ViewSonic VX1940W - 19"" LCD Monitor Specification Sheet
VX1940w
19" WIDESCREEN LCD
WITH 3000:1 DYNAMIC CONTRAST
Enjoy HD content on your desktop.
ViewSonic’s 19" VX1940w widescreen LCD delivers unparalleled
performance with video response as fast as 2ms, 3000:1 DYNAM-
IC CONTRAST RATIO and SUPER-HD 1680X1050 RESOLUTION.
Games, HD movies, videos and graphic-intensive applications have
™
never looked better on your desktop. This Vista
WIDESCREEN DISPLAY ENHANCES PRODUCTIVITY by allowing
you to view two documents side-by-side or to work in two applications
without toggling. Connect your game console, DVD player and other
components through the DIGITAL (DVI-D) AND ANALOG INPUTS.
®
The Kensington
security port provides theft deterrence and the
OSD and power lock prevent unauthorized changes to your optimal
screen settings.
ENHANCE PRODUCTI VITY
AND ENTERTAINMENT
premium certified
Full 19" viewable widescreen with 1680x1050 resolution >
High resolution panel with 36% more clarity than a regular
19" wide monitor.
Fast ClearMotiv >
Video response as fast as 2ms enables digital HD
broadcast-quality video.
3000:1 dynamic contrast ratio >
Provides for darker black levels and better overall
front-of-screen performance.
Stylish slim-bezel design >
The thin bezel lets you see more without taking up valuable
desktop real estate. The high neck and floating head design
accentuate the visual experience.
OptiSync >
Multi-mode input technology supports both digital (DVI) and analog
(VGA) signals for ultimate compatibility and configuration flexibility.
Amplified Impulse >
Advanced amplified impulse technology accelerates grayscale
transitions for superior video and gaming.
OnView >
Screen adjustments are precisely made via
an easy-to-use on-screen menu.
Windows >
PC and Mac compatible >
TCO’03 and ENERGY STAR >
®
video response
®
digital/analog inputs expand your connectivity
™
technology
®
controls for superior screen adjustability
Vista® certified
®
qualified
VX1940w
19" WIDESCREEN LCD WITH 3000:1 DYNAMIC CONTRAST
LCD Type 19" Wide Color TFT Active Matrix LCD
Display Area 16.1" horizontal x 10.0" vertical; 19.0" diagonal
Optimum Resolution 1680x1050
Contrast Ratio 1000:1 static (typ), 3000:1 dynamic (typ)
Viewing Angles 170º horizontal, 160º vertical @ contrast ratio > 10:1
Response Time up to 2ms (gray-to-gray); 5ms black-to-white (typ)
Light Source Long life, 40,000 hrs. (typ)
Brightness 300 cd/m
Panel Surface Anti-glare
VIDEO INPUT Analog/Digital RGB analog (75 ohms, 0.7 Vp-p)/DVI-D (with HDCP)
Frequency Fh: 24~82kHz, Fv: 50~85Hz
Sync H/V separated (TTL), composite, sync-on-green
COMPATIBILITY PC VGA up to 1680x1050 non-interlaced
Mac
CONNECTOR Analog/Digital 15-pin mini D-sub/DVI-D
Power 3-pin AC plug (CEE22)
POWER Voltage AC 100–240V, 50–60Hz (auto switch)
Consumption 44W (typ)
CONTROLS Basic Power, 1, down, up, 2
OnView
(analog, digital), ViewMatch
7500K, 6500K-default, 5400K, user color-RGB),
information (resolution, H. frequency, V. frequency, pixel
clock, model number, serial number), manual image
adjust (H. size, H. position, V. position, fine tune,
sharpness, dynamic contrast aspect ratio), setup menu
(language, resolution notice, OSD position, OSD
timeout, OSD background), memory recall
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 10–90% (non-condensing)
DIMENSIONS Physical with stand 17.4" x 15.1" x 7.7" (442mm x 385mm x 195mm)
(W x H x D) Physical without stand 17.4" x 12.2" x 2.1" (442mm x 310mm x 54mm)
WEIGHT Net with stand 10.1 lb. (4.6 kg)
Net without stand 8.3 lb. (3.8 kg)
Gross with stand 12.7 lb. (5.8 kg)
REGULATIONS UL, cUL, FCC-B, CB, CE, ENERGY STAR
GS, ERGO (covers TUV/ERGO, ISO 13406-2 & MPR II),
TCO’03, GOST-R + 20 original copies hygienic, SASO,
PCBC, VCCI, BSMI, CCC, PSB, C-TICK, TUV-S/IRAM/UL AR S Mark, Green Mark, RoHS, EPEAT-Silver
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
POWER MANAGEMENT Meets TCO’03 and ENERGY STAR
PACKAGE CONTENTS LCD display, power cable, 15-pin VGA video cable,
DVI cable, Quick Start Guide, ViewSonic Wizard CD
WARRANTY Three-year limited warranty on LCD, parts and labor
®
* G3/G4/G5 up to 1680x1050
®
Auto image adjust, brightness, contrast, input select
2
(typ)
®
color adjust (sRGB, 9300K,
®
, NOM,
®
standards
ViewSonic Corporation’s QMS & EMS have been
registered to ISO 9001 & ISO 14001, respectively,
by the British Standards Institution.
Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete
details. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Corporate names, trademarks stated herein are the property of
their respective companies. Copyright © 2008 ViewSonic Corporation. All rights reserved. [13998-01B-09/08] VX1940w-1
For more product information, visit us on the web at ViewSonic.com
