ViewSonic VS11404-1G, N2750w-2G Service Manual

Service Manual

ViewSonic N2750w-2G

Model No. VS11404-1G

27” LCD TV

(N2750w-2G_SM Rev. 1a Sep. 2006)

ViewSonic® 381 Brea Canyon Road, Walnut, California 91789 USA - [phone]

Copyright

Copyright © 2006 by ViewSonic Corporation. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of ViewSonic Corporation.

Disclaimer

ViewSonic makes no representations or warr anties, either expressed or impl ied, with respect to the contents
hereof and specifically disclaims any warranty of merchantability or fitness for any particular purpose. Further,
ViewSonic reserves the right to revise this publication and to make changes from time to time in the contents
hereof without obligation of ViewSonic to notify any person of such revision or changes.

Trademarks

Optiquest is a registered trademark of ViewSonic Corporation.
ViewSonic is a registered trademark of ViewSonic Corporation.
All other trademarks used within this document are the property of their respective owners.

Revision History

Revision SM Editing Date ECR Number Description of Changes Editor

1a 09/22/06 Initial Release Sophia Kao

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

i

TABLE OF CONTENTS

1. Precautions and Safety Notices.................................................................1

3. Front Panel Function Control Description................................................ 10

4. Circuit Description.......................................................................................20

5. Adjustment Procedure................................................................................22

6. Trouble Shooting Flow Chart................................................................ .....48

7. Block Diagram.............................................................................................52

8. Schematic Diagrams....................................................................................53

9. PCB Layout Diagrams.................................................................................65

10. Exploded Diagram And Exploded Parts List...........................................71

11. Recommend Spare Parts List...................................................................74

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

ii

2. Specification.................................................................................................4

1. Appropriate Operation

(1) Turn off the product before cleaning.
(2) Use only a dry soft cloth when cleaning the LCD panel surface.
(3) Use a soft cloth soaked with mild detergent to clean the display housing.
(4) Disconnect the power plug from AC outlet if the product is not used for a long period of

time.

(5) If smoke, abnormal noise, or strange odor is present, immediately switch the LCD display

off.
(6) Do not touch the LCD panel surface with sharp or hard objects.
(7) Do not place heavy objects on the LCD display, video cable, or power cord.
(8) Do not use abrasive cleaners, waxes or solvents for your cleaning.
(9) Do not operate the product under the following conditions:

- Extremely hot, cold or humid environment.

- Areas susceptible to excessive dust and dirt.

- Near any appliance generating a strong magnetic field.

- Place in direct sunlight.

2. Caution

No modification of any circuit should be attempted. Service work should only be performed after
you are thoroughly familiar with all of the following safety checks and servicing guidelines.

3. Safety Check

Care should be taken while servicing this LCD display. Because of the high voltage used in the
inverter circuit, the voltage is exposed in such areas as the associated transformer circuits.

4. Power Supply Requirements

The external AC power operating range shall be from 90 to 264Vac

5. LCD Module Handling Precautions

5.1. Handling Precautions

(1) Since front polarizer is easily damaged, pay attention not to scratch it.
(2) Be sure to turn off power supply when inserting or disconnecting from input connector.
(3) Wipe off water drop immediately. Long contact with water may cause discoloration or

spots.
(4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
(5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard

surface.
(6) Since CMOS LSI is used in this module, take care of static electricity and insure human

earth when handling.
(7) Do not open nor modify the Module Assembly.
(8) Do not press the reflector sheet at the back of the module to any directions.
(9) In case if a Module has to be put back into the packing container slot after once it was

taken out from the container, do not press the center of the CCFL Reflector edge.

Instead, press at the far ends of the CFL Reflector edge softly. Otherwise the TFT

Module may be damaged.
(10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor

tilt the Interface Connector of the TFT Module.
(11) After installation of the TFT Module into an enclosure (LCD monitor housing, for

example), do not twist nor bend the TFT Module even momentary. At designing the

enclosure, it should be taken into consideration that no bending/twisting forces are

applied to the TFT Module from outside. Otherwise the TFT Module may be damaged.
(12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please

follow local ordinances or regulations for disposal.
(13) Small amount of materials having no flammability grade is used in the LCD module.

The LCD module should be supplied by power complied with requirements of Limited

Power Source (IEC60950 or UL1950), or be applied exemption.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

1

1. Precautions and Safety Notices

(14) The LCD module is designed so that the CFL in it is supplied by Limited Current

Circuit (IEC60950 or UL1950). Do not connect the CFL in Hazardous Voltage Circuit.

5.2. Handling and Placing Methods

Correct Methods: Incorrect Methods:

Only touch the metal frame of the LCD panel
or the front cover of the monitor. Do not touch
the surface of the polarizer.

Surface of the LCD panel is pressed by fingers

and that may cause “Mura”

Take out the monitor with cushions Taking out the monitor by grasping the LCD

panel. That may cause “Mura”

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

2

Place the monitor on a clean and soft foam pad. Placing the monitor on foreign objects. That

could scratch the surface of the panel or cause
“Mura”

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

3

2. Specification

Parameter Specification

LCD Type

a-Si TFT Active Matrix Wide Color, Transmissive Mode, Normally

Black
LCD Interface 1-Channel LVDS
Resolution (Native) WXGA, 1366 x 768
Display Area 27” diagonal; 596.259 (H) x 335.232 (V) mm.
Pixel Pitch 0.4365(H) × 0.4365(V) mm
Viewing Angle

H = +/- 88°, V = +/- 88° with CR≥20 (Typical)
Contrast Ratio 1000:1 (Typ); 800:1 (Min)
Brightness 550 nits (Typ.); 450 nits (Min)
Response Time 8ms, (Typical), g-g
Color Gamut NTSC 75% Typ
Brightness Uniformity 1.3 (Max), measured per panel spec.
Chromaticity (CIE1931) White-x:0.285,White-y:0.293 (Standard Mode Only)
Colors 16.7M (8-bit)
Surface Treatment Hard coating (3H)
Backlight 14 CCFLs (Cold cathode Fluorescent Lamp)

Panel Acceptance

Refer to the panel acceptance criteria specification.

Note: Intermittent and/or Display Pattern defects which result in

further bright or dark dots will be counted individually against the

above specification.

Front Screen Artifacts

VS Standard:

a.) No Visible Streaking, Sag or Smearing artifacts when driven by

the specified video cards (see 7.1 General Test Equipment) in the
primary mode (VGA at 60 Hz) and after user adjustment

b.) No image drift or lose fine-tune settings due to panel temperature

change
Note: Panel performance characteristics “ MUST BE” met in all display modes/inputs at
standard test conditions.

1. RF Tuner

RF tuner of this product shall be provided by” LG TAPQ-S701D” and “LG TAPE-S701D” for
PAL/SECAM. The following table defines this tuner specification.

Parameter Specification

RF Input Level 0 ~ 15dBmV

RF Tuning Range

CCIR B/G Cable 48.25~463.25
CCIR B/G Air 48.25~855.25
CCIR D/K Air+Cable 49.75~863.25
CCIR I CABLE 48.25~463.25
CCIR I AIR 48.25~855.25

RF Tuner Sensitivity (S/N Ratio at un-weight) -45 dB (min.)

Channel Bandwidth

PAL: 7/8 MHz Maximum
SECAM: 8 MHz Maximum

0.7(min.)–1.3(max.) V

CVBS Characteristics:
Video Amplitude Signal
DC Level Sync Pulse Typical. 0.35 V
Audio Characteristics:
AF Output Level Measured via LP 20 kHz
Filter, RMS Decoder,
50us De-emphasis
THD
S/N

Typical. 0.45Vrms

10% (max.)
40 dB (min.)

Compatible system TUNER SECAM/PAL

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

4

2. Video

Built-in A/D converter shall provide analog to digital converter for this product.

Input Parameter Specification

CVBS Characteristics:
Video Amplitude Signal
DC Level Sync Pulse

0.7(min.)–1.1(max.) V

Typical. 0.3 Vp-p
S-Video Characteristics:
Video Amplitude Signal
DC Level Sync Pulse

Y : 1.0Vp-p W / Neg. Sync (IN 75 Ω )

C : 0.285Vp-p (IN 75 Ω )

Y, Cb,Cr Characteristics:
Video Amplitude Signal
DC Level Sync Pulse

Y:1.0Vp-p(IN 75 Ω)

Pb:0.7 Vp-p(IN 75 Ω),Pr:0.7 Vp-p(IN 75 Ω)

Video Bandwidth PAL: 7/8 MHz Maximum SECAM: 8 MHz Maximum
HDMI Characteristics Panel Link T.M.D.S HDMI-1.1
RGB Characteristics:
Signal Type
Sync Type
Input Signal Rating
Sync Level:
Frequency Range
Pixel Color

Analog VGA

TTL, Separate Sync, with 4.7KΩ pull-down resistors

1250mv Max without damage to the product, 0-700 mv Full

Range

2.5-5.25 V

Horizontal: 30-80K Hz, Vertical: 50-75 Hz

16 M

3. Audio

Audio amp of this product shall be provided by “TI” with a Model Number of

TPA3002D2PHPR(TQFP48) , MST5151A-LF for N2750w-2G shall be used as sound
processor. In addition, a pair of speakers shall be integrated within this product. The audio
signals of this product shall comply with the specification listed in the following table.

Parameter Specification

Phone Jack out
Tuner Input Base band Input
Speaker Power Output Max

Rating

5 W x 2 at 10% T.H.D
Distortion

5W x 2 at 10% T.H.D.
Distortion

Speaker Impedance

main spk :8 Ω
Treble spk :8 Ω

main spk :8 Ω
Treble spk :8 Ω

Line In Per Tuner Spec

500 mV rms (Typ)

1.6 V rms (Max)

Impedance: 600 ohms

Line Out

500 mVrms +/- 10%
@1K Hz tone (with +/-25k Hz
deviation at input, volume
with non-attenuation and
loading with 47k Ohm)

500 mVrms +/- 10%
@1K Hz tone (with +/-25k Hz
deviation at input, volume
with non-attenuation and

loading with 47k Ohm)
Flatness of Amplitude Response
(100Hz ~ 10KHz)

+/- 3 db (at 1KHz @1W) +/- 3 db (at 1KHz @1W)

Total Harmonic Distortion
(1KHz @1W)

2% 2%

Signal to Noise (1KHz @1W) 30 dB (40Hz to 15KHz) 40dB(400Hz to 20 kHz)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

5

4. Electrical

The following table defines the electrical specification of this product.

ELECTRICAL SPECIFICATION

Power Input Voltage Range 100-240VAC +/- 10% Wide Range
Input Frequency Range 47-63 Hz
Input Current 3.0A @ 115VAC // 1.5A @ 230VAC

Power Supply Inrush

Max in < 80A (with fully loaded power supply) at 230Vac
Shall not result in permanent failure of power supply
(including blown fuse)

Power Consumption: Normal Normal: 150 W (Max) // Stand by: < 5 W

Interference with RF and Video

There shall be no visible interference between power
supply, RF and video signals. This applies to all available
RF channels and video modes.

Electromagnetic Compatibility

This product shall adhere to the compatibility and

immunity specifications in BC.
Power Supply Transient Immunity
(Supply Transients and Outage)

Able to withstand an IEC6100-4-4(1995) ring wave with no

damage.

Surge Immunity Test

Able to withstand 1.25X nominal Line Voltage for one

cycle with no damage.

Power Supply Missing Cycle Immunity

Function properly without reset or visible screen artifact

when 1/3 cycle of AC Power is randomly missing.

Power Supply Acoustics

Power supply shall not produce any audible noise during

startup and normal operation. Audible shall define to be

in compliance with ISO 7779 (DIN EN27779: 1991) .

Power Switch noise shall be Excluded.
Efficiency >= 70% @ full load, nominal line
Leakage Current <0.5mA @ 240VAC
Power Saving(DPMS) N/A
Recovery Time < 3 sec.
Power Factor Correction Compliant with EN60065

5. Firmware & OSD

The product firmware of VS11404-1G shall have a firmware version of V:P01. Any
changes/revisions afterward shall also be pre-approved by ViewSonic in written. For
VS11404-1G, its firmware shall have a built-in frequency table for PAL/SECAM
off-air TV/CATV implementation.

All audio/video and other output adjustments shall be performed by using an On Screen
Display (OSD) via a Remote Control Unit (RCU) adjustments. The following tables list
the OSD functions supported by VS11404-1G.

OSD Table for

VS11404-1G

Items Description
TV/VIDEO MODE

Brightness Adjust the Black levels from 0 to 100
Contrast Adjust the White levels from 0 to 100
Sharpness Adjust the Sharpness levels from 0 to 100
Color Adjust the Color from light to heavy
Tint Adjust from Red from Green
Fresh Tone Adjust the skin from shallow to deep
Color Temperature Select the color temperature between warm,Normal or cool.
Bass Adjust the Low Frequency from light to heavy
Treble Adjust the Hi Frequency from light to heavy
Balance Adjust the Speaker output from left to right
Auto scan To auto scan the TV channels (TV or CATV) and scan TV system.
Manual store To adjust the channel search and fine tune or system select.
Name To edit channel name
Sort Channel exchange
Main source Main source select.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

6

H-position To adjust H position
V-position To adjust V position
OSD position-H Adjust OSD horizontal position
OSD position-V Adjust OSD vertical position
Duration To adjust the OSD display delay time.
Halftone To adjust the OSD transparency level.
Language Select OSD language

PC MODE

Auto adjust Automatically adjust the clock,phase,position,and color.
Brightness Adjust the Black levels from 0 to 100
Contrast Adjust the White levels from 0 to 100
Image H.position Adjust the horizontal positions
Image V.position Adjust the vertical positions
Clock To adjust the clock delay time
Phase To adjust the phase delay time

Color mode To select the preset color temperature or user color setting.
Parental TV
Channel Add/Del TV channel Add or Delete

RCU Key function

Power Soft power on or off
Picture Picture effect selections on Cinema,Sport,Vivid,Hi-bright,and User
Sound Sound effect selections on Rock,POP,Live,Dance,Techno,Classic,Soft,and

User

TV-DTV Swap analog TV(NTSC) and DTV(ATSC).Swap to TV when in other

source
MTS Selcetion on Mono,Stereo and Sap sound
Sleep Set TV Power off time
Info Display current source input information
Mute Mute On or Off sound
0 ~ 9, 100/- Direct channel key number
Return Return to last channel
Guide Electric program guide on Digital TV
CH up/down Adjust channel up or channel down
Volume Adjust the Volume levels
Up/Down/Left/Right
arrows

Select or adjust the function of OSD

Fav.ch Switch to favorite channel
Fav.A/D Add or Del favorite channel
Menu Turn On or Off OSD main menu or exit current menu
Input Selections Input Source
Freeze To freeze the current image
Zoom Enlarge or shrink current image on the screen
Wide Adjust image size on Full, Wide1, Wide2, Wide3, 4:3, 16:9, No scale,

Normal
Enter Confirm the selection
PIP/POP Toggle to select PIP or POP function
P.Pos Adjust picture position of sub source during in PIP
P.size Adjust image size of sub source during in PIP
Swap Switch between main screen and sub screen during in PIP or POP
P.input Sub source selection during in PIP or POP
C.C Displaying captions during closed caption source and closed caption mode

select
V-chip Set V-chip rating

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

7

6. Remote Control Unit (RCU)

An IR remote control unit shall accompany this product along with battery. In addition,
this remote control unit shall have an operational distance of 5 meters and an operational
angle of 15 degrees for both horizontal and vertical.

Parameter Specification

Type IR; Made by Bontech Electronics Co., Ltd.

Range

Off axis ± 10° ≥ 5M

On axis: ≥ 7M
Life Testing
(Buttons)

100,000 cycle operations at a rate of 20~30 cycle / minute without load (with

battery)

Color

Painting Color - PANTONE 877C (Silver for front bezel & back cover)

Power Key - PANTONE 186C (RED)

Key Pads – PANTONE 431C & PANTONE 432C(Cool Gray)

Texts Printed on Silver Cover-PANTONE 5455C(Light Gray),PANTONE

433C(Black),PANTONE 129C(Yellow)

(Notes:Above color spec can refer Bontech documents;VS US dwg color

RRC1200-0801L_R2)

Key
Functions

AV Control: Volume-Up/Dowm,CH/PG-Up/Down,Channel

Up/Down,Mute,PIP/POP,Wide,Sleep/Info,P.Source,Swap,Power,Source.

Numeric: 0~9 numeric keys,Recall.

Navigation: Up,Down,Left,Right,Enter,Menu.

Smart sound and Smart video hot key

7. Mechanical

The following table defines the mechanical specifications of this product for both chassis and
cabinet.

Parameter Specification

Dimension W=680mm, H=540mm and D=243mm
Net Weight 14.6kg
Chassis Plastic Material ABS (CABS HB / ABS VO / PC+ABS)
External Plastic Chassis
Components

Plastic Chassis, Cover, Stand, Lens and Button

Internal Plastic Cabinet
Components

N/A

Exterior Chassis Color “Silver” Pantone 877C
Chassis Component’s Color
Difference

N/A (Only silver color on chassis)

Chassis Color Drift Due to
UV-Light

The color drift due to UL-Light shall be less than 10 “Delta
E” in the 1976 CIE L*a*b color space. Testing shall be
performed according to the requirements of ASTM Test

Method D4459-93.
Chassis Texture Front Bezel:N/A ; Back Cover:MT-11020
Molded Plastic Workmanship shall be inspected according to ViewSonic

Molded Plastic Parts Specification, VSCMPPSPEC001V1.2.
Screen Printed Parts, Bird Logo
Recess

Artwork shall be provided and confirmed by ViewSonic.

Rear Label A label identifying the product name, model/serial number

and FCC ID/Logo shall be placed into the rear label recess

located on the rear panel of the chassis.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

8

Wall- Mount 200mmx100mm VESA high hole (n=6), M4 x 10mm , pitch

=0.75mm screw mounting kit not included.

Sample Sample of textured color chips, plastic material specification,

and Material Safety Data Sheets shall be submitted to

ViewSonic prior to Mass Production Release.

In addition, all exterior surfaces shall have uniform texture/color. The maximum acceptable
gap between the buckets to bezel plastic pieces shall be within 1.5 mm. The maximum

acceptable gap between LCD panel and bezel shall be within 2.5 mm.

8. Environmental

Operating Temperature 0°C to +40°C
Storage Temperature -20°C to +60°C
Operating Relative Humidity 65% non-condensing
Storage Relative Humidity 85% non-condensing
Operating Altitude 0 to +3,000 meters above sea level
Storage Altitude 0 to +12,000 meters above sea level

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

9

3. Front Panel Function Control Description

Front View of the Product

Volume Down

Decrease sound volume or adjust a highlighted control while in OSD menu.

Volume Up

Increase sound volume or adjust a highlighted control while in OSD menu.

Menu

T

urn OSD menu ON/OFF.

CH Down

C

hannel down when source is at TV or select a control while in OSD menu.

CH Up

Channel up when source is at

TV or select a control while in OSD menu.

ENTER

T

o highlight a control in OSD menu.

Power ON/OFF button
Power LED Indicator / Remote Control Receiver

1

3

2

4

5

6

7
8

Note:

1. Press VOL+ and MENU buttons at the same time to lock power button, and press
VOL+ and MENU buttons again to unlock it.

2. Press VOL- and VOL+ buttons at the same time to lock OSD menu, and press
VOL- and VOL+ buttons again to unlock it.

7 8

6

54321

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

10

ENGLISH

RF Antenna / Cable TV Input

Connect to the antenna or cable service.

Composite Video Input

Connect other devices, such as DVD or VCD to this port.

YPbPr / HD Component Video Input

Connect the external video devices with component output to these jacks.

S-Video Input

Connect other devices, such as DVD or VCD to this port.

SCART1 Input

Connect other devices, such as DVD or VCD to this port.

SCART2 Input

Connect external devices, such as DVD or VCD to this port.

Audio Input for AV or S-Video

Connect external audio to this port.

Audio Input for YPbPr Components

Connect external audio to this port.

Audio Output

Connect external speaker into this jack.

PC Audio Input

Connect this port to PC line out jack.

Earphone Jack
VGA (15 pin) Signal Input

Connect to a computer.

HDMI Input Terminal

Connect this port to the HDMI output of A/V device.

Power Input (AC Input)

Connect to LCD TV and AC outlet with the power cord.

AC Power Switch (Must be turned on)

Without using for a period of time, turn the switch off.

J

I

F

E

C

D

B

H

G

O

L

M

N

K

A

D

C

F

E

A
B

JL K

N

M

O

I

G

H

Rear View of the Product

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

11

Remote Control

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

12

ENGLISH

Note: PIP means Picture In Picture. POP means Picture Out Of Picture.

Remote control button function as follow

1 POWER Power ON/OFF

2

LED Power LED Indicator

3

MUTE Volume mute ON/OFF

4

SOURCE Select input source (for main screen)

5

INFO Display the current information

6

POP POP ON/OFF

7

PIP PIP ON/OFF

8

P. SOURCE Input source select (for PIP/POP sub-screen)

9

P. SIZE Adjust the size for PIP/POP sub-screen

10

V+ Adjust PIP/POP sub-screen’s volume increasingly

11

V- Adjust PIP/POP sub-screen’s volume decreasingly

12

P+ Select up program for PIP/POP sub-screen

13

P- Select down program for PIP/POP sub-screen

14

SWAP Swap main and sub screen of PIP/ POP

15

P. POS Adjust PIP/POP sub-screen’s position

16

RED Enter program name edit function

17

GREEN Add desired channels

18

YELLOW Erase desired channels

19

BLUE Confirm edited name

20

VOL UP/ DOWN Adjust volume up or down

21

SMART. S Select situation mode for sound

22

SMART. P Select situation mode for picture

23

PROGRAM UP/ DOWN Select up or down programs

24

MENU OSD menu ON/OFF

25

ASPECT Aspect ratio, used to select image size

26

UP/DOWN/LEFT/RIGHT Select or adjust the function of OSD

27

ENTER Confirm the selection

28

AVC The tuner contains automatic volume control circuitry (AVC)

to prevent converter overload

29

M S SOUND Sound select between main screen and sub-screen

30

0~9 NUMBER

Switch channel number buttons

31

SLEEP TV Sleep timer setup

32

FLASHBACK Return to previos channel

33

DUAL I / II MTS (Multi-Channel TV Sound) select

34

FREEZE Freeze picture

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

13

ENGLISH

Sound

• Sound Mode Select
Press SMART. S to select the sound mode between Movie, Music, Speech, and User.

PIP/POP

PIP/POP button allows you to watch two screens from different sources at the same
time. (PIP is picture in picture; POP is picture out of picture)
Press PIP/POP on the remote control repeatedly.
The screen will change from normal screen → PIP screen → POP screen.

• PIP Input Source Select

1. Press P. SOURCE button to select input source for sub-screen as following.

2. Press ENTER to confirm selection.

• SWAP
Press SWAP to exchange main-screen to sub-screen.

• PIP Size Select
Press P.SIZE to select the size of sub-screen. The function only acts on PIP.

• PIP Position Select
Press P.POS to select the position of sub-screen. The function only acts on PIP.

• Adjust Volume of Sub-screen
Press V+ and V- to adjust volume of sub-screen.

• Select Program for Sub-screen
Press P+ and P- to select the program of sub-screen.

Main Screen Available Sub-Screen Input Source

TV / AV / S-VIDEO / SCART1 / SCART2 /
SCART2-SVIDEO

D-SUB / HDMI / HD

D-SUB / HDMI / HD

TV / AV / S-VIDEO / SCART1 / SCART2 /
SCART2-SVIDEO

PIP Screen POP Screen

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

14

ENGLISH

OSD Functions

Picture Menu — Adjusting the picture

It is active in TV / AV / S-VIDEO / HD / SCART1 / SCART2 / SCART2-SVIDEO / HDMI
source.

• Contrast: To adjust contrast of video.

• Brightness: To adjust luminance of video.

• Colour: To adjust colour.

• Tint: To adjust tint level.

• Sharpness: To adjust picture sharpness.

• Fresh Tone: To adjust colour of skin.

• Colour Temp.: To select the screen colour temperature between Normal, Warm, and Cool.

Sound Menu — To adjust sound

It is active in all input sources.

• Source: To select the sound source from main screen or sub screen by pressing ◄►.

Note: It is available in SCART1/ SCART2/ SCART2-SVIDEO. However, in other input sources,
it is only active when in PIP/POP condition.

• Bass: To adjust bass (It is active in TV/ SCART1/ SCART2/ SCART2-SVIDEO. However,

in other input sources, it is only active when sound mode is in “User” condition).

• Treble: To adjust the treble (It is active in TV/ SCRT1/ SCART2/ SCART2-SVIDEO.

However, in other input sources, it is only active when sound mode is in “User” condition).

• Balance: To adjust left and right audio balance.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

15

ENGLISH

Channel Menu — To setup for TV

It is only active in TV source.

• Auto Scan: To automatically preset the channels into TVs memory by pressing◄►. Kindly

suggest you auto scan all the channels before watching your TV for the first time.

Note: Auto Scan will scan twice. First scan for PAL system, and second scan for SECAM
system. After auto scan all the channels, you need not to do it again when turning on your
TV next time.

*China TV system: PAL D/K

• Manual Store: The function is to give a minute search for possible existing channels and

store them in memory.

1. Press ◄ or ► to get into “Manual Store”.

2. Move the cursor to “Prog. No”, and select the desired channel position with ◄►.

3. Move the cursor to “System”, and select the system according to your local area with◄►.

4. Move your cursor to “Search”, and search the detectable channels with ◄►.

5. Move your cursor to “Fine Tune”, and adjust the picture with ◄►.

6. Move to Store, then store the instruction with ENTER .

Note: The channel will be stored instead of the former program.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

16

ENGLISH

If you want to exchange channel 1 with channel 2:

1. Move your cursor to “From,” and press ◄► to select channel 1.

2. Move your cursor to “To,” and press ◄► to select channel 2.

3. Move your cursor to “Store,” and confirm the instruction with

ENTER .

4. Press MENU to exit.

• Sort: To exchange one channel with another. Press ◄ or ► to get into “Sort”.

1. To enter a name:

Press red button (on the remote control) to move your cursor to “Name”.
Use ▲▼ to select the desired letter and use◄► to move the cursor to enter next letter.
To confirm the name, press blue button.

2. To Erase/Add channels:

Use ▲▼ to select the desired channel.
Press yellow button to erase the channel or press green button to add it.
When using Program▲▼ button, the channels you erased will be passed over. You may
press green button to add the erased channels or use Auto Scan function to re-present
them.

• Name: To enter a name for program with 0~9, +-. /, and A~Z. Press ◄ or ► to get into “Name”.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

17

ENGLISH

Option Menu

When input source is TV/ AV/ S-VIDEO/
HD/ SCART1/ SCART2/ HDMI (HDCP)
SCART2-S-VIDEO:

• Main Source: To select the input source for main screen between TV, AV, S-VIDEO, HD,

SCART1, SCART2, SCART2-SVIDEO, D-SUB, and HDMI with ◄►.

• H-Position: To adjust the horizontal position of the video with ◄►.

• V-Position: To adjust the vertical position of the video with ◄►.

• Language: To select the OSD language between English, Simply Chinese and Traditional

Chinese with ◄►.

• Reset: Press ENTER to reset all the settings in All mode.

• Auto Adjust: Auto adjust picture’s horizontal position, vertical position, fine tune, and

H-Size with ◄►.

• Contrast: To adjust foreground luminance of video.

• Brightness: To adjust background luminance of video.

• H-Position: To adjust horizontal position of video.

• V-Position: To adjust vertical position of video.

• Clock: To adjust delay time of clock in order to reduce the noise of picture.

• Phase: To adjust delay time of phase in order to reduce the noise of picture.

PC Menu — to adjust for PC

It is only active in D-SUB and HDMI (support PC mode).

When input source is D-SUB: When input source is HDMI (PC):

When input source is D-SUB/ HDMI (PC):

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

18

ENGLISH

OSD Menu — to setup OSD window

It is active in all input sources.

• H-Position: To adjust the OSD horizontal position with ◄►.

• V- Position: To adjust the OSD vertical position with ◄►.

• Duration: To automatically shut off the OSD after a preset period of time passed. Use ◄►

to preset the time from 5 to 60 seconds.

• Halftone: To adjust background transparency of OSD.

1. Press ◄ or ► to get into Colour Mode.

2. Use ◄►to select between Cool, sRGB, User, Normal, and Warm.

3. When select “User”, it allows you separately adjust the colour of red, green, and blue.

• Colour Mode: To adjust colour temperature.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

19

A. A/D converter (PC & YPbPr) and DVI(HDCP) input

The MST5151A-LF offers designers the flexibility of an analog interface and
High-Definition Multimedia Interface (DVI) receiver integrated on a single chip. Also
included is support for High bandwidth Digital Content Protection (HDCP).

Analog Interface

The MST5151A-LF is a complete 8-bit 165 MSPS monolithic analog interface optimized
for capturing Component Video (YPbPr) and RGB graphics signals. Its 165 MSPS encode rate
capability and full power analog bandwidth of 300 MHz supports all HDTV formats (up to
1080p) and FPD resolutions up to UXGA (1600 x 1200 @ 60 Hz). The analog interface
includes a 165 MHz triple ADC with internal 3.3V reference, a Phase Locked Loop (PLL),
and programmable gain, offset, and clamp control. The user provides only 1.8V and 3.3V
power supply, analog input, and Hsync. Three-state CMOS outputs may be powered from

1.8V to 3.3V. The MST5151A-LF on-chip PLL generates a pixel clock from Hsync. Pixel
clock output frequencies range from 12MHz to 165 MHz. PLL clock jitter is typically less
than 500 ps p-p at 165 MHz. The MST5151A-LF also offers full sync processing for
composite sync and Sync-on-Green (SOG) applications.

Digital Interface

The MST5151A-LF contains a DVI(HDCP) 1.0 compatible receiver and supports all
HDTV formats (up to 1080p) and display resolutions up to UXGA (1600 x 1200 @ 60 Hz).
The receiver features an intra-pair skew tolerance of up to one full clock cycle. With the
inclusion of HDCP, displays may now receive encrypted video content. The MST5151A-LF
allows for authentication of a video receiver, decryption of encoded data at the receiver, and
renew ability of that authentication during transmission as specified b y th e HDCP v1.1
protocol.

Fabricated in an advanced CMOS process, the MST5151A-LF is provided in a
space-saving 100-lead LQFP surface-mount Pb free plastic package and is specified over the 0

o

C to 70 oC temperature range.

B. Video Decoder (video)

The SAA7117 is a highly integrated NTSC, PAL, and SECAM video decoder support for
high quality LCD-TV video applications, SAA7117 supports NTSC/PAL chroma and luma
separation using a 2-dimensional adaptive comb filter for reducing the cross-luma and
cross-chroma artifacts. The frame buffer is also use for 2D noise reduction circuit that resumes
good visual quality when the input signal is a noisy video source

The SAA7117 10-bits CMOS Analog-to-Digital Converters(ADC) at four-fold ”ITU656”
oversampling(54MHZ);Sixteen analog input pins.allowing fo multiple combinations of
composite.S-Video component video;Eight 3-level capable sensor pins for D-connector or
SCART AV- and RGB- switch signals(three of those can be active simultaneously),one Fast
blanking input;Level sensitive fast blanking(RGB switch control);I²C read back of digital
AGC gain factor; The component, composite, or S-Video signals are sampled at a free-run
external clock frequency (10~58.6 MHz). After the video decoder processing, the video data
was sent out with a line-locked alignment rate (24.576 MHz).

The SAA7117 comes with 160-pin QFP package.

C. Scaling controller

The MST5151A-LF chip is a LCD-TV controller chip for color display up to SXGA or

/WXGA wide screen panel. It includes a 128/256/512 4-bit/fixel font 3D interlace-to
progressive video processing. It also supports non-linear scaling for 4:3 to/form 16:9
conversion, flexible picture in video display, cinema to TV conversion, hue/saturation
adjustment, and advanced OSD system.

The MST5151A-LF chip is targeted for the applications of high-end LCD-TV. It will

accept all HDTV video signals for flat panel display. It comes with 256-pin LQFP package.
General Feature:

 1M*32Bit*4Banks SDRAM controller for interlaced to progressive video processing and

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

20

4. Circuit Description

fram-rate conversion for computer graphics.

 PIP (picture in picture)/POP(picture on picture)
 MstarACE-2 picture/color processing and Embedded On-screen display controller(OSD)

engine

 Hardware mode detection for HDTV.
 Two sets of mode detection for flexible simultaneous main- picture and sub-picture

display.

 Copy protection detect and display enable.
 On chip hue, saturation, brightness, contrast, and gamma correction.
 Max pixel rate up to 135 MHz.
 Video Black White Expansion.
 Flesh tone adjustment.
 Improved temporal-spatial dithering.
 Non-linear scaling for 4:3 to/form 16:9 conversion.
 Auto cinema mode detection, 3:2/2:2 pull-down, and 3D de-interlacing.
 Desk and ceiling mode for projector application.
 PWM (Pulse Width Modulators) from 28K to 100Hz.

D. Audio

Three audio sources put into MSP 4410G which fist sel ect t he sources and do pre-amplify. The
bass treble control also is provided. The control of all the functions is accomplished by serial
bus. Audio amplifier put into IC TI TPA3004D2 is a class-D amplifier that is output power of
20W/channel on a 12V power supply operation.

E. Tuner

The Antenna receive the TV signal and modulate it to the CVBS signal which can be
recognized by the decoder and FM-stereo/FM-mono/NICAM audio signal output to the sound
Automatic standard decoder IC MSP3410G. The MCU can automatic detect the tuner and send
order by serial bus.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

21

1. Function Test

1.1. Product

- 27” LCD TV

1.2. Test Equipment

-PC signal generator: CHROMA 2525 CARD ,CHROMA 2327 or 2329,Pioneer
DV-S969AVi.

-TV and Video signal generator.

-Color analyzer: MINOLTA CA110.

-Power meter: CP-310A or CP-320A.

-AC power supply transformer: 110V/120V ±20% 60Hz ±5%.

-Digital ammeter

1.3. Test Condition

Before function test and alignment, each LCD TV should be run-in and warmed up for at
least 30 minutes with the following conditions:
(a) In room temperature,
(b) With full-white screen, and 16 grey scale,
(c) With cycled display modes.

1.4. Test Display Modes & Pattern

1.4.1 EEPROM INIT
A. Timing: 1360*768@60Hz
B. Pattern: 16*12 grids
C. Press ’POWER’, ‘▲’and ‘ENTER’ at the same time, then go into the FACTORY

MODE.

Fig. 1 Fig. 2

D As shown in Fig. 1, press “ENTER” key and Fig.2 will show. After “EEPROM

INIT” disappears, the procedure of “EEPROM INITIAL” is completed, and the OSD
moves to “WHITE BALANCE”.

1.4.2 COLOR TEMPERATURE ADJUSTING
PC MODE:

A. Timing: 1360*768@60Hz.
B. Pattern: 16 gray-scale and all-white screen.
C. Confirm that the TV uses BURN IN screen and the warm-up time lasts over 30

minutes.

D. How to enter/exit BURN IN mode:First, enter Factory mode OSD (refer to

previous instruction), move the cursor to the column of BURN IN, press
“ENTER” key to switch to ON, press ”POWER” key to restart the TV, and then
press ”ENTER” key to enter BURN IN mode. To exit BURN IN mode, repeat the
procedure again, but switch the column of BURN IN to “OFF”.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

22

5. Adjusting Procedure

E. Confirm that the distance between the SENSOR of CA110 color temperature

meter and the central point of the machine is 20cm.

COLOR TEMPERATURE OSD

Fig.3 Fig.4

When in the 16 gray-scale screen, the cursor will point to “WHITE BALANCE”, as shown in
Fig.3. Press “ENTER” key to start temperature adjustment automatically, as shown in Fig.4.
After “WHITE BALANCE” disappears, the performing of “WHITE BALANCE” is
completed.After the adjustment is done, switch to an all-white screen to confirm the
chromaticity coordinate value.

Preset color for N2750w (2G)

Normal ---- 9300 x=0.285 ±0.015 y=0.293±0.015
Warm ---- 6500 x=0.313 ±0.015 y=0.329±0.015

COOL ----- 12000 x=0.271 ±0.015 y=0.278±0.015

1.4.3 COLOR TEMPERATURE ADJUSTING

HD MODE:

A.

Timing: PAL OR NTSC

B.

Pattern: Color bar

When in the color bar screen, the cursor will point to “WHITE BALANCE”, as shown in
Fig.3. After “WHITE BALANCE” disappears, the performing of “WHITE BALANCE” is
completed.

Normal ---- 9300 x=0.285 ±0.015 y=0.293±0.015

Warm ---- 6500 x=0.313 ±0.015 y=0.329±0.015

COOL ----- 12000 x=0.271±0.015 y=0.278±0.015

1.4.4 POWER SAVING TEST

A. Timing: 640 × 480 @ 75Hz
B. Pattern: TEST-TTL/ECL

C. Set BRIGHTNESS and CONTRAST to the maximum
D. The power dissipation for each mode is as follows

MODE Maximum Power

Dissipation

POWER LED COLOR

NORMAL <150W GREEN

Standby < 5 W Orange

OFF < 5 W Orange

1.4.5 Confirm HDMI MODE TIMING
A. In DVI MODE, switch TIMING according to the FACTORY PRESET TIMING

TABLE, and confirm that the screen is normal
B. Confirm that the four TIMING screens of 408i, 480P, 720P, and 1080i are normal
C. Confirm that HDMI DVD functions normally

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

23

1.4.6 Confirm OSD Function Performing
A. Timing: 640 × 480 @ 75Hz
B. Pattern: “GENERAL-1
C. Confirm that each function in the OSD works
D. After the confirmation is completed, the default setting of EEPROM INITIAL

AND WHITE BALANCE must be restored before shipping

1.4.7 DTV FUNCTION TEST
A. Select input source to DTV, Fig.3 will be shown.

Fig.3

1.4.8 YPbPr, S-VIDEO, AV, TV, DTV’S FUNCTION TEST
A. Input YPbPr, S-VIDEO, AV , TV, DTV’S signal and check.
B. Input USA air channel (TABLE 1) and USA CATV channel for TV channel.
C. Under YPbPr MODE, Make sure the 408i, 480P, 720P, 1080i is right.

1.4.9 AUDIO FUNCTION TEST

A. Audio input includes PC AUDIO IN, S-VIDEO/AV AUDIO IN and YPbPr AUDIO

IN.

B. Under PC MODE, input PC AUDIO signal, checks whether the action of AUDIO

IN is right.

C. Under S-VIDEO/AV MODE, input L/R AUDIO signal, checks whether the action

of AUDIO IN is right.

D. Under YPbPr MODE, input L/R AUDIO signal, checks whether the action of

AUDIO IN is right.
E. Under HDMI MODE, checks whether the action of AUDIO IN is right.
F. Under DTV MODE, checks whether the action of SPDIF is right.
G. AUDIO OUT FUNCTION TEST: Under all patterns except PC pattern, The Audio

output meets active extra speaker, examines whether the extra speaker makes the

sound.

1.4.10 EARPHONE FUNCTION TEST
Under PC MODE, input PC AUDIO signal, determines whether the action of INT
SPEAKER output is right. Meets earphone with the EARPHONE, Determined
whether the action of EARPHONE output is normal.

1.4.11.TV RECEIVING TEST:

A. Examines sound by ear, whether the sound does have mechanical resonation and

the electrical unusual sound, and image to sound disturbance.

B. Examines whether the sound does receive the image disturbance, Judgment basis:

Whether there is unusual sound, input signal LEVEL<=36dBu,and STEREO
SENSITIVITY is normal.

C. Adjustment attenuator, If the critical point of the change of the image signal to

noise ratio is under LEVEL<=60dBu,regards as normally.

D. Examines TV brightness; confirm whether DUAL FUNCTION is normal under

DUAL MODE: whether DUAL SENSITIVITY is normal when input signal is
under LEVEL<=36dBu.

E. Examines whether PAL color demodulation is normal by using DEM image;

whether STEREO SENSITIVITY is normal when input signal is under
LEVEL<=36dBu.

F. Examines whether DUAL FUNCTION is normal under DUAL MODE; whether

DUAL SENSITIVITY is normal when input signal is under LEVEL<=36dBu.

G. Examines whether the sound does receive the image disturbance, Judgment basis:

Whether there is unusual sound, input signal LEVEL<=36dBu,and STEREO

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

24

SENSITIVITY is normal.

H. Adjustment attenuator, If the critical point of the change of the image signal to

noise ratio is under LEVEL<=60dBu,regards as normally.

1.4.12.VIDEO RECEIVING TEST:

AV receives supply oscillator: AV/S-Video/HD/SCART1/SCART2/SCART-SV are

from DVD to LCD TV; Examines whether has the image and the sound and is

normal.
A. AV: Video cable (Yellow), Audio cable (Left (White), Right (Red) sound track).
B. S-Video: S-Video signal cable (White), Audio cable (Left (White), Right (Red)

sound track).

C. HD (Ypbpr/YcbCr): brightness signal cable (Green), Component signal cable (Red,

Blue), Audio cable (Left (White), Right (Red) sound track).
D. SCART1: 21Pin SCART signal cable (Black).
E. SCART2: 21Pin SCART signal cable (Black).

1.4.13.VIDEO/AUDIO OUTPUT TEST:
A. SCART/AV output: A 27” LCD TV in AV pattern, inputs the CVBS signal; the

output meets SCART, SCART connects another 27” LCD TV which is in SCART
pattern, Examines two 27” LCD TV whether demonstrates the same image. But
their sound doesn’t mutually affect, Must respectively adjust volume to examine
sound. AV output test method is in the same way.

B. Under any pattern except PC pattern, The Audio output meets active extra speaker,

examines whether the extra speaker makes the sound.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

25

1.5. Compatible Mode Table

All timings must be properly PHASED, SIZED, and CENTERED.

Aspect Ratio=Resolution to which the native signal is SCALED and CENTERED
1:1=Centered, 1:1 Pixel Correlation, No Scaling. No Filtering, Image must be properly

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

26

phased.
Full Screen=The Input timing is scaled to full screen, regardless of scaling artifacts.
=>640*480

N/A=Not Applicable to a green timing.

MODE

CVBS SVHS YCBCR

(scart CVBS)

YPBPR

(scart RGB)

RGB

(D-Sub)

HDMI

(HDCP)

TV

RF(Analog)

NO NO NO NO NO NO YES

576i

YES YES YES YES NO YES NO

576p

NO NO NO YES NO YES NO

HD 720p

NO NO NO YES NO YES NO

HD 1080i

NO NO NO YES NO YES NO

640*480@60Hz

NO NO NO NO YES YES NO

640*480@75Hz

NO NO NO NO YES YES NO

800*600@60Hz

NO NO NO NO YES YES NO

800*600@75Hz

NO NO NO NO YES YES NO

1024*768@60Hz

NO NO NO NO YES YES NO

1024*768@75Hz

NO NO NO NO YES YES NO

1280*720@60Hz

NO NO NO NO YES YES NO

1280*768@60Hz

NO NO NO NO YES YES NO

1360*768@60Hz

NO NO NO NO YES YES NO

1280*1024@60Hz

NO NO NO NO YES YES NO

Chart 3. Mode Compatibility Table---N2750W(2G)

MODE

1:1 FS FA R

576i**

N/A 1366*768 1024*768*

576p**

N/A 1366*768 1024*768*

HD 720p

1250*700 1366*768 N/A

HD 1080i

N/A 1366*768 N/A

640*480@60Hz

N/A 1366*768 1024*768*

640*480@75Hz

N/A 1366*768 1024*768*

800*480@60Hz

800*600 1366*768 1024*768*

800*600@75Hz

800*600 1366*768 1024*768*

1024*768@60Hz

1024*768* 1366*768 N/A

1024*768@75Hz

1024*768* 1366*768 N/A

1280*720@60Hz

1280*720* 1366*768 N/A

1280*768@60Hz

1280*768* 1366*768 N/A

1360*768@60Hz

1360*768* N/A N/A

1280*1024@60Hz

N/A 1366*768* N/A

Chart 4. ASPECT RATIO CONTROLS (YPBPR/RGB/HDCP Only): Viewing Window

(on1366*768 panel)---N2750W(2G)

*=Default Setting,**=These modes also woke on CVBS/SVHS/YCBCR inputs

1.6. All Modes Reset

After final QC step, we have to erase all saved changes again and restore the factory defaults.

You should do “All Mode Reset” again.
Power Off LCD TV.

Turn off the LCD TV by pressing “Power” button.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

27

2. DDC Key In Procedure
Note:

1. Every time after replacing the main board, you have to do the DDC key in.

2. If you find the DDC does not conform to the LCD TV, you have to do the DDC key in.

2.1 Equipment Needed

- N2750W(2G) LCD TV

- DDC Card

- PC

- RS-232 cable

- Barcode Reader

- VGA Cable

N2750W(2G) LCD TV DDC Card PC

RS-232 Cable VGA Cable Barcode Reader

2.2 Setup Procedure

2.2.1 Connect VGA Card and DDC Card with RS-232 cable.

2.2.2 Barcode Reader connects with keyboard and PC keyboard port.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

28

2.2.3 Connect DDC Card and N2750W(2G) LCD TV with VGA Cable.
(When key in DVI DDC information, use VGA transform to DVI port.)

2.2.4 Connect Power Cord to N2750W(2G) LCD TV.

2.3 DDC Key In Procedure

2.3.1 Run DDC.exe

2.3.2 Choose model number and conform the Time then Press “ENTER” key.

2.3.3 When appear the PIC “ choose DDC Card”, Press ALT+2 Enter DDC 2B test

interface

.

Choose DDC Card

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

29

2.3.4 Press F8 to choose corresponding model. DAT
(N2750W(2G)-A.DAT press “ENTER” key)

2.3.5 Press F9 enter the download interface

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

30

2.3.6 Key in the serial number or use the barcode reader to scan the barcode of the LCD

TV, and press “ENTER” key.

2.3.7 The successful picture is as follows. “Compare EDID:OK! Press any key to

continue”.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

31

2.4 Check Method

Use ViewSonic EDID Editor

Connect the N2750W(2G) LCD TV to PC with VGA Cable. Execute the EDID Editor,
then Press Ctrl+F5. If the DDC is correct, you can see the information as follow:

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

32

3. Firmware Upgrade Procedure
When you receive the returned LCD TV, please check whether the firmware version is

the latest. If not, please do the following procedures to upgrade it to the latest version.

3.1 Equipment Needed

- N2750W(2G) LCD TV

- Fixture for Firmware Upgrade

- VGA Cable

- PC (Personal Computer)

- RS-232 Cable (pin to pin)

- Firmware Upgrade Program

- One additional LCD TV for checking the program execution

3.2 Setup Procedure

3.2.1

Connect P2 of Fixture with COM port of PC by RS-232 Cable.

3.2.2 Connect P1 of Fixture with N2750W(2G) LCD TV by VGA Cable.

3.2.3 Connect Power Cord to N2750W(2G) LCD TV.

3.2.4 Connect PC to the additional LCD TV.

3.3 ISP Download program procedure

3.3.1 HARDWARE CONNECT STATUS:

Com Port

PC

N2750W(2G) LCD TV

RS-232 Cable (pin to pin)

VGA Cable

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

33

3.3.2 DOWNLOAD ISP PROGRAM

Step 1: Execute ISP.exe

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

34

Step 2: Select MCU type

Pressing the Comb box to select the type of the MCU, It need to be selected W79E632

for this project., then press the OK Button.

Step 3: Load file

Press the Select File 0

and Select File 1 button to select the file (File 0 and File 1) will

be downloaded. (*.Hex)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

35

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

36

Step 4: Test Communication

Pressing the ConN

ect button to test whether the communication is well.

Step 5: Run

Pressing the Program All to start download program. Pressing the ‘確定’ Button to finish

the download program procedure.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

37

Trouble shooting:

If you find the status like the follow picture. Please check the following item.
a. The connecting status between PC and ISP board.
b. The connecting status between ISP status and LCD TV.

Turn off the power of LCD TV (AC plug off) and disconnect the D-Sub connector. To
connect the D-Sub connector and then turn on the power of LCD TV.(AC plug on)

If the test result shows “Connected,” it means the connection is well. If not (failed), it
means the connection has problems. Then you need to check the setup procedure or
reboot the PC, or simply use another PC to do the firmware upgrade.

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

38

Packing For Shipping And Disassembly Procedure

Packing For Shipping

1. Packing Procedure

1.1 Paste protection film to protect the LCD TV. (Figure 1)

1.2 Put the LCD TV in the PE bag and seal the bag. (Figure 2)

1.3 Put the cushions on the LCD TV and then put all the accessories into the carton. (Figure 3)

1.4 Place the LCD TV into the carton .At last, close the carton and seal it with tape. (Figure 4)

Figure 4

Figure 3

Figure 1 Figure 2

1.Power Cord 2.VGA Cable 3.M/F Cable

4.RCA Cable 5.User’s Guide 6.Remote contrl

7.Guarant Card 8.Battery

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

39

PACKING PART LIST ( N2750W-2G )

ViewSonic Model Number: VS11404-1G

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

40

Item ViewSonic P/N Ref. P/N Description Q'ty

1 N/A N2750W(2G) monitor 1
2 N/A 2013054003P POLYETHY BAG 1
3 2012198300P JC278 EPS TOP 1
4 2012198600P JC278 EPS MID 1
5 2012198500P JC278 EPS DOWN 1
6 P-00008064 2013228807P POLYETHY BAG 1
7 DC-00008111 2001131610P OWNER GUIDE 1
8 DC-00008112 2002310592P GUARANT CARD(QSG) 1

9 A-00006132 2427130097P AC POWER CORD 1
10 CB-00003425 2427701893P RCA CABLE 1
11 CB-00008036 2427751802P M/F CABLE 1
12 A-VC-0101-0386 2427501187P VGA CABLE 1
13 P-00004497 2011100017P CARTON BOX 1
14 P-00008113 2011127035P CARTON BOX 1
15 N/A 2055632220P LABEL 1
16 N/A 2005100400P BATTERY 2
17 A-00004438 2419200047P REMOTE CONTRL 1

Rev: 1.0

Disassembly Procedure

1. Disassembly of Stand and Dust Cover from LCD TV.

1.1 Detach Dust Cover from the LCD TV and Unscrew 4 screws that secure Stand Unit.

Stand Dust Cover Dust Cover

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

41

2. Disassembly of Rear Cover.

2.1 Unscrew 8 screws to remove Rear Cover.

3. Disassembly of Main Board,Power Board,IR Board,Speaker,Front Cover
and Panel Unit.

3.1 Unscrew 14 screws to remove Shield Plate and dust cover.

Rear Cover

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

42

3.2. Unscrew 4 screws to remove Speaker.

3.3. Unscrew 10 screws to remove Bracket.Fix.

Shield Plate

Speaker

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

43

3.4. Unscrew 15 screws to remove METAL FITTG-IO.

METAL FITTG-I/O-Down

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

44

3.5. Unscrew 5 screws and disconnect the wires to remove Main Board.

METAL FITTG-I/O-Side

Main Board

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

45

3.6. Unscrew 4 screws and disconnect the wires to remove Power Board.

3.7. Unscrew 2 screws to remove Front Cover.

Power Board

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

46

3.8. Lay Panel Unit facedown and unscrew 9 screws on its right,left,up and down sides, to remove
Panel Unit and Panel Bracket.

Panel Bracket

Panel Unit

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

47

6. Trouble Shooting Flow Chart

6.1. NO POWER

Check

P902 pin 5,6

Is 12v?

START

Check I301
is working?

Check p711
pin 5 is 5v?

Replace IR board

Check wireharness

P703

Replace

X301,I302,I301

Remove P902

Check 12v & 5v

Replace Power

Board

NO

NO

NO

NO

YES

YES

YES

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

48

Check

I501 pin 14

Replace I501

Check I601

pin 44,45

Replace I601

Check C602,C603

L601,L604

Check

I205 pin 9,10,12,13

C264,C265,L512,L513

Check

I205 pin 9,11,12,14

C261,C262,L510,L511

Check I601

pin 38,39

Check

C610,C612,L605,L606

Check I601

pin 35,36

Check I601

pin20,21

Check Power

12v

Check L609

12v?

Replace I602

Check P603

Check speaker

L607,L608
C607,C608

Check I601

pin 41,42

NO

NO

SCART1

SCART2

NO

NO

NO

PC

NO

NO

NO

Yes

Yes

Yes

TV model

SCART

AV,

S-VIDEO

YPbPr

6.2. NO VOICE

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

49

Check I501 pin 12 has

signal?

Replace I501

Check I203 pin 27 has

signal

Check

I204 pin 2,6 has

signal?

Check

I205 pin 2,4 C259

Check

I205 pin3,4 C263

Check

I203 pin 26,34 has

signal?

Check

C272,C273,R245,R246,

L501,L503

Check

I207 pin 27

Check

I204 pin 2,4 L502

Check I203 is

working?

Replace X201

Check I107 has output signal at

RP30,RP31

Replace I101

Check

P401 pin 4,5+5v?

Check FFC cable & LCD

Panel

Replace I404

Check

I401 LVDS

signal out

Check

I401 pin 34 has signal?

Check

C504,R502

L504

Replace

I401

NO

NO

NO

NO

NO

NO

NO

NO

NO

NO

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

TV model SCART SCART1

SCART2

S-VIDEO

AV

YPbPr model

6.3. NO DISPLAY

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

50

Check power region Check led color

Press menu Key if

osd display

DVI D SUB YPbPr

Check I/O cable is ok

Check I/O signal is in pwr

saying mode?

Refer to No Power
trouble shoot flow

chart

Press Power Key on/

off is ok?

Check X301 crystal 24MHZ if

working?

Check I301 if RST pin81 have reset pulse

Check I301 reset

Change I301

Check keypad pcb is

ok?

Check Reset circuit

Check if inverter is ok

Change Inverter

I301 set reset pusle?

Check I103 crystal 14.318MHZ if working?

Change I301

Check P401 data bus have signal

Check panel power 5v

Change LCD panel

dark

Amber

yes

Amber&Green

Green

yes

n

y

n

y

n

n

n

yes

y

n

y

y

n

yes

y

y

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

51

7. Block Diagram

N2750w-2G SYSTEM BLOCK

YPbPr(HD)

HDMI

VGA

MST5151A-LF

I401

I402

KEY PAD & IR

14.318MHz

SCALER

SAA7117

I203

Video decoder

AV

SV

TUNER I501

SCART1

SCART2-SV

PANEL

128Mbit DDR

5W*2

I601

Audio decoder

MSP4410G

PC AUDIO INPUT RL

AV/SV AUDIO RL

HD AUDIO RL AUDIO AMP

I602

TPA3002D2

I2S

MCU

W79E632A

I301

SIF

Scart Audio IN R/L

I205

A/V Switch

TS5V330DBQR

A

A

V

V

Scart Video IN

SCART1 / SCART2 Audio out

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

52

8. Schematic Diagrams

8.1. VGA and HDMI Interface

VGA Analog InputHDMI Input

ISP_SDA

ISP_SDA

RIN

SOG

RIN+

RIN-

GIN+

GIN-

BIN+

BIN-

TXD

RXD

ISP_SDA

ISP_SCL

VGA_VS

ISP_SCL

ISP_SCL

VGA_HS

VGA_CK

HS

GIN

VS

VGA_Cable_Check

RXC+

RX0-

RX0+

RX1-

RX1+

RXC-

GVCK

RX2-

RX2+

+5V_DSUB

VGA_SDA

VGA_SCL

BIN

SCL_HDMI

SDA_HDMI

GSDA

GSCL

5VD

5VD

5VD

5VD

5VD

+5V_DSUB

5VD

GVCCGDC5V

GVCCGVCC

GDC5V

GDC5V

+5V_DSUB

V33

R111 47R

R119
2K2

R109 47R

L101 0 ohm/0805

R115
100

C117
NC

C119

0.1U

R126 10

D114

MLL5232B 5.6V

D118
SM17

1 2

D115

MLL5232B 5.6V

C114

V_PORT 10P

C112
V_PORT 10P

L105 0 ohm/0805

C103 47nf

D116
SM17

1 2

R124 100

R128 10

C115

NC

C118
NC

R118
2K2

C107

NC

R103 47R

R112

4K7

L104 0 ohm/0805

R101 10

I102

24LC22/SMD

1
2
3

4

5

6

7

8

NC1
NC2
NC3

GND

SDA

SCL

VCLK

VCC

C110

NC

D111

MLL5232B 5.6V

R113
4K7

D108

MLL5232B 5.6V

R125 10

C105 47nf

R129 10

C106 47nf

R138

1K

C108 47nf

R139 10K

D109

MLL5232B 5.6V

R132 10

C116

NC

Q101

MMBT3904

1

2 3

C109 47nf

R131 10

C111 47nf

R105 47R

D110

MLL5232B 5.6V

I101

24LC22/DIP

1
2
3

4

5

6

7

8

NC1
NC2
NC3

GND

SDA

SCL

VCLK

VCC

C104

NC

R106 47R

1611

P102

VGA_DB15P

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16 17

R135

2.2K

R104

75R

D112
1N4148WS

1 2

L103

0 ohm/0805

D117

5.6V

1 2

R108 47R

R133 4.7K

P103

SIP4

Debug Port

2.54mm/Male

1
2
3
4

I103

24LC21(SMD)

1 8
2 7
3 6
4 5

NC VCC
NC VCLK
NC SCL
GND SDA

R120

100

C101

10nf

C113
V_PORT 10P

R110

75R

R137 100

R134

2.2K

R136 100

P101

HDMI/19

1

3

5

7

9

11

13

15

2

6

8

10

14

4

12

16

17

19

18

RX2+

RX2-

GND

RX0+

RX0-

GND

CEC

SCL

GND

RX1-

GND

RXC+

NC

RX1+

RXC-

SDA

GND

DET

+5V

R107

75R

D113
1N4148WS

1 2

R130 10

C120

0.1U

R102 NC

I104

24LC21(DIP)

1 8
2 7
3 6
4 5

NC VCC
NC VCLK
NC SCL
GND SDA

Q102
2SK2158

Q103

2SK2158

C102 NC

L102

0 ohm/0805

R116 100

R114

4K7

R117 100

R123 100

SOG (3)

RIN+ (3)

RIN- (3)

GIN+ (3)

GIN- (3)

BIN+ (3)

BIN- (3)

VGA_CK (4)

RXD (4)

TXD (4)

5VD (3,4,6,8,10)

HS (3)
VS (3)

RX2- (3)

RX1+ (3)

RX1- (3)

RX2+ (3)

RX0+ (3)

RX0- (3)

RXC+ (3)

RXC- (3)

SDA_HDMI (3)

SCL_HDMI (3)

HPD_CAB (4)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

53

8.2. SCALER (MST5151A-LF)

Scalar

HDMI INPUT

PANEL INTERFACE

VGA INPUTY,Pb,Pr INPUTuP INTERFACE VIDEO INPUT

Scaler Power

+3.3AVDD for
AVDD_PLL

+3.3V for
VDD_MPLL

3.3V for
AVDD_PLL2
(51512)

+1.8V for VDDC

+3.3AVDD for
AVDD_ADC

+3.3AVDD for
AVDD_DVI

Note SMD bead limit current

pin49

SC_VDDC must be larger than 1.8V. If
doesn't, Panel won't light up.

+1.8V for 6151A
+2.5V for 6151

RD

PB+

SCL_HDMI

WR

AD0

VD3

RIN+

FSCLK+

RXE1-

VD5

RX2-

FSADDR3

FSADDR6

VD6

GIN+

SCL_HDMI

AD3

Y+

RX2+

RX0+

BIN+

VS

RD

ALE

RXC+

PR-

RX1+

RXE2+

FSADDR0

FSCKE

PR+

FSCLK+

PB-

FSADDR1

RXC

FSDQM1

SOY

PR+

RX1+

SDA_HDMI

AD1

FSADDR10

ADJ_PWM

ALE

SOY

PB+

FSADDR8

Y-

RX0+

FSDQM1

FSDQM0

INT

BIN-

RX2+

FSADDR2

RX1-

INT

RXE1+

AD2

WR

AD1

VD3

RXC-

FSDQM0

VD1

VD2

MUTE_AMP

VD7

RXEC+

VD2

VD0

RX0-

VD4

RX0-

RIN-

VD0

SDA_HDMI

GIN-

PR-

RXE3-

VD6

FSCKE

VLLC

SOG

FSADDR7

AD0

VD7

HS

FSADDR4

VD1

Y+

RX2-

VD4

RXE2-

RXEC-

RXE3+

AD3

RX1-

FSADDR5

PB-

Y-

AD2

RXC-

VD5

VLLC

SOG

VS

RIN-

GIN-

HS

BIN+
BIN-

GIN+

RIN+

HWRESET

RXE0

+

RXE0-

+3.3V
+2.5V

MVref

FSCLK-

FSCLK-

FSBKSEL1

/FSCAS

/FSWE

FSBKSEL0

/FSRAS

FSADDR11

FSDQS2U

FSDQS1U

FSDATAU18

FSDATAU16
FSDATAU17

FSDATAU19
FSDATAU20
FSDATAU21
FSDATAU22
FSDATAU23
FSDATAU24
FSDATAU25
FSDATAU26
FSDATAU27
FSDATAU28
FSDATAU29
FSDATAU30
FSDATAU31

FSDATAU15

FSDATAU14

FSDATAU13

FSDATAU12

FSDATAU11

FSDATAU10

FSDATAU9

FSDATAU8

FSDATAU7

FSDATAU6

FSDATAU5

FSDATAU4

FSDATAU3

FSDATAU2

FSDATAU1

FSDATAU0

MVref

FSADDR9

FSADDR11

FSADDR8

FSADDR0

FSADDR6

FSADDR2
FSADDR1

FSADDR10

FSADDR5

FSADDR7

FSADDR4
FSADDR3

FSADDR9

FSDQS3U

FSDQS0U

PW_DOWN

AUSD

AISD

SPDIFO

AUSCK

AUMUTE

AISCK

AIWS

AIMCK

AUWS

AUMCK

+VDD_MPLL

+AVDD_DVI +2.5MVDD

+VDDC+AVDD_PLL

+AVDD_DVI

+AVDD_ADC +3.3DV1

+AVDD_PLL2

+AVDD_PLL +3.3DV1

+2.5MVDD +VDDC

+AVDD_PLL2

+3.3V

+VDD_MPLL

+3.3VD

+3.3VD

+3.3VA

+AVDD_ADC+3.3VA

+3.3VA +AVDD_DVI

+3.3VD

+3.3VA

+3.3V

+2.5V

+3.3DV2

+3.3V +3.3DV2

5VD SC_VDDC

+APLL+VDDC

+2.5MVDD

SC_VDDC

+APLL

+3.3V

C438

0.1U

C427

10U

C437

0.1U

C431

0.1U

C419

30P

R430 75 ohm

C433

0.1U

C440

10U

C441

0.1U

R429 75 ohm

7531

8642

RP40
RP 0Rx4

C423

0.1U

C426

0.1U

C424

10U

7531

8642

RP52
RP 0Rx4

C445

0.1U

C453

0.1U

C448

0.1U

I403 AIC1084-ADJ

1

23

4

ADJ

VOUTVIN

TAB

C432

10U

C442

0.1U

C420 0.1U

X401

14.318MHZ

L401

220 ohm

L410

200/2A

C422

0.1U

L406

220 ohm

C446

0.1U

C421

10U

C418

0.1U

C449

0.1U

R439 100

L417

200/2A ohm

R440

10K

C472

10U

C471

0.1U

C417

30P

C434

10U

L409

200/2A

R420 0R

C469

0.1U

C450

0.1U

C454

0.1U

TP21

C435

0.1U

TP26

C429

0.1U

TP24

L404

220 ohm

TP23

I401

MST5151A-LF

207
208

2
3
5
6
8

9
11
14
15

18
19
20
21
22
23
24
25
26

27
28
29
30
31
32
33
36
37
38
39
40

51

53
54
55
56
57
58
59
60
61

67
68
69
70
71

727374

75 203

2021734

10

20466182

16286102

154

139121096379

156

131

195

185

158

201

200

171316355064

105

107

111

112

115

116

117

118

119

120

121

122

123

124

127

128

129

187
186
181
180
179
178
177
176
175
174
171
170
169
168
167
166
165
164
161
160

153
134
100
81

133

152
151
150
149
148
147
146
145
144
143
142
141
138
137
136
135

104

130

41
42
43
44
45
46
47
48

77

62

76
52

78

999897969594939291908988858483

82

106

101

188

189

190

191

192

193

196

197

198

199

49

125

113

173

4

658087

103

108

114

126

132

140

155

157

159

163

172

183

184

194

205

206

110

DVI_R+
DVI_R­DVI_G+
DVI_G­DVI_B+
DVI_B­DVI_CK+
DVI_CK­REXT
DDCD_DA
DDCD_CK

HSYNC1
VSYNC1
BIN1
BIN1M
SOGIN1
GIN1
GIN1M
RIN1
RIN1M

BIN0M
BIN0
GIN0M
GIN0
SOGIN0
RIN0M
RIN0
HSYNC0
VSYNC0
RMID
REFP
REFM

GPIO[5]/VHS

VI_CK
VI_DATA[0]
VI_DATA[1]
VI_DATA[2]
VI_DATA[3]
VI_DATA[4]
VI_DATA[5]
VI_DATA[6]
VI_DATA[7]

HWRESET
INT
ALE
RDZ
WRZ

DBUS[0]

DBUS[1]

DBUS[2]

DBUS[3] XIN

XOUT

AVDD_ADC

AVDD_ADC

AVDD_DVI

AVDD_MPLL

VDDP

VDDP

VDDP

VDDM

VDDM

VDDM

VDDM

AVDD_PLL

AVDD_PLL2

VDDC

VDDC

VDDC

VDDC

VDDC

VDDC

BYPASS

PWM1

PWM0

GND1

GND2

GND3

GND4

GND5

GND6

GND7

MCLKE

MCLK

BADR[0]

RASZ

CASZ

WEZ

MADR[0]

MADR[1]

MADR[2]

MADR[3]

MADR[4]

MADR[5]

MADR[6]

MADR[7]

MADR[8]

MADR[9]

MADR[10]

LVB0M

LVB0P

LVB1M

LVB1P

LVB2M

LVB2P
LVBCKM
LVBCKP

LVB3M

LVB3P

LVA0M

LVA0P

LVA1M

LVA1P

LVA2M

LVA2P
LVACKM
LVACKP

LVA3M

LVA3P

DQS[0]
DQS[1]
DQS[2]
DQS[3]

DQM[0]

MDATA[0]
MDATA[1]
MDATA[2]
MDATA[3]
MDATA[4]
MDATA[5]
MDATA[6]
MDATA[7]
MDATA[8]

MDATA[9]
MDATA[10]
MDATA[11]
MDATA[12]
MDATA[13]
MDATA[14]
MDATA[15]

MVREF

MADR[11]

VI_DATA[8]
VI_DATA[9]
VI_DATA[10]
VI_DATA[11]
VI_DATA[12]
VI_DATA[13]
VI_DATA[14]
VI_DATA[15]

GPIO[2]/VVS

VCTRL

GPIO[3]/VDE
GPIO[4]/VI_SCK

GPIO[1]/VFIELD

MDATA[16]

MDATA[17]

MDATA[18]

MDATA[19]

MDATA[20]

MDATA[21]

MDATA[22]

MDATA[23]

MDATA[24]

MDATA[25]

MDATA[26]

MDATA[27]

MDATA[28]

MDATA[29]

MDATA[30]

MDATA[31]

MCLKZ

DQM[1]

NCNCNCNCNCNCNCNCNC

NC

VDDC

VDDM

VDDM

VDDC

AVDD_DVI

GND8

GND9

GND10

GND11

GND12

GND13

GND14

GND15

GND16

GND17

GND18

GND19

GND20

GND21

GND22

GND23

GND24

GND25

GND26

BADR[1]

TP22

R433
1K

L414

BEAD 3.5x9x0.8

C428

0.1U

TP25

R434
1K

L415

BEAD 3.5x9x0.8

C455

0.1U

R401

392

1%

L408

200/2A ohm

C451

0.1U

R428

100 ohm

R419 0R

C443

0.1U

+

C470

1000uF/16V

R418

1M

C910

0.1U

C436

0.1U

L407

220 ohm /0805

C439

0.1U

L416

220 OHM 2A

C401 0.1U

C430

10U

L405

220 ohm

C425

0.1U

R432 75 ohm

C452

0.1U

C447

10U

C909

0.1U

TP20

R421 100

R427 240 ohm

R431 75 ohm

C444

0.1U

PB-(11)

RXEC- (8)

ADJ_PWM(10)

FSCLK+ (12)

SOY(11)

RXE0- (8)

AD[0..3](4)

RX1-(2)

RXE1+ (8)

PR-(11)

RXE1- (8)

RXE3- (8)

WR(4)

FSCKE (12)

RX2-(2)

PB+(11)

SCL_HDMI(2)

RXEC+ (8)

RX0-(2)

RD(4)

VLLC(5)

RXE3+ (8)

RXE0+ (8)

VD[0..7](5)

Y+(11)

SDA_HDMI(2)

RX0+(2)

FSDQM1 (12)

RXC-(2)

ALE(4)

Y-(11)

HWRESET(4)

RXC+(2)

RXE2- (8)

RX1+(2)

PR+(11)

RXE2+ (8)

RX2+(2)

MUTE_AMP(7)

GIN-(2)

GIN+(2)

SOG(2)

BIN-(2)

BIN+(2)

RIN-(2)

RIN+(2)

VS(2)

HS(2)

+3.3V(8,10)
+2.5V(10,12)

FSDQM0 (12)

INT(4)

FSCLK- (12)

FSBKSEL1 (12)

FSBKSEL0 (12)

FSRAS

FSCAS

FSWE

FSADDR[0..11](12)

FSDQS2 (12)

FSDQS1 (12)

FSDQS0 (12)

FSDATAU[0..31] (12)

+APLL

FSDQS3 (12)

PW_DOWN

AUSD (6)
AUSCK (6)
AUWS (6)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

54

8.3. MPU

MPU

Debug port

KEYPAD

Interface

I2C address A4

For HDCP encode
key storagy

TXD

PWR_G

RXD

TXD

PWR_R

AD1

AD0

MPU_RST

VGA_CK

RXD

IR_DAT

EA/VP

MSCL

INT

AD2
AD3

HPD_CAB

ON_PBACK

ON_PANEL

OSD_MN

ALE

MSDA OSD_DEC

OSD_INC

HWRESET

MSDA

MSCL

LED1

LED2

OSD_UP

LED1

IR_DAT

OSD_PW

OSD_UP

DN

LED2

IR_PW

OSD_DN

/STBY_S

5VD

AV_PW_ON

VTTRESET

OSD_DEC

OSD_EN

OSD_EN

INC OSD_INC

LED_R
LED_G

MENU OSD_MN

OSD_PW

RD
WR

OSD_MN

OSD_DN

TUNER_SEL

TUNER_SEL

IR_Int

DEC

PWRON

UP

ENTER

PWR_G

PWR_R

PW_EN

5VD

5VD

5VD

5VD

5VD

5VD

5VD

5VD

5VD

5VD

5VD

5VD 5VD5VD

5VD 5VD

R312 NC

R329

4.7K

L306

220 ohm

R330

4.7K

C306

20P

E

B

C

SOT

23

Q301
MMBT3904

1

3

2

C302

0.1U

C317

0.1U

7531

8642

RP30

RP4K7X4

C301

10U

L302

220 ohm

C305

20P

R301

10K

L310

220 ohm

R323

4.7K

R322

4.7K

C318

0.1U

I303

24LC04BT/SN//DIP

8

2 7

6

54

3

1

VCC

A1 WP

SCL

SDAGND

A2

A0

R313

470

D301

1N4148WS

1 2

7531

8642

RP32

RP4K7X4

R309

10K

R320 100

R319 100

P301

HEADER 14

1

2

3

4

5

6

7

8

9

10

11

12

13

14

R324 0

R314 4.7K

R326 0

R304 220

R310

10K

I301

80C51_PLCC

MPU

35

21

20

10

14
15
16
17

2
3
4
5
6
7
8
9

43
42
41
40
39
38
37
36

24
25
26
27
28
29
30
31

19
18
32
33
13
11

1

12

23
34

22 44

EA/VP

X1

X2

RESET

INT0/P3.2
INT1/P3.3
T0/P3.4
T1/P3.5

P1.0
P1.1
P1.2
P1.3
P1.4
P1.5
P1.6
P1.7

P0.0
P0.1
P0.2
P0.3
P0.4
P0.5
P0.6
P0.7

P2.0
P2.1
P2.2
P2.3
P2.4
P2.5
P2.6
P2.7

RD/P3.7
WR/P3.6

PSEN

ALE/P
TXD/P3.1
RXD/P3.0

P4.2
P4.3/ISP

P4.0
P4.1

GND VCC

R303

1M

L304

220 ohm

C309

100P

R317

470/180

C308

1000U/16V

E

B

C

SOT

23

Q302
MMBT3904

1

3

2

I302

24C32

1
2
3
4 5

6

7

8

A0
A1
A2
GND SDA

SCL

WP

VCC

L301

47ohm res 0805(220 for N2750w-2G)

C313

0.1U

R302 10K

L309

220 ohm

L303

220 ohm

L307

220 ohm

L308

220 ohm

7531

8642

RP31

RP4K7X4

R311 0

C314

0.1U

L305

220 ohm

R331

4.7K

R305 220

C310

0.1U

C307

0.1U

R308 0R

C315

0.1U

R318 4.7K

R327
NC

R316

10K

R328

NC

P302

SIP4

Debug Port

2.54mm/Male

1
2
3
4

R321

4.7K

C311

0.1U

C316

0.1U

R315

10K

C303

0.1U

X301
24MHZ

R325

10K

C312

0.1U

C304

0.1U

RD (3)
WR (3)

AD[0..3] (3)

INT(3)

ON_PANEL(8)
ON_PBACK(10)

HWRESET(3)

ALE(3)

MSCL (5,6,11)

TXD (2)
RXD (2)

MSDA (5,6,11)

VGA_CK(2)

PW_EN (10)
/STBY_S (6)

5VD(2,3,6,8,10)

AV_PW_ON(10)

VTTRESET(6)

MSCL (5,6,11)

MSDA (5,6,11)

SELVOUT1 (5)
SELVOUT2 (5)
SELVOUT3 (5)

HPD_CAB(2)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

55

8.4. SAA7117 VIDEO DECODER

Cut-off the power plane of
Crystal Parts Area

FOR SAA7117

04 SAA7117A

FOR SAA7117A

*Short these ground planes on PCB

Video Decoder
SAA7117

Power Line : +1-8V_PLL,+1-8V,+12V

Ground Plane : GND , GNDV

I2c Address Select:
R206 on: 42h
R207 on: 40h

MSCL
MSDA

TR

TG A32

TB

A24

A14

SCART_FSW_S

I2C_SEL

A41

A31

A11

A44

A32

A14

A13

A24

A21

A22

A42
A43

A22

A42

A33

A23

A13

A43

A33

A11

A21

A31

A41

A23

FSW_T

A44

VD5

VD2

VD1

VD6

VLLC

VD0

VD7

VD3
VD4

A12

LUM_IN

CHR_IN

A12

SCART_BLUE2

SWITCH_L
SWITCH_R

SCART_AV1

SCART_ALin1
SCART_ARin1

SCART_AV2_Y

SCART_ALin2
SCART_ARin2

SCART_AV

SCART_AV

SCART_BLUE1

SCART_GREEN1

VOUT1

SCART_GREEN2

SCART_RED2_C

VOUT1

AV_5V

VD1
VD2

VD0

VD3
VD4
VD5
VD6
VD7

VLLC

I2C_SEL

SAA_OUT

THS
TVS

SCART_FSW_S

MSCL

MSDA

SCART_RED1

VLLC (3)

+1-8V

+1-8V_VA+1-8V_VB

GNDV

+3-3V_VA

+3-3V_VB

+3-3V_VB

+1-8V_VB

GNDV GNDV

+3-3V_VB

+1-8V_VA

GNDVGNDV

+3-3V_S

GNDV

+3-3V_VB

GNDV

AV_5V

GNDV

GNDV

GNDVGNDV

GNDV GNDV

AV_5V

GNDV

AV_5V

AV_5V

GNDV

GNDV

GNDV

GNDV

+3-3V_S

AV_5V

+3-3V_VA

+3-3V_VB

GNDV

AV_5V

AV_5V

GNDV

GNDV

GNDV

GNDV

GNDV

GNDV

GNDV

GNDV

R247 27

R223

0

7531

8642

RP21 RP 33X4

C246 0.1U

I204

MM1501

5

4 3

2

16

GND

IN2 VCC

OUT

SWIN1

+

C210
47U/16V

+

C209
10U/16V

Q203

MMBT3906

1

23

C273 0.1U

C215

0.1U

Q205

MMBT3906

1

23

+

C205
10U/16V

R216 47

L207

0

R219 0

R226 0

R236

1K2

C232

0.1U

R209 33

C269

0.1U

C235

0.1U

R246 0

C271

NC

R213 47

C229 0.1U

C270

47P

C240

100P

CP20
CP 22PX4

8 176

5 4

3

2

+

C256

100U/16V

C206

0.1U

CP21
CP 22PX4

8 176

5 4

3

2

+

C263

100U/16V

C216

0.1U

C249

100P

C255

0.1U

C236

0.1U

R211

75

C266

0.1U

C234

0.1U

C248 0.1U

+

C204

47U/16V

C267
22U/16V

L204

R201/0805

C253 0.022U

R250

150

R229

6.8K

C245 0.1U

R248

150

C237 0.1U

R225
1k

C212

0.1U

R252
47

R208 33

+

C268

100U/16V

R221 0

R232
10k

I203

SAA7117

Video Decoder

455973

101

114

136

151506595106

132

142

3732332425161789

157

476388

104

129

137

153516796108

133

145

382820124335

154

156
155

44
66
68

27
29
31
34
30

19
21
23
26
22

11
13
15
18
14

2
5
7

10

6

139
138
135
134
131
130
128
127

147

76

143

87
89

113
112
111
110
109
107
105
103

102
100
99
98
97
94
93
92

39

152
148
149

144
141
140

126

86

77

52

158

146

150

90

91

71

85

69
70

46
48

64

83

49

43

62
61
60
58
57
56
55
54
53

84

747275

40

41

VDDD1

VDDD3

VDDD5

VDDD7

VDDD9

VDDD11

VDDD13

VDDD2

VDDD4

VDDD6

VDDD8

VDDD10

VDDD12

VDDA0

VDDA1

VDDA1A

VDDA2

VDDA2A

VDDA3

VDDA3A

VDDA4

VDDA4A

VXDD

VSSD1

VSSD3

VSSD5

VSSD7

VSSD9

VSSD11

VSSD13

VSSD2

VSSD4

VSSD6

VSSD8

VSSD10

VSSD12

VSSA0

VSSA1

VSSA2

VSSA3

VSSA4

AGND

AGNDA

VXSS

XTAL
XTALI

CE
SCL
SDA

AI11
AI12
AI13
AI14
AI1D

AI21
AI22
AI23
AI24
AI2D

AI31
AI32
AI33
AI34
AI3D

AI41
AI42
AI43
AI44
AI4D

XPD0
XPD1
XPD2
XPD3
XPD4
XPD5
XPD6
XPD7

TRSTN

AMXCLK

XCLK

IGP0
IGP1

HPD0
HPD1
HPD2
HPD3
HPD4
HPD5
HPD6
HPD7

IPD0
IPD1
IPD2
IPD3
IPD4
IPD5
IPD6
IPD7

AOUT

TDI
TCK
TMS

XDQ
XRH
XRV

XTRI

ITRI

ITRDY

TESTCLK$

XTOUT

XRDY

TDO

IGPV

IGPH

RTCO

IDQ

RTS0
RTS1

LLC

LLC2_54$

INT_A

FSW

RESON

GPIN$

ADTEST1$
ADTEST2$
ADTEST3$
ADTEST4$
ADTEST5$
ADTEST6$
ADTEST7$
ADTEST8$
ADTEST9$

ICLK

ASCLK

AMCLK

ALRCLK

VDDA_C18$

VDDA_A18$

1

2

3

I202

AP1117E-3.3V

SOT-223

3

214

R233
1k

C251

100P

L206

R201/0805

C233

0.1U

R212
75

Q201

MMBT3904

1

2 3

C238 0.1U

R249

150

C207

0.1U

C272 0.1U

R206
10K

R215 47

C222

0.1U

R244 0

R218 NC

C243 20P

R207 0

R238
470

C257 0.022U

R228
10k

L201

R201/0805

+

C231
47U/16V

C254 0.022U

C230 0.1U

R202

392

C252 0.022U

+

C219

10U/16V

C201

100P

C217

0.1U

C244
47P

Q202

MMBT3904

1

23

7531

8642

RP20 RP 33X4

C211

0.1U

C213

0.1U

X201

24.576MHZ

+

C202

10U/16V

L202

R201/0805

R239 680

C214

0.1U

ADJ

OUT

IN

I201

AIC117-1.8V/SOT223

3

214

C218

0.1U

C275
100P

R242
3K

R220 0

R210

75

D202
LL4148

1 2

C276
100P

R205

75

D201
LL4148

1 2

R203

75

C225

0.1U

R227
3K

+

C221

47U/16V

C224

0.1U

R231

NC(10k)

L205

NC

C227

0.1U

+

C259

100U/16V

R243 0

C277
100P

R241
3K

C223

0.1U

L203

R201/0805

+

C258

100U/16V

R214 47

C239 20P

C261 1U

C203

0.1U

R240

510

I205

PI5V330

11

2

6

15

3

7

10

1

5

9
12

4

8

16

14

13

S1C

S1A

S2B

/EN

S2A

DB

S2C

IN

S1B

DC
DD

DA

GND

VCC

S1D

S2D

R273

2.2K

R245 27

Q204
NC

1

2 3

C250

100P

R222 0

Q206

MMBT3904

1

2 3

R251
47

C242

100P

C260

0.1U

C241

100P

C247 0.1U

C265 1U

C274
100P

R201 27

C264 1U

C228

0.1U

R224

0

C262 1U

C208

0.1U

C278
100P

R234

68

R230

82

C220

0.1U

R235

75

R237
10K

C226

0.1U

R217 0

R204

75

VD[0..7](3)

VLLC(3)

AV_5V (6,10,11)

MSCL (4)

MSDA (4,6,11)

SCART_BLUE1(11)

SCART_GREEN1(11)

SCART_RED1(11)

SCART_BLUE2(11)

SCART_RED2_C(11)

SCART_GREEN2(11)

RCA_AV(11)

SCART_AV1(11)

SCART_ALin1(11)
SCART_ARin1(11)

SCART_AV2_Y(11)

SCART_ALin2(11)
SCART_ARin2(11)

TV_CVBS(11)

LUM_IN(11)

CHR_IN(11)

SWITCH_L (6)

SELVOUT3 (4)

SELVOUT2 (4)

SELVOUT1 (4)

SELVOUT2 (4)

SWITCH_R (6)

TG

TB

TR

FSW_T

SCART_FSW2(11)

SCART_FSW1(11)

THS
TVS

SAA_OUT

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

56

8.5. AUDIO DECODER

Audio Decoder

If ANA_IN2+ not use

8V FOR SCART AUDIO OUTPUT

AP1115AYLA ADJUSTABLE 12V CONVERT TO 8V.

THE CURRENT LOAD ABOUT 20mA. PRICE 2.0

Vout = Vref ( 1 + R1 / R2 )

Vref = 1.25V

If Vout = 8V , R1 = 650ȍ , R2 = 120ȍ
If Vout = 9V , R1 = 750ȍ , R2 = 120ȍ

MSDA
MSCL

AV-S_ALin
AV-S_ARin

PC_ARin

PC_ALin

/STBY_S

YUV_ARin

YUV_ALin

MSCL

TUN_SIF

SWITCH_L

PC_ARin

AV-S_ALin

AV-S_ARin

RSTN

YUV_ARin

SWITCH_R

YUV_ALin

TUN_SIF

MSDA

RSTN

PC_ALin

VTTRESET

TUN_SIF

+5V_A1

5VD

5VD

/STBY_S

AUDIO_L AMP

SWITCH_L

SWITCH_R

SCART1_OUT_R

SCART1_OUT_L

SCART1_OUT_L
SCART1_OUT_R

AUDIO_R_AMP

AUSCK
AUWS
AUSD

AUSD

AUWS

AUSCK

GND_APO

AV_5V

GND_API

5VD

5VD

GND_API

GND_API

GND_API

GND_API

GND_API

GND_APO

GND_API

GND_API

GND_API

GND_APO

GND_API

GND_API

12VD

GND_API

AGND AGNDAGND AGND AGND

5VD

5VD GND_APO

GND_APO GND_APO GND_APO GND_APO

GND_APO

GND_APO

GND_API

C628

3.3nF

C603 0.33U

C627

3.3nF

C604 0.33U

C626

8.2P

C605 0.33U

C623 NC

C607 0.33U

200 ohm 2A

L615

C608 0.33U

NC(200 ohm 2A)

L614

200 ohm 2A

L603

R654

NC

C629

47u/16V

C722
NC

C610 0.33U

C621 56P

C720

47uF/16V

+

C631

10u/16V

C698

3.3nF

C612 0.33U

C699

3.3nF

C614

0.1u

C622 56P

C620

0.1U

R656

680

1K

R602

R655

120

+

C617

10u/16V

C624 56P

R664 22

C606 0.1U

R665 22

MSP 44xxG
64Pin
PMQFP64

I601

MSP4410G-PLQFP64

49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64

123456789101112131415

16

17

18

19

20

21

22

24
23

25

26

27

28

29

30

31

32

333435363738394041424344454647

48

AVSUP
ANA_IN1+
ANA_IN­ANA_IN2+
TESTEN
XTAL_IN
XTAL_OUT
TP
AUD_CL_OUT
NC
NC
D_CTR_I/OUT1
D_CTR_I/OUT0
ADR_SEL
STANDBYQ
NC

I2C_CL

I2C_DA

I2S_CL

I2S_WS

I2S_DA_OUT

I2S_DA_IN1

ADR_DA

ADR_WS

ADR_CL

DVSUP

DVSS

I2S_DA_IN2NCNCNCRESETQ

DACA_R

DACA_L

VREF2

DACM_R

DACM_L

DACM_C

DACM_S

DACM_SUB

SC2_OUT_R

SC2_OUT_L

VREF1

SC1_OUT_R

SC1_OUT_L

CAPL_A

AHVSUP

CAPL_M

AHVSS

AGNDC

SC4_IN_L

SC4_IN_R

ASG

SC3_IN_L

SC3_IN_R

ASG

SC2_IN_L

SC2_IN_R

ASG

SC1_IN_L

SC1_IN_R

VREFTOP

MONO_IN

AVSS

R666 22

C600
20P

C700
20P

C701

20P

R650

12K

R648

100

R647

3.9K

L616
1uH

INDUCTOR

L617
1uH

INDUCTOR

R649

470

220 ohmL602

+

C613

10u/16V

C691

3.9n

C690

680p

C688

220p

R646
330

C692

470p

Q601
MMBT3904

C693

10nF

C689

390p

+

C619

10u/16V

X601

18.432MHz

+

C615

10u/16V

L618 10uH/0805

+

C618
10u/16V

R606

2K2

C616

0.1u

C611 0.33U

L619 10uH/0805

4K7R605

C630

0.1U

100R652

R604 0

C719

47uF/16V

R645

NC

C721
NC

R603 0

R653

NC

+

C609

10u/16V

adjout in

I604

AP1115A

3

2

1

C625

8.2P

C602 0.33U

MSCL(4)

MSDA(4,5,11)

/STBY_S(4)

AV-S_ALin(9)
AV-S_ARin(9)

PC_ALin(9)
PC_ARin(9)

YUV_ARin(9)

YUV_ALin(9)

AUDIO_L AMP (7)

TUN_MONO(11)

AUDIO_L_Lineout (9)

VTTRESET (4)

AUDIO_R_Lineout (9)

5VD(2,3,4,8,10)

TUN_SIF(11)

SWITCH_L(5)

SWITCH_R(5)

AUDIO_OUT_L (11)

AUDIO_OUT_R (11) AUDIO_R AMP (7)

AUSD(3)
AUSCK(3)
AUWS(3)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

57

8.6. AUDIO AMP

12VD

SP_L_OUTN

SP_R_OUTN

SP_L_OUTP

SP_R_OUTP

AMPPVCC

AMPPVCC

AMPPVCC

AMPPVCC

12VD

AGND

AGND

AGND

GND_APO

GND_APO

GND

GND

GND

GND

GND

GND GND

GND

GND

GNDGND

AGND AGND

AGND

GND

GND

GND

R630 10K

R662

1K

L610

40uH

R644

10K

C658

0.1U

C687

10uF/16V

R631 NC

R661
10K

C682

1u/50V

C666

NC

R639
1K

C681

1u/16V 0603

C683

1u/50V

P603

CON_2.54mm_4

123

4

R636
120K

R663

1K

C680

1u/16V 0603

C685

10uF/16V

C679
10u/16V

C660

0.1/1206

Q604

MMBT3904

1

2 3

C686

1u/16V 0603

R638

75

R640

NC(1K)

R641

NC(1K)

C664

0.1U

L613

40uH

L609
40 uH

P604
AUDIO O/P

L611

40uH

R642
1K

R633
NC

Q605

MMBT3904

1

2 3

C667

0.1/1206

R627
NC/0805

D602

1N5406

12

C656 1U

R651
NC/0805

C661

0.1U

C672

0.1/1206

C151
330P

C697

10nf

C150
330P

C694

10nf

R660
75

C696

10nf

C684

0.1U

C678 0.01U/0805

R643
10K

C695

10nf

L620

80/0805

C677

0.1/1206

C657 1U

C668 0.01U/0805

C655 1U

C670

0.1U

I602

TPA3002D2

1

2

3

4

5

6

7

8
9

10

11

12

13
14
15
16
17

18
19

20
21

24

22
23

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

SDZ

R_INN

R_INP

V2P5

L_INP

L_INN

AVDDref

Vref
VARDIFF
VARMAX

VOL

REFGND

BSLN
PVCCL
PVCCL

L_OUTN
L_OUTN

PGNDL
PGNDL

L_OUTP
L_OUTP

BSLP

PVCCL
PVCCL

VCLAMPL

AGND

ROSC

COSC

AVDD

AGND

VAROUTL

VAROUTR

AVCC

MODE

MODEB

VCLAMPR

BSRP

PVCCR

PVCCR

R_OUTP

R_OUTP

PGNDR

PGNDR

R_OUTN

R_OUTN

PVCCR

PVCCR

BSRN

C669 0.01U/0805

+

C653
470uF/16V

C654 0.01U/0805

C662 1U

C671

10u/16V

C663 1U

D601

1N5406

12

R634
10K

C674

0.1U

C652

0.1U

R637

4.7K

R629 12K

L612

40uH

R635
NC/0805

R626 NC

C673 220P

R628 NC C665

10u/16V

C675

10u/16V

C651

0.1U

C676

NC

C659

10u/16V

Q602

NC(MMBT3904)

1

2 3

R632
39K

Q603

NC(MMBT3904)

1

2 3

AUDIO_L AMP(6)

AUDIO_R AMP(6)

MUTE_AMP(3)

12VD (6,8,10)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

58

8.7. PANEL Interface

Note L411,L412, L413 bead limit current

ROTATION

LOW COLOR SHIFT. ON

PAL 50Hz

RXEC­RXEC+
RXE3-

RXE0-

RXE2+

RXE1+

RXE1-

RXE0+

RXE2-

RXE3+

ON_PANEL

12VD

5VD

+3.3V

RXE0­RXE1­RXE2- RXE2+
RXEC- RXEC+
RXE3- RXE3+

RXE0+
RXE1+

+3.3V

12VD

5VD

+PANELVCC

5VD

+PANELVCC

5VD 5VD

I404

Si9435

1
2
3
4

8
7
6
5

S
S
S
G

D
D
D
D

R438

0R

R437

NC

C460

0.1U

C457

10U

C456

0.1U

C461

0.1U

P401

CONN DUAL 15

1
3
5
7
9

11
13
15
17
19
21
23
25
27
29

2
4
6
8
10
12
14
16
18
20
22
24
26
28
30

1
3
5
7
9
11
13
15
17
19
21
23
25
27
29

2
4
6

8
10
12
14
16
18
20
22
24
26
28
30

C459

1000P

E

B

C

SOT

23

Q401

MMBT3904

1

3

2

+

C458

470U

C462

0.1U

L411

NC

R436

0R

R435

NC

R426

100K

L412

80 OHM 6A 0805

R425

1K

R423
NC

R422
4K7

R424
10K

L413

NC

RXE3+(3)

RXE0+(3)

RXE2+(3)

RXE1-(3)

RXE2-(3)

RXE3-(3)

RXE0-(3)

RXEC-(3)

RXE1+(3)

RXEC+(3)

ON_PANEL(4)

12VD(6,7,10)

5VD(2,3,4,6,10)

+3.3V(3,10)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

59

8.8. AUDIO Interface

AUDIO-OUT

AV

YUV-Audio-L

YUV-Audio-R

YCbCr

AV1-AudioR

AV1-AudioL

PC-Audio-IN

EARPHONE

AUDIO_OUT_L_RCA

AUDIO_OUT_L_RCA

AUDIO_OUT_R_RCA

AUDIO_R_Lineout

AUDIO_L_Lineout

AUDIO_OUT_R2

AUDIO_OUT_R_RCA

AUDIO_OUT_L2

AGND

AGNDAGND

AGND

AGND

AGND AGND

AGND

AGND

AGND

GND_APO

GND_APO

GND_APO

GND_APO

AGND

AGND AGND

AGND AGND

L608

220 ohm

R624

8.2k

R625

10k

C649
100p

C648
100p

C647

100p

C650
100p

R619

1k

L607
220 ohm

R622

8.2k

R623

10k

C643

47uF/16V

R620 0

C645

47uF/16V

L604

220 ohm

R608

2.2K

R610

10K

R613

10k

R612

2.2K

L605

220 ohm

R617

10k

R611

NC

R616

2.2K

C636
NC

L606

220 ohm

R609 0

C635
100p

C633

47uF/16V

P601
RCA JACK

1

2

3

4

5

6

7

8

9

C601
100p

C641
100p

C640
1n

C634
100p

C639

47uF/16V

C637
100p

C638
100p

C632
100p

C642
100p

L601

220 ohm

R607

10K

R601

2.2K

R615

1k

P602

AUDIO_JACK

1

4
5

2

3

R614 0

C644
1n

R618 0

R621

NC

C646
NC

AUDIO_L_Lineout(6)

AUDIO_R_Lineout(6)

AV-S_ALin (6)

AV-S_ARin (6)

YUV_ALin (6)

YUV_ARin (6)

AUDIO_OUT_R2 (11)

PC_ALin (6)

PC_ARin (6)

AUDIO_OUT_L2 (11)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

60

8.9. DC to DC

1

23

2 or 4

TO-263

GND

Vout

Vin

Vout

SOT-223

1

2

3

BCE

+2.5V

+3.3V

SOT23

Inverter Connector

+3.3V

12VD
5VD
AV_5V
AV_3V3
+3.3V
+2.5V

24_PW_EN

BACK_ON/OFF

E_PWM

24_PW_EN

BACK_ON/OFF

E_PWM

+3.3V

5VD

5VD

5VD

+2.5V

5VD

5VD

12VD

5VD

5VD

AV_5V

V33

Q904

MMBT3904 NC

1

2 3

C927

1U

E

B

C

SOT

23

Q902

MMBT3904

1

3

2

C918

0.1U

R909
1K

+

C931

10U/16V

C908

0.1U

R908
100K

E

B

C

SOT

23

Q901

MMBT3904

1

3

2

ADJ

OUT

IN

I903

AP1117-ADJ

SOT223

+2.5V Regulator

3

2

1

4

R904

100

R905

100

R912
1K

C917

1000U/16V

+

C905

100U/16V

R911
10K

C930

NC

R907

4K7

OUT

ADJ

IN

I902

AP1084N-3.3

+3.3V Regulator TO-263

3

2

1

4

E

B

C

SOT

23

Q903

MMBT3904

1

3

2

R910

4K7

C912

0.1U

C906

0.1U

R902
10K

+

C907

100U/16V

C367

0.1U

L155

R201/0805

+

C365
100U/16V

R903

1K

L903

BEAD 3.5x9x0.8

+

C903

1000uF/16V/LowESR

P902

CON_ 2.5mm_12

1
2
3
4
5
6
7
8
9
10
11
12

C922

0.1U

R913 0

C913

1000uf/16V/LOWESR

L907

40UH

C915

0.1U

C902

0.1U

R914 0

C929

470u/16V/LOWESR

I901

AP9435M

1 8

2 7

3 6

4 5

SD

SD

SD

GD

C914

0.1U

R901

4K7

R906

10K

+

C928

1000uF/16V/LowESR

PW_EN(4)

ON_PBACK(4)

ADJ_PWM(3)

12VD (6,7,8)
5VD (2,3,4,6,8)
AV_5V (5,6,11)
AV_3V3
+3.3V (3,8)
+2.5V (3,12)

AV_PW_ON(4)

V33 (2)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

61

8.10. TUNER/AV/SCART Interface

S-Video

SCALAR SIDE

Pr

Pb

AV1-CVBS

Y

SCALAR SIDE

CVBS OUT

Switch

Audio L-Out

Blue I/O

Blanking I/O

Audio R-Input

Green I/O

Audio L-Input

CVBS INPUT

Red I/O

Audio R-Out

TUNER

CVBS OUT

Blanking I/O

Green I/O

CVBS INPUT

Red I/O

BLUE I/O

scart pin8 off 0v ~ 2v

4:3 9.5v ~ 12v
16:9 4.5v ~ 7v

===================

scart pin16 composite 0v ~ 0.4v

scart pin16 R.G.B 1v ~ 3v

S_LUMS_Y

S_C

S_CHR

AV_5V

Pr_IN

PB+

RCA_AV

Y-

PR+

PR-

Y+

PB-

AV_IN

SOY

Y_IN

Pb_IN

SCART_CVBS_OUT

SCART_ALin1

SCART_BLUE1

SCART_FSW1

SCART_ARin1

MSCL
MSDA

TV_CVBS

TUN_MONO

TUN_SIF

AUDIO_OUT_L

AUDIO_OUT_R

SCART_ARin2

SCART_ALin2

FS_SC1

FS_SC2

TV_CVBS

SCART_BLUE2

SCART_GREEN2

SCART_GREEN1

SCART_RED1

SCART_RED2_C

SCART_AV2_Y

SCART_AV1

SCART_FSW2

SCART2_CVBS_OUT

SCART2_CVBS_OUT

AGND AGND

AGND GND

AGND

AGND

AGND

AGNDAGND

AGND

AGND

AV_5V

AV_5V

AGND

AGND AGNDAGNDAGNDAGND

AGND

AGND

AGND

AGND AGND

AGND

AGND

AGND

AGND

AGND

AGND

AGND

AGND

AGND

AGND

AGND

AV_5V AV_5V

AGND

C536
100p

L504

220 ohm

C535

100p

C515

22p

R538 0

C520 10nf

L508

220 ohm

R539 0

L511

220 ohm

C539

47P

R509 47

L501
220 ohm

D513

10p

C521 47nf

R502 47

P502
RCA JACK

1

2

3

4

5

6

R525 2.2K

R557
75

C518

NC

R561
75 0805

R558

75

R546

4.7K

C508 47nf

R529

4.7K

R547

1.3K

D504

10p

R532

1.3K

D519

10p

C537

100p

D506

10p

C555

47P

L515
220

C523

1000P

R552
75 0805

C558
22U/16V

R533
75R

R551

3.3K

C556

100U/16V

R505 47

R550

3.3K
Q502

MMBT3904

1

2 3

P504

SIP4

2.54mm/Male

1
2
3
4

C561

NC(100U/16V)

C560

10P/ESD

R503 47

C553

10P/ESD

C559

NC(100U/16V)

R514
75

Q501

MMBT3904

1

2 3

R559

3.3K

L507
40uH

C550

100U/16V

R560

3.3K

R51033

C552
22U/16V

R563
NC

R549

1K

L514
220

R562 0

R548

1K

C551

0.1U

C557

0.1U

C549

1000P

R553 0

R504 100

C548

1000P

C540

47P

R530

1K

C513

0.1U

D523

10p

R526

10K

C541

47P

D525

10p

D508

10p

R515
3K

D524

10p

L503

220 ohm

D507

10p

R564
75

R544 2.2K

R513 47

P501

S_TERMINAL

81

6 2

5/3

R545

10K

C538
100p

P505

SIP4

2.54mm/Male

1

2

3

4

C546

100p

D526

10p

C524

0.1U

C519

NC

L513
220 ohm

L502

220 ohm

C547
100p

D520

10p

R506

75

L505

220 ohm

R528

10K

R555
75

R542 2.2K

C554

47p

C544

100p

C511

10P

L512
220 ohm

R507

75

R543

10K

D521

10p

C545
100p

C522
47u/16V

C509

22p

C525

1500u/16V

R531

1K

C512

10P

R527 2.2K

R5110

R508

75

D511

10p

C507 1000P

D522

10p

R519
75

R512 47

C504 47nf

C543

1000P

P503

SCART Connector 1

2

4

6

8

10

12

14

16

18

20

1

3

5

7

9

11

13

15

17

19

21

R554
NC

C506

22p

L506 40uH

L510
220 ohm

C510

10P

C514

1500u/16V

C516 47nf

R536 0

C503 47nf

P506

SCART Connector 2

2

4

6

8

10

12

14

16

18

20

1

3

5

7

9

11

13

15

17

19

21

R534 0

R556

75

C542

1000P

R537 0

I501

Tuner FQ1216MK3

1
2
3

11
12
13
1418

15
16
17

4
5
6

9
10

NC/AGC

NC/Monitor

VCC

SIF

CVBS
VCC-IF
AF O/PCHASSIS

CHASSIS
CHASSIS
CHASSIS

SCL
SDA

AS

NC
NC

C517 47nf

R535 0

R50133

LUM_IN (5)

CHR_IN (5)

AV_5V(5,6,10)

PR- (3)

PB+ (3)

PB- (3)

Y- (3)

SOY (3)

Y+ (3)

PR+ (3)

RCA_AV (5)

SCART_FSW1 (5)

SCART_GREEN1 (5)

SCART_AV1 (5)

SCART_RED1 (5)

SCART_BLUE1 (5)

MSDA (4,5,6)

MSCL (4)

TUN_SIF (6)

TV_CVBS (5)

TUN_MONO (6)

AUDIO_OUT_L (6)

AUDIO_OUT_R (6)

AUDIO_OUT_R2 (9)

AUDIO_OUT_L2 (9)

FS_SC2

SCART_ARin1 (5)

SCART_ALin1 (5)

FS_SC1

SCART_ARin2 (5)
SCART_ALin2 (5)

SCART_BLUE2 (5)

SCART_GREEN2 (5)

SCART_RED2_C (5)

SCART_AV2_Y (5)

SAA_OUT

SCART_FSW2 (5)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

62

8.11. SDRAM

Place this parallel termination close to

corresponding memory IC Pins

Near The DDR-SDRAM IC

layout

ױאࠉທ ႉࠐᓳᒵ

Near The DDR-SDRAM IC

Near The
DDR-SDRAM IC
Stub as short as
possible.

Near The DDR-SDRAM IC

H/W
Swamp

H/W
Swamp

FSDATAU9

FSDATAU25

FSDATAU18

FSBKSEL1

/FSCAS

FSDQM01

/FSWE

FSDATAU14

FSDQS3

FSDATA5

FSDATA25

FSDATAU23

FSDATAU31

FSDATAU30

FSDATAU3

FSCLK+

FSDATAU4

FSDQM10

FSCLK-

FSDATA6

FSDATA18

FSDATAU22

FSDATA30

FSADDR10

FSDATA28

FSDATAU2

FSDATA8

FSDATAU28

FSDATAU11

FSDATA9

FSDATA12

FSDATA27

FSDATA23

FSDATA29

FSDATA13

FSDATAU7

FSADDR1

FSDATAU20

FSDQS2

FSDQM11

FSADDR8

FSADDR4

FSDATA22

FSDATA7

FSCKE

FSDATA26

FSDQS1

FSDATA19

FSDATAU0

FSDATAU13

FSADDR6

FSDQM00

FSDATA24

FSDATA17

FSDATAU8

FSDQS0

FSDATAU26

FSCLK-

FSDATAU15

FSDATAU16

FSADDR0

FSADDR9

FSDATA3

FSDATA20

FSDATAU5

FSDATA2

FSDATAU10

FSCLK+

FSADDR7

FSDATAU29

FSDATA31

FSDATAU12

FSDQM1

FSVREF

FSDATA1

FSDATAU6

FSDQM0

FSDATA15

FSDATAU19

FSADDR3

FSADDR5

FSDATAU27

FSDATA0

FSDATA10
FSDATA11

/FSRAS

FSDATA4

FSDATA21

FSDATAU21

FSDATAU17

FSADDR2

FSADDR11

FSDATAU1

FSBKSEL0

FSDATA14

FSDATA16

FSDATAU24

FSDATA18

FSDATA13

FSDATA31

FSDATA26

FSDATA29

FSDATA12

FSDATA7

FSDATA21

FSDATA20

FSDATAU[0..31]

FSDATA22

FSDATA3

FSDATA19

FSDATA6

FSDATA25

FSDATA11

FSDATAU6

FSDATA2

FSDATA24

FSDATA10

FSDATAU21

FSDATA9

FSDATA1

FSDATA27

FSDATA[0..31]

FSDATA23

FSDATAU5

FSDATAU3

FSDATAU20

FSDATA17

FSDATA15

FSDATA28

FSDATA5

FSDATA0

FSDATA16

FSDATA8

FSDATA30

FSDATA4

FSDATA14

FSDATAU28
FSDATAU29
FSDATAU30
FSDATAU31

FSDATAU27

FSDATAU26

FSDATAU25

FSDATAU24

FSDATAU23

FSDATAU22

FSDATAU19

FSDATAU18

FSDATAU17

FSDATAU16

FSDATAU15

FSDATAU14

FSDATAU13

FSDATAU12

FSDATAU11

FSDATAU10

FSDATAU9

FSDATAU8

FSDATAU7

FSDATAU4

FSDATAU2

FSDATAU1

FSDATAU0

FSVREF

+2.5V_DMC

+2.5V_DMC

FSVREF

+2.5V

+2.5V +2.5V_DMC

GND

+2.5V_DMQ

+2.5V_DMQ

GND

GND

+2.5V_DMQ

GND

GND

GND

GND

+2.5V_DMQ

L402

220 ohm /0805

C404

0.1U

7531

8642

RP41 RP75x4

7531

8642

RP42 RP75x4

7531

8642

RP43 RP75x4

L403

220 ohm /0805

7531

8642

RP44 RP75x4

7531

8642

RP45 RP75x4

C464

0.1U

7531

8642

RP47 RP75x4

R408

150 ohm

5%

R404 100 ohm/R0603

7531

8642

RP49 RP75x4

R402

1K ohm

C468

0.1U

7531

8642

RP48 RP75x4

R406 100 ohm/R0603

R412 100 ohm/R0603

C463

10U

R414

1K ohm

R410 100 ohm/R0603

C465

0.1U

C466

0.1U

C409

0.1U

C405

0.1U

C406

0.1U

C407

0.1U

C408

0.1U

C467

0.1U

C414

0.1U

C411

0.1U

C410

0.1U

C413

0.1U

C412

0.1U

C402

10U

C403

0.1U

I402

NT5DS4M32EG-5

N5
N6
M6
N7
N8
M9

N9
N10
N11

M8

L6

M7

B7
C6
B6
B5
C2
D3
D2
E2

K13
K12
J13
J12
G13
G12
F13
F12

F3
F2
G3
G2
J3
J2
K2
K3

E13
D13
D12
C13
B10
B9
C9
B8

B2

H13

H2
B13

B3

H12

H3
B12

N4

M5

M11

M12

N12

N2

M2

L2
L3

N13

D7D8E4

E11L4L7L8L11

C3C5C7C8C10

C12E3E12F4F11G4G11J4J11K4K11

E5E7E8

E10F6F7F8F9G6G7G8G9H6H7H8H9J6J7J8J9K6K7K8K9L5L10

B4
B11
D4
D5
D6
D9
D10
D11
E6
E9
F5
F10
G5
G10
H5
H10
J5
J10
K5
K10

C4
C11

H4
H11

L9

L12
L13

M3

M4

M10
M13

N3

A0
A1
A2
A3
A4
A5
A6
A7
A8/AP
A9
A10
A11

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7

DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15

DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23

DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31

DQS0
DQS1
DQS2
DQS3

DM0
DM1
DM2
DM3

BA0
BA1

CK

CK

CKE
CS
RAS
CAS
WE

VREF

VDD

VDD

VDD

VDD

VDD

VDD

VDD

VDD

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VDDQ

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ
VSSQ

NC
NC
NC
NC

RFU1

NC
NC
NC
NC

RFU2
MCL

NC

FSDQM0(3)

FSCLK-(3)

FSDQS3(3)

FSDQM1(3)

FSBKSEL0(3)

FSDATAU[0..31](3)

FSCLK+(3)

FSBKSEL1(3)

FSCKE(3)

FSADDR[0..11](3)

FSDQS0(3)
FSDQS2(3)
FSDQS1(3)

/FSCAS

/FSWE

/FSRAS

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

63

8.12. IR & KEY PAD

VOL­DEC

VOL+
INC

MENU DOWN UP OK

POWER

IR

LED

5VD

LED_G

IR_IN

KEY1_OK
KEY2_UP

KEY5_DEC

KEY0_MENU

KEY3_DOWN
KEY4_INC

LED_R

PWRON

GND

GND

GND

GND

I711
CAM-1538TP5

123

VOUT

GND

VCC

P711

CON6_2mm

1
2
3
4
5
6

P701

CON7_2mm

1
2
3
4
5
6
7

D711

S701

S707S706S704S703S702S705

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

64

9.1. MAIN PCB TOP VIEW

ViewSonic C orporation Confidential - Do Not Copy N2750w-2G

65

9. PCB Layout Diagrams

9.2. MAIN PCB BOTTOM VIEW

ViewSonic C orporation Confidential - Do Not Copy N2750w-2G

66

9.3. CON PCB TOP VIEW

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

67

9.4. CON PCB BOTTOM VIEW

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

68

9.5. IR PCB TOP VIEW

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

69

9.6. IR PCB BOTTOM VIEW

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

70

10. Exploded View And Exploded Parts List

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

71

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

72

ViewSonic Model Number: VS11404-1G
Rev: 1a

Serial No. Prefix: QBS

Item ViewSonic P/N Ref. P/N Q'ty

1 N/A 2024268006P FRONT BEZEL JC278UB ABS94HB BLACK/PS-7604B 1
2

N

/A 2033150600P IR COVER JC278UB PC LIMPID 476C 1

3

N

/A 2044266901P FUNCTION KEY JC278UB ABS 94V0 AL-PLATE PWR 1
4 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 1
5

N

/A 2071977901P METAL FITTG JC278XX65E SECC 1.0T PANEL 1
6

N

/A 2080005200P SCREW,SPE M3*3 TYPEI FOR HS PANEL HI 9
7 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 1
8 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 8
9

N

/A 2072051702P METAL FITTG-I/O JC278XX65E SECC 0.8T IO-MAIN H_SWITCH 1

10

N

/A 2082340082P SCREW,CSK+ SCREW CSK+ M4x8 4

11

N

/A 2083730108P SCREW,BND T+ M3*10 T24 F NI 2

12

N

/A 2083630068P SCREW FMS+ M3X6,M,S-TITE,F,NI 1

13

N

/A 2072051801P METAL FITTG-I/O JC278XX65E SECC 0.8T IO-SIDE (E) HDMI 1

14 N/A 2082340082P SCREW,CSK+ SCREW CSK+ M4x8 3
15

N

/A 2027264001P DUST COVER JC278XX65E ABS94HB BLACK_C (E) HDMI 1

16

N

/A 2083730108P SCREW,BND T+ M3*10 T24 F NI 1

17

N

/A 2083630068P SCREW FMS+ M3X6,M,S-TITE,F,NI 2

18

N

/A 2027263202P DUST COVER

N

2751W ABS94HB BLACK C FUN-KEY 1

19

N

/A 2044266601P FUNCTION KEY JC278 ABS 94V0 AL-PLATE FUNCTI 1

20 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 2
21 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 3
22

N

/A 2080040062P SCREW,SPE M4*8 PMS-3/W 1

23

N

/A 2071675800P SHIELD PLATE JC278XXXXUA SECC T=0.8MM SHIELD COVER 1

24

N

/A 2082340082P SCREW,CSK+ SCREW CSK+ M4x8 11

25

N

/A 2071879400P BRACKET,FIX JC278XXXXUA SECC T=1.6MM SUPPORT 1

26

N

/A 2082340082P SCREW,CSK+ SCREW CSK+ M4x8 2

27

N

/A 2071879500P BRACKET,FIX JC278XXXXUA SECC T=0.8MM SUPPORT-SP

K

1
28 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 2
29 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 6
30

N

/A 2080007100P SCREW,SPE M3x6mm,M,I,NI (9.35mm) 4

31 C-00008126 2022266403P CABI BAC

K

JC278XX65E ABS94HB BLACK C 1

32

N

/A 2082340102P SCREW,CSK+ SCREW F M4X10 (CSK+) 8

33

N

/A 2027263302P DUST COVER

N

2751W ABS94HB BLACK C SIDE 1

34

N

/A 2027263402P DUST COVER

N

2751W ABS94HB BLACK C DOWN 1

35

N

/A 2071871700P BRACKET,FIX JC278UB ALUMINUM PS-7604B ARM 1
36 N/A 2039802304P FOOT PAD CRφ16.5X7.3/BLACK 6
37

N

/A 2082750402P SCREW,BND+ M5X40,M,P,ZN-CC 4
38 PL-00003417 2028258801P STAND JC278UB ABS 94HB PS-7604B 1
39

N

/A 2071878800P BRACKET,FIX JC278UB SECC T=2.0MM STAND 1
40

N

/A 2054256201P ORNAMENT JC278UB BASE PLATE LEFT 1
41

N

/A 2054256301P ORNAMENT JC278UB BASE PLATE RIGHT 1
42

N

/A 2082340102P SCREW,CSK+ SCREW F M4X10 (CSK+) 4
43 M-SCW-0824-0123 2084740102P SCREW,BND T+ M4X10(BND T+) 8
44

N

/A 2427430028P WIRE HARNESS 30/30P H/H L=150mm 1
45

N

/A 2427412007P WIRE HARNESS 12/10P H/H L=390mm 1
46

N

/A 2427404016P WIRE HARNESS 4/2+2P H/A 1007#24 L=610mm 1
47

N

/A 2427414012P WIRE HARNESS 14/6+7P H/H L=610mm 1
48

N

/A 2391307081P SPEAKER ASS'Y 7W/8ohm L228*W60*H76mm J.G 2

Description

EXPLODED PARTS LIST (N2750w-2G)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

73

Serial No. Prefix: QBS Rev: 1a

Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number#

1

Remote Control A-00004438 2419200047P H901

2 Power Cord - (China wall 1.83M BLACK ROHS) A-00006132 2427130097P P951
3 Power Supply Board (FSP212-3F01(J051)SPI B-00005504 2200227028P U801
4 Main Board B-00008098 6201-7027146321
5 Control Board B-00008099 6202-7027136501
6 Sub Board (IR Board) B-00008100 6206-7027446591
7 Back Cover C-00008126 2022266403P 2C01
8 Front Panel PS-7604B C-00008127 2603308042

9 Cable RCA 3P(Y/R/W) 2562#26 1.8M BLK CB-00003425 2427701893P P954
10 Cable - RG59U (M/F) L=1.83M CB-00008036 2427751802P P952
11 Video Cable-Cable ,D15/D15 20276(3+6) 1.83M Black A-VC-0101-0386 2427501187P P961
12 User's Guide China DC-00008111 2001131610P 6P80
13 Quick Start Guide DC-00008112 2002310592P 6P81
14

Electronic

LCD Panel - V270B1-L01 (A) WXGA CMO E-00005508 2212008800P V901

15 Box B (360X220X50mm) P-00004497 2011100017P 6P85
16 Foam - EPE UP (Left) P-00005510 2012177501P 6P20
17 Foam - EPE UP ( Right) P-00005511 2012177601P 6P21
18 Craft Box P-00008113 2011127035P 6P01
19 Foam - EPE (Down) P-00008114 2012180002P 6P22
20 PolyBag HDPE P-00008115 2013054003P 6P60
21 Generic Foam Set P-00002919 30291
22 Generic Box P-00002920 21901
23

Plastics: [All Covers: Dust, Cable, Hinge covers]

Pedestal (Stand) PL-00003417 2028258801P 5B04

Remark 1:

Above listed items are examples, supplier can expand the rows to add more necessary items.

Remark 2:

RECOMMENDED SPARE PARTS LIST (N2750w-2G)

Description

Accessories: [Adapter, Remote Control]

PC Board Assembly: [All PCBA]

Packing Material:

[Box, Foam]

ViewSonic Model Number: VS11404-1G

All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic
Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.

Cabinets:

[Front Panel, Back Cover, Base]

Cables: [All Cables]

Documentation: [Quick Start Guide, CD Rom]

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

74

11. Recommended Spare Parts List

Rev: 1a

Serial No. Prefix: QBS

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'ty

1 PL-00003417 Active 2028258801P STAND JC278UB ABS 94HB PS-7604B 5B04 1
2 P-00008114 Active 2012180002P POLYFOAM JC278UB&EC 65E EPE DOWN 6P22 1
3 P-00008113 Active 2011127035P CARTON BOX VIEWSONIC N2750W-2G VS11404-1G 6P01 1
4 P-00008064 Active 2013228807P POLYETHY BAG 200X350X0.03T mm LDPE B5 6P86 1
5 P-00005511 Active 2012177601P POLYFOAM NEW JC278AA EPE UP (R) 6P21 1
6 P-00005510 Active 2012177501P POLYFOAM NEW JC278AA EPE UP (L) 6P20 1
7 P-00004497 Active 2011100017P CARTON BOX 360X220X50mm (WXDXH) BOX(B) 6P85 1
8 N/A N/A 2340722008P CAP,ARRAY P=0.8 85'C 1206Y5V 22.000PF 16V M 8P CP20 1

9 N/A N/A 2340722008P CAP,ARRAY P=0.8 85'C 1206Y5V 22.000PF 16V M 8P CP21 1
10 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C103 1
11 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C105 1
12 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C106 1
13 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C108 1
14 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C109 1
15 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C111 1
16 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ C112 1
17 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ C113 1
18 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ C114 1
19 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C119 1
20 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C120 1
21 N/A N/A 2341133196P CAP,CHIP 125'C CS 0603/COG/50V 330p J T C150 1
22 N/A N/A 2341133196P CAP,CHIP 125'C CS 0603/COG/50V 330p J T C151 1
23 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C203 1
24 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C206 1
25 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C207 1
26 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C208 1
27 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C211 1
28 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C212 1
29 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C213 1
30 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C214 1
31 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C215 1
32 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C216 1
33 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C217 1
34 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C218 1
35 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C220 1
36 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C222 1
37 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C223 1
38 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C224 1
39 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C225 1
40 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C226 1
41 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C227 1
42 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C228 1
43 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C229 1
44 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C230 1
45 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C232 1
46 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C233 1
47 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C234 1
48 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C235 1
49 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C236 1
50 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C237 1
51 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C238 1
52 N/A N/A 2341120096P CAP,CHIP 125'C CS 0603/COG/50V 20p J T C239 1
53 N/A N/A 2341120096P CAP,CHIP 125'C CS 0603/COG/50V 20p J T C243 1
54 N/A N/A 2341147096P CAP,CHIP 125'C CS 0603/COG/50V 47p J T C244 1
55 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C245 1
56 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C246 1
57 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C247 1
58 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C248 1
59 N/A N/A 2346122396P CAP,CHIP 125'C CS 0603/X7R/50V 0.022u K T C252 1
60 N/A N/A 2346122396P CAP,CHIP 125'C CS 0603/X7R/50V 0.022u K T C253 1
61 N/A N/A 2346122396P CAP,CHIP 125'C CS 0603/X7R/50V 0.022u K T C254 1
62 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C255 1
63 N/A N/A 2346122396P CAP,CHIP 125'C CS 0603/X7R/50V 0.022u K T C257 1
64 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C260 1
65 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C266 1
66 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C269 1
67 N/A N/A 2341147096P CAP,CHIP 125'C CS 0603/COG/50V 47p J T C270 1
68 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C272 1
69 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C273 1
70 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C302 1
71 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C303 1
72 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C304 1
73 N/A N/A 2341120096P CAP,CHIP 125'C CS 0603/COG/50V 20p J T C305 1
74 N/A N/A 2341120096P CAP,CHIP 125'C CS 0603/COG/50V 20p J T C306 1
75 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C307 1
76 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C310 1
77 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C311 1
78 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C312 1

ViewSonic Model Number: VS11404

-

Description

BOM LIST (N2750w-2G)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

75

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

79 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C313 1
80 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C314 1
81 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C315 1
82 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C316 1
83 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C317 1
84 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C318 1
85 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C367 1
86 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C401 1
87 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C403 1
88 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C404 1
89 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C405 1
90 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C406 1
91 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C407 1
92 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C408 1
93 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C409 1
94 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C410 1
95 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C411 1
96 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C412 1
97 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C413 1
98 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C414 1
99 N/A N/A 2341130096P CAP,CHIP 125'C CS 0603/COG/50V 30p J T C417 1

100 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C418 1
101 N/A N/A 2341130096P CAP,CHIP 125'C CS 0603/COG/50V 30p J T C419 1
102 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C420 1
103 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C422 1
104 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C423 1
105 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C425 1
106 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C426 1
107 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C428 1
108 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C429 1
109 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C431 1
110 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C433 1
111 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C435 1
112 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C436 1
113 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C437 1
114 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C438 1
115 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C439 1
116 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C441 1
117 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C442 1
118 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C443 1
119 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C444 1
120 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C445 1
121 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C446 1
122 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C448 1
123 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C449 1
124 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C450 1
125 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C451 1
126 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C452 1
127 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C453 1
128 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C454 1
129 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C455 1
130 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C456 1
131 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C459 1
132 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C460 1
133 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C461 1
134 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C462 1
135 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C464 1
136 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C465 1
137 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C466 1
138 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C467 1
139 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C468 1
140 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C469 1
141 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C471 1
142 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C503 1
143 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C504 1
144 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C507 1
145 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C508 1
146 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C513 1
147 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C516 1
148 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C517 1
149 N/A N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C521 1
150 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C523 1
151 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C524 1
152 N/A N/A 2341147096P CAP,CHIP 125'C CS 0603/COG/50V 47p J T C539 1
153 N/A N/A 2341147096P CAP,CHIP 125'C CS 0603/COG/50V 47p J T C540 1
154 N/A N/A 2341147096P CAP,CHIP 125'C CS 0603/COG/50V 47p J T C541 1
155 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C542 1
156 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C543 1
157 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C548 1
158 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C549 1
159 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C551 1
160 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ C553 1
161 N/A N/A 2341147096P CAP,CHIP 125'C CS 0603/COG/50V 47p J T C554 1
162 N/A N/A 2341147096P CAP,CHIP 125'C CS 0603/COG/50V 47p J T C555 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

76

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

163 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C557 1
164 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ C560 1
165 N/A N/A 2341120096P CAP,CHIP 125'C CS 0603/COG/50V 20p J T C600 1
166 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C602 1
167 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C603 1
168 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C604 1
169 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C605 1
170 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C606 1
171 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C607 1
172 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C608 1
173 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C610 1
174 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C611 1
175 N/A N/A 2346733496P CAP,CHIP 85'C CS 0603/Y5V/16V 0.33u Z T C612 1
176 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C614 1
177 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C616 1
178 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C620 1
179 N/A N/A 2341156096P CAP,CHIP 125'C CS 0603/COG/50V 56p J T C621 1
180 N/A N/A 2341156096P CAP,CHIP 125'C CS 0603/COG/50V 56p J T C622 1
181 N/A N/A 2341156096P CAP,CHIP 125'C CS 0603/COG/50V 56p J T C624 1
182 N/A N/A 2341182996P CAP,CHIP 125'C CS 0603/COG/50V 8.2p D T C625 1
183 N/A N/A 2341182996P CAP,CHIP 125'C CS 0603/COG/50V 8.2p D T C626 1
184 N/A N/A 2346133296P CAP,CHIP 125'C CS 0603/X7R/50V 3300p K T C627 1
185 N/A N/A 2346133296P CAP,CHIP 125'C CS 0603/X7R/50V 3300p K T C628 1
186 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C630 1
187 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C640 1
188 N/A N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C644 1
189 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C651 1
190 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C652 1
191 N/A N/A 2347110396P CAP,CHIP 125'C CS 0805/X7R/50V 0.01u K T C654 1
192 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C658 1
193 N/A N/A 2349110496P CAP,CHIP 125'C CS 1206/X7R/50V 0.1u K T C660 1
194 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C661 1
195 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C664 1
196 N/A N/A 2349110496P CAP,CHIP 125'C CS 1206/X7R/50V 0.1u K T C667 1
197 N/A N/A 2347110396P CAP,CHIP 125'C CS 0805/X7R/50V 0.01u K T C668 1
198 N/A N/A 2347110396P CAP,CHIP 125'C CS 0805/X7R/50V 0.01u K T C669 1
199 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C670 1
200 N/A N/A 2349110496P CAP,CHIP 125'C CS 1206/X7R/50V 0.1u K T C672 1
201 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C674 1
202 N/A N/A 2349110496P CAP,CHIP 125'C CS 1206/X7R/50V 0.1u K T C677 1
203 N/A N/A 2347110396P CAP,CHIP 125'C CS 0805/X7R/50V 0.01u K T C678 1
204 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C684 1
205 N/A N/A 2341139196P CAP,CHIP 125'C CS 0603/COG/50V 390p J T C689 1
206 N/A N/A 2341168196P CAP,CHIP 125'C CS 0603/COG/50V 680p J T C690 1
207 N/A N/A 2341147196P CAP,CHIP 125'C CS 0603/COG/50V 470p J T C692 1
208 N/A N/A 2346133296P CAP,CHIP 125'C CS 0603/X7R/50V 3300p K T C698 1
209 N/A N/A 2346133296P CAP,CHIP 125'C CS 0603/X7R/50V 3300p K T C699 1
210 N/A N/A 2341120096P CAP,CHIP 125'C CS 0603/COG/50V 20p J T C700 1
211 N/A N/A 2341120096P CAP,CHIP 125'C CS 0603/COG/50V 20p J T C701 1
212 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C902 1
213 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C906 1
214 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C908 1
215 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C909 1
216 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C910 1
217 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C912 1
218 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C914 1
219 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C915 1
220 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C918 1
221 N/A N/A 2346110496P CAP,CHIP 125'C CS 0603/X7R/50V 0.1u K T C922 1
222 N/A N/A 2364505636P DIODE,ZENER SMD BZV55-B5V6 2% SOD-80C PHILIPS D108 RD 1
223 N/A N/A 2364505636P DIODE,ZENER SMD BZV55-B5V6 2% SOD-80C PHILIPS D109 RD 1
224 N/A N/A 2364505636P DIODE,ZENER SMD BZV55-B5V6 2% SOD-80C PHILIPS D110 RD 1
225 N/A N/A 2364505636P DIODE,ZENER SMD BZV55-B5V6 2% SOD-80C PHILIPS D111 RD 1
226 N/A N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD80C GRANDE D112 RB 1
227 N/A N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD80C GRANDE D113 RB 1
228 N/A N/A 2364505636P DIODE,ZENER SMD BZV55-B5V6 2% SOD-80C PHILIPS D114 RD 1
229 N/A N/A 2364505636P DIODE,ZENER SMD BZV55-B5V6 2% SOD-80C PHILIPS D115 RD 1
230 N/A N/A 2364302496P DIODE,SCHOTTKY(SMD) SM17 DO-214AC MOSPEC D116 1
231 N/A N/A 2364505636P DIODE,ZENER SMD BZV55-B5V6 2% SOD-80C PHILIPS D117 RD 1
232 N/A N/A 2364302496P DIODE,SCHOTTKY(SMD) SM17 DO-214AC MOSPEC D118 1
233 N/A N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD80C GRANDE D201 RB 1
234 N/A N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD80C GRANDE D202 RB 1
235 N/A N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD80C GRANDE D301 RB 1
236 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D504 1
237 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D506 1
238 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D507 1
239 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D508 1
240 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D511 1
241 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D513 1
242 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D519 1
243 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D520 1
244 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D521 1
245 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D522 1
246 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D523 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

77

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

247 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D524 1
248 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D525 1
249 N/A N/A 2349900996P CAP,CHIP SPEC 0603V-PORT 10P+-10% INPAQ D526 1
250 N/A N/A 2365813696P IC,LINEAR(SMD) AP1117E18LA SOT-223 AnaChip I201 RA 1
251 N/A N/A 2365335086P LINEAR IC AIC1117A-18PY SOT223 AIC I201 RB 1
252 N/A N/A 2365335076P LINEAR IC CM1117GDCM223 SOT223 CHAMPION I201 RC 1
253 N/A N/A 2365808396P IC,LINEAR(SMD) AIC1117-33PY SOT-223 AIC I202 RB 1
254 N/A N/A 2365809496P IC,LINEAR(SMD) CM1117SCM-3.3V SOT223 CHAMPION I202 RC 1
255 N/A N/A 2365807196P IC,LINEAR(SMD) AMC1117-3.3 SOT-223 ADD I202 RD 1
256 N/A N/A 2365425066P DIGITAL IC SAA7117AH QFP-160 PHILIPS I203 1
257 N/A N/A 2365335216P LINEAR IC MM1501XNRE SOT-26B MITSUMI I204 1
258 N/A N/A 2365915496P IC,DIGITAL SMD IS61C256AH-12J ISSI SOJ28 I205 RA 1
259 N/A N/A 2365931896P IC,DIGITAL SMD FSAV330QSCX QSOP-16 FAIRCHILD I205 RC 1
260 N/A N/A 2365335276P LINEAR IC TS5V330DR SOIC-16 TI I205 RD 1
261 N/A N/A 2365425016P DIGITAL IC W79E632A40PL PLCC-44 Winbond I301 1
262 N/A N/A 2365106896P MEMORY IC AT24C32AN-10SU-2.7 SO-8 AMTEL I302 RA 1
263 N/A N/A 2365107496P MEMORY IC (EEPROM) M24C32-WMN6TP SO-8 ST I302 RB 1
264 N/A N/A 2365108696P MEMORY IC (EEPROM) HT24LC04 SO-8 HOLTEK I303 RA 1
265 N/A N/A 2365903996P IC,DIGITAL SMD AT24C04N-10SU-2.7 SO8 ATMEL I303 RB 1
266 N/A N/A 2365425506P DIGITAL IC MST5151A-LF PQFP-208 Mstar I401 1
267 N/A N/A 2365104396P MEMORY IC NT5DS4M32EG FBGA-144 NANYA I402 RA 1
268 N/A N/A 2365105796P MEMORY IC (SDRAM) EM6A9320BI-5MG FBGA144 Etron I402 RB 1
269 N/A N/A 2365810296P IC,LINEAR(SMD) AIC1084PM-ADJ TO263 AIC I403 RA 1
270 N/A N/A 2365808096P IC,LINEAR(SMD) AP1084KLA TO-263 AnaChip I403 RB 1
271 N/A N/A 2365425266P DIGITAL IC MSP4410G-QI PMQFP64 Micronas I601 1
272 N/A N/A 2365930096P IC,DIGITAL SMD TPA3002D2PHPR TQFP-48 TI I602 RA 1
273 N/A N/A 2365335246P LINEAR IC TPA3004D2PHPRG34 HTQFP48 TI I602 RB 1
274 N/A N/A 2365335256P LINEAR IC AP1115AYLA(ADJ) SOT-89 Anachip I604 1
275 N/A N/A 2365809196P IC,LINEAR(SMD) CM1084SCN263 TO263 CHAMPION I902 RB 1
276 N/A N/A 2365335096P LINEAR IC AIC1117APY SOT-223 AIC I903 RA 1
277 N/A N/A 2365809396P IC,LINEAR(SMD) CM1117CM-ADJ SOT223 CHAMPION I903 RB 1
278 N/A N/A 2438000001P SOFTWARE HDCP KEY CODE KC01 1
279 N/A N/A 2253300096P RES CHIP 1/8W RC 0805 1/8 W 0 ohm J T L101 1
280 N/A N/A 2253300096P RES CHIP 1/8W RC 0805 1/8 W 0 ohm J T L102 1
281 N/A N/A 2253300096P RES CHIP 1/8W RC 0805 1/8 W 0 ohm J T L103 1
282 N/A N/A 2253300096P RES CHIP 1/8W RC 0805 1/8 W 0 ohm J T L104 1
283 N/A N/A 2253300096P RES CHIP 1/8W RC 0805 1/8 W 0 ohm J T L105 1
284 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L155 1
285 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L201 1
286 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L202 1
287 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L203 1
288 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L204 1
289 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L206 1
290 N/A N/A 2253300096P RES CHIP 1/8W RC 0805 1/8 W 0 ohm J T L207 1
291 N/A N/A 2253322196P RES CHIP 1/8W RC 0805 1/8 W 220 ohm J T L301 1
292 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L302 1
293 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L303 1
294 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L304 1
295 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L305 1
296 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L306 1
297 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L307 1
298 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L308 1
299 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L309 1
300 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L310 1
301 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L401 1
302 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L402 1
303 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L403 1
304 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L404 1
305 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L405 1
306 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L406 1
307 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L407 1
308 N/A N/A 2379500196P BEAD,HI-CURRENT Z= 80 ohm 0805 I=6.0A L412 1
309 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L501 1
310 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L502 1
311 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L503 1
312 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L504 1
313 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L505 1
314 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L508 1
315 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L510 1
316 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L511 1
317 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L512 1
318 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L513 1
319 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L514 1
320 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L515 1
321 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L601 1
322 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L602 1
323 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L604 1
324 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L605 1
325 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L606 1
326 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L607 1
327 N/A N/A 2379822106P BEAD,HI-IMPEDANCE Z= 220 ohm(200MHZ~) 0805 200mA L608 1
328 N/A N/A 2377410996P INDUCTOR CHIP MULTI-LAYER 1uH/0603 K T L616 1
329 N/A N/A 2377410996P INDUCTOR CHIP MULTI-LAYER 1uH/0603 K T L617 1
330 N/A N/A 2377510096P INDUCTOR CHIP MULTI-LAYER 10.0uH/0805 K T L618 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

78

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

331 N/A N/A 2377510096P INDUCTOR CHIP MULTI-LAYER 10.0uH/0805 K T L619 1
332 N/A N/A 2379500196P BEAD,HI-CURRENT Z= 80 ohm 0805 I=6.0A L620 1
333 N/A N/A 2407390144P SOCKET,IC 1.27mm*44PIN PLCC SMD P130 1
334 N/A N/A 2360609796P FET,N-CH(SMD) 2SK2158 SOT-23 NEC Q102 1
335 N/A N/A 2360609796P FET,N-CH(SMD) 2SK2158 SOT-23 NEC Q103 1
336 N/A N/A 2360100696P XISTOR,PNP R SMD PMBS3906 SOT-23 PHILIPS Q203 RA 1
337 N/A N/A 2360100696P XISTOR,PNP R SMD PMBS3906 SOT-23 PHILIPS Q205 RA 1
338 N/A N/A 2259200008P RES,CHIP NETWORKS 8P4R 1/16W 0 ohm J P=0.8 RP40 1
339 N/A N/A 2259275008P RES,CHIP NETWORKS 8P4R 1/16W 75 ohm J P=0.8 RP41 1
340 N/A N/A 2259275008P RES,CHIP NETWORKS 8P4R 1/16W 75 ohm J P=0.8 RP42 1
341 N/A N/A 2259275008P RES,CHIP NETWORKS 8P4R 1/16W 75 ohm J P=0.8 RP43 1
342 N/A N/A 2259275008P RES,CHIP NETWORKS 8P4R 1/16W 75 ohm J P=0.8 RP44 1
343 N/A N/A 2259275008P RES,CHIP NETWORKS 8P4R 1/16W 75 ohm J P=0.8 RP45 1
344 N/A N/A 2259275008P RES,CHIP NETWORKS 8P4R 1/16W 75 ohm J P=0.8 RP47 1
345 N/A N/A 2259275008P RES,CHIP NETWORKS 8P4R 1/16W 75 ohm J P=0.8 RP48 1
346 N/A N/A 2259275008P RES,CHIP NETWORKS 8P4R 1/16W 75 ohm J P=0.8 RP49 1
347 N/A N/A 2259200008P RES,CHIP NETWORKS 8P4R 1/16W 0 ohm J P=0.8 RP52 1
348 N/A N/A 2253227096P RES CHIP 1/10W RC 0603 1/10W 27 ohm J T R201 1
349 N/A N/A 2251239206P RES,CHIP 1/10 RC 0603 1/10W 392 ohm F T R202 1
350 N/A N/A 2253268296P RES CHIP 1/10W RC 0603 1/10W 6.8Kohm J T R229 1
351 N/A N/A 2253282096P RES CHIP 1/10W RC 0603 1/10W 82 ohm J T R230 1
352 N/A N/A 2253268096P RES CHIP 1/10W RC 0603 1/10W 68 ohm J T R234 1
353 N/A N/A 2253212296P RES CHIP 1/10W RC 0603 1/10W 1.2Kohm J T R236 1
354 N/A N/A 2253268196P RES CHIP 1/10W RC 0603 1/10W 680 ohm J T R239 1
355 N/A N/A 2253227096P RES CHIP 1/10W RC 0603 1/10W 27 ohm J T R245 1
356 N/A N/A 2253227096P RES CHIP 1/10W RC 0603 1/10W 27 ohm J T R247 1
357 N/A N/A 2251239206P RES,CHIP 1/10 RC 0603 1/10W 392 ohm F T R401 1
358 N/A N/A 2253210496P RES CHIP 1/10W RC 0603 1/10W 100Kohm J T R426 1
359 N/A N/A 2253224196P RES CHIP 1/10W RC 0603 1/10W 240 ohm J T R427 1
360 N/A N/A 2253213296P RES CHIP 1/10W RC 0603 1/10W 1.3Kohm J T R532 1
361 N/A N/A 2253213296P RES CHIP 1/10W RC 0603 1/10W 1.3Kohm J T R547 1
362 N/A N/A 2253375096P RES CHIP 1/8W RC 0805 1/8 W 75 ohm J T R552 1
363 N/A N/A 2253375096P RES CHIP 1/8W RC 0805 1/8 W 75 ohm J T R561 1
364 N/A N/A 2253282296P RES CHIP 1/10W RC 0603 1/10W 8.2Kohm J T R622 1
365 N/A N/A 2253282296P RES CHIP 1/10W RC 0603 1/10W 8.2Kohm J T R624 1
366 N/A N/A 2253212396P RES CHIP 1/10W RC 0603 1/10W 12Kohm J T R629 1
367 N/A N/A 2253239396P RES CHIP 1/10W RC 0603 1/10W 39Kohm J T R632 1
368 N/A N/A 2253212496P RES CHIP 1/10W RC 0603 1/10W 120Kohm J T R636 1
369 N/A N/A 2253239296P RES CHIP 1/10W RC 0603 1/10W 3.9Kohm J T R647 1
370 N/A N/A 2253212396P RES CHIP 1/10W RC 0603 1/10W 12Kohm J T R650 1
371 N/A N/A 2253212196P RES CHIP 1/10W RC 0603 1/10W 120 ohm J T R655 1
372 N/A N/A 2251268106P RES,CHIP 1/10 RC 0603 1/10W 680 ohm F T R656 1
373 N/A N/A 2253210496P RES CHIP 1/10W RC 0603 1/10W 100Kohm J T R908 1
374 N/A N/A 2202524202P PCB MULTILAYER 278FE65E MB FR4*4 240*217 3.02 U101 1
375 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C202 1
376 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C205 1
377 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C209 1
378 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C219 1
379 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C256 1
380 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C258 1
381 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C259 1
382 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C263 1
383 N/A N/A 2336322613P CAP,MINI ELE 105'C EC 22u/ 16V 4*7 P=2.5 T C267 1
384 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C268 1
385 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C301 1
386 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C365 1
387 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C402 1
388 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C421 1
389 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C424 1
390 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C427 1
391 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C430 1
392 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C432 1
393 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C434 1
394 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C440 1
395 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C447 1
396 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C457 1
397 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C463 1
398 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C472 1
399 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C550 1
400 N/A N/A 2336322613P CAP,MINI ELE 105'C EC 22u/ 16V 4*7 P=2.5 T C552 1
401 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C556 1
402 N/A N/A 2336322613P CAP,MINI ELE 105'C EC 22u/ 16V 4*7 P=2.5 T C558 1
403 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C609 1
404 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C613 1
405 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C615 1
406 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C617 1
407 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C618 1
408 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C619 1
409 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C631 1
410 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C659 1
411 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C665 1
412 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C671 1
413 N/A N/A 2333310613P CAP ELE 105'C EC 10u/ 16V 5*11 P=2.5 T C675 1
414 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C679 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

79

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

415 N/A N/A 2333610513P CAP ELE 105'C EC 1u/ 50V 5*11 P=2.5 T C682 1
416 N/A N/A 2333610513P CAP ELE 105'C EC 1u/ 50V 5*11 P=2.5 T C683 1
417 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C685 1
418 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C687 1
419 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C905 1
420 N/A N/A 2333310713P CAP ELE 105'C EC 100u/ 16V 6.3*11 P=2.5 T C907 1
421 N/A N/A 2335347713P CAP,ELE LOW ESR 105'C EC 470u/ 16V 8*12 P=5.0 T C929 1
422 N/A N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C931 1
423 N/A N/A 2335310841P CAP,ELE LOW ESR 105'C EC 1000u/ 16V 10*16 P=5.0 C C308 1
424 N/A N/A 2335215811P CAP,ELE LOW ESR 105'C EC 1500u/ 10V10*16 P=5.0 C C514 1
425 N/A N/A 2335215811P CAP,ELE LOW ESR 105'C EC 1500u/ 10V10*16 P=5.0 C C525 1
426 N/A N/A 2363217112P DIODE,RECT 1N5406 CTC D601 RA 1
427 N/A N/A 2363216812P DIODE,RECT 1N5406 600V/3A DO-201AD TSC D601 RB 1
428 N/A N/A 2363216212P DIODE,RECT 1N5406 FAGOR D601 RC 1
429 N/A N/A 2363217112P DIODE,RECT 1N5406 CTC D602 RA 1
430 N/A N/A 2363216812P DIODE,RECT 1N5406 600V/3A DO-201AD TSC D602 RB 1
431 N/A N/A 2363216212P DIODE,RECT 1N5406 FAGOR D602 RC 1
432 N/A N/A 2371106700P COIL,CHOKE JC186H 40uH 35.5TS(REF) L506 1
433 N/A N/A 2371106700P COIL,CHOKE JC186H 40uH 35.5TS(REF) L507 1
434 N/A N/A 2371106700P COIL,CHOKE JC186H 40uH 35.5TS(REF) L609 1
435 N/A N/A 2371106700P COIL,CHOKE JC186H 40uH 35.5TS(REF) L610 1
436 N/A N/A 2371106700P COIL,CHOKE JC186H 40uH 35.5TS(REF) L611 1
437 N/A N/A 2371106700P COIL,CHOKE JC186H 40uH 35.5TS(REF) L612 1
438 N/A N/A 2371106700P COIL,CHOKE JC186H 40uH 35.5TS(REF) L613 1
439 N/A N/A 2407640119P SOCKET,SMD HDMI T019PIN-JSN001B TAYBANG P101 RA 1
440 N/A N/A 2407640219P SOCKET,SMD HDMI HMR47-19P ACON P101 RB 1
441 N/A N/A 2407640419P SOCKET,SMD HDMI 908DA2F19FCND03 COXOC P101 RC 1
442 N/A N/A 2407430900P SOCKET DHSB-15FTF7 BLUE(661C) LEOCO P102 1
443 N/A N/A 2404301103P CONNECTOR JST PH 4P SIDE P=2.0 OR EQUAL P103 1
444 N/A N/A 2404301113P CONNECTOR JST PH 14P SIDE P=2.0 OR EQUAL P301 1
445 N/A N/A 2404312130P CONNECTOR 2R1L TOP P=2.0mm 2046P**V*** P401 1
446 N/A N/A 2407442900T SOCKET MINI DIN 4P SIDE BLACK P501 1
447 N/A N/A 2405322201P RCA JACK 2*2P (4P BLU/YEL/RED/GRN) P502 1
448 N/A N/A 2404322421P CONNECTOR RC-2129 JINGYA or EQUAL P503 1
449 N/A N/A 2404322421P CONNECTOR RC-2129 JINGYA or EQUAL P506 1
450 N/A N/A 2405332201P RCA JACK 2*3(6P WHT/RED) P601 1
451 N/A N/A 2405106000P EARPHONE JACK 2SJ-P520-A04 (577C) SINGATRON P602 1
452 N/A N/A 2404300003P CONNECTOR JST XH 4P TOP P=2.5 OR EQUAL P603 1
453 N/A N/A 2405105900P EARPHONE JACK ERR 3.5∮ SIDE 284C(BLUE) P604 1
454 N/A N/A 2404301011P CONNECTOR JST XH 12P SIDE P=2.5 OR EQUAL P902 1
455 N/A N/A 2369105701P XTAL,OSC 24.0000MHZ/49US 0.1mw/16PF X301 1
456 N/A N/A 2369105501P XTAL,OSC 18.432MHZ/49US 0.1mW/12pf X601 1
457 N/A N/A 2404301106P CONNECTOR JST PH 7P SIDE P=2.0 OR EQUAL P701 1
458 N/A N/A 2202129800P PC BOARD JC278 KEY/B CEM1 120*20 V1.00 U701 1
459 N/A N/A 2363703800P LED 3∮ GRN/YEL D721 1
460 N/A N/A 2419301400P RECEIV BLOCK ECM-A38-3VS28 ECEL I721 1
461 N/A N/A 2202129901P PC BOARD JC278 IR/B CEM1 54*53 V2.01 U702 1
462 N/A N/A 2063451300P ADHESI SHEET JC186H PVC 7.5X7.5X3t 9R80 1
463 N/A N/A 2074750100P LED HOLDER-PWR NYLON 66 H=6.0MM LED306 9R81 1
464 N/A N/A 2200227025P PC BOARD ASS'Y B028-101 DARFON U801 RB 1
465 N/A N/A 2200227027P PC BOARD ASS'Y LINGCHANG U801 RC 1
466 N/A N/A 2024268006P FRONT BEZEL JC278UB ABS94HB BLACK/PS-7604B 1F01 1
467 N/A N/A 2054256001P ORNAMENT JC278 FRONT BAR ABSHB AL-PLATE 1F02 1
468 N/A N/A 2033150600P IR COVER JC278UB PC LIMPID 476C 1F03 1
469 N/A N/A 2053754201P LED INDIC.-PWR JC278UB PMMA LIMPID 1F04 1
470 N/A N/A 2044266901P FUNCTION KEY JC278UB ABS 94V0 AL-PLATE PWR 1F05 1
471 N/A N/A 2051356100P NAME PLATE 18.0*12.7MM E015-002-W BIRDS 1F07 1
472 N/A N/A 2051355600P NAME PLATE 45*7.21M ELECTOR LABEL N2751W 1F08 1
473 N/A N/A 2427430028P WIRE HARNESS 30/30P H/H L=150mm P507 1
474 N/A N/A 2427412007P WIRE HARNESS 12/10P H/H L=390mm P508 1
475 N/A N/A 2427404016P WIRE HARNESS 4/2+2P H/A 1007#24 L=610mm P605 1
476 N/A N/A 2427414012P WIRE HARNESS 14/6+7P H/H L=610mm P712 1
477 N/A N/A 2434325603P SHIELDING TAPE W25*L60mm (AL) K901 1
478 N/A N/A 2434325603P SHIELDING TAPE W25*L60mm (AL) K902 1
479 N/A N/A 2433310011P SHIELDING FOAM W10*H3*L15mm K903 1
480 N/A N/A 2407001700P SOCKET,ASSY INLET+CON/SW 1015#18 L=110 P801 1
481 N/A N/A 2391307081P SPEAKER ASS'Y 7W/8ohm L228*W60*H76mm J.G W901 2
482 N/A N/A 2071977901P METAL FITTG JC278XX65E SECC 1.0T PANEL 1F10 1
483 N/A N/A 2080005200P SCREW,SPE M3*3 TYPEI FOR HS PANEL HI 1F11 9
484 N/A N/A 2072051702P METAL FITTG-I/O JC278XX65E SECC 0.8T IO-MAIN H_SWITCH 1F14 1
485 N/A N/A 2082340082P SCREW,CSK+ SCREW CSK+ M4x8 1F15 4
486 N/A N/A 2083730108P SCREW,BND T+ M3*10 T24 F NI 1F16 2
487 N/A N/A 2083630068P SCREW FMS+ M3X6,M,S-TITE,F,NI 1F17 1
488 N/A N/A 2072051801P METAL FITTG-I/O JC278XX65E SECC 0.8T IO-SIDE (E) HDMI 1F18 1
489 N/A N/A 2082340082P SCREW,CSK+ SCREW CSK+ M4x8 1F19 3
490 N/A N/A 2027264001P DUST COVER JC278XX65E ABS94HB BLACK_C (E) HDMI 1F20 1
491 N/A N/A 2083730108P SCREW,BND T+ M3*10 T24 F NI 1F21 1
492 N/A N/A 2083630068P SCREW FMS+ M3X6,M,S-TITE,F,NI 1F22 2
493 N/A N/A 2027263202P DUST COVER N2751W ABS94HB BLACK C FUN-KEY 1F23 1
494 N/A N/A 2044266601P FUNCTION KEY JC278 ABS 94V0 AL-PLATE FUNCTI 1F24 1
495 N/A N/A 2080040062P SCREW,SPE M4*8 PMS-3/W 1F29 1
496 N/A N/A 2071675800P SHIELD PLATE JC278XXXXUA SECC T=0.8MM SHIELD COVER 1F30 1
497 N/A N/A 2082340082P SCREW,CSK+ SCREW CSK+ M4x8 1F31 11

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

80

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

498 N/A N/A 2071879400P BRACKET,FIX JC278XXXXUA SECC T=1.6MM SUPPORT 1F32 1
499 N/A N/A 2082340082P SCREW,CSK+ SCREW CSK+ M4x8 1F33 2
500 N/A N/A 2071879500P BRACKET,FIX JC278XXXXUA SECC T=0.8MM SUPPORT-SPK 1F34 1
501 N/A N/A 2080007100P SCREW,SPE M3x6mm,M,I,NI (9.35mm) 1F37 4
502 N/A N/A 2061456600P BUSHING RUBBER 15*15 T:10.0MM BLACK 1F40 4
503 N/A N/A 2072461500P INSULATOR MYLAR FR700 94V0 132X135 0.5T 1F42 1
504 N/A N/A 2061152000P FELT 610*12 T=0.5MM NO.5000NS 1F43 1
505 N/A N/A 2061253700P SPONGE 190MM*65MM*3MM 1F45 2
506 N/A N/A 2082340102P SCREW,CSK+ SCREW F M4X10 (CSK+) 2C02 8
507 N/A N/A 2027263302P DUST COVER N2751W ABS94HB BLACK C SIDE 2C03 1
508 N/A N/A 2027263402P DUST COVER N2751W ABS94HB BLACK C DOWN 2C04 1
509 N/A N/A 2061254000P SPONGE SPONGE BLACK 10*6*180MM 2C05 2
510 N/A N/A 2055636058P LABEL N2750W-2G SMALL LABEL 6P05 1
511 N/A N/A 2055135143P LABEL N2750W-2(G) VS11404-1G CMO 6P50 1
512 N/A N/A 2071871700P BRACKET,FIX JC278UB ALUMINUM PS-7604B ARM 5B01 1
513 N/A N/A 2039802304P FOOT PAD CRφ16.5X7.3/BLACK 5B02 6
514 N/A N/A 2082750402P SCREW,BND+ M5X40,M,P,ZN-CC 5B03 4
515 N/A N/A 2071878800P BRACKET,FIX JC278UB SECC T=2.0MM STAND 5B05 1
516 N/A N/A 2054256201P ORNAMENT JC278UB BASE PLATE LEFT 5B06 1
517 N/A N/A 2054256301P ORNAMENT JC278UB BASE PLATE RIGHT 5B07 1
518 N/A N/A 2082340102P SCREW,CSK+ SCREW F M4X10 (CSK+) 5B08 4
519 N/A N/A 2005100400P BATTERY,DRY R6PGS 1.5V (AA) CHINA TOSHIBA B901 2
520 N/A N/A 2405313001P RCA JACK RCA (R/W/Y)/SCART P953 1
521 N/A N/A 2002370032P GUARANT CARD VIEWSONIC WARRANTY CARD-C TV 6P07 1
522 N/A N/A 2055632220P LABEL N2750W-2G VS11404-1G (G) SMO 6P02 1
523 N/A N/A 2055613509P LABEL VIEWSONIC HDMI STICKER 431C 6P04 1
524 N/A N/A 2063301700P PROTECTOR 355mm*620mm*0.075mm 6P30 1
525 N/A N/A 2013054003P POLYETHY BAG 800X800mm HDPE BAG 6P60 1
526 N/A N/A 2013054012P POLYETHY BAG 810LX380WX1050H T=0.08MM 6P70 1
527 N/A Inactive 2346110396P CAP,CHIP 125'C CS 0603/X7R/50V 0.01u K T C101 1
528 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C201 1
529 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C240 1
530 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C241 1
531 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C242 1
532 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C249 1
533 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C250 1
534 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C251 1
535 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C261 1
536 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C262 1
537 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C264 1
538 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C265 1
539 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C274 1
540 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C275 1
541 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C276 1
542 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C277 1
543 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C278 1
544 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C309 1
545 N/A Inactive 2346110396P CAP,CHIP 125'C CS 0603/X7R/50V 0.01u K T C520 1
546 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C535 1
547 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C536 1
548 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C537 1
549 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C538 1
550 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C544 1
551 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C545 1
552 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C546 1
553 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C547 1
554 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C601 1
555 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C632 1
556 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C634 1
557 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C635 1
558 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C637 1
559 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C638 1
560 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C641 1
561 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C642 1
562 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C647 1
563 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C648 1
564 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C649 1
565 N/A Inactive 2341110196P CAP,CHIP 125'C CS 0603/COG/50V 100p J T C650 1
566 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C655 1
567 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C656 1
568 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C657 1
569 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C662 1
570 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C663 1
571 N/A Inactive 2341122196P CAP,CHIP 125'C CS 0603/COG/50V 220p J T C673 1
572 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C680 1
573 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C681 1
574 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C686 1
575 N/A Inactive 2341122196P CAP,CHIP 125'C CS 0603/COG/50V 220p J T C688 1
576 N/A Inactive 2346110396P CAP,CHIP 125'C CS 0603/X7R/50V 0.01u K T C693 1
577 N/A Inactive 2346110396P CAP,CHIP 125'C CS 0603/X7R/50V 0.01u K T C694 1
578 N/A Inactive 2346110396P CAP,CHIP 125'C CS 0603/X7R/50V 0.01u K T C695 1
579 N/A Inactive 2346110396P CAP,CHIP 125'C CS 0603/X7R/50V 0.01u K T C696 1
580 N/A Inactive 2346110396P CAP,CHIP 125'C CS 0603/X7R/50V 0.01u K T C697 1
581 N/A Inactive 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C927 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

81

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

582 N/A Inactive 2364500396P DIODE,ZENER SMD RLZ5.6B 5.45-5.73V LL-34 ROHM D108 RC 1
583 N/A Inactive 2364500396P DIODE,ZENER SMD RLZ5.6B 5.45-5.73V LL-34 ROHM D109 RC 1
584 N/A Inactive 2364500396P DIODE,ZENER SMD RLZ5.6B 5.45-5.73V LL-34 ROHM D110 RC 1
585 N/A Inactive 2364500396P DIODE,ZENER SMD RLZ5.6B 5.45-5.73V LL-34 ROHM D111 RC 1
586 N/A Inactive 2364500396P DIODE,ZENER SMD RLZ5.6B 5.45-5.73V LL-34 ROHM D114 RC 1
587 N/A Inactive 2364500396P DIODE,ZENER SMD RLZ5.6B 5.45-5.73V LL-34 ROHM D115 RC 1
588 N/A Inactive 2364500396P DIODE,ZENER SMD RLZ5.6B 5.45-5.73V LL-34 ROHM D117 RC 1
589 N/A Inactive 2365807496P IC,LINEAR(SMD) AIC1084-33PM TO-263 AIC I902 RA 1
590 N/A Inactive 2365810796P IC,LINEAR(SMD) AP1084K33LA TO-263 ATC I902 RC 1
591 N/A Inactive 2407310108P SOCKET,IC 2.54mmX7.62 08PIN DIP D/L P131 1
592 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q101 RA 1
593 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q101 RB 1
594 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q101 RF 1
595 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q201 RA 1
596 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q201 RB 1
597 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q201 RF 1
598 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q202 RA 1
599 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q202 RB 1
600 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q202 RF 1
601 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q206 RA 1
602 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q206 RB 1
603 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q206 RF 1
604 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q301 RA 1
605 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q301 RB 1
606 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q301 RF 1
607 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q302 RA 1
608 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q302 RB 1
609 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q302 RF 1
610 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q401 RA 1
611 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q401 RB 1
612 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q401 RF 1
613 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q501 RA 1
614 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q501 RB 1
615 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q501 RF 1
616 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q502 RA 1
617 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q502 RB 1
618 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q502 RF 1
619 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q601 RA 1
620 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q601 RB 1
621 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q601 RF 1
622 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q604 RA 1
623 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q604 RB 1
624 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q604 RF 1
625 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q605 RA 1
626 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q605 RB 1
627 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q605 RF 1
628 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q901 RA 1
629 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q901 RB 1
630 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q901 RF 1
631 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q902 RA 1
632 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q902 RB 1
633 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q902 RF 1
634 N/A Inactive 2360300396P XISTOR,NPN R SMD MMBT3904 SOT-23 MOTOROLA Q903 RA 1
635 N/A Inactive 2360300596P XISTOR,NPN R SMD MMBT3904-7 SOT23 VISHAY Q903 RB 1
636 N/A Inactive 2360300296P XISTOR,NPN R SMD HMBT3904 SOT23 HI-SIN Q903 RF 1
637 N/A Inactive 2259233008P RES,CHIP NETWORKS 8P4R 1/16W 33 ohm J P=0.8 RP20 1
638 N/A Inactive 2259233008P RES,CHIP NETWORKS 8P4R 1/16W 33 ohm J P=0.8 RP21 1
639 N/A Inactive 2259247208P RES,CHIP NETWORKS 8P4R 1/16W 4.7Kohm J P=0.8 RP30 1
640 N/A Inactive 2259247208P RES,CHIP NETWORKS 8P4R 1/16W 4.7Kohm J P=0.8 RP31 1
641 N/A Inactive 2259247208P RES,CHIP NETWORKS 8P4R 1/16W 4.7Kohm J P=0.8 RP32 1
642 N/A Inactive 2253210096P RES CHIP 1/10W RC 0603 1/10W 10 ohm J T R101 1
643 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R103 1
644 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R104 1
645 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R105 1
646 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R106 1
647 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R107 1
648 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R108 1
649 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R109 1
650 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R110 1
651 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R111 1
652 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R115 1
653 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R116 1
654 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R117 1
655 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R118 1
656 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R119 1
657 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R120 1
658 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R123 1
659 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R124 1
660 N/A Inactive 2253210096P RES CHIP 1/10W RC 0603 1/10W 10 ohm J T R125 1
661 N/A Inactive 2253210096P RES CHIP 1/10W RC 0603 1/10W 10 ohm J T R126 1
662 N/A Inactive 2253210096P RES CHIP 1/10W RC 0603 1/10W 10 ohm J T R128 1
663 N/A Inactive 2253210096P RES CHIP 1/10W RC 0603 1/10W 10 ohm J T R129 1
664 N/A Inactive 2253210096P RES CHIP 1/10W RC 0603 1/10W 10 ohm J T R130 1
665 N/A Inactive 2253210096P RES CHIP 1/10W RC 0603 1/10W 10 ohm J T R131 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

82

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

666 N/A Inactive 2253210096P RES CHIP 1/10W RC 0603 1/10W 10 ohm J T R132 1
667 N/A Inactive 2253233296P RES CHIP 1/10W RC 0603 1/10W 3.3Kohm J T R134 1
668 N/A Inactive 2253233296P RES CHIP 1/10W RC 0603 1/10W 3.3Kohm J T R135 1
669 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R136 1
670 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R137 1
671 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R139 1
672 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R203 1
673 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R204 1
674 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R205 1
675 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R206 1
676 N/A Inactive 2253233096P RES CHIP 1/10W RC 0603 1/10W 33 ohm J T R208 1
677 N/A Inactive 2253233096P RES CHIP 1/10W RC 0603 1/10W 33 ohm J T R209 1
678 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R210 1
679 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R211 1
680 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R212 1
681 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R213 1
682 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R214 1
683 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R215 1
684 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R216 1
685 N/A Inactive 2253230296P RES CHIP 1/10W RC 0603 1/10W 3.0Kohm J T R227 1
686 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R228 1
687 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R232 1
688 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R235 1
689 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R237 1
690 N/A Inactive 2253247196P RES CHIP 1/10W RC 0603 1/10W 470 ohm J T R238 1
691 N/A Inactive 2253251196P RES CHIP 1/10W RC 0603 1/10W 510 ohm J T R240 1
692 N/A Inactive 2253230296P RES CHIP 1/10W RC 0603 1/10W 3.0Kohm J T R241 1
693 N/A Inactive 2253230296P RES CHIP 1/10W RC 0603 1/10W 3.0Kohm J T R242 1
694 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R251 1
695 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R252 1
696 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R273 1
697 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R301 1
698 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R302 1
699 N/A Inactive 2253210596P RES CHIP 1/10W RC 0603 1/10W 1.0Mohm J T R303 1
700 N/A Inactive 2253222196P RES CHIP 1/10W RC 0603 1/10W 220 ohm J T R304 1
701 N/A Inactive 2253222196P RES CHIP 1/10W RC 0603 1/10W 220 ohm J T R305 1
702 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R309 1
703 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R310 1
704 N/A Inactive 2253247196P RES CHIP 1/10W RC 0603 1/10W 470 ohm J T R313 1
705 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R315 1
706 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R316 1
707 N/A Inactive 2253247196P RES CHIP 1/10W RC 0603 1/10W 470 ohm J T R317 1
708 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R319 1
709 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R320 1
710 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R325 1
711 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R404 1
712 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R406 1
713 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R410 1
714 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R412 1
715 N/A Inactive 2253210596P RES CHIP 1/10W RC 0603 1/10W 1.0Mohm J T R418 1
716 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R421 1
717 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R424 1
718 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R428 1
719 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R429 1
720 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R430 1
721 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R431 1
722 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R432 1
723 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R439 1
724 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R440 1
725 N/A Inactive 2253233096P RES CHIP 1/10W RC 0603 1/10W 33 ohm J T R501 1
726 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R502 1
727 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R503 1
728 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R504 1
729 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R505 1
730 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R506 1
731 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R507 1
732 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R508 1
733 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R509 1
734 N/A Inactive 2253233096P RES CHIP 1/10W RC 0603 1/10W 33 ohm J T R510 1
735 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R512 1
736 N/A Inactive 2253247096P RES CHIP 1/10W RC 0603 1/10W 47 ohm J T R513 1
737 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R514 1
738 N/A Inactive 2253230296P RES CHIP 1/10W RC 0603 1/10W 3.0Kohm J T R515 1
739 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R519 1
740 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R525 1
741 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R526 1
742 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R527 1
743 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R528 1
744 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R533 1
745 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R542 1
746 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R543 1
747 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R544 1
748 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R545 1
749 N/A Inactive 2253233296P RES CHIP 1/10W RC 0603 1/10W 3.3Kohm J T R550 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

83

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

750 N/A Inactive 2253233296P RES CHIP 1/10W RC 0603 1/10W 3.3Kohm J T R551 1
751 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R555 1
752 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R556 1
753 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R557 1
754 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R558 1
755 N/A Inactive 2253233296P RES CHIP 1/10W RC 0603 1/10W 3.3Kohm J T R559 1
756 N/A Inactive 2253233296P RES CHIP 1/10W RC 0603 1/10W 3.3Kohm J T R560 1
757 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R564 1
758 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R601 1
759 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R606 1
760 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R607 1
761 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R608 1
762 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R610 1
763 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R612 1
764 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R613 1
765 N/A Inactive 2253222296P RES CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R616 1
766 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R617 1
767 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R623 1
768 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R625 1
769 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R630 1
770 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R634 1
771 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R638 1
772 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R643 1
773 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R644 1
774 N/A Inactive 2253233196P RES CHIP 1/10W RC 0603 1/10W 330 ohm J T R646 1
775 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R648 1
776 N/A Inactive 2253247196P RES CHIP 1/10W RC 0603 1/10W 470 ohm J T R649 1
777 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R652 1
778 N/A Inactive 2253275096P RES CHIP 1/10W RC 0603 1/10W 75 ohm J T R660 1
779 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R661 1
780 N/A Inactive 2253222096P RES CHIP 1/10W RC 0603 1/10W 22 ohm J T R664 1
781 N/A Inactive 2253222096P RES CHIP 1/10W RC 0603 1/10W 22 ohm J T R665 1
782 N/A Inactive 2253222096P RES CHIP 1/10W RC 0603 1/10W 22 ohm J T R666 1
783 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R902 1
784 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R904 1
785 N/A Inactive 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T R905 1
786 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R906 1
787 N/A Inactive 2253210396P RES CHIP 1/10W RC 0603 1/10W 10Kohm J T R911 1
788 N/A Inactive 2333347791P CAP ELE 105'C EC 470u/ 16V 10*12.5 P=5.0 T C458 1
789 N/A Inactive 2333347791P CAP ELE 105'C EC 470u/ 16V 10*12.5 P=5.0 T C653 1
790 N/A Inactive 2365412600P DIGITAL IC 24LC21A/P PSDIP-8 MICROCHIP I104 1
791 N/A Inactive 2369103901P XTAL,OSC 24.576MHZ/49US 0.1mW/20pF X201 1
792 N/A Inactive 2369102901P XTAL,OSC 14.31818MHZ/49US 0.1mW/30PF X401 1
793 N/A Inactive 2433303010P SHIELDING FOAM W10*H10.5*L10mm K904 1
794 N/A Inactive 2433303010P SHIELDING FOAM W10*H10.5*L10mm K905 1
795 N/A Inactive 2056606025P SERIAL LABEL VS CN WARRANTY CARD SN STICKER 6P08 2
796 N/A Inactive 2055613379P LABEL VIEWSONIC CONTAINER LABEL 6P11 111
797 N/A Inactive 2056606009P SERIAL LABEL VIEWSONIC SERVICE STICKER-G 6P15 1
798 M-SW-0815-0182 Active 2403702200P TACT SWITCH TSAA-2 HUAJIE S702 1
799 M-SW-0815-0182 Active 2403702200P TACT SWITCH TSAA-2 HUAJIE S703 1
800 M-SW-0815-0182 Active 2403702200P TACT SWITCH TSAA-2 HUAJIE S704 1
801 M-SW-0815-0182 Active 2403702200P TACT SWITCH TSAA-2 HUAJIE S705 1
802 M-SW-0815-0182 Active 2403702200P TACT SWITCH TSAA-2 HUAJIE S706 1
803 M-SW-0815-0182 Active 2403702200P TACT SWITCH TSAA-2 HUAJIE S707 1
804 M-SW-0815-0182 Active 2403702200P TACT SWITCH TSAA-2 HUAJIE S721 1
805 M-SCW-0824-0811 Active 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 1F13 8
806 M-SCW-0824-0811 Active 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 1F28 3
807 M-SCW-0824-0811 Active 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 1F35 2
808 M-SCW-0824-0285 Active 2084730082P SCREW,BND T+ M3X8(BND T+) 1F06 4
809 M-SCW-0824-0285 Active 2084730082P SCREW,BND T+ M3X8(BND T+) 1F12 1
810 M-SCW-0824-0285 Active 2084730082P SCREW,BND T+ M3X8(BND T+) 1F26 2
811 M-SCW-0824-0285 Active 2084730082P SCREW,BND T+ M3X8(BND T+) 1F36 6
812 M-SCW-0824-0123 Active 2084740102P SCREW,BND T+ M4X10(BND T+) 5B09 8
813 M-MS-0808-6354 Active 2404301105P CONNECTOR JST PH 6P SIDE P=2.0 OR EQUAL P711 1
814 M-LB-0813-0984 Active 2002201323P DISPLAY CARD VIEWSONIC CRT QUALIFIED LABEL 6P09 1
815 M-LB-0813-0959 Active 2055613392P LABEL VSC HIGH VOLTAGE WARNING LABEL 6P14 1
816 M-LB-0813-0863 Active 2056606010P SERIAL LABEL VIEWSONIC BOX STICKER-G 6P12 1
817 M-LB-0813-0530 Active 2055617101P LABEL 10*20 HI-POT TESTED OK 6P13 1
818 E-R-0405-6602 Active 2253215196P RES CHIP 1/10W RC 0603 1/10W 150 ohm J T R248 1
819 E-R-0405-6602 Active 2253215196P RES CHIP 1/10W RC 0603 1/10W 150 ohm J T R249 1
820 E-R-0405-6602 Active 2253215196P RES CHIP 1/10W RC 0603 1/10W 150 ohm J T R250 1
821 E-R-0405-6602 Active 2253215196P RES CHIP 1/10W RC 0603 1/10W 150 ohm J T R408 1
822 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R207 1
823 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R217 1
824 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R219 1
825 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R220 1
826 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R221 1
827 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R222 1
828 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R223 1
829 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R224 1
830 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R226 1
831 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R243 1
832 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R244 1
833 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R246 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

84

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

834 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R308 1
835 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R311 1
836 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R324 1
837 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R326 1
838 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R419 1
839 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R420 1
840 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R436 1
841 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R438 1
842 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R511 1
843 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R534 1
844 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R535 1
845 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R536 1
846 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R537 1
847 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R538 1
848 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R539 1
849 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R553 1
850 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R562 1
851 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R603 1
852 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R604 1
853 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R609 1
854 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R614 1
855 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R618 1
856 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R620 1
857 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R913 1
858 E-R-0405-6600 Active 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R914 1
859 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R112 1
860 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R113 1
861 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R114 1
862 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R133 1
863 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R314 1
864 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R318 1
865 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R321 1
866 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R322 1
867 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R323 1
868 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R329 1
869 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R330 1
870 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R331 1
871 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R422 1
872 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R529 1
873 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R546 1
874 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R605 1
875 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R637 1
876 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R901 1
877 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R907 1
878 E-R-0405-6419 Active 2253247296P RES CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R910 1
879 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R138 1
880 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R225 1
881 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R233 1
882 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R402 1
883 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R414 1
884 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R425 1
885 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R433 1
886 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R434 1
887 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R530 1
888 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R531 1
889 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R548 1
890 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R549 1
891 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R602 1
892 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R615 1
893 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R619 1
894 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R639 1
895 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R642 1
896 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R662 1
897 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R663 1
898 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R903 1
899 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R909 1
900 E-R-0405-6410 Active 2253210296P RES CHIP 1/10W RC 0603 1/10W 1.0Kohm J T R912 1
901 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q101 RD 1
902 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q201 RD 1
903 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q202 RD 1
904 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q206 RD 1
905 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q301 RD 1
906 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q302 RD 1
907 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q401 RD 1
908 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q501 RD 1
909 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q502 RD 1
910 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q601 RD 1
911 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q604 RD 1
912 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q605 RD 1
913 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q901 RD 1
914 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q902 RD 1
915 E-Q-0402-1624 Active 2360301696P XISTOR,NPN R SMD PMBS3904 SOT-23 PHILIPS Q903 RD 1
916 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q101 RG 1
917 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q201 RG 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

85

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

918 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q202 RG 1
919 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q206 RG 1
920 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q301 RG 1
921 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q302 RG 1
922 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q401 RG 1
923 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q501 RG 1
924 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q502 RG 1
925 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q601 RG 1
926 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q604 RG 1
927 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q605 RG 1
928 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q901 RG 1
929 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q902 RG 1
930 E-Q-0402-1608 Active 2360300896P XISTOR,NPN R SMD MMBT3904K SOT-23 FAIRCHILD Q903 RG 1
931 E-Q-0402-1607 Active 2360100796P XISTOR,PNP R SMD MMBT3906-F SOT-23 DIODES Q203 RB 1
932 E-Q-0402-1607 Active 2360100596P XISTOR,PNP R SMD MMBT3906-NL SOT23 FAIRCHILD Q203 RC 1
933 E-Q-0402-1607 Active 2360100796P XISTOR,PNP R SMD MMBT3906-F SOT-23 DIODES Q205 RB 1
934 E-Q-0402-1607 Active 2360100596P XISTOR,PNP R SMD MMBT3906-NL SOT23 FAIRCHILD Q205 RC 1
935 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q101 RE 1
936 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q201 RE 1
937 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q202 RE 1
938 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q206 RE 1
939 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q301 RE 1
940 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q302 RE 1
941 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q401 RE 1
942 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q501 RE 1
943 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q502 RE 1
944 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q601 RE 1
945 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q604 RE 1
946 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q605 RE 1
947 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q901 RE 1
948 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q902 RE 1
949 E-Q-0402-1180 Active 2360301296P XISTOR,NPN R SMD MMBT3904-F SOT23 DIODES Q903 RE 1
950 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q101 RC 1
951 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q201 RC 1
952 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q202 RC 1
953 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q206 RC 1
954 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q301 RC 1
955 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q302 RC 1
956 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q401 RC 1
957 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q501 RC 1
958 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q502 RC 1
959 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q601 RC 1
960 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q604 RC 1
961 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q605 RC 1
962 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q901 RC 1
963 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q902 RC 1
964 E-Q-0402-1087 Active 2360301896P XISTOR,NPN R SMD MMBT3904LT1 SOT23 LRC Q903 RC 1
965 E-L-0407-0013 Active 2379101495P FERRITE CORE 3.5*9*0.8 L414 1
966 E-L-0407-0013 Active 2379101495P FERRITE CORE 3.5*9*0.8 L415 1
967 E-L-0407-0013 Active 2379101495P FERRITE CORE 3.5*9*0.8 L903 1
968 E-L-0407-0013 Active 2379101495P FERRITE CORE 3.5*9*0.8 L907 1
969 E-IC-0401-2924 Active 2365808196P IC,LINEAR(SMD) AP1117E33LA SOT-223 AnaChip I202 RA 1
970 E-D-0403-2808 Active 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D108 RA 1
971 E-D-0403-2808 Active 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D109 RA 1
972 E-D-0403-2808 Active 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D110 RA 1
973 E-D-0403-2808 Active 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D111 RA 1
974 E-D-0403-2808 Active 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D114 RA 1
975 E-D-0403-2808 Active 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D115 RA 1
976 E-D-0403-2808 Active 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D117 RA 1
977 E-D-0403-1892 Active 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D112 RC 1
978 E-D-0403-1892 Active 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D113 RC 1
979 E-D-0403-1892 Active 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D201 RC 1
980 E-D-0403-1892 Active 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D202 RC 1
981 E-D-0403-1892 Active 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D301 RC 1
982 E-D-0403-1779 Active 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D108 RB 1
983 E-D-0403-1779 Active 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D109 RB 1
984 E-D-0403-1779 Active 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D110 RB 1
985 E-D-0403-1779 Active 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D111 RB 1
986 E-D-0403-1779 Active 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D114 RB 1
987 E-D-0403-1779 Active 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D115 RB 1
988 E-D-0403-1779 Active 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D117 RB 1
989 E-C-0404-4423 Active 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J T C506 1
990 E-C-0404-4423 Active 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J T C509 1
991 E-C-0404-4423 Active 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J T C515 1
992 E-C-0404-4225 Active 2346139296P CAP,CHIP 125'C CS 0603/X7R/50V 3900p K T C691 1
993 E-C-0404-3898 Active 2341110096P CAP,CHIP 125'C CS 0603/COG/50V 10 p J T C510 1
994 E-C-0404-3898 Active 2341110096P CAP,CHIP 125'C CS 0603/COG/50V 10 p J T C511 1
995 E-C-0404-3898 Active 2341110096P CAP,CHIP 125'C CS 0603/COG/50V 10 p J T C512 1
996 E-C-0404-3096 Active 2335310812P CAP,ELE LOW ESR 105'C EC 1000u/ 16V 10*20 P=5.0 K C470 1
997 E-C-0404-3096 Active 2335310812P CAP,ELE LOW ESR 105'C EC 1000u/ 16V 10*20 P=5.0 K C903 1
998 E-C-0404-3096 Active 2335310812P CAP,ELE LOW ESR 105'C EC 1000u/ 16V 10*20 P=5.0 K C913 1

999 E-C-0404-3096 Active 2335310812P CAP,ELE LOW ESR 105'C EC 1000u/ 16V 10*20 P=5.0 K C917 1
1000 E-C-0404-3096 Active 2335310812P CAP,ELE LOW ESR 105'C EC 1000u/ 16V 10*20 P=5.0 K C928 1
1001 E-00008040 Active 2365104000P MEMORY IC 24LC22A-I/P PDIP-8 MICROCHIP I101 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

86

Item ViewSonic P/N STATUS Ref. P/N Location Universal number# Q'tyDescription

1002 E-00005508 Active 2212008800P LCD PANEL V270B1-L01 (A GRADE) WXGA CMO V901 1
1003 E-00003954 Active 2416901800P UV TUNER TAPE-S701D (J) LG I501 1
1004 E-00003830 Active 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D112 RD 1
1005 E-00003830 Active 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D113 RD 1
1006 E-00003830 Active 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D201 RD 1
1007 E-00003830 Active 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D202 RD 1
1008 E-00003830 Active 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D301 RD 1
1009 E-00003534 Active 2363600696P DIODE,SWITCH RLS4148-T11 SOD80C ROHM D112 RA 1
1010 E-00003534 Active 2363600696P DIODE,SWITCH RLS4148-T11 SOD80C ROHM D113 RA 1
1011 E-00003534 Active 2363600696P DIODE,SWITCH RLS4148-T11 SOD80C ROHM D201 RA 1
1012 E-00003534 Active 2363600696P DIODE,SWITCH RLS4148-T11 SOD80C ROHM D202 RA 1
1013 E-00003534 Active 2363600696P DIODE,SWITCH RLS4148-T11 SOD80C ROHM D301 RA 1
1014 E-00003533 Active 2379520196P BEAD,HI-CURRENT Z= 200 ohm 0805 I=2.0A L408 1
1015 E-00003533 Active 2379520196P BEAD,HI-CURRENT Z= 200 ohm 0805 I=2.0A L409 1
1016 E-00003533 Active 2379520196P BEAD,HI-CURRENT Z= 200 ohm 0805 I=2.0A L410 1
1017 E-00003533 Active 2379520196P BEAD,HI-CURRENT Z= 200 ohm 0805 I=2.0A L416 1
1018 E-00003533 Active 2379520196P BEAD,HI-CURRENT Z= 200 ohm 0805 I=2.0A L417 1
1019 E-00003533 Active 2379520196P BEAD,HI-CURRENT Z= 200 ohm 0805 I=2.0A L603 1
1020 E-00003533 Active 2379520196P BEAD,HI-CURRENT Z= 200 ohm 0805 I=2.0A L615 1
1021 E-00003530 Active 2365813796P IC,LINEAR(SMD) TS5V330DBQR SSOP-16 TI I205 RB 1
1022 E-00003529 Active 2360501796P FET,P-CH SMD APM9435KC SO-8 Anpec I404 RC 1
1023 E-00003529 Active 2360501796P FET,P-CH SMD APM9435KC SO-8 Anpec I901 RC 1
1024 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C204 1
1025 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C210 1
1026 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C221 1
1027 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C231 1
1028 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C522 1
1029 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C629 1
1030 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C633 1
1031 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C639 1
1032 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C643 1
1033 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C719 1
1034 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C720 1
1035 E-00000999 Active 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C645 1
1036 E-00000916 Active 2360501596P FET,P-CH SMD AO4405 SO-8 AOS I404 RB 1
1037 E-00000916 Active 2360501596P FET,P-CH SMD AO4405 SO-8 AOS I901 RB 1
1038 E-00000915 Active 2360501196P FET,P-CH SMD AP9435GM SO-8 APEC I404 RA 1
1039 E-00000915 Active 2360501196P FET,P-CH SMD AP9435GM SO-8 APEC I901 RA 1
1040 DC-00008112 Active 2002310592P GUARANT CARD VIEWSONIC N2750W-2G QSG 6P81 1
1041 DC-00008111 Active 2001131610P OWNER GUIDE N2750W-2G VS11404-1G CHINA 6P80 1
1042 CB-00008036 Active 2427751802P CABLE RG59U (M/F) L=1.83M BLACK P952 1
1043 CB-00003425 Active 2427701893P CABLE RCA 3P(Y/R/W) 2562#26 1.8M BLK P954 1
1044 C-00008126 Active 2022266403P CABI BACK JC278XX65E ABS94HB BLACK C 2C01 1
1045 B-00005504 Active 2200227028P PC BOARD ASS'Y FSP212-3F01(J051) SPI U801 RA 1
1046 A-VC-0101-0386 Active 2427501187P I/O CABLE D15/D15 20276(3+6) 1.83M BLACK P961 1
1047 A-00006132 Active 2427130097P AC POWER CORD CHINA WALL 1.83M BLACK P951 1
1048 A-00004438 Active 2419200047P CONT BLOCK N3250W(G) VinewSonic CHINA H901 1

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

87

* Reader’s Response*

Dear Readers:
Thank you in advance for your feedback on our Service Manual, which allows continuous improvement
of our products. We would appreciate your completion of the Assessment Matrix below, for return to
ViewSonic Corporation.

Assessment

A. What do you think about the content of this Service Manual?

Unit Excellent Good Fair Bad

1. Precautions and Safety Notices

2. Specification

3. Front Panel Function Control Description

4. Circuit Description

5. Adjustment Procedure

6. Trouble Shooting Flow Chart

7. Block Diagram

8. Schematic Diagrams

9. PCB Layout Diagrams

10. Exploded Diagram And Exploded Parts List

11. Recommended Spare Parts List

B. Are you satisfied with this Service Manual?

Item Excellent Good Fair Bad

1. Service Manual Content

2. Service Manual Layout

3. The form and listing

C. Do you have any other opinions or suggestions regarding this service manual?

Reader’s basic dada:

Name: Title:
Company:
Add:
Tel: Fax:
E-mail:

After completing this form, please return it to ViewSonic Quality Assurance in the USA at facsimile
1-909-839-7943. You may also e-mail any suggestions to the Director, Quality Systems & Processes
([e-mail]

)

ViewSonic Corporation Confidential - Do Not Copy N2750w-2G

88
