ViewSonic VE175b-2, VLCDS23895-6W, VLCDS23895-7W Service Manual

Model No. VLCDS23895-6W/7W
17” Color TFT LCD Display
Service Manual
ViewSonic VE175-2
ViewSonic
381 Brea Canyon Road, Walnut, California 91789 USA - (800) 888-8583
VE175b-2
QDI (A2KYYWW00001 ~ 50000 )
(A2UYYWW00001 ~ 50000)
CPT (A2KYYWW50001 ~ 99999 )
(A2UYYWW50001 ~ 99999)
Copyright
Copyright
¤
2003 by ViewSonic Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of ViewSonic Corporation.
Disclaimer
ViewSonic makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranty of merchantability or fitness for any particular purpose. Further, ViewSonic reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of ViewSonic to notify any person of such revision or changes.
Revision History
Revision Date Description Of Changes Approval
1a 17/06/02 Initial Release DCN- 2251 WANGJE
!
!
ViewSonic Corporation
i
Confidential –DoNotCopy
VE175/b-2
Trademarks
ViewSonic is a registered trademark of ViewSonic Corporation. All other trademarks used within this document are the property of their respective owners.
Optiquest is a registered trademark of ViewSonic Corporation.
1b 14/08/03 Revised DCN- 3760 Teddy.Liaw
TABLE OF CONTENTS
2. SPECIFICATIONS ...............................................................................................2
1. PRECAUTIONS AND SAFETY NOTICES..........................................................1
3. FRONT PANEL FUNCTION CONTROL DESCRIPTION.....................................4
4. CIRCUIT DESCRIPTION......................................................................................10
5. ADJUSTING PROCEDURE ................................................................................15
6. TROUBLE SHOOTING FLOW CHART ..............................................................17
7. EXPLODED DIAGRAM........................................................................................21
8. EXPLODED PARTS LIST ...................................................................................23
9. BLOCK DIAGRAM .............................................................................................25
10. SCHEMATIC DIAGRAM.....................................................................................26
11. PCB LAYOUT .....................................................................................................32
12. RECOMMENDED SPARE PARTS LIST..........................................................38
!
!
ViewSonic Corporation
ii
Confidential –DoNotCopy
VE175/b-2
1. Precautions and Safety Notices
1.1. SAFETY PRECAUTIONS
This monitor is manufactured and tested on a ground principle that a user's safety comes first. However, improper use or installation may cause damage to the monitor as well as to the user. Carefully go over the following WARNINGS before installing and keep this guide handy.
WARNINGS:
This monitor should be operated only at the correct power sources indicated on the label on the rear end of the monitor. If you're unsure of the power supply in your residence, consult your local dealer or Power Company.
Do not try to repair the monitor your self as it contains no user-serviceable parts. This monitor should only be repaired by a qualified technician.
Do not remove the monitor cabinet. There is high-voltage parts inside that may cause electric shock to human bodies, even when the power cord is unplugged.
Stop using the monitor if the cabinet is damaged. Have it checked by a service technician.
Put your monitor only in a clean, dry environment. If it gets wet, unplug the power cable immediately and consult your service technician.
Always unplug the monitor before cleaning it. Clean the cabinet with a clean, dry cloth. Apply non-ammonia based cleaner onto the cloth, not directly onto the glass screen.
Keep the monitor away from magnetic objects, motors, TV sets, and transformer.
Do not place heavy objects on the monitor or power cord.
1.2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this chassis have special safety visual inspections and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltages, wattage, etc. Before replacing any of these components read the parts list in this manual carefully. The use of substitute replacement parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, or other hazards.
1.3. SERVICE NOTES
1. When replacing parts or circuit boards, clamp the lead wires around terminals before soldering.
2. When replacing a high wattage resistor (more than 1W of metal oxide film resistor) in circuit board, keep the resistor about 5mm away from circuit board.
3. Keep wires away from high voltage, high temperature components and sharp edges.
4. Keep wires in their original position so as to reduce interference.
5. Usage of this product please refers to also user's manual.
!
!
ViewSonic Corporation
1
Confidential –DoNotCopy
VE175/b-2
2. Specification
2.1. PRODUCT SPECIFICATIONS
LCD Panel 17.0" TFT Power Management Energy Star compliant VESA DPMS compatible < 2W Displayable Resolution SXGA 1280× 1024 (max.) Pixel Dimension 0.264(H)× 0.264(V)mm LCD Display Color 16.2M Color Max. (6bit + FRC) Viewing Angle CR≧10 Horizontal: 70°+70° Vertical: -65°+65° Tilt +90°, -3° Contrast Ratio 450 : 1 (typ.) 360:1 (m i n.) Brightness 240 cd/ m
2
(min.)
300 cd/m2 (typ.) Response Time Tr: 9 ms Tf: 16 ms (typ.) Tr: 18 ms Tf: 32 ms (max.) Active Display A rea 337.920mm(H)× 270.336mm(V ) Temperature Operating: 0°C ~ +40°C Storage: -20°C ~ +60°C Compliance UL 1950, cUL, EN60950, FCC-B, CE MARK, TÜV/GS, TCO99, CB. Power Input Voltage: 100~240 Vac Consumption: 50 Watts (Max.)
2.2. FACTORY SUPPORTING MODES
Primary Preset: VESA 1280 x 1024 @ 60Hz Look up table timing: 1. IND 640 x 350 @ 70Hz, 31.47kHz, -/+
2. IND 720 x 400 @ 70Hz, 31.467kHz, +/-
3. VESA 640 x 480 @ 60Hz, 31.469kHz, -/-
4. VESA 640 x 480 @ 72Hz, 37.861kHz, -/-
5. VESA 640 x 480 @ 75Hz, 37.5kHz, -/-
6. MAC 640 x 480 @ 67Hz, 35kHz.
7. VESA 800 x 600 @ 56Hz, 35.156kHz, +/+
8. VESA 800 x 600 @ 60Hz, 37.879kHz, +/+
9. VESA 800 x 600 @ 72Hz, 48.077kHz, +/+
!
!
ViewSonic Corporation
2
Confidential –DoNotCopy
VE175/b-2
10. VESA 800 x 600 @ 75Hz, 46.875kHz, +/+
11. MAC 832 x 624 @ 75Hz, 49.725kHz.
12. VESA 1024 x 768 @ 60Hz, 48.363kHz, -/-
13. VESA 1024 x 768 @ 70Hz, 56.476kHz, -/-
14. VESA 1024 x 768 @ 72Hz, 58.036kHz, -/-
15. VESA 1024 x 768 @ 75Hz, 60.023kHz, +/+
16. MAC 1024 x 768 @ 75Hz, 60.241kHz.
17. VESA 1280 x 1024 @ 60Hz, 63.981kHz, +/+
18. VESA 1280 x 1024 @ 75Hz, 79.976kHz, +/+
19. MAC 1152 x 870 @ 75Hz, 68.6kHz.
2.3. D-SUB CONNECTOR
D-SUB 15 PIN CONNECTOR
SIGNAL LEVEL
CONNECTOR SIGNAL DESCRIPTION
R RED 0.7vp-p(VIDEO) G GREEN 0.7vp-p(VIDEO) B BLUE 0.7vp-p(VIDEO) H H/SYNC TTL positive or negative V V/SYNC TTL positive or negative
SDA DDC1/2B TTL
SCL DDC1/2B TTL
12345
678910
11 12 13 14 15
1.R 6.GND 11.NC
2.G 7.GND 12.SDA
3.B 8.GND 13.H.SYNC
4.NC 9. +5V 14.V.SYNC
5.GND 10.GND 15.SCL
!
!
ViewSonic Corporation
3
Confidential –DoNotCopy
VE175/b-2
Scrolls through menu options and adjusts the displayed control.
Displays, saves changes to, and exits the Main Menu.
Power On/Off
Selects a highlighted control. Also, displays the control screen for the selected control and toggles between control pairs.
Power light
Front Control Panel
Main Menu with OSD controls
3. Front Panel Function Control Description
!
!
ViewSonic Corporation
4
Confidential –DoNotCopy
VE175/b-2
Do the following to adjust the screen image:
1
To display the Main Menu, press button [1].
NOTE: All OSD menus and adjustment screens disappear automatically
after about 30 seconds. This time period is adjustable through the Setup menu and the OSD timeout control described.
2
To highlight a control you want to adjust, press or to scroll up or down the Main Menu.
3
To select the highlighted control, press button [2]. A control screen appears like the example shown below.
4
To adjust the control, press the up or down buttons.
5
To save the adjustments and exit the menu, press button [1] twice.
The following tips may help you optimize your display:
Adjust your computer's graphic card so that it outputs a video signal 1280 x 1024 @ 60 Hz to the LCD display. (Look for instructions on “changing the refresh rate” in your graphic card's user guide.)
If necessary, make small adjustments using H POSITION and V POSITION until the screen image is completely visible
. (The black border around the edge of the screen should barely touch the illuminated “active area” of the LCD display.)
The down arrow decreases Contrast, up arrow increases Contrast.
The line at the bottom of the screen tells you what you can do next: select the Brightness control or Exit.
!
!
ViewSonic Corporation
5
Confidential –DoNotCopy
VE175/b-2
Main Menu Controls
Adjust the menu items shown below by using the up and down buttons.
Control Explanation
Auto Adjust
automatically sizes, centers, and fine tunes
the video signal to eliminate waviness and distortion. Press the [2] button to obtain a sharper image.
NOTE: Auto Adjust works with most common video cards. If this function does not work on your LCD display, then lower the video refresh rate to 60 Hz and set the resolution to its pre-set value.
Contrast
adjusts the difference between the image background
(black level) and the foreground (white level).
Brightness
adjusts background black level of the screen image.
Color Adjust
provides several color options: preset color temperatures and User which allows you to adjust red (R), green (G), and blue (B). The factory setting for this product is 6500K (6500 Kelvin).
User
Individual adjustments for red, green, and blue.
5400K
Adds blue and green to the screen image for a darker
color.
6500K
Adds red to the screen image for warmer white and
richer red. Default setting.
9300K
Adds blue to the screen image for cooler white (used
in most office settings with fluorescent lighting).
1
To select color (R, G or B) press button [2].
2
To adjust selected color, press or .
3
When you are finished making all color adjustments, press button [1] twice.
Information
displays the timing mode (video signal input) coming from the graphics card in your computer. See your graphic card’s user guide for instructions on changing the resolution and refresh rate (vertical frequency).
VESA 1280 x 1024 @ 60 Hz (recommended) means that the resolution is 1280 x 1024 and the refresh rate is 60 Hertz.
!
!
ViewSonic Corporation
6
Confidential –DoNotCopy
VE175/b-2
Image Adjust
The Image Adjust controls are explained below:
H./V. Position adjusts horizontal and vertical position of the
screen image. You can toggle between Horizontal and Vertical by pressing button [2]. Horizontal moves the screen image to the left or to the right. Vertical moves the screen image up and down.
H. Size (Horizontal Size) adjusts the width of the screen image.
Vertical size is automatic with your LCD display.
Fine Tune sharpens focus by aligning the illuminated text and/
or graphic characters. Try the Auto Adjust (see page 9) before using the Fine
Tune control.
Sharpness adjusts the clarity and focus of the screen image.
Setup Menu displays the menu shown below:
The Setup Menu controls are explained below:
Language Select allows you to choose the language used in the
menus and control screens.
Control Explanation
!
!
ViewSonic Corporation
7
Confidential –DoNotCopy
VE175/b-2
Resolution Notifier
advises the optimal resolution to use.
OSD Position allows you to move the on-screen display menus
and control screens.
OSD Timeout sets the length of time an on-screen display
screen is displayed. For example, with a “15 second” setting, if a control is not pushed within 15 seconds, the display screen disappears.
Memory Recall returns adjustments to the original factory
settings if the display is operating in a factory Preset Timing Mode listed in this user guide.
Control Explanation
!
!
ViewSonic Corporation
8
Confidential –DoNotCopy
VE175/b-2
Short Cut Key
Function Key : 5 Key à
: Show OSD Menu or Exit OSD Menu. : Select down or decrease.(-) :Select up or increase(+). : Select Or Enter. : Auto adjust. (When No OSD)
: Power On/Off. + = Power key lock / unlock.
+ = OSD lock / unlock.
+ + = Auto White Balance.
(Remark: recommend to use 5-Disc full white pattern)
+ = Recall Contrast and Brightness. (Don’t show OSD) + + No Signal = Enter Burn in mode
+ + (Power On) = Enter Maintain mode.
!
!
ViewSonic Corporation
9
Confidential –DoNotCopy
VE175/b-2
4. Circuit Description
A. DC-DC CONVERTER
The DC-DC converter converts the 12V input voltage to 5V for panel use, and 3.3V and 1.8V for controller use. It consists of a PWM IC (LM2596), flywheel Diode (B340), buck choke (L108), and capacitor C173.
I102 (LM2596) is a PWM generator working at 150KHz.
Self protection features include a two stage frequency reducing cur rent limit for the output switch and an over temperature shutdown for complete protection under fault condition.
B. Scaling controller
The ADC is used to convert RGB analog signal to digital signal that scaling chip can acknowledge. The HSYNC input receives a logic signal and provides the frequency reference for pixel clock generation. The scaling IC converts the input signal ranging from VGA to SXGA into SXGA resolution that panel can acknowledge. When power is first applied, the ADE3XXX is asynch ronou sly reset. The u C typically prog rams the ADE3XXX with a number of default values and sets up the ADE3XXX to identify activity on any of the input pins. All preconfigured values and RAMs, such as line-lock PLL settings, OSD characters, LCD timing values (output sequencer), scale kernels, gamma curves, sRGB color warp, APC dithering, output pin configuration (OMUX), etc. can be preloaded into the ADE3XXX. The typical end state is that the ADE3XXX is initialized into a low power mode, ready to turn active once the power button is pressed. When the monitor has been powered on, the inputs can be monitored for active video sources. Based on the activity monitors, the uC choo ses an input or power down state. Once an input source is selected, all available information on frequencies and line/pixel counts is measured for the selected source and made available to the uC.
MTV312M64
The MTV312M micro-controller is an 8051 CPU core embedded device especially tai lor ed for CRT/LCD Monitor applications. It includes an 8051 CPU core, 1024-byte SRAM, 14 built-in PWM DACs, VESA DDC interface, 4-channel A/D converter, and a 64K-byte internal program Flash-ROM. A “CMOS output pin” means it can sink and drive at least 4mA current. It is not recommended to use such pin as input function. An “open drain pin” means it can sink at least 4mA current but only drive 10~20uA to VDD. It can be used as input or output function and needs an external pull up resistor. A “8051 standard pin” is a pseudo open drain pin. It can sink at least 4mA current when output is at low level and drive at least 4mA current for 160nS when output transits from low to high, then keep driving at 100uA to maintain the pin at high level. It can be used as input or output function. It needs an external pull up resistor when driving heavy load devices.
POWER CONFIGURATION
The MTV312M can work on either 5V or 3.3V power supply system. In 5V power system, the VDD pin is connected to 5V power and the VDD3 needs an external cap acitor, all output pins can swing from 0~5V, input pins can accept 0~5V input range. The ADC conversion range is 5V. However, X1 and X2 pins must be kept below 3.3V. In 3.3V power system, the VDD and VDD3 are connected to 3.3V power, all output pins swing from 0~3.3V, HSYNC, VSYNC and open drain pin can accept 0~5V input range, other pins must be kept below 3.3V. The ADC conversion range is 3.3V.
C. INVERTER
In order to drive the CCFLs embedded in the panel module, there is a ROYER inverter to convert the input 12V up to hundreds of AC voltage output. The inverter is formed by symmetric circuitry, in order to drive the separate lamp modules. The input stage consists of a PWM controller, buck choke, and switching MOSFET to convert DC input into AC output. The output stage consists of a tuning capacitor, transformer, and push-pull transistor pair to boost ac output up to hundreds of voltage. There is also one resister in series with the lamp for output current feedback. A 6-pin connector is the only interface to control the inverter. Pin 5/6 is 12V input, pin 1/2 is the returns, pin 3 is the control of output current, and pin 4 is the enable/disable control.
!
!
ViewSonic Corporation
10
Confidential –DoNotCopy
VE175/b-2
5. Adjusting Procedure
5.1. ADJUSTMENT CONDITIONS AND PRECAUTIONS
1. Approximately 30 minutes should be allowed for warm up before proceeding.
2. Adjustments should be undertaken only on those necessary elements since most of them have been carefully preset at the factory.
3. ESD protection is needed before adjustment.
5.2. MAIN ADJUSTMENTS
NO. FUNCTION DESIGNATION
1. WHITE BALANCE FUNCTION KEY
2. GEOMETRY FUNCTION KEY
5.3. ALIGNMENT PROCEDURES
Adjustment Conditions and Precautions:
(A). Power supply voltage:
AC 110/120V±10% 60 Hz±5%, AC 220/240V±10% 50 Hz±5%.
(B). Warm up time:
The display must be powered ON for at least 30 minutes at full white pattern before starting alignments. This is especially critical in color temperature and white balance adjustments.
(C). Signals: reference the front detail specifications and timing table.
Video: reference the front detail specifications.
1. Adjustment of White Balance:
A. TIMING: 1280x1024 64KHz/60Hz. B. PATTERN: 5 Blocks. C. LCD MONITOR set to 1280x1024 80K/75Hz BURN IN and warm up over 30 minutes. D. CA110 color analizer at the center of screen and along a perpendicular to the screen at 20cm from the
display.
E. Power turn off, Press
“▲” and “
and turn on power at the same time after power LED is on,
release
“▼” and “
key, Then press “ ” key go to factory mode. (Fig.1)
F. Adjust Color Temperature:
(1) EEPROM INIT (5 BLOCKS): Press “▼” key move cursor to EEPROM INIT, Press “ “ key then monitor will INIT ADC value.
2
(Fig.1)
1
2
2
!
!
ViewSonic Corporation
11
Confidential –DoNotCopy
VE175/b-2
(2) Press “▲” key move cursor to “White Balance”, Press “ “ key for white balance
adjustment.
(3) Press “▼” key move cursor to “Color Temerature Adjust”, Press “ “ key, Then OSD will display Fig. 2
(4) 9300K verify: move cursor to 9300K Press “ “ key. Press “▼” ,“▲” key adjust R.G.B value x=0.283
±
0.03
y=0.298
±
0.03
Press “ “ key return to Fig.2
(5) 6500K verify: Repeat (4) press “▼” ,“▲” move cursor to 6500K press “ “ key x=0.310
±
0.03
y=0.330
±
0.03
Y
240 cd/m
2
(6) 5400K verify: Repeat (4) press “▼” ,“▲” move cursor to 5400K press “ “ key x=0.332
±
0.03
y=0.348
±
0.03
(7) Press “ “ key go back to Fig.2, Then press “ “ key return to Fig.1, Power key OFF/ON quit factory mode.
G. Color Temperature & Luminance Verify: BRIGHTNESS MAX, CONTRAST MAX 9300K: x=0.283
±
0.03 y=0.298 ±0.03
6500K: x=0.310
±
0.03 y=0.330 ±0.03 Y≧240 cd/m
2
5400K: x=0.332
±
0.03 y=0.348 ±0.03
2. Geometry:
(a). Set cross-hatch pattern and preset timing as timing table listed.
(b). Change to each mode in turn and wait for the monitor finish auto-alignment and save process before
change to next mode.
(c). After all of modes are adjusted, exit OSD menu and press PWR OFF to exit factory mode.
2
2
(Fig.2)
2
1
2
2
1
1
!
!
ViewSonic Corporation
12
Confidential –DoNotCopy
VE175/b-2
< How to use Myson ISP tool >
1. Install the “Myson ISP S/W”
2. Create a security file when you run “ISP tool” first time.
Choose 8 commands and enter the security code.
Security code: 7C , 7C , 5A , 39 , 31 , 30 , 31 , 30, 33
3. Choose ‘MCU type”
We use MTV312M64
4. Load MCU file Choose the Hex file that you’re going to load.
5.4. ISP MODE
!
!
ViewSonic Corporation
13
Confidential –DoNotCopy
VE175/b-2
You need to reload the hex file after you change its contents.
5. Before loading the code into MCU, you need to check following: a. AC power On b. S/W power is OFF ( This makes you easy to enter ISP mode ) c. D-Sub cable has been connected to ISP board correctly.
6. DO NOT disconnect D-sub cable or power off while you’re loading the code.
7. You can adjust ISP speed to meet your PC.
8. Hardware Connect
Print Port
ISP Board
D-sub I/O Cable
IBM Compatible PC
LCD Monitor
!
!
ViewSonic Corporation
14
Confidential –DoNotCopy
VE175/b-2
6. TROUBLE SHOOTING FLOW CHART
6.1. NO POWER
Check AC TO DC
PCB
F801,D810~D813
N
Y
Start
Check 12V
on C170/+
Replace
AC TO DC PCB
N
Y
Check 5V
on C173/+
Check
12V to 5V CKT
N
Y
Check
3.3V/1.8V
Check
3.3V/1.8V to GND
N
Y
Check
pin 8 of I108
+5V_MCU
Check
Q107,Q108
R210~R212
N
Replace
Main Board
N
!
!
ViewSonic Corporation
15
Confidential –DoNotCopy
VE175/b-2
6.2. MCU NO FUNCTION
N
Y
CHECK
C239
MCU 5V
OK?
CHECK
Q108,Q107
OK?
CHECK
I108 PIN7,PIN9
5V?
N
CHECK
R190,C219
OK?
Y
CHECK
12MHz PIN11,PIN12
OK?
N
CHECK
X102,C222,C223
OK?
Y
CHECK PIN13,PIN14 CLOCK OK?
N
CHECK
I108 TO I101
OK?
Y
CHECK
I108,EVERY TWO
PIN SHORT?
N
CHECK
KEYPAD P105
OK?
N
Replace
Main Board
N
Replace
Keypad
!
!
ViewSonic Corporation
16
Confidential –DoNotCopy
VE175/b-2
6.3. NO DISPLAY
Power key
work ok
Y
Check
DVDD_3.3
N
Check
I103
H/V sync
on pin 54,55
of I101
Check
pin 10,12 of I108
N
Y
Check R124
Check R.G.B. in
DATA
Check R.G.B.
input
N
Check
key-pad
Y
N
Check
P983
N
refer to
no power
Y
Check
pin 3,4 of P104
N
Replace
I101
Y
Check
I/O cable
N
Check
FPCLK,FPDE,
PFVS,PFHS
Y
Check
X101
N
Check R158 high Check Q104
N
Y
Check R156
Voltage Range
Check Q101
N
Y
Invertor unit
failed
Replace
Y
Y
!
!
ViewSonic Corporation
17
Confidential –DoNotCopy
VE175/b-2
6.4. MISSING COLOR
Some bits
lost
Y
Check
RP1~RP12
I101,I106,I107
poor
soldering
N
Y
RP1~RP12
poor
soldering
Lose color
R or G or B
Y
Check
P104
Pin 8,10,12
Check your
PC or soldering
N
Y
Check
L120,L121,L122 R122,R125,R127 R128,R129,R130
Poor
soldering
N
Y
I101
fail or
poor soldering
!
!
ViewSonic Corporation
18
Confidential –DoNotCopy
VE175/b-2
X44645
42
29
X230
44
X347
39
43
X4
49
48
38
37
41
36
35
31 X2
X4
40
12
P953
X213
14
I/O CABLE
20
18
6
X2
7
X2
16 X2
18
27
26
V901
5
17
X6
9 X4
2
1
19
3
4
X2
36
22
28
23
X2
15 X2
X4
8
21
10
11
FIG.1
FIG.2
FIG.2
FIG.1
MAIN PCB ASS'Y
24
25
FIG.3
FIG.3
U901
50
52
I801
D804
53
POWER PCB ASS'Y
FIG.4
51
CON. PCB ASS'Y
FIG.4
6 X2
32
32
33
X3
33 X3
34
7. Exploded Diagram
!
!
ViewSonic Corporation
19
Confidential –DoNotCopy
VE175/b-2
MAIN PCB
POWER PCB
TO:METAL FITTG GND
P801
JT178/188A 2202118700 VER:1.00
INVERTER PCB
J2
J1
J3
P802
P803
P983
P802
LCD PANEL
P981
P701
KEYPAD PCB
2202120100 V:0.02
P982
AC SOCKET ASS'Y
N
(BLU) (BRN)
L
P953
P105
P101
P102
P104
P103
P961
I/O CABLE
!
!
ViewSonic Corporation
20
Confidential –DoNotCopy
VE175/b-2
Item ViewSonic P/N Ref. P/N
ocationQ'TY Remark
1-1 C-FP-0301-0934 2024263002
FRONT BEZEL PC+ABS 94 V0 GY7521
1F01 1
VE175-2
1-2 C-FP-0301-0153 2024263004
FRONT BEZEL PC+ABS 94V0 MIDNIGHT GRAY
1F01 1
VE175b-2
2 M-MS-0808-8180 2053751901
LED INDIC.-PWR VE150-2/PMMA 94HB
1F02 1
3-1 PL-FK-0707-0137 2044260901
FUNCTION KEY VE150-2/ABS 94V0 GY7521
1F03 1
VE175-2
3-2 PL-BT-0706-0147 2044260904
FUNCTION KEY ABS 94V0 MIDNIGHT GRAY
1F03 1
VE175b-2
4 M-SCW-0824-0122 2084730102
SCREW,BND T+ M3X10(BND T+)
1F04 2
5 M-BK-0805-0009 2071961402
METAL FITTG SECC T=1.0 VE175(2) ST
1F05 1
6 M-SCW-0824-6715 2080002200
SCREW,SPE L355 M3x6 DH NICKEL-PLATED
1F06 4
7 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F07 2
8 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F08 4
9 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F09 4
10 M-MS-0808-1420 2071663201
SHIELD PLATE SPTE t=0.3(Main board-ST)
1F10 1
11 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F11 1
12 M-BK-0805-0008 2071960201
METAL FITTG SECC t=0.8 NON-P.S.M
1F12 1
13 M-SCW-0824-6716 2080002400
SCREW,SPE VE155/3x8 STAND
1F13 2
14 M-SCW-0824-0493
2085740082 SCREW,B OTW+ SCREW B OTW+ M4X8
1F14 1
15 M-SCW-0824-6718 2081430082
SCREW,(WASH) M3X8 P=0.5(TOOTH,WASHER)
1F15 2
16 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F16 2
17 M-SCW-0824-0285 2084730082
SCREW,BND T+ M3X8(BND T+)
1F17 6
18 M-SCW-0824-0123 2084740102
SCREW,BND T+ M4X10(BND T+)
1F18 2
19 M-MS-0808-4026 2051350200
NAME PLATE JD144V3 VIEWSONIC 3BIRDS AL
1F19 1
20-1 M-MS-0808-1619 2063451101
ADHESI SHEET 27.2x42.4 PVC COLOR:GREY
1F20 1
VE175-2
20-2 M-MS-0808-1664 2063451102
ADHESI SHEET 27.2x42.4 PVC COLOR:BLACK
1F20 1
VE175b-2
21 M-MS-0808-8182 2072452601
INSULATOR VE800 PC FR-700 0.2t FOR POWER
1F21 1
22 M-MS-0808-1389 2071662800
SHIELD PLATE SPTE t=0.3mm VE175
1F22 1
23 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F23 2
24 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F24 1
25 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F25 1
26 M-BK-0805-0006 2071859600
BRACKET,FIX SECC t=1.0mm VE175
1F26 1
27 M-BK-0805-0007 2071859700
BRACKET,FIX SECC t=1.0mm VE175
1F27 1
28 PL-HD-0705-0116 2074191000
HOLDER JK1461 JEAN
1F28 1
29 M-BK-0805-0004 2071859200
BRACKET,FIX SECC t=1.0
1F29 1
30 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F30 2
31 M-SCW-0824-0123 2084740102
SCREW,BND T+ M4X10(BND T+)
1F31 2
32 M-BK-0805-0002 2071864900
BRACKET,FIX SECC T=1.2MM VE175-2
1F34 2
33 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
1F35 6
34 M-SCW-0824-0261 2084730142
SCREW,BND T+ M3X14(BND T+)
1F70 1
35-1 C-BC-0302-0409 2022259202
CABI BACK PC+ABS 94 V0 GY7521
2C01 1
VE175-2
35-2 C-BC-0302-0410 2022259205
CABI BACK PC+ABS MIDNIGHT GRAY NON-STAMP
2C01 1
VE175b-2
36-1 M-SCW-0824-0123 2084740102
SCREW,BND T+ M4X10(BND T+)
2C03 2
VE175-2
36-2 M-SCW-0824-0123 2084740102
SCREW,BND T+ M4X10(BND T+)
2C03 2
VE175b-2
37-1 M-MS-0808-1364 2026252601
CASE ABS 94 HB GY7521
2C04 1
VE175-2
37-2 M-MS-0808-1074 2026252603
CASE ABS 94HB MIDNIGHT GRAY
2C04 1
VE175b-2
38 M-SCW-0824-0123 2084740102
SCREW,BND T+ M4X10(BND T+)
2C05 1
39 M-MS-0808-1314 2106653500
HINGE TORQUE 20~60 KGF -5'~90'
2C20 1
40 M-SCW-0824-6717 2081430062
SCREW,(WASH) M3X6 P=0.5(TOOTH WASHER)
2C21 4
41-1 M-SCW-0824-0285 2084730082
SCREW,BND T+ M3X8(BND T+)
2C22 1
VE175-2
41-2 M-SCW-0824-0416 2084730084
SCREW,BND T+ M3X8(BND T+) (BLK)
2C22 1
VE175b-2
42-1 PL-PS-0715-0186 2028254801
STAND VE800 ABS 94HB/GY7521
5B01 1
VE175-2
42-2 PL-PS-0715-0187 2028254803
STAND ABS 94HB MIDNIGHT GRAY
5B01 1
VE175b-2
43-1 PL-PD-0714-0058 2039802301
FOOT PAD CR 420xφ16.5x5.8
5B02 4
VE175-2
43-2 PL-PD-0714-0058 2039802301
FOOT PAD CR 420xφ16.5x5.8
5B02 4
VE175b-2
44 M-SCW-0824-6719 2082630062
SCREW M3X6 P=0.5
5B03 1
45 M-SCW-0824-6722 2087340106
SCREW,B SPW+ 4X10(+)SWRM-3 ZMC2-C
5B05 4
46 M-BK-0805-0003 2071859301
BRACKET,FIX VE800 SECC 2.0t FOR STAND
5B06 1
47 M-SCW-0824-6721 2084740082
SCREW,BND T+ M4X8(BND T+)
5B07 3
48-1 M-MS-0808-1362 2027255301
DUST COVER VE800 ABS 94HB/GY7521 STAND
5B08 1
VE175-2
48-2 M-MS-0808-1315 2027255303
DUST COVER ABS 94HB MIDNIGHT GRAY
5B08 1
VE175b-2
49 M-SCW-0824-0123 2084740102
SCREW,BND T+ M4X10(BND T+)
5B09 1
50 M-MS-0808-8181 2072258300
HEAT SINK JT178S AL 6063S 45Wx20Dx22H
9H01 1
51 M-MS-0808-8181 2072258300
HEAT SINK JT178S AL 6063S 45Wx20Dx22H
9H02 1
52 M-SCW-0824-0285 2084730082
SCREW,BND T+ M3X8(BND T+)
9S01 1
53 M-SCW-0824-0285 2084730082
SCREW,BND T+ M3X8(BND T+)
9S02 1
54-1
M-LCD-0826-0197 2212003610
LCD PANEL CLAA170EA02VG CPT V901
1
CPT
54-2
M-LCD-0826-0196 2212003900
LCD PANEL QD17EL07 QUANTA V901
1
55-1
B-SB-0221-0290 2414500400
INVERTER PLCD07174 LINK COM U901
1
for CPT Panel
55-2
B-SB-0221-0434 2414501000
INVERTER DIVTL0058-D42 SAMPO U901
1
for CPT Panel (2nd Source)
55-3
B-SB-0221-0002 2414502100
INVERTER JT178P93 EMAX U901
1
for QDI Panel
55-4
B-SB-0221-0597 2414502200
INVERTER DIVLJK0221D42- SAMPO U901
1
for QDI Panel (2nd Source)
56
M-MS-0808-9164 2407000100
SOCKET,ASSY AC INLET ASS'Y 1015#18 L=130 P953
1
57
M-WR-0828-6624 2427412710
WIRE HARNESS 4/5P H/B 1007#20 160L+CORE P802
1
58-1
A-VIO-0118-0025 2427501149
I/O CABLE D15/C13 2919(3+6)1.83M GE96750 P961
1
VE175-2
58-2
A-VIO-0118-0035 2427501164
I/O CABLE D15/C13 2919(3+6) 1.83M BLK P961
1
VE175b-2
59
M-WR-0828-6625 2427430131
WIRE HARNESS 30P JAE F1/15*2P 1571#28 130L P981
1
60
M-WR-0828-6626 2427408181
WIRE HARNESS 8P H/B 1061#26 L=180mm P=2.0 P982
1
61
M-WR-0828-6627 2427412624
WIRE HARNESS 6P(2.0) H/H 1007#24+112C 350L P983
1
Exploded Parts List (VE175-2/VE175b-2 QDI & CPT Panel)
Description
8. Exploded Parts List
!
!
ViewSonic Corporation
21
Confidential –DoNotCopy
VE175/b-2
9. Block Diagram
AC-DC
POWER
AC INPUT 12V
DC-DC
CONVERTER
I102,D101,L108
5V
REGULATOR
I103
3.3V
INVERTER
U901
VGA INPUT
P104
CONTROLLER IC
I101
Micro
CONTROLLER
DDC I108
KEY PAD
&
LED
PANEL
DISPLAY
HIGHT
VOLTAGE
OSC
X102
EERROM
I109
LVDS
INTERFACE
I106,I107
12V
REGULATOR
I104
1.8V
!
!
ViewSonic Corporation
22
Confidential –DoNotCopy
VE175/b-2
INTERNAL ADC REFERENCE RESISTORS AND DECOUPLING CAPACITORS. PLACE THESE COMPONENTS CLOSE TO THEIR RESPECTIVE PINS
PLACE CAPACITORS C111, C112, AND C113 ON PINS 14, 38, AND 42, RESPECTIVELY (TMDS power supply pins)
PLACE CAPACITORS C114, C115, C116, C117, C118, C119, AND C120 ON PINS 15, 19, 22, 25, 29, (31 & 32), AND 40, RESPECTIVELY (TMDS power supply pins)
AGND
DGND
AGND and DGND are isolated, not completely separated Place near PAD1
XCLK_EN 0:xclk o/p
disable
1:xclk o/p
active
Sync RA
GA BA
BB
GB
RB
* Same VIA # * Similar length
1 52
104
GND splitting
AGND
DGND
ADE3000
Indicate Pin# at every 5/10 pins 5 : short line 10 : long line 1,53,105 &157 should be labeled
0805
NEW SCALER CEJ....
REFPB
OGA0
ORA2
REFPG
REFR OGA1
ORB6
ORA7
ORA4
REFR
REFMB
OGA7
ORA6
ORB4
OBA6
OBA4
OBA1
OBB4
OGB5
REFMR
ORA1
OBB5
ORB3
ORB0
REFMG
REFMG
OBA3
OGB7
ORB5
ORB1
OBA0
ORA0
AGND
REFB
REFCR
OGA4
OBB1
REFCG
OBB3
OGB3
REFCG
REFCB
OGA2
OGB1
OBA2
OBB2
OGB4
ORB7
REFG
OBA7
REFCR
REFMB
REFPR
REFPB
OBA5
OGA6
OGA3
ORA3
OBB6
OBB0
OGB6
OGB2
REFPR
OGB0
ORB2
REFCB
REFMR
REFG
ORA5
REFB
REFPG
OGA5
OBB7
DGND
ORB[7:0] [5]
OGB[7:0]
[5]
OBA[7:0] [5]
OGA[7:0] [5]
ORA[7:0] [5]
OBB[7:0] [5]
INR[4] ING[4] INB[4]
AVSYNC[4]
AHSYNC[4]
ADE-RESET#[6]
ADE-SCL[6]
OHS
[5]
OVS
[5]
ADE-SDA[6]
ODE
[5]
OCLK [5]
AVDD_1.8 LVDD_1.8 XVDD_1.8
AVDD_1.8
DVDD_3.3
AVDD_3.3
RVDD_3.3
DVDD_1.8 AVDD_1.8
XVDD_1.8
PVDD_1.8
LVDD_1.8
LVDD_1.8
DVDD_3.3 PVDD_1.8AVDD_3.3 AVDD_3.3
AVDD_1.8
AVDD_3.3
DVDD_1.8
C136
0.1uF
C131
0.1uF
C137
0.1uF
C126
0.1uF
C128
0.1uF
C133
0.1uF
I101
ADE3XXX
PQFP208
1
2
3
4
5
6
7
8
9
10 11
12
16 17 20 21 23 24 27 28
30 36
48 49
53
54
55
63
64
65
68
71
75
76
77
80
83
87
88
89
92
95
99
102
103
104
106
107
108
109
110
113
114
115
116
117
118
119
120
121
126
127
128
129
130
131
132
133
136 137
138
139
144
145
146
147
150
151
152
153
154
155
156
157
160
161
162
163
168
169
170
171
174
175
176
177
182
183
184
187
188
189
190
195
196
197
198
203 204
205
206
207
208
100
105
112
122
124
135
141
143
149
159
165
167
173
179
181
186
192
194
200
202
1318263334353739414345
56576062666772787984909196
52
47
123
140
142
164
166
178
180
191
193
199
201
101
111
125
134
148
158
172
185
143842
44
46
61737485869798
15192225293132
40
58596970818293
94
51
50
YUV6
YUV5
YUV4
YUV3
YUV2
YUV1
YUV0
YUVCLK
DVDD18
DGND
DVDD18
DGND
RX2M RX2P RX1M RX1P RX0M RX0P RXCP RXCM
REXT RBIAS
XTAL_IN XTAL_OUT
CSYNC
VSYNC
HSYNC
REFB
REFMB
REFPB
INB
REFCB
REFG
REFMG
REFPG
ING
REFCG
REFR
REFMR
REFPR
INR
REFCR
TST_SCAN
OBA7
OBA6
OBA5
OBA4
OBA3
OBA2
OBA1
OBA0
OGA7
OGA6
OGA5
OGA4
OGA3
OGA2
OGA1
OGA0
DVDD18
ORA7
ORA6
ORA5
ORA4
ORA3
ORA2
ORA1
ORA0
ODE OHS
OCLK
OVS
OBB7
OBB6
OBB5
OBB4
OBB3
OBB2
OBB1
OBB0
OGB7
OGB6
OGB5
OGB4
OGB3
OGB2
OGB1
OGB0
ORB7
ORB6
ORB5
ORB4
ORB3
ORB2
ORB1
ORB0
CLKOUT
CLKIN
TCON_IN
TCON7
TCON6
TCON5
TCON4
TCON3
TCON2
TCON1
TCON0
SCL SDA
XCLK
XCLK_EN
RESETN
YUV7
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DNGD
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
RGND
RGND
RGND
RGND
RGND
RGND
RGND
RGND
RGND
PGND
PGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
LGND
XGND
DVDD18
DVDD18
DVDD18
DVDD18
DVDD18
DVDD18
DVDD18
DVDD18
DVDD18
DVDD18
DVDD18
DVDD33
DVDD33
DVDD33
DVDD33
DVDD33
DVDD33
DVDD33
DVDD33
RVDD18
RVDD18
RVDD18
PVDD18
PVDD18
AVDD18
AVDD18
AVDD18
AVDD18
AVDD18
AVDD18
AVDD18
RVDD33
RVDD33
RVDD33
RVDD33
RVDD33
RVDD33
RVDD33
RVDD33
AVDD33
AVDD33
AVDD33
AVDD33
AVDD33
AVDD33
AVDD33
AVDD33
LVDD18
XVDD18
R105 NC 0603
C125
0.1uF
C135
0.1uF
C109
0.1uF
0603
C130
0.1uF
C110
0.1uF
0603
C129
0.1uF
C127
0.1uF
C118 10nF
C119
0.1uF
C111
0.1uF
0603
L102
0805
BEAD120R
1 2
C158
0.1uF
0603
R104
15K 1% 0603
C122
10uF/16V
R112
NC
0603
R111
1M0603
TP09
1
R204
0R 0805
C154 100pF
R110
0R 0603
R201
0R 0805
C106
0.1uF
C103
0.1uF
R202
0R 0805
R203
0R 0805
C108
0.1uF
C107
0.1uF
C104
0.1uF
C105
0.1uF
R188
0R 0603
R187
0R
0603
C101
10uF/16V
C151
0.1uF
C113 1nF
C152
0.1uF
C115 100pF
C123
10uF/16V
C120 10nF
L103
0603 BEAD100R
1 2
C150
0.1uF
C164
0.1uF
0603
C163 15pF 0603
X101
27MHz Crystal
L101
0805
BEAD120R
1 2
C148
10uF/16V
C160 100pF
0603
C112
0.1uF
C138
0.1uF
0603
C162 10pF 0603
C124
0.1uF
C114 10nF
0603
C157 100pF
0603
C161
0.1uF
0603
C140
0.1uF
C117
1nF
C159
0.47uF
0603
R106
15K 1% 0603
C121
10uF/16V
C156
0.47uF
0603
C145
0.1uF
R108
NC
C102
0.1uF
R102
15K 1% 0603
C139
10uF/16V
C116
0.1uF
C143
0.1uF
C155
0.1uF
0603
C144
0.1uF
C149
0.1uF
C147
0.1uF
C234 1uF
C233 1uF
C232 10uF
C141
0.1uF
R103 NC 0603
C142
0.1uF
R101
NC
R107 NC 0603
C134
0.1uF
C153
0.47uF
0603
C146
0.1uF
C132
0.1uF
10. Schematic Diagrams
10.1. ADE3000SX
!
!
ViewSonic Corporation
23
Confidential –DoNotCopy
VE175/b-2
1Amax
Copper plate Min : 10 x 10 mm
AU 17",CMO 17",CPT 17" USE R209 DELETE L104
CPT 18" USE L104 DELETE R209
DGND
PGND and DGND are isolated, not completely separated
0805
0805
5V
PAN 12V
DGND
PANELPOWER
[6]
DVDD_1.8
DVDD_3.3
+5V
DVDD_3.3
+5V
+12V
AVDD_3.3
AVDD_1.8
VLCD
PAD3 1 2 3 4 5
6
7
8
9
+
C179
47uF/16V M5-16V
12
I104 RC1117-ADJ
SOT252
1
23
ADJ
VOUTVIN
R114 10
C178
0.1uF 0603
PAD4 1 2 3 4 5
6
7
8
9
PAD5 1 2 3 4 5
6
7
8
9
D102
5.6V
1 2
C168
0.1uF
L108 50UH
R119
2.2K
Q103 MMBT3904
C170
470uF/25V
I102
LM2596
1
2
3
4
5
VIN
SW
GND
FB
SHDN
R118 220
I103
AIC1084
3
1
2
INPUT
GND
OUTPUT
L119
BEAD60R
1206
1 2
R113 10K
R207
0.62/2W
PAD2 1 2 3 4 5
6
7
8
9
C167
0.1uF
R208
0.47/2W
D101 B340
R205
470/2W
L132
NC
1206
1 2
C173
1000uF/10V
R121 249 1%
0603
C172
0.1uF
R209
0 R
L131
BEAD60R
1206
1 2
C180
0.1uF 0603
L104
33uH
R120 560
0603
P101
CON4
1 2 3 4
L107
40UH
C177
0.1uF
C165
470uF/25V
Q102
SI9953/SO8
6
5437
81
2
C174
0.1uF
C176 330uF/16V
10.2. DC TO DC Power
!
!
ViewSonic Corporation
24
Confidential –DoNotCopy
VE175/b-2
Analog Input (VGA)
INPUT INTERFACE
Place near CN
Place near CN
R128-130 Place at CN side
Guraded by AGND All the way (From CN to ADE) & >= 12mil
AHSYNC is important signal First Priority with Least VIA TOP side ONLY
AGND Add VIA on AGND
every 10mm
R/G/B
AGND
TB160808B800
L120,L121,L122 from BEAD80R change to 0R for QDI panel
RC-AHSYNC
RC-AVSYNC
RC-AHSYNC
VGA_5V
RC-AVSYNC
DB15-AVSYNC
DB15-AVSYNC
DB15-AHSYNC
DB15-AHSYNCBLUE
GREEN
RED
DB15-SCL DB15-SDA
DDC-SCL [6]
DDC-SDA [6]
AHSYNC [2]
MCU_VS
AVSYNC [2]
MCU_CS
INR
[2]
INB
[2]
ING
[2]
AVDD_3.3
VGA_5V
AVDD_3.3 AVDD_3.3
AVDD_3.3
AVDD_3.3
R139
10K 0603
L127
0603
BEAD100R
1 2
D106 1N4148
1 2
R137
100
0603
L122
0603 0R
1 2
R132
47
0603
P104
1 2 3 4 5 6 7 8 9 10 11 12 13
1 2 3 4 5 6 7 8
9 10 11 12 13
R127 47
R125
47
R122 47
0603
C188 5pF/NC
0603
R124
47
0603
C187
5pF/NC
0603
L121
0603
0R
1 2
C190 5P
0603
R133 33K/NC
0603
D105 1N4148
1 2
R138
100
0603
C184 5P
0603
R126 33K/NC
0603
R123
330
0603
R131
330
0603
R130
75 0603
R135 110
0603
R134
47
0603
C189
5pF/NC
0603
I105B
74LVC14
SO-14
3 4
14
7
I105E
74LVC14
SO-14
11 10
14
7
D108 1N4148
1 2
C191 27P
0603
C192 47pF
C193
47pF/NC
R197
100
0603
I105A
74LVC14
SO-14
1 2
14
7
D104 1N4148
1 2
C182 0.1uF C183 0.1uF
D103
1N4148
1 2
C186 0.1uF
0603
D107 1N4148
1 2
C185 27P
0603
C240
0.1uF
0603
R198
100
0603
TP11
1
TP10
1
R140
10K 0603
D110
1N4148
1 2
D114
1N4148
1 2
R199
100
0603
I105F
74LVC14
SO-14
13 12
14
7
D113 1N4148
1 2
D112 1N4148 1 2
D111 1N4148 1 2
D115 1N4148 1 2
L120
0603
0R
1 2
D119 BAT54C SOT-23
23
1
D117 1N4148
1 2
D116 1N4148 1 2
R128
75 0603
R129
75 0603
D120
5.6V
1 2
10.3. Input Interface
!
!
ViewSonic Corporation
25
Confidential –DoNotCopy
VE175/b-2
OUTPUT INTERFACE
These are CRITICAL signal NO VIA is allowed
3 2
BLON pin : Reset HIGH Place Q104 if inverter is Low active Place R180 if inverter is High active
MMBT3904
1
0805
THE 6 PIN PCB MUST CANCER DELETE
RA0
OGA7
OGA1
OGA0
OGA5
OGA4 OGA6
GA0
OGA3
GA2
OGA2
OBB2
OBB4 OBB5
OBB3
OBB6
OBB0
OBB7
OBB1
ORA7
ORA0
ORA5
ORA2
ORA4
ORA1 ORA3
ORA6
OGB1
GB0
OGB6 OGB7
OGB2
OGB0
OGB3
OGB4 OGB5
ORB1
ORB0
ORB3
ORB4
ORB7
ORB5 ORB6
ORB2
OVS
ODE
OCLK
BA4 BA6
OBA0
OBA6 OBA7
OBA3
OBA4 OBA5
OBA1 OBA2
FPVS
RA2
GB4
BB6
GA4
GB6
BB4
GA6
RA3
GA5 GB5
BA5
BB7BA7
BB5
GB3
GB1
GA3
GB7
GA1
GA7
RA1
FPDE
OHS
BA5
BA0
TXA4
RA3
RA0
TXA3 TXA5
RA4
GA4 GA5
RA6
FPVS
TXA6
RA7
BA4
GA6
BA2
TXA8
RA5
BA7
GA1
GA0
BA6
FPHS
TXA7
TXA2
TXA9
GA3
FPCLK
BA1
GA2
BA3
GA7
FPDE
BB7
GB3 GB5
BB0 BB1
BB6
GB6
GB4
BB2
TXB0
GB1
GB7
TXB8
GB0
LVDSPDN
TXB9
BB4
BB3
RA1 RA2
LVDSPDN
TXA0 TXA1
FPCLK
RA6
RA5 RA7
RA4
BB3
BB1 BB2
BB0
BA1 BA3
BA2
BA0
TXB7
TXB6
BB5
TXB3
TXB2
TXB1
RB3
RB7
RB1
RB6
RB5
RB7 RB1
RB0
RB4
RB3
RB2
RB6
RB2
RB5
RB0
RB4
GB2
GB2
FPCLK
FPVS FPDE
FPHS
FPHS
TXB2
TXA4
TXB3
TXB7
TXA1
TXA8
TXB9
GND
TXA5
TXB4
TXB4
TXB1
TXA9
TXA7
TXB0
TXB8
TXB5
TXA2
GND
GND
TXB6
TXA0
GND
TXB5
TXA6
TXA3
LVDS_STBY[6]
OGA[7:0][2]
OBA[7:0][2]
ORA[7:0][2]
OGB[7:0][2]
OBB[7:0][2]
ORB[7:0][2]
OCLK[2]
ODE[2]
OHS[2]
OVS[2]
BRIGHTNESS[6]
BLON
[6]
DVDD_3.3
DVDD_3.3
VCC_LVDS
VCC_LVDS
VCC_LVDS
VCC_LVDS
VCC_LVDS
VCC_LVDS
+5V
+12V
+5V
VLCD
C212
0603
C199
0.1uF 0603
C200 10nF
0603
L111
BEAD120R
0805
C196
0.1uF 0603
C197
0.1uF 0603
C194
0.1uF 0603
C195
0.1uF 0603
CP02 NC
123
45
678
CP06 NC
123
45
678
R141
10K 0603
C201 1nF
0603
TP16
1
C210
CAP/NC
0603
Q104 MMBT3904
SOT-23
1
3
2
C211
CAP/NC
0603
RP03
22R
RP8SF
1 2 3 4
8 7 6 5
P102
CON6
1
2
3
4
5
6
1
2
3
4
5
6
RP01
22R
RP8SF
1 2 3 4
8 7 6 5
P105
CONN 15x2
1 3
7 19 16 13 11
9 30 28 17 26 23 21
2 4 6 14 18 15 12 10 8 29 27 24 25 22 20
5
1 3
7 9 11 13 15 17 19 21 23 25 27 29
2 4 6
8 10 12 14 16 18 20 22 24 26 28 30
5
C203
0.1uF 0603
C202
0.1uF
0603
CP08 NC
123
45
678
RP05
22R
RP8SF
1 2 3 4
8 7 6 5
C205
0.1uF 0603
CP01 NC
123
45
678
C204
0.1uF 0603
R158
4.7K 0603
RP12
22R
RP8SF
1 2 3 4
8 7 6 5
RP11
22R
RP8SF
1 2 3 4
8 7 6 5
RP09
22R
RP8SF
1 2 3 4
8 7 6 5
RP07
22R
RP8SF
1 2 3 4
8 7 6 5
RP08
22R
RP8SF
1 2 3 4
8 7 6 5
CP09 NC
123
45
678
RP10
22R
RP8SF
1 2 3 4
8 7 6 5
CP10 NC
123
45
678
CP07 NC
123
45
678
+
C166
47uF/25V
L126
BEAD120R
0805
CP04 NC
123
45
678
L113
BEAD120R
0805
C237
0.1uF 0603
C169
0.1uF
RP02
22R
RP8SF
1 2 3 4
8 7 6 5
+
C236
10uF/16V
RP04
22R
RP8SF
1 2 3 4
8 7 6 5
CP11 NC
123
45
678
R174 100/NC
0603
C215
0.1uF 0603
RP06
22R
RP8SF
1 2 3 4
8 7 6 5
R155 1K 0603
Q101
MMBT3904
SOT-23
1
3
2
L125
BEAD120R
CP03 NC
123
45
678
TP141TP15
1
TP121TP13
1
R151 22
0603
R149 22
0603
R148 22
0603
R147 22
0603
R156
2.2K
0603
R159
4.7K
0603
C214
0603
R160 NC 0603
TP17
1
R157
4.7K
0603
R142 0R
0603
CP12 NC
123
45
678
C207
0.1uF 0603
I107
CS5824 TSSOP56
51 52 54 55 56
2
3
4 6 7
8
10
11 12 14
15
16 18
19 20 22
31
32 48
47 46 45 42 41
40 39
44 49
43 36
34 35
33
5
13
21
29
53
1917
26
50
23 24
25 27 28 30
38 37
TXIN0 TXIN1 TXIN2 TXIN3 TXIN4
TXIN5
TXIN6
TXIN7 TXIN8 TXIN9
TXIN10 TXIN11
TXIN12 TXIN13 TXIN14
TXIN15
TXIN16 TXIN17
TXIN18 TXIN19 TXIN20
TXCLKIN
PWRDWN
TXOUT0-
TXOUT0+
TXOUT1-
TXOUT1+
TXOUT2-
TXOUT2+
TXCLKOUT­TXCLKOUT+
LVDSVCC LVDSGND
LVDSGND LVDSGND
PLLVCC
PLLGND PLLGND
GND
GND
GND
GND
GND
VVV
V
TXIN27
TXIN21 TXIN22
TXIN23 TXIN24 TXIN25 TXIN26
TXOUT3-
TXOUT3+
C206
0.1uF 0603
C213
0603
CP05 NC
123
45
678
L112
BEAD120R
0805
C208 10nF
0603
C209 1nF
0603
L110
BEAD120R
0805
C198
0.1uF 0603
I106
CS5824 TSSOP56
51 52 54 55 56
2
3
4 6 7
8
10
11 12 14
15
16 18
19 20 22
31
32 48
47 46 45 42 41
40 39
44 49
43 36
34 35
33
5
13
21
29
53
1917
26
50
23 24
25 27 28 30
38 37
TXIN0 TXIN1 TXIN2 TXIN3 TXIN4
TXIN5
TXIN6
TXIN7 TXIN8 TXIN9
TXIN10 TXIN11
TXIN12 TXIN13 TXIN14
TXIN15
TXIN16 TXIN17
TXIN18 TXIN19 TXIN20
TXCLKIN
PWRDWN
TXOUT0­TXOUT0+ TXOUT1­TXOUT1+ TXOUT2­TXOUT2+
TXCLKOUT­TXCLKOUT+
LVDSVCC LVDSGND
LVDSGND LVDSGND
PLLVCC PLLGND
PLLGND
GND
GND
GND
GND
GND
VVV
V
TXIN27
TXIN21 TXIN22
TXIN23 TXIN24 TXIN25 TXIN26
TXOUT3­TXOUT3+
L123
BEAD80R
0805
10.4. Output Interface
!
!
ViewSonic Corporation
26
Confidential –DoNotCopy
VE175/b-2
MICROCONTROLLER
EEPROM
OSD Control Panel Interface
Write Protect (H:protect)
* From 7414
Backlite ON
AD KEY PORTI/O KEY PORT
GREEN ORANGE
KEY PAD
SDA
SCL
/STANDBY
ADE-SDA ADE-SCL
SDA
RXD
TXD
WP
SCL
CW3
CW5
ADE-RESET#
BLON
ENTER
POWER
BRIGHTNESS
CW6
LED-GREEN
CW7
LED-GREEN LED-ORANGE
LED_ORG
LED_GRN
LED-ORANGE
LED_ORG
LED_GRN
VOLUME
CW1
DOWN
POWER
UP
CW2
MENU
MENU
CW4
ENTER
MUTE
DOWN
UP
DOWN
2
PSM/LED
PWR/LED
UP
1
PWR/SW
ADE-SDA
[2]
ADE-SCL
[2]
ADE-RESET#[2]
BRIGHTNESS
[4]
LVDS_STBY
[4]
DDC-SCL DDC-SDA
MCU_VS MCU_CS
BLON
PANELPOWER
[3]
+5V_MCU
+5V_MCU
+5V_MCU
+5V_MCU
+5V_MCU
+5V
+5V
+12V
+12V
+5V_MCU
+5V
VGA 5V
R192
3.3K 0603
R162 12K 0603
S?
S?S?S?
R180
1K
0603
R167 10k
0603
Q108
MMBT3906
R212
10k
D?S?
P? 8 HEADER
1234567
8
P108 HEADER 5
12345
R178
3.3K 0603
C226NC
L115 BEAD600R
C228NC
C222 33pF 0603
R190 100 0603
C238
0.1uF 0603
Q107
MMBT3906
X102
12MHz Crystal
R165 10k
0603
R168 100K 0603
R193
3.3K 0603
C229NC
P107/NC
CON4
1 2 3 4
P103 CON8
1234567
8
R169 10K 0603
L117 BEAD600R
Q105
MMBT3906
R183
3.3K 0603
C218
0.1uF 0603
L114 BEAD600R
R211
1.5k
C224
0.1uF 0603
I108
MTV312M44PLCC
12345
6
7
10 11 12 13 14 15 16 17
1819202122232425262728
29
30
31
32
34
35
36
37
38
39
4041424344
33
8 9
DA2/P5.2
DA1/P5.1
DA0/P5.0
VDD3
NC
NC
RST
VSS X2 X1 ISDA/P3.4/T0 ISCL/P3.5/T1 STOUT/P4.2 P6.2/AD2/HLFHI P1.0
P1.1
P3.2/INT0
P1.2
P1.3
P1.4
P1.5
P1.6
P1.7
P6.1/AD1
P6.0/AD0
HSDA/P3.1/Txd
HSCL/P3.0/Rxd
P6.4/DA10
P6.5/DA11
P6.6/DA12
DA6/P5.6
DA7/HCLAMP
VBLANK/P4.0
HBLANK/P4.1
DA9/HALFV
DA8/HLFHO
DA5/P5.5
DA4/P5.4
DA3/P5.3
HSYNC
VSYNC
P6.7/DA13
VDD P6.3/AD3
R194
3.3K 0603
I109 24C16 DIP8
1 2 3 4
8 7 6 5
A0 A1 A2
GND
VCC TEST SCL SDA
R181
1M
0603
L118 BEAD600R
R177 20K 0603
R161 20K 0603
C216
0.1uF 0603
C225NC
L116 BEAD600R
C217
0.1uF 0603
R195
3.3K 0603
R175
3.3K 0603
R200 2K/NC
0603
Q106
MMBT3906
R176
3.3K 0603
R196
3.3K 0603
R185 680 0603
C230NC
C219 1uF 0603
C221 33pF 0603
C231NC
C220 100pF/NC 0603
R210 1k
R186 680 0603
R182
3.3K 0603
C227 NC
R179
3.3K 0603
C223
33pF
0603
C239 47uF/16V
10.5. Microcontroller
!
!
ViewSonic Corporation
27
Confidential –DoNotCopy
VE175/b-2
I803
F801
R802
P801
AC IN 100-240V
N
L
TL431D
+
C818 NC
D804 FCH20A15
C815
100PF NPO
R804 200K 3W
D807 15V
L807 NC
I801 KA1M0565R
3 2 1 4
Vcc DRAIN GND FB
D803 UF4004
+
C808
100UF/50V
R801
1.5M 0.5W
+
C819 NC
R816 1
D805 NC
+
C813
3300UF/16V
C809
0.1UF
D810 2A07
C822 NC
C802 4700PF
R809 NC
I802
TLP721F
4
3
1
2
+
C816
1000UF/16V
C824
0.22UF L804
5UH
L801
JUMPER
C823 4700PF
C803 4700PF
+
C817 NC
C801
0.22UF
P802
1 2 3 4 5
2.5A/250V
L803
JUMPER
+
C811 NC
C810
0.033UF/50V MEF
7A/125V
F803
R808 NC
P803 NC
1 2 3 4 5 6 7 8 9
T801
ERL-28
1
6
5
3
9
12 7,8
10,11
D814 NC
R807
16.2K 1%
R840
10
R815 120
L805 ET-24
+
C812
100UF 400V
C820
0.1UF/50V MEF
D813 2A07
R805
150K 1W
R813 100
C806
0.22UF 630V
R811
19.1K 1%
D812 2A07
D802
HER157G
R812
4.87K 1%
L802 BEAD
NC
D811 2A07
R806 150K 1W
10.6. AC TO DC POWER
!
!
ViewSonic Corporation
28
Confidential –DoNotCopy
VE175/b-2
11. PCB Layout Diagrams
11.1. MAIN PCB TOP VIEW
!
!
ViewSonic Corporation
29
Confidential –DoNotCopy
VE175/b-2
11.2. MAIN PCB BOTTOM VIEW
11.3. CON PCB TOP VIEW
!
!
ViewSonic Corporation
30
Confidential –DoNotCopy
VE175/b-2
11.4. CON PCB BOTTOM VIEW
11.5. POWER PCB TOP VIEW
!
!
ViewSonic Corporation
31
Confidential –DoNotCopy
VE175/b-2
11.6. POWER PCB BOTTOM VIEW
ItemViewSonic P/N Reference P/N Descriptio
n
Locatio
n
Q'tyRemar
k
1 P-BX-0601-0938 2011170007 VE175-2 VLCDS23895-6W CARTON BOX 1 2 P-FM-0602-0736 2012171400 EPS d=0.016 POLYFOAM 1 3 P-FM-0602-0737 2012171500 EPS d=0.016 POLYFOAM 1 4 C-BC-0302-0408 2022259203 PC+ABS 94-V0 BLACK(4001) CABI BACK 1 5 PL-PS-0715-0185 2028254802 VE800 AB 94HB/BLACK 4001 STAND 1 6 B-SB-0221-0002
2414502100
INVERTER JT178P93 EMAX U901 RA
1
7 B-SB-0221-0597
2414502200
INVERTER DIVLJK0221D42- SAMPO U901 RB
1
QDI (2nd Source
)
8 B-SB-0221-0290
2414500400
INVERTER PLCD07174 LINK COM U901 RA
1 CPT
9 B-SB-0221-0434
2414501000
INVERTER DIVTL0058-D42 SAMPO U901 RB
1 CPT (2nd Source) 10 A-VIO-0118-0035 2427501164 D15/C13 2919(3+6) 1.83M BLK I/O CABLE 1 11 M-MS-0808-9162
2002310329
VIEWSONIC VE175-2 QSG 0616 2P02
1 12 M-MS-0808-9163
2002310370
GUARANT CARD VIEWSONIC VE175-2 QSG CPT 0818 2P02
1 CPT 13 C-FP-0301-0857 2603307326 PC+ABS 94-V0 877C VA720-1 PANEL ASSY 1 14 B-MB-0201-0792 6201-7978906251 PCB ASS'Y BLOCK (MAIN) PCB ASS'Y BLOCK (MAIN) 1 15 B-CB-0206-0027 6202-7978906521 PCB ASS'Y BLOCK (CON) PCB ASS'Y BLOCK (CON) 1 16 B-PS-0204-0006 6204-7978906521 PCB ASS'Y BLOCK (POWER) PCB ASS'Y BLOCK (POWER) 1 17 C-FP-0301-0934 2024263002 PC+ABS 94 V0 GY7521 FRONT BEZEL 1 18 M-MS-0808-8180 2053751901 LED INDIC.-PWR LED INDIC.-PWR 1 19 PL-FK-0707-0137 2044260901 VE150-2/ABS 94V0 GY7521 FUNCTION KEY 1 20 M-BK-0805-0002 2071864900 BRACKET,FIX,SECC T=1.2MM VE175-2 BRACKET,FIX 1 21 M-MS-0808-1064 2061452800 RUBBER 10*10 T=9.0MM GRAY BUSHING 1 22 M-MS-0808-1364 2026252601 ABS 94 HB GY7521 CASE 1 23 M-LB-0813-0883 2055636015 VE175-2 VLCDS23895-6W SMALL LABEL 1 24 M-MS-0808-1314 2106653500 TORQUE 20~60 KGF -5'~90' HINGE 1 25 PL-PD-0714-005
8
2039802301 CR 420xφ16.5x5.
8
FOOT PAD 1 26 M-BK-0805-0003 2071859301 VE800 SECC 2.0t FOR STAND BRACKET,FIX 1 27 M-MS-0808-1362 2027255301 VE800 ABS 94HB/GY7521 STAND DUST COVER 1 28 M-LB-0813-0769 2055613293 VIEWSONIC OPEN STAND LABEL-LCD LABEL 1 29 M-MS-0808-4026 2051350200 JD144V3 VIEWSONIC 3BIRDS AL NAME PLATE 1 30 M-MS-0808-1316 2013222536 250mmx350mmxt0.3 ADD>PE-LD< POLYETHY BAG 1 31 M-LB-0813-0885 2055632024 VE175-2 VLCDS23895-6W UPC LABEL UPC LABEL 1 32 M-MS-0808-1317 2013053000 90CMX75CMX0.02t PE-LD POLYETHY BAG 1 33 M-LB-0813-0528 2055103400 DATE CORD LABEL JK0936F WEN DATE CORD LABEL 1 34 M-LB-0813-0869 2055613281 VIEWSONIC VA520 NUMBER STICKER LABEL 4 35 M-LB-0813-0002 2056603050 VIEWSONIC LCD SERIAL LABEL SERIAL LABEL 1 36 M-LB-0813-0884
2055132059
LABEL VE175 VLCDS23895-6W 030311 6P50
1
37 M-LB-0813-0923
2055132105
LABEL VE175-2 VLCDS23895-6W CPT 6P50
1 CPT
38 M-LB-0813-0885
2055632024
LABEL VE175-2 VLCDS23895-6W 6P02
1
39 M-LB-0813-0924
2055632029
LABEL VE175-2(3) VLCDS23895-6W CPT 6P02
1 CPT
40 M-LCD-0826-0196
2212003900
LCD PANEL QD17EL07 QUANTA V901
1
41 M-LCD-0826-019
7
2212003610
LCD PANEL CLAA170EA02VG CPT V901
1 CPT
Item
V
iewSonic P/N Reference P/N Descriptio
n
Locatio
n
Q't
y
1 A-PC-0106-0143 2427130082 CHINA WALL 1.83M IVORY POWER CORD 1 2 M-LB-0813-0859 2055613334 LABEL VIEWSONIC VE175B 3C STICKER LABEL 1 3 M-MS-0808-0028 2002310338 GUARANT CARD VIEWSONIC CHINA WARRANTY CA
R
GUARANT CARD 1
4 M-MS-0808-003
3
201305180
0
POLYETHY JT166A14 500LX470WX490H t=0.08 POLYETHY BAG 1
Item
V
iewSonic P/N Reference P/N Descriptio
n
Locatio
n
Q't
y
1 A-PC-0106-0123 2427130035 USA WALL 1.8M IVORY POWER CORD 1 2 A-PC-0106-0142 2427130055 E WALL 1.8M IVORY POWER CORD 1
Item
V
iewSonic P/N Reference P/N Descriptio
n
Locatio
n
Q't
y
1 A-PC-0106-0123 2427130035 USA WALL 1.8M IVORY POWER CORD 1 2
A
-PC-0106-0142242713005
5
E WALL 1.8M IVORY POWER CORD 1
Item
V
iewSonic P/N Reference P/N Descriptio
n
Locatio
n
Q't
y
1 A-PC-0106-0123 2427130035 USA WALL 1.8M IVORY POWER CORD 1 2
A
-PC-0106-0142242713005
5
E WALL 1.8M IVORY POWER CORD 1
INDIVIDUAL PARTS OF VSE-E
INDIVIDUAL PARTS OF VSA-M
INDIVIDUAL PARTS OF VSI-P
V
E175-2
INDIVIDUAL PARTS OF VSCN-G
12. Recommended Spare Parts List
!
ViewSonic Corporation
32
Confidential –DoNotCopy
VE175/b-2
Item ViewSonic P/N Ref. P/N Description Location Q'ty Remark
1 P-BX-0601-0884 2011170008 CARTON BOX 6P01 1 2 P-FM-0602-0736 2012171400 POLYFOAM 6P20 1 3 P-FM-0602-0737 2012171500 POLYFOAM 6P21 1 4 M-MS-0808-1316 2013222536 POLYETHY BAG 6P31 1 5 C-BC-0302-0410 2022259205 CABI BACK 2C01 1 6 PL-PS-0715-0187 2028254803 STAND 5B01 1 7 M-LB-0813-0528 2055103400 DATE CORD LABEL JK0936F WEN 6P52 1 8 M-SCW-0824-0285 2084730082 SCREW,BND T+ 1F17 2C22 9S01 9S02 1
9 E-FS-0410-0009 2213125207 FUSE F801 1 10 A-VIO-0118-0035 2427501164 I/O CABLE P961 1 11 C-FP-0301-0859 2603307327 PANEL ASSY PANEL ASSY 1 12 B-MB-0201-2729 6201-7978906562 PCB ASS'Y BLOCK (MAIN) PCB ASS'Y BLOCK (MAIN) 1 13 B-CB-0206-0027 6202-7978906521 PCB ASS'Y BLOCK (CON) PCB ASS'Y BLOCK (CON) 1 14 B-PS-0204-0006 6204-7978906521 PCB ASS'Y BLOCK (POWER) PCB ASS'Y BLOCK (POWER) 1 15 C-FP-0301-0153 2024263004 FRONT BEZEL FRONT BEZEL 1 16 M-MS-0808-8180 2053751901 LED INDIC.-PWR LED INDIC.-PWR 1 17 PL-BT-0706-0147 2044260904 FUNCTION KEY FUNCTION KEY 1 18 M-MS-0808-1064 2061452800 RUBBER 10*10 T=9.0MM GRAY RUBBER 10*10 T=9.0MM GRAY 1 19 M-MS-0808-1074 2026252603 ABS 94HB MIDNIGHT GRAY ABS 94HB MIDNIGHT GRAY 1 20 M-LB-0203-0065 2055636016 VE175B-2 VLCDS23895-7W SMALL VE175B-2 VLCDS23895-7W SMALL 1 21 M-MS-0808-1314 2106653500 TORQUE 20~60 KGF -5'~90' TORQUE 20~60 KGF -5'~90' 1 22 PL-PD-0714-0058 2039802301 CR 420
x
φ16.5x5.
8
CR 420xφ16.5x5.
8
1 23 M-MS-0808-1315 2027255303 ABS 94HB MIDNIGHT GRAY ABS 94HB MIDNIGHT GRAY 1 24 M-LB-0813-0769 2055613293 VIEWSONIC OPEN STAND LABEL-LCD
VIEWSONIC OPEN STAND LABEL-LCD 1
25 M-MS-0808-4026 2051350200 JD144V3 VIEWSONIC 3BIRDS AL JD144V3 VIEWSONIC 3BIRDS AL 1 26 M-MS-0808-1316 2013222536 250mmx350mmxt0.3 ADD>PE-LD< 250mmx350mmxt0.3 ADD>PE-LD< 1 27 M-MS-0808-1317 2013053000 90CMX75CMX0.02t PE-LD 90CMX75CMX0.02t PE-LD 1 28 M-LB-0813-0869 2055613281 LABEL VIEWSONIC VA520 NUMBER STICKER 6P06 1 29 M-LB-0203-0065 2055636016 LABELVE175B-2 VLCDS23895-7W SMALL 6P03 1 30 M-LB-0813-0002 2056603050 VIEWSONIC LCD SERIAL LABEL 6P56 6P55 6P54 6P51 4 31 B-SB-0221-0002 2414502100 INVERTER JT178P93 EMAX U901 RA 1 32 B-SB-0221-0597 2414502200 INVERTER DIVLJK0221D42- SAMPO U901 RB 1 QDI( 2nd Source ) 33 B-SB-0221-0290 2414500400 INVERTER PLCD07174 LINK COM U901 RA 1 CPT 34 B-SB-0221-0434 2414501000 INVERTER DIVTL0058-D42 SAMPO U901 RB 1 CPT( 2nd Source) 35 M-LCD-0826-0196 2212003900 LCD PANEL QD17EL07 QUANTA V901 1 36 M-LCD-0826-0197 2212003610 LCD PANEL CLAA170EA02VG CPT V901 1 CPT 37 M-LB-0203-0695 2055132060 LABEL VE175B-2 VLCDS23895-7W 030311 6P50 1 38 M-LB-0813-0921 2055132106 LABEL VE175B-2 VLCDS23895-7W CPT 6P50 1 CPT 39 M-LB-0813-0871 2055632025 UPC LABEL VE175B-2 VLCDS23895-7W 6P02 1 40 M-LB-0813-0922 2055632030 UPC LABEL VE175B-2(3) VLCDS23895-7W CPT 6P02 1 CPT 41 M-MS-0808-915
9
2002310330 GUARANT CARD VIEWSONIC VE175B-2 QSG
2P02 1
42 M-MS-0808-916
0
2002310371 GUARANT CARD VIEWSONIC VE175B-2 QSG CPT 2P02 1 CPT
Item ViewSonic P/N Ref. P/N Description Location Q'ty
1 A-PC-0106-0277 2427130097 POWER CORD
(
CHINA WALL 1.83M BLACK SCP P951 1
2 M-LB-0813-0859 2055613334 LABEL VIEWSONIC VE175B 3C STICKE LABEL 1
3 M-MS-0808-0028 2002310338 VIEWSONIC CHINA WARRANTY CARD GUARANT CARD 1
4 M-MS-0808-003
3
2013051800 POLYETHY BAG JT166A14 500LX470WX490H t=0.0POLYETHY BAG 1
Item ViewSonic P/N Reference P/N Description Location Q'ty
1 A-PC-0106-0121 2427130046 USA WALL 1.8M BLACK POWER CORD 1 2
A
-PC-0106-0138 2427130047 E WALL 1.8M BLAC
K
POWER CORD 1
Item ViewSonic P/N Reference P/N Description Location Q'ty
1 A-PC-0106-0121 2427130046 USA WALL 1.8M BLACK POWER CORD 1 2
A
-PC-0106-0138 2427130047 E WALL 1.8M BLAC
K
POWER CORD 1
Item ViewSonic P/N Reference P/N Description Location Q'ty
1 A-PC-0106-0121 2427130046 USA WALL 1.8M BLACK POWER CORD 1 2
A
-PC-0106-0138 2427130047 E WALL 1.8M BLAC
K
POWER CORD 1
VIEWSONIC INDIVIDUAL PARTS OF VSE-E
VIEWSONIC INDIVIDUAL PARTS OF VSI-P
VE175b-2 Recommended Spare Parts List
Recommended Spare Parts List VSCN-G
VIEWSONIC INDIVIDUAL PARTS OF VSA-M
!
ViewSonic Corporation
33
Confidential –DoNotCopy
VE175/b-2
ItemViewSonic P/N Ref. P/N
Location
Q'ty Remark
1 M-MS-0808-9162 2002310329 GUARANT CARD VIEWSONIC VE175-2 QSG 0616 2P02 1 2 M-MS-0808-9163 2002310370 GUARANT CARD VIEWSONIC VE175-2 QSG CPT 0818 2P02 1
CPT
3 P-BX-0601-0938 2011170007 CARTON BOX VE175-2 VLCDS23895-6W 6P01 1 4 P-FM-0602-0736 2012171400 POLYFOAM EPS d=0.016 6P20 1 5 P-FM-0602-0737 2012171500 POLYFOAM EPS d=0.016 6P21 1 6 M-MS-0808-1317 2013053000 POLYETHY BAG 90CMX75CMX0.02t PE-LD 6P30 1 7 M-MS-0808-1316 2013222536 POLYETHY BAG 250mmx350mmxt0.3 ADD>PE-LD< 6P31 1 8 C-BC-0302-0409 2022259202 CABI BACK PC+ABS 94 V0 GY7521 2C01 1
9 C-FP-0301-0934 2024263002 FRONT BEZEL PC+ABS 94 V0 GY7521 1F01 1 10 M-MS-0808-1364 2026252601 CASE ABS 94 HB GY7521 2C04 1 11 M-MS-0808-1362 2027255301 DUST COVER VE800 ABS 94HB/GY7521 STAND 5B08 1 12 PL-PS-0715-0186 2028254801 STAND VE800 ABS 94HB/GY7521 5B01 1 13 PL-PD-0714-0058 2039802301 FOOT PAD
CR 420xφ16.5x5.8
5B02 4 14 PL-FK-0707-0137 2044260901 FUNCTION KEY VE150-2/ABS 94V0 GY7521 1F03 1 15 M-MS-0808-4026 2051350200 NAME PLATE JD144V3 VIEWSONIC 3BIRDS AL 1F19 1 16 M-MS-0808-8180 2053751901 LED INDIC.-PWR VE150-2/PMMA 94HB 1F02 1 17 M-LB-0813-0528 2055103400 LABEL JK0936F WEN 6P52 1 18 M-LB-0813-0884 2055132059 LABEL VE175 VLCDS23895-6W 030311 6P50 1 19 M-LB-0813-0923 2055132105 LABEL VE175-2 VLCDS23895-6W CPT 6P50 1
CPT
20 M-LB-0813-0869 2055613281 LABEL VIEWSONIC VA520 NUMBER STICKER 6P06 1 21 M-LB-0813-0769 2055613293 LABEL VIEWSONIC OPEN STAND LABEL-LCD 5B10 1 22 M-LB-0813-0870 2055613379 LABEL ViewSonic CONTAINER LABEL 6P11 1 23 M-LB-0813-0885 2055632024 LABEL VE175-2 VLCDS23895-6W 6P02 1 24 M-LB-0813-0924 2055632029 LABEL VE175-2(3) VLCDS23895-6W CPT 6P02 1
CPT
25 M-LB-0813-0883 2055636015 LABEL VE175-2 VLCDS23895-6W SMALL 6P03 1 26 M-LB-0813-0002 2056603050 SERIAL LABEL VIEWSONIC LCD SERIAL LABEL 6P56 6P55 6P54 6P51 4 27 M-MS-0808-1064 2061452800 BUSHING RUBBER 10*10 T=9.0MM GRAY 1F50 2 28 M-MS-0808-1619 2063451101 ADHESI SHEET 27.2x42.4 PVC COLOR:GREY 1F20 1 29 #N/A 2063451203 ADHESI SHEET PC 94V0 56wX30LX1.0t BLACK 1F33 1 30 M-MS-0808-1389 2071662800 SHIELD PLATE SPTE t=0.3mm VE175 1F22 1 31 M-MS-0808-1420 2071663201 SHIELD PLATE SPTE t=0.3(Main board-ST) 1F10 1 32 M-BK-0805-0004 2071859200 BRACKET,FIX SECC t=1.0 1F29 1 33 M-BK-0805-0003 2071859301 BRACKET,FIX VE800 SECC 2.0t FOR STAND 5B06 1 34 M-BK-0805-0006 2071859600 BRACKET,FIX SECC t=1.0mm VE175 1F26 1 35 M-BK-0805-0007 2071859700 BRACKET,FIX SECC t=1.0mm VE175 1F27 1 36 M-BK-0805-0002 2071864900 BRACKET,FIX SECC T=1.2MM VE175-2 1F34 2 37 M-MS-0808-6316 2071958300 METAL FITTG VE170 KENSINGTON 2C02 1 38 M-BK-0805-0008 2071960201 METAL FITTG SECC t=0.8 NON-P.S.M 1F12 1 39 M-BK-0805-0009 2071961402 METAL FITTG SECC T=1.0 VE175(2) ST 1F05 1 40 M-MS-0808-8181 2072258300 HEAT SINK JT178S AL 6063S 45Wx20Dx22H 9H01 1 41 M-MS-0808-8181 2072258300 HEAT SINK JT178S AL 6063S 45Wx20Dx22H 9H02 1 42 M-MS-0808-8182 2072452601 INSULATOR VE800 PC FR-700 0.2t FOR POWER 1F21 1 43 PL-HD-0705-0116 2074191000 HOLDER JK1461 JEAN 1F28 1 44 M-SCW-0824-6715 2080002200 SCREW,SPE L355 M3x6 DH NICKEL-PLATED 1F06 4 45 M-SCW-0824-6716 2080002400 SCREW,SPE VE155/3x8 STAND 1F13 2 46 M-SCW-0824-6717 2081430062 SCREW,(WASH) M3X6 P=0.5(TOOTH WASHER) 2C21 5 47 M-SCW-0824-6718 2081430082 SCREW,(WASH) M3X8 P=0.5(TOOTH,WASHER) 1F15 2 48 M-SCW-0824-6719 2082630062 SCREW M3X6 P=0.5 1F35 1F07 1F08 1F09 26 49 M-SCW-0824-0285 2084730082 SCREW,BND T+ M3X8(BND T+) 9S01 09S02 1F17 2C22 9 50 M-SCW-0824-0122 2084730102 SCREW,BND T+ M3X10(BND T+) 1F04 2 51 M-SCW-0824-0261 2084730142 SCREW,BND T+ M3X14(BND T+) 1F70 1 52 M-SCW-0824-6721 2084740082 SCREW,BND T+ M4X8(BND T+) 5B07 3 53 M-SCW-0824-0123 2084740102 SCREW,BND T+ M4X10(BND T+) 1F18 1F31 1F32 5B09 14 54 M-SCW-0824-6722 2087340106 SCREW,B SPW+ 4X10(+)SWRM-3 ZMC2-C 5B05 4 55 M-MS-0808-1314 2106653500 HINGE TORQUE 20~60 KGF -5'~90' 2C20 RA 1 56 #N/A 2106653501 HINGE 29~32/55~58KGF-CM/-3'~20'/90' 2C20 RB 57 #N/A 2202118703 PC BOARD JT178A62 P/B CAM1 170*76 4.05 U801 1
Description
VE175-2 (QDI & CPT) BOM LIST
!
ViewSonic Corporation
34
Confidential –DoNotCopy
VE175/b-2
58 B-KB-0207-0040 2202120102 PC BOARD VE155 K/B PAPER 140*15 3.00 U701 1 59 B-MB-0201-0746 2202512400 PCB MULTILAYER VE175ST M/B FR4*4 150*100 1.00 U001 1 60 M-LCD-0826-0196 2212003900 LCD PANEL QD17EL07 QUANTA V901 1 61 M-LCD-0826-0197 2212003610 LCD PANEL CLAA170EA02VG CPT V901 1
CPT
62 E-FS-0410-0009 2213125207 FUSE FUSE 2.5A/250V 21502.5 LITTEL F801 RA 1 63 E-FS-0410-0102 2213125211 FUSE FUSE 2.5A/250V SG501302.5 PICO F801 RB 1 64 #N/A 2213270205 FUSE MICRO R251007 7A/125V(T52) LITTEL F803 RB 1 65 #N/A 2213270295 FUSE MICRO 20N7000FS 7A/125V PICO F803 RA 1 66 E-TH-0416-0042 2229201212 THERMISTOR,PTH SCK-103 10+-20% 3A THINKING R840 1 67 E-R-0405-3433 2232610195 RES,CBN 1/2 RD 1/2W 100.00 J T52 MINI R809 1 68 #N/A 2232610995 RES,CBN 1/2 RD 1/2W 1.00 J T52 MINI R816 1 69 #N/A 2232615595 RES,CBN 1/2 RD 1/2W 1.50M J T52 MINI R801 1 70 E-R-0405-1757 2233410195 RES,CBN 1/4 S RD 1/4WS 100.00 J T52 MINI R813 1 71 E-R-0405-0401 2233412195 RES,CBN 1/4 S RD 1/4WS 120.00 J T52 MINI R815 1 72 E-R-0405-6995 2235415403 RES,MTL 1 RS 1W 150Kohm J P=15.0 R805 R806 2 73 #N/A 2235547113 RES,MTL 2 RS 2WS 470ohm J P=15.0 R205 1 74 E-R-0405-1507 2235547813 RES,MTL 2 RS 2WS 0.47ohm J P=15.0 R208 1 75 #N/A 2235562813 RES,MTL 2 RS 2W 0.62 J P=15 MINI R207 1 76 #N/A 2235620417 RES,MTL 3 RS 3WS 200Kohm J P=25.0 R804 1 77 E-R-0405-5611 2239216225 RES,PRE 1/4 S RN 1/4WS 16.20K F R807 1 78 E-R-0405-6996 2239219125 RES,PRE 1/4 S RN 1/4WS 19.10K F R811 1 79 E-R-0405-6997 2239248715 RES,PRE 1/4 S RN 1/4WS 4.87K F R812 1 80 #N/A 2251215026 RES,CHIP 1/10 RC 0603 1/10W 15Kohm F T R102 R104 R106 3 81 #N/A 2251224906 RES,CHIP 1/10 RC 0603 1/10W 249 ohm F T R121 1 82 #N/A 2251275096 RES,CHIP 1/10 RC 0603 1/10W 75 ohm F T R122 R125 R127 R128 6 83 E-R-0405-6600 2253200096 RES,CHIP 1/10W RC 0603 1/10W 0 ohm J T L120 L121 L122 R110 7 84 E-R-0405-6998 2253210096 RES,CHIP 1/10W RC 0603 1/10W 10 ohm J T R114 1 85 E-R-0405-6409 2253210196 RES,CHIP 1/10W RC 0603 1/10W 100 ohm J T R137 R138 R190 R197 6 86 E-R-0405-6410 2253210296 RES,CHIP 1/10W RC 0603 1/10W 1Kohm J T R155 R210 2 87 E-R-0405-6411 2253210396 RES,CHIP 1/10W RC 0603 1/10W 10Kohm J T R113 R139 R140 R141 8 88 E-R-0405-6984 2253210496 RES,CHIP 1/10W RC 0603 1/10W 100Kohm J T R168 R181 1 89 E-R-0405-6601 2253210596 RES,CHIP 1/10W RC 0603 1/10W 1Mohm J T R111 2 90 #N/A 2253211196 RES,CHIP 1/10W RC 0603 1/10W 110 ohm J T R135 1 91 #N/A 2253212396 RES,CHIP 1/10W RC 0603 1/10W 12Kohm J T R162 1 92 #N/A 2253215296 RES,CHIP 1/10W RC 0603 1/10W 1.5Kohm J T R211 1 93 E-R-0405-6999 2253220396 RES,CHIP 1/10W RC 0603 1/10W 20Kohm J T R161 R177 2 94 E-R-0405-6603 2253222096 RES,CHIP 1/10W RC 0603 1/10W 22 ohm J T R147 R148 R149 R151 4 95 E-R-0405-7000 2253222196 RES,CHIP 1/10W RC 0603 1/10W 220 ohm J T R118 1 96 E-R-0405-6604 2253222296 RES,CHIP 1/10W RC 0603 1/10W 2.2Kohm J T R119 R156 2 97 E-R-0405-6606 2253233196 RES,CHIP 1/10W RC 0603 1/10W 330 ohm J T R123 R131 2 98 E-R-0405-6416 2253233296 RES,CHIP 1/10W RC 0603 1/10W 3.3Kohm J T R175 R176 R178 R179 12 99 E-R-0405-6417 2253247096 RES,CHIP 1/10W RC 0603 1/10W 47 ohm J T R124 R132 R134 3
100 E-R-0405-6419 2253247296 RES,CHIP 1/10W RC 0603 1/10W 4.7Kohm J T R157 R158 R159 3 101 #N/A 2253256196 RES,CHIP 1/10W RC 0603 1/10W 560 ohm J T R120 1 102 E-R-0405-6456 2253268196 RES,CHIP 1/10W RC 0603 1/10W 680 ohm J T R185 R186 2 103 E-R-0405-5988 2253300096 RES,CHIP 1/8 RC 0805 1/8 W 0ohm J T R201 R202 R204 R209 4 104 #N/A 2259222008 RES,CHIP NETWORKS 8P4R 1/16W 22ohm J P=0.8 RP01 RP02 RP03 12 105 E-C-0404-0157 2272110191 CAP,CER TC 100p/50V CH P=5.0 J T C815 1 106 E-C-0404-4833 2281110491 CAP,CER CC 0.1u/50V K T C809 1 107 E-C-0404-1869 2285133191 CAP,CER CK45B 330.000PF 1KV K T C822 1 108 E-C-0404-1855 2287247212 CAP,CER CK45F 4700.000PF 250VAC M KC C802 C803 C823 3 109 E-C-0404-4834 2300922401 CAP,MTL MINI 0.220UF 275V M C801 C824 2 110 E-C-0404-4835 2301510491 CAP,MTL CF93M 0.100UF 100V J T C820 1 111 E-C-0404-4836 2301533391 CAP,MTL CF93M 0.033UF 100V J T C810 1 112 E-C-0404-4837 2307522312 CAP,MTL MPP 0.022u/630V P=10.0 J K C806 1 113 E-C-0404-4838 2330005112 CAP,MINI ELE ES1C332MB41625DE 3300/16 ELITE C813 1 114 E-C-0404-1867 2333310891 CAP,ELE 105'C EC 1000u/ 16V 10*20 P=5.0 T C816 1 115 E-C-0404-3097 2333333791 CAP,ELE 105'C EC 330u/ 16V 8*11 P=5.0 T C176 1 116 #N/A 2333347613 CAP,ELE 105'C EC 47u/ 16V 5*11 P=2.5 T C179 C101 C121 C122 8
!
ViewSonic Corporation
35
Confidential –DoNotCopy
VE175/b-2
117 E-C-0404-1426 2333447691 CAP,ELE 105'C EC 47u/ 25V 5*11 P=5.0 T C166 1 118 E-C-0404-2414 2333447791 CAP,ELE 105'C EC 470u/ 25V10*13.0 P=5.0 T C165 C170 C236 3 119 E-C-0404-1830 2333610791 CAP,ELE 105'C EC 100u/ 50V10*12.5 P=5.0 T C808 1 120 #N/A 2335210813 CAP,ELE LOW ESR 105'C EC 1000u/ 10V 10*13 P=5.0 T C173 1 121 E-C-0404-3898 2341110096 CAP,CHIP 125'C CS 0603/COG/50V 10p J T C162 1 122 E-C-0404-4828 2341110196 CAP,CHIP 125'C CS 0603/COG/50V 100p J T C115 C154 C157 C160 4 123 E-C-0404-4909 2341115096 CAP,CHIP 125'C CS 0603/COG/50V 15p J T C163 1 124 #N/A 2341127096 CAP,CHIP 125'C CS 0603/COG/50V 27p J T C185 C191 2 125 E-C-0404-3900 2341133096 CAP,CHIP 125'C CS 0603/COG/50V 33p J T C221 C222 C223 3 126 E-C-0404-4224 2341147096 CAP,CHIP 125'C CS 0603/COG/50V 47p J T C192 1 127 #N/A 2341150996 CAP,CHIP 125'C CS 0603/COG/50V 5p J T C184 C190 2 128 #N/A 2341168996 CAP,CHIP 125'C CS 0603/COG/50V 6.8P J T C187 C188 C189 3 129 E-C-0404-3816 2346110296 CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C113 C117 C210 C209 4 130 E-C-0404-4424 2346110396 CAP,CHIP 125'C CS 0603/X7R/50V 0.01u K T C114 C118 C120 C200 5 131 E-C-0404-3815 2346410496 CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C102 C103 C104 C105 72 132 #N/A 2346747496 CAP,CHIP 85'C CS 0603/Y5V/16V 0.47u Z T C153 C156 C159 3 133 E-C-0404-4213 2347610596 CAP,CHIP 85'C CS 0805/Y5V/16V 1.0u Z T C219 C233 C234 3 134 #N/A 2347710696 CAP,CHIP 85'C CS 0805/Y5V/10V 10u Z T C232 1 135 E-C-0404-4831 2350100114 CAP,ELE SPE CE69W 100uF/400V 25*25 M TS C812 RA 1 136 E-C-0404-4832 2350100214 CAP,ELE SPE CE69W 100uF/400V 25*25 M LELON C812 RB 1 137 #N/A 2350100514 CAP,ELE SPE CE69W 100uF/400V 25*25 M HEC C812 RC 1 138 E-Q-0402-1375 2360100396 XISTOR,PNP R SMD MMBT3906-7 VISHAY SOT-23 Q105 RA Q106 4 139 E-Q-0402-1607 2360100596 XISTOR,PNP R SMD MMBT3906 FAIRCHILD SOT23 Q105 RB Q106 4 140 #N/A 2360100796 XISTOR,PNP R SMD MMBT3906 SOT-23 DIODES Q105 RC Q106 4 141 E-Q-0402-1378 2360300596 XISTOR,NPN R SMD MMBT3904-7 VISHAY S0T-23 Q101 RA Q103 3 142 E-Q-0402-1608 2360300896 XISTOR,NPN R SMD MMBT3904 FAIRCHILD SOT23 Q101 RB Q103 3 143 E-Q-0402-1180 2360301296 XISTOR,NPN R SMD MMBT3904 DIODES SOT-23 Q101 RC Q103 3 144 #N/A 2360500196 FET,P-CH SMD SI9953DY-TI TEMIC SO-08 Q102 RA 1 145 #N/A 2360500996 FET,P-CH SMD CEM9953A SO-8 CET Q102 RB 1 146 #N/A 2360510196 FET,P-CH SMD SI4953DY SO-8 VISHAY Q102 RC 1 147 E-PC-0411-0082 2362401600 PHOTO COUPLR TLP721F(D4-GR) TOSHIBA I802 RB 1 148 E-PC-0411-0083 2362401800 PHOTO COUPLR TLP621(D4-GR-LF2) TOSHIBA I802 RA 1 149 E-D-0403-0462 2363215495 DIODE,RECT BYV26C PHILIPS D802 1 150 E-D-0403-1105 2363217595 DIODE,RECT 20D8 IR D810 RC D811 4 151 E-D-0403-1291 2363219895 DIODE,RECT FUF4004 FAGOR D803 RA 1 152 E-D-0403-1465 2363220395 DIODE,RECT UF4004G T/B PEC D803 RB 1 153 E-D-0403-1671 2363224295 DIODE,RECT 20E6 NI(IR) D810 RB D811 4 154 E-D-0403-2009 2363227295 DIODE,RECT 2A07 TSC D810 RA D811 4 155 E-D-0403-2037 2363300300 DIODE,SCHOTTKY FCH20A15 20A/150V NI D804 1 156 E-D-0403-2038 2363502295 DIODE,ZENER RD15EB3 14.35V-15.09V 0.5W NEC D807 RB 1 157 E-D-0403-1109 2363506395 DIODE,ZENER HZ15-2 14.5-15.1V 0.5W HITACHI D807 RA 1 158 #N/A 2363703891 LED
LED 3φ GRN/YEL
D701 1
159 #N/A 2364201296 DIODE,RECT(SMD) BAT54C-7 SOT-23 DII D119 RA 1 160 #N/A 2364201896 DIODE,RECT(SMD) BAT54C CHENMKO SOT-23 D119 RB 1 161 E-D-0403-2040 2364301096 DIODE,SCHOTTKY(SMD) B340 DIODES D101 1 162 E-D-0403-1779 2364503996 DIODE,ZENER SMD BZV55-C5V6 PHILIPS D102 1 163 E-D-0403-1667 2364600196 DIODE,SWITCH SMD
LL4148 3.5X1.5φ TEMIC GS08
D103 D104 D105 D106 14
164 E-IC-0401-0836 2365307391 IC,LINEAR TL431CLP MOTOROLA I803 RA 1 165 E-IC-0401-2015 2365316200 IC,LINEAR 24LC16B DIP-8 MICROCHI I109 RA 1 166 E-IC-0401-2152 2365321991 IC,LINEAR KA431AZTA TO-92 FAIRCHILD I803 RC 1 167 E-IC-0401-2122 2365326600 IC,LINEAR KA1M0565R FAIRCHILD I801 1 168 #N/A 2365327691 IC,LINEAR CM431BCN CHAMPION I803 RB 1 169 E-IC-0401-2748 2365424000 IC,DIGITAL AM24LC16(PDIP-8L) ATC I109 RC 1 170 E-IC-0401-2747 2365424300 IC,DIGITAL M24C16-WBN6T ST PDIP8 I109 RB 1 171 E-IC-0401-2123 2365807496 IC,LINEAR(SMD) AIC1084-33CM AIC TO-263 I103 RA 1 172 E-IC-0401-2745 2365810796 IC,LINEAR(SMD) AP1084K33A(3.3V) TO-263 ATC I103 RB 1 173 E-IC-0401-2746 2365810896 IC,LINEAR(SMD) AP1117DA(ADJ) TO-252 ATC I104 1 174 E-IC-0401-2744 2365810996 IC,LINEAR(SMD) AP15015K5(5V) TO263 ANACHIP I102 RB 1 175 E-IC-0401-2124 2365917996 IC,DIGITAL SMD SN75LVDS83DGG TI I106 RB I107 RB 2
!
ViewSonic Corporation
36
Confidential –DoNotCopy
VE175/b-2
176 E-IC-0401-2125 2365919596 IC,DIGITAL SMD LM2596S-3.3 TO-263 NS I102 RA 1 177 E-IC-0401-1932 2365920096 IC,DIGITAL SMD THC63LVDM83A THINE I106 RA I107 RA 2 178 #N/A 2365921996 IC,DIGITAL SMD SN74LVC14AD TI I105 RB 1 179 E-IC-0401-2132 2365922496 IC,DIGITAL SMD 74LVC14A PHILIPS SO14 I105 RA 1 180 E-IC-0401-2135 2365926196 IC,DIGITAL SMD NT7181CF TSSOP NOVATEK I106 RC I107 RC 2 181 E-IC-0401-2743 2365928496 IC,DIGITAL SMD ADE3000SX PQFP208 ST I101 1 182 #N/A 2365928596 IC,DIGITAL SMD MTV312MV64 PLCC44 MYSON I108 1 183 #N/A 2365928896 IC,DIGITAL SMD M385 TSSOP-56P MRT I106 RD I107 RD 2 184 E-X-0415-0119 2369103601 XTAL,OSC XTAL 12MHZ CL30P H/S X102 1 185 #N/A 2369104701 XTAL,OSC 27MHZ 20PF +-30PPM HC-49/US X101 1 186 #N/A 2371107000 COIL,CHOKE JC186H 28uH 29TS(REF) LAE L107 1 187 #N/A 2371150001 COIL,CHOKE 50uH 0.4*3 28Ts T50-52D 2.5A L108 1 188 E-L-0407-1533 2371154600 COIL,CHOKE JD176 5.2UH 15.5T(REF) L804 1 189 E-L-0407-1534 2371157800 COIL,CHOKE JT178A62 ET-24 4P L805 1 190 E-T-0408-0480 2374208800 XFORMER,POWR JT178A62 ERL-28 12PIN T801 1 191 E-L-0407-0013 2379101495 FERRITE CORE 3.5X9X0.8 L802 1 192 #N/A 2379310166 BEAD,HI-IMPEDANCE Z= 100ohm( 50MHZ~) 0603 200mA L103 L127 2 193 #N/A 2379512196 BEAD,HI-CURRENT Z= 120ohm 0805 I>3.0A L125 L126 2 194 #N/A 2379560086 BEAD,HI-CURRENT Z= 60ohm 1206 I>3.0A L119 L131 L132 3 195 #N/A 2379580096 BEAD,HI-CURRENT Z= 80ohm 0805 I>2.5A L123 1 196 #N/A 2379812156 BEAD,HI-IMPEDANCE Z= 120ohm( 1MHZ~) 0805 300mA L101 L102 L110 L111 6 197 E-L-0407-1536 2379860166 BEAD,HI-IMPEDANCE Z= 600ohm( 50MHZ~) 0805 200mA L114 L115 L116 L117 5 198 #N/A 2403702513 SWITCH,TACT TSTA-2 4.3mm 160g HUA JIE S701 S702 S703 S704 5 199 #N/A 2404222230 PIN PLUG CH71302V1P3 P=2.0 30PIN CVILUX P105 1 200 M-MS-0808-6353 2404301003 CONNECTOR JST XH 4P SIDE P=2.5 OR EQUAL P101 1 201 M-MS-0808-6354 2404301105 CONNECTOR JST PH 6P SIDE P=2.0 OR EQUAL P102 1 202 M-MS-0808-6355 2404301107 CONNECTOR JST PH 8P SIDE P=2.0 OR EQUAL P103 1 203 #N/A 2404301112 CONNECTOR JST PH 13P SIDE P=2.0 OR EQUAL P104 1 204 #N/A 2404339301 CONNECTOR LEOCO 3951-01(V) 2PIN P=3.96 P801 1 205 M-MS-0808-9164 2407000100 SOCKET,ASSY AC INLET ASS'Y 1015#18 L=130 P953 1 206 M-MS-0808-1313 2407200791 HOLDER,FUSE FC-05C F802 RA 1 207 #N/A 2407200991 HOLDER,FUSE CQ-05T (5mm DIA FUSE) F802 RB 1 208 B-SB-0221-0002 2414502100 INVERTER JT178P93 EMAX U901 RA 1 209 B-SB-0221-0597 2414502200 INVERTER DIVLJK0221D42- SAMPO U901 RB 1 QDI (2nd Source) 210 B-SB-0221-0290 2414500400 INVERTER PLCD07174 LINK COM U901 RA 1
CPT
211 B-SB-0221-0434 2414501000 INVERTER DIVTL0058-D42 SAMPO U901 RB 1
CPT (2nd Source)
212 A-PC-0106-0123 2427130035 POWER CORD SVT 18/3 1.8M USA WALL KDS P951 1 213 A-PC-0106-0142 2427130055 POWER CORD E WALL 1.83M(71922) P952 1 214 M-WR-0828-6626 2427408181 WIRE HARNESS 8P H/B 1061#26 L=180mm P=2.0 P982 1 215 M-WR-0828-6627 2427412624 WIRE HARNESS 6P(2.0) H/H 1007#24+112C 350L P983 1 216 M-WR-0828-6624 2427412710 WIRE HARNESS 4/5P H/B 1007#20 160L+CORE P802 1 217 M-WR-0828-6625 2427430131 WIRE HARNESS 30P JAE F1/15*2P 1571#28 130L P981 1 218 A-VIO-0118-0025 2427501149 I/O CABLE D15/C13 2919(3+6)1.83M GE96750 P961 1 219 M-WR-0828-0455 2428106050 JUMPER
0.6φ5.00MM
L801 L803 2
220 M-WR-0828-0450 2428106075 JUMPER
0.6φ7.50MM
J701 J702 J802 3
221 M-WR-0828-0478 2428106100 JUMPER
0.6φ10.00MM
J801 1
222 E-R-0405-7004 2436101012 VARISTOR
SIOV-S14K320 14φ510V
R802 1
223 #N/A 2438501107 CD-OWNER GUIDE VE175-2 WIZARD DATE:20030616 2P01 1 224 #N/A 2438501133 CD-OWNER GUIDE VE175-2 WIZARD DATE:20030818 2P01 1
CPT
225 M-MS-0808-8007 2504250800 ADHESI TAPE 3M #1350 W=10mm Yellow K901 1 226 M-MS-0808-8007 2504250800 ADHESI TAPE W10mm*L60M*T0.083mm Yellow K901 1 227 #N/A 2700514900 ACCESSORY ASS'Y VE175(23) B012 1 228 #N/A 2700614900 PACKING ASS'Y VE175(23) B013 1 229 #N/A 2701514900 FRONT ASS'Y VE175(23) B022 1 230 #N/A 2701614900 FINAL ASS'Y VE175B(23) B023 1 231 #N/A 2702210900 PCB-CON VE175(2) BB31 1 232 #N/A 2702310900 PCB POWER VE175(2) BC31 1 233 #N/A 2704210900 AUTO INSERT-CON VE175(2) BB41 1 234 #N/A 2704310900 AUTO INSERT-POWER VE175(2) BC41 1
!
ViewSonic Corporation
37
Confidential –DoNotCopy
VE175/b-2
235 #N/A 2708110900 FRONT BEZEL VE175(2) BT31 1 236 #N/A 2708614900 CABI BACK VE175B(23) BN31 1 237 #N/A 2710110900 MANUAL INSERT-MAIN VE175(2) BA42 1 238 #N/A 2710210900 PROCESS-MAIN VE175(2) BA43 1 239 #N/A 2710610900 MANUAL INSERT-CON VE175(2) BB42 1 240 #N/A 2711110900 MANUAL INSERT-POWE
R
VE175(2) BC42 1 241 #N/A 2711210900 PROCESS-POWER VE175(2) BC43 1 242 #N/A 2711310900 MI OTHER-POWER VE175(2) BC49 1 243 #N/A 2718114900 LCD PANEL ASS'Y VE175(23) BT32 1 244 #N/A 2718514900 FRONT OTHER VE175(23) BT39 1 245 #N/A 2718610900 STAND ASS'Y VE175(2) BN32 1 246 #N/A 2719010900 FINAL OTHER VE175(2) BN39 1 247 #N/A 2720110900 V-TYPE-MAIN VE175(2) BA52 1 248 #N/A 2720610900 V-TYPE-CON VE175(2) BB52 BB53 2 249 #N/A 2721110900 V-TYPE-POWER VE175(2) BC52 BC53 2
Ite
m
ViewSonic P/N Ref. P/N Description Location Q'ty Remark
1
A-PC-0106-0143
2427130082 POWER CORD CHINA WALL 1.83M GE96750 P951 1
2
#N/A
2055613334 LABEL VIEWSONIC VE175B 3C STICKER 6P04 1
3
#N/A
2002310338 GUARANT CARD VIEWSONIC CHINA WARRANTY CARD 6P05 1
4
M-LB-0813-0002
2056603050 SERIAL LABEL VS WARRANTY CARD SERIAL NO-J 6P07 1
5
#N/A
2013051800 POLYETHY BAG JT166A14 500LX470WX490H t=0.08 6P70 1
Ite
m
ViewSonic P/N Ref. P/N
Location
Q'ty Remark
1
M-MS-0808-9159
2002310330 GUARANT CARD VIEWSONIC VE175B-2 QSG
2P02
1
2
M-MS-0808-9160 2002310371 GUARANT CARD VIEWSONIC VE175B-2 QSG CPT 2P02 1 CPT
3
P-BX-0601-0884
2011170008 CARTON BOX VE175B-2 VLCDS23895-7W
6P01
1
4
C-BC-0302-0410
2022259205 CABI BACK PC+ABS MIDNIGHT GRAY NON-STAMP
2C01
1
5
C-FP-0301-0153
2024263004 FRONT BEZEL PC+ABS 94V0 MIDNIGHT GRAY
1F01
1
6
M-MS-0808-1074
2026252603 CASE ABS 94HB MIDNIGHT GRAY
2C04
1
7
M-MS-0808-1315
2027255303 DUST COVER ABS 94HB MIDNIGHT GRAY
5B08
1
8
PL-PS-0715-0187
2028254803 STAND ABS 94HB MIDNIGHT GRAY
5B01
1
9
PL-BT-0706-0147
2044260904 FUNCTION KEY ABS 94V0 MIDNIGHT GRAY
1F03
1
10
M-MS-0808-4026
2051350200 NAME PLATE JD144V3 VIEWSONIC 3BIRDS AL
1F19
1
11
M-LB-0203-0695
2055132060 LABEL VE175B-2 VLCDS23895-7W 030311
6P50
1
12
M-LB-0813-0921 2055132106 LABEL VE175B-2 VLCDS23895-7W CPT 6P50 1 CPT
13
M-LB-0813-0871
2055632025 UPC LABEL VE175B-2 VLCDS23895-7W
6P02
1
14
M-LB-0813-0922 2055632030 UPC LABEL VE175B-2(3) VLCDS23895-7W CPT 6P02 1 CPT
15
M-LB-0203-0065
2055636016 LABEL VE175B-2 VLCDS23895-7W SMALL
6P03
1
16
A-PC-0106-0121
2427130046 POWER CORD USA WALL 1.8M BLACK
P951
1
17
A-PC-0106-0138
2427130047 POWER CORD E WALL 1.8M BLACK
P952
1
18
A-CD-VE175B-2
2438501108 CD-OWNER GUIDE VE175B-2 WIZARD DATE:20030616
2P01
1
19
#N/A 2438501134 CD-OWNER GUIDE VE175B-2 WIZARD DATE:20030818 2P01 1 CPT
20
#N/A 2700514901 ACCESSORY ASS'Y VE175B(23) B012 1
21
#N/A 2700614901 PACKING ASS'Y VE175B(23) B013 1
22
#N/A 2701514901 FRONT ASS'Y VE175B(23) B022 1
23
#N/A 2701614901 FINAL ASS'Y VE175B(23) B023 1
24
#N/A 2708110901 FRONT BEZEL VE175B(2) BT31 1
25
#N/A 2708614901 CABI BACK VE175B(23) BN31 1
26
#N/A 2718114901 LCD PANEL ASS'Y VE175(23) BT32 1
27
#N/A 2718514901 FRONT OTHER VE175B(23) BT39 1
28
#N/A 2718610901 STAND ASS'Y VE175B(2) BN32 1
29
#N/A 2721210900 H-TYPE-POWER VA720(2) BC53 1
VE175-2 INDIVIDUAL PARTS OF VSCN-G (China)
VE175b-2 (QDI & CPT) BOM LIST (Different Parts from VE175-2)
Description
!
ViewSonic Corporation
38
Confidential –DoNotCopy
VE175/b-2
ItemViewSonic P/N Ref. P/N Description Location Q'ty Remark
1
#N/A
2427130097 POWER CORD CHINA WALL 1.83M BLACK P951 1
2
#N/A
2056606021 SERIAL LABEL VS WARRANTY CARD SERIAL NO-J 6P07 1
VE175b-2 INDIVIDUAL PARTS OF VSCN-G (China) (Different Parts from VE175-2)
!
ViewSonic Corporation
39
Confidential –DoNotCopy
VE175/b-2
*Readers Response*
Dear Readers:
Thank you in advance for your feedback on our Service Manual,which allows continuous improvement
of our products. We would appreciate your completion of the Assessment Matrix below, for return to ViewSonic
Corporation.
Assessment
B.Are you satisfied with the VE175-2/ VE175b-2 service ma nual?
C. Do you have any other opinion or suggestion about this service manual?
Readers basic data:
After completing this form, please return it to ViewSonic Quality Assurance
A. What do you think about the content after reading VE175-2/ VE175b-2 Service Manual?
:emaN:eltiT
:ynapmoC
:ddA
:leT:xaF
:liam-E
metI tnellecxE dooG riaF daB
tnetnoClaunaMecivreS.1
tuoyaLlaunaMecivreS.2
gnitsildnamrofehT.3
tinU tnellecxE dooG riaF daB
in the USA at facsimile
1-909-839-7943.
You may also e-mail any suggestions to the Director of Quality System & Process
(marc.maupin@viewsonic.com)
!
!
ViewSonic Corporation
40
Confidential –DoNotCopy
VE175/b-2
2. SPECIFICATIONS
1. PRECAUTIONS AND SAFETY NOTICES
3. FRONT PANEL FUNCTION CONTROL DESCRIPTION
4. CIRCUIT DISCRIPTION
5. ADJUSTING PROCEDURE
6. TROUBLE SHOOTING FLOW CHART
7. EXPLODED DIAGRAM
8. EXPLODED DIAGRAM
9. BLOCK DIAGRAM
10. SCHEMATIC DIAGRAM
Loading...
