Content
Product Registration ......................................................................................................1
For Your Records ..........................................................................................................1
PRODUCT
Contents ........................................................................................................................2
Features ........................................................................................................................2
Power saver................................................................................................................... 2
Plug & play.....................................................................................................................2
SAFETY
Electrical ........................................................................................................................3
Common ........................................................................................................................3
SET UP YOUR LCD MONITOR
Installation......................................................................................................................4
Screen Adjustments.......................................................................................................4
OSD Control .................................................................................................................. 5
OTHER INFORMATION
Trouble Shooting ........................................................................................................... 8
Customer Support..........................................................................................................9
Maintenance ................................................................................................................10
Limited Warranty..........................................................................................................11
APPENDIX
Saft Guidelines ............................................................................................................12
Compliance Information for U.S.A. ..............................................................................13
CE Conformity for Europe............................................................................................13
09/15/04 A ViewSonic VE902m
Copyright © ViewSonic Corporation, 2004. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of
ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC are
trademarks of VESA.
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA).
As an ENERGY STAR® partner, ViewSonic Corporation has determined that this product meets the
ENERGY STAR® guidelines for energy efficiency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the
performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to change
product specifications without notice. Information in this document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without
prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes available, please
register your product on the Internet at: www.viewsonic.com. The ViewSonic® Wizard CD-ROM also
provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic.
For Your Record
Product Name: ViewSonic VE902m
Model Number: VS10552
Document Number: A-CD-VE902m-1
Serial Number: __________________
Purchase Date: __________________
Product disposal at end of product life
ViewSonic is concerned about the preservation of our environment. Please dispose of this product properly
at the end of its useful life. For TCO'03 recycling information, please refer to our website:
1. USA: www.viewsonic.com/pdf/recyclePlus.pdf
2. Europe: www.viewsoniceurope.com
3. Taiwan: recycle.epa.gov.tw
1
PRODUCT
Contents
Features
Power saver
Note：Save the original box and packing material for future shipping needs.
LCD Monitor and Base. Please refer to Quick Setup.
The Accessories in this LCD Monitor Model. Please refer to Quick Setup
High Brightness.
Light in weight.
Fast response time.
Stereo Speaker.
Power Saver.
Low electromagnetic wave and power saver.
Kensington security lock.
Safety certifications.
.
Plug & play
Power control system, also called (Power Saver), is installed inside the LCD Monitor.
If the monitor has not been used for a certain period of time, the system will turn the
monitor to low voltage mode to save power. Slight moving or any click will return to the
original image.
The VGA card inside the computer handles Power Saver. You can use computer
software to set the function.
The LCD Monitor is compatible with EPA ENERGY STAR and NÜTEK if used with a
VESA DPMS computer.
To save power, turn off the power of the LCD monitor when not in use.
The new VESA Plug and Play function is used which eliminates the complicated and
time-consuming installation process.
You can use the Plug and Play system without encountering usual installation
problems. Your computer system can easily identify and automatically adjust the
monitor.
The LCD Monitor uses Display Data Channel (DDC) to send Extended Display
Identification Data (EDID) to the computer system, so the computer system can be
set to monitor auto adjust.
2
SAFETY
Electrical
Sure the Voltage
Electrical Shock
Note: Please note the following safety precaution before using this monitor.
Before connecting the AC power cord to the DC adapter socket, make sure that
voltage of the DC adapter is suitable for local power.
Do not insert any metal object into opening on the LCD monitor casing to prevent
electrical shock.
To prevent electrical shock, do not touch the interior of the LCD monitor. Only a
qualified technician should open the casing of monitor.
If the power cord is damaged, do not use the LCD monitor. Do not place any object on
the power cord, and place the power cord away from crowded areas.
While pulling the LCD monitor plug away from the socket on the wall, hold the plug not
the power cord.
Do not expose the LCD monitor in the rain or somewhere closed to the water (such as
in the kitchen, near the pool).
If the LCD monitor is dampened, please unplug the power cord and contact Service
Center.
Unusual condition
Common
Monitor and Screen
Care
If the LCD monitors functions improperly, especially when making unusual noise or
spreading strange odor, unplug it immediately and contact service center.
Avoid touching the screen with your fingers or any tough objects. Oil from the skin is
difficult to remove, and touching objects to the screen may damage the panel. It is
suggested to clean the monitor by first turning it off and using a soft, dry cloth.
The LCD monitor should be placed in areas with low humidity and less dust. Please
watch out for environmental conditions on humidity and ventilation.
The LCD monitor should be kept away from heat sources and irradiation. For
example: kitchen, oven or direct sunlight and etc.
To reduce glare, avoid placing the monitor in a place that receives direct sunlight.
Avoid letting small children play with monitor. The frequent touching of the panel will
cause panel to look dirty and will affect the quality of the brightness if too dirty.
If moving the monitor, please handle with care when unplugging and moving it.
Do not place items over the monitor when placing and adjusting the LCD monitor.
If the LCD monitor is not in use for a long time, please unplug it and restore it into the
proper package, the original carton & packaging stuffs are preferred.
Clean screen
The opening on the LCD Monitor
overheating, the openings should not be blocked or covered. Do not place the LCD
monitor on a bed, sofa, blanket or other soft surfaces; or else the soft objects will
block the openings of the LCD monitors.
If you place the LCD Monitor on a bookshelf or other airtight spaces, it’s essential to
leave a space of 4”(10cm) distance between the Monitor and the hard surface.
Ensure the area around the LCD monitor is clean and free of moisture. Please refer to
[Maintenance] chapter for normal maintenance practice.
3
casing is for the purpose of ventilation. To prevent
SET UP YOUR LCD MONITOR
Installation
Notes
Installation Position
Workstation Height
Angle of Vision
Quick Installation
Screen
Adjustments
Auto Adjust
Note: Please read last section “ Safety” before you install the LCD Monitor.
Please note the instruction below prior to installing your LCD monitor.
Choose a position where the reflection of light is minimal and away from a window for
maximizing the quality of the screen image.
It is important to keep 30 cm between the LCD monitor to minimize eyestrain.
Position the LCD monitor slightly above your horizontal vision as you are sitting.
Tilt either forward or backward for the most comfortable viewing angle.
This LCD monitor supports connection to a computer or workstation. The steps are
described as Quick Setup.
After installation, please refer to “Auto Adjust” for automatic adjust procedures.
Though your computer system can identify the new LCD monitor system, the Auto Adjust
function can be as to enhance the display. To enter adjust mode, please refer to “OSD
Control”.
Turn the computer and LCD monitor on.
Self Test Function
Check (STFC):
Press ‘Auto’ button to start Auto Adjust.
The LCD monitor will start the Auto Adjust process automatically for 10 consecutive
seconds, where you will notice the image change as the Auto Adjust is working.
Your LCD monitor provides a STFC function, through which you can check whether
the LCD monitor functions are working properly.
If your LCD monitor is properly connected, but there is no image showing and the
indicator light keeps orange, please follow the steps below to start STFC.
Shutdown computer and LCD monitor.
Unplug the signal connector from the back of computer.
Turn the LCD monitor on.
If the image connector is disconnected or damaged, the image shown on following
figure will also appear during normal operation.
Turn off the LCD monitor and reconnect signal cable, and then turn the
computer and LCD monitor on.
If the LED of the LCD monitor is an orange color after completing the steps above,
please check your VGA card and computer system. Your monitor should be
operating properly.
4
OSD Control
Keypad Button
Definition
Thanks to the user-friendly design of OSD (On Screen Display), you can adjust your
monitor by the keypads in the front of the monitor.
Power Switch Power On/Off
1
LED Power Indicator
Green: Normal
Orange: Power Saving
Off: Power Off
2 Auto / Exit Automatically optimize positions, phase & clock when OSD
is not shown
Exit the OSD menu when OSD is shown
3 Turbo Quick brightness switching
┼/
4
5 ―/ Adjustment when OSD is shown
6 Menu Enter OSD
7 Speaker
Selection or adjustment when OSD is shown
Quick brightness adjustment
Quick contrast adjustment
Access sub-menu & selection
5
Operate Explanation
ting
Your LCD has been adjusted to its optimal status before shipment. You can also adjust
the image in accordance with the following illustrations and steps.
Press the “Menu” button to start the OSD feature.
Click the “+” or “-“ button to select the function to be adjusted.
Click the “Menu” button to access into the function to be adjusted.
Click the “+” or “-“ button to change the current setting of the function.
To exit the OSD menu or go back to the previous action by clicking the “Auto/Exit”
button. It will save the change automatically.
To repeat above steps for changing the setting of other functions.
Color Temp. Selection
Volume Adjustment
V-Position
Image Adjustment
Language Selection
s
Set
Input Source Selection (optional)
50
Audio Current Status Source Resolution & Frequency
Color Temp. Status
Input Source Status (Optional)
Notes
The OSD disappears several seconds after you stop pressing the buttons while
performing an adjustment.
Any changes are automatically saved in the memory when the OSD disappears.
Turning off the power should be avoided while using the menu.
Adjustments for clock, phase and positions are saved for each signal timing. Except
for these adjustments, all other adjustments have only one setting which applies to
all signal timings.
The color will change from white to pink while the function is selected.
6
Adjustment of
Screen
Function Definition
Primary
Directory
Audio
Color
Language
Settings
Secondary
Directory
Brightness
Contrast
Clock
Phase
H. Position
V. P o si t io n
Sharpness
Volume
Mute
9300K
7500K
6500K
User/Red
User/Green
User/Blue
English
Français
Italiano
Deutsch
Español
日本語
简体中文
繁體中文
OSD Timeout
OSD Position
Description
Adjust the brightness of the screen.
Adjust the contrast of the image.
Adjust the clock pulse of the image.
Adjust the focus of the image.
Move the image left and right on the screen.
Move the image up and down on the screen.
Adjust the picture sharpness of lower resolutions.
Adjust the volume of the audio.
Set up the audio to be mute on or off.
Set up the color temp. to be 9300K white color.
Set up the color temp. to be 7500K white color.
Set up the color temp. to be 6500K white color.
Adjust red/green/blue gain.
Select the language you want.
Adjust OSD display time setting.
Move OSD display position to any one of the following 5
positions within the overall screen.
Direct
1
2
3
4
Auto Setting
Recall
Input Source
Analog
Digital
(Optional)
You can skip the Menu pages and display an adjustment scale directly by using the
following button operations:
Brightness: Press the Brightness Button when the Menu is not displayed.
Contrast: Press the Contrast Button when the Menu is not displayed.
Auto Setting: Press the Auto Button when the Menu is not displayed.
Turbo: Press the Input Button when the Menu is not displayed.
Pct: Picture Mode (High brightness)
Text: Text Mode (Normal)
Eco Economy (Brightness of back-light is reduced)
Changing to a lower brightness mode can lessen eye fatigue.
Change from Picture Mode to Text Mode when working with text.
Change from Text Mode to Economy Modes when viewing the screen for long
periods.
Set up to adjust clock, phase and positions automatically.
Restore to factory settings
Select Analog input source:
Select Digital input source:
5
7
OTHER INFORMATION
Trouble
Shooting
No image
No Signal Input
“Out Of Range”
Fuzzy image
Image too bright
Image too dark
Irregular image
Distorted image
Check the information in this section to see if the problems can be solved before
requesting repair.
Note：The consumers are only allowed to solve the problems described as below.
Any unauthorized product modification, or failure to follow instructions
supplied with the product will end the warranty immediately.
Make sure power button is ON.
Check whether the LCD monitor and computer power cords are plugged and
whether there is a supply of power.
Check the signal connection between the computer and LCD monitor.
Check the computer image output resolution and frequency and compare the value
with the preset values (Please refer to [Appendix-Display Mode]).
Adjust Phase.
Adjust brightness and contrast by OSD.
Check the signal connection between the computer and LCD monitor.
Perform Auto Adjust.
Reset the LCD monitor. (perform the “Recall” function by OSD)
Take off extra accessories (such as signal extension cord).
Image is not centered
Size is not appropriate
Uneven color
Color too dark
Dark area distorted
White color is not white
Can’t adjust LCD monitor
with the buttons in the
front.
The other problem
Use OSD Image Menu to adjust H. Position and V. Position.
Check image size setting.
Perform Auto Adjust.
Use OSD Color Menu to adjust color setting.
Please contact the stores where you purchased the unit or service center listed at
your warranty card.
8
Customer
Support
For technical support or product service, see the table below or contact your reseller.
Note： You will need the product serial number.
Country/Region Web site
United States www.viewsonic.com/support/ T= (800) 688 6688
Canada www.viewsonic.com/support/ T= (866) 463 4775
T = Telephone
Email
F = Fax
service.us@viewsonic.com
F= (909) 444 8800
service.ca@viewsonic.com
F= (909) 468 1202
United Kingdom www.viewsoniceurope.com T= (0800) 833 648
F= +44 (0) 1293 643
910
"Europe/Middle
East/
Baltic countries/
North Africa"
www.viewsoniceurope.com Contact your reseller service.eu@viewsoniceurope.com
www.viewsonic.com.au/support/ Aus Toll Free= 1800
880 818
NZ Toll Free= 0800
service.eu@viewsoniceurope.com
service@au.viewsonic.com
008 822
Australia and
New Zealand
Singapore/
www.viewsonic.com.sg/support/ T= +65 273 4018
F= +65 273 1566
www.viewsonic.com T= +65 6273 4018
service@sg.viewsonic.com
service@sd.viewsonic.com
Malaysia/Tailand
South
Africa/Other
countries
F= +65 6273 1566
www.hk.viewsonic.com/support/ T= +852 2268 6878
F= +852 2268 6778
Toll Free= +852 310
22 900
service@hk.viewsonic.com
9
Maintenance
This product is under strict quality control in the production process. Maintaining the LCD
monitor, refer to the description as below, and is important for maximizing the display
performance and product life.
Warring: To prevent electrical shock, do not open the LCD monitor casing. Users
shall not repair the LCD monitor on their own. Users’ maintenance is
limited to cleaning of the parts below.
Unplug the power
Check the cover
Clean
Cleaner
Screen
Accessory
Conserve
Case
Unplug the LCD monitor from an AC socket before conducting maintenance.
Check to see if the LCD Monitor and accessories are damaged, broken, or strained.
Never spray or pour any liquid directly onto the screen or case.
Avoid water or and liquid permeating into the LCD monitor or accessories.
Pure water or non-ammonia, non-alcohol based glass cleaner.
Do not use ketene (such as acetone), ethanol, toluene, acetic acid, methane,
chloride, or abrasive detergent to clean the monitor because those chemicals
can damage the LCD monitor.
To clean your LCD monitor screen, use water or mild cleaner, as above, to
gently moist a soft, clean cloth.
If possible, use a special screen cleaner sheet or a solution suitable for static
electricity application.
To clean your LCD monitor case, use water or mild cleaner, as above, to gently
moist a soft, clean cloth.
To clean your accessories, use water or mild cleaner, as above, to gently moist
a soft, clean cloth.
If the LCD monitor is not in use for a long time, please unplug and save in original
box in order to avoid any unexpected damage.
Disclaimer
Any damage resulting from use of any cleaner that is not mentioned above is not
covered under this warranty term.
10
Limited Warranty
VIEWSONIC LCD DISPLAY
What the warranty covers:
®
ViewSonic
warranty period. If a product proves to be defective in material or workmanship during the warranty
period,
product or parts may include remanufactured or refurbished parts or components.
How long the warranty is effective:
ViewSonic
three (3) years for all labor from the date of the first consumer purchase.
Who the warranty protects:
This warranty is valid only for the first consumer purchaser.
What the warranty does not cover:
1. Any product on which the serial number has been defaced, modified or removed.
2. Damage, deterioration or malfunction resulting from:
a. Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product
b. Repair or attempted repair by anyone not authorized by
c. Any damage of the product due to shipment.
d. Removal or installation of the product.
e. Causes external to the product, such as electrical power fluctuations or failure.
f. Use of supplies or parts not meeting
g. Normal wear and tear.
h. Any other cause which does not relate to a product defect.
3. Removal, installation, and set-up service charges.
How to get service:
1. For information about receiving service under warranty, contact
You will need to provide your product's serial number.
2. To obtain service under warranty, you will be required to provide (a) the original dated sales slip, (b) your
name, (c) your address, (d) a description of the problem, and (e) the serial number of the product.
3. Take or ship the product freight prepaid in the original container to an authorized
service center or
4. For additional information or the name of the nearest
ViewSonic
Limitation of implied warranties:
THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, WHICH EXTEND BEYOND THE
DESCRIPTION CONTAINED HEREIN INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Exclusion of damages:
VIEWSONIC'S LIABILITY IS LIMITED TO THE COST OF REPAIR OR REPLACEMENT OF THE
PRODUCT. VIEWSONIC SHALL NOT BE LIABLE FOR:
1. DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECTS IN THE PRODUCT, DAMAGES
BASED UPON INCONVENIENCE, LOSS OF USE OF THE PRODUCT, LOSS OF TIME, LOSS OF
PROFITS, LOSS OF BUSINESS OPPORTUNITY, LOSS OF GOODWILL, INTERFERENCE WITH
BUSINESS RELATIONSHIPS, OR OTHER COMMERCIAL LOSS, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
2. ANY OTHER DAMAGES, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
3. ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY.
Effect of state law:
This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state. Some states do not allow limitations on implied warranties and/or do not allow the exclusion of
incidental or consequential damages, so the above limitations and exclusions may not apply to you.
Sales outside the U.S.A. and Canada:
For warranty information and service on
contact
ViewSonic LCD Warranty (V3.0) Release Date: 01-29-2002
warrants its products to be free from defects in material and workmanship during the
ViewSonic
LCD displays are warranted for three (3) years for all parts including the light source and
modification, or failure to follow instructions supplied with the product.
ViewSonic
will, at its sole option, repair or replace the product with a like product. Replacement
.
ViewSonic Customer Support
ViewSonic
service center, contact
ViewSonic
.
or your local
.
ViewSonic
ViewSonic
ViewSonic
products sold outside of the U.S.A. and Canada,
dealer.
ViewSonic
’s specifications.
ViewSonic
.
11
Appendix
Safety Guidelines
CAUTION:
CAUTION:
certified for the individual country. Some examples are listed below:
The socket-outlet should be installed near the equipment and should be easily accessible.
Use a power cable that is properly grounded. Always use the appropriate AC cord that is
USA.................UL
Canada.............CSA
Germany.......... VDE
Switzerland ..... SEV
Britain ............. BASE/BS
Japan ............... Electric Appliance Control Act
IMPORTANT NOTICE CONCERNING POWER CORD SELECTION
The power cord set for this unit has been enclosed and has been selected according to the country of
destination and must be used to prevent electric shock. Use the following guidelines if it is necessary to
replace the original cord set, or if the cord set is not enclosed.
The female receptacle of the cord set must meet IEC-60320 requirements and may look like (Figure A1
below):
Figure A1
Figure A2
For the United States and Canada
In the United States and Canada the male plug is a NEMA5-15 style (Figure A2), UL Listed, and CSA
Labeled. For units which are mounted on a desk or table, type SVT or SJT cord sets may be used. For
units which sit on the floor, only SJT type cord sets may be used. The cord set must be selected according
to the current rating for your unit. Please consult the table below for the selection criteria for power cords
used in the United States and Canada.
Cord Type Size of Conductors in Cord Maximum Current Rating of Unit
SJT 18 AWG
16 AWG
14 AWG
SVT 18 AWG
17 AWG
10 Amps
12 Amps
12 Amps
10 Amps
12 Amps
For European Countries
In Europe you must use a cord set which is appropriate for the receptacles in your country. The cord set is HARCertified, and a special mark that will appear on the outer sheath, or on the insulation of one of the inner conductors.
AC PLUG CORD PRECAUTIONS FOR THE UNITED KINGDOM
FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET THEN THE PLUG SHOULD BE
CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED INTO AN
APPROPRIATE SOCKET.
If a new plug is to be fitted, please observe the wiring code as shown below.
If in any doubt, please consult a qualified electrician.
WARNING:
IMPORTANT:
If the coloured wires of the mains lead of this appliance do not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by
the letter E or by the Earth symbol or coloured GREEN or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the letter N or
coloured BLACK. The wire which is coloured BROWN must be connected to the terminal in the plug which is marked
with the letter L or coloured RED.
If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you
have purchased the product.
THIS APPLIANCE MUST BE EARTHED.
The wires in this mains lead are coloured in accordance with the following code:
Green-and-Yellow: Earth
Blue: Neutral
Brown: Live
12
Compliance Information for U.S.A.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Warning
To assure continued FCC compliance, the user must use grounded power supply cord and the provided
shielded video interface cable with bonded ferrite cores. If a BNC cable is going to be used, use only a
shielded BNC(5) cable. Also, any unauthorized changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this device.
CE Conformity for Europe
The device complies with the requirements of the EEC directive 89/336/EEC
as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic
compatibility,” and 73/23/EEC as amended by 93/68/EEC Art.13 with regard
to “Safety.”
13
Loading...
