Page 1
VE150 ViewPanel
®
User’s Guide
VLCDS21458-1
with Plug and Play
15.1" Viewable Diagonal
Page 2
E
N
G
L
I
S
H
ViewSonic VE150
1
For Your Records
The serial number of this product is on the back of the ViewPanel. Write the
serial number of this unit in the space below and keep this booklet as a
permanent record of your pur chase to aid in identification in the event of theft
or loss.
Model Name: ViewSonic VE150
Model Number: VLCDS21458-1
Serial Number: __________________
Purchase Date: ___________________
Power Cord Safety Guidelines
Caution : Use a po wer cable that is properly grounded. Always use the A C cords listed
below for each area :
USA ...........................UL
Canada ......................CSA
Germany ....................VDE
Switzerland ................SEV
Britain .........................BASEC/BS
Japan .........................Electric Appliance Control Act
In other areas, use AC cord which meets local safety standards.
Register your ViewPanel at www.viewsonic.com. It’ s f ast, easy, and will simplify future support
needs.
Electronic Warranty Registration
Copyright © ViewSonic Corporation 1998. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.
Microsoft, Windows, Windows NT, and the Windows Logo are registered trademarks of Microsoft
Corporation in the United States and other countries.
Vi ewSonic, V iewMeter , and ViewMatch are registered trademarks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association (VESA). DPMS is a
trademark of VESA.
E
NERGY STAR is a registered trademark of the U.S. Environmental Protection Agency (EPA).
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from furnishing this
material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specifications without notice. Information in this document may change without
notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.
As an ENERGY STAR® partner, ViewSonic Corporation has determined that this product meets the
ENERGY STAR® guidelines for energy efficiency.
Page 3
E
N
G
L
I
S
H
ViewSonic VE150
2
Important Safety Instructions
1 Read these instructions thoroughly .
2 Follow all w arning and instructions marked on this product.
3 Unplug the product from the wall outlet before cleaning. See the
Cleaning the Vie wPanel
on page 12.
4 Do not use the product near water . Ne ver spill liquid of an y kind on the product.
5 Do not place the product on an unstable cart, stand, or table. Doing so ma y cause the
product to fall, which can seriously damage it.
6 Slots and openings in the cabinet are provided for v entilation. To ensure reliable
operation, nev er block these ventilation slots b y placing the product on a bed, sofa, rug,
or similar surface. This product should ne v er be placed near or over a r adiator or heat
register; or installed in any enclosure that pre vents proper v entilation.
7 Make sure the power source complies with the po wer recommendation printed on the
back of the product. If you are not sure of the type of po wer provided b y the w all socket,
consult your dealer or local power company.
8 Do not place any object on the power cord. Do not place this product where people could
walk on the power cord.
9 If you use an extension cord with this product, mak e sure the total ampere rating of the
product(s) plugged into the extension cord does not e xceed the ampere rating of the
extension cord.
10 Nev er push objects of any kind through the ventilation slots at the bac k of the product. To
do so could risk fire or electric shock.
11 Do not attempt to service this product yourself. Opening or removing co vers ma y e xpose
you to dangerous voltage that could cause fire or electric shock. Refer all servicing
needs to authorized service personnel.
12 Unplug this product from the wall outlet and contact authorized service personnel under
the follo wing conditions:
a) When the power cord or plug is damaged or fra yed.
b) If a liquid has been spilled into or on the product, including rain.
c) If the product does not operate normally when operating instructions are follow ed.
Only adjust those controls that are cov ered by the operating instructions, since
improper adjustment of other controls may result in damage and will often require
extensive w ork by a qualified technician to restore the product to normal operation.
d) If the product has been dropped or the cabinet has been damaged.
e) If the product exhibits a distinct change in perf ormance, indicating a need for
service.
Page 4
E
N
G
L
I
S
H
ViewSonic VE150
3
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate r adio frequency energy , and if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. Howe ver , there is no guarantee that interf erence will not occur in a
particular installation. If this equipment does cause unacceptable interf erence to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the follo wing measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiv er.
● Connect the equipment into an outlet on a circuit diff erent from that to which the
receiver is connected.
● Consult your dealer or an e xperienced radio/TV technician f or help.
FCC Warning:
T o assure continued FCC compliance, the user m ust use the provided
grounded power suppl y cord and the shielded video interface cable with
bonded ferrite cores. Also, an y unauthorized changes or modifications to this
ViewPanel w ould void the user’ s authority to operate this device.
Department of Industry Canada (IC) Compliance Notice
This digital apparatus does not exceed the Class B limits f or radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
DOC avis de conformation
Cet appareil est bien conforme à la directive communautaire No 82/499/CEE.
CE Certification
This device complies with the requirements of the EEC directive 89/336/EEC
with regard to "Electromagnetic compatibility ."
Page 5
4
Getting Started
ViewSonic VE150
E
N
G
L
I
S
H
CONTENTS
Power Cord Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Getting Started
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Quick Installation* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation
Adjusting the Screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
On-Screen Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Other Information
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cleaning the ViewPanel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . back cover
*T o meet your future needs, and to receive any additional product information as it becomes a vailable,
please register your monitor's warranty on the Internet at: http://www .viewsonic.com.
Page 6
5
ViewSonic VE150
Getting Started
E
N
G
L
I
S
H
Congratulations on your purchase of an ViewSonic VE150 color Vi ewPanel®!
Save the original box and all packing material for your future shipping needs.
The word "Windows®" in this user guide refers to the following Microsoft
®
operating systems: Windows '95, Windows '98, Windows NT® (4.0).
Pac kage Contents
Your ViewSonic® VE150 package includes the following:
• ViewSonic VE150 ViewPanel
• Video cable (15 pin mini D-sub connector)
• DC adapter
• Power cord
• User’s guide
• INF and ICM installation files on CD-ROM
IMPORTANT: The supplied INF file assures compatibility with Windows
operating systems, and the ICM (Image Color Matching) file ensures accurate
on-screen colors. ViewSonic r ecommends that you install both files: insert the
CD-ROM into your system, wait for it to auto-install, select “Monitor
Drivers,” and f ollow the on-screen instructions.
• Sit at least 18" from the ViewPanel.
• DO NOT APPLY PRESSURE TO THE SCREEN. The LCD screen is
very delicate.
• DO NOT TOUCH THE SCREEN DIRECTLY WITH YOUR
FINGERS. You ma y damage the screen, and oil from your skin is
difficult to remove.
• Avoid exposing the ViewPanel to direct sunlight or other heat source.
The ViewPanel should be facing away from direct sunlight to reduce
glare.
• Choose a well ventilated area to position your ViewPanel to allow
adequate dissipation of heat. Do not place anything on top of the
ViewPanel.
• Ensure the area around the ViewPanel is clean and moisture-free.
• If smoke, abnormal noise, or strange odor is present, immediately
switch the ViewPanel off and call your dealer. It is dangerous to
continue using the ViewPanel.
• Never remove the rear cover. The display unit contains high-voltage
parts. You may suffer electric shock if you touch these parts.
• Always handle your ViewPanel with care when moving it.
Precautions
Getting Started
Page 7
6
Getting Started
ViewSonic VE150
E
N
G
L
I
S
H
Quick Installation
1 Connect video cable
Make sure both the ViewPanel® and
computer are powered OFF. Connect the
video cable to the computer , then to
the ViewPanel.
Macintosh® users:
Connect a
Macintosh adapter (part No. VMAC-1)
to the video cable, then to the
ViewPanel. To order an adapter,
contact Vie wSonic (see the back c o v er
of this guide). Y ou will need to provide
your V ie wP anel's serial number.
2 Connect power adpater and cables
Connect the DC Adapter to the
ViewPanel, then to the po wer cord.
Connect the power cord to a properly
grounded AC outlet.
3 Power -on computer and Vie wP anel
P o w er ON the computer, then power
ON the ViewP anel .
NOTE: At this point Windows
®
98 users
will receive a message asking them to
install the VE150’ s INF file . Insert the
enclosed CD-ROM diskette and f ollow
the on-screen instructions.
4 IMPORTANT: Initial screen image
adjustments
A. If there is no screen image and you
see the Outside Range Limits
message, check to make sure y our
system is set to one of the f actory
preset timing modes (see page 10.)
• If you also have a CRT monitor,
connect it t o your computer and
set the signal timing.
•
Windows® 95 & 98 users:
If you
4 A. (continued)
do not have a CR T monitor , you
may reboot y our system in "Saf e
Mode" to display a supported
timing. See your Windows
®
documentation for instructions.
B. For the best image quality, set the
timing (resolution and refresh rate)
of your graphics card to:
1024x768@60Hz.
C. If you see vertical bars after
powering on the ViewPanel:
(1) From the Windows 95 or 98
ST ART menu, select SHUTDOWN
(but do not click "Yes").
(2) Use the VE150 controls to
adjust the CLOCK control until
the ve rtical bars vanish. (See
page 8)
(3) Adjust CLOCK PHASE until the
horizontal bars ("line noise")
are minimized. (See page 9)
(4) Repeat steps (2) and (3) to
optimize the sharpness of the
screen image.
(5) Select "No" to close the Windows
SHUTDOWN screen.
NOTE: If you see the Check Signal
Cable message , check to see that
the video cable and power cable are
both securely attached.
Installation is complete!
Enjoy your ne w color VE150 Vie wPanel!
Write the serial number (see back of the
ViewP anel) in
"For y our Records"
on page
1 of this users guide and register the
warranty of your ViewPanel on the Int ern et
at: http//:www.viewsonic.com
DC Adapter
Video cable
Power
cord
Page 8
ViewSonic VE150
E
N
G
L
I
S
H
7
Operation
Operation
Adjusting the Screen Image
With your ViewPanel powered ON, follow the numbered steps in sequence as
shown below.
Power light:
Green =On
Amber =Power
Saving
Mode
Press [<] or [>] to
adjust the control
you selected.
Press [<] or [>] to
highlight the control
you want to adjust.
To save your
adjustments and
exit all OSD screens,
press the MENU
button.
Press the ENTER button
to display the adjustment
screen for the control you
want to adjust.
➌
➎
➋
➍
➊
Press the
MENU button
to display the
Main Menu.
To save your
adjustments and
return to the Main
Menu, press the
ENTER button.
Power
ON/
OFF
button
or:
See the next page for information about each on-screen control.
IMPORTANT: The supplied INF file assures compatibility with Windows
operating systems, and the ICM (Image Color Matching) file ensures accurate
on-screen colors. ViewSonic® recommends that you install both files: insert
the CD-ROM into your system, wait for it to auto-install, select “Monitor
Drivers,” and follow the on-screen instructions.
Page 9
8
ViewSonic VE150
E
N
G
L
I
S
H
Operation
Contrast adjusts the contrast
between the background (black
level) and the foreground (white
level) of the screen image.
[>] Increases contrast
[<] Decreases contrast
Brightness adjusts the
background black level of the
screen image.
[>] Increases brightness
[< ] Decreases brightness
Shortcut
: Before you display the
Main Menu, press [>] or [<] to
display the Brightness
adjustment screen.
H Position (Horizontal Position)
moves
the screen image to the
left or right.
[>] Moves the screen image right
[< ] Moves the screen image left
V Position (Ver tical Position)
moves the screen image up or
down.
[> ] Moves the screen image up
[<] Moves the screen image down
Clock adjusts the hor izontal
size (width) of the screen image,
and mimimizes the vertical bars
that can be present during initial
installation.
[>] Increases
the width of the
screen image
[< ] Decreases the width of the
screen image
"Contrast" Ad ju st me nt
Screen
(example)
MAIN MENU with
"Contrast" highlighted.
To display the Contrast
adjustment screen, press
the ENTER button. (See
below.)
On-Screen Controls
Page 10
ViewSonic VE150
E
N
G
L
I
S
H
9
Operation
Clock Phase minimizes narrow
horizontal lines ("horizontal
noise") and sharpens displayed
characters of text.
[> ] or [<] to adjust
T
OSD Time allows you to select
the length of time the Main
Menu or adjustment screen
OSD (On Screen Display) is
displayed on screen.
[>] Increases
the OSD display
time.
[<] Decreases the OSD display
time.
ViewMatch® Color provides
two preset color temperature
options and a user-defined
option.
[>] or [<] to highlight an option.
9300K is slightly bluish white,
ideal for use under fluorescent
lights.
6500K (factory default) is warmwhite, good for displaying a video
image.
User allows you to adjust the
intensities of R (red), G (green),
and B (blue) individually.
[>] or [<] to adjust each color
OSD Position allows you to
select where the Main Menu or
adjustment screen OSD (On
Screen Display) will display.
H Position (Hor izontal Position)
[> ] moves the OSD to the right
[< ] moves the OSD to the left
V Position (Ver tical Position)
[> ] moves the OSD up
[< ] moves the OSD down
Language allows you to
choose from one of five
languages for the Main Menu
and adjustment screens:
English, German, French,
Spanish, and Italian.
[>] or [<] to select a language.
Mode Recall recalls the
factory default settings for most
controls.
With "YES" selected, the press
ENTER button to the recall
factory default setting for all
controls (except User Color).
If you change your mind and
would
not like to recall factory
default settings, highlight "NO"
and press the ENTER button.
ViewMeter® displays the signal
timing (resolution and refresh
rate) coming from the video card
in your computer.
For example,1024x768 / 60Hz
means 1024x768 resolution at a
refresh rate (vertical frequency)
of 60 Her tz.
NOTE: If the signal timing
coming from your video card is
not one of the factory presets, it
will not be recalled the next time
you power-on the ViewPanel.
Tip: For the best results, adjust
Clock and Clock Phase
together:
1 From the Windows® 95 or 98
ST ART menu, select SHUTDOWN
(but do not clic k "Yes").
2 Adjust Clock until the vertical
bars vanish.
3 Adjust Cloc k Phase until the
horizontal lines ("line noise") are
minimized.
4 Repeat steps 2 and 3 to
optimize the sharpness of the
screen image.
5 Select "No" to close the Windows
SHUTDOWN screen.
Page 11
10
E
N
G
L
I
S
H
ViewSonic VE150
Other Information
Specifications
LCD Type 15.1" diagonal viewab le screen, TFT Active Matrix Panel
0.30mm pixel pitch
Color Filter RGB Stripe Arrangement, c olors = 8-bit, 16M
Glass surface Anti-Glare and Hard Coating (3H)
Minimum Left 55
0
Viewing Right 55
0
Angles Up 40
0
Down 40
0
Input Signal Video RGB analog (0.7Vp-p, 75 ohms)
Sync H/V (5Vpp) separated (TTL)
fH: 31-61 kHz, fV: 56-75 Hz
Compatibility PC Up to 1024 x 768 NI (Non Interlaced)
Macintosh®*
1
Power Macintosh® (832 x 624)
Power Voltage AC 100-240V 50/60 Hz
Display Area 307mm (H) x 230mm (V)
Operating Temperature 32°F to 95°F (0°C to 35°C)
Conditions Humidity 10% to 80% (no condensation)
Altitude To 10,000 feet
Storage Temperature -4°F to +140°F (-20°C to +60°C)
Conditions Humidity 5% to 90% (no condensation)
Altitude To 40,000 feet
Dimensions Physical 405.2mm (W) x 361.6mm (H) x 182.4mm (D)
16.0" (W) x 14.2" (H) x 7.2" (D)
Weight Net 5.2kgs (11.4 lbs) ViewPanel only
Regulations UL, CSA, DOC, NOM, CE, FCC-B, MPR II,
ENERGY STAR® , Energy 2000, TCO '95
Power sa ving On 40W (max) Green LED
modes DPMS Suspend <15W Amber LED
DPMS Off <5W Amber LED
*1A Macintosh computer requires VMA C-1 Macintosh adapter. To order an adapter, contact Vi e wSonic
®
Customer Support (see the back cover). You will need to provide your monitor's serial number.
*
2
Warning: Do not set the graphics card in your computer to exceed these maximum refresh r ates.
Doing so may result in permanent damage to the ViewPanel. NI = Non Interlaced.
Other Information
VESA® 640 x 350 NI @ 70Hz
IND
640 x 480 NI @ 60Hz
VESA 640 x 480 NI @ 72Hz
VESA 640 x 480 NI @ 75Hz
VESA 800 x 600 NI @ 56Hz
VESA 800 x 600 NI @ 60Hz
VESA 800 x 600 NI @ 72Hz
Preset Timing Modes*
2
VESA 800 x 600 NI @ 75Hz
VESA 1024 x 768 NI @ 60Hz
VESA 1024 x 768 NI @ 70Hz
VESA 1024 x 768 NI @ 72Hz
Macintosh 640 x 480 NI @ 67Hz
Macintosh 832 x 624 NI @ 75Hz
NOTE: The VE150 ViewPanel has been pre-adjusted to VESA 1024 x 768 NI @ 60Hz.
Page 12
11
ViewSonic VE150
E
N
G
L
I
S
H
Other Information
Troubleshooting
No power
• Make sure power button (or switch) is ON.
• Make sure A/C power cord is securely connected to the AC/DC adapter
supplied with the ViewPanel
®
, then connected to a power outlet.
• Plug another electrical device (like a radio) into the power outlet to verify
that the outlet is supplying proper voltage.
Power on but no screen image
• Make sure the video cable supplied with the ViewPanel is tightly secured to
the video output port on the back of the computer.
• Adjust brightness and contrast.
• Macintosh
®
and workstation users: your system may require a cable
adapter. Verify that the settings on the adapter are adjusted correctly.
Screen image with horizontal "noise" or unclear characters
• Adjust the CLOCK PHASE control (see page 8).
"Outside Range Limits" message appears
• Verify that the output from your computer's video card is within operating
range: a refresh rate (ver tical frequency) between 56 and 75 Hertz, and a
resolution of 1024 x 768 or lower. See the table on page 10 for supported
timing modes.
"Check Signal Cable" message appears
• If this message appears, check to make sure the video signal cable is
securely connected. Also check for Loose or broken pins in the cable
connector could cause an improper connection. NOTE: the power LED will
be lit amber.
• If the "Power Saving Mode" message briefly appears
and the power LED is
lit amber, the ViewPanel is functioning normally.
Page 13
12
E
N
G
L
I
S
H
ViewSonic VE150
Other Information
Cleaning the View Panel
®
• DO NOT APPLY PRESSURE TO THE SCREEN.
• NEVER POUR OR SPRAY ANY LIQUID DIRECTLY ONTO THE
SCREEN OR CASE OF THE VIEWPANEL.
To clean the screen:
1 Gently wipe the screen with a clean camel hair lens brush, or a soft,
clean, lint-free cloth. This removes dust and other particles that can
scratch the screen.
2 If still not clean, blow on the screen and gently wipe with a soft, clean,
lint-free cloth.
DISCLAIMER
ViewSonic® does not recommend the use of any liquid cleaner s on the ViewPanel
screen or case. Chemical cleaner s have been reported to damage the screen and/or
case of the ViewPanel. Further, Vie wSonic does not recommend applying pressure
when wiping the ViewPanel screen clean. Vie wSonic will not be liable for dama ge
resulting from use of liquid cleaner s or resulting from applying pressure to the
screen.
Page 14
13
ViewSonic VE150
E
N
G
L
I
S
H
Other Information
Limited W arranty
ViewSonic
VE150
ViewPanel
What the warranty covers:
ViewSonic
®
warrants its products to be free from defects in material and wo rkmanship during the
warranty period. If a product pro ves to be defective in material or workmanship during the warranty
period, ViewSonic will at its sole option repair or replace the product with a like product. Replacement
product or parts may include remanufactured or refurbished parts or components.
How long the warranty is effective:
The ViewSonic
VE150
ViewPanel® is warranted for three (3) years for all parts excluding the light
source, three (3) years f or all labor, and one (1) year for the light source from the date of the first
consumer purchase.
Who the warranty protects:
This warranty is valid only for the first consumer purchaser.
What the warranty does not cover:
1. Any product on which the serial number has been defaced, modified or removed.
2 . Damage, deterioration or malfunction resulting from:
a. Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product
modification, or failure to follo w instructions supplied with the product.
b. Repair or attempted repair by anyone not authorized by ViewSonic.
c. Any damage of the product due to shipment.
d. Removal or installation of the product.
e. Causes external to the product, such as electric power fluctuations or failure.
f. Use of supplies or parts not meeting ViewSonic's specifications.
g. Normal wear and tear.
h. Any other cause which does not relate to a product defect.
3. Removal, installation, and set-up service charges.
How to get service:
1. For information about receiving service under warranty, contact ViewSonic Customer Support.
See the back cover of this user's guide .
2. To obtain warranty service, you will be required to provide (a) the original dated sales slip, (b) your
name, (c) your address, (d) a description of the problem, and (e) the serial number of the product.
3. Take or ship the product prepaid in the original container to your ViewSonic dealer, an y ViewSonic
service center or ViewSonic.
4. For additional information or the name of the nearest ViewSonic service center, contact y our
ViewSonic dealer or ViewSonic.
Limitation of implied warranties:
THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED , WHICH EXTEND BEYOND THE
DESCRIPTION CONTAINED HEREIN INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Exclusion of damages:
VIEWSONIC’S LIABILITY IS LIMITED T O THE COST OF REPAIR OR REPLACEMENT OF THE
PRODUCT. VIEWSONIC SHALL NOT BE LIABLE FOR:
1. DAMAGE TO OTHER PR OPER TY CAUSED BY ANY DEFECTS IN THE PRODUCT, DAMAGES
BASED UPON INCONVENIENCE, LOSS OF USE OF THE PR ODUCT, LOSS OF TIME, LOSS OF
PROFITS, LOSS OF BUSINESS OPPORTUNITY, LOSS OF GOODWILL, INTERFERENCE WITH
BUSINESS RELATIONSHIPS, OR OTHER COMMERCIAL LOSS , EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMA GES.
2. ANY OTHER DAMA GES , WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
3. ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY.
Effect of state law:
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state. Some states do not allo w limitations on implied warr anties and/or do not allow the
exclusion of incidental or consequential damages, so the above limitations and exclusions may not
apply to you.
Sales outside the U.S.A.:
For ViewSonic products sold outside of the U.S.A., contact your ViewSonic dealer for warr anty
information and service.
REV 09/24/98
Page 15
14
E
N
G
L
I
S
H
ViewSonic VE150
Other Information
NO TES
Page 16
V8120501501-P
Vi ewSonic® Corporation
381 Brea Canyon Road
Walnut, CA 91789
Tel (909) 869-7976
Tel (800) 688-6688
Fax (909) 468-1202
For ViewSonic ® Customer Support:
U .S. and Canada only
1-800-688-6688
From outside U .S. and Canada
909-869-7976
From Europe
44 (1293) 643-900
From Asian/Pacific Rim countries
886 (22) 248-4072
T echnical Support Questions
Product or Dealer Questions
W orld Wide W eb :
http://www.viewsonic.com
To order parts or accessories
(from U .S. & Canada only)
1-800-888-8583
Loading...
