PG707X/PG707W
Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product
in a safe manner, as well as registering your product for future service. Warranty information contained in this
User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”
Model No. VS18090/VS18089
Model Name: PG707X/PG707W
Thank you for choosing ViewSonic®
As a world-leading provider of visual soluons, ViewSonic® is dedicated to exceeding the
world’s expectaons for technological evoluon, innovaon, and simplicity. At ViewSonic®,
we believe that our products have the potenal to make a posive impact in the world, and
we are condent that the ViewSonic® product you have chosen will serve you well.
Once again, thank you for choosing ViewSonic®!
2
Safety Precautions - General
Please read the following Safety Precautions before you start using the projector.
• Keep this user guide in a safe place for later reference.
• Read all warnings and follow all instructions.
• Allow at least 20“ (50 cm) clearance around the projector to ensure proper
ventilation.
• Place the projector in a well-ventilated area. Do not place anything on the
projector that prevents heat dissipation.
• Do not place the projector on an uneven or unstable surface. The projector may
fall over, causing personal injury or projector malfunction.
• Do not use if the projector is tilted at an angle of more than 10° degrees left or
right, nor at an angle of more than 15° degrees forwards or backwards.
• Do not look straight at the projector lens during operation. The intense light
beam may damage your eyes.
• Always open the lens shutter or remove the lens cap when the projector lamp is
on.
• Do not block the projection lens with any objects when the projector is under
operation as this could cause objects to become heated and deformed or even
cause a fire.
• The lamp becomes extremely hot during operation. Allow the projector to
cool for approximately 45 minutes prior to removing the lamp assembly for
replacement.
• Do not use lamps beyond the rated lamp life. Excessive use of lamps beyond the
rated life could cause them to break on rare occasions.
• Never replace the lamp assembly or any electronic component unless the
projector is unplugged.
• Do not attempt to disassemble the projector. There are dangerous high voltages
inside which may cause death if you should come into contact with live parts.
• When moving the projector, be careful not to drop or bump the projector on
anything.
• Do not place any heavy objects on the projector or connection cables.
• Do not stand the projector on end vertically. Doing so may cause the projector
to fall over, causing personal injury or projector malfunction.
• Avoid exposing the projector to direct sunlight or other sources of sustained
heat. Do not install near any heat sources such as radiators, heat registers,
stoves, or other devices (including amplifiers) that may increase the
temperature of the projector to dangerous levels.
3
• Do not place liquids near or on the projector. Liquids spilled into the projector
may cause it to fail. If the projector does become wet, disconnect it from the
power supply and call your local service center to have the projector serviced.
• When the projector is under operation, you may sense some heated air and
odor from its ventilation grill. It is a normal operation and not a defect.
• Do not attempt to circumvent the safety provisions of the polarized or
grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding-type plug has two blades and a third grounding prong. The
wide and third blade are provided for your safety. If the plug does not fit into
your outlet, obtain an adapter and do not attempt to force the plug into the
outlet.
• When connecting to a power outlet, DO NOT remove the grounding prong.
Please ensure grounding prongs are NEVER REMOVED.
• Protect the power cord from being treaded upon or pinched, particularly at the
plug, and at the point where it emerges from the projector.
• In some countries, the voltage is NOT stable. This projector is designed to
operate safely within a voltage between 100 to 240 volts AC, but could fail if
power cuts or surges of ±10 volts occur. In areas where voltage may fluctuate
or cut out, it is recommended that you connect your projector through a power
stabilizer, surge protector, or uninterruptable power supply (UPS).
• If smoke, an abnormal noise, or a strange odor is present, immediately switch
the projector off and call your dealer or ViewSonic®. It is dangerous to continue
using the projector.
• Use only attachments/accessories specified by the manufacturer.
• Disconnect the power cord from the AC outlet if the projector is not being used
for a long period of time.
• Refer all servicing to qualified service personnel.
CAUTION: Possibly hazardous optical radiation is emitted from this product. As
with any bright light source, do not stare into the beam,
RG2 IEC 62471-5:2015.
4
Safety Precautions - Ceiling Mounting
Please read the following Safety Precautions before you start using the projector.
If you intend to mount the projector on the ceiling, we strongly recommend
that you use a proper fitting projector ceiling mount kit and that you ensure it is
securely and safely installed.
If you use an inappropriate projector ceiling mount kit, there is a safety risk that the
projector may fall from the ceiling due to an improper attachment through the use
of the wrong gauge or length screws.
You can purchase a projector ceiling mount kit from the place you purchased your
projector. We recommend that you also purchase a separate security cable and
attach it securely to both the anti-theft lock slot on the projector and the base of
the ceiling mount bracket. This will perform the secondary role of restraining the
projector should its attachment to the mounting bracket become loose.
