ViewPad 4
User Guide
Model No. VS14034
Page 2
i
Compliance Information
For Battery
Risk of explosion if battery replaced aced by an incorrect type. Dispose of used
batteries according to the instructions.
For Charger
Users have to use the connection to USB interfaces with USB 2.0 version or higher.
PLUGGABLE EQUIPMENT, the socket-outlet shell be installed near the equipment
and shall be easily accessible.
Please read before proceeding
Use only the batteries and power adapter provided by the manufacturer. The use of
unauthorized accessories may void your warranty.
Do not store your phone in temperatures higher than 55° C or 131° F.
The operating temperature for this device is from -10° C to 42° C .
CE SAR Information
THIS MOBILE DEVICE MEETS GUIDELINES FOR EXPOSURE TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the
limits for exposure to radio waves recommended by international guidelines. These
guidelines were developed by the independent scientific organization ICNIRP and
include safety margins designed to assure the protection of all persons, regardless of
age and health.
The exposure guidelines for mobile devices employ a unit of measurement known as
the Specific Absorption Rate or SAR. The SAR limit stated in the ICNIRP guidelines is
2.0 W/kg averaged over 10 grams of tissue. Test for body worn SAR, the positions of
the device are at a minimum of 1.5 cm from the body with the device transmitting at its
highest certified power level in all tested frequency bands. The actual SAR level of an
operating device can be below the maximum value because the device is designed to
use only the power required to reach the network. That amount changes depending
on a number of factors such as how close you are to a network base station. The
highest SAR value under the ICNIRP guidelines for use of the device at the ear is
0.451 W/kg and at the body is 0.436 W/kg. Use of device accessories and
enhancements may result in different SAR values. SAR values may vary depending
on national reporting and testing requirements and the network band.
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage
Directive 2006/95/EC.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment as
unsorted municipal waste, but use the return and collection systems according
to local law.
If the batteries, accumulators and button cells included with this equipment,
display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a
heavy metal content of more than 0.0005% Mercury, or more than 0.002%
Cadmium, or more than 0.004% Lead.
Page 3
ii
European Union Regulatory Conformance
The equipment complies with the RF Exposure Requirement 1999/519/EC, Council
Recommendation of 12 July 1999 on the limitation of exposure of the general public to
electromagnetic fields (0–300 GHz). This equipment meets the following conformance
standards: EN62209-1/2, EN60950-1, IEC60950-1, EN50332-1/2, EN301489-1,
EN301489-3, EN301489-7, EN301489-17, EN301489-24, EN301511, EN301908-1/2,
EN300328, EN300440-1/2, EN55022, EN55024.
For the device which is tested in accordance to EN60950-1:2006, it is
mandatory to perform audio tests for EN50332. The device has been tested
to comply with the Sound Pressure Level requirement laid down in the
applicable EN 50332-1 and EN 50332-2 standards. Permanent hearing
loss may occur if earphones or headphones are used at high volume for prolonged
periods of time.
A pleine puissance, l’écoute prolongée du baladeur peut endommager l’oreille de
l’utilisateur.
The conformity assessment procedure has been followed with the involvement of the
following Notified Body:
PHOENIX TESTLAB
Identification mark: CE0700 (Notified Body) CE
We, hereby, declare that this cellular, Wi-Fi, & Bluetooth radio is in compliance with
the essential requirements and other relevant provisions of Directive 1999/5/EC.
Products with 2.4-GHz Wireless LAN Devices France
For 2.4-GHz wireless LAN operation of this product, certain restrictions apply. This
equipment may use the entire-2400-MHz to 2483.5-MHz frequency band (channels 1
through 13) for indoor applications. For outdoor use, only 2400-2454 MHz frequency
band (channels 1-9) may be used. For the latest requirements, see http://www.arttelecom.fr.
This equipment may be operated in:
AT BE BG CH CY CZ DE DK
EE ES FI FR GB GR HU IE
IT IS LI LT LU LV MT NL
NO PL PT RO SE SI SK TR
0700
Page 4
iii
Guarantee of Provision of Operating Instructions
This company hereby guarantees that all large-screen smartphones sold (or
manufactured) by it (including their LP RF electric devices or modules) (brand:
ViewSonic, model number: VS14034) shall have operating instructions inside the
packaging when they are made available on the market. The instructions or external
packaging of the products shall contain: (1) a warning that reads, “Use properly to
reduce the effect of electromagnetic waves”; (2) a measured value of SAR 0.451 W/
Kg; (3) instructions on the safe use of batteries/electric power; (4) a warning that
reads, “Without permission, companies, stores or users shall not arbitrarily change or
amplify the power or modify the features and functions of the original design of this LP
RF electric device, which has obtained an LP approval certificate”; and (5) a warning
that reads, “Use of LP RF electric devices shall not impact flight safety or interfere with
legitimate telecommunication. If interference is found, use of the device shall be
immediately terminated, and usage shall not resume until the interference is
eliminated. Legitimate telecommunication refers to wireless telecommunication
conducted as per the Telecommunications Act. LP RF electric devices must endure
the interference caused by electrical waves sent out or radiation produced by
legitimate telecommunication or industrial, scientific and medical devices.” If this
company contravenes its guarantee, it shall unconditionally accept revocation of the
approval certificate issued to it, be held legally responsible, and pay for all losses
suffered by the users.
Page 5
iv
Important Safety Instructions
1. DO NOT place objects on top of the ViewPad, as objects may scratch the screen.
2. DO NOT expose the ViewPad to dirty or dusty environments.
3. DO NOT place the ViewPad on an uneven or unstable surface.
4. DO NOT insert any foreign objects into the ViewPad.
5. DO NOT expose the ViewPad to strong magnetic or electrical field.
6. DO NOT expose the ViewPad to direct sunlight as it can damage the LCD Screen.
Keep it away from heat sources.
7. SAFE TEMPERATURE: This ViewPad should only be used in environments with
ambient temperatures between -15°C (5°F) and 55°C(131°F).
8. DO NOT use the ViewPad in the rain.
9. Please check with your Local Authority or retailer for proper disposal of electronic
products.
10. The ViewPad and the adapter may produce some heat during normal operation or
charging. DO NOT leave the ViewPad on your lap to prevent discomfort or injury
from heat exposure.
11. POWER INPUT RATING: Refer to the rating label on the ViewPad and be sure
that the power adapter complies with the rating. Only use accessories specified
by the manufacturer.
12. DO NOT use a pen or any sharp object to tap the screen.
13. Clean the touch screen with a soft cloth. If needed, dampen the cloth slightly
before cleaning. Never use abrasives or cleaning solutions.
14. Always power off the ViewPad to install or remove external devices that do not
support hot-plug.
15. Disconnect the ViewPad from an electrical outlet and power off before cleaning
the ViewPad.
16. DO NOT disassemble the ViewPad, only a certified service technician should
perform repair.
17. The ViewPad has apertures to disperse heat. DO NOT block the ViewPad
ventilation, the ViewPad may become hot and malfunction as a result.
18. Risk of explosion if battery replaced aced by an incorrect type. Dispose of used
batteries according to the instructions.
19. Users have to use the connection to USB interfaces with USB 2.0 version or
higher.
20. PLUGGABLE EQUIPMENT, the socket-outlet shell be installed near the
equipment and shall be easily accessible.
Page 6
v
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive 2002/
95/EC of the European Parliament and the Council on restriction of the use of certain
hazardous substances in electrical and electronic equipment (RoHS Directive) and is
deemed to comply with the maximum concentration values issued by the European
Technical Adaptation Committee (TAC) as shown below:
Certain components of products as stated above are exempted under the Annex of
the RoHS Directives as noted below:
Examples of exempted components are:
1. Mercury in compact fluorescent lamps not exceeding 5 mg per lamp and in other
lamps not specifically mentioned in the Annex of RoHS Directive.
2. Lead in glass of cathode ray tubes, electronic components, fluorescent tubes, and
electronic ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by
weight or more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight,
aluminium containing up to 0.4% lead by weight and as a cooper alloy containing
up to 4% lead by weight.
Substance Proposed Maximum Concentration Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr
6+
)
0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Page 7
vi
Copyright Information
Copyright © ViewSonic® Corporation, 2011. All rights reserved.
Android is a trademark of Google Inc. Use of this trademark is subject to Google
Permissions.
This product has an Android™ platform based on Linux, which can be expanded by a
variety of JME-based application SW.
All products used in this device and trademarks mentioned herein are trademarks or
registered trademarks of their respective owners.
Google™, the Google logo, Android™, the Android logo and Gmail™ are trademarks
of Google Inc. Use of this trademark is subject to Google Permissions.
Wi-Fi and the Wi-Fi CERTIFIED logo are registered trademarks of the Wireless
Fidelity Alliance.
microSD™ is a trademark of SD Card Association.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.
Java, JME and all other Java-based marks are trademarks or registered trademarks
of Sun Microsystems, Inc. in the United States and other countries.
The prediction engine of the input method is TOUCHPAL, provided by COOTEK.
DataViz and RoadSync are registered trademarks of DataViz, Inc. All rights reserved.
DataViz and Documents To Go are trademarks or registered trademarks of DataViz,
Inc. All rights reserved.
Word To Go™, Sheet To Go®, Slideshow To Go®, PDF To Go® and icons are
trademarks or registered trademarks of DataViz, Inc. All rights reserved.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting
from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves
the right to change product specifications without notice. Information in this document
may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for
any purpose without prior written permission from ViewSonic Corporation.
Intellectual Property Right Information
Right to all technologies and products that comprise this device are the property of
their respective owners:
This product has an Android platform based on Linux, which can be expanded by a
variety of Java-Script-based application SW.
Google, the Google logo, Android, the Android logo, Gmail, and YouTube are
trademarks of Google Inc.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.
Java, JME and all other Java-based marks are trademarks or registered trademarks
of Sun Microsystems, Inc. in the United States and other countries.
microSD is a trademark of SD Card Association.
The prediction engine of the input method is TOUCHPAL, provided by COOTEK.
Page 8
vii
Product Registration
To meet your future needs, and to receive any additional product information as it
becomes available, please register your product on the Internet at:
www.viewsonic.com.
Product disposal at end of product life
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic
website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx
Risk group 2
CAUTION
•Possibly hazardous optical radiation emitted from this product.
•Do not stare at operating lamp. May be harmful to the eyes.
IEC 62471: 2006
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
ViewPad 4
VS14034
ViewPad 4_UG_ENG Rev. 1a 03-21-11
_________________________________
_________________________________
Page 9
viii
Chapter 1: Getting Started.................................................................... 1
1.1 Your Phone .................................................................................................. 1
Front............................................................................................................ 1
Back ............................................................................................................ 1
Top .............................................................................................................. 2
Down ........................................................................................................... 2
Side ............................................................................................................. 2
1.2 Accessories ................................................................................................. 2
1.3 Installing SIM Card, Battery and Memory Card ........................................ 3
SIM card...................................................................................................... 3
Memory card ............................................................................................... 3
Battery......................................................................................................... 4
1.4 Charging Battery ......................................................................................... 5
1.5 Using Headsets ........................................................................................... 5
1.6 Turning Phone On or Off ............................................................................ 6
1.7 Unlocking the Screen.................................................................................. 7
Chapter 2: The Basics........................................................................... 8
2.1 Home Screen ............................................................................................... 8
Extended Home screen............................................................................... 8
Status Bar Icons.......................................................................................... 9
Shortcut menu........................................................................................... 11
Using widgets............................................................................................ 12
Application drawer..................................................................................... 12
Setting wallpaper....................................................................................... 13
Changing ViewScene................................................................................ 14
2.2 Adjusting Volume...................................................................................... 14
2.3 Contacts ..................................................................................................... 15
Adding contacts......................................................................................... 15
Searching for contacts .............................................................................. 15
Importing contacts..................................................................................... 16
Backing up contacts .................................................................................. 16
Favorite contacts....................................................................................... 17
Chapter 3: Using the Phone ............................................................... 18
3.1 Making a Call ............................................................................................. 18
3.2 Answering a call ........................................................................................ 19
Chapter 4: Entering Information ........................................................ 20
4.1 On-Screen Keyboard................................................................................. 20
Using the on-screen keyboard .................................................................. 20
Setting input method ................................................................................. 21
4.2 Configuring Keyboard Settings ............................................................... 21
Chapter 5: Email & Messaging........................................................... 22
5.1 Text Message............................................................................................. 22
Creating and sending a text message....................................................... 22
Receiving and managing messages ......................................................... 23
Page 10
ix
5.2 Multimedia Message ................................................................................. 25
Creating and sending multimedia messages ............................................ 25
5.3 Voice Message........................................................................................... 26
5.4 Email Accounts ......................................................................................... 27
Setting up an Internet email account......................................................... 27
Viewing email accounts............................................................................. 27
5.5 Using Email................................................................................................ 28
Composing and sending emails ................................................................ 28
Receiving emails ....................................................................................... 28
Reading and replying to emails................................................................. 29
Managing email folders ............................................................................. 29
Customizing email settings ....................................................................... 30
Chapter 6: Using Internet ................................................................... 31
6.1 Connecting to Internet .............................................................................. 31
Wi-Fi.......................................................................................................... 31
Cellular Data Network ............................................................................... 33
Starting a Data Connection ....................................................................... 34
6.2 Browsing Web Pages................................................................................ 35
Managing web pages ................................................................................ 35
Chapter 7: Google Apps ..................................................................... 37
7.1 Gmail .......................................................................................................... 37
Signing in to Gmail .................................................................................... 37
Refreshing Gmail ...................................................................................... 37
Creating and sending emails..................................................................... 37
Reading and replying to emails................................................................. 38
Forwarding emails..................................................................................... 38
Managing emails ....................................................................................... 38
Viewing folder labels ................................................................................. 39
Searching for emails ................................................................................. 39
Configuring Gmail settings ........................................................................ 39
7.2 Talk ............................................................................................................. 40
Signing in to Google Talk .......................................................................... 40
Google Talk options .................................................................................. 40
Starting chat .............................................................................................. 40
Configuring Google Talk settings .............................................................. 41
7.3 Maps ........................................................................................................... 41
Viewing Map.............................................................................................. 41
Finding places ........................................................................................... 42
7.4 Navigation .................................................................................................. 43
Getting directions ...................................................................................... 43
Finding your current location..................................................................... 44
7.5 Latitude ...................................................................................................... 44
Starting Latitude ........................................................................................ 44
Configuring privacy settings ...................................................................... 45
7.6 Market......................................................................................................... 45
Searching for applications......................................................................... 45
Downloading applications ......................................................................... 45
Page 11
x
Removing applications .............................................................................. 46
7.7 Places ......................................................................................................... 46
7.8 Google Search ........................................................................................... 47
Searching information by entering text...................................................... 47
7.9 Voice Search.............................................................................................. 47
7.10 YouTube ................................................................................................... 48
Watching videos........................................................................................ 48
Uploading videos....................................................................................... 48
Searching videos....................................................................................... 48
7.11 Facebook.................................................................................................. 48
Logging in to Facebook............................................................................. 48
Chapter 8: Using Bluetooth................................................................ 49
8.1 Connecting to Bluetooth Devices............................................................ 49
Chapter 9: Multimedia Applications .................................................. 50
9.1 Videos and Photos .................................................................................... 50
Recording a video ..................................................................................... 50
Taking a photo .......................................................................................... 51
Reviewing a video ..................................................................................... 51
Reviewing a photo..................................................................................... 52
Configuring camera settings ..................................................................... 52
9.2 Viewing Videos & Photos ......................................................................... 54
Playing videos ........................................................................................... 54
Viewing photos.......................................................................................... 54
9.3 Using Music Player ................................................................................... 55
Music screen ............................................................................................. 55
Playing music ............................................................................................ 56
Changing playback options ....................................................................... 56
Managing playlists..................................................................................... 57
Chapter 10: Programs......................................................................... 58
10.1 Browser .................................................................................................... 60
10.2 Calculator................................................................................................. 60
10.3 Calendar ................................................................................................... 61
10.4 Camcorder ............................................................................................... 61
10.5 Camera ..................................................................................................... 61
10.6 Clock......................................................................................................... 61
10.7 Contacts ................................................................................................... 61
10.8 Documents To Go ................................................................................... 62
10.9 Email......................................................................................................... 62
10.10 Facebook................................................................................................ 62
10.11 File Browser........................................................................................... 63
Managing files and folders ........................................................................ 63
10.12 FM Radio ................................................................................................ 63
Recording the radio................................................................................... 64
10.13 Gmail ...................................................................................................... 64
10.14 Google Search ....................................................................................... 64
Page 12
xi
10.15 Latitude .................................................................................................. 64
10.16 Maps ....................................................................................................... 64
10.17 Market..................................................................................................... 65
10.18 Messaging.............................................................................................. 65
10.19 Music ...................................................................................................... 65
10.20 My Gallery .............................................................................................. 65
10.21 Navigation .............................................................................................. 65
10.22 News & Weather .................................................................................... 66
Viewing News & Weather.......................................................................... 66
Changing News & Weather settings ......................................................... 66
10.23 Note Pad................................................................................................. 67
Create notes.............................................................................................. 67
10.24 Phone ..................................................................................................... 67
10.25 Places ..................................................................................................... 67
10.26 RSS Reader............................................................................................ 68
10.27 Settings .................................................................................................. 68
10.28 SIM Toolkit ............................................................................................. 68
10.30 Talk ......................................................................................................... 68
10.31 Video Portal ........................................................................................... 69
10.32 Videos..................................................................................................... 69
10.33 Voice Dialer............................................................................................ 70
10.34 Voice Note.............................................................................................. 70
Recording voice notes............................................................................... 70
Playing voice notes ................................................................................... 70
10.35 Voice Search.......................................................................................... 70
10.36 YouTube ................................................................................................. 71
Chapter 11: Managing Your Phone.................................................... 72
11.1 Phone Settings ........................................................................................ 72
Wireless & networks.................................................................................. 72
Call settings............................................................................................... 72
Sound........................................................................................................ 72
Display ...................................................................................................... 73
Location & security.................................................................................... 73
Applications............................................................................................... 74
Accounts & sync........................................................................................ 74
Privacy ...................................................................................................... 74
SD card & phone storage.......................................................................... 74
Language & keyboard ............................................................................... 75
Voice input & output .................................................................................. 75
Accessibility............................................................................................... 75
Date & time ............................................................................................... 75
About phone.............................................................................................. 75
11.2 Changing Basic Settings ........................................................................... 76
Date and time settings .............................................................................. 76
Alarms settings.......................................................................................... 76
Display settings ......................................................................................... 77
Ringtone settings ...................................................................................... 77
11.3 Using Wireless & networks .................................................................... 77
Page 13
xii
11.4 Protecting Your Phone ........................................................................... 78
SIM card PIN settings ............................................................................... 78
Screen lock protection settings ................................................................. 78
11.5 Resetting the Phone................................................................................ 79
Specifications ..................................................................................................... 80
Page 14
1
Chapter 1: Getting Started
1.1 Your Phone
Front
Back
Return
Menu:
Press to view
menu options.
Home:
• Press to return to Home
screen.
Search
Front camera
Sensors (Ambient light and proximity sensor)
Earpiece
Microphone
Touch screen
5 Megapixels camera:
See “Videos and Photos”
on page 50.
Microphone
Flash LED
Back cover
Page 15
2
Top
Down
NOTE: The battery can also be charged when you connect your phone to a computer
using the USB cable.
Side
1.2 Accessories
Your package comes with the following items. If any of them is missing, please contact
your retailer.
•ViewPad 4
• AC adapter and plugs
• Micro USB cable
• Headset
• Li-ion battery
• Compliance Information
3.5mm Headset jack:
Use a headset for hands-free
conversation or listening to music.
Micro HDMI type connector
Micro USB connector:
• Connect USB cable to PC as a modem /
USB mass storage.
• Connect USB cable and the AC adapter to
charge the battery.
Power:
• Press and hold for 5
seconds to turn the
device on or off.
• To save battery,
press to temporarily
turn the screen on or
off.
Speakers
Speakers
Volume: Press to
adjust the volume.
Page 16
3
1.3 Installing SIM Card, Battery and Memory Card
To remove the back cover
1. Turn the phone off.
2. Push and slide downwards to open the
back cover.
SIM card
The SIM card contains your phone number, contacts, and network service details.
To install the SIM card
1. Remove the battery.
2. Insert the SIM card as shown. Make sure the
gold contacts are facing down.
To remove the SIM card
1. Remove the battery.
2. Use your finger to push and slide the SIM
card out of the card slot.
Memory card
You need a microSD® card to store photos, music, videos, and other data.
To install the memory card
Insert the memory card with the gold contacts
facing down.
To remove the memory card
1. For safe removal, tap > Settings > SD card
& phone storage > Unmount SD card.
2. Remove the back cover.
3. Use your finger to push and slide the memory
card out of the card slot.
Page 17
4
Battery
Your phone comes with a rechargeable Li-Ion battery. Battery life varies depending on
usage.
To install the battery
Insert the battery. Make sure the contacts of the
battery are aligned with the connectors in the
battery slot.
To remove the battery
Use your fingertip to lift the battery tab and
remove the battery.
To replace the back cover
Secure the hooks on the back cover with
designated holes on the device and close the
back cover.
NOTE: To ensure battery performance and avoid the risk of fire:
• Use only original batteries designated for the phone.
• Do not store batteries in temperatures below -10ºC or higher than 45ºC.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSED OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
Page 18
5
1.4 Charging Battery
The battery is only partially charged. To fully charge the battery, charge it for 2 hours.
Charge the battery
1. Plug the Micro USB connector to the Micro
USB port of your phone as shown.
2. Plug the other end to the AC adapter.
3. Plug the AC adapter to a wall outlet to start
charging.
When the battery is charging, the LED indicator
turns on (red). If the phone is turned on, the
icon is displayed on the status bar.
When the battery is fully charged, the LED
indicator turns green. If the phone is turned on,
the icon is displayed on the status bar.
NOTE:
• The battery can also be charged when you connect your phone to the
computer using a USB cable.
• To ensure safety, do not remove the battery from the phone while the AC
adapter is connected or while it is being charged.
1.5 Using Headsets
For hands-free conversation or listening to music, plug a headset to the headset jack.
NOTE:
• When using a headset, your ability to hear outside sounds may be limited.
Do not use headset if it will endanger you.
• When using a headset, do not set the volume to its maximum as it may
damage your hearing.
Page 19
6
1.6 Turning Phone On or Off
After installing the SIM card and charging the battery, you are now ready to turn on
your phone.
To turn on your phone
Press and hold the Power button until the phone vibrates.
To turn off your phone
1. Press and hold the Power button for 5 seconds.
2. A pop-up window appears, tap Power off.
3. Select OK to confirm.
To set your phone to Sleep mode
To set the phone to sleep mode, press the Power button. This will turn the display off.
To turn the display on, press the Power button again.
Page 20
7
1.7 Unlocking the Screen
By default, the screen automatically locks after a period of inactivity. You can set the
length of time until the screen locks, see “Display” on page 73.
To unlock the screen
1. Press the Power button to turn on the display from Sleep mode.
2. Drag to the center of the screen to unlock the screen.
Page 21
8
Chapter 2: The Basics
2.1 Home Screen
From the Home screen, you can quickly access common features and view
notifications of missed calls, received messages, battery and connection status.
Extended Home screen
Swipe your finger to the left or right across the Home screen.
The two extensions to the left and to the right of the Home screen provide more space
for icons, widgets, shortcuts, and other items.
Application Drawer
Tap to view the applications
and settings of the phone.
Status bar
• Displays status and
notification icons and
clock.
• Message, appointment,
task, and connection
notifications are also
displayed here.
Google Search
Enter the text you
want to search in
the box.
Swipe left/right to
view the extended
Home screen.
Shortcut Menu
Tap an icon to
access the
application.
Phone
Tap to make calls.
Browser
Tap to browse the Internet.
Page 22
9
Status Bar Icons
Status bar icons indicate different types of information.
The icons on the status bar indicate the following information:
Signal strength icon
Bluetooth icon
USB connection
icon
Battery icon
Network icon
Volume icon
The following icons may appear on the
volume icon area.
To adjust the volume, see “Adjusting
Volume” on page 14.
Battery icon
The following icons may appear on the
battery icon area:
To charge the battery, see “Charging
Battery” on page 5.
Icon Description
Sound is off.
Vibrate mode is activated.
Speakerphone is on.
Phone is muted.
Icon Description
Battery is full.
Battery is low.
Battery is charging.
Phone Network icon
The following icons may appear on the phone network icon area.
Icon Description
No network signal.
Maximum signal strength. Fewer
bars indicate lower signal
strength.
GPRS network is in use.
Call is in progress.
Call is on hold.
No SIM card inserted.
Icon Description
Page 23
10
Tap the status bar and scroll down to view
notifications or view system information easily. To
close the window, tap .
Connection icon
The following icons may appear on the
connection icon area.
Notification icon
The following icons may appear on the
notification icon area.
Icon Description
WiFi is connected.
Bluetooth connection is active.
GPRS data connection is active.
HSDPA data connection is
active.
Device is connected to PC via
USB connector.
File has been downloaded.
Icon Description
New text message notification.
New WAP Push notification.
New email notification.
New Google mail notification.
Alarm.
Task notification.
Missed call notification.
Page 24
11
Shortcut menu
The shortcut menu allows you to easily access an application from the Home screen.
To open an application, tap an icon.
Customizing shortcut menu
To add a shortcut:
1. Tap Menu > Add > Shortcuts.
2. Tap Applications to display the list of applications.
3. Tap to add the items that you want to appear on the
Home screen.
To remove shortcut:
1. Tap and hold an application icon. The icon enlarges.
The icon appears on the bottom of the Home
screen.
2. Drag the application icon to icon to delete. The
application icon is removed from the Home screen.
Page 25
12
Using widgets
Save time with live updates right on the Home screen and get all your personalized
updates in one place.
You may add and customize the Widgets on the Home screen as you like.
1. From the Home screen, tap Menu > Add >
Widgets.
A list of all available widgets is displayed.
2. Tap to select the widget you want to add on the
Home screen.
To remove widgets:
1. From the Home screen, tap and hold the desired
widget. The widget enlarges and the icon
appears at the bottom of the Home screen.
2. Drag the widget to icon to delete it from the
Home screen.
Application drawer
The Application Drawer contains all applications and settings. Tap to open the
menu.
• Swipe the screen
up/down to view
more applications.
• Tap an icon to
access the
application.
Page 26
13
Setting wallpaper
You can customize the wallpaper of your Home screen with a default wallpaper or with
pictures taken with your phone.
Set wallpaper from Live Wallpaper gallery
1. From the Home screen, tap Menu > Wallpaper.
The Select wallpaper from is displayed on the
screen.
2. Tap Live wallpapers.
3. All default live wallpapers are displayed. Swipe your
finger up or down to browse, and tap to preview the
wallpaper on screen.
4. Tap Set wallpaper to set the previewed wallpaper as
wallpaper.
Set wallpaper from My Gallery
1. From the Home screen, tap Menu > Wallpaper.
The Select wallpaper from is displayed on the
screen.
2. Tap My Gallery.
3. You will see thumbnail images of all pictures. Tap to
select the picture you want to use as wallpaper.
4. Drag your finger to select the crop area.
5. Tap Save to set the cropped photo as wallpaper.
Set wallpaper from Wallpaper gallery
1. From the Home screen, tap Menu > Wallpaper.
The Select wallpaper from is displayed on the screen.
2. Tap Wallpapers.
3. All default wallpapers are displayed. Swipe your finger left or right to browse and
preview the wallpaper on screen.
4. Tap Set wallpaper to set the previewed wallpaper as wallpaper.
Page 27
14
Changing ViewScene
You can choose one of three available ViewScene modes to suit your preference.
1. From the Home screen, tap Menu > ViewScene.
2. Select the desired ViewScene type.
3. Tap Apply.
4. Tap Smart switch check box to enable the
automatic ViewScene switch.
2.2 Adjusting Volume
This device features four types of volume which can be adjusted separately:
• Ringer volume: Set the volume for incoming calls and notifications.
• In-call volume: Set the volume during a call.
• Media volume: Set the volume for music and videos.
•Alarm volume: Set the volume for alarms.
To adjust ringer volume
1. From the Home screen, tap > Settings >
Sound.
2. Tap Volume .
3. To adjust the ringtone volume, do either of the
following:
a. Drag the volume slider to adjust the volume.
b. Press the volume button to adjust the volume.
NOTE: When the device is set to silent mode,
all sounds are turned off except media
and alarm.
4. Tap OK to save your settings.
To adjust in-call volume
During a phone call, press the volume button to adjust
the volume.
Page 28
15
To adjust media/alarm volume
1. From the Home screen, tap > Settings> Sound.
2. Tap Volume .
3. Drag the media/alarm volume slider to adjust the volume.
4. Tap OK to save your settings.
2.3 Contacts
Contacts is your phonebook that lets you store names, phone numbers, email, and
other information. Contacts are stored in the phone memory. You can also add the
frequently used contacts to the favorites list. See “Favorite contacts” on page 17.
Adding contacts
1. From the Home screen, tap > Contacts.
2. Tap Menu > New contact.
3. Enter contact information such as name, phone
number, email address, etc.
4. When finished, tap Done to save the contact or tap
Revert to exit without saving any changes.
Searching for contacts
On Contacts screen, do any of the following to easily
search for Contacts:
• In the search box, type the first few letters of the
contact to search, or tap Menu > Search. The list is
filtered as you type.
• Filter Contacts list by categories. Tap Groups tab,
then select an option from the group lists: Family,
Friends, Coworkers, SIM, or Block.
Page 29
16
Importing contacts
You can import contacts from the SIM card or the memory card to your phone.
1. From the Home screen, tap > Contacts.
2. Tap Menu > Import/Export.
3. Select Import from SIM card or Import from SD
card.
4. Select contacts to import, tap Menu to select Import
all or select vCard files to import.
Backing up contacts
You can copy contacts to the memory card to back up your contacts information.
Export contacts to the memory card
1. From the Home screen, tap > Contacts.
2. Tap Menu > Import/Export > Export to SD card.
NOTE: Copying contacts to the memory card will
overwrite the old backup file.
3. A warning message pops up, tap OK to proceed. All
contacts are copied to the memory card.
Page 30
17
Favorite contacts
Add the most frequently called contacts to the Favorite contact list to help you access
contacts quickly and easily.
Add to Favorites
1. From the Home screen, tap > Contacts.
2. From the contact list, tap and hold a contact.
3. Tap Add to favorites.
The contact is now displayed in the Favorites list.
Remove from Favorites
1. From the Home screen, tap > Contacts.
2. Tap the Favorites tab.
The Favorites list is displayed.
3. Tap and hold a contact to display the submenu.
4. Tap Remove from favorites.
The contact is removed from the Favorites list.
Page 31
18
Chapter 3: Using the Phone
To open Phone screen, do any of the following:
• From the Home screen, tap .
• Tap > Phone.
3.1 Making a Call
To make a call from the Phone
1. From the Home screen, tap or tap > Phone.
2. Tap the phone number on the keypad.
NOTE: Tap to erase a wrong number. Tap and
hold to erase the entire number.
3. Tap to make the call.
4. To end the call, tap .
To make a call from Contacts
1. From the Home screen, tap > Contacts.
2. Tap the contact to call.
3. Tap Call [number].
If the contact has more than one number, tap Call
mobile, Call work, or Call home.
Page 32
19
To manage other voice call features
• Tap Add call to place a second call while placing
the current caller on hold.
• Tap Dialpad to display the on-screen keypad.
• Tap Bluetooth to route the device's audio through a
connected Bluetooth device.
• Tap Mute to mute or unmute the microphone.
• Tap Speaker to activate or deactivate the
Speakerphone.
3.2 Answering a call
When you receive incoming calls:
• The phone rings if the ringer volume is turned on.
• The screen displays an incoming call message. If the caller is listed in your
Contacts, the contact’s name appears. You may also see the caller’s phone
number, if available.
To accept or reject an incoming call
• To answer a call, slide to the right.
• To reject the call, slide to the left.
Page 33
20
Chapter 4: Entering Information
4.1 On-Screen Keyboard
The on-screen keyboard appears when an application requires text input, such as
messaging and writing emails. The keyboard input method is activated by default.
Using the on-screen keyboard
Tap the screen to display the on-screen keyboard.
• Tap the keys to enter the characters.
• To toggle between upper and lower case letter display, tap .
• To display the numeric and symbols keyboard, tap . Tap to toggle back.
Lowercase keyboard Uppercase keyboard Numbers and symbols
CAPs Lock
selector:
Tap to toggle
between upper
case or lower
case text input
method.
Dictionary:
Tap to enable
dictionary.
Input method selector:
• Tap to choose your
preferred input method.
• Tap and hold to access
settings.
Page 34
21
Setting input method
1. Tap and hold a text field. For instance, in Messaging, tap and hold the field “To :”.
2. Tap Input method.
3. Tap desired input method.
4.2 Configuring Keyboard Settings
Use keyboard aids to set up various input settings.
1. From the Home screen, tap > Settings > Language & keyboard.
2. Tap TouchPal.
3. Select the applicable options from the following Basic settings, Prediction &
Gestures, Chinese, and Handwriting submenus.
• Basic settings: available options are Word
prediction, Key press sound, Key press
vibration, Layout in portrait mode, Layout in
landscape mode, Swipe to switch layout, Mixed
language input, and Select languages.
• Prediction & Gestures: available options are
Predict next word, Correct mistyping, Slidedown symbols, and Relevant words.
• Chinese: tap Ambiguous PinYin to see more
options.
• Handwriting: available options are Stroke
width, Recognize interval, Stroke Color, and
Help.
Page 35
22
Chapter 5: Email & Messaging
Use Messaging to access text messages and multimedia messages. Use Email
to send and receive email messages via your internet email accounts.
5.1 Text Message
A text message can only contain letters, numbers, and symbols.
Creating and sending a text message
Your phone offers several ways to create and send a new text message.
From Messaging
1. From the Home screen, tap > Messaging.
2. Tap New message.
3. In the To field, enter the recipient’s phone number.
TIP: To add recipients from Contacts, tap To and
enter at least two numbers of a contact number
or two characters of a contact name. Then the
corresponding contact will be listed.
4. Type your message in the Type to compose field.
5. Tap Send to send your message.
From Call log
1. From the Home screen, tap > Contacts.
2. Tap the Call log tab to view all call history.
3. Tap and hold a call from Call log.
4. Tap Send text message.
5. Compose your message.
6. Tap Send.
NOTE: If you exit Messaging before sending, the unsent message will be
automatically saved as a draft.
Page 36
23
To request message delivery notification
1. In Messaging, tap Menu > Settings to access SMS
and MMS settings.
2. Tap Delivery reports check box to activate delivery
reports function.
3. Tap to exit the menu.
Receiving and managing messages
When you send and receive messages from a contact, these messages are grouped
as a message thread. A message thread looks like an exchanged conversation.
To reply to text messages
1. From the Home screen, tap > Messaging.
2. Tap a message thread.
3. Tap Type to c ompos e to compose your message.
4. Tap Send.
To forward text messages
1. From the Home screen, tap > Messaging.
2. Tap a message thread.
3. Tap and hold a message to display the message
options.
4. Tap Forward.
5. In the To field, enter the recipient’s phone number.
6. Tap Send.
Page 37
24
To delete all text messages
You can delete all text threads in Messaging.
1. From the Home screen, tap > Messaging.
2. Tap Menu > Delete threads.
3. Tap Delete to confirm.
To delete one message thread
1. From the Home screen, tap > Messaging.
2. Tap and hold the message thread that you want to
delete.
3. Tap Delete thread.
4. Tap Delete to confirm.
To copy message text
Copy the text from a message to a new message.
1. From the Home screen, tap > Messaging.
2. Tap a message thread.
3. Tap and hold the message.
4. Tap Copy message text.
5. Go to New Message.
6. Tap and hold Type to compose.
7. Tap Paste to paste the copied texts to your new
message.
Page 38
25
5.2 Multimedia Message
A multimedia message can contain letters, photos, an audio or video file.
Creating and sending multimedia messages
Your phone offers several ways to create and send a multimedia message.
From Messaging
1. From the Home screen, tap > Messaging.
2. Tap New Message.
3. Tap Menu > Add subject.
The message automatically converts to a
multimedia message. Enter a subject.
4. In the To field, enter the recipient’s phone number or
email address.
TIP: To add recipients from Contacts, tap To and
enter at least two numbers of a contact number
or two characters of a contact name. Then the
corresponding contact will be listed.
5. Tap Type to compose, then enter your message.
• To insert a picture or video file, tap Menu >
Attach.
• To insert an audio file, tap Menu > Attach >
Audio.
6. Tap Send MMS.
From Call log
1. From the Home screen, tap > Contacts > Call
log.
2. Tap and hold a call from Call log.
3. Tap Send text message.
4. Tap Menu > Add subject to convert to a multimedia
message.
5. Enter the Subject.
• To insert a picture or video file, tap Menu >
Attach > Pictures or Videos.
• To insert an audio file, tap Menu > Attach > Audio.
• To insert text, tap Type
to Compose, then enter your message.
6. Tap Send MMS.
Page 39
26
5.3 Voice Message
Your phone supports sending of voice message.
To create a voice message
1. From the Home screen, tap > Messaging.
2. Tap New Message.
3. Tap Menu > Attach > Record audio.
4. Tap to record your message.
5. Tap to stop recording.
6. Tap to listen to your recording.
7. Tap Use this recording to proceed or Discard to
return to the compose message screen.
8. Tap Play to listen to your recording again, or tap
Remove to delete your recording from the
multimedia message.
9. Enter the recipient’s phone number in the To field.
10.Tap Ty p e to co mpose to enter your message.
11. Tap Send MMS.
Page 40
27
5.4 Email Accounts
Your phone can send and receive emails just as you do with a computer. Your phone
supports email accounts provided by an Internet Service Provider (ISP) or web-based
email, such as Hotmail, Yahoo! Mail, etc.
Setting up an Internet email account
1. From the Home screen, tap > Email.
2. Enter your Email address and Password.
3. Tap Next. The device will automatically retrieve the
email settings.
• To add another email account, tap Menu >
Accounts > Menu > Add account.
4. Enter Your Name and Account display name.
NOTE: The Account display name is the name
shown to the recipients of your emails.
5. Tap Done.
Viewing email accounts
1. From the Home screen, tap > Email.
The account picker screen lists the available email
accounts.
2. Tap the account you want to access.
Customizing email settings
Configure message settings using the Account
settings menu.
1. From the Home screen, tap > Email.
2. Tap the account you want to access.
3. Tap Menu > Account settings to open the email
setting menu.
Page 41
28
5.5 Using Email
Composing and sending emails
1. From the Home screen, tap > Email.
2. Tap an email account.
3. Tap Menu > Compose.
4. In the To field, enter the recipient’s email address.
5. Enter a Subject.
6. Compose your email.
7. Tap Send.
Sending an email from Contacts
You can send an email to a contact with an email
address stored in Contacts.
1. From the Home screen, tap > Contacts.
2. Tap a name to open contact.
3. Tap Email home or Email work.
4. Enter a Subject.
5. Compose your email.
6. Tap Send.
Adding attachments to an email message
1. On the Compose screen, tap Menu > Add
attachment.
2. Select items to attach.
Receiving emails
Emails are automatically received in your Inbox when the phone connects to a
wireless network.
Page 42
29
To manually receive emails
1. From the Home screen, tap > Email.
2. Tap an email account.
3. Tap Menu > Refresh.
Reading and replying to emails
Inbox displays email headers. Download the email to view the complete content.
To download attachments
• With POP3 email accounts, attachments are downloaded when you download the
complete message.
• With IMAP4 email accounts, tap the attachment to mark it for download. The
attachment is downloaded the next time you connect to your email server.
NOTE: Only supported file types can be opened on the phone.
To reply or forward an email
1. From the Home screen, tap > Email.
2. Tap an email account.
3. Tap a message to open.
4. Do any of the following:
•Tap Reply or Reply all to reply the email.
•Tap Menu > Forward. Then enter the recipient in the To field.
5. Compose your message.
6. Tap Send.
Managing email folders
To delete an email
1. From the Home screen, tap > Email.
2. Tap an email account.
3. Tap and hold a message.
4. Tap Delete.
To view other email accounts
1. From the Home screen, tap > Email.
2. Tap Menu > Accounts.
3. Tap the account you want to view.
Page 43
30
Customizing email settings
You can configure the general settings of your email
account such as account name, email checking
frequency, default account, notifications, and server
settings.
To set up your account name
1. From the Home screen, tap > Email.
2. Tap an email account.
3. Tap Menu > Account settings to view the email
account settings.
4. Tap Account name to change the account name.
5. Tap OK to confirm.
To set up email checking frequency
1. From the Home screen, tap > Email.
2. Tap an email account.
3. Tap Menu > Account settings to view the email account settings.
4. Tap Email check frequency.
You can set the device to automatically check for new email every 5 mins, every 10
mins, every 15 mins, every 30 mins, every hour, or never.
To set up default account
1. From the Home screen, tap > Email.
2. Tap an email account.
3. Tap Menu > Account settings to view the email account settings.
4. Tap Default account to send email from this account by default.
To delete an email account
1. From the Home screen, tap > Email.
2. Tap and hold the account to delete.
3. Tap Remove account.
4. Tap OK to confirm.
Page 44
31
Chapter 6: Using Internet
6.1 Connecting to Internet
Your phone connects to Internet via either of the following:
•Wi-Fi
• Cellular Data Networks
Wi-Fi
To turn Wi-Fi on or off
1. From the Home screen, tap > Settings >
Wireless & networks.
2. Tap Wi-Fi check box to turn Wi-Fi function on or off.
To connect to a Wi-Fi network
1. Turn Wi-Fi on.
2. Tap Wi-Fi settings > Network notification to start
detecting networks.
3. The available networks are listed. Tap a network to
connect to or tap Add Wi-fi network to manually
add a connection.
4. If you select an unsecured network, the connection
is automatically established. Otherwise, proceed to
the next step.
Page 45
32
5. When connecting to a secured network, you will be
prompted for the password. Enter the password,
then tap Connect.
When Wi-Fi is connected, the connection icon is
displayed on the status bar.
To add Wi-Fi network
1. From the Home screen, tap > Settings >
Wireless & networks.
2. Tap Wi-Fi settings.
3. In Wi-Fi networks, tap Add Wi-Fi network. A new
window is displayed.
4. Follow the on-screen instructions and enter the
necessary information, then tap Save to save the
settings.
Page 46
33
To configure Wi-Fi settings
1. From the Home screen, tap > Settings >
Wireless & networks.
2. Tap Wi-Fi settings > Menu > Advanced.
NOTE: If you use static IP, enter the IP settings as
required.
3. Tap Use static IP.
4. In IP settings, enter the IP address, gateway,
netmask, and DNS.
5. Tap OK to save your settings.
Cellular Data Network
Check the availability of this connection with your
network service provider and obtain the following
information:
• Access Point Names
•Proxy
•Port
•User name
• Password
Page 47
34
To set up data connection
1. From the Home screen, tap > Settings >
Wireless & networks.
2. Tap Mobile networks > Access Point Names.
3. Tap Menu > New APN.
4. Tap Name to enter a name for the connection, then
tap OK.
5. Enter the APN, then tap OK.
6. Enter the Proxy, Port, Username, Password and
other settings (if available), then tap OK.
7. Tap Save to store your settings or tap Discard to
exit without saving the changes.
Starting a Data Connection
Data connection is automatically activated when the device is turned on. If you set up
multiple data connections, select the connection you want to use manually.
To manually start a data connection
1. From the Home screen, tap > Settings.
2. Tap Wireless & networks > Mobile networks > Access Point Names.
3. A list of connections will be displayed. Tap the connection that you want to use.
Page 48
35
6.2 Browsing Web Pages
1. From the Home screen, tap or tap > Browser.
2. Tap the address bar.
3. Type the URL, then tap .
To scroll the page
To scroll up or down, swipe your finger down or up. To scroll left or right, tap and swipe
your finger to the right or left.
To set Home page
1. While viewing a web page, tap Menu > More > Settings > Set home page.
2. Enter the URL of the page that you want to set as home page.
3. Tap OK to save your settings.
Managing web pages
While viewing a web page, tap Menu to apply browser functions.
The following table lists some options. Depending on the function, some options may
be unavailable.
Option Description
New window Open a web page in a new window.
Exit Close the Browser and return to Home screen.
Bookmarks Select from the list of saved favorite web pages to visit.
Windows Display a list of the current active Web pages.
Recently viewed
websites are
listed.
Address bar
Tap to enter the
website.
Page 49
36
Refresh Reload the current Web page.
More > History View your browsing history.
More > Forward Go to the next page.
More > Add a
bookmark
Allows you to save favorite Web pages.
More > Find on
page
Find the text on the web page.
More > Select text Select text on the web page.
More > Page info View web page information.
More > Share page Send this web page via email or messaging.
More > Downloads View the download history.
More > Settings Configure browser settings:
• Page content settings: configure page content settings.
• Privacy settings: configure privacy settings.
• Security settings: configure security settings.
• Advanced settings: set advanced settings for individual websites
or reset all settings to factory default.
Option Description
Page 50
37
Chapter 7: Google Apps
The following sections cover Android and Google applications that come pre-installed
on your phone.
NOTE: Using these applications may incur additional data charges. Contact your
network service provider for data plan rates.
7.1 Gmail
Gmail is the email service provided by Google.
Signing in to Gmail
1. From the Home screen, tap > Gmail.
2. Tap Create or Sign in your Google account.
3. Follow the on-screen instructions to login or create
your Gmail account.
4. Once logged in, you can begin reading and sending
emails from your Gmail account.
Refreshing Gmail
1. From the Home screen, tap > Gmail.
2. Tap Menu > Refresh.
Creating and sending emails
1. From the Home screen, tap > Gmail.
2. Tap Menu > Compose.
3. Enter the recipient.
4. Enter the subject and compose your message.
5. If necessary, do any of the following:
• To add Cc/Bcc, tap Menu > Add Cc/Bcc.
• To attach files, tap Menu > Attach.
• To save as draft, tap or tap Menu > Save
draft.
6. Tap to send the email.
Page 51
38
Reading and replying to emails
1. From the Home screen, tap > Gmail.
2. Tap an email to read.
3. To reply, tap (Reply) or (Reply all).
4. Compose your message.
5. Tap to send the email.
To preview and download attachments
1. From the Home screen, tap > Gmail.
2. Tap an email to read.
3. Scroll to the end of the email and do any of the following:
• To preview an attachment, tap Preview.
• To download an attachment, tap Download.
Forwarding emails
1. From the Home screen, tap > Gmail.
2. Tap an email to open.
3. To forward, tap .
4. Enter the recipient.
5. Tap to send the email.
Managing emails
To delete emails
1. From the Home screen, tap > Gmail.
2. Tap and hold an email, then tap Delete.
To add a star to emails
1. From the Home screen,tap > Gmail.
2. Tap the star icon.
To select emails
1. From the Home screen,tap > Gmail.
2. Tap the check icon.
To mark emails as read or unread
1. From the Home screen, tap > Gmail.
2. Tap and hold an email, then tap Mark read or Mark
unread.
Page 52
39
To place emails in archive
1. From the Home screen, tap > Gmail.
2. Tap and hold an email, then tap Archive.
To mute emails
1. From the Home screen, tap > Gmail.
2. Tap and hold an email, then tap Mute.
To change labels of emails
1. From the Home screen, tap > Gmail.
2. Tap and hold an email, then tap Change labels.
3. Tap a label, then tap OK.
Viewing folder labels
1. From the Home screen, tap > Gmail.
2. Tap Menu > Go to labels.
Searching for emails
1. From the Home screen, tap > Gmail.
2. Tap Menu > Search.
3. Type the text to search, then tap .
Configuring Gmail settings
1. From the Home screen, tap > Gmail.
2. Tap Menu > More > Settings.
3. Tap one of the following settings:
• Signature: Add a text signature to your outgoing emails.
• Confirm actions: Prompts for confirmation before archieving, deleting, or
sending emails.
• Reply all: Make “Reply all” as the default when replying emails.
• Auto-advance: Select which screen to show after you delete or archieve a
conversation.
• Message text size: Set the font size used in emails.
• Batch operations: Allow label operations on more than one conversation.
• Clear search history: Remove all the searches you have performed.
• Labels: Select which labels are synchronized.
• Email notifications: Displays a notification icon on the status bar when an
email is received.
• Select ringtone: Select email notification ringtone.
• Vibrate: Enable the phone to vibrate when an email is received.
• Notify once: Notify once for new email, not for every new email.
Page 53
40
7.2 Talk
Use Google Talk to chat with your friends who also have Google accounts.
Signing in to Google Talk
1. From the Home screen, tap > Talk.
2. Tap Sign in.
3. Enter your username and password, then tap Sign in.
4. Follow the on-screen instructions to complete set up.
Google Talk options
Once logged in, you can begin using Google Talk and
do any of the following:
• To view friends list, tap Menu > All friends.
• To add friends to friend’s list, tap Menu > Add
friends.
• To search a person, tap Menu > Search.
• To sign out, tap Menu > Sign out.
• To configure Google Talk settings, tap Menu >
Settings.
• To block a person, tap Menu > More >
Blocked.
• To invite a person to your chat, tap Menu >
More > Invites.
• To close all chats, tap Menu > More > Close
all chats.
Starting chat
1. From the Home screen, tap > Talk.
2. Tap a friend on your friends list.
3. Type your message, then tap Send.
Chatting Options
The following options can be accessed when a chat window is opened:
• To chat off record, tap Menu > Chat off record.
• To switch chats, tap Menu > Switch chats.
• To view the Friends list window, tap Menu > Friends list.
• To invite another friend to join the chat, tap Menu > Add to chat.
• To close the chat, tap Menu > End chat.
• To insert smileys, tap Menu > More > Insert smiley.
• To view your friend’s profile, tap Menu > More > View contact.
Page 54
41
Configuring Google Talk settings
1. From the Home screen, tap > Talk.
2. Tap Menu > Settings.
3. Tap one of the following settings:
• Automatically sign in: Enable to automatically sign in when Google Talk is
opened.
• Mobile indicator: Enable to show mobile indicator to your friends.
• Automatic away-status: Enable to set status to away when the screen is
turned off.
• Clear search history: Clear previous Google Talk chat searches from show-
ing up in the Search box.
• IM notifications: Enable to display a notification icon when an instant
message is received.
• Select ringtone: Select the ringtone to use when an instant message is
received.
• Vibrate: Enable to vibrate when an instant message is received.
7.3 Maps
Use Google MapsTM to find places, view traffic and direction information, and find your
friends’ location.
Before starting MapsTM, do the following:
1. From the Home screen, tap > Settings > Location & security.
2. Tap to enable Use wireless networks.
3. Tap to enable Use GPS satellites.
Viewing Map
1. From the Home screen, tap > Maps.
2. Do any of the following:
• Tap and hold an area on the map to view the
address.
• Slide your finger on the screen to scroll the
map.
• Tap the zoom controls to zoom in or out.
• To select nearby attractions, tap then tap
the desired category.
• To select Map mode, tap then tap Traffic,
Satellite, Terrain, Buzz, Latitude, My Maps,
Wikipedia, Transit Lines, or Favorite Places.
• To find your location, tap .
Page 55
42
• To search for a place of interest, tap Menu >
Search then type in a keyword to begin search.
• To get direction, tap Menu > Directions.
• To view the starred places, tap Menu > Starred
Places.
• To clear the map, tap Menu > Clear Map.
• To share your location with friends, tap Menu >
Latitude.
• To enable or disable a lab, tap Menu > More >
Labs.
• To get help on the map, tap Menu > More >
Help.
• To view terms, privacy, and notices, tap Menu
> More > Terms, Privacy & Notices.
Finding places
1. From the Home screen, tap > Maps.
2. Tap Menu > Search.
3. Type the place to search on the text field,
4. Tap .
A callout appears to indicate the location of the
searched place.
Page 56
43
7.4 Navigation
Google Maps Navigation allows you to say the destination and get voice directions.
NOTE: Not available in all locations.
Before starting Navigation, do the following:
1. From the Home screen, tap > Settings > Location & security.
2. Tap to enable Use wireless networks.
3. Tap to enable Use GPS satellites.
Getting directions
1. From the Home screen, tap > Navigation.
2. Tap Menu > Directions.
3. Enter the starting point and the ending point, or tap
the corresponding and select an option.
4. Select a direction icon.
• : Driving directions
• : Transit directions
• : Walking directions
5. Tap to view the directions.
6. Tap Menu to do any of the following:
• See map: Tap to view the directions on the
map.
• Reverse: Tap to reverse the directions.
• Update route: Tap to update the route.
• Options: Tap either to avoid highways or to avoid tolls, and then tap Update.
Page 57
44
Finding your current location
1. From the Home screen, tap > Navigation.
2. Tap to view your location on the map.
A blue blinking arrow indicates your current location
on the map.
7.5 Latitude
With Latitude, you can view your friends’ location and share your location to them on
Google MapsTM.
Starting Latitude
1. From the Home screen, tap > Latitude.
2. Tap Menu > Latitude or Join Latitude if logging in
for the first time.
3. Do any of the following:
• To add friends, tap Menu > Add friends.
• To refresh your friends list, tap Menu > Refresh
friends.
• To view the map, tap Menu > See map.
• To change your privacy settings, tap Menu >
Privacy.
Page 58
45
Configuring privacy settings
1. From the Home screen, tap > Latitude.
2. Tap Menu > Privacy.
3. Tap one of the following:
• Detect your location: Select to automatically
update your location.
• Set your location: Select to manually set your
location on the map.
• Hide your location: Select to hide your
location from your friends.
• Turn off Latitude: Tap to sign out from
Latitude.
7.6 Market
Android MarketTM allows you to purchase and download games and other
applications to your phone.
When opening Android Market for the first time, the Terms of Service is displayed on
screen. Tap Accept to accept the terms and continue.
NOTE: Android Market may not be supported in some countries.
Searching for applications
1. From the Home screen, tap > Market.
2. To browse for an application, tap a category to view
available applications.
3. To search, tap Menu > Search.
4. Type the application name, then tap .
Downloading applications
1. From the Home screen, tap > Market.
2. Search for desired application.
3. Tap the application that you want to download.
4. Tap Install.
Page 59
46
Removing applications
1. From the Home screen, tap > Market.
2. Tap Menu > My apps. The list of downloaded applications are displayed on
screen.
3. Tap the application that you want to remove.
4. Tap Uninstall.
5. Tap OK to confirm.
7.7 Places
Places is a location based application that helps you find the places and things
around you. Local information available includes restaurants, coffee shops, bars,
hotels, attractions, ATMs, gas stations, and more. This application also helps you get
where you are going with maps and directions.
From the Home screen, tap > Places.
Page 60
47
7.8 Google Search
From the Home Screen, you can search information on your phone and on the web
with Google Search right away
Searching information by entering text
1. From the Home screen, tap > Google Search or
tap Google Search widget.
2. Enter the text you are searching in Quick Search
Box.
3. As you type, matching items on your phone and
suggestions from Google web search are added to
the list of previously chosen search results.
Tap any match item in the list.
4. If what you are searching is not in the list, tap in
the Quick Search Box. The Browser opens,
displaying results of a Google search on the web.
7.9 Voice Search
Speak your query to search item on Google, or for applications or contacts on your
device.
1. From the Home screen, tap > Voice Search or
tap in the Quick Search Box.
2. A dialog opens, prompting you to speak the words
that you want to search for.
3. When you are finished speaking, Voice Search
analyzes your speech and displays the results of
your search.
If Voice Search misunderstands you, Quick Search
Box presents a list of similar-sounding search terms.
Page 61
48
7.10 YouTube
YouTube allows you to watch, upload, and download videos to your phone.
Watching videos
1. From the Home screen, tap > YouTube.
2. Tap a video to start playback.
Uploading videos
1. From the Home screen, tap > YouTube.
2. Tap to record your video.
3. Sign in to your YouTube account.
4. Follow the on-screen instructions to upload your
video.
Searching videos
1. From the Home screen, tap > YouTube.
2. To search for videos, tap .
3. Type the keyword to search.
4. Tap .
7.11 Facebook
Facebook allows you to connect and share ideas, photos, videos, and messages with
your friends.
Logging in to Facebook
1. From the Home screen, tap > Facebook.
2. Enter your username and password.
3. Tap Login.
NOTE: If you do not have a Facebook account, tap
Sign up.
Using Facebook
• News feed: Tap to view news feeds page.
• Events: Tap to view upcoming events.
• Requests: Tap to view and accept invitations.
• Profile: Tap to view your profile.
• Friends: Tap to view and search for friends.
• Inbox: Tap to read and send messages.
Page 62
49
Chapter 8: Using Bluetooth
Bluetooth modes
• On: Bluetooth is turned on. Your phone detects other Bluetooth devices, but your
phone is not visible to others.
• Discoverable: Bluetooth is turned on and your phone is visible to other Bluetooth
devices.
• Off: Bluetooth is turned off.
To turn Bluetooth on or off
1. From the Home screen, tap > Settings > Wireless & networks.
2. Tap Bluetooth check box to activate the Bluetooth function.
3. To make your phone visible to others, tap Bluetooth settings > Discoverable
check box to make this phone visible to other devices.
8.1 Connecting to Bluetooth Devices
A connection to a Bluetooth device is called a partnership. You need to pair and create
a partnership with a Bluetooth device to exchange information.
1. From the Home screen, tap > Settings >
Wireless & networks.
2. Tap Bluetooth settings to view the menu options.
3. To search for a new device, tap Scan for devices.
4. Tap a device to connect.
5. To start pairing, enter the Passcode, then tap OK.
NOTE: The passcode to be entered must be the
same passcode entered on the other
Bluetooth device.
6. The paired bluetooth device name is displayed.
7. Tap Done.
NOTE: Once a partnership has been created,
connecting to that device again will no longer
require entering the passcode.
Page 63
50
Chapter 9: Multimedia Applications
9.1 Videos and Photos
Your phone is equipped with a 5.0 megapixels camera to take videos and photos.
Recording a video
1. From the Home screen, tap > Camcorder.
2. Aim the device at the subject.
3. To start recording, tap .
To stop recording, tap again.
Tap to record
video.
Page 64
51
Taking a photo
1. From the Home screen, tap > Camera.
2. Aim the device at the subject.
3. Tap to take the shot.
To focus on the image before taking the shot, tap and hold . The focus frame
turns red to indicate that the focus is set.
Reviewing a video
After recording a video, the video preview appears on the screen.
• Tap Gallery to view all saved files in My Gallery.
• Tap Share to share the video via Bluetooth, Messaging, YouTube, Email, or Gmail.
• Tap Play to play the video.
• Tap Delete to delete the video.
Tap to take a
photo.
Page 65
52
Reviewing a photo
After taking a photo, the photo preview appears on the screen.
• Tap Gallery to view all saved files in My Gallery.
• Tap Share to share the picture via Bluetooth, Messaging, FlickrSync, Facebook, or
Picasa.
• Tap Set as to set the current photo as Wallpaper or Contact icon.
• Tap Delete to delete the photo.
Configuring camera settings
Tap the icon (on the left/right side of the screen) to access the respective camera/
camcorder menu. Swipe your finger up and down to scroll the page for more options.
Tap an option to
configure camera
settings.
Page 66
53
Tap to view and adjust the general settings of your camera:
Mode Setting Available options
Video mode
Duration 1 minute, 10 minutes, 30 minutes, 60 minutes
White balance Auto, Sunny, Cloudy, Incandescent,
Fluorescent
Audio On, Mute
Quality MMS(250K), 640 x 480, 720 x 480, 800 x 480,
1280 x 720
Capturing Normal, Tap capture, Face capture, Smile
capture, Self timer, Panorama, Camcorder
Photo mode
Resolution Maximum, Large, Medium, Small
Brightness -2, -1, 0, 1, 2
White Balance Auto, Sunny, Cloudy, Incandescent,
Fluorescent
Flash Auto, On, Off
Capturing Normal, Tap capture, Face capture, Smile
capture, Self timer, Panorama, Camcorder
Geo-tag On, Off
Page 67
54
9.2 Viewing Videos & Photos
Playing videos
1. From the Home screen, tap > Videos. All saved video clips are displayed.
2. Tap the video to playback.
Viewing photos
1. From the Home screen, tap > My Gallery.
2. Tap the desired folder to view the images in
thumbnails.
3. Tap an image to view.
4. Swipe your finger to the left/right to view the previous/next image.
• To play the slideshow, tap Slideshow.
• To share, delete or edit the image, tap Menu, then tap the desired option.
Page 68
55
9.3 Using Music Player
You can transfer music to the phone from the computer. From the Home screen, tap
> Music.
Music screen
• Playback screen: Displays the playback area with the playback controls.
• Library screen: Displays folder categories to
search for media files. It contains the following
categories: Artists, Albums, Songs and Playlists.
Album art
picture or
animation
Audio information
display area.
Go to Now Playing
screen.
Select to toggle repeat
options.
Go to next song.
Drag the slider left/
right to go forward
or backward.
Go to previous
song.
Party shuffle mode.
Play or pause the song.
Page 69
56
• Now Playing screen: Displays the song currently
playing. Drag the media files to arrange the
sequence for playback.
Playing music
To play music
1. From the Home screen, tap > Music.
The Library screen is displayed.
2. Tap Songs to view the list of songs.
3. Tap a song to play.
Changing playback options
While in Playback screen, tap Menu.
• To go to the Music Library screen, tap Library.
• To play songs in shuffle order, tap Party shuffle.
• To add a song to a preferred playlist, tap Add to playlist.
• To set a song as your ringtone, tap Use as ringtone .
• To delete a song, tap Delete.
Page 70
57
Managing playlists
To add a music file to playlist
Add songs to a specific playlist or create a playlist.
1. From the Home screen, tap > Music.
The Library screen is displayed.
2. Browse for the song that you want to add in a
playlist.
3. Tap and hold the song.
4. Tap Add to playlist.
5. Select from the current playlist or tap New to create
a new playlist. The song is added to the playlist.
NOTE: If you create a new playlist, enter the playlist
name, then tap Save.
To remove a music file from playlist
1. From the Home screen, tap > Music.
The Library screen is displayed.
2. Tap Playlists and browse for the playlist.
3. Tap and hold the song that you want to remove from
the playlist.
4. Tap Remove from playlist.
The song is removed from the playlist.
Page 71
58
Chapter 10: Programs
Your phone comes with the following pre-installed programs.
Programs Description
Browser Browse the web and download files from Internet. See
page 31.
Calculator Perform basic arithmetic functions, such as addition,
subtraction, multiplication, and division. See page 60.
Calendar Create and track schedule or appointments. See page 61.
Camcorder Record video clips. See page 50.
Camera Capture photos. See page 51.
Clock Set up alarms. See page 76.
Contacts Store names, numbers, email, and other information. See
page 15.
Documents To Go Use Document To Go applications such as Word To Go,
Sheet To Go, Slideshow To Go, and PDF To Go Lite. See
page 62.
Email Send and receive email messages. See page 28.
Facebook Log in and use Facebook applications on your phone. See
page 48.
File Browser Manage audio, video, photo, and other files. See page 63.
FM Radio Tune and listen to the radio. See page 63.
Gmail Access your Gmail account on your phone. See page 37.
Google Search Search applications and contacts on your device, and the
Internet using Google Search. See page 47.
Latitude See your friends’ locations and share yours with them. You
need to sign in with your Google account to use this feature.
See page 44.
Page 72
59
Maps View the map and get directions to your destination. See
page 41.
Market Purchase games and other applications from Android
Market and download them to your phone. See page 45.
Messaging Send and receive all types of messages, such as text
message, MMS, and voice messages. See page 22.
Music Play and manage music and audio files on your phone. See
page 55.
My Gallery View and edit photos and videos. See page 54.
Navigation Use to track your location, find places, and get driving
directions to your destination. See page 43.
News & Weather View the current weather as well as the weather forecast on
the selected city, and read the latest news. See page 66.
Note Pad Create notes. See page 67.
Phone Make and receive phone calls. See page 18.
Places Help you to find the places around you. Local information
available includes restaurants, coffee shops, bars, hotels,
attractions, ATMs, gas stations, and more. See page 46.
RSS Reader Get live updates of your favorite news or web sites. See
page 68.
Settings
Configure phone settings, wireless settings and call settings
of your phone. See page 72.
SIM Toolkit
Directly connect to and use services provided by your mobile
service provider. See page 68.
Talk Log in and chat with friends using Google Talk. See page 40.
Video Portal Playback video clips from your phone or YouTube. See
page 69.
Videos Playback video clips. See page 54.
Voice Dialer Read and record predefined texts to be recognized and used
by your phone for voice dialing, finding a contact and others.
See page 70.
Programs Description
Page 73
60
10.1 Browser
Open the Browser to view web pages. See “Browsing Web Pages” on page 35.
10.2 Calculator
With Calculator, you can perform basic arithmetic functions on your phone.
1. From the Home screen, tap > Calculator.
2. Use the on-screen calculator keypads to perform
arithmetic calculation.
Voice Note Record voice notes. See page 71.
Voice Search Use Google Search by saying the word instead of typing
them. See page 47.
YouTube Watch videos from YouTube on your phone. See page 48.
Programs Description
Page 74
61
10.3 Calendar
The Calendar lets you schedule and sound alarms for appointments, meetings and
other events. Scheduled appointments for the day can be displayed on the Home
screen.
To schedule an event
1. From the Home screen, tap > Calendar.
2. Tap Menu > More > New event.
3. Enter the event details.
4. Select the date and time for From and To fields.
NOTE: For an all-day event, check All Day.
5. To set repetition, select the repetition from the list.
6. To set a reminder, select the time from the list.
7. When finished, tap Done.
TIP: From the Calendar screen, tap a day or a time
slot then tap New event to set a new
appointment on the tapped date or time.
10.4 Camcorder
Record video clips with this phone. See “Videos and Photos” on page 50.
10.5 Camera
Capture photos with this phone. See “Videos and Photos” on page 50.
10.6 Clock
Set alarms with this phone. See “Alarms settings” on page 76.
10.7 Contacts
View or manage your contact list. See “Contacts” on page 15.
Page 75
62
10.8 Documents To Go
Documents To Go allows you to open Microsoft®
Office and Adobe file formats.
1. From the Home screen, tap > Documents To
Go.
2. Tap the document category that you want to view.
3. Tap the file you want to open.
• Swipe your finger on the screen to pan or go
through other pages.
4. To close the file, tap .
NOTE: To create a new document or edit an
existing document, purchase the full version
of Documents To Go.
Purchase Documents To Go
To get the full version of Documents To Go:
1. Tap Upgrade Store.
2. Tap Buy. Browser is launched and you will be redirected to www.dataviz.com.
3. Follow the on-screen instructions to complete purchase.
10.9 Email
Use Email to connect to your remote mailbox and retrieve your email messages from
your phone. See “Using Email” on page 28.
10.10 Facebook
Facebook application lets you connect to Facebook with your phone. You can log in
to your Facebook account and get connected with your friends anytime. See
“Facebook” on page 48.
Page 76
63
10.11 File Browser
File Explorer lets you browse the contents of your phone and the memory card.
1. From the Home screen, tap > File Browser.
2. Tap the folder list and tap the folder you want to
explore.
Managing files and folders
• To open a folder or file, tap the file or folder.
• To move, delete, rename, or view file or folder
details, tap and hold to view the options. Then tap a
desired option.
• To copy, tap and hold a file or folder, then tap Copy.
To paste a file or folder, tap Menu > Paste.
• To create a new folder, tap Menu > New folder.
• To sort items, tap Menu > Sort, then tap a sorting
option.
• To mark a file or folder, tap Menu > Mark.
• To copy all files and folders, tap Menu > Copy all.
• To delete all files and folders, tap Menu > Delete all.
• To search for a file, tap Menu > More > Search.
10.12 FM Radio
FM Radio lets you listen to the FM radio.
NOTE: You must connect a headset or an earphone to use this function.
1. From the Home screen, tap > FM Radio.
2. Tap to turn on the radio.
3. Do any of the following:
• To manually tune to a frequency, tap or
.
• To view the Favorite List, tap . To add the
current radio station into the Favorite list, tap
, and then enter the station name and tap
OK.
• To share the radio station information via
Bluetooth, Email, Facebook, Gmail, or
Messaging, tap .
• To set the desired radio station frequency, tap
. Enter the radio frequency and tap OK.
• To turn on the speaker, tap Menu > Speaker.
Page 77
64
• To mute the sound, tap Menu > Mute.
• To change the other radio settings, tap Menu > Settings.
Recording the radio
• To start recording, tap while listening to the
radio.
• To stop recording, tap .
• To listen to the recorded files, tap , then tap the
file to play.
10.13 Gmail
Use Gmail to send and receive emails using your Google email account. See “Gmail”
on page 37.
10.14 Google Search
Search information on your phone and on the web with Google Search. See “Google
Search” on page 47.
10.15 Latitude
Latitude allows you to keep track of your friends’ location and share your location to
them. See “Latitude” on page 44.
10.16 Maps
Use Maps to view the map and get directions to your destination. See “Maps” on
page 41.
Page 78
65
10.17 Market
Use Market to purchase and download games and other applications to your phone.
See “Market” on page 45.
10.18 Messaging
Use Messaging to send or receive text and MMS messages. See “Text Message” on
page 22.
10.19 Music
Use Music to play music files or recorded voice files. See “Using Music Player” on
page 55.
10.20 My Gallery
You can view your captured images, recorded video clips, and downloaded images in
My Gallery.
1. From the Home screen, tap > My Gallery.
2. Tap the desired folder to view the camera pictures or
camera videos.
The images or videos are displayed in thumbnails.
3. To view photos or videos, see “Viewing Videos &
Photos” on page 54.
10.21 Navigation
Use Navigation to locate your location and provide a real time turn by turn direction to
your chosen destination. See “Navigation” on page 43.
Page 79
66
10.22 News & Weather
News & Weather allows you to view the weather in your location and read the latest
stories, sports, and entertainment news headlines on your device.
Viewing News & Weather
1. From the Home screen, tap > News & Weather.
2. Swipe your finger to the right or left to browse the
categories.
3. Touch a headline to open Browser and view the
complete story.
Changing News & Weather settings
1. From the Home screen, tap > News & Weather.
2. Tap Menu > Settings.
3. Select one of the following options:
• Weather settings: Tap to set the location and
the temperature scale to use.
• News settings: Tap to pick topics and manage
the download.
• Refresh settings: Tap to set up automatic
update and refresh interval.
Page 80
67
10.23 Note Pad
Use Note Pad to write down notes as you would on a note pad.
Create notes
1. From the Home screen, tap > Note Pad.
2. Tap Menu > Add note.
3. Enter your notes using the on-screen keyboard.
4. Tap Menu > Edit title to add a title to the note.
5. When you are done, tap to return to the Note pad screen. The note is
automatically saved.
10.24 Phone
Use Phone to make phone calls or manage contact list. See “Making a Call” on
page 18.
10.25 Places
Places is a location based application that helps you find the places and things
around you. See “Places” on page 46.
Saved notes are
displayed here.
Tap to add a new note.
Tap to mark the note.
Page 81
68
10.26 RSS Reader
Use Rss Reader to get live update of your favorite web sites.
From the Home screen, tap > Rss Reader.
• To add a Feed URL, tap Menu > New feed.
• To update feeds, tap Menu > Update all.
• To add a new folder, tap Menu > New folder.
• To export feeds, tap Menu > Export all to OPML
file.
• To delete feeds, tap Menu > Mark. Tap feeds to
mark, then tap Menu > Delete marked.
• To modify feed settings, tap Menu > Settings.
10.27 Settings
In the Settings menu, you can view and make adjustments for wireless & network
settings, call settings, phone general settings and security settings. See “Phone
Settings” on page 72.
10.28 SIM Toolkit
Directly connect to and use services provided by your mobile service provider.
From the Home screen, tap > SIM Toolkit.
10.29 Talk
Use Talk to chat with your friends. See “Talk” on page 40.
Page 82
69
10.30 Video Portal
You can view and play back the video clips from your device or YouTube.
1. From the Home screen, tap > Video Portal.
2. Videos are grouped into categories, such as All
Videos, Recent Opened, and Recent Added. Tap a
category to see the available videos for that
category.
To view videos on YouTube, tap on the top
right of the screen. YouTube videos are grouped
into categories, such as Most Viewed, Most
Discussed, Most Recent, and Top Rated. Tap a
category to see the available videos for that
category.
3. Tap a video to play it.
Search a video file
1. From the Home screen, tap > Video Portal.
2. Tap .
3. Enter the video name and tap Search.
10.31 Videos
You can playback video clips captured with your phone. See “Videos and Photos” on
page 50.
Page 83
70
10.32 Voice Dialer
Say a command to execute for voice dialing, finding a contact and others.
1. From the Home screen, tap > Voice Dialer.
2. At the prompt, say a command.
The application recognizes the command. The
application lists possible matches and prompts you
for verification.
3. Tap the right command to execute.
10.33 Voice Note
Recording voice notes
1. From the Home screen, tap > VoiceNote.
2. Tap Menu > Record.
The recording screen is displayed.
3. Tap to record your voice. To stop recording, tap
.
4. Tap Use this recording to save the file.
Playing voice notes
1. From the Home screen, tap > VoiceNote.
A list of voice notes is displayed.
2. Tap the voice note you want to play.
The voice note is played with the Music player.
10.34 Voice Search
Use Voice Search to say the words to search in the Internet using Google search
engine. See “Voice Search” on page 47.
Page 84
71
10.35 YouTube
Use YouTube to watch, upload, and view videos from YouTube using your phone.
See “YouTube” on page 48.
Page 85
72
Chapter 11: Managing Your Phone
11.1 Phone Settings
From the Home screen, tap > Settings to view and adjust the settings of your
phone. Settings menu is categorized into: Wireless & networks, Call settings,
Sound, Display, Location & security, Applications, Accounts & sync, Privacy,
SD card & phone storage, Language & keyboard, Voice input & output,
Accessibility, Date & time, and About phone.
Wireless & networks
Call settings
Sound
Application Description
Airplane mode Disable all wireless connections.
Wi-Fi settings Manage Wi-Fi connections, scan and connect to available Wi-Fi net-
works.
Bluetooth settings Manage connections, set device name, and discoverability of the
device.
Tethering &
portable hotspot
Share your phone mobile data connection via USB or as a portable
Wi-Fi hotspot.
VPN settings Set up and manage Virtual Private Networks (VPNs).
Mobile networks Set options for roaming, networks, and Access Point Names
(APNs).
Application Description
Fixed Dialing
Numbers
Manage fixed dialing numbers.
Voicemail Set voicemail service and settings.
Other call settings Activate other call settings such as call forwarding, call barring,
caller ID, and call waiting.
Application Description
Silent mode Turn silent mode on/off. All sounds except media and alarms are
turned off.
Vibrate Phone vibrates for incoming calls (only during Silent mode).
Volume Adjust the volume for ringtone, media, and alarms.
Phone ringtone Set your default incoming call ringtone.
Page 86
73
Display
Location & security
Notification
ringtone
Set your default notification ringtone.
Audible touch
tones
Enable/disable sound when using dial pad.
Audible selection Enable/disable sound when making screen selection.
Screen lock
sounds
Play sounds when locking or unlocking the screen.
Haptic feedback Play sound when pressing soft keys and on certain UI interactions.
Application Description
Brightness Adjust the brightness of the screen.
Auto-rotate screen Switch orientation automatically when rotating the device.
Animation Show animation when opening and closing windows.
Screen timeout Adjust delay before the screen automatically goes off.
G-Sensor
Calibration
Set the G-sensor calibration for your phone.
E-Compass
Calibration
Set the E-compass calibration for your phone.
Output Screen Adjust the resolution of the output screen.
Application Description
Use wireless
networks
Allow location to be determined by Wi-Fi or mobile networks
Use GPS satellites Enable GPS satellites.
Use assisted GPS Enable assisted GPS function.
AGPS Settings Adjust AGPS settings. This option is only available if you enable the
“Use assisted GPS”.
GPS Ephemeris
Auto Download
Enable/Disable to download Ephemeris updates from the server.
Set up screen lock Set the lock screen with a pattern, PIN, or password.
Set up SIM card
lock
Lock SIM card and change SIM card PIN.
Visible passwords Show passwords as you type.
Application Description
Page 87
74
Applications
Accounts & sync
Privacy
SD card & phone storage
Select device
administrators
Add or remove device administrators.
Use secure
credential
Allow applications to access secure certificates and other
credentials.
Application Description
Unknown sources Allow install of non-market applications.
Manage
applications
Manage and remove installed applications.
Running services View and control currently running services.
Development Set options for application development.
Application Description
Background data Enable background data usage.
Auto-sync Automatically sync data.
Manage accounts Tap Add account to add an account to configure synchronization
settings for Calendar, Contacts, and Gmail.
Applications Description
Back up my data Back up the current settings and other application data.
Automatic restore Automatically restore backed up settings and other data after
application reinstallation.
Factory data reset Delete all data on the phone and restore to factory default settings.
Application Description
SD card Show available memory card storage.
Unmount SD card Unmount the memory card for safe removal.
Internal phone
storage
Show available phone storage.
Application Description
Page 88
75
Language & keyboard
Voice input & output
Accessibility
Date & time
About phone
Check the system update and view device status, battery usage, legal information, model
number, and software version.
Application Description
Select language Set the on-screen display language for your phone.
TouchPal Configure on-screen keyboard settings.
Application Description
Voice recognizer
settings
Set the voice recognizer settings.
Text-to-speech
settings
Set the text-to-speech settings.
Application Description
Accessibility Configure the settings for the downloaded application with an
accessibility feature.
Power button
ends call
End a call by pressing the Power button instead of turning off the
screen.
Application Description
Automatic Check to use network provided values.
Set date Set the date.
Set time zone Select the time zone of your current location.
Set time Set the time.
Use 24-hour
format
Set the clock to 24-hour format.
Select date format Set the preferred date format.
Page 89
76
11.2 Changing Basic Settings
Date and time settings
To automatically set date and time
1. From the Home screen, tap > Settings > Date & time.
2. Tap Automatic to automatically set the date and time according to the network.
To manually set date and time
1. From the Home screen, tap Application Drawer >
Settings > Date & time.
2. Tap Set date to set the date.
• To adjust the date, tap the month, day, or year
field, and tap + or - to increase or decrease the
value. Tap Set to apply the values.
• To change the date format, tap Select date
format, and select the date format from the list.
3. Tap Set time zone to select the time zone from the
list.
4. Tap Set time to set the time.
• To adjust the time, tap the hour, minute, second
or AM/PM field, and tap + or - to increase or
decrease the value. Tap Set to apply the values.
• To use 24-hour format, tap Use 24-hour format.
Alarms settings
You can set up alarms on this device.
To set the alarm
1. From the Home screen, tap > Clock.
2. Tap .
3. To add an alarm, tap Add alarm.
4. Tap the + and - icons to set the alarm time, and tap
Set.
5. To set repeat mode, tap Repeat. Tap one or more
options, then tap OK.
6. To set the ringtone, tap Ringtone. Tap an option,
then tap OK.
7. To vibrate when alarm sounds, check Vibrate.
8. To enter an alarm label, tap Label.
9. After all settings are completed, tap Done.
Page 90
77
Display settings
The display settings of this device affect the battery and external power level.
To turn off backlight when the phone is idle
1. From the Home screen, tap > Settings > Display.
2. Tap Screen timeout.
3. Select from the screen timeout list. Your setting is automatically saved.
To adjust brightness
1. From the Home screen, tap > Settings > Display.
2. Tap Brightness.
3. Drag the Brightness slider to adjust brightness settings.
4. Tap OK when finished.
To change the screen orientation
1. From the Home screen, tap > Settings > Display.
2. Tap Auto-rotate screen to automatically switch the screen orientation when
rotating the device.
Ringtone settings
You can assign a ringtone and a ringtone type for various events such as incoming
calls, receiving new messages, and others.
To change the incoming call ringtone
1. From the Home screen, tap > Settings > Sound.
2. Tap Phone ringtone.
3. Tap a ringtone.
4. Tap OK to save.
To change the notification ringtone
1. From the Home screen, tap > Settings > Sound.
2. Tap Notification ringtone.
3. Tap a ringtone.
4. Tap OK to save.
11.3 Using Wireless & networks
Wireless & networks allows you to manage Wi-Fi, Bluetooth, airplane mode, and
mobile networks.
1. From the Home screen, tap > Settings > Wireless & networks.
2. To enable or disable Wi-Fi, Bluetooth, or Airplane mode, tap their corresponding
boxes.
Page 91
78
3. To configure Wi-Fi or Bluetooth settings, tap Wi-Fi settings or Bluetooth
settings.
4. To change mobile networks settings, tap Mobile networks, then tap the setting to
change.
11.4 Protecting Your Phone
You can protect your phone from unauthorized users by requiring the PIN code or
entering a password.
SIM card PIN settings
When PIN code is enabled, you are required to enter the PIN code before making a
call.
To lock the phone
1. From the Home screen, tap > Settings > Location & security.
2. Tap Set up SIM card lock.
3. Tap Lock SIM card to use PIN to use the device.
To disable this feature, tap the check box once again.
4. Enter the current PIN code to lock the phone.
To change the PIN code
1. From the Home screen, tap > Settings > Location & security.
2. Tap Set up SIM card lock.
3. Tap Change SIM PIN.
4. Enter the old PIN code.
5. Enter the new PIN code and confirm.
Screen lock protection settings
You can increase your device security by creating a screen unlock pattern (disabled
by default). When enabled, you must draw the correct unlock pattern on the screen to
unlock and regain access to the device.
1. From the Home screen, tap > Settings > Location & security.
2. Tap Set up screen lock.
3. Tap Pattern to draw pattern to unlock screen.
4. Follow on-screen instructions to draw your own personal unlock pattern and tap
Continue.
5. Redraw your unlock pattern again and tap Confirm.
Page 92
79
11.5 Resetting the Phone
You can reset your phone to its factory defaults.
1. From the Home screen, tap > Settings > Privacy.
2. Tap Factory data reset.
3. Tap Reset phone to reset.
Page 93
80
Specifications
Radio Band & Standard
GSM bands 850 / 900 / 1800 / 1900
UMTS bands 850 / 1700 / 1900 / 2100 or 900 / 1700 / 1900 / 2100
GPRS GPRS Class 12
EGPRS/EDGE Multi-Slot Class 12
UMTS DL / UL, up to HSDPA 14.4Mbps
Connectivity
GPS GPS / AGPS
Wi-Fi 802.11 b/g/n
Bluetooth 2.1 with EDR
USB USB 2.0 High-Speed client
Power
Battery 1400mAH with hard-packed Li-ion battery
AC Adapter AC input voltage: 100-240Vac, 50 / 60Hz
AC input current: 200mAac max.
DC output voltage: 5Vdc (typical)
DC output current: 1A (typical)
Temperature
Operating -10ºC to 42ºC
Non-operating / Storage -20ºC to 70ºC
Charging 0ºC to 40ºC
Humidity
Operating 10% to 90% non-condensing
Non-operating / Storage 5% to 95% non-condensing
Page 94
81
B
Battery 4
Charge 5
Bluetooth 49
connecting 49
Browser 60
C
Call
answer a call 19
Camcorder 60, 61, 62, 63, 64
Camera
settings 52
Contacts
searching 15
D
device
settings menu 68
Device settings 72
Display
backlight 77
brightness 77
orientation 77
E
E-mail 28
F
Facebook 63
File
managing 63, 64
File Browser 63
FM Radio 63
Folders
managing 63, 64
G
Gallery 64
Google Talk 69
H
Headset 5
Home screen 8
I
Icons
Battery 9
Connection 10
Notification 10
Phone Network 9
Status Bar 9
volume 9
Internet 31
connecting 31
data connection 34
K
Keyboard
on-screen 20
L
Latitude 64
M
Maps 64
Market 65
Messaging
e-mail 27
Voice 26
Messaging
MMS 25
SMS, text 22
Micro USB port 2
Music 65
Music Player 55, 65, 66, 71
N
Navigation 65
News and Weather 66
Note Pad 67
P
Phone 67
answering a call 19
protect 78
reset 79
taking photos 51
PIN code 78
Places 67
Power
button 2
turn on and off 6
Programs 58
R
RSS Reader 68
Page 95
82
S
Screen
orientation 77
Settings 68
alarms 76
basic 76
date and time 76
display 77
keyboard 21
ringtone 77
SIM
install 3
remove 3
SIM Toolkit 68, 69
Bass 69
Treble 69
Volume Boost 69
T
Text
entering 20
U
Unlock screen 7
V
Video
recording 50
viewing 51, 52
Video Portal 69
Videos 70
Voice Dialer 70
Voice Note 71
Voice Search 71
Volume
adjusting 14
slider 2
W
Wi-Fi 31
Wireless & networks 77
Y
YouTube 71
Page 96
83
Customer Support
For technical support or product service, see the table below or contact your reseller.
NOTE: You will need the product serial number.
Country/Region Website
T = Telephone
F = FAX
Email
Australia/New Zealand www.viewsonic.com.au
AUS= 1800 880 818
NZ= 0800 008 822
Canada www.viewsonic.com
T (Toll-Free)= 1-866-463-4775
T (Toll)= 1-424-233-2533
F= 1-909-468-3757
Europe www.viewsoniceurope.com www.viewsoniceurope.com/uk/support/call-desk/
Ireland (Eire)
www.viewsoniceurope.com
/uk/
www.viewsoniceurope.com/
uk/support/call-desk/
service_ie@viewsoniceurope.
com
Latin America
(Argentina)
Latin America
(Columbia)
Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS
Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: 01.999.925.19.16
Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico
Puerto Rico & Virgin
Islands
www.viewsonic.com
T= 1-800-688-6688 (English)
T= 1-866-379-1304 (Spanish)
F= 1-909-468-3757
Singapore/Malaysia/
Thailand
United Kingdom
www.viewsoniceurope.com
/uk/
www.viewsoniceurope.com/
uk/support/call-desk/
service_gb@viewsoniceurope
.com
United States www.viewsonic.com
T (Toll-Free)= 1-800-688-6688
T (Toll)= 1-424-233-2530
F= 1-909-468-3757
Page 97
84
Limited Warranty
ViewSonic® ViewPad
What the warranty covers:
ViewSonic warrants its products to be free from defects in material and workmanship,
under normal use, during the warranty period. If a product proves to be defective in
material or workmanship during the warranty period, ViewSonic will, at its sole option,
repair or replace the product with a like product. Replacement product or parts may
include remanufactured or refurbished parts or components.
How long the warranty is effective:
ViewSonic ViewPad are warranted for at least 1 year for labor from the date of the first
customer purchase.
Who the warranty protects:
This warranty is valid only for the first consumer purchaser.
What the warranty does not cover:
1. Any product on which the serial number has been defaced, modified or removed.
2. Damage, deterioration or malfunction resulting from:
a. Accident, misuse, neglect, fire, water, lightning, or other acts of nature,
unauthorized product modification, or failure to follow instructions supplied with
the product.
b. Any damage of the product due to shipment.
c. Removal or installation of the product.
d. Causes external to the product, such as electric power fluctuations or failure.
e. Use of supplies or parts not meeting ViewSonic’s specifications.
f. Normal wear and tear.
g. Any other cause which does not relate to a product defect.
3. Any product exhibiting a condition commonly known as "image burn-in" which
results when a static image is displayed on the product for an extended period of
time.
4. Removal, installation, one way transportation, insurance, and set-up service
charges.
How to get service:
1. For information about receiving service under warranty, contact ViewSonic Customer Support (Please refer to Customer Support page). You will need to provide
your product's serial number.
2. To obtain warranty service, you will be required to provide (a) the original dated
sales slip, (b) your name, (c) your address, (d) a description of the problem, and (e)
the serial number of the product.
3. Take the original container to an authorised ViewSonic Service Centre or use the
prepaid product freight option to ship to ViewSonic directly.
4. For additional information or the name of the nearest ViewSonic service center,
contact ViewSonic.
Page 98
85
Limitation of implied warranties:
There are no warranties, express or implied, which extend beyond the description
contained herein including the implied warranty of merchantability and fitness for a
particular purpose.
Exclusion of damages:
ViewSonic’s liability is limited to the cost of repair or replacement of the product.
ViewSonic shall not be liable for:
1. Damage to other property caused by any defects in the product, damages based
upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of
business opportunity, loss of goodwill, interference with business relationships, or
other commercial loss, even if advised of the possibility of such damages.
2. Any other damages, whether incidental, consequential or otherwise.
3. Any claim against the customer by any other party.
4. Repair or attempted repair by anyone not authorized by ViewSonic.
4.3: ViewSonic TPC Warranty TPC_LW01 Rev. 1e 08-06-10
Page 99
Loading...
