Designer DDBB363
Viking Designer DDBB363, Professional VCBB363SS, Professional VCBB363, Professional VIBB363, Professional VCBB536BR Specification Sheet
...
REFRIGERATION
Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
RELEASED 12/1/07
©2007 VRC—INFORMATION SUBJECT TO CHANGE
All models include
• Total capacity—20.3 cu. ft. (574.5 L)
o
84”H./24”D.
• ProChill™ Temperature Management
System
o
Variable speed single compressor
system includes the quietest, most
technologically advanced
compressor available
o
Electronic controls maintain the
temperature selection within 1ºF
o
Multi-channel airflow system
removes odors and excess humidity
• Frost-free refrigerator
o
Capacity—15.2 cu. ft. (430.2 L)
o
Five adjustable tempered glass spillproof shelves
o
Convertible temperature-controlled
Meat Savor™/produce drawer with
precision ball-bearing glides
o
Seperate temperature control can
be set for produce or fresh meat
storage
•
Quick-chill option chills foods and
beverages in minutes
o
Two moisture adjustable seethrough produce drawers with precision ball-bearing glides
o
Two in-the-door dairy compartments
with covers
o
Five adjustable aluminum door bins
with tempered glass fronts
o
Top shelf provides quick chill-down
area
o
Egg bin and butter tray
• Frost-free freezer
o
Full-extension freezer drawer with
positive self-closing feature
o
Capacity—5.1 cu. ft. (44.3 L)
o
Adaptive defrost
o
Factory-installed automatic ice
maker
o
Two slide-out wire baskets
• Open door alarm sounds and glows to
warn that door has been ajar for three
minutes
• Adjustable door stops standard—90°,
110°, or 120° swing
• Sabbath Mode
• Must be ordered right or left hinge.
(As you face unit, RIGHT has hinge on
right side and handle on left side;
LEFT has hinge on left side and handle on right side.)
VCBB363/VIBB363
Professional/Professional
Integrated
FINISH DETAILS FOR DFBB MODEL
• Handles not included—opt for custom
handles, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• See Custom Panels section for
more information and additional
specifications.
FINISH DETAILS FOR DDBB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door fronts.
Stainless steel upper grille, side trim,
and handles, with black lower
kickplate.
• Brass Trim Option (BR)—handle. Brass
components maintenance-free normal
use.
FINISH DETAILS FOR VCBB/VIBB MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door fronts.
Stainless steel upper grille, side trim,
and handles (with chrome-plated
brackets); black lower kickplate.
• Brass Trim Option (BR)—nameplate,
handle/brackets, and side trim. Brass
components have a durable protective
coating for maintenance-free normal
use.
DDBB363
Designer
DFBB363
Custom Front
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify model number, followed by hinge preference (“R” for right or “L” for left), and then color code (VCBB363RSS).
If ordering optional brass trim, specify code at end (VCBB363RSSBR).
VCBB363/VIBB363
Professional/Professional
Integrated
REFRIGERATION
Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
RELEASED 12/1/07
©2007 VRC—INFORMATION SUBJECT TO CHANGE
✪
Please see
Installation Notes &
Accessories
for important
information,
including panel,
grille, and handle
kits.
36”
(91.4 cm)
22-3/
16”
(56.4 cm)
24-11/16”
(62.7 cm)
27-1/4”
(69.2 cm)
35”
(88.9 cm)
82-3/4”
(210.2 cm)
min.
to
84-1/16”
(213.5 cm)
max.
79-17/32”
(202 cm)
51-1/2”
(130.8 cm)
3-19/32”
(9.1 cm)
23-
1/16”
(58.5 cm)
36”
(91.4 cm)
23-3/
8”
(59.4 cm)
24”
(61
.0
cm)
26-1/2”
(67.3 cm)
35”
(88.9 cm)
82-3/4”
(210.2 cm)
min.
to
84-1/1
6”
(213.5 cm)
max.
79-17/32”
(202 c
m)
51-1/2”
(130.8 cm)
3-19/32”
(9.1 cm)
23-1/1
6”
(58.5 cm)
VCBB363 VIBB363
Overall width 36” (91.4 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm)
To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm)
To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)
Approx. ship weight 565 lbs. (254.3 kg)
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Specifications
PRODUCT DIMENSIONS
PROFESSIONAL PROFESSIONAL
INTEGRATED
ALL MODELS
35”
(88.9 cm)
82-7/8”
(210.5 cm)
min.
to
84-1/16”
(213.5 cm)
max.
23-3/8”
(59.4 cm)
24”
(61.0 cm)
79-17/32”
(202 cm)
51-1/2”
(130.8 cm)
3-1/2”
(8.9 cm)
23-1/16”
(58.5 c
m)
36”
(91.4 cm)
26”
(66.0
cm)
DESIGNER
35”
(88.9 cm)
82-7/8”
(210.5 cm)
min.
to
84-1/1
6”
(213.5 cm)
max.
23-13/16”
(60.5 cm)
24-3/4”
(62.9 cm)
79-17/32”
(202 cm)
51-1/2”
(130.8 cm)
3-1/2”
(8.9 cm)
23-1/16”
(58.5 c
m)
36”
(91.4 cm)
V
ar
ies
CUSTOM FRONT
REFRIGERATION
Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
RELEASED 12/1/07
©2007 VRC—INFORMATION SUBJECT TO CHANGE
DDBB363
Designer
DFBB363
Custom Front
✪
Please see
Installation Notes &
Accessories
for important
information,
including panel,
grille, and handle
kits.
DDBB363 DFBB363
Overall width 36” (91.4 cm)
Overall height (from bottom) 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 23-3/8” (59.4 cm) 23-13/16” (60.5 cm)
To front of top grille 24” (61.0 cm) 24-3/4” (62.9 cm)
To front of handle 26” (66.0 cm) Varies
Approx. ship weight 565 lbs. (254.3 kg) 500 lbs. (227.3 kg)
See Custom Panels section for
more information and additional
specifications.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Specifications
PRODUCT DIMENSIONS
ALL MODELS
