ViewSonic OptiSync VX710 Specifications

g

g

VX710 LCD Display

17" OptiSync®Slim Bezel Display

Brilliant color in a versatile, stylish display.

The 17" ViewSonic VX710 LCD display offers an ultra-stylish, slim-panel LCD that
delivers dazzling clarity and rich colors at a price that will please you. Advanced
digital technology and optimum 1280x1024 resolution gives you BRILLANT

IMAGES IN A LARGE DI S PLAY AREA. The high brightness, contrast ratio and

ClearMotiv™ broadcast quality 16ms video response time bring your DVDs, games,
video and photos to life with REALISTIC COLOR, D ETAIL AND ACTION. You will
also get precise screen to print colors with sRGB color management. The VX710 is
the innovatively designed LCD that offers lots of extras for the
discerning user without
putting a big dent in your
wallet.

Award-Winning
Company

ViewSonic is the #1
best-selling monitor brand
in the USA, delivering price
and performance leadership.*

Stylish design, elegant display.

>

your connectivity

Multi-mode input technology supports both digital (DVI) and analog
(VGA) signals for ultimate compatibility and configuration flexibility.

>

Stylish slim-bezel design

The full 17" viewable screen in a thin bezel lets you see more without
taking up valuable desktop real estate. The high neck and floating head
design accentuate the visual experience.

>

ClearMotiv technology

Super-fast 16ms video response delivers broadcast-quality full motion
video at 62.5 fps.

>

Ultra-high brightness and contrast

260-nit brightness (typ) and 450:1 contrast ratio (typ) for rich, detailed
images.

digital/analog inputs expand

>

Full 17" viewable screen

>

1280x1024 resolution

>

OnView®controls for
superior screen
adjustability

Screen adjustments are precisely
made via an easy-to-use on-screen
menu.

>

VESA®100mm wall mount
compliant

>

PC and Mac®compatible

>

TCO’99 and ENERGY qualified

Create a Total Desktop Solution

Add ViewMate
to your display for a complete desk­top solution. Choose stylish mice and
wireless keyboards, or turn that display
into a TV with a T V/video processor.

®

Collection accessories

Cuttin

Ed

e

p

VX710 LCD Display

17" OptiSync®Slim Bezel Display

17" COLOR LCD DISPLAY WITH CLEARMOTIV™ TECHNOLOGY

LCD Type 17" Color TFT Active Matrix SXGA LCD

Display Area 13.3" horizontal x 10.6" vertical; 17.0" diagonal

1

2

3

1. Sleek buttons control all major functions

2. Extended neck, floating head design

3. Space-saving slim-line panel design is only 2.4" thick

4. Slim bezel, attractive styling

Available colors:

Black & silver

4

Optimum Resolution
Contrast Ratio 450:1 (typ)
Viewing Angles 160°horizontal, 160°vertical @ contrast ratio > 5
Response Time 16ms (typ)
Light Source Long life, 40,000 hrs. (typ)
Brightness 260 cd/m2 (typ)
Panel Surface Anti-glare

INPUT SIGNAL Video RGB analog (75 ohms, 0.7 Vp-p); DVI-D (TMDS, 100 ohms)

Sync H/V separated (TTL), composite, sync-on-green
Frequency Fh:24~82kHz, Fv:50~85Hz

COMPATIBILITY PC VGA up to 1280x1024 non-interlaced

Mac®** Power Mac™ G3/G4 1280x1024

CONNECTOR Analog 15-pin mini D-sub and DVI-D

Power 3-pin AC plug, (CEE22)

POWER Voltage AC 100–240V, 50–60Hz (auto switch)

Consumption 35W (max)

CONTROLS Basic Power, 1, down, up, 2

OPERATING Temperature 32°—104°F (0°—40°C)
CONDITIONS Humidity 10—90% (no condensing)

DIMENSIONS Physical 388mm x 438mm x 177mm (with stand)
(W x H x D) 15.3" x 17.2" x 7.0" (with stand)

WEIGHT Net 11.0 lb. (5.0 kg) (with stand)

REGULATIONS UL, cUL, FCC-B, CB, CE, ENERGY, NOM, NEMKO/GS(covers TUV/GS),

POWER MANAGEMENT Meets TCO’99 and ENERGY standards
PACKAGE CONTENTS LCD display, power cable, Quick Start Guide, ViewSonic Wizard CD,

WARRANTY One-year limited warranty on parts, labor and backlight for units purchased

®

OnView

Gross 16.8 lb. (7.6 kg) (with stand)

1280x1024

Auto image adjust, brightness, contrast, ViewMatch®color adjust (SRGB,
9300K, 6500K(default), 5400K, user color (RGB), input select (analog, digi­tal), information (resolution, H. frequency, V. frequency, pixel clock, model
number, serial number, manual image adjust (H. size, H. position, V. posi­tion, fine tune, sharpness, scaling, setup menu, language (English, French,
German, Italian, Spanish, Finnish, Japanese, Traditional Chinese, Simplified
Chinese), input priority, resolution notice, OSD position, OSD timeout, OSD
background, touch tone, OSD pivot, memory recall

388mm x 332mm x 62mm (without stand)

15.3" x 13.1" x 2.4" (without stand)

NEMKO ERGO (covers TUV/ERGO, ISO13406-2 & MPR II), TCO’99, GOST-R
20 original copies hygienic, (SASO), PCBC, VCCI, BSMI, CCC, (PSB), (C-TICK),
Argentina-S, PSE (power adapter), Green Mark

15-pin VGA video cable

in the U.S. only. Three-year limited warranty on units purchased outside of
the U.S.

ecifications
s

ViewSonic Corporation’s QMS & EMS have been registered to

ISO 9001 & ISO 14001, respectively, by the British Standards Institution.

ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Phone [phone] or [phone] • In Canada [phone] • Fax [phone]• [e-mail] • ViewSonic.com

*Leading stand-alone, branded monitor by sales (CRT and LCDs combined; iSuppli/Stanford Resources Monitrak®and Flat Panel Monitrak,®4Q04 Report) **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may
vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2005 ViewSonic Corporation. All rights reserved. [12291-00B-01/05] VX710-1

For more product information, visit us on the web at ViewSonic.com
