ViewSonic Pro8200 User Manual

ViewSonic

®

- User Guide

Pro8200

DLP Projector

IMPORTANT: Please read this User Guide to obtain important

information on installing and using your product in a safe

manner, as well as registering your product for future service.

Warranty information contained in this User Guide will describe

your limited coverage from ViewSonic Corporation, which is

also found on our web site at http://www.viewsonic.com in

English, or in specic languages using the Regional selection

box in the upper right corner of our website.

“Antes de operar su equipo lea cuidadosamente las

instrucciones en este manual”

- Guide de l’utilisateur

- Bedienungsanleitung

- Guía del usuario

- Guida dell’utente

- Guia do usuário

- Användarhandbok

- Käyttöopas

- Руководство пользователя

- 使用手冊 (繁體)

- 使用手册 (简体)

- 사용자 안내서

- คู่มือการใช้งาน

- Podręcznik użytkownika

- Kullanιcι kιlavuzu

Model No. : VS13648

Compliance Information

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning:

party responsible for compliance could void your authority to operate the equipment.

For Canada

• This Class B digital apparatus complies with Canadian ICES-003.

• Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CE Conformity for European Countries

You are cautioned that changes or modications not expressly approved by the

The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive
2006/95/EC.

Following information is only for EU-member states:

The mark is in compliance with the Waste Electrical and Electronic Equipment Directive
2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment including any spent or
discarded batteries or accumulators as unsorted municipal waste, but use the return and
collection systems available.
If the batteries, accumulators and button cells included with this equipment, display the
chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of
more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead.

iViewSonic Pro8200

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this unit near water.

6. Clean with a soft, dry cloth.
Do not block any ventilation openings. Install the unit in accordance with the

7.
manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
devices (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade and the third prong are provided
for your safety. If the provided plug does not t into your outlet, consult an electrician
for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs.
Convenience receptacles and the point where they exit from the unit. Be sure that the
power outlet is located near the unit so that it is easily accessible.

11. Only use attachments/accessories specied by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specied by the

manufacturer, or sold with the unit. When a cart is used, use caution when
moving the cart/unit combination to avoid injury from tipping over.

13. Unplug this unit when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the unit
has been damaged in any way, such as: if the power-supply cord or plug is damaged,
if liquid is spilled onto or objects fall into the unit, if the unit is exposed to rain or
moisture, or if the unit does not operate normally or has been dropped.

iiViewSonic Pro8200

Declaration of RoHS Compliance

This product has been designed and manufactured in compliance with Directive 2002/95/EC of the
European Parliament and the Council on restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum
concentration values issued by the European Technical Adaptation Committee (TAC) as shown below:

Substance

Lead (Pb) 0.1% < 0.1%

Mercury (Hg) 0.1% < 0.1%

Cadmium (Cd) 0.01% < 0.01%

Hexavalent Chromium (Cr6+) 0.1% < 0.1%

Polybrominated biphenyls (PBB) 0.1% < 0.1%

Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%

Certain components of products as stated above are exempted under the Annex of the RoHS Directives
as noted below:

Examples of exempted components are:

1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps not

specically mentioned in the Annex of RoHS Directive.

2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and electronic ceramic

parts (e.g. piezoelectronic devices).

3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more lead).

4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing up

to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight.

Proposed Maximum

Concentration

Actual Concentration

iiiViewSonic Pro8200

Copyright Information

Copyright© ViewSonic® Corporation, 2010. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of
ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC are
trademarks of VESA.
PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from furnishing this material, or
the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to change
product specications without notice. Information in this document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes available, please
register your product on the Internet at: www.viewsonic.com. The ViewSonic® Wizard CD-ROM also
provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic.

For Your Records

Product Name:

Model Number:
Document Number:
Serial Number:
Purchase Date:

Pro8200
ViewSonic DLP Projector
VS13648
Pro8200_UG_ENG Rev. 1A 08-25-10
_______________________________
_______________________________

Product disposal at end of product life

The lamp in this product contains mercury which can be dangerous to you and the environment.
Please use care and dispose of in accordance with local, state or federal laws.
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing.
Please visit ViewSonic website to learn more.

1. USA: www.viewsonic.com/company/green/

2. Europe: www.viewsoniceurope.com/uk/support/recycling-information/

3. Taiwan: recycle.epa.gov.tw/recycle/index2.aspx

ivViewSonic Pro8200

CONTENTS

Introduction ........................................................................5

Projector Features .......................................................................................................5

Package Contents .......................................................................................................6

Projector Overview ......................................................................................................8

Using the Product ............................................................10

Control Panel ............................................................................................................ 10

Connection Ports .......................................................................................................11

Remote Control .........................................................................................................13

Installing the Batteries ...............................................................................................15

Remote Control Operation ........................................................................................16

Connection .......................................................................17

Connecting a computer or monitor ............................................................................ 18

Connecting Video source devices ............................................................................. 19

Operation ..........................................................................22

Powering On/Off the Projector ..................................................................................22

Adjusting the Projector Height ...................................................................................23

Adjusting the Projector Zoom and Focus ..................................................................23

Adjusting Projection Image Size ............................................................................... 24

Locking control keys ..................................................................................................25

Menu Operation ........................................................................................................ 26

Maintenance .....................................................................33

Cleaning the Lens .....................................................................................................33

Cleaning the Projector Housing ................................................................................ 33

Cleaning the Filter Cover .......................................................................................... 33

Replacing the Lamp ..................................................................................................34

Specifications ...................................................................36

Dimensions ............................................................................................................... 37

Ceiling mount installation ..........................................................................................37

Appendix ...........................................................................38

LED Indicator Messages ..........................................................................................38

Compatibility Modes ..................................................................................................39

Troubleshooting ........................................................................................................ 41

RS-232 Command and Configuration ...................................................................... 42

IR Control Code ........................................................................................................ 44

ViewSonic Pro8200

Introduction

Projector Features

The projector integrates high-performance optical engine projection and a user - friendly
design to deliver high reliability and ease of use.

The projector offers the following features:

 Single chip 0.65" Texas Instruments DLP® technology
 1080p (1920 x 1080 pixels)
 Compatibility with Macintosh® computers
 Compatibility with NTSC, PAL, SECAM and HDTV
 D-Sub 15-pin terminal for analog video connectivity
 User-friendly, multi-language on-screen display
 Advanced electronic keystone correction
 RS-232 connector for serial control
 HDMI compatibility
 Less than 1 W power consumption in standby mode



The information in this manual is subject to change without notices.



The reproduction, transfer or copy of all or any part of this document is not
permitted without express written consent.

ViewSonic Pro8200 5

Package Contents

When you unpack the projector, make sure you have all these components:

HDMI1 HDMI2 Compo

Video

PC

Swap

Default

Projector with Lens Cap AC Power Cord Remote Control (IR) & batteries

V
ie
w
S
o
n
ic

VGA Cable (D-SUB to D-

SUB)

HDMI Cable ViewSonic CD

Wizard

Quick Start

Guide

Optional accessories

Filter cover
P/N: P4R34-4600-00

RS232 cable
P/N: J2552-0208-00

RGB to component adapter
P/N: J2552-0212-00

ViewSonic Pro8200 6

Projector Carrying Case



Contact you dealer immediately if any items are missing, appear damaged, or if
the unit does not work



Save the original shipping carton and Packing material; they will come-in
handy if you ever to ship your unit. for maximum protection, repack your unit as
it was originally packed at the factory.

.

ViewSonic Pro8200 7

Projector Overview

Front View

13

12 11 10 9

21

3

Lens cap Filter cover

1

Elevator button Speaker

2 9

Elevator foot Focus ring

3

Lens cap strap Zoom ring

4

Projection lens Control panel

5

Front IR remote control sensor Lamp cover

6

Ventilation holes (intake)

7

6

8

10

11

12

13

5

4

7

8

ViewSonic Pro8200 8

Rear View

Connection ports

1

AC power socket

2

Kensington lock

23

Rear IR remote control sensor

4

Speake r

5

Ventilation holes (exhaust)

56

Bottom View

1

324 6

5

1

Ceiling mount holes (M4*8)

1

Tilt-adjustment feet

22

Security bar

3



This projector can be used with a ceiling mount for support. The ceiling mount is
not included in the package.



Contact your dealer for information to mount the projector on a ceiling.

103

227

2

174

3

ViewSonic Pro8200 9

Using the Product

Control Panel

9

1 3

2

4

6

10

Power (Power LED indicator)

1

8

7 5 4

Refer to “LED Indicator Messages”.
TEMP (Temperature LED indicator)

2

Refer to “LED Indicator Messages”.
LAMP (Lamp LED indicator)

3

Refer to “LED Indicator Messages”.

Keystone/Arrow keys ( /Up, /Down)

4

Manually correct distorted images resulting from an angled projection.

Four directional buttons

5

Use four directional buttons to select items or make adjustments to your selection.

ENTER

6

Enter to sub-menu and confirm the menu selection.

SOURCE

7

Display the source selection bar.

MENU/EXIT

8

Display or exit the on-screen display menus.

Power

9

Turn the projector on or off.

Right/Panel key

10

Activate panel key lock.

ViewSonic Pro8200 10

Connection Ports

2

1

16

RS-232

1

When operating the projector via a computer, connect this to the controlling
computer's RS-232C port.

Monitor Out

2

Connect to a computer display, etc.

Component (Y Cb/Pb Cr/Pr)

3

Connect Y Cb/Pb Cr/Pr output from video equipment to this jack.

S-Video

4

Connect S-Video output from video equipment to this jack.

USB A

5

This connector supports firmware update.

HDMI 1

6

Connect HDMI output from video equipment to this jack.

HDMI 2

7

Connect HDMI output from video equipment to this jack.

DC 12V Out

8

12V DC out

MIC in

9

Microphone input jack.

Audio Out

10

Connect to a speaker or other audio input equipment.

Audio 2

11

Connect an audio output from video equipment or computer to this jack.

Audio 1

12

Connect an audio output from video equipment or computer to this jack.

15

3

4

14

13

12

5

1011

6

8

9

7

ViewSonic Pro8200 11

Audio 3 (L/R)

13

Connect an audio output from video equipment to this jack.

Video

14

Connect composite video output from video equipment to this jack.

Computer in 2

15

Connect image input signal (analog RGB or component) to this jack.

Computer in 1

16

Connect image input signal (analog RGB or component) to this jack.

ViewSonic Pro8200 12

Remote Control

Power

1

Turn the projector on or off.

HDMI 1

2

Display HDMI 1 signal.

Video

3

Switch input source to Composite/
S-Video by sequence.

Up/Volume +, Down/

4

Volume -

When the On-Screen Display
(OSD) menu is not activated,
adjust the projector’s sound level.

Left/Mute

5

When the On-Screen Display
(OSD) menu is not activated, this
button is used as mute function.

Menu

6

Display on-screen display menus.

User 1

7

Recall the customized settings
based on the current available
settings.

Function

8

User definable key for customized
function.

Gamma

9

Change the gamma setting.

Pattern

10

Display embedded test pattern.

Color Mode

11

Change the image mode setting
by sequence.

Blank

12

Cut off the screen temporarily.
Press again to cancel the Blank
Screen function.

Light

13

Enable backlight functions of the
remote control’s buttons.

Compo

14

Display Component video (YPbPr/
YCbCr) signal.

HDMI2 Compo

HDMI1

3

Video

PC

4

5

4
6
7

8

9
10
11
12

HDMI 2

15

Display HDMI 2 signal.

PC

16

Switch input source to Computer in 1/
Computer in 2 by sequence.

Enter

17

Confirmed selections.

Right/ Lock

18

When the On-Screen Display (OSD)
menu is activated, the #4, #5, and #18
keys are used as directional arrows to
select the desired menu items and to
make adjustments.
Activate panel key lock.

ESC

19

Leave current page or items or to close
OSD.

Swap

Default

13

14

15

16

17

18

19
20
21
22
23
24

25

ViewSonic Pro8200 13

User 2

20

Recall the customized settings
based on the current available
settings.

PIP/POP

21

Switch screen to PIP/POP by
sequence.

Swap

22

Swap input source in PIP or POP
image.

Aspect

23

Select the display aspect ratio.

RGBCMY

24

Change indivial RGBCMY color (user
color setting).

Default

25

Restore settings to factory default.

ViewSonic Pro8200 14

Installing the Batteries

1. Open the battery cover in the direction shown.

2. Install batteries as indicated by the diagram inside the compartment.

3. Close the battery cover into position.

Caution

 Risk of explosion if battery is replaced by an incorrect type.
 Dispose of used batteries according to the instructions.


Make sure the plus and minus terminals are correctly aligned when loading a battery.



Keep the batteries out of the reach of children. There is a danger of death by
accidentally swallowing the batteries.



Remove batteries from remote control when not using for extended periods.



Do not dispose of the used batteries along with household waste. Dispose of used
batteries according to local regulations.



Danger of explosion may happen if batteries are incorrectly replaced. Replce all
the batteries with new ones.



Batteries should not be in or near to fire or water, keep batteries in a dark, cool
and dry place.



If suspect battery leakage, wipe out the leakage and then replace new batteries.
If the leakage adheres to your body or clothes, rinse well with water immediately.

ViewSonic Pro8200 15

Remote Control Operation

Point the remote control at the infrared remote sensor and press a button.

 Operating the projector from

the front

30

15

6m

5m

8m

6m

7m

HDMI

1
Vid
eo

HDMI

2

Compo

PC

Swap

Defa

ult

 Operating the projector from

the rear

30

15

6m

8m

6m

HDMI1

Vid
eo

HDMI

2

Compo

PC

Swap

Default



Do not point the laser directly to the people's eyes (especially small children).
There is a danger of injury to the eyes.

 The remote control may not operate when there is sunlight or other strong

light such as a fluorescent lamp shining on the remote sensor.

 Operate the remote control from a position where the remote sensor is visible.
 Do not drop the remote control or jolt it.
 Keep the remote control out of locations with excessively high temperature or

humidity.

 Do not get water on the remote control or place wet objects on it.
 Do not disassemble the remote control.

ViewSonic Pro8200 16

Connection

When connecting a signal source to the projector, be sure to:

1. Turn all equipment off before making any connections.

2. Use the correct signal cables for each source.

3. Ensure the cables are firmly inserted.

1

2

VGA cable (D-Sub to D-Sub) S-Video cable

1 6

VGA to DVI-A cable Composite Video cable

2

VGA (D-Sub) to HDTV (RCA) cable Audio cable

3

Component Video cable HDMI cable

4 9

Audio L/R cable Microphone 3.5 mini jack cable

5

1

8

4

3

5 9

7

8

10

677

8

10

8

Important

 In the connections shown above, some cables may not be included with the

projector (see “Package Contents” on page 6). They are commercially
available from electronics stores.

 The connection illustrations above are for reference only. The rear

connecting jacks available on the projector vary with each projector model.

 For detailed connection methods, see pages 18-21.

ViewSonic Pro8200 17

Connecting a computer or monitor

Connecting a computer

The projector provides two VGA input sockets that allow you to connect them to both
IBM® compatibles and Macintosh® computers. A Mac adapter is needed if you are
connecting legacy version Macintosh computers.

To connect the projector to a notebook or desktop computer:

1. Take the supplied VGA cable and connect one end to the D-Sub output socket of the computer.

2. Connect the other end of the VGA cable to the
signal input socket on the projector.

Important

 Many notebooks do not turn on their external video ports when connected to

a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the
external display on/off. Locate a function key labeled CRT/LCD or a function
key with a monitor symbol on the notebook. Press FN and the labeled
function key simultaneously. Refer to your notebook's documentation to find
your notebook's key combination.

Connecting a monitor

If you want to view your presentation close-up on a monitor as well as on the screen,
you can connect the Monitor Out signal output socket on the projector to an external
monitor with a VGA cable following the instructions below:

To connect the projector to a monitor:

1. Connect the projector to a computer as described in “Connecting a computer” on

page 18.

2. Take a suitable VGA cable (only one supplied) and connect one end of the cable
to the D-Sub input socket of the video monitor.
Or if your monitor is equipped with a DVI input socket, take a VGA to DVI-A cable
and connect the DVI end of the cable to the DVI input socket of the video monitor.

3. Connect the other end of the cable to the

Important

 The Monitor Out output only works when Computer in 1 or Computer in 2

is made to the projector.

Computer in 1

Monitor Out

or

Computer in 2

socket on the projector.

ViewSonic Pro8200 18

Connecting Video source devices

You can connect your projector to various Video source devices that provide any one
of the following output sockets:

 Component Video
 S-Video
 Video (composite)

You need only connect the projector to a Video source device using just one of the
above connecting methods, however each provides a different level of video quality.
The method you choose will most likely depend upon the availability of matching
terminals on both the projector and the Video source device as described below:

Best video quality

The best available video connection method is Component Video (not to be confused
with composite Video). Digital TV tuner and DVD players output Component Video
natively, so if available on your devices, this should be your connection method of
choice in preference to (composite) Video.

See “Connecting a Component Video source device” on page 20 for how to connect
the projector to a component video device.

Better video quality

The S-Video method provides a better quality analog video than standard composite
Video. If you have both composite Video and S-Video output terminals on your Video
source device, you should elect to use the S-Video option.
See “Connecting an S-Video source device” on page 20 for how to connect the
projector to an S-Video device.

Least video quality

Composite Video is an analog video and will result in a perfectly acceptable, but less
than optimal result from your projector, being the least video quality of the available
methods described here.
See “Connecting a composite Video source device” on page 21 for how to connect the
projector to a composite Video device.

ViewSonic Pro8200 19

Connecting a Component Video source device

Examine your Video source device to determine if it has a set of unused Component
Video output sockets available:

 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to the

device.

To connect the projector to a Component Video source device:

1. Take a VGA (D-Sub) to HDTV (RCA) cable, Component Video cable or a
Component Video to VGA (D-Sub) adaptor and connect the end with 3 RCA type
connectors to the Component Video output sockets of the Video source device.
Match the color of the plugs to the color of the sockets; green to green, blue to
blue, and red to red.

2. If you are using the VGA (D-Sub) to HDTV (RCA) cable and the Component Video
to VGA (D-Sub) adaptor, connect the other end of the cable (with a D-Sub type
connector) to the
are using the Component Video Cable, connect the other end of 3RCA type
connectors to the

Important

Computer in 1

Y Cb/Pb Cr/Pr

or

Computer in 2

sockets on the projector.

socket on the projector. If you

 If the selected video image is not displayed after the projector is turned on

and the correct video source has been selected, check that the Video source
device is turned on and operating correctly. Also check that the signal cables
have been connected correctly.

 RGB to component adapter (ViewSonic P/N: J2552-0212-00)

Connecting an S-Video source device

Examine your Video source device to determine if it has an unused S-Video output
socket available:

 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to the

device.

To connect the projector to an S-Video source device:

1. Take an S-Video cable and connect one end to the S-Video output socket of the Video source device.

2. Connect the other end of the S-Video cable to the
projector.

S-Video

socket on the

ViewSonic Pro8200 20

Important

 If the selected video image is not displayed after the projector is turned on

and the correct video source has been selected, check that the Video source
device is turned on and operating correctly. Also check that the signal cables
have been connected correctly.

 If you have already made a Component Video connection between the

projector and this S-Video source device using Component Video
connections, you need not connect to this device using an S-Video
connection as this makes an unnecessary second connection of poorer
picture quality. See “Connecting Video source devices” on page 19 for
details.

Connecting a composite Video source device

Examine your Video source device to determine if it has a set of unused composite
Video output sockets available:

 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to the

device.

To connect the projector to a composite Video source device:

1. Take a Video cable and connect one end to the composite Video output socket of the Video source device.

2. Connect the other end of the Video cable to the

Important

 If the selected video image is not displayed after the projector is turned on

and the correct video source has been selected, check that the Video source
device is turned on and operating correctly. Also check that the signal cables
have been connected correctly.

 You need only connect to this device using a composite Video connection if

Component Video and S-Video inputs are unavailable for use. See

“Connecting Video source devices” on page 19 for details.

Video

socket on the projector.

ViewSonic Pro8200 21

Operation

Powering On/Off the Projector

Powering On the Projector:

1. Remove the projector lens cap.

2. Complete the AC power cord and peripheral signal cable(s) connections.

3. Press to turn on the projector. The projector takes a minute or so to warm up.

4. Turn on your source (computer, notebook, DVD, etc.). The projector automatically detects your source.

 If you are connecting multiple sources to the projector simultaneously, press

SOURCE on the projector to select your desired signal or press your desired
signal key on the remote control.

Warn ing

 Remove the lens cap first before powering on.
 Never look into the lens when the lamp is on. This can damage your eyes.
 This focal point concentrates high temperature. Do not place any object near

it to avoid possible fire hazard.

Powering Off the Projector:

1. Press to turn off the projector lamp. You will see a message
Press Power again"

2. Press again to confirm.

appear on the screen.

 The cooling fans continue to operate for cooling cycle.


When the Power LED begins flashing, the projector has entered stand-by
mode.

 If you want to turn the projector back on, you must wait until the projector has

completed the cooling cycle and has entered stand-by mode. Once in stand-

by mode, simply press to restart the projector.

3. Disconnect the AC power cord from the electrical outlet and the projector.

4. Do not turn on the projector right after power off.

"Power off?

ViewSonic Pro8200 22

Adjusting the Projector Height

Tilt-adjustment feet

Elevator foot

Elevator button

The projector is equipped with an elevator foot to adjust the image height.
To raise or lower the image:

1. To raise or lower the image, press the elevator button and raise or lower the front of the projector. Release the button to lock the adjustment.

2. To level the image on the screen, turn the tilt-adjustment feet to fine-tune the height.



To avoid damaging the projector, make sure that the elevator foot and tilt­adjustment feet are fully retracted before placing the projector in its carrying
case.

Adjusting the Projector Zoom and Focus

Zoom ring

Focus ring

1. Focus the image by rotating the focus ring. A still image is recommended for focusing.

2. Adjust the image size by sliding the zoom ring.

ViewSonic Pro8200 23

Adjusting Projection Image Size

Refer to the graphic and table below to determine the screen size and projection distance.

Maximum zoom

Minimum zoom

Screen

Center of lens

Vertical offset

Screen size

Diagonal

[inch (cm)]

30 (76) 35 (0.89) 55 (1.39) 14.7 (37) 5.0 (12.8)
40 (102) 48 (1.21) 74 (1.87) 19.6 (50) 6.7 (17.1)
50 (127) 60 (1.52) 93 (2.35) 24.5 (62) 8.4 (21.4)
60 (152) 72 (1.83) 111 (2.83) 29.4 (75) 10.1 (25.6)
80 (203) 97 (2.46) 149 (3.79) 39.2 (100) 13.5 (34.2)

100 (254) 122 (3.09) 187 (4.75) 49 (125) 16.8 (42.7)
120 (305) 146 (3.72) 224 (5.7) 58.8 (149) 20.2 (51.3)
150 (381) 183 (4.66) 281 (7.14) 73.5 (187) 25.2 (64.1)
200 (508) 246 (6.24) 376 (9.54) 98.1 (249) 33.6 (85.4)
220 (559) 270 (6.87) 413 (10.5) 107.9 (274) 37.0 (94.0)
250 (635) 307 (7.81) 470 (11.94) 1 22.6 (311) 42.0 (106.8)
300 (762) 369 (9.38) 564 (14.33) 147.1 (374) 50.5 (128.2)








Projection distance [inch (m)] Image

(min. zoom) (max. zoom)

Position the projector in a horizontal position; other positions can cause heat
build-up and damage to the projector.
Keep a space of 30 cm or more between the sides of the projector.

Do not use the projector in a smoky environment. Smoke residue may build­up on critical parts and damage the projector or its performance
Consult with your dealer for special installation such as suspending from a
ceiling.

Projection distance

16 : 9 Screen

height [inch

(cm)]

Vertical

offset

[inch (cm)]

.

ViewSonic Pro8200 24

Locking control keys

With the control keys on the projector locked, you can prevent your projector settings
from being changed accidentally (by children, for example). When the Panel Key
Lock is on, no control keys on the projector will operate except Power.

1. Press on the projector or remote control.

2. A confirmation message is displayed. Select

Yes

to confirm.
To release panel key lock, press and hold for
3 seconds on the projector.

Important

 Keys on the remote control are still functional when panel key lock is

enabled.

 If you press

lock, the projector will still be in locked status the next time it is turned on.

Power to turn off the projector without disabling panel key

HDMI1 HDMI2 Compo

Video

PC

Swap

Default

ViewSonic Pro8200 25

Menu Operation

The projector has multilingual on-screen display menus that allow you to make image
adjustments and change a variety of settings.

Color Mode

Brightest, Standard, Theater 1,
Theater 2, ViewMatch, User1,
User2

Video/Audio

Setting

Video Setting

Color Temp.

Overscan

Noise Reduction

Audio Setting

Microphone Volume

Speaker Volume

Mute

Auto Keystone

Keystone -30 - +30

Aspect Ratio

Off, LOW, MID, HIGH

Auto, 4:3, 16:9, 16:10,
ANAMORPHIC 1,
ANAMORPHIC 2

Front-Table, Front-Ceiling,
Rear-Table, Rear-Ceiling

Saturation

Sharpness

Tint

Red Gain

Green Gain

Blue Gain

Color

Hue

Saturation

Gain

-5 - +5

-10 - +10

-10 - +10

0% - 10%

Computer 1

Computer 2

Video Source

HDMI

0 - 10

0 - 20

User, LOW, MID, HIGH

0 - 100

0 - 100

0 - 100

Red, Green, Blue,
Cyan, Megenta, Yellow

-100 - +100

-100 - +100

-100 - +100

Audio in 1, Audio in 2, Audio in 3

Audio in 1, Audio in 2, Audio in 3

Audio in 1, Audio in 2, Audio in 3

Audio in 1, Audio in 2, Audio in 3, HDMI

Filter Mode*2

High Altitude

Quick Power On

Quick Power Off

DC 12V Trigger

ViewSonic Pro8200 26

Information

OSD Setting

Others

Display Type

Swap

Function*3

Input Source

Filter Hours*2

Filter Hours Reset*2

Equivalent Lamp Hours
Equivalent Lamp Hours
Reset

Factory Default

Input Password

Password Delete

Black, Red, Green, Blue,
Cyan, Yellow, Magenta, White

OSD Timeout

OSD Transparency

Off, CC1, CC2, CC3, CC4, T1, T2

Message

Zoom

DCR

Test Pattern

Off, PIP, POP

Yes, No

Computer 1, Computer 2,
Component, Composite,
S-Video, HDMI, USB 1, USB 2

Top-Left, Bottom-Left,
Top-Right, Bottom-Right

20 - 60

0, 10, 20, 30, 40, 50, 60, 70, 80, 90

*1 Adjustable range and default setting vary depending on signal type.
*2 This function is only available when the projector is installed an optional filter cover.
*3 The selectable Function list includes Color Mode, Gamma, Overscan, Noise

Reduction, Keystone and Filter Mode.

ViewSonic Pro8200 27

How to operate

1. Press

2. When OSD is displayed, use S / T to select any feature in the main menu.

3. After selecting the desired main menu item, press X to enter sub-menu for feature

4. Use S / T to select the desired item and adjust the settings with W / X.

5. Press

6. To exit OSD,


Color Mode

There are many factory presets optimized for various types of images.









Brightness

Brighten or darken the image.

Contrast

Set the difference between light and dark areas.

Video Setting

Allow you to enter the Video Setting menu.

 Saturation: Adjust a video image from black and white to fully saturated color.
 Sharpness: Sharpen or soften the image.
 Tint: Shift colors toward red or green.

Color Setting

Adjust the color temperature. At higher temperature the screen looks colder; at lower
temperature, the screen looks warmer. If you select “User”, then you can change the
intensity of each of 3 color (Red, Green, Blue) to customize user color temperature.

User Color

User Color provides six sets (RGBCMY) of colors to be adjusted. When you select each
color, you can independently adjust its range and saturation according to your preference.

Gamma

Effect the represent of dark scenery. With greater gamma value, dark scenery will look
brighter.

MENU

on the projector or

setting.

MENU

the main menu.

OSD menu will close and the projector will automatically save the new settings.

Brightest : For the brightest environment.
Standard : For computer or notebook.
Theater 1 : For home theater.
Theater 2 : For home theater.
ViewMatch : For accuracy color performance.
User 1 : Memorize user 1 defined settings.
User 2 : Memorize user 2 defined settings.

on the projector or

Press

MENU

Menu

on the remote control to open the OSD menu.

Menu

on the remote control, the screen will return to

on the projector or

Menu

on the remote control again. The

ViewSonic Pro8200 28

Video/Audio

Frequency

Adjust the timing of the projector relative to the computer.

Tracking

Adjust the phase of the projector relative to the computer.

H Position (Horizontal Position)

Adjust the image left or right within the projection area.

V Position (Vertical Position)

Adjust the image up or down within the projection area.

Overscan

Remove noise around the video image.

Noise Reduction

Reduce temporal and/or spatial noise in the image.

Audio Setting

Allow you to enter the Audio Setting menu.

 Computer 1:



When Audio in 1 is turned on, Audio in 2 and Audio in 3 will turn off automatically.

 Computer 2:



When Audio in 2 is turned on, Audio in 1 and Audio in 3 will turn off automatically.

 Video Source:



When Audio in 3 is turned on, Audio in 1 and Audio in 2 will turn off automatically.

Select the audio input for Computer in 1 signal.

Select the audio input for Computer in 2 signal.

Select the audio input for video source.

 HDMI: Select the audio input for HDMI signal.

 When HDMI is turned on, Audio in 1, Audio in 2 and Audio in 3 will turn off

automatically.

Microphone Volume

Adjust the microphone’s volume level.

Speaker Volume

Adjust the projector’s volume level.

Mute

Cut off the sound temporarily.

Setting

Auto Keystone

Automatically correct distorted images resulting from an angled projection.

Keystone

Manually correct distorted images resulting from an angled projection.

 When adjusting the Keystone, Auto Keystone will be set at "Off" automatically.

ViewSonic Pro8200 29

Aspect Ratio

Select how the picture fits on the screen:



Auto : Scales an image proportionally to fit the projector's native resolution in its











Projection

Adjust the picture to match the orientation of the projector: upright or upside-down, in front of
or behind the screen. Invert or reverse the image accordingly.

Power Saving

If the input source is not detected and no operation is performed for a specific period of time,
projector will automatically turn off.

Auto Source

Automatically scan through all the input source.

Signal Type

Specify the source to the Computer in 1/Computer in 2 terminal that you wish to project.






ECO Mode

Use this function to dim the projector lamp light output which will lower power consumption
and increase lamp life.



Filter Mode

Use this function to activate filter mode after the projector is installed an optional filter cover.

High Altitude

Use this function to allow the fans operates at full speed continuously to achieve proper high
altitude cooling of the projector.

horizontal or vertical width.

4:3 : Scales an image so that it is displayed in the center of the screen with a 4:3

aspect ratio.

16:9 : Scales an image so that it is displayed in the center of the screen with a 16:9

aspect ratio.

16:10: Scale an image so that it is displayed in the center of the screen with a 16:10

aspect ratio.

ANAMORPHIC 1: Scale an image so that it is displayed in the center of the screen

with a 1.85:1 aspect ratio.

ANAMORPHIC 2: Scale an image so that it is displayed in the center of the screen

with a 2.35:1 aspect ratio.

Auto : Automatically detect the input signal type from Computer in 1 and Computer
in 2 terminals.
RGB : For VGA signal
YCbCr/YPbPr:For component signal

This function will be unavailable when the DCR function is on.

ViewSonic Pro8200 30

Quick Power On

Enable the projector to turn on automatically after the power cord has been connected
and power has been applied.

Quick Power Off

Enable the projector to turn off quickly.

DC 12V Trigger

Enable or disable to trigger external devices such as an electric screen.

Option

Password

Set or delete the password. When the password function is added, image projection will
require to input the preset password when turning on the projector.

Blank Screen

Blank the screen temporarily, and select the screen color when this function is active.

OSD Setting

Allow you to enter the OSD Setting menu.

 Menu Position: Choose the menu location on the display screen.
 OSD Timeout: Duration of OSD menu display countly starts (at idle state by

second).

 OSD Transparency: Select to change the transparency level of the OSD

background.

Closed Caption

Enable or disable closed captions by selecting CC1 (closed caption1, the most common
channel), CC2, CC3, CC4, T1, T2 or OFF.

Others

Allow you to enter the Others menu.

 Message: Enable or disable the message box at the right bottom of the screen.
 Zoom: Zoom in and out the images.
 DCR (Dynamic Contrast Ratio): Enable DCR will further enhance contrast ratio

by darkening the black scenes. Disable DCR will resume to normal contrast
performance. DCR will impact lamp life and system noise performance.

 Test Pattern: Display embedded test pattern.

Display Type

Allow user to select PIP (Picture in Picture) screen, POP (Picture on Picture) screen or
disable PIP/POP function.

Swap

Allow user to swap input source in PIP or POP image.

Function

ViewSonic Pro8200 31

Allow user to define a short cut key on the remote control, and the function item is selected
in OSD menu.

Information

Input Source

Display the current input source.

Resolution

Display current input source resolution.

H. Frequency

Display current image horizontal frequency.

V. Frequency

Display current image vertical frequency.

Filter Hours

Display the filter’s elapsed operating time (in hours).



When Filter Mode is turned on, the Filter Hours also turns on automatically.

Filter Hours Reset

Reset the filter Hour to 0 hours.

Equivalent Lamp Hours

Display the lamp’s elapsed operating time (in hours).

Equivalent Lamp Hours Reset

Reset the lamp Hour to 0 hours.

Factory Default

Restore settings to factory default.

Language

Select the language used by the on-screen menu.

ViewSonic Pro8200 32

Maintenance

The projector needs proper maintenance. You should keep the lens clean as dust, dirt
or spots will project on the screen and diminish image quality. If any other parts need
replacing, contact your dealer or qualified service personnel. When cleaning any part
of the projector, always switch off and unplug the projector first.

Warn ing

Never open any of the covers on the projector. Dangerous electrical voltages
inside the projector can cause severe injury. Do not attempt to service this
product yourself. Refer all servicing to qualified service personnel.

Cleaning the Lens

Gently wipe the lens with lens cleaning paper. Do not touch the lens with your hands.

Cleaning the Projector Housing

Gently wipe with a soft cloth. If dirt and stains are not easily removed, use a soft cloth
damped with water, or water and neutral detergent, and wipe dry with a soft, dry cloth.

Cleaning the Filter Cover

The filter cover, which is located at the side of the projector, should be cleaned after
every 100 hours of use. If it is not cleaned periodically, it can become clogged with
dust and prevent the projector from being ventilated properly. This can cause over
heating and damage the projector.

To clean the filter cover:

1. Switch the projector off and unplug the AC

power cord from the wall socket.

2. Remove the filter cover as the illustration

shown.

3. Clean the filter cover.

 To clean the filter cover, you are

advised to use a small vacuum
cleaner designed for computers and
other office equipment.

 If the filter cover is torn, replace it.

4. Replace the filter cover.

5. Attach the filter cover.

6. Plug the power back into the projector.

 Turn off the projector and remove the AC power cord from the power outlet

before beginning maintenance work.

 Make sure the lens is cool before cleaning.
 Do not use detergents or chemicals other than those noted above. Do not use

benzene or thinners.

 Do not use chemical sprays.
 Use a soft cloth or lens paper only.

ViewSonic Pro8200 33

Replacing the Lamp

As the projector operates over time, the brightness of the projector lamp gradually
decreases and the lamp becomes more susceptible to breakage. We recommend
replacing the lamp if a warning message is displayed. Do not attempt to replace the
lamp yourself. Contact the qualified service personnel for replacement.



The lamp is extremely hot right after turning off the projector. If you touch the
lamp, you may scald your finger. When you replace the lamp, wait for at least
45 minutes for the lamp to cool down.



Do not touch the lamp glass at any time. The lamp may explode due to
improper handling, including the touching of the lamp glass.



Lamp lifetime may differ from lamp to lamp and according to the environment
of use. There is no guarantee of the same lifetime for each lamp. Some lamps
may fail or terminate their lifetime in a shorter period of time than other similar
lamps.



A lamp may explode as a result of vibration, shock or degradation as a result of
hours of use as its lifetime draws to an end. Risk of explosion may differ
according to the environment or conditions in which the projector and lamp are
being used.



Wear protective gloves and eyeglasses when fixing or detaching the lamp.



Faster on-off-cycles will damage the lamp and reduce lamp life. Wait at least
for 5 minutes to turn off the projector after powering on.



Do not operate the lamp in proximity to paper, cloth, or other combustible
material nor cover it with such materials.



Do not operate the lamp in an atmosphere containing an inflammable
substance, such as thinner.



Thoroughly ventilate the area or the room when operating the lamp in an
oxygen atmosphere (in the air). If ozone is inhaled, it could cause headaches,
nausea, dizziness, and other symptoms.



The inorganic mercury is involved in the lamp. If the lamp bursts, the mercury
inside the lamp will be exposed. Leave the area immediately if the lamp
shatters while being operated and ventilate the area for at least 30 minutes in
order to avoid the inhalation of mercury fumes. Otherwise it could be harmful to
user’s health.

ViewSonic Pro8200 34

1. Turn off the projector.

2. If the projector is installed in a ceiling mount, remove it

3. Unplug the power cord.

4. Loosen the screw in the side of the lamp cover and remove the cover.

5. Remove the screws from the lamp module, raise the handle, and lift out the

module.

6. Insert the new lamp module into the projector and tighten the screws.

7. Replace the lamp cover and tighten the screw.

8. Turn on the projector. If the lamp does not turn on after the warm-up period, try

reinstalling the lamp.

9. Reset the lamp hour. Refer to the “Information” menu.



Dispose the used lamp according to local regulations.



Ensure that screws are tightened properly. Screws not tightened fully may
result in injury or accidents.



Since the lamp is made of glass, do not drop the unit and do not scratch the
glass.



Do not reuse the old lamp. This could cause the lamp to explode.



Be sure to turn off the projector and unplug the AC power cord before
replacing the lamp.



Do not use the projector with the lamp cover removed.

ViewSonic Pro8200 35

Specifications

Display system Single 0.65" DLP panel
Resolution 1080p (1920 × 1080 pixels)
Zoom 1.5X
F/No. 2.41 - 2.97
Focal length 20.72 - 31mm
Screen size 30” - 300”
Lamp 230W
Input terminal D-Sub 15-pin x 2, S-Video x 1, Video x 1, Audio signal input (3.5

Output terminal D-Sub 15 pin x 1, Audio signal output (3.5 mm stereo mini jack) x

Control terminal RS-232 x 1, 12-Vdc trigger output x 1
Speaker 10 watt x 2
Video compatibility NTSC, NTSC 4.43

Scanning frequency
Horizontal frequency
Vertical frequency

Environment Operating:

Power requirement AC 100-240 V, 50 - 60 Hz, 2.6A
Power consumption 320 W
Dimension (W x D x H) 334.6 x 264.5 x 109.5 mm
Weight 3.63 kg (8 lb)
Note: Design and Specifications are subject to change without prior notice.

mm stereo mini jack) x 2, HDMI x 2, Component RCA jack x 1,
RCA audio jack (L/R) x 1, 3.5 mm Mic input x1, USB A type x1
(supports firmware update)

1

PAL, PAL-N, PAL M
SECAM, HDTV (480i/p, 576p, 720p, 1080i/p), Composite video

31 - 100 KHz
50 - 120 Hz

Temperature: 0°C to 40°C
Humidity: 10%-80%
Storage:
Temperature: -20°C to 60°C
Humidity: 30%-85%

ViewSonic Pro8200 36

Dimensions

334.6 mm (W) x 264.5 mm (D) x 109.5 mm (H)

264.5

334.6

64.5

Ceiling mount installation

227

174

109.5

Ceiling mount screws:
M4 x 8 (Max. L = 8 mm)

103

84.9

Unit: mm

ViewSonic Pro8200 37

Appendix

LED Indicator Messages

LED type Color Status Meaning

Power LED Blue Solid Lamp life end
Lamp LED Red Flash
Temp LED Red Flash
Power LED Blue Solid Standby mode when green mode is
Lamp LED Red Off
Temp LED Red Off
Power LED Blue Flash Standby mode when green mode is
Lamp LED Red Off
Temp LED Red Off
Power LED Blue Solid Powering up
Lamp LED Red Off
Temp LED Red Off
Power LED Blue Solid Normal operation
Lamp LED Red Off
Temp LED Red Off
Power LED Blue Flash Powering down
Lamp LED Red Off
Temp LED Red Off
Power LED Blue Solid The projector system has some
Lamp LED Red Solid
Temp LED Red Flash
Power LED Blue Solid The lamp has reached its end of life and
Lamp LED Red Solid
Temp LED Red Off

Power LED Blue Solid Temperature is too high. The lamp will
Lamp LED Red Flash
Temp LED Red Off
Power LED Blue Off The lamp ignition failied. If temperature
Lamp LED Red Solid
Temp LED Red Solid
Power LED Blue Flash The projector needs to cool for 90
Lamp LED Red Solid
Temp LED Red Off

turned on.

turned off.

(The projector needs to cool for 35
seconds after the power is turned off.)

problems with its fans, so the projector
cannot start up.

must be changed soon. The lamp will
continue to opearate until it failes.
Change the lamp. If the lamp is off, then
the ballast will become malfuction.

turn off. The fan motor is cooling the
lamp.

is too high, the fans will cool the lamp.

seconds after the power is turned off. If
you try to re-start the projector, it will
shut down again.

ViewSonic Pro8200 38

Compatibility Modes

Computer:

Compatibility Resolution H-Sync [KHz] V-Sync [Hz]

VGA 640 x 480 24.69 50

SVGA 800 x 600 30.99 50

XGA 1024 x 768 39.63 50

SXGA 1280 x 1024 64 60

UXGA 1600 x 1200 47.7 60
Mac 13 640 x 480 35 67
Mac 16 832 x 624 49.72 75
Mac 19 1024 x 768 60.24 75
1080i30 1920 x 1080 33.75 60
1080i25 1920 x 1080 28.13 50
480p 720 x 480 31.47 59.94
576p 720 x 576 31.25 50
720p60 1280 x 720 45 60
720p50 1280 x 720 37.5 50
1080p60 1920 x 1080 67.5 60
1080p50 1920 x 1080 56.25 50

31.5 60

37.9 72

37.5 75

43.3 85

35.2 56

37.9 60

48.1 72

46.9 75

53.7 85

48.4 60

56.5 70
60 75

80 75

ViewSonic Pro8200 39

Video:

Compatibility Resolution H-Sync [KHz] V-Sync [Hz]

1080p 1920 x 1080 67.5 60
1080p 1920 x 1080 56.3 50

1080i 1920 x 1080 33.8 60
1080i 1920 x 1080 28.1 50
720p 1280 x 720 45 60
720p 1280 x 720 37.5 50
576p 720 x 576 31.3 50

576i 720 x 576 15.6 50

480p 720 x 480 31.5 60

480i 720 x 480 15.8 60

ViewSonic Pro8200 40

Troubleshooting

Refer to the symptoms and measures listed below before sending the projector for
repairs. If the problem persists, contact your local reseller or service center. Please
refer to "LED Indicator Messages" as well.

Start-up problems

If no lights turn on:



Be sure that the power cord is securely connected to the projector and the other end
is plugged into an outlet with power.

 Press the power button again.


Unplug the power cord and wait for a short while, then plug it in and press the power
button again.

Image problems

If the searching source is displayed:



Press

SOURCE

 Be sure the external source is turned on and connected.


For a computer connection, ensure your notebook computer’s external video port is
turned on. Refer to the computer manual.

If the image is out of focus:

 Be sure the lens cover is removed.


While displaying the on-screen menu, adjust the focus ring. (The image size should
not change; if it does, you are adjusting the zoom, not the focus.)

 Check the projection lens to see if it needs cleaning.

If the image is flickering or unstable for a computer connection:

 Press

and adjust Frequency or Tracking.

Remote control problems

If the remote control does not operate:

 Be sure nothing is blocking the remote control receiver on the front of the

projector. Use the remote control within the effective range.

 Aim the remote control at the screen or at the front or back of the projector.


Move the remote control so it is more directly in front of or behind the projector and
not as far to the side.

on the projector

MENU

on the projector or

to select an active input source.

Menu

on the remote control

, go to Video/Audio

ViewSonic Pro8200 41

RS-232 Command and Configuration

POWER ON / POWER OFF

POWER ON BE,EF,10,05,00,C6,FF,11,11,01,00,01,00

POWER OFF BE,EF,02,06,00,6D,D2,34,00,00,00,00,00

SOURCE SELECT

Computer 1 BE,EF,02,06,00,BC,D3,35,00,00,00,00,00

Computer 2 BE,EF,02,06,00,8F,D3,36,00,00,00,00,00

COMPONENT BE,EF,02,06,00,5E,D2,37,00,00,00,00,00

COMPOSITE BE,EF,02,06,00,A1,D2,38,00,00,00,00,00

S-VIDEO BE,EF,02,06,00,70,D3,39,00,00,00,00,00

HDMI 1 BE,EF,02,06,00,43,D3,3A,00,00,00,00,0

HDMI 2 BE,EF,02,06,00,92,D2,3B,00,00,00,00,00
