Viking E-1600-03B, E-1600-03B-EWP, E-1600-20A-EWP, E-1600-30A, E-1600-30A-EWP Technical Practice
...
The 1600A Series ADA Compliant Emergency
Phones are designed to provide quick and reliable
handsfree communication for any standard analog
telephone line or analog phone system station port. All
1600A Series phones meet ADA requirements
for elevator/ emergency telephones, and can
be programmed from any Touch Tone phone.
The phones can dial up to 5 programmable
emergency numbers, as well as 2
central station numbers. In addition,
the E-1600-20A and E-1600-52A feature a second "INFO" button that will
dial up to 3 non-emergency numbers.
The 1600A Series phones can be programmed to automatically deliver a digital announcement to identify the location of the emer-
gency call. Alternatively, a DTMF Touch Tone code may also be delivered. A “Call Connected” LED can be initiated manually or
automatically. All programming parameters, including phone numbers and location numbers, are stored in non-volatile E
2
memory. All units are phone line powered, requiring no batteries or external power and are compatible with common Central Station
Monitoring equipment.
For outdoor installations where the unit is exposed to precipitation or condensation, select 1600A Series phones are available with
Enhanced Weather Protection (EWP). EWP products feature foam rubber gaskets and boots, sealed connections, gel-filled butt
connectors, as well as urethane or thermal plastic potted circuit boards with internally sealed, field-adjustable trim pots and DIP
switches for easy on-site programming. For more information, see DOD# 859.
1600A Series
1600A Series
ADA Compliant
Emergency Phones
January 24, 2013
ADA* Compliant Emergency Phones with
Built-In Digital Voice Announcer
• Meets the latest ASME A17.1 code when used with the optional LV-1K
Line Verification Panel, see DOD# 246
• Meets ADA requirements for Emergency Phones:
- Can automatically light the “Call Connected” LED for the
hearing impaired
- Transmits a unique location I.D. code or voice announcement
- Grade 2 Braille label for the visually impaired
• Non-volatile digital voice announcer with 16 seconds of voice memory
• Advanced call progress detection
• Handsfree operation
• Phone line powered
• Non-volatile memory (no batteries required)
• Marine grade 316 stainless steel prevents corrosion on stainless models
• Dials up to 5 emergency numbers
• E-1600-20A and E-1600-52A dial up to 3 non-emergency “INFO”
numbers
• Cycles through backup emergency and non-emergency numbers
on busy or no-answer
• Optional Enhanced Weather Protection (EWP), EWP products are
designed to meet IP66 Ingress Protection Rating, see DOD# 859
• Hangs up on CPC, silence, busy signal, dial tone, time-out or touch
tone command
• Programmable to auto-answer on incoming calls
• Remotely programmable
• Extended temperature range (-15°F to 130°F)
• 9 different chassis or board only available
• Available in 42” tall tower phone model E-1600A-BLT-EWP (DOD# 217)
• Central Station Monitoring capability (dials 2 numbers)
• Optional PB-100 Polling System available (DOD# 232)
• Optional BLK-3-EWP strobe light kit available (DOD# 653)
• Optional LC-6 Six Port Concentrator available (DOD# 245)
• Optional LV-1K Line Verification Panel available (DOD# 246)
PPrraaccttiicce
e
T
T
EELLEECCOOM
M
S
S
OOLLUUTTIIOONNSSFFOORRTTHHE
E
221
1
SST
T
C
C
EENNTTUURRY
Y
TECHNICAL
TECHNICAL
FFeeaattuurrees
s
E-1600-45A
K-1600-EHFA
E-1600A
E-1600-02A
E-1600-03B
E-1600-20A
Power: Telephone line powered. Minimum 24V DC talk battery voltage,
with a minimum loop current of 20mA loop. Loop current may be boosted
on low current lines with a Viking Model TBB-1B talk battery booster, see
DOD# 632.
Dimensions: See Installation and Specifications
Operating Temperature: -26° C to 54° C (-15° F to 130° F)
Humidity - Standard Products: 5% to 95% non-condensing
Humidity - EWP Products: Up to 100%
SSppeecciiffiiccaattiioonns
s
* Americans with Disabilities Act of 1992 contains federal reg-
ulations regarding elevator telephones (Public Law 101-336).
• Elevators
• Parking ramps/lots
• ATM machines
• Area of refuge locations
• Lobbies
• Entryways
• Campus emergency stations
• Roadside emergency stations
• Stadiums
• Convention centers
AApppplliiccaattiioonns
s
CAUTION - When installing on an analog extension of a phone system:
Some phone systems do not conform to analog telecom standards and might
not be compatible with the 1600A Series emergency phones. For a detailed
description of the telephone line specifications required for any of the 1600A
Series phones, see DOD# 869.
E-1600-55AE-1600-30A
E-1600-65A
E-1600-60A
IInnssttaallllaattiioonnaannddSSppeecciiffiiccaattiioonns
s
IMPORTANT: Electronic devices are susceptible to lightning and power station electrical surges from both the AC outlet and the telephone line.
It is recommended that a surge protector be installed to protect against such surges.
** Note: To increase surge protection, loosen the PCB mounting screw labeled (as shown) and fasten a wire with spade terminal (included) from the
mounting screw to Earth Ground (grounding rod, water pipe, etc.)
IF YOU HAVE A PROBLEM WITH A VIKING PRODUCT, PLEASE CONTACT: VIKING TECHNICAL SUPPORT AT (715) 386-8666
Our Technical Support Department is available for assistance Monday 8am - 4pm and Tuesday through Friday 8am - 5pm central time. So that we can give you better service, before you call please:
1. Know the model number, the serial number and what software version you have (see serial label).
2. Have your Technical Practice in front of you.
3. It is best if you are on site.
RETURNING PRODUCT FOR EXCHANGE
The following procedure is for equipment that has failed out-of-box (within 10 days of purchase):
1. Customer must contact Viking’s Technical Support at 715-386-8666 to determine possible causes for the problem. The
customer MUST be able to step through recommended tests for diagnosis.
2. If the Technical Support Product Specialist determines that the equipment is defective based on the customer's input
and troubleshooting, a Return Authorization (R.A.) number will be issued. This number is valid for fourteen (14)
calendar days from the date of issue.
3. After obtaining the R.A. number, return the approved equipment to your distributor, referencing the R.A. number. Your
distributor will then replace the product over the counter at no charge. The distributor will then return the product to
Viking using the same R.A. number.
4. The distributor will NOT exchange this product without first obtaining the R.A. number from you. If you haven't
followed the steps listed in 1, 2 and 3, be aware that you will have to pay a restocking charge.
RETURNING PRODUCT FOR REPAIR
The following procedure is for equipment that needs repair:
1. Customer must contact Viking's Technical Support Department at 715-386-8666 to obtain a Return Authorization (RA)
number. The customer MUST have a complete description of the problem, with all pertinent information regarding the
defect, such as options set, conditions, symptoms, methods to duplicate problem, frequency of failure, etc.
2. Packing: Return equipment in original box or in proper packing so that damage will not occur while in transit. Static
sensitive equipment such as a circuit board should be in an anti-static bag, sandwiched between foam and individually boxed. All equipment should be wrapped to avoid packing material lodging in or sticking to the equipment. Include
ALL parts of the equipment. C.O.D. or freight collect shipments cannot be accepted. Ship cartons prepaid to:
Viking Electronics, 1531 Industrial Street, Hudson, WI 54016
3. Return shipping address: Be sure to include your return shipping address inside the box. We cannot ship to a PO Box.
4. RA number on carton: In large printing, write the R.A. number on the outside of each carton being returned.
!
*** Note: When installing a line powered phone on a low voltage and/or low loop current phone system extension, a TBB-1B Talk Battery Booster
may be required. For more information on the TBB-1B, retrieve DOD# 632.
**** Note: When wires are routed from above, a “drip loop” is recommended to keep water away from the circuit board.
* Note: The gel-filled (water-tight) butt connectors are designed for insulation displacement on 19-26 guage wire with a maximum insulation of 0.082 inch-
es. Cut off bare wire ends prior to terminating.
LIMITED WARRANTY
Viking warrants its products to be free from defects in the workmanship or materials, under normal use and service, for a period of one year from the date of purchase from any authorized Viking distributor or 18 months from the date manufactured, which ever is greater. If at any time during the warranty period, the product is deemed defective or malfunctions, return the product to Viking Electronics, Inc., 1531 Industrial Street, Hudson, WI., 54016. Customer must contact Viking's
Technical Support Department at 715-386-8666 to obtain a Return Authorization (R.A.) number.
This warranty does not cover any damage to the product due to lightning, over voltage, under voltage, accident, misuse, abuse, negligence or any damage caused by use of the product by the purchaser or others. This warranty does not cover
non-EWP products that have been exposed to wet or corrosive environments.
NO OTHER WARRANTIES. VIKING MAKES NO WARRANTIES RELATING TO ITS PRODUCTS OTHER THAN AS DESCRIBED ABOVE AND DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTIES OR MERCHANTABILITY OR FIT-
NESS FOR ANY PARTICULAR PURPOSE.
EXCLUSION OF CONSEQUENTIAL DAMAGES
. VIKING SHALL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE TO PURCHASER, OR ANY OTHER PARTY, FOR CONSEQUENTIAL, INCIDENTAL, SPECIAL OR EXEMPLARY DAM-
AGES ARISING OUT OF OR RELATED TO THE SALE OR USE OF THE PRODUCT SOLD HEREUNDER.
EXCLUSIVE REMEDY AND LIMITATION OF LIABILITY. WHETHER IN AN ACTION BASED ON CONTRACT, TORT (INCLUDING NEGLIGENCE OR STRICT LIABILITY) OR ANY OTHER LEGAL THEORY, ANY LIABILITY OF VIKING SHALL
BE LIMITED TO REPAIR OR REPLACEMENT OF THE PRODUCT, OR AT VIKING'S OPTION, REFUND OF THE PURCHASE PRICE AS THE EXCLUSIVE REMEDY AND ANY LIABILITY OF VIKING SHALL BE SO LIMITED.
IT IS EXPRESSLY UNDERSTOOD AND AGREED THAT EACH AND EVERY PROVISION OF THIS AGREEMENT WHICH PROVIDES FOR DISCLAIMER OF WARRANTIES, EXCLUSION OF CONSEQUENTIAL DAMAGES, AND EXCLUSIVE REMEDY AND LIMITATION OF LIABILITY, ARE SEVERABLE FROM ANY OTHER PROVISION AND EACH PROVISION IS A SEPARABLE AND INDEPENDENT ELEMENT OF RISK ALLOCATION AND IS INTENDED TO BE ENFORCED
AS SUCH.
2
the necessary modifications to maintain uninterrupted service.
If trouble is experienced with the E-1600A Series phone, for repair or warranty information, please contact:
Viking Electronics, Inc., 1531 Industrial Street, Hudson, WI 54016 (715) 386-8666
If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the
equipment until the problem is resolved.
Connection to Party Line Service is subject to State Tariffs. Contact the state public utility commission, public service commission or corporation commission for information.
WHEN PROGRAMMING EMERGENCY NUMBERS AND (OR) MAKING TEST CALLS TO EMERGENCY NUMBERS:
Remain on the line and briefly explain to the dispatcher the reason for the call. Perform such activities in the off-peak
hours, such as early morning or late evenings.
It is recommended that the customer install an AC surge arrester in the AC outlet to which this device is connected. This
is to avoid damaging the equipment caused by local lightning strikes and other electrical surges.
PART 15 LIMITATIONS
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
FCC REQUIREMENTS
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. Located on the equipment is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone company.
The REN is used to determine the number of devices that may be connected to a telephone line. Excessive REN's on a
telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of
the REN's should not exceed five (5.0) To be certain of the number of devices that may be connected to a line, as determined by the total REN's, contact the local telephone company. For products approved after July 23, 2001, the REN for
this product is part of the product identifier that has the format US:AAAEQ##TXXXX. The digits represented by ## are the
REN without a decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately shown on the label.
The plug used to connect this equipment to the premises wiring and telephone network must comply with the applicable
FCC Part 68 rules and requirements adopted by the ACTA. If your home has specially wired alarm equipment connected
to the telephone line, ensure the installation of this E-1600A Series phone does not disable your alarm equipment. If you
have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.
If the E-1600A Series phone causes harm to the telephone network, the telephone company will notify you in advance that
temporary discontinuance of service may be required. But if advance notice isn't practical, the telephone company will
notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you
believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the
operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make
***
Analog
PABX/KSU
C.O. Line
Station
Rear View of a
1600A Series Phone
* Gel-Filled Butt
Connectors
-or-
Red
Green
**** Drip Loop
Ring
Terminal
(included)
** Earth Ground
(optional)
EE--11660000AA//--4455AA//--6600AA//--6655A
A
((ooppttiioonnaallEEWWPP)
)
Dimensions: 133mm x 102mm x 51mm (5.25” x 4.0” x 2.0”)
Shipping Weight: 1.13 kg (2.5 lbs.)
Material: .062” (16 gauge) steel, E-1600A - Red powder paint, E-1600-45A - Yellow powder paint, E-1600-60A/65A - Blue powder paint
Connections: Gel-filled butt connectors
Mounting: Surface mount to walls, posts, single gang boxes or 4” x 4” electrical junction boxes or recess mount in elevator phone boxes.
Optional Enhanced Weather Protection (EWP): The optional EWP products feature foam rubber gaskets and boots, sealed connec-
tions, gel-filled butt connectors, as well as urethane or thermal plastic potted circuit boards. See DOD# 859.
Note: For greater weather resistance, apply a bead of clear silicon caulking around the top edge and sides of the chassis.
2.00
4.00
5.25
0.703
diameter
4.96
3.40
3.40
1.70
1.70
3.30
3.82
2.00
1.15
EMERGENCY
PHONE
MODEL E-1600A
CALL
CONNECTED
PUSH FOR
VIKING©
HELP
Grade 2
Braille Label
Red Call
Connected LED
Push to Call
Button
POLICE
Condensation
Drain Hole
(Side View)
(Bottom
View)
(Front View)
(Rear
View)
on model E-1600-60A only
3/4" knockout
Model E-1600-45A has
"EMERGENCY" vertically
down the side. Model E1600-60A has "POLICE"
vertically down the side.
0.15 x 0.31 Wire
Exit Notch
(4) .20 diameter
mounting holes
(2) .20 x .40 slots
for single gang box
EE--11660000--0022A
A
((ooppttiioonnaallEEWWPP)
)
Dimensions: 330mm x 267mm x 51mm (13” x 10.5” x 2”)
Shipping Weight: 3.18 kg (7 lbs.)
Connections: Gel-filled butt connectors
Material: .125” (11 gauge) brushed stainless steel
Mounting: Flush mount in elevator cabs, ATMs, stairwells, hall-
ways, etc.
Suggested Hardware: (6) #8 x 3/4 flat head phillips sheet metal
type A screws (not included)
Optional Enhanced Weather Protection (EWP): The optional
EWP products feature foam rubber gaskets and boots, sealed connections, gel-filled butt connectors, as well as urethane or thermal
plastic potted circuit boards. See DOD# 859.
Note: When mounting outside to rough or uneven surfaces (brick,
stucco, etc.) apply a bead of clear silicone caulking around the top
edge and sides of faceplate or VE-5x5.
Front View
Side
View
Red Call
Connected
LED
Push To
Call Button
Grade 2
Braille
Label
Minimum
Cutout
(6) 0.188 diameter
countersunk holes
KK--11660000--EEHHFFA
A
VIIKKIINNGG
Dimensions: 251mm x 174mm x 53mm (9.875” x 6.86” x
2.10”)
Shipping Weight: .91 kg (2 lbs.)
Material: .062” (16 Gauge) Red powder painted steel
Connections: Gel-filled butt connectors
Mounting: Recess mounted in standard elevator phone
box (10.0” x 7.0” x 3.0”)
Front View
Top View
Side
View
3
Grade 2
Braille Label
(2) countersunk
mounting holes
for #8 flat head
screws (not
included)
8.50
9.875
0.675
0.70
0.25
13.0
12.5
0.25
6.25
1.60
3.1
EMERGENCY
PUSH FOR
HELP
EMERGENCY
PHONE
MODEL K-1600-EHFA
PUSH FOR
HELP
V
©
6.86
10.5
10.0
3.8
PHONE
MODEL E-1600-02A
VIKING©
VIKING©
CALL
CONNECTED
CALL
CONNECTED
Red Call
Connected LED
Push to Call
Button
4.8
4.7
2.0
2.10
* Note: Peel off paper liner and adhere gasket to the back of the faceplate, centering it over
the four corner mounting holes.
The black plastic rough-in box (part # 259576) may be
purchased separately (Example: Mounting boxes to
studs before the walls are finished for flush installation). Go to www.vikingelectronics.com and click on
“Spare Parts” to order these rough-in boxes.
EE--11660000--2200A
A
((ooppttiioonnaallEEWWPPaavvaaiillaabbllee)
)
4
Dimensions: Overall - 127mm x 127 x 57mm (5.0” x 5.0”
x 2.25”), Plastic Electrical Box - 102mm x 102mm x 54mm
(4.0” x 4.0” x 2.14”)
Shipping Weight: 1 kg (2.12 lbs.)
Front Panel Material: 14 gauge Marine grade 316
brushed stainless steel
Connections: Gel-filled butt connectors
The black plastic rough-in box (part # 259576) may be
purchased separately (Example: Mounting boxes to
studs before the walls are finished for flush installation).
Go to www.vikingelectronics.com and click on “Spare
Parts” to order these rough-in boxes.
EE--11660000--3300A
A
((ooppttiioonnaallEEWWPPaavvaaiillaabbllee)
)
Important: The E-1600-20A will NOT mount to a standard double gang box.
* Note: Peel off paper liner and adhere gasket to the back of the faceplate, centering it over the
four corner mounting holes.
Optional Enhanced Weather Protection (EWP): The optional EWP products feature
foam rubber gaskets and boots, sealed connections, gel-filled butt connectors, as well as
urethane or thermal plastic potted circuit boards. See DOD# 859.
Mounting with Plastic Rough-In Box (included): Flush into walls, mounts to side of wall
stud Mounting with Optional VE-5x5: Surface mount to walls, single gang boxes, double gang boxes, posts, or to a Viking VE-GNP Gooseneck pedestal (as shown above).
Note: When mounting outside to rough or uneven surfaces (brick, stucco, etc.) apply a
bead of clear silicone caulking around the top edge and sides of faceplate or VE-5x5.
Dimensions: Overall - 127mm x 127 x 57mm (5.0” x 5.0”
x 2.25”), Plastic Electrical Box - 102mm x 102mm x 54mm
(4.0” x 4.0” x 2.14”)
Shipping Weight: 1 kg (2.12 lbs.)
Front Panel Material: 14 gauge Marine grade 316
brushed stainless steel
Connections: Gel-filled butt connectors
Optional Enhanced Weather Protection (EWP): The optional EWP products feature
foam rubber gaskets and boots, sealed connections, gel-filled butt connectors, as well as
urethane or thermal plastic potted circuit boards. See DOD# 859.
Mounting with Plastic Rough-In Box (included): Flush into walls, mounts to side of wall
stud Mounting with Optional VE-5x5: Surface mount to walls, single gang boxes, double gang boxes, posts, or to a Viking VE-GNP Gooseneck pedestal (see options below).
Note: When mounting outside to rough or uneven surfaces (brick, stucco, etc.) apply a
bead of clear silicone caulking around the top edge and sides of faceplate or VE-5x5.
** Important: Optional Braille “Push for Help” label should be adhered to the faceplate in ADA applications. Clean surface with isopropyl alcohol, peel off backing and press firmly to the front panel in location as shown above.
*** Caution: When warm air comes in contact with cold surfaces, such as outside walls and conduits, it causes condensation. To prevent condensation from accumulating inside the E-1600-30A always bring conduit into the bottom of the unit. If this is not possible, drill a 1/4” diameter
hole in the bottom of the black plastic box.
** Caution: When warm air comes in contact with cold surfaces, such as outside walls and
conduits, it causes condensation. To prevent condensation from accumulating inside the E-1600-20A always bring conduit into the bottom of the unit. If
this is not possible, drill a 1/4” diameter hole in the bottom of the black plastic box.
Front View of
Plastic Rough-In
Box (included)
Wall Stud
Wire knock out
(2) Standard flat head dry wall
(sheet rock) screws (not included)
4.0"
2.1”
EMERGENCY
INFO
PHONE
* Adhere gasket to front panel,
centering over mounting holes
5.0”
5.14”
HELP
L
AL
C
ED
T
EC
NN
O
C
"Help" Push to Call Button
Call Connected Red LED
"Info" Push to Call Button
(4) 6-32 X 3/4” Marine grade 316 stainless steel,
flat head, 5/64" hexdrive screws (included)
Condensation Drain Hole
Grade 2 Braille
Label
Marine grade 316 stainless
steel faceplate and push
button switches
(sealed per IP67)
2.25”
5.22”
Front View of Optional
VE-5x5 (not included)
(4) 0.38” diameter
(4) 0.2 x 0.43 slots
for double gang box
(2) 0.2 x 0.43 slots
for single gang box
** 3/4"
Knockout
3.25”
3.8”
Condensation
Drain Hole
** 3/4" Knockout
for conduit
3.0”
Rear View of VE-5x5
(not included)
10.5”
3.0” 3.3”
Side View of VE-GNP
39.5”
42”
(not included)
Wall Stud
Front View of
Plastic Rough-In
Box (included)
4.0"
2.1”
* Adhere gasket to front panel,
centering over mounting holes
5.0”
Call Connected
Red LED
CONNECTED
Push to Call Button
5.14”
5.22”
3.25”
Condensation
*** 3/4" Knockout
(4) 0.38” diameter
(4) 0.2 x 0.43 slots
for double gang box
(2) 0.2 x 0.43 slots
for single gang box
Drain Hole
for conduit
3.0” 3.3”
Wire knock out
(2) Standard flat head dry wall
(sheet rock) screws (not included)
Marine grade 316 stainless
steel faceplate and push
button switches
Condensation Drain Hole
**Optional Braille Label
(4) 6-32 X 3/4” Marine grade 316 stainless steel, flat head, 5/64" hexdrive screws (included)
(sealed per IP67)
2.25”
Front View of Optional
VE-5x5 (not included)
3.0”
Rear View of VE-5x5
(not included)
Loading...
