ViewSonic®
VG710b/VG710s
LCD Display
- User Guide
- Guide de l'utilisateur - Bedienungsanleitung - Guía del usuario
- Guida dell'utente - Guia do usuário
- Användarhandbok
- Käyttöopas
- Podręcznik użytkownika - Használati útmutató
- Pyководство польэователя
- Uživatelská píruka -
-
-
-
-
Content |
|
Compliance Information.............................................................................. |
1 |
Important Safety Instructions...................................................................... |
2 |
Product Registration................................................................................... |
3 |
Getting Started |
|
Package Contents ...................................................................................... |
4 |
Precautions ................................................................................................ |
4 |
Quick Installation ........................................................................................ |
5 |
Installation of Wall Mount (Optional)........................................................... |
6 |
Using the LCD Display |
|
Setting the Timing Mode............................................................................. |
7 |
OSD and Power Lock Settings................................................................... |
7 |
Adjusting the Screen Image ....................................................................... |
8 |
Main Menu Controls ................................................................................... |
9 |
Other Information |
|
Specifications ........................................................................................... |
14 |
Troubleshooting........................................................................................ |
15 |
Customer Support .................................................................................... |
16 |
Cleaning the LCD Display ........................................................................ |
17 |
Limited Warranty ...................................................................................... |
18 |
ViewSonic VG710b/VG710s
Compliance Information
For U.S.A.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC Warning
To assure continued FCC compliance, the user must use grounded power supply cord and the cables which are included with the equipment or specified. Also, any unauthorized changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this device.
For Canada
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numeique de la Classe B repecte toutes les exigences du Reglement sur le materiel brouilleur du Canada.
CE Conformity for European Countries
CE Conformity
The device complies with the requirements of the EEC directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility,” and 73/23/EEC as amended by 93/68/EEC Art.13 with regard to “Safety.”
ViewSonic VG710b/VG710s |
1 |
Important Safety Instructions
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this unit near water.
6.Clean only with dry cloth.
7.Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8.Do not install near any heat sources such as radiators, heat registers, stoves, or other devices (including amplifiers) that produce heat.
9.Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs. Convenience receptacles and the point where they exit from the unit. Be sure that the power outlet is located near the unit so that it is easily accessible.
11.Only use attachments/accessories specified by the manufacturer.
12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the unit. When a cart is used, use caution when moving the cart/unit combination to avoid injury from tip-over
13.Unplug this unit when unused for long periods of time.
14.Refer all servicing to qualified service personnel. Servicing is required when the unit has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the unit, the unit has been exposed to rain or moisture, does not operate normally, or has been dropped.
ViewSonic VG710b/VG710s |
2 |
Copyright© ViewSonic Corporation, 2004. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC are trademarks of VESA.
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA). As an ENERGY STAR® partner, ViewSonic Corporation has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to change product specifications without notice. Information in this document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic® Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic.
For Your Records
Product Name: |
VG710b/s |
|
ViewSonic 17” LCD Display |
Model Number: |
VLCDS23719-5W//4W |
Document Number: |
VG710b/s-1_UG_ENG Rev. 1C 12-31-04 |
Serial Number: |
_______________________________ |
Purchase Date: |
_______________________________ |
Product disposal at end of product life
ViewSonic is concerned about the preservation of our environment. Please dispose of this product properly at the end of its useful life. For TCO'03 recycling information, please refer to our website:
1.USA: www.viewsonic.com/pdf/recyclePlus.pdf
2.Europe: www.viewsoniceurope.com
3.Taiwan: recycle.epa.gov.tw
ViewSonic VG710b/VG710s |
3 |
Getting Started
Congratulations on your purchase of a ViewSonic® LCD display.
Important! Save the original box and all packing material for future shipping needs.
NOTE: The word “Windows” in this user guide refers to the following Microsoft operating systems: Windows ‘95, Windows NT, Windows ‘98, Windows 2000, Windows Me (Millennium), and Windows XP.
Package Contents
Your LCD display package includes:
•LCD display
•VGA cable
•Power cord
•AC/DC power adapter
•Audio cable (for speakers)
•ViewSonic Wizard CD-ROM
NOTE: The CD jacket contains the Quick Start Guide, and the CD includes the User Guide PDF files and INF/ICM display optimization files. The INF file ensures compatibility with Windows operating systems, and the ICM file (Image Color Matching) ensures accurate onscreen colors. ViewSonic recommends that you install both files.
Precautions
•Sit at least 18” from your LCD display.
•Avoid touching the screen. Skin oils are difficult to remove.
•Never remove the rear cover. Your LCD display contains high-voltage parts. You may be seriously injured if you touch them.
•Avoid exposing your LCD display to direct sunlight or another heat source. Orient your LCD display away from direct sunlight to reduce glare.
•Always handle your LCD display with care when moving it.
•Place your LCD display in a well ventilated area. Do not place anything on your LCD display that prevents heat dissipation.
•Ensure the area around the LCD display is clean and free of moisture.
•Do not place heavy objects on the LCD display, video cable, or power cord.
•If smoke, abnormal noise, or strange odor is present, immediately switch the LCD display off and call your dealer or ViewSonic. It is dangerous to continue using the LCD display.
ViewSonic VG710b/VG710s |
4 |
Quick Installation
1.Connect power cord and AC/DC adapter
2.Connect video cable
•Make sure both the LCD display and computer are turned OFF
•Remove rear panel covers if necessary
•Connect the video cable from the LCD display to the computer
Macintosh users: Models older than G3 require a Macintosh adapter. Attach the adapter to the computer and plug the video
cable into the adapter.
To order a ViewSonic® Macintosh adapter, contact ViewSonic Customer Support.
3. Turn ON LCD Display and computer
Turn ON the LCD display, then turn ON the computer. This sequence (LCD display before computer) is important.
NOTE: Windows users may receive a message asking them to install the INF file. This is on the CD.
4.Insert the ViewSonic Wizard CD into the computers CD drive.
Follow the on-screen instructions. If your computer does not have a CD-ROM drive, see “Customer Support” on page 16.
• Wait for the CD-ROM to auto-start.
NOTE: If the CD-ROM does not autostart: double-click on the CD-ROM icon in
the Windows Explorer, then double-click on viewsonic.exe.
•Follow the on-screen instructions.
5.Audio Installation (optional)
•Speakers Connect the audio cable (lime-colored) to the AUDIO OUT port of your computer’s sound card, then to the LCD display’s AUDIO IN port (see illustration below).
6.Windows users: Set the timing mode (resolution and refresh rate)
Example: 1280 x 1024 @ 60 Hz.
For instructions on changing the resolution and refresh rate, see the graphic card’s user guide.
Installation is complete. Enjoy your new ViewSonic, LCD display.
To be best prepared for any future customer service needs: print this user guide and write the serial number in “For Your Records” on page 3. (See back of LCD display.)
You can register your product online at the website for your region. See the Customer Support table in this guide.
The ViewSonic Wizard CD-ROM also provides an opportunity for you to print the registration form which you may mail or fax to ViewSonic.
DC IN |
|
|
|
|
|
|
Audio Cable |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
Video Cable |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rear panel covers
Power Code and AC/
DC adapter
AC Outlet
(Wall Socket)
Computer Power Cord
ViewSonic VG710b/VG710s |
5 |
