ViewSonic P70f User Manual

P70f Color Monitor

User Guide

Guide de l’utilisateur

Bedienungsanleitung

Guía del usuario

Guida dell'utente

Guia do usuário

Användarhandbok

Käyttöopas

Jmdh\h^kl\hihevah\Zl_ey

,QVWUXNFMDREVáXJL

With PerfectFlat Technology

17" (16.0" Diagonal Viewable)

Contents

Product Registration..............................................................2

For Your Records .................................................................. 2

Getting Started

Package Contents ................................................................. 3

Precautions ...........................................................................3

Quick Installation ................................................................... 4

Using the Monitor

Setting the Timing Mode .......................................................5

OSD Lock Settings ................................................................ 5

Adjusting the Screen Image .................................................. 6

Main Menu Controls .............................................................. 8

Other Information

Specifications ...................................................................... 11

Troubleshooting...................................................................12

Customer Support ............................................................... 13

Cleaning the Monitor ........................................................... 14

Limited Warranty ................................................................. 15

Appendix

Safety Guidelines ................................................................ 16

Compliance Information for U.S.A.......................................17

CE Conformity for Europe ................................................... 17

ViewSonic P70f 1

Copyright © ViewSonic Corporation, 2001. All rights reserved.

Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.

Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and other countries.

ViewSonic, the three birds logo, OnView, ViewMatch, ViewMeter, and PerfectFlat are registered
trademarks of ViewSonic Corporation.

VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC
are trademarks of VESA.

®

E

NERGY STAR

As an E
E

NERGY STAR

Disclaimer: ViewSonic
contained herein; nor for incidental or consequential damages resulting from furnishing this mate-

is a registered trademark of the U.S. Environmental Protection Agency (EPA).

®

NERGY STAR

partner, ViewSonic Corporation has determined that this product meets the

®

guidelines for energy efficiency.

Corporation shall not be liable for technical or editorial errors or omissions

rial, or the performance or use of this product.

In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specifications without notice. Information in this document may change without
notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes avail­able, please register your product on the Internet at:

www.viewsonic.com.

CD-ROM also provides an opportunity for you to print the registration form, which you may mail
or fax to ViewSonic.

The ViewSonic Wizard

For Your Records

Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:

ViewSonic P70f
VCDTS23482-1
A-CD-P70f-1
_______________
_______________

Product disposal at end of product life

ViewSonic is concerned about the preservation of our environment. Please dispose of this product
properly at the end of its useful life. Your local waste disposal company may provide information
about proper disposal.

2 ViewSonic P70f

Getting Started

Congratulations on your purchase of a ViewSonic® color monitor. Important!

Save the original box and all packing material for future shipping needs.

NOTE:

operating systems: Windows 95, Windows 98, Windows 2000, Windows Me
(Millennium Edition), Windows NT, and Windows XP.

Package Contents

Yo u r package includes:

• Color monitor

• DB-15 video cable

• Power cord

• ViewSonic Wizard CD-ROM

NOTE:

Guide PDF files and INF/ICM display optimization files. The INF file ensures
compatibility with Windows operating systems, and the ICM file (Image Color
Matching) ensures accurate on-screen colors. ViewSonic
install both files.

Precautions

The word “Windows” in this user guide refers to the following Microsoft

The CD jacket contains the Quick Start Guide, and the CD includes User

recommends that you

• For best viewing conditions sit at least
18” from the monitor.

• AVOID TOUCHING THE SCREEN
WITH YOUR FINGERS. Oils from the
skin are difficult to remove.

• NEVER REMOVE THE REAR
COVER. The monitor contains high
voltage parts. You may suffer serious
injury if you touch these parts.

• Avoid exposing the monitor to direct
sunlight or another heat source,
including an open flame. The monitor
should be facing away from direct
sunlight to reduce glare.

• Always handle your monitor with care
when moving it.

• Place your monitor in a well ventilated
area. Do not place anything on the
monitor that prevents adequate
dissipation of heat.

• Ensure the area around the monitor is
clean and free of moisture.

• Keep the monitor away from magnets,
motors, transformers, speakers, and
televisions.

• Do not place heavy objects on the
monitor, video cable, or power cord.

• If smoke, abnormal noise, or strange
odor is present, immediately switch the
monitor off and call your dealer or
ViewSonic. It is dangerous to continue
using the monitor.

ViewSonic P70f 3

Quick Installation

1 Connect power cord

Connect the power cord to a properly
grounded AC outlet.

2 Connect video cable

Make sure both the monitor and computer
are turned OFF.

Connect the video cable to the computer.

Macintosh

require a Macintosh adapter. Attach the
adapter to the computer and plug the video
cable into the adapter.

To order a ViewSonic
contact ViewSonic. See “Customer Support”
on page 13.

®

users: Models older than G3

®

Macintosh adapter,

3 Turn ON monitor and computer

Turn ON the monitor, then turn ON the
computer. This sequence (monitor before
computer) is very important.

At this point Windows users may

NOTE:

receive a message asking them to install the
INF file.

4 Install Display Optimization files

(INF and ICM files)

(1) Insert the ViewSonic Wizard CD-ROM
into your computer’s CD-ROM drive.

If your computer does not have a

NOTE:

CD-ROM drive, see “Cutomer Support” on
page 13.

(Continued)

(2) Wait for the CD-ROM to auto-start.

If the CD-ROM does not auto-start:

NOTE:

double-click on the CD-ROM icon in
Windows Explorer, then double-click on

viewsonic.exe

(3) Follow the on-screen instructions.

.

5 Windows users: Set the Timing

Mode (resolution and refresh rate) Example:
1024 X 768 @ 75 Hz.

For instructions on changing the resolution
and refresh rate, see the graphic card’s user
guide.

Installation is complete. Enjoy your new
ViewSonic color monitor.

To be best prepared for any future customer
service needs: print this user guide and write
the serial number in “For Your Records” on
page 2. (See back of monitor.) To reg i s t e r
your product go online to

www.viewsonic.com

The ViewSonic Wizard CD-ROM also
provides an opportunity for you to print the
registration form which you may mail or fax
to ViewSonic.

.

Power
cord to
monitor

4 ViewSonic P70f

Video cable
from monitor
to computer

Power cord to computer

Using the Monitor

Setting the Timing Mode

Setting the timing mode is important for maximizing the quality of the
screen image and minimizing eye strain. The timing mode consists of the
resolution (example 1024 x 768) and refresh rate (or vertical frequency;
example 75 Hz). After setting the timing mode, use the OnView
to adjust the screen image.

For the best picture quality set your monitor timing mode to:

VESA 1024 x 768 @ 85 Hz.

To set the Resolution:

1

Right-click on the Windows desktop.

2

Click Properties on the drop-down menu.

3

Click the Settings tab.

4

Move the slider pointer which displays in the Desktop area or Screen area in
the window.

NOTE: The refresh rate should already be set if you have done the CD
installation (or refer to your graphics card documentation).

OSD Lock Settings

®

controls

You have the option of using the OSD Lock feature to prevent current image
adjustments from being changed.

• OSD Lock: Press and hold [1] and [

pressed the message OSD Locked will display for 5 seconds.

• OSD Unlock: Press and hold [1] and [

J]

for 10 seconds. If any buttons are

J]

again for 10 seconds.

ViewSonic P70f 5

Adjusting the Screen Image

Use the buttons on the front control panel to display and adjust the OnView®
controls which display on the screen. The OnView controls are explained at the
top of the next page and are defined in “Main Menu Controls” on page 8.

Main Menu
With OnView controls

Front Control Panel

Displays Main Menu; also saves
changes/exits Main Menu

Scroll through menu
options and adjust the
displayed control

Displays control screen for
highlighted control (or pair
of controls). Also, toggles
between pairs of controls on
some control screens.

6 ViewSonic P70f

Power On/Off

Power Light

One Touch Auto Adjust

Automatically adjusts horizontal and
vertical size and position of the
screen image.

Do the following to adjust the screen image:

1

To display the Main Menu, press button [1].

2

To select a control you want to adjust, press the arrow buttons on the front
control panel of your monitor and scroll through the choices. When the
control you want is highlighted, press button [2].

NOTE: Some controls on the Main Menu are listed in pairs, such as
Contrast/Brightness. Display control screen (sample shown in step 3 below).
Press button [2] to toggle to the next control in the pair.

3

To adjust the selected control, such as

Contrast

in the sample below, press

the arrow buttons.

4

To save the control setting and Exit the menu press button [1] twice.

ViewSonic P70f 7

Main Menu Controls

Adjust the menu items shown below by using the up Iand down Jbuttons.

Control Explanation

Contrast

adjusts the difference between the image

background (black level) and the foreground (white level).

Brightness

adjusts the background black level of the screen

image.

H. Size

(Horizontal Size) adjusts width of the screen image.

H. Position

(Horizontal Position) moves the screen image

left or right.

V. S iz e

(Vertical Size) adjusts the height of the screen

image.

V. Po si ti o n

(Vertical Position) moves the screen image up

or down.

Zoom

expands and contracts the entire screen image.

Pincushion

Pin Balance

curves the vertical edges of the screen image.

curves the vertical edges of the screen image

to the left or right.

8 ViewSonic P70f

Control Explanation

Trape zoid

adjusts the top and bottom of the screen image

until they have equal width.

Parallelogram

slants the vertical edges of the screen image

until they are parallel.

Rotation

Degauss

rotates the entire screen image.

removes the build-up of magnetic fields that can

cause irregular colors to appear around the edges of screen
images. There are two ways to degauss the display:
automatically by turning the monitor on, or manually by
selecting the DEGAUSS control from the menu.

To degauss the monitor manually, select DEGAUSS from
the menu and press button [2].

Important: Do not degauss repeatedly. Doing so can be
harmful to the display. Wait at least 20 minutes before

selecting this control again.

ViewMatch® Color

provides provides several color options:

three preset color temperatures and User Color. The factory
setting for this product is 9300K (9300°

9300K

— Adds blue to the screen image for cooler white

Kelvin).

(used in most office settings with fluorescent lighting).

6500K

— Adds red to the screen image for warmer white

and richer red.

5000K

— Adds blue and green to the screen image for a

darker color.

User Color

— Individual adjustments for red and blue

(green is fixed).

OSD Position

(On Screen Display) allows you to move the

menus and control screens.

Moire Reduction

reduces interference patterns that appear

as ripples, waves, or unwanted background color textures.
Interference patterns of this type are most noticeable when
viewing images having closely spaced lines or finely
detailed patterns.

ViewSonic P70f 9

Control Explanation

Purity

adjusts the uneven color of the screen image.

NOTE: If one area of a color appears darker than another
area, first use the DEGAUSS feature. If color is still uneven,
use the PURITY control.

Language

allows you to choose from among several
languages for the menus and control screens: English,
French, German, Italian, and Spanish.

Memory Recall

returns adjustments to the original factory

settings if the display is operating in a factory preset timing
mode listed in this user guide.

Exception: This control does not affect changes made with
the User Color control.

ViewMeter

®

displays information regarding the current

input signal coming from the graphics card of the computer.

10 ViewSonic P70f

Other Information

Specifications

CRT

Input Signal

Compatibility

Resolution

Power

Display Area

Operating
Conditions

Storage
Conditions

Dimensions

Weight

Regulations

Power Saving
Modes

Ty p e

Phosphor
Glass surface

Video
Sync

PC
Macintosh

Recommended and
supported

Voltage AC 90-260 VAC (auto switch)

Default
Full scan

Temperature
Humidity
Altitude

Temperature
Humidity
Altitude

Physical
(monitor)

Net (monitor only) 17.1 kg (37.62 lb)

On
Off

1

17" (16.0" viewable diagonal area), 0.24 mm stripe
pitch, PerfectFlat

RGB medium/short persistence
TM = 40%, anti-static, anti-reflection

RGB Analog (0.7Vp-p, 75 Ohms)

: 30-97 kHz, fv: 50-180 Hz

f

H

HV Separate (TTL)

VGA up to 1920 x 1440
Power Macintosh

1920 x 1440; may require Macintosh cable adapter)

1600 x 1200 @ 75 Hz (VESA)
1280 x 1024 @ 75, 85 Hz (VESA)
1024 x 768 @ 75, 85 Hz (VESA)
800 x 600 @ 85 Hz (VESA)
640 x 480 @ 60, 85 Hz (VESA)
640 x 400 @ 70 Hz (VGA)
832 x 624 @ 75 Hz (Mac)
1024 x 768 @ 74.9 Hz (Mac)
640 x 480 @ 66.7 Hz (Mac)

50/60 (+/- 3)Hz

310 mm (H) x 232 mm (V) (typical)
325 mm (H) x 244 mm (V) (depends on signal timing)

+32° F to +104° F (0° C to +40° C)
5% to 95% (no condensation)
To 10,000 feet

-40° F to +140° F (-40° C to +60° C)
5% to 95% (no condensation)
To 40,000 feet

422 mm (W) x 433 mm (H) x 431 mm (D)

16.63” (W) x 17.04” (H) x 16.95” (D)

UL, cUL, CSA, FCC-B, CB, ISO9241-3, CE, DHHS,
DOC-B, MPR-II, NOM, IRAM, TUV/GS, VCCI, BSMI,
PSB, C-Tick, S. Africa, TUV/Ergo, NEMKO, SEMKO,
DEMKO, FIMKO, PCBC, GOST, SASO, CCIB,

CCEE, EMC, KMI-B, TCO 99, Energy Star

< 120 W Maximum (Green LED)
< 3 W (Orange LED)

®

, 90° deflection

®

G3, G4 (from 640 x 480 to

®

1

Macintosh models prior to G3 require a Macintosh adapter. To order a ViewSonic Macintosh adapter,

contact Customer Support. You will need to provide the product serial number.

NOTE: This product was designed for operation in the magnetic fields of the hemisphere where it was
purchased.

ViewSonic P70f 11

Troubleshooting

No power

• Make sure power button (or switch) is ON.

• Make sure A/C power cord is securely connected to the back of the monitor

and to a power outlet.

• Plug another electrical device (like a radio) into the power outlet to verify that
the outlet is supplying proper voltage.

Power is ON but no screen image

• Make sure the video cable supplied with the monitor is tightly secured to the
video output port on the back of the computer. If the other end of the video cable
is not attached permanently to the monitor, tightly secure it to the monitor.

• Adjust brightness and contrast.

• Verify whether an adapter is required for proper signal continuity between

graphics card and monitor.

Flickering

• Not enough power supplied. Connect the monitor to a different outlet. If
using a surge protector, reduce the number of devices plugged in.

®

• Check the ViewMeter
frequency) is 75 Hz or higher. See “Specifications” on page 11.

• Remove any devices from the area around the monitor that emit magnetic
fields such as radios, surge protectors, unshielded speakers, fluorescent
lights, AC power converters, desk fans, etc.

• Make sure the graphics card in your computer can use non-interlaced mode at
the desired frequencies. To enable your graphics card to support higher
refresh rates, try selecting fewer colors or running lower resolutions.

Wrong or abnormal colors

• If any colors (red, green, or blue) are missing, check the video cable to make
sure it is securely connected. Loose or broken pins in the cable connector
could cause an improper connection.

• Connect the monitor to another computer.

• Select Degauss from the Main Menu. Do this only once.

• If you have an older graphics card, contact ViewSonic

Entire screen image rolls vertically

• Make sure video input signals are within the monitor's specified frequency range.

• Try the monitor with another power source, graphics card, or computer system.

• Connect the video cable securely.

Control buttons do not work

• Press only one button at a time.

from the main menu to verify the refresh rate (vertical

®

Customer Support.

12 ViewSonic P70f

Customer Support

For technical support or product service, see the table below or contact your
reseller.

NOTE:

You will need the product serial number.

Country/
Region

United States

Canada

United Kingdom viewsoniceurope.com T: 0800 833 648

Europe, Middle
East, Baltic
countries, and
North Africa

Australia and New
Zealand

Singapore/India
and Southeast
Asia

Other Asia/Pacific
countries

South Africa viewsonic.com/asia T: 886 2 2246 3456

Web site T = Telephone

F = FAX

viewsonic.com/
support

viewsonic.com/
support

viewsoniceurope.com Contact your

viewsonic.com.au T: [phone]

viewsonic.com.sg T: 65 273 4018

viewsonic.com.tw T: 886 2 2246 3456

T: [phone]
F: [phone]

T: [phone]
F: [phone]

F: [phone]

reseller

F: [phone]

F: 65 273 1566

F: 886 2 8242 3668

F: 886 2 8242 3668

Email

service.us@
viewsonic.com

service.ca@
viewsonic.com

service.eu@
viewsoniceurope.com

service.eu@
viewsoniceurope.com

service.au@
viewsonic.com

service.sg@
viewsonic.com

service.ap@
viewsonic.com

service.ap@
viewsonic.com

ViewSonic P70f 13

Cleaning the Monitor

• MAKE SURE THE MONITOR IS TURNED OFF.

• NEVER SPRAY OR POUR ANY LIQUID DIRECTLY ONTO THE

SCREEN OR CASE.

To clean the screen:

1

Wipe the screen with a clean, soft, lint-free cloth. This removes dust and
other particles.

2

If still not clean, apply a small amount of non-ammonia, non-alcohol based
glass cleaner onto a clean, soft, lint-free cloth, and wipe the screen.

To clean the case:

1

Use a soft, dry cloth.

2

If still not clean, apply a small amount of a non-ammonia, non-alcohol
based, mild non-abrasive detergent onto a clean, soft, lint-free cloth, then
wipe the surface.

DISCLAIMER

ViewSoni c
cleaners on the monitor screen or case. Some chemical cleaners have been
reported to damage the screen and/or case of the monitor. ViewSonic will not be
liable for damage resulting from use of any ammonia or alcohol-based cleaners.

®

does not recommend the use of any ammonia or alcohol-based

14 ViewSonic P70f

Limited Warranty

VIEWSONIC MONITORS

What the warranty covers:
ViewSonic

warranty period. If a product proves to be defective in material or workmanship during the warranty
period,
product or parts may include remanufactured or refurbished parts or components.

How long the warranty is effective:
ViewSonic

and three (3) years for all labor from the date of the first consumer purchase.

Who the warranty protects:

This warranty is valid only for the first consumer purchaser.

What the warranty does not cover:

1. Any product on which the serial number has been defaced, modified or removed.

2. Damage, deterioration or malfunction resulting from:

3. Removal, installation, and set-up service charges.

How to get service:

1.

2. To obtain service under warranty, you will be required to provide (a) the original dated sales slip, (b)

3. Take or ship the product freight prepaid in the original container to an authorized

4. For additional information or the name of the nearest

Limitation of implied warranties:

THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, WHICH EXTEND BEYOND THE
DESCRIPTION CONTAINED HEREIN INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Exclusion of damages:

VIEWSONIC'S LIABILITY IS LIMITED TO THE COST OF REPAIR OR REPLACEMENT OF THE
PRODUCT. VIEWSONIC SHALL NOT BE LIABLE FOR:

1. DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECTS IN THE PRODUCT, DAMAGES

2. ANY OTHER DAMAGES, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.

3. ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY.

Effect of state law:

This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state. Some states do not allow limitations on implied warranties and/or do not allow the exclusion of
incidental or consequential damages, so the above limitations and exclusions may not apply to you.

Sales outside the U.S.A. and Canada:

For warranty information and service on
contact

ViewSonic Monitor Warranty (V2.0) Release Date: 10-15-1999

®

warrants its products to be free from defects in material and workmanship during the

ViewSonic

a. Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product

modification, or failure to follow instructions supplied with the product.
b. Repair or attempted repair by anyone not authorized by
c. Any damage of the product due to shipment.
d. Removal or installation of the product.
e. Causes external to the product, such as electrical power fluctuations or failure.
f. Use of supplies or parts not meeting
g. Normal wear and tear.
h. Any other cause which does not relate to a product defect.

For information about receiving service under warranty, contact ViewSonic Customer
Support.

your name, (c) your address, (d) a description of the problem, and (e) the serial number of the
product.

service center or

BASED UPON INCONVENIENCE, LOSS OF USE OF THE PRODUCT, LOSS OF TIME, LOSS OF
PROFITS, LOSS OF BUSINESS OPPORTUNITY, LOSS OF GOODWILL, INTERFERENCE WITH
BUSINESS RELATIONSHIPS, OR OTHER COMMERCIAL LOSS, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.

ViewSonic

will, at its sole option, repair or replace the product with a like product. Replacement

color monitors, including the display tubes, are warranted for three (3) years for all parts

ViewSonic

ViewSonic

You will need to provide your product's serial number.

ViewSonic

or your local

.

ViewSonic

ViewSonic

dealer.

’s specifications.

ViewSonic

products sold outside of the U.S.A. and Canada,

.

ViewSonic

service center, contact

ViewSonic

.

ViewSonic P70f 15

Appendix

yp

Safety Guidelines

CAUTION:

CAUTION:

certified for the individual country. Some examples are listed below:

The socket-outlet should be installed near the equipment and be easily accessible.

Use a power cable that is properly grounded. Always use the appropriate AC cord that is

USA................. UL

Canada............. CSA

Germany.......... VDE

Switzerland ..... SEV

Britain ............. BASE/BS

Japan ............... Electric Appliance Control Act

IMPORTANT NOTICE CONCERNING POWER CORD SELECTION

The power cord set for this unit has been enclosed and has been selected according to the country of
destination and must be used to prevent electric shock. Use the following guidelines if it is necessary to
replace the original cord set, or if the cord set is not enclosed.
The female receptacle of the cord set must meet IEC-60320 requirements and may look like (Figure A1
below):

Figure A1

Figure A2

For the United States and Canada

In the United States and Canada the male plug is a NEMA5-15 style (Figure A2), UL Listed, and CSA
Labeled. For units which are mounted on a desk or table, type SVT or SJT cord sets may be used. For
units which sit on the floor, only SJT type cord sets may be used. The cord set must be selected according
to the current rating for your unit. Please consult the table below for the selection criteria for power cords
used in the United States and Canada.

Cord T

For European Countries

In Europe you must use a cord set which is appropriate for the receptacles in your country. The cord set is HAR­Certified, and a special mark that will appear on the outer sheath, or on the insulation of one of the inner conductors.

AC PLUG CORD PRECAUTIONS FOR THE UNITED KINGDOM

FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY.

IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET THEN THE PLUG SHOULD BE
CUT OFF AND DISPOSED OF SAFELY.

THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED INTO AN
APPROPRIATE SOCKET.

If a new plug is to be fitted, please observe the wiring code as shown below.

If in any doubt, please consult a qualified electrician.

WARNING:

IMPORTANT:

Green-and-Yellow: Earth
Blue: Neutral
Brown: Live

If the coloured wires of the mains lead of this appliance do not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:

The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by
the letter E or by the Earth symbol or coloured GREEN or GREEN-AND-YELLOW.

The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the letter N or
coloured BLACK. The wire which is coloured BROWN must be connected to the terminal in the plug which is marked
with the letter L or coloured RED.

If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you
have purchased the product.

e Size of Conductors in Cord Maximum Current Rating of Unit

SJT 18 AWG

SVT 18 AWG

THIS APPLIANCE MUST BE EARTHED.

The wires in this mains lead are coloured in accordance with the following code:

16 AWG
14 AWG

17 AWG

10 Amps
12 Amps
12 Amps

10 Amps
12 Amps

16 ViewSonic P70f

Compliance Information for U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a resi­dential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer­ence to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Warning

To assure continued FCC compliance, the user must use grounded power supply cord and the provided
shielded video interface cable with bonded ferrite cores. If a BNC cable is going to be used, use only a
shielded BNC(5) cable. Also, any unauthorized changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this device.

Notice for Japan

This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information
Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may
cause radio interference. Install and use the equipment according to the instruction manual.

CE Conformity for Europe

The device complies with the requirements of the EEC directive 89/336/EEC as amended
by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility, and 73/
23/EEC as amended by 93/68/EEC Art.13 with regard to “Safety."

ViewSonic P70f 17

NOTES

18 ViewSonic P70f

ViewSonic Corporation
