/2” (181.6 cm) 72” (182.9 cm) 72” (182.9 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

VCRB536/VCFB530 VIRB536/VIFB530 DFRB536/DFFB530

VCRB536/VCFB536 VIRB536/VIFB536 DFRB536/DFFB536

WATER LINE ENTRY AREA

Note: cutout opening shown with All Freezer model on left.

Reverse water line entry if All Freezer model is on right

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 36”W. All Refrigerator

! Installation Notes & Accessories

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished, freestanding look; unit must still be secured to the wall Kit includes one panel and installation hardware

•

Model Description Approx. ship wt. lbs. (kg)

PSSPL2 Professional side panel left (VCRB) 45 (20.2) PSSPR2 Professional side panel right (VCRB) 45 (20.2) DSSPL2 Designer side panel left (VIRB/DFRB) 45 (20.2) DSSPR2 Designer side panel right (VIRB/DFRB) 45 (20.2)

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

PHKDS Side panel hardware 3 (1.4)

S

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-36 36”W. top panel 22 (10.0)

Top Grille Kits

• Stainless Steel (SS)

• 66”W. top grille kit—for use with installation of one 36”W. and one 30”W. all refrigerators/all freezers side-by-side

• 72”W. top grille kit—for use with installation of two 36”W. all refrigerators/all freezers side-by-side

• Grille creates a single unit look

• Kit includes one full-length grille, center cabinet trim connector, and all installation hardware

Model Description Approx. ship wt. lbs. (kg)

PGK66-SS Professional 66”W. grille (for two VCRB/VCFB units) 23 (10.4) PGK72-SS Professional 72”W. grille (for two VCRB/VCFB units) 25 (11.3) IGK66-SS Professional Integrated 66”W. grille (for two VIRB/VIFB units) 23 (10.4) IGK72-SS Professional Integrated 72”W. grille (for two VIRB/VIFB units) 25 (11.3) DGK66-SS Designer 66”W. grille (for two DFRB/DFFB units) 23 (10.4) DGK72-SS Designer 72”W. grille (for two DFRB/DFFB units) 25 (11.3)

Center Trim Kit

• Stainless Steel (SS)

• Kit includes cabinet trim connector to install two custom front units with wood top grille

Model Description Approx. ship wt. lbs. (kg)

FCTK-SS Center trim 5 (2.3)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 36”W. All Refrigerator

Handle Kits

• For use with custom front refrigerators

• For use on locally supplied custom front panels Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products

•

• Kit includes handle(s) and installation hardware

Model Description Approx. ship wt. lbs. (kg)

PHK28-SS Professional one handle (Stainless Steel) 7 (3.2) PHK28-BR Professional one handle (Brass) 7 (3.2) DHK25-SS Designer one handle (Stainless Steel) 7 (3.2) DHK25-BR Designer one handle Brass) 7 (3.2) PHKDFSB5-SS Professional two handles Stainless Steel) 10 (4.5) PHKDFSB5-SS Professional two handles (Brass) 10 (4.5) HKFDS-SS Designer two handles (Stainless Steel) 10 (4.5) HKFDS-BR Designer two handles (Brass) 10 (4.5)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system and automatic ice maker

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser, dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

* For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 30”W. All Freezer

Standard Features & Accessories

All models include

• Capacity—15.9 cu. ft. (450.0 L)

o 84”H./24”D.

• ProChill™ Temperature Management

System o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Six adjustable half-width wire shelves

• One full-width metal shelf

• Two full-width slide-out wire baskets

with tempered glass fronts

• Factory-installed automatic ice maker

• One full-width ice storage drawer with two separate metal ice bins

• Full-extension precision ball-bearing glides on all baskets and drawers

• Three patented adjustable aluminum door bins with tempered glass fronts

• Adaptive defrost

• All-metal freezer interior

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar for three minutes

Model Options

REFRIGERATION

• Adjustable door stops standard—90°, 110°, or 120° swing

• Sabbath Mode

• For installation of two units side-byside, a separate grille kit accessory must be purchased

• Must be ordered right or left hinge. (As you face unit, RIGHT has hinge on right side and handle on left side; LEFT has hinge on left side and handle on right side.)

VCFB530/VIFB530

Professional/Professional Integrated

FINISH DETAILS FOR VCFB/VIFB MODELS

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door front. Stainless steel upper grille, side trim, and handle (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, and side trim. Brass components have a durable protective coating for maintenance-free normal use.

ORDERING INSTRUCTIONS

First specify model number, followed by hinge preference (“R” for right or “L” for left), and then color code (VCFB530RSS). If ordering optional brass trim, specify code at end (VCFB530RSSBR).

FINISH DETAILS FOR DFFB MODEL

• Handle not included—opt for custom handle, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for more information and additional specifications.

DFFB530

Custom Front

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

4

–

1

/

1

6

”

(

6

2

.

7

c

m)

2

9

”

(

7

3

.

7

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3

–

1

9

/

3

2

”

(

9

.

1

c

m

)

3

0

”

(

7

6

.

2

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

0

–

3

/

4

”

(

5

2

.

7

c

m

)

2

–

3

/

1

6

”

(

5

6

.

4

c

m

)

2

7

–

1

/

4

”

(

6

9

.

2

c

m

)

2

6

-

1

/

2

”

(

6

7

.

3

c

m)

2

9

”

(

7

3

.

7

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3–

1

9

/

3

2

”

(

9

.

1

c

m

)

3

0

”

(

7

6

.

2

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

3

-

3

/

8

”

(

5

9

.

4

cm

)

2

4

”

(

61

.

0

c

m

)

2

6

–

1

/

2

”

(

6

7

.

3

c

m

)

Quiet Cool™ Built-In 30”W. All Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, trim, and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCFB530/VIFB530

Professional/

Professional Integrated

PROFESSIONAL

Overall width 30” (76.2 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 530 lbs. (238.5 kg) 530 lbs. (238.5 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

PROFESSIONAL INTEGRATED

VCFB530 VIFB530

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

4

”

(

6

1

.

0

c

m)

2

9

”

(

7

3

.

7

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3

–

1

/

2

”

(

8

.

9

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

0

–

3

/

4

”

(

5

2

.

7

c

m

)

2

3

–

3

/

8

”

(

59

.

4

c

m

)

2

6

”

(

6

.

0

c

m

)

3

0

”

(

7

6

.

2

c

m

)

Quiet Cool™ Built-In 30”W. All Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, trim, and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFFB530

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 30” (76.2 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 23-13/16” (60.5 cm) To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 490 lbs. (220.5 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFFB530

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 30”W. All Freezer

22--11//22””

((66..44 ccmm))

5522--33//88”” ((113333..00 ccmm))

2244--1111//1166”” ((6622..77 ccmm))

5511””

((112299..55 ccmm))

4

499--11//1166””

((112244..66 ccmm

)

1111--77//88””

((3300..22 ccmm))

3300””

((7766..22 ccmm))

2299””

(

(7733..77 ccmm))

1155--2277//3322”” ((4400..22 ccmm))

3

3--11//3322””

((77..77 ccmm))

112200..00

00

111100..00

00

9900..00

00

””

))

22--11//1166””

((55..22 ccmm))

2244””

((6611..00 ccmm))

3300””

((7766..22 ccmm))

2299””

((7733..77 ccmm))

5522--1111//3322 ((113322..99 ccmm

5511””

((112299..55 ccmm))

4499--11//1166””

((112244..66 ccmm

)

1100--3311//3322””

((2277..99 ccmm))

1155--33//3322”” ((3388..33 ccmm))

11--2277//3322”” ((44..77 ccmm))

112200..00

00

111100..00

00

9900..00

00

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

VCFB530/VIFB530

Professional/

Professional Integrated

PROFESSIONAL

DFFB530

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay

cabinet door

Door

Wall

1-13/16”

(4.6 cm)

space if 24” standard

cabinet depth is used

3/4”

(1.9 cm) full end panel

24”

(61.0 cm) standard

c

abinet

depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

D

oor

24”

(61.0 cm)

standard cabinet depth

W

all

3/4”

(

1.9 cm)

full end panel

2

-1/2”

(6.4 cm) offset

Countertop overhang

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL

REFRIGERATION

Quiet Cool™ Built-In 30”W. All Freezer

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 30”W. All Freezer

Door

2

4

”

(

6

1

.

0 c

m

)

s

tan

d

ar

d

c

a

b

i

n

e

t

d

e

p

th

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depthis used

Flush

Cabinet door

Door

Wall

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm)

full end panel

25”

(63.5 cm)

Flush

D

oor

2

4”

(61.0 cm) standard

cabinet

depth

25”

(63.5 cm) countertop depth

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED

REFRIGERATION

TOP VIEW

Overlapping cabinet doors

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.3

c

m

)

1

”

(

2

.

5

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

9

”

(

2

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

2

9

-

1

/

2

”

(

7

4

.

9

c

m

)

m

i

n

.

t

o

2

9

-

3

/

4

”

(

7

5

.

6

c

m

)

m

a

x

.

P

r

o

f

e

s

i

o

n

a

l

3

0

”

(

7

6

.

2

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

REFRIGERATION

Quiet Cool™ Built-In 30”W. All Freezer

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC/60 Hz; 15 amp dedicated circuit

• Maximum amp usage—9.1

• Estimated energy usage— 601 kWh/year

Installation Requirements

ACCESS REQUIREMENTS – Single Installation

VCFB530/VIFB530

Professional/

Professional Integrated

DFFB530

Custom Front

See Custom Panels section for more information and additional specifications.

ELECTRIC OUTLET LOCATION

PLUMBING

• Inlet waterline requirements— 1/4”copper tubing

• 20 psi min.; 120 psi max.

*Custom front models fit flush in 25”-deep (63.5 cm)

cabinet openings. They can be installed in standard 24”-deep openings. The door faces and top grille

Cutout width 29-1/2” (74.9 cm) min. to 30” (76.2 cm) 30” (76.2 cm)

Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

will protrude 3/4” (1.9 cm) into the room.

VCFB530 VIFB530 DFFB530

29-3/4” (75.6 cm) max.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

9”

(

2

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

) m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

6

5

-

1

/

2

”

P

r

o

f

e

s

i

o

n

a

l

(

1

6

.

4

c

m

)

6

”

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

(

1

6

7

.

6

c

m

)

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

cm

)

O

p

t

i

o

n

a

l f

l

o

r

w

a

t

e

r

l

i

ne

en

t

r

y

1

”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

r

d

i

n

s

t

a

l

a

t

i

o

n

6”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

9”

(

2

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

ni

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

5

9

-

1

/

2

”

P

r

o

f

e

s

i

o

n

a

l

(

1

5

1

.

1

c

m

)

6

0

”

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

(

1

5

2

.

4

c

m

)

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

1”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

r

d

i

n

s

t

a

l

a

t

i

o

n

6

”

(

1

5

.

2

cm

)

9

”

(

2

.

9

cm

)

Installation Requirements

ACCESS REQUIREMENTS – Dual Installation

REFRIGERATION

Quiet Cool™ Built-In 30”W. All Freezer

ELECTRIC OUTLET LOCATION

30”/30” FREEZER/ REFRIGERATOR COMBINATION

WATER LINE ENTRY AREA

Note: cutout opening shown with All Freezer model on left.

Reverse water line entry if All Freezer model is on right

ELECTRIC OUTLET LOCATION

30”/36” FREEZER/ REFRIGERATOR COMBINATION

*Custom front models fit flush in 25”-deep (63.5 cm) cabinet openings. They can be installed in standard 24”-deep openings. The

door faces and top grille will protrude 3/4” (1.9 cm) into the room.

WATER LINE ENTRY AREA

Note: cutout opening shown with All Freezer model on left.

Reverse water line entry if All Freezer model is on right

Cutout width 59-1/2” (151.1 cm) 60” (152.4 cm) 60” (152.4 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

Cutout width 65-1/2” (166.4 cm) 66” (167.6 cm) 66” (167.6 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

VCFB530/VCRB530 VIFB530/VIRB530 DFFB530/DFRB530

VCFB530/VCRB536 VIFB530/VIRB536 DFFB530/DFRB536

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 30”W. All Freezer

! Installation Notes & Accessories

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished, freestanding look; unit must still be secured to the wall Kit includes one panel and installation hardware

•

Model Description Approx. ship wt. lbs. (kg)

PSSPL2 Professional side panel left (VCFB) 45 (20.2) PSSPR2 Professional side panel right (VCFB) 45 (20.2) DSSPL2 Designer side panel left (VIFB/DFFB) 45 (20.2) DSSPR2 Designer side panel right (VIFB/DFFB) 45 (20.2)

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

SPHKDS Side panel hardware 3 (1.4)

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-30 30”W. top panel 21 (9.5)

Top Grille Kits

• Stainless Steel (SS)

• 60”W. top grille kit—for use with installation of two 30”W. all refrigerators/all freezers side-by-side

• 66”W. top grille kit—for use with installation of one 30”W. and one 36”W. all refrigerators/all freezers side-by-side

• Grille creates a single unit look

• Kit includes one full-length grille, center cabinet trim connector, and all installation hardware

Model Description Approx. ship wt. lbs. (kg)

PGK60-SS Professional 60”W. grille (for two VCRB/VCFB units) 21 (9.5) PGK66-SS Professional 66”W. grille (for two VCRB/VCFB units) 23 (10.4) IGK60-SS Professional Integrated 60”W. grille (for two VIRB/VIFB units) 21 (9.5) IGK66-SS Professional Integrated 66”W. grille (for two VIRB/VIFB units) 23 (10.4) DGK60-SS Designer 60”W. grille (for two DFRB/DFFB units) 21 (9.5) DGK66-SS Designer 66”W. grille (for two DFRB/DFFB units) 23 (10.4)

Center Trim Kit

• Stainless Steel (SS)

• Kit includes center cabinet trim connector to install two custom front units with wood top grille

Model Description Approx. ship wt. lbs. (kg)

FCTK-SS Center trim 5 (2.3)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 30”W. All Freezer

Handle Kits

• For use with custom front freezers

• For use on locally supplied custom front panels Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products

•

• Kit includes handle(s) and installation hardware

Model Description Approx. ship wt. lbs. (kg)

HK28-SS Professional one handle (Stainless Steel) 7 (3.2)

P

HK28-BR Professional one handle (Brass) 7 (3.2)

P DHK25-SS Designer one handle (Stainless Steel) 7 (3.2) DHK25-BR Designer one handle (Brass) 7 (3.2) PHKDFSB5-SS Professional two handles (Stainless Steel) 10 (4.5) PHKDFSB5-SS Professional two handles (Brass) 10 (4.5) HKFDSS-SS Designer two handles (Stainless Steel) 10 (4.5) HKFDS-BR Designer two handles (Brass) 10 (4.5)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser, dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. All Freezer

Standard Features & Accessories

All models include

• Capacity—19.1 cu. ft. (541.0 L)

o 84”H./24”D.

• ProChill™ Temperature Management

System o

Variable-speed DC Overdrive™ Compressor is one of the quietest, most technologically advanced compressors available

o

Electronic controls maintain the temperature selection within 1ºF

o

Multi-channel airflow system and Odor Eliminator™ Evaporator removes odors and excess humidity

• Six adjustable half-width wire shelves

• One full-width metal shelf

• Two full-width slide-out wire baskets

with tempered glass fronts

• Factory-installed automatic ice maker

• One full-width ice storage drawer with two separate metal ice bins

• Full-extension precision ball-bearing glides on all baskets and drawers

• Five patented adjustable aluminum door bins with tempered glass fronts

• Adaptive defrost

• All-metal freezer interior

• Super Clog-Resistant™ Condenser is maintenance-free under normal use

• Tru-Flush™ design o

Allows Professional Integrated and Custom Panel models to fit flush into 24” deep installation cutout

• Open door alarm sounds and glows to warn that door has been ajar for three minutes

Model Options

REFRIGERATION

• Adjustable door stops standard—90°, 110°, or 120° swing

• Sabbath Mode

• For installation of two units side-byside, a separate grille kit accessory must be purchased

• Must be ordered right or left hinge. (As you face unit, RIGHT has hinge on right side and handle on left side; LEFT has hinge on left side and handle on right side.)

VCFB536/VIFB536

Professional/Professional Integrated

FINISH DETAILS FOR VCFB/VIFB MODELS

• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

• Finish codes designate door front. Stainless steel upper grille, side trim, handle, (with chrome-plated brackets); black lower kickplate.

• Brass Trim Option (BR)—nameplate, handle/brackets, and side trim. Brass components have a durable protective coating for maintenance-free normal use.

ORDERING INSTRUCTIONS

First specify model number, followed by hinge preference (“R” for right or “L” for left), and then color code (VCFB536RSS). If ordering optional brass trim, specify code at end (VCFB536RSSBR).

FINISH DETAILS FOR DFFB MODEL

• Handle not included—opt for custom handle, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• See Custom Panels section for more information and additional specifications.

DFFB536

Custom Front

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

4

–

1

/

1

6

”

(

6

2

.

7

c

m)

3

5

”

(

8

.

9

c

m

)

7

5

–1

5

/1

6

”

(

1

9

2

.

9

c

m

)

3–

1

9

/

3

2

”

(

9

.

1

c

m

)

3

6

”

(

9

1

.

5

c

m

)

2

7

–

1

/

4

”

(

6

9

.

2

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

0

–

3

/

4

”

(

5

2

.

7

c

m

)

2

–

3

/

1

6

”

(

56

.

4

c

m

)

2

6

-

1

/

2

”

(

6

7

.

3

c

m

)

3

5

”

(

8

.

9

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3

–

1

9/

3

2

”

(

9

.

1

c

m

)

3

6

”

(

9

1

.

5

c

m

)

2

6

–

1

/

2

”

(

6

7

.

3

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

3

-

3

/

8

”

(

5

9

.

4

c

m

)

2

4

”

(

6

1.

0

c

m

)

Quiet Cool™ Built-In 36”W. All Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, trim, and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

VCFB536/VIFB536

Professional/

Professional Integrated

PROFESSIONAL PROFESSIONAL

Overall width 36” (91.5 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm) To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm) To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)

Approx. ship weight 500 lbs. (227.3 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

INTEGRATED

VCFB536 VIFB536

R E L E AS ED 3 / 1 / 09

REFRIGERATION

2

4

”

(

6

1

.

0

c

m)

3

5

”

(

8

.

9

c

m

)

7

5

–

1

5

/

1

6

”

(

1

9

2

.

9

c

m

)

3

–

1

/

2

”

(

8

.

9

c

m

)

9

–

5

/

3

2

”

(

2

3

.

3

c

m

)

8

2

–

3

/

4

”

(

2

1

0

.

2

c

m

)

m

i

n

.

t

o

8

4

–

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

2

0

–

3

/

4

”

(

5

2

.

7

c

m

)

2

3

–

3

/

8

”

(

5

9

.

4

c

m

)

2

6

”

(

6

.

0

c

m

)

3

6

”

(

9

1

.

5

c

m

)

Quiet Cool™ Built-In 36”W. All Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including panel,

grille, trim, and

handle kits.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

DFFB536

Custom Front

See Custom Panels section for more information and additional specifications.

Overall width 36” (91.5 cm) Overall height (from bottom) 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 23-13/16” (60.5 cm) To front of top grille 24-3/4” (62.9 cm) To front of handle Varies

Approx. ship weight 500 lbs. (227.3 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

CUSTOM FRONT

DFFB536

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. All Freezer

22--11//22””

((66..44 ccmm))

5588--1111//3322”” ((114488..22 ccmm))

2244--1111//1166”” ((6622..77 ccmm))

5566--55//88””

((114433..88 ccmm))

5544--77//3322””

((113377..77 ccmm

)

1144””

((3355..66 ccmm))

3366””

((9911..44 ccmm))

3355””

((8888..99 ccmm))

1188--2299//3322”” ((4488..00 ccmm))

33--11//3322”” ((77..77 ccmm))

112200..00

00

111100..00

00

9900..00

00

2244””

((6611..00 ccmm))

3366””

((9911..44 ccmm))

3355””

((8888..99 ccmm))

22--11//1166”” ((55..22 ccmm))

5588--33//88”” ((114488..33 ccmm))

5566--1111//1166””” ((114444..00 ccmm))

5544--99//3322””

((113377..99 ccmm

)

1133--11//88””

((3333..33 ccmm))

1188--33//1166”” ((4466..22 ccmm))

11--2277//3322”” ((44..77 ccmm))

112200..00

00

111100.0

9900..00

00

0

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION

VCFB536/VIFB536

Professional/

Professional Integrated

PROFESSIONAL

DFFB536

Custom Front

See Custom Panels section for more information and additional specifications.

PROFESSIONAL INTEGRATED

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Partial overlay

cabinet door

Door

Wall

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

3/4”

(1.9 cm) full end panel

24”

(61.0 cm) standard cabinet depth

2-1/2”

(6.4 cm) offset

5/16”

(0.8 cm)

1-13/16”

(4.6 cm) space if 24” standard cabinet depth is used

Door

24”

(61.0 cm)

standard cabinet depth

Wall

3/4”

(1.9 cm)

full end panel

2-1/2”

(6.4 cm) offset

Countertop overhang

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL

REFRIGERATION

Quiet Cool™ Built-In 36”W. All Freezer

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

Quiet Cool™ Built-In 36”W. All Freezer

Door

2

4

”

(

6

1

.

0 c

m

)

s

tan

d

ar

d

c

a

b

i

n

e

t

d

e

p

th

24-3/4”

(62.9 cm)

Wall

3/4”

(1.9 cm)

full end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Cabinet door

Door

Wall

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

3/4”

(1.9 cm)

full end panel

25”

(63.5 cm)

Flush

Door

24”

(61.0 cm) standard cabinet depth

25”

(63.5 cm)

countertop

depth

Wall

3/4”

(

1.9 cm)

f

ull end panel

1”

(2.5 cm)

if 25” (63.5 cm)

cabinet depth is used

Flush

Dimensions & Specifications

CLEARANCE DIMENSIONS— PROFESSIONAL INTEGRATED

TOP VIEW

REFRIGERATION

TOP VIEW

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

TOP VIEW

Overlapping cabinet doors

R E L E AS ED 3 / 1 / 09

REFRIGERATION

A

n

t

i

-

t

i

p

b

o

a

r

d

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

7

3

-

3

/

8

”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

2

4

”

*

(

6

1

.

0

c

m

)

m

i

n

.

ELECTRIC OUTLET LOCATION

WATER LINE ENTRY AREA

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

1

”

(

2

.

5

c

m

)

3

-

5

/

8

”

(

9.

2

c

m

)

O

p

t

i

on

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

9

”

(

2

.

9

c

m

)

3

5

-

1

/

2

”

(

9

0

.

2

c

m

)

m

i

n

.

t

o

3

5

-

3

/

4

”

(

9

0

.

8

c

m

)

m

a

x

.

P

r

o

f

e

s

i

o

n

a

l

3

6

”

(

9

1

.5

c

m

)

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

Quiet Cool™ Built-In 36”W. All Freezer

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord with grounded three-prong plug attached to product

• 115 VAC/60 Hz; 15 amp dedicated circuit

• Maximum amp usage—9.5

• Estimated energy usage— 601 kWh/year

Installation Requirements

ACCESS REQUIREMENTS – Single Installation

VCFB536/VIFB536

Professional/

Professional Integrated

DFFB536

Custom Front

See Custom Panels section for more information and additional specifications.

PLUMBING

• Inlet waterline

• 20 psi min.;

requirements— 1/4” copper tubing

120 psi max.

*Custom front models fit flush in 25”-deep (63.5 cm)

cabinet openings. They can be installed in standard

Cutout width 35-1/2” (90.2 cm) min. to 36” (91.5 cm) 36” (91.5 cm)

Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

24”-deep openings. The door faces and top grille will protrude 3/4” (1.9 cm) into the room.

VCFB536 VIFB536 DFFB536

35-3/4” (90.8 cm) max.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

9

”

(

2

.

9

c

m

)

7

3

-

3/

8

”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

ei

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

7

1

-

1

/

2

”

P

r

o

f

e

s

i

o

n

a

l

(

1

8

2

.

9

c

m

)

7

2

”

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

(

1

8

2

.

9

c

m

)

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

1

”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

r

d

i

n

s

t

a

l

a

t

i

o

n

6

”

(

1

5

.

2

c

m

)

9

”

(

2

.

9

c

m

)

9”

(

2

.

9

c

m

)

7

3

-

3

/

8”

(

1

8

6

.

4

c

m

)

8

2

-

7

/

8

”

(

2

1

0

.

5

c

m

)

m

i

n

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

ni

n

g

h

e

i

g

h

t

8

4

-

1

/

1

6

”

(

2

1

3

.

5

c

m

)

m

a

x

.

a

n

t

i

-

t

i

p

b

o

a

r

d

&

o

p

e

n

i

n

g

h

e

i

g

h

t

6

5

-

1

/

2

”

P

r

o

f

e

s

i

o

n

a

l

(

1

6

.

4

c

m

)

6

”

P

r

o

f

e

s

i

o

n

a

l

I

n

t

e

g

r

a

t

e

d

/

C

u

s

t

o

m

F

r

o

n

t

(

1

6

7

.

6

c

m

)

2

4

”

*

(

6

1

.

0

c

m

)

6

-

3

/

4

”

(

1

7

.

1

c

m

)

7

-

5

/

8

”

(

1

9

.

4

c

m

)

3

”

(

7

.

6

c

m

)

5

/

8

”

(

1

.

5

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

1

/

2

”

(

2

6

.

7

c

m

)

5

/

8

”

(

1

.

5

c

m

)

1

0

-

3

/

4

”

(

2

7

.

3

c

m

)

3

-

5

/

8

”

(

9

.

2

c

m

)

O

p

t

i

o

n

a

l

f

l

o

r

w

a

t

e

r

l

i

n

e

n

t

r

y

1

”

(

2

.

5

c

m

)

S

e

a

n

t

i

-

t

i

p

b

o

a

rd

i

n

s

t

a

l

a

t

i

o

n

6

”

(

1

5

.

2

cm

)

9

”

(

2

.

9

cm

)

Installation Requirements

ACCESS REQUIREMENTS – Dual Installation

REFRIGERATION

Quiet Cool™ Built-In 36”W. All Freezer

ELECTRIC OUTLET LOCATION

36”/30” FREEZER/ REFRIGERATOR COMBINATION

36”/36” FREEZER/ REFRIGERATOR COMBINATION

*Custom front models fit flush in 25”-deep (63.5 cm) cabinet openings. They can be installed in standard 24”-deep openings. The

door faces and top grille will protrude 3/4” (1.9 cm) into the room.

Cutout width 65-1/2” (166.4 cm) 66” (167.6 cm) 66” (167.6 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

Cutout width 71-1/2” (181.6 cm) 72” (182.9 cm) 72” (182.9 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) min.*

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

VCFB536/VCRB530 VIFB536/VIRB530 DFFB536/DFRB530

VCFB536/VCRB536 VIFB536/VIRB536 DFFB536/DFRB536

WATER LINE ENTRY AREA

Note: cutout opening shown with All Freezer model on left.

Reverse water line entry if All Freezer model is on right

ELECTRIC OUTLET LOCATION

WATER LINE ENTRY AREA

Note: cutout opening shown with All Freezer model on left.

Reverse water line entry if All Freezer model is on right

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 36”W. All Freezer

! Installation Notes & Accessories

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished, freestanding look; unit must still be secured to the wall

Kit includes one panel and installation hardware

•

Model Description Approx. ship wt. lbs. (kg)

SSPL2 Professional side panel left (VCFB) 45 (20.2)

P

SSPR2 Professional side panel right (VCFB) 45 (20.2)

P

SSPL2 Designer side panel left (VIFB/DFFB) 45 (20.2)

D

SSPR2 Designer side panel right (VIFB/DFFB) 45 (20.2)

D

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Model Description Approx. ship wt. lbs. (kg)

SPHKDS Side panel hardware 3 (1.4)

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished, freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Model Description Approx. ship wt. lbs. (kg)

TOP-36 36”W. top panel 22 (10.0)

Top Grille Kits

• Stainless Steel (SS)

• 66”W. top grille kit—for use with installation of one 36”W. and one 30”W. all refrigerators/all freezers side-by-side

• 72”W. top grille kit—for use with installation of two 36”W. all refrigerators/all freezers side-by-side

• Grille creates a single unit look

• Kit includes one full-length grille, center cabinet trim connector, and all installation hardware

Model Description Approx. ship wt. lbs. (kg)

PGK66-SS Professional 66”W. grille (for two VCRB/VCFB units) 23 (10.4) PGK72-SS Professional 72”W. grille (for two VCRB/VCFB units) 25 (11.3) IGK66-SS Professional Integrated 66”W. grille (for two VIRB/VIFB units) 23 (10.4) IGK72-SS Professional Integrated 72”W. grille (for two VIRB/VIFB units) 25 (11.3) DGK66-SS Designer 66”W. grille (for two DFRB/DFFB units) 23 (10.4) DGK72-SS Designer 72”W. grille (for two DFRB/DFFB units) 25 (11.3)

Center Trim Kit

• Stainless Steel (SS)

• Kit includes center cabinet trim connector to install two custom front units with wood top grille

Model Description Approx. ship wt. lbs. (kg)

FCTK-SS Center trim 5 (2.3)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

REFRIGERATION

Quiet Cool™ Built-In 36”W. All Freezer

Handle Kits

• For use with custom front freezers

• For use on locally supplied full custom front panels

Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products

•

• Kit includes handle(s) and installation hardware

Model Description Approx. ship wt. lbs. (kg)

PHK28-SS Professional one handle (Stainless Steel) 7 (3.2) PHK28-BR Professional one handle (Brass) 7 (3.2)

HK25-SS Designer one handle (Stainless Steel) 7 (3.2)

D

HK25-BR Designer one handle (Brass) 7 (3.2)

D

HKDFSB5-SS Professional two handles (Stainless Steel) 10 (4.5)

P

HKDFSB5-BR Professional two handles (Brass) 10 (4.5)

P

KFDS-SS Designer two handles (Stainless Steel) 10 (4.5)

H

KFDS-BR Designer two handles (Brass) 10 (4.5)

H

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system and automatic ice maker

• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited—cosmetic parts such as glass, painted, and decorative items

* For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 3 / 1 / 09

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

REFRIGERATION

Built-In 30”W. Full-Height Wine Cellar

R E LE A S ED 1 2 / 1/ 0 7

All models include

• Capacity—accommodates up to 150

full-size bottles o 84”H./24”D.

• Exclusive TriTemp™ storage system

o Three independent temperature

zones

o Settings are adjustable in each zone

from 43˚F (6.1˚C) – 65˚F (18.3˚C)

o Electronic control center maintains

set temperature within 1.5˚F (0.83˚C)

• Exclusive glass control pad

• Versatile shelving system stores

standard, magnum, and half-size bottles

• Two convertible wine shelves adjust to

allow for bottle display

• Solid maple wood facings provide

additional ultraviolet protection, and may be finished to coordinate with surrounding cabinetry

• Coated wine shelves reduce vibration and hold bottles in place

• Shelves are fully removable for easy cleaning

• Ultraviolet-resistant tempered glass and black interior protect wine from harmful light

• Low-intensity lighting displays wine with minimal heat and light output

• Lower zone with raised wood facings

• High temperature alarm

• Door open alarm

• Home security system connection

• Dual magnet and spring assist door closure mechanism

• Keyed door lock

• Adjustable door stays standard—90˚, 110˚, or 120˚

• Power interruption switch

• Top-mounted and front-venting sealed refrigeration system

• lower kickplate

• Must be ordered right or left hinge. (As you face unit, RIGHT has hinge on right side and handle on left side; LEFT has hinge on left side and handle on right side.)

VCWB300

Professional

FINISH DETAILS FOR DFWB MODEL

• Black interior

• Handle not included—opt for custom handle, or purchase a Viking Professional Series or Designer Series handle kit (see Installation Notes & Accessories).

• Accepts 3/4”-thick custom panel—no visible trim

• See Custom Panels section for more information and additional specifications.

FINISH DETAILS FOR DDWB MODEL

• Clear and fluted glass doors

• Stainless Steel (SS)—stainless steel frame around large window door, stainless steel handle, and black interior.

• Brass Trim Option (BR)—handle. Brass components have a durable protective coating for maintenance-free normal use.

FINISH DETAILS FOR VCWB MODEL

• Clear and fluted glass doors

• Stainless Steel (SS)—stainless steel frame around large window door, stainless steel handle with chromeplated brackets, and black interior.

• Brass Trim Option (BR)—nameplate, handle/brackets. Brass components have a durable protective coating for maintenance-free normal use.

DDWB300

Designer

DFWB300

Custom Front

Model Options

Standard Features & Accessories

ORDERING INSTRUCTIONS

First specify model number. If ordering special fluted or solid door (“F” for fluted or ”D” for solid), specify immediately after model number (VCWB300F). Next, specify hinge preference (“R” for right or “L” for left), and then color code (VCWB300FRSS). If ordering optional brass trim, specify code at end (VCWB300FRSSBR).

REFRIGERATION

Built-In 30”W. Full-Height Wine Cellar

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

R E LE A S ED 1 2 / 1/ 0 7

✪

Please see

Installation Notes &

Accessories

for important

information,

including panel and

handle kits.

Dimensions & Specifications

82-7/8”

(210.5 cm)

min.

to

84-1/16”

(213.5 cm)

max.

29”

(73.7cm)

70”

(177.5 cm)

9-5/16”

(23.6 cm)

22-3/16”

(56.4

cm)

24-1/2”

(62.2 cm)

30”

(76.2 cm)

27”

(68.6

cm)

30”

(76.2 cm)

23-13/16”

(60.5

cm)

29”

(73.7 cm)

82-7/8”

(21

0.5 cm) min.

to

84-1/16”

(213.5 cm)

max.

70”

(177.5 cm)

9-5/8”

(24.4 cm)

24-1/32”

(61.0

cm)

24-3/

4”

(62

.

9

cm)

26”

(66.0 cm)

V

A

R

IES

PROFESSIONAL DESIGNER/

CUSTOM FRONT

VCWB300 DDWB300 DFWB300

Overall width 30” (76.2 cm) Overall height (from bottom) 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear)

To front edge of side trim 22-3/16” (56.4 cm) 23-13/16” (60.5 cm) 23-13/16” (60.5 cm) To front of top grille 24-1/2” (62.2 cm) 24-1/32” (61.0 cm) 24-3/4” (62.9 cm) To front of handle 27” (68.6 cm) 26” (66.0 cm) Varies

Approx. ship weight 560 lbs. (252.0 kg)

VCWB300

Professional

DDWB300

Designer

DFWB300

Custom Front

PRODUCT DIMENSIONS

See Custom Panels section for more information and additional specifications.

ALL MODELS

Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

R E LE A S ED 1 2 / 1/ 0 7

90

o

110

o

120

o

2” (5.0 cm)

48-5/8”

(123.5 cm)

50”

(127.0 cm)

51-7/8”

(131.8 cm)

11-3/8” (28.9 cm)

15-3/8”

(39.1 cm)

REFRIGERATION

Built-In 30”W. Full-Height Wine Cellar

Dimensions & Specifications

DOOR SWING

• Adjustable door stops standard—90°, 110°, or 120° swing

90

o

110

o

120

o

11-1/2”

(29.2 cm)

15-1/2”

(39.4 cm)

48-5/8”

(123.5 cm)

51-7/8”

(131.8 cm)

50-1/2”

(128.2 cm)

2-1/2”

(6.4 cm)

PROFESSIONAL

DESIGNER

VCWB300

Professional

DDWB300

Designer

DFWB300

Custom Front

See Custom Panels section for more information and additional specifications.

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

R E LE A S ED 1 2 / 1/ 0 7

REFRIGERATION

Built-In 30”W. Full-Height Wine Cellar

Door

29-1/2” (90.2 cm)

Wall

1-13/16” (4.6 cm) space if 24” (61.0 cm) standard cabinet depth is used

3/4” (1.9 cm) full end panel

2-5/16” (5.9 cm) offset

24” (61.0 cm) standard cabinet depth

Partial overlay cabinet door

Door

Wall

29-1/2” (90.2 cm)

1-13/16” (4.6 cm)

3/4” (1.9cm) full end panel

24” (61.0cm) standard cabinet depth

5/16” (0.8 cm)

2-5/16” (5.9 cm) offset

Door

Countertop overhang

29-1/2” (90.2 cm)

Wall

1-13/16” (4.6 cm) space if 24” (61.0 cm) standard cabinet depth is used

3/4” (1.9 cm) full end panel

24” (61.0 cm) standard cabinet depth

2-5/16” (5.9 cm) offset

Dimensions & Specifications

CLEARANCE DIMENSIONS—PROFESSIONAL

TOP VIEW

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

R E LE A S ED 1 2 / 1/ 0 7

REFRIGERATION

Built-In 30”W. Full-Height Wine Cellar

Door

Wine cellar and cabinet door flush

30” (76.2 cm)

Wall

3/4” (1.9 cm) space if 24” (61.0 cm) standard cabinet depth is used

24-3/4” (62.9 cm)

24” (61.0 cm) standard cabinet depth

Cabinet front

Door

Flush

30” (76.2 cm)

Wall

3/4” (1.9 cm) full end panel

25” (63.5 cm)

1” (2.5 cm)

Door

Flush

Countertop depth

30” (76.2 cm)

Wall

1” (2.5 cm) space if 25” (63.5 cm) cabinet depth is used

3/4” (1.9 cm) full end panel

25” (63.5 cm)

24” (61.0 cm) standard cabinet depth

Cabinet front

Dimensions & Specifications

CLEARANCE DIMENSIONS—DESIGNER

TOP VIEW

REFRIGERATION

Built-In 30”W. Full-Height Wine Cellar

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

R E LE A S ED 1 2 / 1/ 0 7

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord

with grounded three-prong plug attached to product

• 115 VAC/60 Hz;

15 amp dedicated circuit

• Maximum amp

usage—2.0

PLUMBING

Not applicable

Installation Requirements

29-1/2” (74.9 cm) Professional

30” (76.2 cm) Designer/Custom Front

82-7/8” (210.5 cm) min. anti-tip board and opening height

73-3/4”

(187.3 cm)

1-1/2”

(3.8 cm)

3-1/2”

(8.9 cm)

84-1/16” (213.5 cm) max. anti-tip board and opening height

2” x 4” Mounting Board (1-1/2” (3.8 cm) x 3-1/2” (8.9 cm)) Attached to anti-tip mounting bracket

Note: If unit is installed deeper than 24” (61.0 cm), then shim behind anti-tip bracket thickness by the same amount

8-1/4”

(20.9 cm)

24” (61. 0 cm) Professional/Designer 25” (63.5 cm) Custom Front

Electrical outlet location

Anti-tip mounting brackets attached to wall studs

4”

(10. cm)

ACCESS REQUIREMENTS

VCWB300 DDWB300 DFWB300

Cutout width 29-1/2” (74.9 cm) 30” (76.2 cm) 30” (76.2 cm) Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max. Cutout depth 24” (61.0 cm) 24” (61.0 cm) 25” (63.5 cm)*

*Can be installed in 24”-deep (61.0 cm) openings; door faces and top grille will protrude 3/4” (1.9 cm) into room.

VCWB300

Professional

DDWB300

Designer

DFWB300

Custom Front

See Custom Panels section for more information and additional specifications.

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

REFRIGERATION

Built-In 30”W. Full-Height Wine Cellar

R E LE A S ED 1 2 / 1/ 0 7

Side Panel Kits

• Stainless Steel (SS)

• Panels provide finished freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Side Panel Hardware Kit

• For use with Designer built-in refrigerator/freezers

• Hardware allows installation of custom side panels

• Kit includes brackets, screws, and installation instructions to mount panels on left and right side

Top Panel Kit

• Stainless Steel (SS)

• Panel provides finished freestanding look; unit must still be secured to the wall

• Kit includes one panel and installation hardware

Handle Kits

• For use with custom front wine cellars

• For use on locally supplied custom front panels

• Handles allow wine cellar with custom front panel to coordinate with other Professional & Designer products

• Kit includes one handle and installation hardware

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Twelve-year limited warranty—sealed refrigeration system

• Ninety-day limited warranty—cosmetic parts such as glass, painted items, and decorative items

*For complete warranty see

Use & Care Guide

. Warranty valid on Viking products shipped within the United States and Canada.

✪

Installation Notes & Accessories

Model Description Approx. ship wt. lbs. (kg)

PSSPL2 Professional side panel left 45 (20.2) PSSPR2 Professional side panel right 45 (20.2) DSSPL2 Designer side panel left 45 (20.2) DSSPR2 Designer side panel right 45 (20.2)

Model Description Approx. ship wt. lbs. (kg)

PHK-26-SS Professional handle (Stainless Steel) 7 (3.2) PHK-26-BR Professional handle (Brass) 7 (3.2) DHK-25-SS Designer handle (Stainless Steel) 7 (3.2) DHK-25-BR Designer handle (Brass) 7 (3.2)

Model Description Approx. ship wt. lbs. (kg)

TOP-30 3 0 ” W. top panel 21 (9.5)

Model Description Approx. ship wt. lbs. (kg)

SPHKDS Side panel hardware 3 (1.4)

Standard Features & Accessories

Models include

• Total capacity—19.9 cu. ft. (563.2 L)

• 72”H./24”D.

• “Cabinet depth” design (24”D. side panels) integrates with surrounding cabinetry—fit for replacement of most existing appliances

• Electronic controls with digital readouts maintain the temperature selection

• Frost-free refrigerator o Capacity—14.4 cu. ft. (407.5 L) o Four slide-out adjustable tempered

glass spillproof shelves o One stationary glass shelf o Temperature adjustable Meat

Savor™/produce drawer o Two moisture adjustable see-

through produce drawers o In-the-door dairy compartment with

cover

o Three half-width door bins o One full-width door bin o Internal filtered water dispensing o Water filter indicator light

(illuminates when filter needs to be replaced)

o See-through egg bin with carrier

holds up to 24 eggs

o Glass butter tray with cover

• Frost-free freezer o Capacity—5.5 cu. ft. (155.7 L) o Adaptive defrost o Factory-installed automatic ice

maker o Two slide-out baskets o Max ice feature

• Open door alarm sounds to warn that door has been ajar for five minutes

• High temperature alarm

• Vacation Mode

REFRIGERATION

Freestanding 36”W. Bottom-Mount

Refrigerator/Freezer

• Gray exterior cabinet

• Must be ordered right or left hinge. (As you face unit, RIGHT has hinge on right side and handle on left side; LEFT has hinge on left side and handle on right side.)

Model Options

FINISH DETAILS FOR BOTH MODELS

• Stainless Steel (SS)

• Finish code designates door fronts. Black cabinet sides and top.

VCBF136*

Professional

*Shown throughout with top grille kits. See Installation Notes & Accessories for details.

ORDERING INSTRUCTIONS

First specify model number, followed by hinge preference (“R” for right or “L” for left), and then color code (VCBF136RSS).

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E V I SE D 8 /1 8/ 0 9

REFRIGERATION

4

1-

1

/

8

”

(

1

0

4

.

5

c

m

)

2

4

”

(

6

1

.

0

c

m

)

7

0

-

1

/

8

”

(

1

7

8

.

1

c

m

)

7

1-

7

/

8

”

(

1

8

2

.

6

c

m

w

t

i

h

t

o

p

g

r

i

lle

/

t

op

a

cc

e

s

o

r

y

3

5-

7

/

8

”

(

9

1

.

1

c

m

)

w

/s

i

d

e

p

a

n

e

l

a

c

ce

s

o

r

y

3

5-

5

/

8

”

(

9

0

.

5

c

m

)

2

3

-

1

/

2

”

(

5

9

.

7

c

m

)

2

8

-

3

/

4

”

(

7

3

.

0

c

m

)

2

6

-

3

/

4

”

(

6

7

.

9

c

m

)

Freestanding 36”W. Bottom-Mount

Refrigerator/Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including water

filter, handle, trim

and top grille kits.

Dimensions & Specifications

PRODUCT DIMENSIONS

VCBF136

Professional

Overall width 35-5/8” (90.5 cm)

Addition of side panels 35-7/8” (91.1 cm)

Overall height (from bottom) 70-1/8” (178.1 cm)

Addition of tops/grilles 71-7/8” (182.6 cm)

Overall depth (from rear)

To front of door 26-3/4” (67.9 cm) To front of handle 28-3/4” (73.0 cm)

Approx. ship weight 327 lbs. (148.7 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

PROFESSIONAL

VCBF136

R E V I SE D 8 /1 8/ 0 9

Dimensions & Specifications

35-5/8”

(90.5 cm)

26-1/4”

(66.7 cm)

60-3/4”

(154.0 cm)

2-1/2”

(6.4 cm)

90.0°

DOOR SWING

REFRIGERATION

Freestanding 36”W. Bottom-Mount

Refrigerator/Freezer

VCBF136

Professional

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

PROFESSIONAL

R E V I SE D 8 /1 8/ 0 9

REFRIGERATION

70-1/2”

(179.1 cm)

cutout without

addition of

tops/grilles

72”

(182.9 cm)

cutout with

addition of

tops/grilles

26”

(66.0 cm)

24”

(61.0 cm)

min.

36”

(91.4 cm)

14”

(35.6 cm)

Water line

location

Recommended

receptacle location

20”

(50.8 cm)

2

0”

(50.8 cm)

36”

(91.4 cm)

42”

(106.7cm)

26”

(66.0 cm)

Freestanding 36”W. Bottom-Mount

Refrigerator/Freezer

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord

with grounded three-prong plug attached to product. Do not use an extension cord or adapter plug for a twoprong receptacle—call a qualified electrical installer.

o 115V/60 Hz; 15

amp dedicated circuit

o Maximum amp

usage—7.9

o Estimated energy

usage—452 kWh/year

Installation Requirements

ACCESS REQUIREMENTS

VCBF136

Professional

PLUMBING

• Inlet waterline

requirements— 1/4” copper tubing

• 35 psi min.;

100 psi max.

Cutout width 36” (91.4 cm) Cutout height 70-1/2” (179.0 cm)

Addition of tops/grilles 72” (182.9 cm)

Cutout depth 24” (61.0 cm)

When installing into a cutout, the edge of the door must be 2-7/8” (7.3 cm) from the adjacent countertop cabinet.

Allow 1/2” (1.3 cm) space at top and 1/2” (1.3 cm) behind the machine compartment cover (located in the rear) for proper air circulation. Sub-flooring or floor coverings (i.e. carpet, tile, wood floors, rugs) may make your opening smaller than anticipated. Some clearance may be gained by using the leveling procedure under

Leveling in the Installation Guide.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

VCBF136

R E V I SE D 8 /1 8/ 0 9

REFRIGERATION

Freestanding 36”W. Bottom-Mount

Refrigerator/Freezer

Installation Notes & Accessories

!

Side Trim Kits

• Stainless steel finish

• Provides ”built-in” look when used with a top grille kit

Model Description Approx. ship wt. lbs. (kg)

FRSTKRB Right hinged bottom-mount side trim kit 13 (5.9) FRSTKLB Left hinged bottom-mount side trim kit 13 (5.9)

Top Grille Kits

• Stainless steel finish

• Provides ”built-in” look when used with a side trim kit; provides “wrapped” look when used with side panel and top kits

Model Description Approx. ship wt. lbs. (kg)

PFRGKRB Professional right hinged bottom-mount grille kit 10 (4.5)

FRGKLB Professional left hinged bottom-mount grille kit 10 (4.5)

P DFRGKRB Designer right hinged bottom-mount grille kit 10 (4.5) DFRGKLB Designer left hinged bottom-mount grille kit 10 (4.5)

Side Panel Kits

• Stainless steel finish

• Provides ”wrapped” look when used with top grille and top kits

• Side panel kits include panels for both sides

Model Description Approx. ship wt. lbs. (kg)

FRSPKRB Rght hinged bottom-mount side panel kit 60 (27.0) FRSPKLB Left hinged bottom-mount side panel kit 60 (27.0)

Top Kit

• Stainless steel finish

• Provides ”wrapped” look when used with side panel and top grille kits

Model Description Approx. ship wt. lbs. (kg)

FRTOP Professional right hinged bottom-mount top kit 19 (8.6)

Replacement Water Filter

• Replaces water filter cartridges supplied with freestanding refrigerator/freezers

• Reduces sediment, bad taste and odor

• Reduces cysts, particulates, turbidity, lead, chlorine, atrazine and lindane

• Ready to install—no assembly required

Model Description Approx. ship wt. lbs. (kg)

RWF-FR Replacement water filter 5 (2.3)

Brass Handle Kits

• Replaces handles supplied with unit for brass trim

• Bottom-mount kits include two handles

Model Description Approx. ship wt. lbs. (kg)

PFRHKBBR Professional bottom-mount handle kit 10 (4.5) DFRHKBR Designer bottom-mount/side-be-side handle kit 10 (4.5)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Twelve-year limited warranty—sealed refrigeration system

• Ninety-day limited warranty—cosmetic parts such as glass, painted items, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E V I SE D 8 /1 8/ 0 9

Standard Features & Accessories

Models include

• Total capacity—19.6 cu. ft. (545.7 L)

• 72”H./24”D.

• “Cabinet depth” design (24”D. side panels) integrates with surrounding cabinetry—fit for replacement of most existing appliances

• Electronic controls with digital readouts maintain the temperature selection

• Frost-free refrigerator o Capacity—14.1 cu. ft. (399 lit.) o Four slide-out adjustable tempered

glass spillproof shelves o One stationary glass shelf o Temperature adjustable Meat

Savor™/produce drawer o Two moisture adjustable see-

through produce drawers

o In-the-door dairy compartment

with cover

o Five large door bins (two bins store

gallon containers) o Internal filtered water dispensing o Water filter indicator light

(illuminates when filter needs to be

replaced) o See-through egg bin with carrier

holds up to 24 eggs o Glass butter tray with cover

• Frost-free freezer o Capacity—5.5 cu. ft. (156 lit.) o Adaptive defrost o Factory-installed automatic ice

maker

o Two slide-out baskets

o Max ice feature

REFRIGERATION

Freestanding 36”W. French-Door

Bottom-Mount Refrigerator/Freezer

• Open door alarm sounds to warn that door has been ajar for five minutes

• High temperature alarm

• Gray exterior cabinet (VCFF)

Model Options

FINISH DETAILS FOR BOTH MODELS

• Stainless Steel (SS)

• Finish code designates door fronts. Black cabinet sides and top.

VCFF136*

Professional

DDFF036*

Designer

*Shown throughout with top grille kits. See Installation Notes & Accessories for details.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 4 / 1 / 09

REFRIGERATION

2

3

-

1

/

2

”

(

5

9

.

7

c

m

)

2

8

-

3

/

4

”

(

7

3

.

0

c

m

)

7

0

-

1

/

8

”

(

1

7

8

.

1

c

m

)

7

1

-

7

/

8

”

(

1

8

2

.

6

c

m

w

i

t

h

t

o

p

g

r

i

l

e

/

t

op

a

cc

e

s

or

y

3

5-

5

/

8

”

(

9

0

.

5

c

m

)

3

5

-

7

/

8

”

(

9

1

.

1

c

m

)

w

/

s

i

d

e

p

a

n

e

l

a

c

ce

s

o

r

y

2

6

-

3

/

4

”

(

6

7

.

9

c

m

)

4

1

-

1

/

8

”

(

1

0

4

.

5

c

m

)

2

4

”

(

6

1

.

0

c

m

)

2

3

-

1

/

2

”

(

5

9

.

7

c

m

)

2

8

-

3

/

8

”

(

7

2

.

1

c

m

)

7

0-

1

/

8

”

(

1

7

8

.

1

c

m

)

7

1

-

7

/

8

”

(

1

8

2

.

6

c

m

)

w

i

t

h

t

op

g

ri

l

e

/

t

o

p

a

c

ce

s

o

r

y

3

5

-

5

/

8

”

(

9

0

.

5

c

m

)

3

5-

7

/

8

”

(

9

1

.

1

c

m

)

w

/

s

i

d

e

p

a

n

e

l

a

c

ce

s

o

r

y

2

6

-

3

/

4

”

(

6

7

.

9

c

m

)

4

1

-

1

/

8

”

(

1

0

4

.

5

c

m

)

2

4

”

(

6

1

.

0

c

m

)

Freestanding 36”W. French-Door

Bottom-Mount Refrigerator/Freezer

Please see

!

Installation Notes &

Accessories

for important

information,

including water

filter, handle, trim

and top grille kits.

Dimensions & Specifications

PRODUCT DIMENSIONS

VCFF136

Professional

DDFF036

Designer

Overall width 35-5/8” (90.5 cm)

Addition of side panels 35-7/8” (91.1 cm)

Overall height (from bottom) 70-1/8” (178.1 cm)

Addition of tops/grilles 71-7/8” (182.6 cm)

PROFESSIONAL DESIGNER

Overall depth (from rear)

To front of door 26-3/4” (67.9 cm) To front of handle 28-3/4” (73.0 cm) 28-3/8” (72.1 cm)

Approx. ship weight 327 lbs. (148.7 kg)

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

VCFF136 DDFF036

R E L E AS ED 4 / 1 / 09

35-5/8”

(90.5 cm)

42-7/8”

(109.0 cm)

90.0°90.0°

42-7/8”

(109.0 cm)

2-1/8”

(5.4 cm)

2-1/8”

(5.4 cm)

Dimensions & Specifications

35-5/8”

(90.5 cm)

42-7/8”

(109.0 cm)

2-1/2”

(6.4 cm)

2-1/2”

(6.4 cm)

90.0°90.0°

42-7/8”

(109.0 cm)

DOOR SWING

REFRIGERATION

Freestanding 36”W. French-Door

Bottom-Mount Refrigerator/Freezer

VCFF136

Professional

PROFESSIONAL

DDFF036

Designer

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

DESIGNER

R E L E AS ED 4 / 1 / 09

REFRIGERATION

70-1/2”

(179.1 cm)

cutout without

addition of

tops/grilles

72”

(182.9 cm)

cutout with

addition of

tops/grilles

26”

(66.0 cm)

24”

(61.0 cm)

min.

36”

(91.4 cm)

14”

(35.6 cm)

Water line

location

Recommended

receptacle location

20”

(50.8 cm)

20”

(50.8 cm)

36”

(91.4 cm)

42”

(106.7cm)

26”

(66.0 cm)

Freestanding 36”W. French-Door

Bottom-Mount Refrigerator/Freezer

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord

with grounded three-prong plug attached to product. Do not use an extension cord or adapter plug for a two-prong receptacle—call a qualified electrical installer. o 115V/60 Hz; 15

amp dedicated circuit

o Maximum amp

usage—7.9

o Estimated

energy usage— 451 kWh/year

Installation Requirements

ACCESS REQUIREMENTS

VCFF136

Professional

DDFF036

Designer

PLUMBING

• Inlet waterline

requirements— 1/4” copper tubing o 35 psi min.;

100 psi max.

Cutout width 36” (91.4 cm) Cutout height 70-1/2” (179.0 cm)

Addition of tops/grilles 72” (182.9 cm)

Cutout depth 24” (61.0 cm)

When installing into a cutout, the edge of the door must be 2-7/8” (7.3 cm) from the adjacent countertop cabinet.

Allow 1/2” (1.3 cm) space at top and 1/2” (1.3 cm) behind the machine compartment cover (located in the rear) for proper air circulation. Sub-flooring or floor coverings (i.e. carpet, tile, wood floors, rugs) may make your opening smaller than anticipated. Some clearance may be gained by using the leveling procedure under

Leveling in the Installation Guide.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

All models

R E L E AS ED 4 / 1 / 09

REFRIGERATION

Freestanding 36”W. French-Door

Bottom-Mount Refrigerator/Freezer

Installation Notes & Accessories

!

Side Trim Kit

• Stainless Steel finish

• Provides ”built-in” look when used with a top grille kit

Model Description Approx. ship wt. lbs. (kg)

FRSTKF French door bottom-mount side trim kit 13 (5.9)

Top Grille Kits

• Stainless Steel finish

• Provides ”built-in” look when used with a side trim kit; provides “wrapped” look when used with side panel and top kits

Model Description Approx. ship wt. lbs. (kg)

FRGKFS Professional french door bottom-mount grille kit 10 (4.5)

P

FRGKFS Designer french door bottom-mount grille kit 10 (4.5)

D

Side Panel Kit

• Stainless Steel finish

• Provides ”wrapped” look when used with top grille and top kits

• Side panel kits include panels for both sides

Model Description Approx. ship wt. lbs. (kg)

FRSPKF French door bottom-mount side panel kit 60 (27.0)

Top Kit

• Stainless steel finish

• Provides ”wrapped” look when used with side panel and top grille kits

Model Description Approx. ship wt. lbs. (kg)

FRTOP French door bottom-mount top kit 19 (8.6)

Replacement Water Filter

• Replaces water filter cartridges supplied with freestanding refrigerator/freezers

• Reduces sediment, bad taste and odor

• Reduces cysts, particulates, turbidity, lead, chlorine, atrazine and lindane

• NSF certified

• Ready to install—no assembly required

Model Description Approx. ship wt. lbs. (kg)

RWF-FR Replacement water filter 5 (2.3)

Brass Handle Kits

• Replaces handles supplied with unit for brass trim

• French door kits include three handles

Model Description Approx. ship wt. lbs. (kg)

PFRHKFBR Professional french door handle kit 15 (6.8) DFRHKFBR Designer french door handle kit 15 (6.8)

Compliance Information

WARRANTY SUMMARY*

• Two-year full warranty—complete unit

• Six-year full warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Twelve-year limited warranty—sealed refrigeration system

• Ninety-day limited warranty—cosmetic parts such as glass, painted items, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

P L A N N I N G A N D D ES IG N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E AS ED 4 / 1 / 09

• Total capacity—21.5 cu. ft. (608.5 L)

• 72”H./24”D.

• “Cabinet depth” design (24”-deep side panels) integrates with surrounding cabinetry—fit for replacement of most existing appliances

• Electronic controls with digital readouts maintain the temperature selection

• Frost-free refrigerator o Capacity—13.5 cu. ft. (382.1 L) o Four tempered glass spillproof

shelves o One stationary glass shelf o Temperature adjustable Meat

Savor™/produce drawer o Two moisture adjustable see-

through produce drawers

o In-the-door dairy compartment with

cover

o Five door bins (three bins store

gallon containers)

o Separate adjustable temperature

control for door bin area

o See-through egg bin with carrier

holds up to 24 eggs

o Glass butter tray with cover

• Frost-free freezer o Capacity—8.0 cu. ft. (226.4 L) o Factory-installed automatic ice

maker o Two adjustable wire shelves o Two slide-out baskets o Five large door bins (three tilt out-

ward for easy access) o Adaptive defrost

o Max ice feature

• Open door alarm sounds to warn that door has been ajar for five minutes

• High temperature alarm

• Vacation mode

REFRIGERATION

Freestanding 36”W. Side-By-Side

Refrigerator/Freezer

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

R E LE A S ED 1 2 / 1/ 0 7

Models include

FINISH DETAILS FOR BOTH MODELS

• Stainless Steel (SS)

• Finish code designates door fronts. Black cabinet sides and top.

Standard Features & Accessories

Model Options

VCSF036*

Professional

DDSF036*

Designer

*Shown throughout with top grille kits. See Installation Notes & Accessories for details.

VCSF036

Professional

✪

Please see

Installation Notes &

Accessories

for important

information,

including handle,

trim and top grille

kits.

REFRIGERATION

Freestanding 36”W. Side-By-Side

Refrigerator/Freezer

P L A N N I N G A ND D ES I G N G UI DE

V I K I N GR A N G E . C O M • 1 - 8 88 - V I K I N G 1

R E LE A S ED 1 2 / 1/ 0 7

23-1/2”

(59.7

cm)

28-

3/4”

(73.0 cm)

70”

(177.8 cm)

71-

7/8”

(182.6 cm

)

with top

gri

lle/top

acce

ss

ory

35-5/8”

(90.5 cm)

35-7/8”

(91.1 cm)

w/side panel ac

cessory

26-

3/4”

(67.9

cm)

23-1/2”

(59.7 cm)

28-

3/8”

(72.1 cm)

70”

(177.8 cm)

71-

7/8”

(182.6 cm

)

with top

gri

lle/

top

accessory

35-5/8”

(90.5 cm)

35-7/8”

(91.1 cm)

w/side panel ac

cessory

26-

3/4”

(67

.9 cm)

VCSF036 DDSF036

Overall width 35-5/8” (90.5 cm)

Addition of side panels 35-7/8” (91.1 cm)

Overall height (from bottom) 70” (177.8 cm)

Addition of tops/grilles 71-7/8” (182.6 cm)

Overall depth (from rear)

To front of door 26-3/4” (67.9 cm) To front of handle 28-3/4” (73.0 cm) 28-3/8” (72.1 cm)

Approx. ship weight 314 lbs. (141.3 kg)

PROFESSIONAL DESIGNER

Dimensions & Specifications

PRODUCT DIMENSIONS

DDSF036

Designer
